Actiontec T3200M User Manual

Wireless 11ac Bonded VDSL2

Modem Gateway with MoCA 2.0

Model # T3200M

User Guide

xxxx-xxxx-000 rev. 1

Table of Contents

Getting Started With the Gateway 4

Package Contents 5
Minimum System Requirements 5
Features 5
Getting to Know the Gateway 6
Connecting the Gateway 9

Accessing the Home Screen 11

Accessing the Home Screen 11
Icon Bar 13
Connection Status 13

Checking the Gateway’s Status 14

Accessing the Status Screens 14
Connection Status 15
xDSL Status 16
WAN Ethernet 17
Routing Table 17
Firewall Status 18
NAT Table 19
Wireless Status 19
Modem Utilization 21
LAN Status 22
ARP Table 23
Interface Statistics 23
Multicast Statistics 24
System Log 24

Configuring Wireless Settings 25

Accessing Wireless Settings 25
Basic Settings 26
Advanced Settings 27
WPS 28
MAC Address Control 29
WDS 30

i

i

Table of Contents

Configuring Firewall Settings 31

Accessing Firewall Settings 31
Firewall 32
IPv6 Firewall 33
Port Forwarding 34
Applications 35
DMZ Hosting 36
IPv6 DMZ Hosting 37
UPnP 38

Advanced Settings 39

Accessing the Advanced Setup Screens 39
Services Blocking 40
Website Blocking 41
Scheduling Access 41
WAN IP Addressing 42
IPv6 WAN Settings 43
LAN IP Settings 44
IPv6 LAN Settings 45
DHCP Reservation 45
Dynamic DNS 46
DNS Host Mapping 47
Port Bridging 47
Admin Password 48
Storage Device Info 48
Samba Configuration 49
Voice Advanced Setting 49
Voice Basic Setting 50
Voice Debug Setting 51
Reboot 51
Restore Defaults 52
Check for New Firmware 52
Speed Test 53
Ping Test 54
Tcpdump Debug 55
Iperf Test 56
IPv6 Ping Test 57
Traceroute 58

ii

ii

Table of Contents

IPv6 Traceroute 58
Time Zone 59
Language Settings 59
DNS Cache 60
IGMP Setting 60
Upgrade History 61
SIP ALG 61
Tool Box 62
DLNA 62
xDSL Diagnostics 63
User’s Manual 63

Specifications 64

General 64
Wireless Operating Range 65
LED Indicators 65
Environmental 65

Notices 66

Regulatory Compliance Notices 66
Modifications 66
GPL (General Public License) 67

iii

Getting Started
With the Gateway

Congratulations on purchasing the T3200M Wireless 11ac Bonded VDSL2 Modem
Gateway with MoCA 2.0. The Gateway is a single platform device that supports
universal WAN access, FTTN, FTTdp, FTTB, or FTTP. With support for advanced

802.11ac 4x4 WiFi and bonded MoCA 2.0, the Gateway enables blazing fast HD
video streaming, with multi-channel HD video throughput. The Gateway also
offers an unprecedented level of security, helping protect your network resources. It
has also been designed to delver unparalleled WiFi performance, using dual-band
WiFi supporting speeds up to 2.3 Gbps.

1

4

Introduction

Package Contents

• Black Power adapter

• Yellow cable(Ethernet, 6ft.)

• White cable (Ethernet, 10ft.)

• Quick Start Guide

• Installation Guide

• Wall-mount template

• Vertical stand

Minimum System Requirements

• Active ADSL2+ service

• Computer with an 10 Mbps or 10/100/1000 Mbps Ethernet connection

• Microsoft Windows 10, 8, 7; Mac OS OS X+

• TCP/IP network protocol installed on each computer

Features

• ADSL2+, VDSL2, G.fast, and Fiber in a single CPE

• Dual Band WiFi delivering up to 2.3 Gbps with 802.11ac 4x4 5GHz and

802.11n 3x3 2.4GHz

• MoCA 2.0 with Channel Bonding and Turbo Mode

• Optimized for IPTV and Video over WiFi

• Integrated VoIP with 2 FXS Ports

• SFP cage for G.fast or EPON/GPON ONT modules

5

Telus T3200M Gateway

Getting to Know the Gateway

This section contains a quick description of the Gateway’s lights, ports, and other
features. The Gateway has several indicator lights (LEDs) and a button on its front
panel, and a series of ports and switches on its rear panel.

Front Panel

The front panel of the Gateway features 2 LEDs (WAN and Wireless), and a WPS
(Wireless Protected Setup) button.

WAN LED

The WAN LED illuminates when the Gateway is properly connected to a WAN
Internet connection.

Wireless LED

The Wireless LED illuminates when the Gateway’s wireless network is operating
and properly configured.

WPS Button

The WPS button is used when connecting a wireless device to the Gateway’s
wireless network using WPS.

6

Introduction

Rear Panel

The rear panel of the Gateway features 14 ports, and a Reset button.

Power Port

The Power port is used to connect the Power cord (Model No.
NBS40C120300VU, made by NetBit, or Model No. CDS036-W120U, made by
Actiontec) to the Gateway.

Reset Button

Depressing the Reset button for 10 seconds will restore the Gateway’s factory
default settings. The reset process will start after releasing the button.

7

Telus T3200M Gateway

Coax Port

The Coax port is used to connect the Gateway to a coaxial connection via
coaxial (MoCA) cable.

SFP Cage

The SFP cage is used to connect the Gateway to a service provider connection
via optical fiber cable.

WAN Ethernet Port

The WAN Ethernet port is used to connect the Gateway to a WAN connection
via an Ethernet cable.

LAN Ethernet Ports (4)

The LAN Ethernet ports are used to connect computers to the Gateway via
Ethernet cable. The Ethernet ports are 10/100/1000 Mbps auto-sensing ports,
and either a straight-through or crossover Ethernet cable can be used when con­necting to the ports.

USB Ports (2)

The USB ports are used to connect the Gateway to a USB device.

DSL Ports (2)

The DSL ports are used to connect the Gateway to a DSL wall outlet via DSL
cable.

VoIP Ports (2)

The VoIP ports are used to connect the Gateway to a telephone or other com­munication device via phone cable.

WARNING! Do not unplug the Power cord from the Gateway
during the reset process. Doing so may result in permanent damage
to the Gateway.

8

Introduction

Connecting the Gateway

There are many variables involved when connecting the Gateway, depending on the
type of Internet service available. The figure below shows all of the possible connec­tions available for the Gateway.

Connecting a Computer to the Gateway

To connect a computer to the Gateway to access the Gateway’s graphical user inter­face (GUI):

1. Get the Gateway and black Power cord from the box.

2. Plug the black Power cord in the black port on the back of the Gateway and

then into a power outlet.

3. Turn the Gateway on.

4. Plug the yellow Ethernet cable from the box into one of the four yellow

Ethernet ports on the back of the Gateway.

9

Telus T3200M Gateway

5. Make sure the computer is powered on, then plug the other end of the yel-

low Ethernet cable into an Ethernet port on the computer.

6. Make sure at least the LED on the LAN port into which the Ethernet cable

is plugged steadily green. This may take a few moments.

7. The computer should either be configured with a statically defined IP address

and DNS address, or instructed to automatically obtain an IP address using
the Network DHCP server. The Gateway is set up, by default, with an active
DHCP server, and it is recommended to leave this setting as is.

10

Accessing the
Home Screen

This chapter gives a short overview of the Home screen of the Gateway’s graphical
user interface (GUI).

Accessing the Home Screen

To access the Home screen:

1. Open a Web browser on computer connected, via Ethernet cable, to one of the

Gateway’s LAN ports. In the Address text box, type:
http://192.168.1.254
then press Enter on the keyboard.

2

11

Telus T3200M Gateway

2. The Gateway’s Home screen appears.

3. Enter the username “admin” and the password found on the sticker on the back of the

Gateway in the Username and Password text boxes at the top right side of the screen,
then click Login.

The Gateway’s GUI is now accessible.

12

Home Screen

Icon Bar

At the top of the Home screen is the Icon Bar. Here, you can quickly access the
other four main sections of the Gateway’s GUI by clicking on the appropriate icon:
Status (see chapter x for more details); Wireless Setup (see chapter x for more
details); Firewall (see chapter x for more details); Advanced Setup(see chapter x for
more details). Clicking Home in any other screen generates the Home screen.

Connection Status

The bottom of the Home screen consists of connection and device information
relating to the Gateway. There are no configurable options here.

13

Checking the
Gateway’s Status

This chapter explains the options available on the Status screens, which
display information about the Gateway’s network connections.

Accessing the Status Screens

To access the Gateway’s Status screens:

1. Open a Web browser. In the Address text box, type:

http://192.168.1.254

then press Enter on the keyboard.

2. The Gateway’s Main screen appears. Click the Status icon.

3

14

Status

3. The Connection Status screen appears.

From here, all the Status screens can be accessed from the menu on the left.

Connection Status

Clicking Connection Status from any Status screen generates the Connection Status
(see figure, above). Information concerning the devices connected to the Gateway’s
network, whether wired or wireless, is displayed here, along with the connected
device’s IP address, MAC address, and (if applicable) IPv6 address.

15

Telus T3200M Gateway

xDSL Status

Click xDSL Status from any Status screen to generate the xDSL Status screen. This
screen displays the Gateway’s DSL connection parameters.

16

Status

WAN Ethernet

Click WAN Ethernet from any Status screen to generate the WAN Ethernet Status
screen. This screen displays the Gateway’s WAN (wide access network) parameters.

Routing Table

Click Routing Table from any Status screen to generate the Routing Table screen.
This screen displays the Gateway’s routes.

17

Telus T3200M Gateway

Firewall Status

Click Firewall Status from any Status screen to generate the Firewall Status screen.
This screen displays parameters concerning the Gateway’s firewall.

NAT Table

Click NAT Table from any Status screen to generate the NAT Ta b le screen. This
screen displays the Gateway’s WAN (wide access network) parameters.

18

Status

Wireless Status

Click Wireless Status from any Status screen to generate the WAN Ethernet Status
screen. This screen displays the Gateway’s wireless network parameters.

19

Telus T3200M Gateway

Wireless Status

Click Advanced Wireless Statistics from the bottom of the Wireless Status
screen to generate the Advanced Wireless Statistics screen. This screen displays the
Gateway’s additional wireless network parameters.

Wireless Monitor

Click Modemstatus Wireless Monitor from the bottom of the Wireless Status
screen to generate the Wireless Monitor screen. This screen displays parameters for
the clients connected to the Gateway’s wireless network.

20

Status

Modem Utilization

Click Modem Utilization from any Status screen to generate the Modem
Utilization screen. This screen displays statistics related to the Gateway’s modem

operation.

21

Telus T3200M Gateway

LAN Status

Click LAN Status from any Status screen to generate the LAN Status screen. This
screen displays the Gateway’s LAN (local area network) parameters.

ARP Table

Click ARP Table from any Status screen to generate the ARP Table screen. This
screen displays the Gateway’s ARP (address resolution protocol) table.

22

Status

Interface Statistics

Click Interface Statistics from any Status screen to generate the Estimated
Interface Statistics screen. This screen displays various statistics and parameters

relating to the Gateway’s connection interfaces.

Multicast Statistics

Click Multicast Statistics from any Status screen to generate the Multicast
Statistics screen. This screen displays the Gateway’s multicast statistics.

23

Telus T3200M Gateway

System Log

Click System Log from any Status screen to generate the System Log screen. This
screen displays the Gateway’s system log, which keeps track of all events that occur
on the Gateway.

24

Configuring
Wireless Settings

This chapter explains the options provided in the Wireless Settings section of the
Gateway’s firmware, including basic and advanced settings, and WPS.

Accessing Wireless Settings

To access the Wireless Settings screens:

1. Open a Web browser. In the Address text box, type:

http://192.168.1.254
then press Enter on the keyboard.

4

25

Telus T3200M Gateway

2. The Gateway’s Main screen appears. Enter the user name and password,

then click Wireless Settings from the row of icons at the top of
the screen.

3. The Wireless Status screen appears, with a menu of other wireless options listed

on the left side of the screen.

Basic Settings

Click Basic Settings from any Wireless Settings screen to generate the Basic
Settings screen, as shown in the figure above. This screen displays a series of

settings relating to the basic functionality of the Gateway’s wireless network,
including SSID (network name), frequency, and security.

26

Wireless

Advanced Settings

Click Advanced Settings from any Wireless Settings screen to generate the
Advanced Settings screen. This screen displays a series of settings relating to the
advanced capabilities of the Gateway’s wireless network, including compatibility
mode, channel width, and WMM power save.

27

Telus T3200M Gateway

WPS

Click WPS from any Wireless Settings screen to generate the WPS (Wi-Fi Protected
Setup) screen, which allows the user to configure WPS by following the onscreen

instructions.

28

Telus T3200M Gateway

MAC Address Control

Click MAC Address Control from any Wireless Settings screen to generate the
Wireless MAC Authentication screen, which allows the user to configure allow or
deny access to the Gateway’s wireless network using the MAC address of the
wireless device. Follow the onscreen instructions to configure.

29

Wireless

WDS

Click WDS from any Wireless Settings screen to generate the WDS Wireless
Distribution System screen, which allows the user to configure the Gateway to allow

wireless connections between access points. Follow the onscreen instructions to
configure.

30

Configuring
Firewall Settings

This chapter explains the options provided in the Firewall section of the Gateway’s
firmware, including setting up port forwarding and static NAT.

Accessing Firewall Settings

To access the Firewall screens:

1. Open a Web browser. In the Address text box, type:

http://192.168.1.254
then press Enter on the keyboard.

The Gateway’s Home screen appears. Click the Firewall icon.

5

31

Telus T3200M Gateway

2. The Firewall screen appears, with a menu of other wireless options listed on the

left side of the screen.

Firewall

Click General from any Firewall Settings screen to generate the Firewall screen, as
shown in the figure above. To set up, follow the onscreen instructions.

32

Firewall

IPv6 Firewall

Click IPv6 Firewall from any Firewall Settings screen to generate the IPv6 Firewall
screen. To set up, follow the onscreen instructions.

33

Telus T3200M Gateway

Port Forwarding

Click Port Forwarding from any Firewall screen to generate the Port Forwarding
screen. Activating port forwarding allows the network to be exposed to the
Internet in certain limited and controlled ways, enabling some applications to work
from the local network (game, voice, and chat applications, for example), as well as
allowing Internet access to servers in the local network. This screen allows you to
configure the port forwarding settings of the Gateway. If changes are made in this
screen, click Apply at the bottom of the screen to save them.

Port forwarding settings should only be adjusted by experienced technical users
who are extremely familiar with wireless networking concepts.

34

Firewall

Applications

Click Applications from any Firewall screen to generate the Applications screen.
This screen allows the user to designate certain applications to be forwarded, cir­cumventing the usual firewall security settings. If changes are made in this screen,
click Apply at the bottom of the screen to save them.

35

Telus T3200M Gateway

DMZ Hosting

Click DMZ Hosting from any Firewall screen to generate the DMZ Hosting screen.
The DMZ host feature allows one device on the network to operate outside the firewall
to use an Internet service that otherwise would be blocked, or to expose a networked
device to all services without restriction or security. To activate, click in the Enable
radio button, then enter the device’s IP address in the appropriate text boxes.

Caution! A DMZ host is not protected by the firewall and may be
vulnerable to attack. Designating a DMZ host may also put other
computers in the local network at risk. When designating a DMZ
host, consider the security implications and protect it if necessary.

36

Firewall

IPv6 DMZ Hosting

Click IPv6 DMZ Hosting from any Firewall screen to generate the IPv6 DMZ
Hosting screen. The DMZ host feature allows one device on the network to operate

outside the firewall to use an Internet service that otherwise would be blocked, or to
expose a networked device to all services without restriction or security. To activate,
follow the onscreen instructions.

Caution! A DMZ host is not protected by the firewall and may be
vulnerable to attack. Designating a DMZ host may also put other
computers in the local network at risk. When designating a DMZ
host, consider the security implications and protect it if necessary.

37

Telus T3200M Gateway

UPnP

Click UPnP from any Firewall screen to generate the UPnP screen, which activates
UPnP (Universal Plug and Play). To activated, click in the Enable radio button,
then click Apply.

38

Advanced Settings

6

This chapter explains the options available with the Advanced Setup screens, which
configure some of the more complex settings on the Gateway.

Accessing the Advanced Setup Screens

To access the Gateway’s Advanced Setup screens:

1. Open a Web browser. In the Address text box, type:

http://192.168.1.254
then press Enter on the keyboard.

2. The Gateway’s Main screen appears. Click the Advanced Setup icon.

39

Telus T3200M Gateway

3. The Services Blocking screen appears.

From here, all the Advanced Setup screens can be accessed from the menu on the left.

Services Blocking

Click Services Blocking from any Advanced Setup screen to generate the Services
Blocking screen (see the figure, above). This feature allows the user to block certain

services from accessing the Gateway’s network(s). Follow the onscreen instructions
to configure.

40

Advanced

Website Blocking

Click Website Blocking from any Advanced Setup screen to generate the Website
Blocking screen. This feature allows the user to block certain websites from access-

ing the Gateway’s network(s). Follow the onscreen instructions to configure.

Scheduling Access

Click Scheduling Access from any Advanced Setup screen to generate the Scheduling
Access screen. This feature allows the user to schedule access to the Gateway’s

network(s) for certain devices. Follow the onscreen instructions to configure.

41

Telus T3200M Gateway

WAN IP Addressing

Click WAN IP Addressing from any Advanced Setup screen to generate the WAN
IP Address screen. This feature allows the user to set the protocol used by the ISP for

Internet access. Follow the onscreen instructions to configure.

42

Advanced

IPv6 WAN Settings

Click IPv6 WAN Settings from any Advanced Setup screen to generate the IPv6
WAN Settings screen. This feature allows the user to set the IPv6 protocol used by the

ISP for Internet access. Follow the onscreen instructions to configure.

43

Telus T3200M Gateway

LAN IP Settings

Click LAN IP Settings from any Advanced Setup screen to generate the LAN IP and
DHCP Settings screen. This feature allows the user to set LAN IP and DHCP server

settings on the Gateway. Follow the onscreen instructions to configure.

44

Advanced

IPv6 LAN Settings

Click IPv6 LAN Settings from any Advanced Setup screen to generate the IPv6 LAN
Settings screen. This feature allows the user to set the IPv6 LAN IP settings on the

Gateway. Follow the onscreen instructions to configure.

DHCP Reservation

Click DHCP Reservation from any Advanced Setup screen to generate the DHCP
Reservation screen. This feature allows the user to lease a permanent DHCP-

allocated address to a client on the Gateway’s network. Follow the onscreen
instructions to configure.

45

Telus T3200M Gateway

Dynamic DNS

Click Dynamic DNS from any Advanced Setup screen to generate the Dynamic
DNS screen. This feature allows the user to associate the WAN IP address of the

Gateway with a host name. Follow the onscreen instructions to configure.

46

Advanced

DNS Host Mapping

Click DNS Host Mapping from any Advanced Setup screen to generate the
Dynamic DNS screen. This feature allows the user to create a static host name for a
specified IP address. Follow the onscreen instructions to configure.

Port Bridging

Click Port Bridging from any Advanced Setup screen to generate the Port Bridging
screen. This feature allows the user to create a port bridge on the Gateway. Follow
the onscreen instructions to configure.

47

Telus T3200M Gateway

Admin Password

Click Admin Password from any Advanced Setup screen to generate the Admin
Password screen. This feature allows the user to change the password for accessing

the Gateway’s graphical user interface. Follow the onscreen instructions to configure.

Storage Device Info

Click Storage Device Info from any Advanced Setup screen to generate the Storage
Service screen. This feature allows storage devices connected to the Gateway to be

easily accessed. Any storage devices connected to the Gateway will be listed in the
table at the bottom of the screen.

48

Advanced

Samba Configuration

Click Samba Configuration from any Advanced Setup screen to generate the Samba
Configuration screen. This feature allows the user to set up a Samba environment.

Follow the onscreen instructions to configure.

Voice Advanced Setting

Click Voice Advanced Setting from any Advanced Setup screen to generate the
Service VoIP - Advanced screen. This feature allows the user to configure advanced
VoIP settings on the Gateway. Follow the onscreen instructions to configure.

49

Telus T3200M Gateway

Voice Basic Setting

Click Voice Basic Setting from any Advanced Setup screen to generate the Service
VoIP - Basic screen. This feature allows the user to configure basic VoIP settings on

the Gateway. Follow the onscreen instructions to configure.

50

Advanced

Voice Debug Setting

Click Voice Debug Setting from any Advanced Setup screen to generate the Service
VoIP - Debug screen. This feature allows the user to configure VoIP debug settings on

the Gateway. Follow the onscreen instructions to configure.

Reboot

Click Reboot from any Advanced Setup screen to generate the Reboot screen. Reboot
the Gateway by clicking Reboot.

51

Telus T3200M Gateway

Restore Defaults

Click Restore Defaults from any Advanced Setup screen to generate the Restore
Defaults screen. To restore certain settings on the Gateway, click the appropriate
Restore button.

Check for New Firmware

Click Check for New Firmware Link from any Advanced Setup screen to gener­ate the Upgrade Firmware from Internet screen. Follow the onscreen instructions to
upgrade the firmware on the Gateway.

52

Advanced

Speed Test

Click Speed Test from any Advanced Setup screen to generate the Speed Test screen.
This screen allows the user to perform a speed test on the Gateway’s Internet (or
WAN) connection. Enter the URL for a speed test site, then click Tes t.

53

Telus T3200M Gateway

Ping Test

Click Ping Test from any Advanced Setup screen to generate the Ping Test screen. To
perform a ping test on the Gateway, follow the onscreen instructions.

54

Advanced

Tcpdump Debug

Click Tcpdump Debug from any Advanced Setup screen to generate the Tcpdump
Debug screen. To perform a tcpdump debug on the Gateway, follow the onscreen

instructions.

55

Telus T3200M Gateway

Iperf Test

Click Iperf Test from any Advanced Setup screen to generate the Iperf Test screen. To
perform an iperf test on the Gateway, follow the onscreen instructions.

56

Advanced

IPv6 Ping Test

Click IPv6 Ping Test from any Advanced Setup screen to generate the IPv6 PingTest
screen. To perform an IPv6 ping test on the Gateway, follow the onscreen instructions.

57

Telus T3200M Gateway

Traceroute

Click Traceroute from any Advanced Setup screen to generate the Traceroute screen.
To perform an route trace on the Gateway, follow the onscreen instructions.

IPv6 Traceroute

Click IPv6 Traceroute from any Advanced Setup screen to generate the IPv6
Traceroute screen. To perform an IPv6 route trace on the Gateway, follow the onscreen

instructions.

58

Advanced

Time Zone

Click Time Zone from any Advanced Setup screen to generate the Time Zone screen.
Use this screen to set the time zone on the Gateway.

Language Settings

Click Language Settings from any Advanced Setup screen to generate the Language
Settings screen. Use this screen to set the language on the Gateway’s graphical

user interface.

59

Telus T3200M Gateway

DNS Cache

Click DNS Cache from any Advanced Setup screen to generate the DNS Cache
screen. Use this screen to set up a DNS cache on the Gateway.

IGMP Setting

Click IGMP Setting from any Advanced Setup screen to generate the IGMP Setting
screen. Use this screen to set up IGMP processes on the Gateway.

60

Advanced

Upgrade History

Click Upgrade History from any Advanced Setup screen to generate the Upgrade
History screen. This screen displays a list of firmware upgrades applied to the Gateway.

SIP ALG

Click SIP ALG from any Advanced Setup screen to generate the SIP ALG screen. This
screen allows the user to configure SIP ALG on the Gateway.

61

Telus T3200M Gateway

Tool Box

Click Tool Box from any Advanced Setup screen to generate the Too l B o x screen. This
screen allows the user to configure traffic and port mirroring on the Gateway.

DLNA

Click DLNA from any Advanced Setup screen to generate the DLNA screen. This
screen allows the user to configure DLNA settings on the Gateway.

62

Advanced

xDSL Diagnostics

Click xDSL diagnostics from any Advanced Setup screen to generate the DLNA
screen. This screen allows the user to select a type of diagnostics on the Gateway.

User’s Manual

Click xDSL diagnostics from any Advanced Setup screen to view the Gateway’s user
manual.

63

Specifications

General

Model Number(s)

T3200M (Wireless 11ac Bonded VDSL2 Modem Gateway with MoCA 2.0)

Standards

IEEE 802.3 (10BaseT)
IEEE 802.3u (100BaseTX)
IEEE 802.11 b, g, n (Wireless)
G.dmt
G.lite
t1.413
RFC 1483, 2364, 2516

Protocol

LAN - CSMA/CD
WA N - PPP, DHCP, Static IP

A

WAN

VDSL2 interface

LAN

10/100/1000 RJ-45 switched ports

Speed

LAN Ethernet: 10/100/1000 Mbps auto-sensing
Wireless: 802.11n 300 Mbps optimal (see Wireless Operating Range for details)

Cabling Type

Ethernet 10BaseT: UTP/STP Category 3 or 5
Ethernet100BaseTX: UTP/STP Category 5

64

Specifications

Wireless Operating Range

Indoors

Up to 91M (300 ft.) @ 300 Mbps

Outdoors

Up to 457M (1500 ft.) @ 300 Mbps

Topology

Star (Ethernet)

LED Indicators

WAN, Wireless, and WPS Push Button

Power Adapter

This device is supplied with one of two power adapters:

Adapter 1
Model No. - NBS40C120300VU
Input - 100-240V~, 50/60Hz, 1.0A
Output - 12.0V === 3.0A
Manufacturer - NetBit

Adapter 2
Model No. - CDS036-W120U
Input - 100-240V~, 50/60Hz, 1.0A
Output - 12.0V === 3.0A
Manufacturer - Actiontec

65

Telus T3200M Gateway

Environmental

Power

External, 12V DC, 3 A

Certifications

FCC Class B, FCC Class C (part 15, 68), CE Mark Commercial, UL

Operating Temperature

0º C to 45º C (32ºF to 113ºF)

Storage Temperature

-20ºC to 70ºC (-4ºF to 158ºF)

Operating Humidity

10% to 85% non-condensing

Storage Humidity

5% to 90% non-condensing

66

Notices

Warranty

This product has a one-year Limited Hardware Warranty and 90-day free software
updates from date of purchase.

Local Law

This Limited Warranty Statement gives the customer specific legal rights. The
customer may also have other rights, which vary from state to state in the United
States, and from country to country elsewhere in the world.

To the extent that this Limited Warranty Statement is inconsistent with local
law, this Statement shall be deemed modified to be consistent with such local
law. Under such local law, certain disclaimers and limitations of this Warranty
Statement may not apply to the customer.

Go to http://www.actiontec.com/products/warranty.php for more information.

Important Safety Instructions

Basic safety precautions should always be followed to reduce the risk of fire, electri­cal shock, and personal injury, including the following:

• Do not use this product near water – for example, near a bathtub, kitchen
sink, laundry tub, or swimming pool, or in a wet basement; only clean with
dry cloth.

• Do not block any ventilation openings. Install in accordance with the
manufacturer’s instructions. Do not install near any heat sources such as
radiators, heat registers, stoves, or other apparatus including amplifiers that
produce heat.

• Do not use the telephone to report a gas leak in the vicinity of the leak.

• Use only the power cord indicated in this manual.

67

Notices

Coaxial Cable

If applicable, the coaxial cable screen shield needs to be connected to the Earth at
the building entrance per ANSI/NFPA 70, the National Electrical Code (NEC),
in particular Section 820.93, “Grounding of Outer Conductive Shield of a Coaxial
Cable,” or in accordance with local regulation.

FCC Class B Equipment

This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installa­tion. This equipment generates, uses and can radiate radio frequency energy and,
if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that inter­ference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try and correct the
interference by implementing one or more of the following measures:

• Reorient or relocate the device;

• Increase the separation between the equipment and receiver;

• Consult the dealer or an experienced radio or television technician for help.

Modifications

The FCC requires the user to be notified that any changes or modifications made
to this device that are not expressly approved by Actiontec Electronics, Inc, may
void the user’s authority to operate the equipment.

68

Notices

Declaration of Conformity for Products Marked With the FCC Logo

This device complies with part 15 of the FCC. Operation is subject to the following
two conditions:

1. This device may not cause harmful interference;

2. This device must accept any interference received, including interference that

may cause undesired operation of the device.

Important Note on Wi-Fi

If applicable, this equipment complies with FCC radiation exposure limits set forth
for an uncontrolled environment.

The radio has been found to be compliant to the requirements set forth in CFR 47
Sections 2.1091, 15.247 (b) (4),15.407 addressing RF Exposure from radio frequen­cy devices as defined in Evaluating Compliance with FCC Guidelines for Human
Exposure to Radio Frequency Electromagnetic Fields. The equipment should be
installed more than 30 cm (~12 in.) from your body or nearby persons.

For product available in the USA market, only channel 1~11 can be operated.
Selection of other channels is not possible.

The device could automatically discontinue transmission in case of absence of
information to transmit, or operational failure. Note that this is not intended to
prohibit transmission of control or signaling information or the use of repetitive
codes where required by the technology.

The device for the band 5150-5250 MHz is only for indoor usage to reduce poten­tial for harmful interference to co-channel mobile satellite systems.

The maximum antenna gain permitted for devices in the band 5725-5825 MHz
shall comp with the e.i.r.p. limits specified for point-to-point and non point-to­point operation as appropriate.

The transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.

69

Telus T3200M Gateway

Contact Info

For questions regarding your product or the FCC declaration, contact:

Actiontec Electronics, Inc
760 North Mary Avenue, Sunnyvale, CA 94085, United States
Tel: [phone]
Fax: [phone]

70
