Acer V193HQB, V193HQL, V193HQV, V193HQ User Manual

Acer LCD Monitor

User's Guide

Copyright © 2008. Acer Incorporated.
All Rights Reserved.

Acer LCD Monitor User's Guide
Original Issue: 6/2008

Changes may be made periodically to the information in this publication without obligation
to notify any person of such revisions or changes. Such changes will be incorporated in new
editions of this manual or supplementary documents and publications. This company makes
no representations or warranties, either expressed or impli ed, with re spe ct to th e co nte nts
hereof and specifically disclaims the implied warranties of merchantability or fitness for a
particular purpose.

Record the model number, serial number, purchase date and place of purchase information in
the space provided below. The serial number and model number are recorded on the label
affixed to your computer. All correspondence concerning your unit should include the serial
number, model number and purchase information.

No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in
any form or by any means, electronically, mechanically, by photocopy, recording or otherwise,
without the prior written permission of Acer Incorporated.

Acer LCD Monitor User's Guide

Model number: __________________________________
Serial number: ___________________________________
Date of purchase: ________________________________
Place of purchase: ________________________________

Acer and the Acer logo are registered trademarks of Acer Incorporated. Other companies'
product names or trademarks are used herein for identification purposes only and belong to
their respective companies.

Special notes on LCD monitors

The following are normal with the LCD monitor and do not indicate a problem.

• Due to the nature of the fluorescent light, the screen may flicker during

initial use. Turn off the power switch and then turn it on again to make
sure the flicker disappears.

• You may find slightly uneven brightness on the screen depending on the

desktop pattern you use.

• The LCD screen has 99.99% or more effective pixels. It may include

blemishes of 0.01% or less such as a missing pixel or a pixel lit all the time.

• Due to the nature of the LCD screen, an afterimage of the previous screen

may remain after switching the image, when the same image is displayed
for hours. In this case, the screen is recovered slowly by changing the image
or turning off the power switch for a few hours.

Information for your safety and comfort

Safety instructions

Read these instructions carefully. Keep this document for future reference.
Follow all warnings and instructions marked on the product.

iii

Cleaning your monitor

Please carefully follow these guidelines when cleaning the monitor:

• Always unplug the monitor before cleaning.

• Use a soft cloth to wipe the screen and cabinet front and sides.

Connecting/disconnecting the device

Observe the following guidelines when connecting and disconnecting power
from the LCD monitor:

• Make sure the monitor is attached to its base before connecting the power

cord to the AC power outlet.

• Make sure both the LCD monitor and thecomputer are turned off before

connecting any cable or unplugging the power cord.

• If the system has multiple sources of power, disconnect power from the

system by unplugging all power cords from the power supplies.

iv

Accessibility

Be sure that the power outlet you plug the power cord into is easily accessible
and located as close to the equipment operator as possible. When you need to
disconnect power from the equipment, be sure to unplug the power cord from
the electrical outlet.

Safe listening

To protect your hearing, follow these instructions.

• Gradually increase the volume until you can hear it clearly and comfortably

and without distortion.

• After setting the volume level, do not increase it after your ears have

adjusted.

• Limit the amount of time listening to music at high volume.

• Avoid turning up the volume to block out noisy surroundings.

• Turn the volume down if you can't hear people speaking near you.

Warnings

• Do not use this product near water.

• Do not place this product on an unstable cart, stand or table. If the product

falls, it could be seriously damaged.

• Slots and openings are provided for ventilation to ensure reliable

operation of the product and to protect it from overheating. These
openings must not be blocked or covered. The openings should never be
blocked by placing the product on a bed, sofa, rug or other similar surface.
This product should never be placed near or over a radiator or heat
register, or in a built-in installation unless proper ventilation is provided.

• Never push objects of any kind into this product through cabinet slots as

they may touch dangerous voltage points or short-out parts that could
result in a fire or electric shock. Never spill liquid of any kind onto or into
the product.

• To avoid damage of internal components and to prevent battery leakage,

do not place the product on a vibrating surface.

• Never use it under sporting, exercising, or any vibrating environment

which will probably cause unexpected short current or damage internal
devices.

Using electrical power

• This product should be operated from the type of power indicated on the

marking label. If you are not sure of the type of power available, consult
your dealer or local power company.

• Do not allow anything to rest on the power cord. Do not locate this

product where people will walk on the cord.

• If an extension cord is used with this product, make sure that the total

ampere rating of the equipment plugged into the extension cord does not
exceed the extension cord ampere rating. Also, make sure that the total
rating of all products plugged into the wall outlet does not exceed the fuse
rating.

• Do not overload a power outlet, strip or receptacle by plugging in too

many devices. The overall system load must not exceed 80% of the branch
circuit rating. If power strips are used, the load should not exceed 80% of
the power strip's input rating.

• This product's power cord is equipped with a three-wire grounded plug.

The plug only fits in a grounded power outlet. Make sure the power outlet
is properly grounded before inserting the power cord plug. Do not insert
the plug into a non-grounded power outlet. Contact your electrician for
details.

Warning! The grounding pin is a safety feature. Using a power
outlet that is not properly grounded may result in electric shock
and/or injury.

Note: The grounding pin also provides good protection from
unexpected noise produced by other nearby electrical devices that
may interfere with the performance of this product.

• Use the product only with the supplied power supply cord set. If you need

to replace the power cord set, make sure that the new power cord meets
the following requirements: detachable type, UL listed/CSA certified, type
SPT-2, rated 7 A 125 V minimum, VDE approved or its equivalent, 4.6
meters (15 feet) maximum length.

v

Product servicing

Do not attempt to service this product yourself, as opening or removing covers
may expose you to dangerous voltage points or other risks. Refer all servicing to
qualified service personnel.

Unplug this product from the wall outlet and refer servicing to qualified service
personnel when:

• the power cord or plug is damaged, cut or frayed

• liquid was spilled into the product

• the product was exposed to rain or water

• the product has been dropped or the case has been damaged

• the product exhibits a distinct change in performance, indicating a need

for service

• the product does not operate normally after following the operating

instructions

vi

Note: Adjust only those controls that are covered by the operating
instructions, since improper adjustment of other controls may
result in damage and will often require extensive work by a
qualified technician to restore the product to normal condition.

Potentially explosive environments

Switch off your device in any area with a potentially explosive atmosphere and
obey all signs and instructions. Potentially explosive atmospheres include areas
where you would normally be advised to turn off your vehicle engine. Sparks in
such areas could cause an explosion or fire resulting in bodily injury or even
death. Switch off the device near gas pumps at service stations. Observe
restrictions on the use of radio equipment in fuel depots, storage and
distribution areas; chemical plants; or where blasting operations are in progress.
Areas with a potentially explosive atmosphere are often, but not always,
marked. They include below deck on boats, chemical transfer or storage
facilities, vehicles using liquefied petroleum gas (such as propane or butane),
and areas where the air contains chemicals or particles such as grain, dust or
metal powders.

Additional safety information

Your device and its enhancements may contain small parts. Keep them out of
the reach of small children.

IT Equipment Recycling Information

Acer is strongly committed to environmental protection and views recycling, in
the form of salvaging and disposal of used equipment, as one of the company's
top priorities in minimizing the burden placed on the environment.

We at Acer are very conscious of the environmental effects of our business and
strive to identify and provide the best working procedures to reduce the
environmental impact of our products.

For more information and help when recycling, please go to this website:
http://global.acer.com/about/sustainability32.htm
Visit www.global.acer.com for further information on the features and benefits

of our other products.

vii

Disposal instructions

Do not throw this electronic device into the trash when discarding.
To minimize pollution and ensure ut most protection of the gl obal environment,
please recycle. For more information on the Waste from Electrical and
Electronics Equipment (WEEE) regulations, visit
http://global.acer.com/about/sustainability.htm

Mercury advisory

For projectors or electronic products containing an LCD/CRT monitor or display:
lamp(s) inside this product conta in mercur y and must be recycl ed or dispo sed of
according to local, state or federal laws. For more information, contact the
Electronic Industries Alliance at www.eiae.org
information, check www.lamprecycle.org

. For lamp-specific disposal

.

LCD pixel statement

The LCD unit is produced with high-precision manufacturing techniques.
Nevertheless, some pixels may occasionally misfire or appear as black or
red dots. This has no effect on the recorded image and does not constitute
a malfunction.

ENERGY STAR (for selected models) is a government program (public/private
partnership) that gives people the power to protect the environment in a cost
effective way and without sacrificing quality or product features. Products that
earn the ENERGY STAR prevent greenhouse gas emissions by meeting strict
energy efficiency guidelines set by the US Environmental Protection Agency
(EPA) and the US Department of Energy (DOE). In the average home, 75% of all
electricity used to power home electronics is consumed while the products are
turned off. ENERGY STAR qualified home electronic products in the off position
use up to 50% less energy than conventional equipment. More information

viii

refers to http://www.energystar.gov and http://www.energystar.gov/
powermanagement.

As an ENERGY STAR partner, Acer Inc. has determined that this product meets
the ENERGY STAR guidelines for energy efficiency.

Note: The statement above is applicable only to Acer LCD monitor
with an ENERGY STAR logo.

This product has been shipped enabled for power management:

• Activate display’s Sleep mode within 15 minutes of user inactivity.

• Activate computer’s Sleep mode within 30 minutes of user inactivity.

• Wake the computer from Sleep mode by pushing the power button.

Tips and information for comfortable use

Computer users may complain of eyestrain and headaches after prolonged use.
Users are also at risk of physical injury after long hours of working in front of a
computer. Long work periods, bad posture, poor work habits, stress,
inadequate working conditions, personal health and other factors greatly
increase the risk of physical injury.

Incorrect computer usage may lead to carpal tunnel syndrome, tendonitis,
tenosynovitis or other musculoskeletal disorders. The following symptoms may
appear in the hands, wrists, arms, shoulders, neck or back:

• numbness, or a burning or tingling sensation

• aching, soreness or tenderness

• pain, swelling or throbbing

• stiffness or tightness

• coldness or weakness

If you have these symptoms, or any other recurring or persistent discomfort
and/or pain related to computer use, consult a physician immediately and
inform your company's health and safety department.

The following section provides tips for more comfortable computer use.

Finding your comfort zone

Find your comfort zone by adjusting the viewing angle of the monitor, using a
footrest, or raising your sitting height to achieve maximum comfort. Observe
the following tips:

• refrain from staying too long in one fixed posture

• avoid slouching forward and/or leaning backward

• stand up and walk around regularly to remove the strain on your leg

muscles

Taking care of your vision

Long viewing hours, wearing incorrect glasses or contact lenses, glare, excessive
room lighting, poorly focused screens, very small typefaces and low-contrast
displays could stress your eyes. The following sections provide suggestions on
how to reduce eyestrain.

Eyes

• Rest your eyes frequently.

• Give your eyes regular breaks by looking away from the monitor and

focusing on a distant point.

• Blink frequently to keep your eyes from drying out.

Display

• Keep your display clean.

• Keep your head at a higher level than the top edge of the display so your

eyes point downward when looking at the middle of the display.

• Adjust the display brightness and/or contrast to a comfortable level for

enhanced text readability and graphics clarity.

• Eliminate glare and reflections by:

• placing your display in such a way that the side faces the window or

any light source

• minimizing room light by using drapes, shades or blinds

• using a task light

• changing the display's viewing angle

• using a glare-reduction filter

• using a display visor, such as a piece of cardboard extended from the

display's top front edge

• Avoid adjusting your display to an awkward viewing angle.

• Avoid looking at bright light sources, such as open windows, for extended

periods of time.

ix

Developing good work habits

Develop the following work habits to make your computer use more relaxing
and productive:

• Take short breaks regularly and often.

• Perform some stretching exercises.

• Breathe fresh air as often as possible.

• Exercise regularly and maintain a healthy body.

Congratulations!

The display you have just purchased carries the TCO’03
Displays label. This means that your display is designed,
manufactured and tested according to some of the strictest
quality and environmental requirements in the world. This
makes for a high performance product, designed with the
user in focus that also minimizes the impact on our natural
environment.

Some of the features of the TCO’03 Display requirements:

Ergonomics

Good visual ergonomics and image quality in order to improve the working environment
for the user and to reduce sight and strain problems. Important parameters are luminance,
contrast, resolution, reflectance, colour rendition and image stability.

Energy

Energy-saving mode after a certain time – beneficial both for the user and the
environment
Electrical safety

Emissions

Electromagnetic fields
Noise emissions

Ecology

The product must be prepared for recycling and the manufacturer must have a certified
environmental management system such as EMAS or ISO 14 001
Restrictions on
chlorinated and brominated flame retardants and polymers
heavy metals such as cadmium, mercury and lead.

The requirements included in this label have been developed by TCO Development in co­operation with scientists, experts, users as well as manufacturers all over the world. Since the
end of the 1980s TCO has been involved in influencing the development of IT equipment in a
more user-friendly direction. Our labelling system started with displays in 1992 and is now
requested by users and IT-manufacturers all over the world.

For more information, please visit
www.tcodevelopment.com

x

We,
Acer Computer (Shanghai) Limited
3F, No. 168 Xizang medium road, Huangpu District,
Shanghai, China
Contact Person: Mr. Easy Lai

Tel: [phone] Fax: [phone]
E-mail: [e-mail]
Hereby declare that:
Product: LCD Monitor
Trade Name: Acer
Model Number: V193HQ
SKU Number: V193HQ

xxxx

The first x shows the front frame's ID and color.
The second x shows pedestal's ID color.

The third x shows the sale area.
The fourth x shows the others.;

Is compliant with the essential requirements and other relevant provisions of
the following EC directives, and that all the necessary steps have been taken
and are in force to assure that production units of the same product will
continue comply with the requirements.

EMC Directive 2004/108/EC as attested by conformity with the following
harmonized standards:

• EN55022:2006, AS/NZS CISPR22:2006, Class B

• EN55024:1998 + A1:2001 + A2:2003

• EN61000-3-2:2006, Class D

• EN61000-3-3:1995 + A1:2001+A2:2005

Low Voltage Directive 2006/95/EC as attested by conformity with the following
harmonized standard:

• EN60950-1:2001

RoHS Directive 2002/95/EC on the Restriction of the Use of certain Hazardous
Substances in Electrical and Electronic Equipment

Easy Lai / Director
Acer Computer (Shanghai) Limited

.

Federal Communications Commission

Declaration of Conformity

This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference,
and (2) This device must accept any interference received, including
interference that may cause undesired operation.

The following local manufacturer/importer is responsible for this declaration:

xi

Product name:

Model number:

SKU number:

Name of responsible party: Acer America Corporation

Address of responsible party: 333 West San Carlos St.

Contact person: Acer Representative

Tel: [phone]

Fax: [phone]

18.5" LCD Monitor

V193HQ

V193HQxxxx (x can be 0 - 9, A - Z or blank)

San Jose, CA 95110
USA

xii

Special notes on LCD monitors iii
Information for your safety and comfort iii

Safety instructions iii

Cleaning your monitor iii
Connecting/disconnecting the device iii
Accessibility iv
Safe listening iv
Warnings iv
Using electrical power iv

Product servicing v
Additional safety information vi
IT Equipment Recycling Information vi
Disposal instructions vii
LCD pixel statement vii
Tips and information for comfortable use viii

CEDeclaration of Conformity

Federal Communications Commission
Declaration of Conformity xi

Unpacking 1

Attaching/removing the base 2

Screen position adjustment 2

Connecting the power cord 3

Power saving 3

Display Data Channel (DDC) 3
Connector pin assignment 4
Standard timing table 6

Installation 7

User controls 8

How to adjust a setting 9

Acer eColor Management 10
User 11

Troubleshooting 13

VGA mode 13
DVI mode 14

1

x

2

English

Unpacking

Please check that the following items are present when you unpack the box,
and save the packing materials in case you need to ship or transport the
monitor in the future.

LCD monitor User’s guide Quick start guide

1

D-sub cable

Audio cable (Option)

DVI cable (only dual-

input models)

AC power cord

2

English

Attaching/removing the base

Attaching:
Align the release button on the
bottom of the monitor with the
corresponding slots on the bottom of
the base.

Removing:
Press the release button as

indicated, then pull in the direction
of the arrow to remove the base.

Screen position adjustment

To optimize the viewing position, you can adjust the monitor tilt by using
both of your hands to hold the edges of the monitor as shown below.
The monitor can be adjusted to 15 degrees up or 5 degrees down.

English

Connecting the power cord

• Check first to make sure that the power cord you use is the correct type

required for your area.

• The monitor has a universal power supply that allows operation in either

100/120 V AC or 220/240 V AC voltage area. No user-adjustment is
required.

• Plug one end of the power cord to the AC inlet, and plug the other end

into an AC outlet.

• For units using 120 V AC:

Use a UL-listed cord set, type SVT wire and plug rated 10 A/125 V.

• For units using 220/240 V AC:

Use a cord set consisting of H05VV-F cord and plug rated 10 A/250 V. The
cord set should have the appropriate safety approvals for the country in
which the equipment will be installed.

Power saving

The monitor will be switched to "power saving" mode by the control signal
from the display controller, as indicated by the amber-colored power LED.

Mode LED light

On Blue

Power saving Amber

3

The power saving mode will be kept until a control signal has been detected or
the keyboard or mouse is activated. The recovery time from "power saving"
mode back to "on" is around 3 seconds.

Display Data Channel (DDC)

To make installation easier, so long as your system supports the DDC protocol,
the monitor is able to plug-and-play. The DDC is a communication protocol
through which the monitor automatically informs the host system about its
capabilities; for example, supported resolutions and corresponding timing. The
monitor supports the DDC2B standard.

4

English

Connector pin assignment

15

6

11

15-pin color display signal cable

PIN No. Description PIN No. Description

1 Red 9 +5 V
2 Green 10 Logic ground
3 Blue 11 Monitor ground
4 Monitor ground 12 DDC-serial data
5 DDC-return 13 H-sync
6 R-ground 14 V-sync
7 G-ground 15 DDC-serial clock
8B-ground

10

15

English

24-pin color display signal cable

PIN No. Description PIN No. Description

1 TMDS data 2- 13 NC
2 TMDS data 2+ 14 +5 V power
3 TMDS data 2/4 shield 15 GND (return for +5 V hsync.vsync)
4 NC 16 Hot-plug detection
5NC 17TMDS data 0­6DDC clock 18TMDS data 0+
7 DDC data 19 TMDS data 0/5 shield
8NC 20NC

9 TMDS data 1- 21 NC
10 TMDS data 1+ 22 TMDS clock shield
11 TMDS data 1/3 shield 23 TMDS clock+
12 NC 24 DDC TMDS clock-

5

6

English

Standard timing table

Mode Resolution

1 640 x 480 60 Hz

2 640 x 480 72 Hz

3 640 x 480 75 Hz

4 MAC 640 x 480 66.66 Hz

5 VESA

6

7

8

9

10

11

12

13

14

15

16

17

18

19 VESA

20

21

SVGA

SVGA

SVGA 800 x 600 72 Hz

SVGA 800 x 600 75 Hz

MAC 832 x 624 74.55

XGA

XGA

XGA

MAC

VESA

VESA

SXGA

SXGA

WXGA

WXGA

720x400 70 Hz

800 x 600

800 x 600

1024 x 768 60 Hz

1024 x 768 70 Hz

1024 x 768 75 Hz

1152 x 870 75 Hz

1152 x 864 75 Hz

1280 x 960 60 Hz

1280 x 1024 60 Hz

1280 x 1024

1280 x 720

1280 x 800 60 Hz

1366x768

56

60

75 Hz

60 Hz

60 Hz

Hz

Hz

Hz

English

Installation

To install the monitor on your host system, please follow the steps below:

Steps

1 Connect the video cable

a Make sure both the monitor and computer are switched off.
b Connect the VGA video cable to the computer.
c Connect the digital cable (only for dual-input models).

(1) Make sure both the monitor and computer are switched off.
(2) Connect one end of the 24-pin DVI cable to the back of the

monitor and the other end to the computer's port.

2 Connect the power cord

Connect the power cord to the monitor, then to a properly grounded AC
outlet.

3 Turn on the monitor and computer

Turn on the monitor first, then the computer. This sequence is very
important.

4 If the monitor does not function properly, please refer to the

troubleshooting section to diagnose the problem.

7

8

English

User controls

Front panel controls

1 Power LED: Lights up to indicate the power is turned on.
2 Power switch: Turns the power on or off.

3.4 < / > : Press < or > to navigate to the desired function, press Enter to select
the function. Press < or > to change the settings of the current
function.

5 Menu/Enter: Activate the OSD menu when the OSD is off or activate/

deactivate the adjustment function when the OSD is on.

6 Auto adjust button/Exit:

a When the OSD menu is active, this button will act as the exit key

(OSD menu).

b When the OSD menu is inactive, press this button for two seconds to

activate the Auto Adjustment function. The Auto Adjustment
function is used to set the HPos, VPos, Clock and Focus.

7 Empowering Key/Exit:

a When the OSD menu is active, this button will act as the exit key

(exit OSD menu).

b When the OSD menu is inactive, press this button to select scenario

mode.

English

How to adjust a setting

1 Press the Menu button to activate the OSD window.
2 Press < or > to select the desired function.
3 Press the Menu button again to select the function that you want to

adjust.
4 Press < or > to change the settings of the current function.
5 To exit and save, select the exit function. If you want to adjust any other

function, repeat steps 2 to 4.

A Acer eColor Management: If "Acer eColor Management" is selected,

the Acer eColor Management OSD will appear.

B User: If "User" is selected, the standard OSD will appear.

9

I. Only analog-input mode II. Only digital-input mode

10

English

Acer eColor Management

• Operation instructions

1 Press the Empowering Key to open the Acer eColor Management

OSD and access the scenario modes.
2 Press "<" or ">" to select the mode.
3 Press the Auto-adjust button to confirm the mode and run Auto

Adjust.

• Features and benefits

Main
menu
icon

Sub menu item Description

User mode User-defined. Settings can be fine-tuned to

suit any situation.

Text mode Optimal balance of brightness and contrast to

prevent eyestrain. The most comfortable way
to read onscreen text.

Standard mode Default settings, reflects native display

capability.

Graphic mode Enhances colors and emphasizes fine detail.

Pictures and photographs appear in vibrant
colors with sharp detail.

Movie mode Displays scenes in clearest detail. Presents

great visuals, even in unsuitably-lit
environments.

English

User

11

Main
menu
icon

Sub
menu
icon

N/A Warm Sets the color temperature to warm

N/A Cool Sets the color temperature to cool white.

Sub menu item Description

Contrast Adjusts the contrast between the

foreground and background of the
screen image.

Brightness Adjusts the background brightness of the

screen image.

ACM ACM (Adaptive Contrast Management)

ACM On/Off switch, default Off.

Focus Adjusts picture focus (available in analog

mode only).

Clock Adjusts the picture clock (available in

analog mode only).

H. Position Adjusts the horizontal position of the

OSD (available in analog mode only).

V. Position Adjusts the vertical position of the OSD

(available in analog mode only).

white.

User/red Adjusts red intensity.

User/green Adjusts green intensity.

User/blue Adjusts blue intensity.

12

English

Main
menu
icon

Sub
menu

Sub menu item Description

icon
N/A English Language selection.
N/A

繁體中文

Deutsch
Français
Español
Italiano

简体中文

日本語

Suomi EMEA version OSD only.

Hollands

Русский

H. Position Adjusts the horizontal position of the

OSD.

V. Position Adjusts the vertical position of the OSD.

OSD Timeout Adjusts the OSD timeout.

N/A
N/A

Input Source

Wide Mode

Select input signal from D-Sub or DVI-D or HDMI

Select Wide mode setting for Full screen,
Aspect ratio or 1:1

mode

N/A DDC/CI Turns on/off DDC/CI support
N/A Information

Shows the resolution, H/V frequency,
input port and serial number for current
input.

N/A Reset Clears Auto-configuration changes and

sets the color temperature to warm.

N/A Exit Saves user changes and closes the OSD.

English

Troubleshooting

Before sending your LCD monitor for servicing, please check the
troubleshooting list below to see if you can self-diagnose the problem.

VGA mode

Problem LED status Remedy

No picture visible Blue Using the OSD, adjust brightness and

contrast to maximum or reset to their
default settings.

Off Check the power switch.

Check if the power cord is properly
connected to the monitor.

Amber Check if the video signal cable is

properly connected at the back of
monitor.

Check if the computer system is
switched on and in power saving/
standby mode.

Unstable picture Check if the specification of graphics

Abnormal picture Image is missing,

off-center, too
large or too
small on the
screen.

adapter and monitor is in compliance
which may be causing the input signal
frequency mismatch.

Using the OSD, adjust focus, clock, H­position and V-position with non­standard signals.

Check the display setting on your
system. In case of a missing image,
please select another resolution or
vertical refresh rate.

13

Wait for a few seconds after adjusting
the size of the image before changing
or disconnecting the signal cable or
switching off the monitor.

14

English

DVI mode

Problem LED status Remedy

No picture visible Blue Using the OSD, adjust brightness and

contrast to maximum or reset to their
default settings.

Off Check the power switch.

Check if the AC power cord is properly
connected to the monitor.

Amber Check if the video signal cable is

properly connected at the back of
monitor.

Check that the computer system is
switched on and in power saving/
standby mode.
