ACTi I98 User Manual
Outdoor Speed Dome
Hardware Manual
B945, B949
I98
2016/05/23
www.acti.com
Hardware Manual
Table of Contents
Precautions ............................................................. 4
Safety Instructions .................................................................................... 6
Introduction ............................................................. 7
List of Models ............................................................................................. 7
Package Contents ...................................................................................... 8
Physical Description ................................................................................. 9
Mounting Options ..................................................................................... 11
Other Mounting Accessories ................................................................. 12
Before Installation................................................. 13
Insert the Memory Card (Optional) ......................................................... 13
Attach the Safety Strap ........................................................................... 15
Installation Procedures ........................................ 16
Mount the Camera ................................................................................... 16
Attach the Ferrite Cores .......................................................................... 18
Waterproof the Cable Connections ........................................................ 20
Using the Cable Gland .......................................................................... 21
Using the Conduit Gland ....................................................................... 25
Using the Junction Box ......................................................................... 29
Connect to Network ................................................................................. 31
Other Cable Connections ..................................... 32
How to Use the Power Adapter ............................................................... 32
2
www.acti.com
Hardware Manual
How to Replace the Fuse ...................................................................... 33
How to Connect Digital Input / Digital Output Devices ......................... 34
Connecting DI/DO Devices ................................................................... 35
How to Connect Audio Devices .............................................................. 39
Accessing the Camera ......................................... 40
Configure the IP Addresses .................................................................... 40
Access the Camera .................................................................................. 44
3
www.acti.com
Hardware Manual
Precautions
Read these instructions
You should read all the safety and operating instructions before using this product.
Heed all warnings
You must adhere to all the warnings on the product and in the instruction manual. Failure to follow
the safety instructions given may directly endanger people, cause damage to the system or to
other equipment.
Servicing
Do not attempt to service this video device yourself as opening or removing covers may expose
you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.
Trademarks
All names used in this manual are probably registered trademarks of respective companies.
Liability
Every reasonable care has been taken during the writing of this manual. Please inform your local
office if you find any inaccuracies or omissions. We cannot be held responsible for any
typographical or technical errors and reserve the right to make changes to the product and
manuals without prior notice.
4
www.acti.com
Hardware Manual
Federal Communications Commission Statement
This equipment has been tested and found to comply with the limits for a class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Warning: Changes or modifications to the equipment that are not expressly approved by the
responsible party for compliance could void the user’s authority to operate the equipment.
European Community Compliance Statement
This product has been tested and found to comply with the limits for Class B
Information Technology Equipment according to European Standard EN 55022
and EN 55024. In a domestic environment, this product may cause radio interference in which
cause the user may be required to take adequate measures.
5
www.acti.com
Hardware Manual
Safety Instructions
Cleaning
Disconnect this video product from the power supply before cleaning.
Attachments
Do not use attachments or accessories not recommended by the video product manufacturer as
they may cause hazards.
Water and Moisture
Install other devices (such as PoE injector, alarm, etc.) that will be used with the camera in a dry
place protected from weather.
Servicing
Do not attempt to service this video product yourself. Refer all servicing to qualified service
personnel.
Damage Requiring service
Disconnect this video product from the power supply immediately and refer servicing to qualified
service personnel under the following conditions:
1) When the power-supply cord or plug is damaged.
2) If liquid has been spilled or objects have fallen into the video product.
3) If the inner parts of the video product have been directly exposed to rain or water.
4) If the video product does not operate normally by following the operating instructions in this
manual. Adjust only those controls that are covered by the instruction manual, as an improper
adjustment of other controls may result in damage, and will often require extensive work by a
qualified technician to restore the video product to its normal operation.
Safety Check
Upon completion of any service or repairs to this video product, ask the service technician to
perform safety checks to determine if the video product is in proper operating condition.
6
www.acti.com
Hardware Manual
B945
2MP Video Analytics Outdoor Speed Dome with D/N, Adaptive IR,
Extreme WDR, SLLS, 20x Zoom lens
B949
2MP Video Analytics Indoor Speed Dome with D/N, Extreme WDR,
ELLS, 30x Zoom lens
I98
2MP Video Analytics Outdoor Speed Dome with D/N, Adaptive IR,
Extreme WDR, SLLS, 33x Zoom lens
Introduction
List of Models
This hardware manual contains the following model:
7
www.acti.com
Hardware Manual
Camera
Power Cord
Power Adapter
Universal Converter
Cable Gland
Conduit Gland
Ferrite Core (x3)
Safety Strap
DI/DO Terminal
Blocks (x2)
Screws
Quick Installation
Guide
Warranty Card
Package Contents
Check if the following items come with the camera package. If any of them is missing, please
contact your local sales agents or the Customer Help Desk (CHD).
NOTE: The above pictures are for reference only; actual items may slightly vary.
8
www.acti.com
Physical Description
No.
Item
Description
1
Power LED
The Power LED lights red when the camera is powered up and
goes off when the boot up process is complete.
2
Reset Button
The reset button is used to restore the factory default settings
of the camera, including the administrator’s password.
To reset the camera, do the following: Press and hold the reset
button for at least 5 seconds or until the Power LED turns on.
3
Memory Card Slot
Insert a memory card into this slot for local recording purposes.
See Insert the Memory Card (Optional) on page 13 for more
information.
NOTE: Supports microSDHC cards only.
4
Audio Output
This jack connects to an audio output device, such as a
speaker. See How to Connect Audio Devices on page 39.
5
Audio Input
This jack connects to an audio input device, such as a
microphone with built-in amplifier. See How to Connect Audio
Devices on page 39.
NOTE: Make sure that the connected audio input device has a
built-in amplifier. Connecting an ordinary microphone will dwarf
sounds and will result in inaudible recording.
Hardware Manual
9
www.acti.com
No.
Item
Description
6
Digital Input / Output
The two (2) connectors connect to digital input or output
devices, such as an alarm trigger, panic button, etc. Digital
Input (DI) and Digital Output (DO) devices are used for
applications like motion detection, event triggering, alarm
notifications, etc. See How to Connect Digital Input / Digital
Output Devices on page 34 for information.
7
AC 24V Power Input
This jack connects to the power adapter and power cord to
supply power to the camera. See How to Use the Power
Adapter on page 32.
8
Ethernet Port
The Ethernet port connects to a network using a standard
Ethernet cable.
Hardware Manual
10
www.acti.com
Hardware Manual
Mount Types
Accessories
Pendant
Mount
Suitable when mounting the Outdoor PTZ on a hard ceiling.
PMAX-0102 (Straight Tube w/o Bracket)
PMAX-0103 (Straight Tube with Bracket)
Straight Wall
Mount
Suitable when mounting the Outdoor PTZ on a straight wall.
PMAX-0312 (PTZ Wall Mount)
Vertical Pole
Mount
Suitable when mounting the Outdoor PTZ on a vertical pole.
PMAX-0312
+
PMAX-0503
Mounting Options
There are several mounting options that you can use to install the camera. Below are some
examples.
For more information about mounting solutions and accessories, please visit our website
(http://www.acti.com/mountingselector).
11
www.acti.com
Hardware Manual
Horizontal
Pole Mount
Suitable when mounting the Outdoor PTZ on a horizontal pole.
PMAX-0102
+
PMAX-0503
Corner
Mount
Suitable when mounting the Outdoor PTZ on a corner wall.
PMAX-0312
+
PMAX-0402
Accessories
PMAX-0702 (Junction Box)
PMAX-0104 (Extension Tubes)
Other Mounting Accessories
12
www.acti.com
Hardware Manual
Before Installation
This section describes the procedures that can be done to prepare the camera prior to installation.
Do the following according to application needs.
Insert the Memory Card (Optional)
If a memory card will be used for local recording, do the following to insert the memory card.
1. Locate the memory card slot at the back of the lens module. The slot cover is marked with a
triangle . Loosen the two (2) screws to open the cover.
2. Pull to detach the cover.
13
www.acti.com
Hardware Manual
3. Insert the memory card with the metal contacts facing against the card logo . Push until the
card clicks into place.
4. Make sure the surrounding rubber is in place then attach the cover.
5. Tighten the two (2) screws to secure the cover.
