The information and specifications included in this publication were in effect at the time of approval for printing. Honda Motor Co., Ltd., reserves the right, however, to discontinue or change specifications or design at any time without notice and without incurring any obligation.
Accessories Precautions
The GPS antenna is located in the dashboard. Metallic front or side window tinting can seriously degrade or obstruct GPS reception.
Signal noise from devices such as radar detectors, vehicle tracking devices, remote starters, and additional amplifiers can disrupt the navigation system. If you install any such item, install it away from the navigation display and antenna.
Important Safety Information
WARNING
Using the navigation system while driving can take your attention away from the road, causing a crash in which you could be seriously injured or killed.
Only operate system controls when the conditions permit you to safely do so.
Avoid focusing on the screen or manually operating the system controls while driving.
Enter information before you begin driving or when stopped. As you drive, listen to the audible instructions and use voice commands when possible. Pull to the side of the road if you need more time to look at the screen or operate the controls.
Route guidance may conflict with street closures, road construction, detours, and out-of-date map data.
The system itself may also have limitations. Verify route information by carefully observing roads, signs, and signals. Always use your own judgment and obey traffic laws.
2 System Limitations P. 308
2 System Setup P. 21
Start-up 22 |
Voice Control System 24 |
Interface Settings 27 |
Personal Information 38 |
Routing 53 |
Guidance 62 |
Map 69 |
Data Reset 85 |
On Demand Multi-Use Display™ 86 |
|
|
|
|
|
|
|
2 Navigation P. 87 |
|
|
|
Entering a Destination 88 |
Calculating the Route 112 |
Driving to Your Destination 114 |
Map Menu 120 |
Changing Your Route 126 |
Changing Your Destination 135 |
Resuming Your Trip 138 |
|
2 Audio P. 139
Audio System 140 |
Audio Remote Controls 146 |
Playing SiriusXM® Radio 157 |
Playing a Disc 162 |
Playing an iPod® 181 |
Playing Internet Radio 193 |
2 Bluetooth® HandsFreeLink® P. 207
Bluetooth® HandsFreeLink® 208
2 AcuraLink® P. 253
AcuraLink® 254
2 Rear Entertainment System P. 261
Rear Entertainment System 262 Rear Control Panel Operation 265
2 Other Features P. 283
Trip Computer 284 Calendar 285
2 Troubleshooting P. 291
Troubleshooting 292 Error Messages 298
2 Reference Information P. 305
System Initialization 306 System Limitations 308
2 Voice Commands P. 321
Voice Commands 322
Audio Settings 147 |
Playing FM/AM Radio 151 |
Playing Hard Disc Drive (HDD) Audio 169 |
|
Playing a USB Flash Drive 197 |
Playing Bluetooth® Audio 203 |
Text Message/E-mail 240
Front Control Panel Operation 276 |
Wireless Headphones 280 |
Information Functions 286 |
Multi-view Rear Camera 288 |
Client Assistance 310 |
Legal Information 313 |
Quick Reference Guide P.2
System Setup P.21
Navigation P.87
Audio P.139
Bluetooth® HandsFreeLink® P.207
AcuraLink® P.253
Rear Entertainment System P.261
Other Features P.283
Troubleshooting P.291
Reference Information P.305
Voice Commands P.321
Index P.337
Guide Reference Quick
Navigation |
You can select any place/landmark as a destination by using voice control or the Interface Dial. The navigation |
|
|
|
system gives you turn-by-turn driving directions to your destination. |
Store home address (P46)
Register 1 home address.
Store contacts (P39)
Store up to 200 contacts in 2 address books.
Enter destination (P88)
Select your destination using 12 methods.
Select route (P113)
Set route preferences and select one of 3 routes.
Track route (P114)
Follow your route in real-time with voice guidance.
Subscription service
AcuraLink Real-Time Traffic™ (P124)
Bypass congestion and traffic incidents.
Avoid certain areas (P134)
Set streets and areas to detour around.
Add waypoints (P128)
Add up to 4 “pit stops” along your route.
2
Audio |
The advanced audio system provides clear, well-defined sound and makes the most of your music. |
|
|
|||||||||||||||||
|
|
|
||||||||||||||||||
|
Enjoy listening to a variety of audio sources, such as: |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
FM/AM Radio (P151) |
iPod® (P181) |
|
|
||||||||||||||||
|
SiriusXM® Radio (P157) |
Internet Radio (P193) |
|
|
||||||||||||||||
|
Compact Disc (P162) |
USB Flash Drive (P197) |
|
|
||||||||||||||||
|
Hard Disk Drive (HDD) (P169) |
Bluetooth® Audio (P203) |
|
|
||||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
AcuraLink® (P254)
AcuraLink® provides you with important information and messages between your vehicle and
Acura.
Voice Control (P24)
Use voice commands for safer system control while driving. You can operate all key functions of the navigation, audio, Bluetooth® HandsFreeLink®, and climate control systems.
Bluetooth® HandsFreeLink® (P208)
Pair a compatible cell phone to receive incoming and make outgoing calls. You can operate the phone features without ever taking your hands off the wheel.
Rear Entertainment System (P261)
Rear seat passengers can enjoy a completely separate entertainment source than front passengers, including movies, games, and other audio choices.
Guide Reference Quick
3
Guide Reference Quick
1 PHONE Button (P210) |
Navigation Screen |
On Demand Multi-Use |
|
|
DisplayTM |
2 NAV Button (P88) |
|
|
|
3 BACK Button |
|
|
|
4 a(Display Mode) |
|
|
lc Microphone (P24) |
Button (P74) |
|
|
|
5 Interface Dial/ENTER |
|
|
ld Left Selector |
Button (P7) |
|
|
Wheel (P146) |
6 INFO Button |
|
|
le SOURCE Button |
|
|
(P146) |
|
7 MENU Button |
|
|
|
|
|
|
|
8 SETTINGS Button |
|
|
|
|
|
|
lf h(Pick-Up) Button (P208) |
Models with RES |
|
|
lg J(Hang-Up/Back) |
NAV |
FRONT |
REAR |
Button (P208) |
9 FRONT AUDIO Button |
AUDIO |
AUDIO |
|
|
|
lh d(Talk) Button (P5) |
|
0 REAR AUDIO Button |
|
|
|
|
|
|
|
(P276) |
|
|
Models without RES |
lb REAR 9(Power) Button |
|
|
|
REAR |
|
li AUDIO Button |
|
|
|
||
Navigation |
|
|
|
Rear Entertainment System |
|
|
|
Voice Control |
|
|
|
Bluetooth® HandsFreeLink® |
|
|
|
Audio |
|
|
|
4
Voice Portal Screen
aPress and release the d(Talk) button on the top screen of any mode.
The system prompts you to say a voice
command and gives examples. Press and release the d(Talk) button again to bypass this prompt.
The system beeps when ready for a command. Press the J(Hang-Up/ Back) button to cancel.
Available voice commands are highlighted on the screen.
bSay a voice command (e.g., Address). After that, follow the voice prompt and say a voice command.
The audio system is muted during voice control mode.
You can use other voice commands on the Voice Portal screen. Voice Command Index (P322)
Say d“Voice Help” to enter supported commands for the current screen. A
voice help tutorial is also available. Voice Help (P16)
During the voice control mode, press and hold the J(Hang-Up/Back) button to return to the Voice Portal screen.
Set Voice Prompt to Off to bypass the voice prompt. Voice Recognition Settings (P26)
Carefully read the usage note for the voice control. Voice Control System
(P24)
On the Menu Screen
aPress and release the d(Talk) button on the menu or setting screen.
The system prompts you to say a voice
command and gives examples. Press and release the d(Talk) button again to bypass this prompt.
Available voice commands are highlighted on the screen.
bSay a voice command.
Say d“Voice portal” to display the Voice Portal on any screen.
Say d“Voice Help” to enter supported commands for the current screen. A voice
help tutorial is also available. Voice Help
(P16)
Guide Reference Quick
5
Guide Reference Quick
Shortcuts |
|
|
*: See the Owner's Manual. |
Places (P44) |
Phone (P220) |
Audio (P144) |
Climate* |
Audio Source
Select to change an audio source.
Source List Icons
Presets
Select to store a station.
To listen to a stored station, select 1-6 (AM) or 1-12 (FM).
More
Select to display the menu items.
Menu Items
AM, FM, SiriusXM®, Pandora® , AhaTM
bn : Select the preset station (AM/FM/Pandora®/AhaTM) or category (SiriusXM®). cx : Select to search the selected band for a station with a strong signal. (AM/FM)
Select the channel. In channel mode, select and hold to change the channel rapidly. (SiriusXM®) Select a song (Pandora®) or a contents (AhaTM).
CD, HDD, USB flash drive, Bluetooth® Audio
bn : Select nto skip to the next folder, and bto skip to the beginnig of the previous
folder.
cx : Select to change tracks. Select and hold to move rapidly within a track.
iPod®
Album bar : Select an album.
cx : Select to change tracks. Select and hold to move rapidly within a track.
6
Rotate dial i
Changes scale
Map screens
You will see these icons in each chapter.
They represent how you can operate the Interface Dial.
Press ENTER
Rotate dial
Press ENTER u
Selects function Selects map icon
Map screens
FRONT AUDIO
Guide Reference Quick
|
Move up Move left |
Move down Move right |
|
|||||||||
Highlights menu options |
Move |
|
|
|
Selecting Icon |
|||||||
Menu screens |
eup rdown wleft yright |
Selects highlighted option |
||||||||||
|
||||||||||||
|
Scrolls map |
Selects labeled |
Menu screens |
|||||||||
|
|
|||||||||||
|
(8 directions) |
function |
|
|||||||||
|
Map screens |
Menu screens |
|
|||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
7
Guide Reference Quick
8
You can enter information (e.g., city names, street names, personal names, and business names comprising letters, numbers, and symbols) when prompted on input screens by two different methods.
Using Voice Control
When you see din this manual, voice commands are available for that feature.
Say the letter, number, or symbol (e.g., say d“A”).
Use spelling assist (e.g., say d“Alpha” to enter the letter “A” or d“Hyphen” to enter a hyphen).
The system beeps if you say an unavailable (grayed out) letter or number.
If a voice command is not recognized, a list is displayed with possible options.
On list screens:
Say the number of the list item (e.g., say d“Five” to select item 5).
Say d“Up” or d“Previous” to scroll up one page.
Say d“Down” or d“Next” to scroll down one page.
Using the Interface Dial
Rotate ito highlight a character.
Select to display upper/lower case characters.
Select Sym to display symbols and accented characters.
Select Edit (or move e) to edit the entered characters. Press uto enter the highlighted character.
Move yto select Space to enter a space character.
Move wto select Delete to remove the last entered character.
Number of Hits
On input search screens, the number of hits in the map database is displayed. Move rto select OK to display a list of possible entries.
You can also use the touch screen to enter information.
Scrolling through lists or tabs is limited while the vehicle is moving.
Certain screen functions are limited or inoperable while the vehicle is moving. For these functions, use available voice commands or pull over to proceed.
GPS signal strength
Best reception
Good reception
No icon: Poor/No reception
Map scale (P80)
Feature areas
Park |
Airport/Business |
Hospital |
Water Area |
Shopping Mall |
Cemetery |
Golf Course |
University |
Map orientation (P76)
North up |
3D map |
Heading up
Current map scale
Current street name
Current vehicle position
(P78)
Streets
Freeways
State routes Verified streets Unverified streets One-way streets
AcuraLink® Message icon
(P14)
AcuraLink signal indicator
Landmark icons (P71)
Acura dealer
Honda dealer
ATM
School
Parking lot
Parking garage
Grocery store
Hotel/Lodging
Gas station
Hospital
Post office
Restaurant
Freeway exit information
Guide Reference Quick
9
Guide Reference Quick
During route guidance, route information is displayed on the map screen and guidance screen. Press the NAV button to toggle between the map and guidance screen.
Map Screen
Tracking dots |
Calculated route |
(P117) |
(P114) |
Guide to destination or |
Next guidance |
waypoint |
indicator |
|
Distance to the next |
Estimated time to |
guidance point. |
destination (waypoint) |
Calculated route |
|
(unverified roads) |
Distance to destination |
(P116) |
|
|
(waypoint) |
Destination icon |
Distance of the actual route. |
|
|
Waypoint (P128) |
Day or Night Mode
Press the a(Display mode) button to manually switch between day and night mode.
|
|
|
|
|
|
Day mode |
|
Night mode |
|
|
|
|
|
|
Multi-information Display
Guidance Screen
Guidance point
Guide to destination or waypoint
Estimated time to destination (waypoint)
Distance to destination (waypoint)
Distance of the actual route.
|
Turn-by-Turn Directions |
|||
Guidance indicator |
The next guidance point appears on the |
|||
Street name of |
multi-information display. |
|||
|
|
|
|
|
guidance point and |
|
|
|
|
distance to the |
Remaining |
|
Street name of next |
|
guidance point. |
distance |
|
guidance point |
|
Lane guidance |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Guidance point
No entry icon
Next driving maneuver is approaching
10
The “Home” feature automatically routes you to your home address from any location simply by selecting Go Home, or saying d“Go Home.”
Storing Your Home Address
a Press the SETTINGS
SETTINGS
button.
bRotate ito select Navi Settings. Press u.
cRotate ito select Edit Go Home. Press u.
dRotate ito select Name. Press u.
e Enter a name.
fRotate ito select Address. Press u.
gEnter an address.
hRotate ito select Phone No. Press u.
iEnter a phone number.
jMove rand rotate ito select OK. Press u.
Going Home
a From the map screen,
press the MENU button. |
MENU |
bRotate ito select Go Home. Press u.
Alternatively, you can say d“Go Home” from any screen. Your home address is displayed on the Calculate Route screen.
cRotate ito select Set as Destination. Press u.
The following voice commands are available: say d“Go Home.”
Guide Reference Quick
11
Guide Reference Quick
12
Enter your destination using one of several methods, then follow route guidance on the map or guidance screen to your destination. You can also perform these steps using dvoice commands.
a From the map screen,
press the MENU button. |
MENU |
b Rotate ito select Address. Press u.
c Rotate ito select Street. Press u.
dEnter the name of your destination street.
eRotate ito select your destination street from the list. Press u.
fEnter the street number. Move rto select OK when finished.
gIf there is more than one city with the
specified street, a list of cities is displayed. Rotate ito select the desired city from the list. Press u.
hRotate ito select Set as Destination. Press u.
Route guidance to the destination begins.
View Routes: Choose one of three routes.
Route Preference: Choose Max or Min for the five settings.
You can alter your route by adding waypoints to visit, adding streets to avoid, or changing your destination during route guidance.
Adding a Waypoint
(“Pit Stop”)
You can add up to four waypoints along your route. (P128)
aFrom the map screen, press the MENU button.
bRotate ito select Destination List. Press u.
cRotate ito select Add New Destination. Press u.
dRotate ito select Find Along Route. Press u.
eRotate ito select location and search method. Press u.
Search Around: Search around a location.
Search Along: Search between two locations.
fSelect the icon category and location to add to the Destination List when prompted. Edit the order of destinations if necessary.
gMove rand rotate ito select Start Route. Press u.
Changing Your
Destination
There are four methods you can use to specify a new destination during route guidance.
Say d“Find Nearest…” (P135)
Searches for the nearest place/landmark on the map screen (e.g., d“Find nearest gas station”).
Say d“Go Home” (P11)
Routes to your home address.
Selecting an icon on the map (P136) Scroll the map to position the cursor over
a place/landmark icon or a new area on the map. Press utwice.
Entering a new destination (P137) Press the MENU button. Move wto select Destination and enter a new destination.
Canceling Your Route
aPress the MENU button.
bRotate ito select Cancel Route. Press u.
From the map screen:
aPress uon the map screen.
bRotate ito select Cancel Route. Press u.
Guide Reference Quick
13
Guide Reference Quick
AcuraLink® Messages
AcuraLink® provides a direct communication link between you and Acura. It sends and receives several kinds of messages through the Acura server.
The following features are available:
Vehicle feature guide
Operating quick tips
Safety and maintenance information
Diagnostic information
Dealer appointment and maintenance reminders
AcuraLink Real-Time Traffic™
Displays continuously updated traffic information and recalculates your route in response to traffic flow, incidents, or road closures.
(P124)
Traffic incident icons
Congestion
Incident
Weather
Construction
Road Closed
Traffic status indicator (P124)
Traffic information available
Traffic information off or map scale too large
No icon: Out of coverage area
Traffic flow indicator
Heavy
Moderate
Free-flow
NOTE AcuraLink Real-Time Traffic™ is a subscription service. For more information, contact an Acura dealer or visit owners.acura.com.
14
The rear passengers can enjoy a wide array of audio/visual sources with the Rear Entertainment System (RES). The rear passengers can use wireless headphones and operate the system with the rear control panel.
Overhead Screen and Rear Control Panel
RES |
Select the audio source. |
|
|
|
|
|
|
Press the buttons to |
Pull down the bottom edge of Press the Release button to |
select items. |
|
|
||
the screen. |
remove the rear control panel. |
|
|
|
Ultrawide RES
Press the Open button to open and pull down the screen.
9(Power) Button
Turn the system on or off (when rear power is turned on).
(Light-up) Button
Illuminate the buttons on the rear control panel.
Select the audio source.
Rotate the Interface Dial Press the Release button to to select items.
remove the rear control panel.
CH/FOLDER Bar |
CATEGORY Bar |
||||
Select a channel (Radio) or a |
Select a category (SiriusXM®). |
||||
folder (Disc/USB). |
|
|
|
|
(Play/Pause) Button |
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
or pause the playback. |
TUNE/SKIP Bar |
Play |
||||
Find stations (FM/AM). Skip to |
TITLE SCROLL Bar |
||||
start/end of tracks, or press |
Display track title, artist, and |
||||
and hold to fast reverse/fast |
other text information. |
||||
forward (Disc/USB/DVD). |
|
|
|
|
|
Basic Operation
aOpen the overhead screen.
bPress the REAR 9
(Power) button on |
REAR |
the front control |
|
panel. |
|
c Select the audio source.
RES: Press the desired button on the rear control panel.
Ultrawide RES: Press the SOURCE button and rotate the Interface Dial on the rear control panel to select an audio source. Press the ENTER button.
Guide Reference Quick
15
Guide Reference Quick
16
This navigation system comes with voice help, which shows you what command to say when using the voice command functions.
Command Help
aPress and release the d(Talk) button.
bSay d“Voice Help.”
The voice help screen is displayed.
The d“Voice Help” command is available on most screens.
cPress and release the d(Talk) button.
dSay one of the options for a list of
available commands by category (e.g., d“Navi commands”).
ePress and release the d(Talk) button.
fSay one of the options for a list of
available commands by category (e.g., d“Route commands”).
gThe system displays a list of all
available commands for the category. Press uto hear the list read aloud.
Getting Started Tutorial
aMove rand rotate ito select
Getting Started on the voice help screen. Press u.
For “Voice Settings” and “All
Commands.” (P321)
bPress uto have the system read the tips for the voice control.
Rotate ito read the tips.
Move wor yto display the previous/ next page.
Troubleshooting
Why does the vehicle position icon on the map “lag” a short distance behind my actual position, especially at intersections?
This is normal. The navigation system is unaware of the width of intersections. Large differences in vehicle position can indicate a temporary loss of the GPS signal.
Why does the “time to destination” display sometimes increase even though I am getting closer to my destination?
The “time to destination” is based on your actual road speed and traffic conditions to give you a better estimate of arrival time.
How do I specify a destination when an entered city or street could not be found?
Try entering the street first. Some cities are lumped in with a major metro area. In rural “unverified” areas or new subdivisions, streets may be missing or only partially numbered.
For more Information (P291)
|
|
|
Quick |
|
|
|
GuideReference |
|
|
How do I turn on the navigation system voice guidance? |
|
|
|
|
|
|
|
1. Press the SETTINGS button. Rotate ito select System |
|
|
|
|
|
|
|
|
|
|
|
Settings and press u. Check that Volume is not set to |
|
|
|
0. |
|
|
|
||
|
|
2. Move wor yto select Voice Rec. Set Voice Prompt |
|
|
|
to On if you want the system to provide confirmations |
|
|
|
and system prompts. |
|
|
|
|
|
|
|
My battery was disconnected or went dead, and the |
|
|
|
|
|
|
|
navigation system is asking for a code. Where do I find it? |
|
|
|
In most cases, you do not need to enter a code. Simply |
|
|
|
|
|
|
|
|
|
|
|
press and hold the 9(Power) button for two seconds; the |
|
|
|
system should reactivate. |
|
|
|
|
|
|
|
2 System Initialization P. 306 |
|
17
This section explains different methods on how you can easily find information in this manual.
Searching the Table of Contents
(P1)
Two types of Tables of Contents help you find your desired information.
Searching the Index (P337)
Menu items displayed on the navigation screen (e.g., Address Book) can be found individually in the Index.
18
More Detailed |
Contents |
Table of Contents |
Chapter Contents |
First, find the general chapter related to what you are looking for (e.g., entering a destination from the Address Book).
Then, go to that chapter to view a more specific table of contents.
This more detailed table of contents shows you exactly what information is listed by section and title.
The Index consists of main
terms and sub-entries. The sub-entries help you get to the desired page depending
on what you are looking for.
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Go to the |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Navigation Screen |
|
|
|
|
|
|
|
|
|
Index |
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Next Page |
Menu Tree
The menu tree helps guide you through the system’s menu options. To get to your desired function, follow the menu tree in order of the steps shown.
NOTE:
All menu options can also be activated with voice commands.
After following the menu tree, step-by-step instructions explain how to achieve the desired result.
MENU button
FRONT |
REAR |
AUDIO |
AUDIO |
SETTINGS |
|
Press the hard button on the |
Select the menu option with the |
system control panel. |
Interface Dial. |
Press the MENU button. |
Rotate ito select Address Book. |
|
Press u. |
Sample pages and images in this section may differ from the actual ones.
19
20
This section describes the start-up procedure and the navigation and
setup functions.
Start-up .............................................................. |
22 |
PIN Numbers .................................................... |
47 |
Color ............................................................... |
73 |
Voice Control System........................................ |
24 |
Previous Destination ......................................... |
48 |
View (Map Orientation).................................... |
76 |
Command Input .............................................. |
24 |
Category History .............................................. |
49 |
3D Angle Adjustment ...................................... |
77 |
Voice Recognition ............................................ |
25 |
Download POI .................................................. |
50 |
Straight Line Guide .......................................... |
77 |
Voice Recognition Settings............................... |
26 |
Routing............................................................... |
53 |
Current Location.............................................. |
78 |
Interface Settings .............................................. |
27 |
Route Preference.............................................. |
54 |
Map Legend .................................................... |
79 |
Display Settings................................................ |
27 |
Unverified Routing ........................................... |
56 |
Display Tracking............................................... |
83 |
Sound and Beep Settings ................................. |
28 |
Traffic Rerouting .............................................. |
58 |
Correct Vehicle Position ................................... |
84 |
Clock Adjustment ............................................ |
29 |
Edit POI Search Radius Along Route.................. |
59 |
Data Reset ......................................................... |
85 |
Wallpaper Settings ........................................... |
31 |
Avoided Area ................................................... |
60 |
Defaulting All the Settings ............................... |
85 |
Unit Settings .................................................... |
34 |
Guidance ............................................................ |
62 |
On Demand Multi-Use Display™ ..................... |
86 |
Language Settings............................................ |
35 |
Guidance Mode ............................................... |
63 |
Changing the Screen Settings .......................... |
86 |
Background Color............................................ |
36 |
Street Name Guidance ..................................... |
65 |
|
|
Header Clock Display ....................................... |
37 |
Non-map screens ............................................. |
66 |
|
|
Personal Information ........................................ |
38 |
Guidance Point................................................. |
67 |
|
|
Address Book |
39 |
Estimated Time................................................. |
68 |
|
|
Map |
69 |
|
|
||
Home Address ................................................. |
46 |
|
|
||
|
|
Showing Icons on Map..................................... |
71 |
|
21 |
|
|
|
|
|
Start-up
Setup System
The navigation system starts automatically when you set the power mode to ACCESSORY or ON. At start-up, the following Confirmation screen is displayed.
1. Press uto select OK.
If you do not select OK, the map screen is displayed after a certain period of time.
Your current position is displayed on the map screen.
2. Press the NAV button if a different mode is selected.
Your current position is displayed on the map screen.
1 Start-up
If the navigation system loses power at any time, you may need to press and hold the 9(Power) button for more than two seconds, or you may be prompted for the five-digit security code.
2 System Initialization P. 306
At start-up, the driver’s keyless access remote is automatically detected and the address book settings, setup preferences, wallpapers, and audio settings for that driver (e.g., Driver 1) are loaded.
“OK” on the Confirmation screen cannot be selected by using a voice command.
22
■Limitations for Manual Operation
Disabled option |
Certain manual functions are disabled |
||
or inoperable while the vehicle is in |
|||
|
|
||
|
|
||
|
|
motion. You cannot select a grayed- |
|
|
|
out option using the Interface Dial |
|
|
|
until the vehicle is stopped. |
|
|
|
Voice commands are still operable |
|
|
|
while the vehicle is in motion. |
Start-up
Setup System
23
Voice Control System
Setup System
Your vehicle has a voice control system that allows hands-free operation of most of the navigation system functions.
The voice control system uses the d(Talk) and J(Hang-Up/Back) buttons on the steering wheel and a microphone near the map lights on the ceiling.
A “Getting Started” feature provides a tutorial that explains how to use the voice control system.
2 Getting Started Tutorial P. 16
Command Input
If the system does not understand a command or you wait too long to give a command, the system asks you to repeat the command.
When you give a command, the system generally either repeats the command as a confirmation or asks you for further information. If you do not wish to hear this feedback, you can turn it off. However, listening to the feedback will help familiarize you with the way the system expects commands to be phrased.
If the system cannot perform a command or the command is not appropriate for the screen you are on, the system beeps.
On character input screens, a list of possible characters is displayed if the system does not recognize your command.
You can find out which voice commands are available for a particular screen using the d“Voice Help” command. The system will display and read the list of available commands to you.
2 Voice Help P. 16
1 d(Talk) Button
When you press the d(Talk) button, the system prompts you to say a voice command and gives examples. Press and release the d(Talk) button again to bypass this prompt and give a command.
1 Command Input
The audio system is muted while using the voice control system.
24
Voice Control SystemVoice Recognition
Voice Recognition
To achieve optimum voice recognition when using the navigation voice control system:
•Make sure the correct screen is displayed for the voice command that you are using.
2 Voice Commands P. 322
•Close the windows and moonroof.
•Adjust the dashboard and side vents so air does not blow onto the microphone on the ceiling.
•Speak clearly in a clear, natural speaking voice without pausing between words.
•Reduce any background noise if possible. The system may misinterpret your command if more than one person is speaking at the same time.
•Refer to the Voice Help feature.
2 Voice Help P. 16
1 Voice Recognition
The voice control system can only be used from the driver’s seat because the microphone unit removes noises from the front passenger’s side.
Setup System
25
Setup System
Voice Control SystemVoice Recognition Settings
Voice Recognition Settings
H SETTINGS button System Settings Voice Rec
Rotate ito select an item. Press u.
The following items are available:
•Volume: Adjusts the voice prompt volume level.
•Voice Prompt: Turns the voice prompt on or off. On (factory default): Provides the voice prompts. Off: Disable the feature.
•Song by Voice: Turns the Song By VoiceTM on or off.
2 Song By VoiceTM (SBV) P. 188
•Song by Voice Phonetic Modification: Modifies a voice command of music stored in the HDD or an iPod®.
2 Phonetic Modification P. 190
•Phonebook Phonetic Modification: Modifies a voice command for the phonebook.
2 Phonebook Phonetic Modification P. 223
26
Interface Settings
Display Settings
H SETTINGS button System Settings Display
Adjusts the screen’s preferences.
1. Rotate ito select an item. Press u.
2. Rotate ito make the adjustment. Press u.
The following items are available:
•Sync Display Brightness: Selects whether the display brightness synchronizes with the instrument panel brightness.
•Brightness: Adjusts the screen’s brightness.
•Contrast: Adjusts the screen’s contrast.
•Black Level: Adjusts the screen’s black level.
1 Display Settings
You can set separate daytime and nighttime settings for Brightness, Contrast, and Black Level. Adjust each setting when the display is in either daytime or nighttime mode.
Setup System
27
Setup System
Interface SettingsSound and Beep Settings
Sound and Beep Settings
H SETTINGS button System Settings Sound/Beep
Changes the system sound and beep settings.
Rotate ito select an item. Press u.
The following items are available:
•Volume: Adjusts the navigation system volume level.
•Interface Dial Feedback: Sets if and when the system reads aloud a selection made using the Interface Dial.
On: Always reads the selection. Off: Disables the feature.
Auto (factory default): Reads the selection only when the vehicle is moving.
•Message Auto Reading: Selects whether the system automatically reads out messages, and, if selected, whether only when driving.
On: Always reads the message. Off: Disables the feature.
Auto (factory default): Reads the message only when the vehicle is moving.
•Verbal Reminder: Turns the verbal reminders on and off. On: Sets the verbal reminders.
Off: Disables the feature.
1 Sound and Beep Settings
Volume
If you set Volume to 0, you will not hear route guidance or voice command confirmations.
If you then select Voice in the Map Menu, you will hear route guidance at the default volume.
Interface Dial Feedback
You can use this feature to minimize the need to look at the screen while operating the Interface Dial.
28
Interface SettingsClock Adjustment
Clock Adjustment
H SETTINGS button System Settings Clock
Set the automatic adjustment of the system clock for daylight saving and international time zones.
Rotate ito select an item. Press u.
The following items are available:
•Clock/Wallpaper Type: Changes the clock display type and the wallpaper type.
2 Setting the Clock Type P. 30
•Clock Adjustment: Adjust the current time manually.
2 Setting the Clock P. 30
•Clock Format: Sets the time notation to either 12-hour clock (12H, factory default) or 24-hour clock (24H).
•Auto Time Zone: The navigation system automatically adjusts the clock when driving through different time zones.
On (factory default): Adjusts the clock automatically. Off: Disables the feature.
•Auto Daylight: The navigation system automatically adjusts the clock (“spring ahead” or “fall back” by one hour) when a daylight saving time change occurs. On (factory default): Adjusts the clock automatically.
Off: Disables the feature.
•Clock Reset: Resets the settings of all items in the Clock group.
1 Clock Adjustment
Auto Time Zone
If you live and work in two different time zones, you may want to turn Auto Time Zone to OFF. When driving near a time zone boundary, the displayed time zone may fluctuate between the two zone times.
Auto Daylight
This function is not activated in areas that have not adopted daylight saving time, even if you have set Auto Daylight to ON.
You can turn the clock display in the navigation screen on and off.
2 Header Clock Display P. 37
Setup System
29
