Acer LCD Monitor
User Guide
Copyright © 2018. Acer Incorporated.
All Rights Reserved.
Acer LCD Monitor User Guide
Original Issue: 7/2018
Changes may be made periodically to the information in this publication without obligation
to notify any person of such revisions or changes. Such changes will be incorporated in
new editions of this manual or supplementary documents and publications. This company
makes no representations or warranties, either expressed or implied, with respect to the
contents hereof and specifically disclaims the implied warranties of merchantability or
tness for a particular purpose.
Record the model number, serial number, purchase date and place of purchase information
in the space provided below. The serial number and model number are recorded on the
label afxed to your computer. All correspondence concerning your unit should include the
serial number, model number and purchase information.
No part of this publication may be reproduced, stored in a retrieval system, or transmitted,
in any form or by any means, electronically, mechanically, by photocopy, recording or
otherwise, without the prior written permission of Acer Incorporated.
Acer LCD Monitor User Guide
Model number: __________________________________
Serial number: ___________________________________
Date of purchase: ________________________________
Place of purchase: ________________________________
Acer and the Acer logo are registered trademarks of Acer Incorporated. Other companies’
product names or trademarks are used herein for identication purposes only and belong
to their respective companies.
Information for your safety and comrt
Safety instructions
Read these instructions carefully. Keep this document for future reference. Follow all
warnings and instructions marked on the product.
Special notes on LCD monitors
The following are normal with the LCD monitor and do not indicate a problem.
• Due to the nature of the uorescent light, the screen may icker during initial use. Turn off
the power switch and then turn it on again to make sure the icker disappears.
• You may nd slightly uneven brightness on the screen depending on the desktop pattern
you use.
• The LCD screen has 99.99% or more effective pixels. It may include blemishes of 0.01%
or less such as a missing pixel or pixel lit all the time.
• Due to the nature of the LCD screen, an afterimage of the previous screen may remain
after switching the image, when the same image is displayed for hours. In this case, the
screen is recovered slowly by changing the image or turning off the power switch for a few
hours.
Cleaning your monitor
Please carefully follow these guidelines when cleaning the monitor:
• Always unplug the monitor before cleaning.
• Use a soft cloth to wipe the screen and cabinet front and sides.
Accessibility
Be sure that the power outlet you plug the power cord into is easily accessible and
located as close to the equipment operator as possible. When you need to disconnect
power from the equipment, be sure to unplug the power cord from the electrical
outlet.
Safe listening
To protect your hearing, follow these instructions.
• Gradually increase the volume until you can hear it clearly and comfortably and without
distortion.
• After setting the volume level, do not increase it after your ears have adjusted.
• Limit the amount of time listening to music at high volume.
• Avoid turning up the volume to block out noisy surroundings.
• Turn the volume down if you can’t hear people speaking near you.
Warnings
• Do not use this product near water.
• Do not place this product on an unstable cart, stand or table. If the product falls, it could
be seriously damaged.
• Slots and openings are provided for ventilation to ensure reliable operation of the product
and to protect it from overheating. These openings must not be blocked or covered. The
openings should never be blocked by placing the product on a bed, sofa, rug or other
similar surface. This product should never be placed near or over a radiator or heat
register, or in a built-in installation unless proper ventilation is provided.
• Never push objects of any kind into this product through cabinet slots as they may touch
dangerous voltage points or short-out parts that could result in a re or electric shock.
Never spill liquid of any kind onto or into the product.
• To avoid dmage of internal components and to prevent battery leakage, do not place the
product on a vibrating surface.
• Never use it under sporting, exercising, or any vibrating environment which will probably
cause unexpected short current or damage internal devices.
• The adapter is only used for this monitor, do not be used for other purposes.
• Your device uses one of the following power supplies:
Manufacture: DELTA: ADP-230EB T (19.5Vdc/230W)
Using electrical power
• This product should be operated from the type of power indicated on the marking label.
If you are not sure of the type of power available, consult your dealer or local power
company.
• Do not allow anything to rest on the power cord. Do not locate this product where people
will walk on the cord.
• If an extension cord is used with this product, make sure that the total ampere rating of the
equipment plugged into the extension cord does not exceed the extension cord ampere
rating. Also, make sure that the total rating of all products plugged into the wall outlet does
not exceed the fuse rating.
• Do not overload a power outlet, strip or receptacle by plugging in too many devices. The
overall system load must not exceed 80% of the branch circuit rating. If power strips are
used, the load should not exceed 80% of the power strip’s input rating.
• This product’s power cord is equipped with a three-wire grounded plug. The plug only
ts in a grounded power outlet. Make sure the power outlet is properly grounded before
inserting the power cord plug. Do not insert the plug into a non-grounded power outlet.
Contact your electrician for details.
Warning!
The grounding pin is a safety feature. Using a power outlet that is not properly
grounded may result in electric shock and/or injury.
Note:
The grounding pin also provides good protection from unexpected noise produced
by other nearby electrical devices that may interfere with the performance of this
product.
• Use the product only with the supplied power supply cord set. If you need to replace the
power cord set, make sure that the new power cord meets the following requirements:
detachable type, UL listed/CSA certied, type SPT-2, rated 7 A 125 V minimum, VDE
approved or its equivalent, 4.6 meters (15 feet) maximum length.
Product servicing
Do not attempt to service this product yourself, as opening or removing covers may
expose you to dangerous voltage points or other risks. Refer all servicing to qualied
service personnel.
Unplug this product from the wall outlet and refer servicing to qualied service
personnel when:
• the power cord or plug is damaged, cut or frayed
• liquid was spilled into the product
• the product was exposed to rain or water
• the product has been dropped or the case has been damaged
• the product exhibits a distinct change in performance, indicating a need for service
• the product does not operate normally after following the operating instructions
Note:
Adjust only those controls that are covered by the operating instructions, since
improper adjustment of other controls may result in damage and will often require
extensive work by a qualied technician to restore the product to normal condition.
Potentially explosive environments
Switch off your device in any area with a potentially explosive atmosphere and obey
all signs and instructions. Potentially explosive atmospheres include areas where
you would normally be advised to turn off your vehicle engine. Sparks in such areas
could cause an explosion or re resulting in bodily injury or even death. Switch off the
device near depots, storage and distribution areas; chemical plants; or where blasting
operations are in progress. Areas with a potentially explosive atmosphere are often,
but not always, marked. They include below deck on boats, chemical transfer or
storage facilities, vehicles using liqueed petroleum gas (such as propane or butane),
and areas where the air contains chemicals or particles such as grain, dust or metal
powders.
Additional safety information
Your device and its enhancements may contain small parts. Keep them out of the
reach of small children.
IT Equipment Recycling Information
Acer is strongly committed to environmental protection and views recycling, in the
form of salvaging and disposal of used equipment, as one of the company’s top
priorities in minimizing the burden placed on the environment.
We at Acer are very conscious of the environmental effects of our business and strive
to identify and provide the best working procedures to reduce the environmental
impact of our products.
For more information and help when recycling, please go to this website:
http://www.acer-group.com/public/Sustainability/sustainability01.htm
Visit www.acer-group.com for further information on the features and benets of our
other products.
Disposal instructions
Do not throw this electronic device into the trash when discarding. To
minimize pollution and ensure utmost protection of the global environment,
please recycle. For more information on the Waste from Electrical and Electronics
Equipment (WEEE) regulations, visit http://www.acer-group.com/public/Sustainability/
sustainability01.htm
LCD pixel statement
The LCD unit is produced with high-precision manufacturing techniques.
Nevertheless, some pixels may occasionally misre or appear as black or red dots.
This has no effect on the recorded image and does not constitute a malfunction.
Power management statement should be as below.
• Activate display’s Sleep mode within 5 minutes of user inactivity.
• Wake the monitor when it is in Active Off mode, move the mouse or press any keyboard
key.
Tips and information for comfortable use
Computer users may complain of eyestrain and headaches after prolonged use.
Users are also at risk of physical injury after long hours of working in front of a
computer. Long work periods, bad posture, poor work habits, stress, inadequate
working conditions, personal health and other factors greatly increase the risk of
physical injury.
Incorrect computer usage may lead to carpal tunnel syndrome, tendonitis,
tenosynovitis or other musculoskeletal disorders. The following symptoms may
appear in the hands, wrists, arms, shoulders, neck or back:
• numbness, or a burning or tingling sensation
• aching, soreness or tenderness
• pain, swelling or throbbing
• stiffness or tightness
• coldness or weakness
If you have these symptoms, or any other recurring or persistent discomfort and/
or pain related to computer use, consult a physician immediately and inform your
company’s health and safety department.
The following section provides tips for more comfortable computer use.
Finding your comfort zone
Find your comfort zone by adjusting the viewing angle of the monitor, using a footrest,
or raising your sitting height to achieve maximum comfort. Observe the following tips:
• refrain from staying too long in one xed posture
• avoid slouching forward and/or leaning backward
• stand up and walk around regularly to remove the strain on your leg muscles
Taking care of your vision
Long viewing hours, wearing incorrect glasses or contact lenses, glare, excessive
room lighting, poorly focused screens, very small typefaces and low-contrast displays
could stress your eyes. The following sections provide suggestions on how to reduce
eyestrain.
Eyes
• Rest your eyes frequently.
• Give your eyes regular breaks by looking away from the monitor and focusing on a istant
point.
• Blink frequently to keep your eyes from drying out.
Display
• Keep your display clean.
• Keep your head at a higher level than the top edge of the display so your eyes point
downward when looking at the middle of the display.
• Adjust the display brightness and/or contrast to a comfortable level for enhanced text
readability and graphics clarity.
• Eliminate glare and reections by:
• placing your display in such a way that the side faces the window or any light source
• minimizing room light by using drapes, shades or blinds
• using a task light
• changing the display’s viewing angle
• using a glare-reduction lter
• using a display visor, such as a piece of cardboard extended from the display’s top
front edge
• Avoid adjusting your display to an awkward viewing angle.
• Avoid looking at bright light sources, such as open windows, for extended periods of time.
Developing good work habits
Develop the following work habits to make your computer use more relaxing and
productive:
• Take short breaks regularly and often.
• Perform some stretching exercises.
• Breathe fresh air as often as possible.
• Exercise regularly and maintain a healthy body.
Acer Incorporated
New Taipei City 221, Taiwan
8F, 88, Sec. 1, Xintai 5th Rd., Xizhi
Declaration of Conformity
We,
Acer Incorporated
8F, 88, Sec. 1, Xintai 5th Rd., Xizhi, New Taipei City 221, Taiwan
And,
Acer Italy s.r.l.
Via Lepetit, 40, 20020 Lainate (MI) Italy
Tel: +39-02-939-921 ,Fax: +39-02 9399-2913
www.acer.it
ct: LCD Monitor
Produ
Trade Name: Acer
Model Number:
SKU Number:
We, Acer Incorporated, hereby declare under our sole responsibility that the product described above is in
conformity with the relevant Union harmonization legislations as below Directive and following harmonized
standards and/or other relevant standards have been applied:
EMC Directive: 2014/30/EU
EN 55032:2012/AC:2013 Class B
EN 55032:2015/AC:2016 Class B
EN 61000-3-2:2014-3- Class D
LVD Directive: 2014/35/EU
EN 60950-1:2006/A11:2009/A1:2010/A12:2011/A2:2013
RoHS Directive: 2011/65/EU
EN 50581:2012
ErP Directive: 2009/125/EC
Regulation (EC) No. 1275/ 2008; EN 50564:2011
XV273K
XV273K xxxxxx;
(“x” = 0~9, a ~ z, A ~ Z, or blank)
EN 55024:2010
EN 61000-3-3:2013
Year to begin affixing CE marking: 2018.
_______________________________
RU Jan / Sr. Manager
Acer Incorporated (Taipei, Taiwan)
Jul.30,2018
Date
Acer America Corporation
333 West San Carlos St., San Jose
Suite 1500
CA 95110, U. S. A.
Tel : 254-298-4000
Fax : 254-298-4147
www.acer.com
Federal Communications Commission Supplier’s Declaration of
Conformity
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
The following local Manufacturer /Importer is responsible for this declaration:
Product: LCD Monitor
Model Number: XV273K
SKU Number:
XV273K xxxxxx
(“x” = 0~9, a ~ z, or A ~ Z)
Name of Responsible Party: Acer America Corporation
333 West San Carlos St.
Address of Responsible
Party:
Suite 1500
San Jose, CA 95110
U. S. A.
Contact Person: Acer Representative
Phone No.: 254-298-4000
Fax No.: 254-298-4147
Table of Contents
Information for your safety and comrt ...........................................................................ii
Safety instructions .......................................................................................................ii
Special notes on LCD monitors ..................................................................................ii
Cleaning your monitor ........................................................................................ii
Accessibility ........................................................................................................ii
Safe listening ......................................................................................................ii
Warnings ............................................................................................................ii
Using electrical power .......................................................................................iii
Product servicing ............................................................................................... iii
Potentially explosive environments ...................................................................iv
Additional safety information ......................................................................................iv
IT Equipment Recycling Information ..........................................................................iv
Disposal instructions ..................................................................................................iv
LCD pixel statement ....................................................................................................v
Tips and information for comfortable use ....................................................................v
Finding your comfort zone ..................................................................................v
Taking care of your vision ...................................................................................v
Developing good work habits ............................................................................vi
Unpacking .........................................................................................................................1
Adjusting the monitor ......................................................................................................2
Height Adjustment ...................................................................................................... 2
Tilt .............................................................................................................................. 2
Swivel ......................................................................................................................... 3
Monitor shading hood installation .............................................................................. 4
Monitor introduction ........................................................................................................6
Connecting the cables ............................................................................................... 7
Connecting the adapter and AC Power cord .............................................................. 8
Power saving ............................................................................................................. 8
Display Data Channel (DDC) ..................................................................................... 9
Standard timing table ................................................................................................11
Using the Shortcut Menu ................................................................................................. 12
Main page ................................................................................................................ 12
Hot key1 (default: Modes) ............................................................................... 12
Hot key2 (default: Brightness) ......................................................................... 12
Hot key3 (Selecting the input) ......................................................................... 13
Main Menu ....................................................................................................... 13
Troubleshooting ...............................................................................................................23
HDMI/DP Mode (Optional) ....................................................................................... 23
Unpacking
Please check that the following items are present when you unpack the box, and save the
packing materials in case you need to ship or transport the monitor in the future.
LCD monitor Quick start guide
LCD Monitor NITRO XV3 series-XV273K
USER GUIDE
USB cable
(Optional)
HDMI cable
(Optional)
DP Cable
(Optional)
AC Power cord
Shading Hood Packet
XV273K User Guide English 1
Adjusting the monitor
25°-5°
• For optimal viewing, we recommend that you look at the full face of the monitor, then
adjust the monitor to the angle that is most comfortable for you.
• Hold the stand to prevent the monitor from falling when you change its angle.
• You can adjust the monitor’s angle from +25˚ to -5˚, and it allows 20˚ swivel adjustment
from either left or right. You can also adjust the monitor’s height within +/- 100 mm.
Height Adjustment
1
2
100mm
Note:
Please adjust the height of the monitor afer pressing the top of the monitor.
Tilt
XV273K User Guide English 2
Swivel
20°
20°
XV273K User Guide English 3
Monitor shading hood installation
1. Align the screw holes on the side of monitor.
2. Use screwdriver or coin to fasten screw and x door on the head.
3. Repeat the same process to x door on the other side.
XV273K User Guide English 4
4. Put down top shield and x on the head.
5. Shading hood installation complete.
* How to open top small door
1. Use ngers to push up under cover.
2. Slide small door to the end as shown in the direction of the picture.
* How to close top small door
1. Slide small door back to the end.
2. Push down to lock the door.
XV273K User Guide English 5
Monitor introduction
1
2
3
4
5
X
User Controls
External controls
1 Power button Turns the monitor on/off.Blue indicates power on. Amber indicates
(Standby/ Power Saving mode/ OSD locked).
2 Function key/a. Press to view Main page. Press again to enter hotkey1 function.
b. When the Function Menu is active, press this key to view the basic
information for your monitor and current input or reset the custom
color settings to the factory defaults.
3 Function key/a. Press to view Main page.Press again to enter hotkey2 function.
b. When the Function Menu is active, press this button to select select
scenario mode or game mode .
4 Function key
/
5 Function key/a. Press to view Main page.Press again to enter next function in the
a. Press to view Main page.Press again to enter Input select function.
b. When the Function Menu is active, this button will quit the OSD.
Function Menu.
b. The single toggle button on the backside of the Display bezel
operates like a joystick. To move the cursor, simply toggle the button
in four directions. Press the button to select desired option.Red
indicates operable. Grey indicates inoperable.
XV273K User Guide English 6
Connecting the cables
To install the monitor on your host system, please follow the steps below:
1. Turn off your computer and unplug your computer's power cord.
2. Connect the signal cable to the DP (optional) and/or HDMI (optional) input
socket of the monitor, and the DP (optional) and/or HDMI (optional) output
socket of the graphics card on the computer. Then tighten the thumbscrews on
the signal cable connector.
3. Connect the USB Cable(Optional)
Connect the USB 3.0 cable to port for fast charge.
Connect the USB 3.0 cable to port.
4. Insert the monitor power cable into the power port at the back of the monitor.
5. Connect the power adapter and power cord to the monitor, then to a properly
grounded AC outlet.
USB
DP
HDMI 1(2.0) HDMI 2(2.0)
-----------------------------------------------------------------------------------------------------------
Note: Audio output is only for audio output model. Please check user manual for
more instruction.
XV273K User Guide English 7
Connecting the adapter and AC Power cord
• Check rst to make sure that the power cord you use is the correct type required
for your area.
• The monitor has a universal power supply that allows operation in either
100/120 V AC or 220/240 V AC voltage area. No user-adjustment is required.
• Plug one end of the AC power cord to the Adapter, and plug the other end into
an AC outlet.
• For units using 120 V AC:
• Use a UL-listed cord set, type SVT wire and plug rated 10 A/125 V.
• For units using 220/240 V AC:
• Use a cord set consisting of H05VV-F cord and plug rated 10 A/250 V. The cord
set should have the appropriate safety approvals for the country in which the
equipment will be installed.
Power saving
The monitor will be driven into "Power Saving" mode by the control signal from the
display controller, as indicated by the amber-color power LED.
State LED Light
ON Blue
Power Saving Mode Amber
The power saving states will be kept until a control signal has been detected or the
keyboard or mouse is activated. The recovery time from Active OFF state back to ON
state is around 3 seconds.
XV273K User Guide English 8
Display Data Channel (DDC)
To make installation easier, so long as your system supports the DDC protocol, the
monitor is able to plug-and-play. The DDC is a communication protocol through which
the monitor automatically informs the host system about its capabilities; for example,
supported resolutions and corresponding timing. The monitor supports the DDC2B
standard.
20-pin color display signal cable
PIN No. Description PIN No. Description
1 ML_Lane 0+ 2 GND
3 ML_Lane 0- 4 ML_Lane 1+
5 GND 6 ML_Lane 1-
7 ML_Lane 2+ 8 GND
9 ML_Lane 2- 10 ML_Lane 3+
11 GND 12 ML_Lane 3-
13 KONFIG1 14 CONFIG2
15 AUX CH+ 16 GND
17 AUX CH- 18 Hot Plug
19 Return 20 DP_PWR
XV273K User Guide English 9
19-pin color display signal cable
PIN No. Description PIN No. Description
1 TMDS Data2+ 2 TMDS Data2 Shield
3 TMDS Data2- 4 TMDS Data1+
5 TMDS Data1 Shield 6 TMDS Data1-
7 TMDS Data0+ 8 TMDS Data0 Shield
9 TMDS Data0- 10 TMDS Clock+
11 TMDS Clock Shield 12 TMDS Clock-
13 CEC 14 Reserved (N.C. on device)
15 SCL 16 SDA
17 DDC/CEC Ground 18 +5V Power
19 Hot Plug Detect
XV273K User Guide English 10
Standard timing table
VESA MODE
MODE Resolution
1 VGA 640x480 60Hz
2 SVGA 800x600 56Hz
3 SVGA 800x600 60Hz
4 XGA 1024x768 60Hz
5 SXGA 1280x1024 60Hz
6 VESA 1280x720 60Hz
7 WXGA 1280x800 60Hz
8 WXGA+ 1440x900 60Hz
9 WXGA+ 1680x1050 60Hz
10 UXGA 1920x1080 60Hz
11 UHD 3840x2160 30Hz
12 UHD 3840x2160 60Hz
13 UHD 3840x2160 120Hz
14 UHD 3840x2160 144Hz
Note:
• HDMI1 (2.0): Support max timing resolution (3840x2160-60Hz), Support HDR.
• HDMI2 (2.0): Support max timing resolution (3840x2160-60Hz), Support HDR.
• DP1: Support max timing resolution (3840x2160-120Hz), Support (FreeSync & HDR).
• DP2: Support max timing resolution (3840x2160-120Hz), Support (FreeSync & HDR).
• DP1 + DP2: AMD Gfx card can support max Timing resolution (3840x2160-144Hz), Not
Support (FreeSync & HDR).
• Need to use VESA certied DP cables
XV273K User Guide English 11
Using the Shortcut Menu
Mode
Standard
Brightness
80
Input
HDMI
Menu
1
2
3
4
Acon
Racing
Sports
User
HDR
Graphics
ECO
Standard
Modes
OK
Move
The following content is for general reference only. Actual product specications may vary.
The OSD (On Screen Display) can be used to adjust the settings of your LCD monitor.
Press the key to open the OSD. You can use the OSD to adjust the picture quality, OSD
position and general settings. For advanced settings, please refer to following page:
Main page
1. Hot Key1:
Modes, Brightness, Volume, Gamma, Contrast, Blue Light, Over Drive,VRB
2. Hot Key2:
Modes, Brightness, Contrast, Volume, Gamma, Blue Light, Over Drive,VRB
3. Hot Key3:
Input Switch Hot Key
4. Direction Key:
Main Menu
Hot key1 (default: Modes)
To choose scenario mode (G1, G2, G3) which user-dened prole to use or scenario mode
(User, Standard, ECO, Graphics, HDR)
Hot key2 (default: Brightness)
Open the Brightness control and select your preferred brightness setting. When you are
done, press the joystick to quit current page and store.
Brightness
80
Adjust
XV273K User Guide English 12
OK
Hot key3 (Selecting the input)
Input
Enter
Move
Exit
HDMI1(2.0)
Input
On
Auto Source
X
Mode - Standard
80
50
Off
Off
Off
Color
Audio
OSD
System
Brightness
Contrast
Blue Light
ACM
HDR
Off
Light Sensor
Enter
Move
5
Black Boost
X
Off
Super Sharpness
Gaming
Open the Input control and select HDMI1 (2.0), HDMI2 (2.0), DP1, DP2 or Auto Source.
When you are done, press the joystick to exit current page and store.
Main Menu
1. Press the MENU key to open the OSD.
2. Toggle the joystick to the up or down to select Picture from the OSD.Then
toggle to the right to navigate to the element you wish to adjust and press the joystick
to enter it.
3. Toggle the joystick to the left or right to adjust the sliding scales.
4. Information Hot Key
5. Modes Hot Key
6. Exit Hot Key
to exit current page and store.
:
Show Monitor Information and Reset control function.
:
To change Modes Hot Key menu.
• Brightness: Adjust the brightness from 0 to 100.
------------------------------------------------------------------------------------------------------
Note: Adjusts the balance between light and dark shades.
• Contrast: Adjust the contrast from 0 to 100.
------------------------------------------------------------------------------------------------------
Note: Sets the degree of difference between light and dark areas.
• Black Boost: Adjust the Black Boost from 0 to 10. Enhances shadows by increasing the
brightness without changing lighter shades.
------------------------------------------------------------------------------------------------------
Note: If the image is very bright or has few shadow areas, adjusting this setting may
not result in any noticeable changes to the image.
• Blue Light: Filters out blue light to protect your eyes by adjusting how much blue light is
shown -- Off, 80%, 70%, 60%, or 50%.
------------------------------------------------------------------------------------------------------
Note: Higher values allow more blue light through. For the best protection select a
lower value.
When “Blue Light” is on, Brightness & Contrast will show each level of “Blue
XV273K User Guide English 13
Light” value.
• ACM: Turn ACM on or off.
------------------------------------------------------------------------------------------------------
Note: Set to “On”, will be based on the current screen to dynamic contrast
adjustment.
• HDR: Can control (off / Auto / HD-400) the default is off, set to auto will automatically
detect and deal with HDR signal.
----------------------------------------------------------------------------------------------------------
Note:
1. When HDR=Auto or HD-400, the Modes will also be automatically set to “HDR”.
2. When HDR=Auto, some parameters: (ACM, Gamma, Contrast, Blue Light, Black
Boost…) functions is gray out and disable, and if you change other adjustable
parameters, the “Modes” will not jump to “User” Mode.
• Light Sensor: Light Sensor can choose: (Off, Level 1, Level 2 and Level 3), Off is
default, Level 3 brightness automatically adjust the maximum range, Level 2 brightness
automatically adjust the range is moderate, Level 1 brightness automatically adjust the
minimum range.
• Super Sharpness: Turn the Super Sharpness On or Off. Super Sharpness technology
can simulate high-resolution images by boosting the pixel density of the original source to
make images sharper and clearer.
XV273K User Guide English 14
Color
Mode - Standard
2.2
Warm
Audio
OSD
System
Gamma
Color Temp.
R Gain
G Gain
B Gain
Color
50
50
50
X
Enter
Move
Mode - Standard
Standard
Audio
OSD
System
Mode
Color Space
OffGrayscale Mode
6-axis Saturate
X
Enter
Move
R Bias
G Bias
B Bias
50
50
50
6-axis Hue
Color
Gaming
Gaming
Acon
Racing
Sports
User
HDR
Graphics
ECO
Standard
Modes
OK
Move
• Gamma: allows you to adjust the luminance tone. The default value is 2.2 (standard value
for windows). Adjust range are 1.8, 2.0, 2.2, 2.4 or 2.6.
• Color temperature: You can choose color temperature as Warm, Normal, Cool,
Bluelight or User.
Warm: Increases the color temperature. The screen appears warmer with a red/yellow tint. This is the default
preset mode.
Normal: Loads the monitor's normal color settings.
Cool: Decreases the color temperature. The screenappears cooler with a blue tint.
Bluelight: Decreases the level of blue light emitted from the screen to make viewing more comfortable for
your eyes.
User: Allows you to manually adjust the color settings.
• Modes: Open Modes Hot Key Menu. Detail rules please refer Modes Spec.
Action: For better color matching representation with the Action game or movie, Users can modify some
parameters and save them by themselves.
Racing: For better color matching representation with the Racing game or movie, Users can modify some
parameters and save them by themselves.
Sports: For better color matching representation with the Sports game or movie, Users can modify some
parameters and save them by themselves.
User: Applies a combination of picture settings dened by users.
XV273K User Guide English 15
Standard: For basic PC application (Default Setting).
ECO: For saving electricity with low power consumption by providing minimum brightness for all running
programs.
Graphics: For better color matching representation with the graphics.
HDR: For better color matching representation with the high dynamic lighting rendering (HDR).
-------------------------------------------------------------------------------------------------------
In HDR mode, same function item is gray out and parameters are xed not open to modify:
Note:
1. The signal content is SDR, the brightness can to adjustment, but content is HDR the brightness is
xed at 100 and gray out.
2. Users can adjustment (Brightness (SDR), Aim Point, Over Drive, Refresh Rate Num and Super
Sharpness).
3. If to adjust the parameter or be saved the Modes will not jump to User mode.
4. 6-axis (Hue & Saturate) are gray out and can't adjustment.
• Color Space: You can choose sRGB, Rec.709, EBU, DCI, SMPTE-C and Standard.
-------------------------------------------------------------------------------------------------------
Note: Color Space = HDR to correspond Modes is HDR, Other Color Space the
Modes=Standard.
1. CIE 1931 positive and negative error of 0.05, ("HDR" according to current Panel to
ne-tune).
2. Color Space = HDR, the Modes = HDR, Picture page HDR = Auto.
3. The signal content is SDR, the brightness can to adjustment, but content is HDR
the brightness is xed at 100 and gray out unavailable.
4. Modes = (Action/Racing/Sports/User/Standard/ECO/Graphic) is selected; the color
space is auto set to “Standard”.
5. Color space = (sRGB/Rec.709/EBU/DCI/SMPTE-C), The Modes = Standard, and
parameters can be adjusted and saved as shareable values.
6. Color Space = (sRGB/Rec.709/HDR/EBU/DCI/SMPTE-C), If to adjust the
parameter the Modes will not jump to User mode, but except Color Space =
Standard.
7. Color Space = (sRGB/Rec.709/HDR/EBU/DCI/SMPTE-C), 6-Axis Hue & Saturate
is gray out and unavailable.
XV273K User Guide English 16
8. Color Space = (sRGB/Rec.709/HDR/EBU/DCI/SMPTE-C), Grayscale Mode is gray
Mode - Standard
70
OSD
System
Color
Volume
Audio
X
Enter
Move
OffMute
Gaming
out and unavailable.
• Grayscale Mode: Select garyscale mode “On” or “Off”.
On: Color only black and white effect.
Off: Normal color effect.
• 6-axis Hue: Adjust the Red Hue, Green Hue, Blue Hue, Yellow Hue, Magenta Hue , Cyan
Hue or Reset.
Mode - Standard
Color
Audio
Performance Performance
OSD
System
Move
Mode
Color Space
6-axis Hue
6-axis Saturate
Enter
Standard
OffGrayscale Mode
X
Color
Audio
OSD
System
Move
6-axis Hue
Red Hue
Green Hue
Blue Hue
Yellow Hue
Magenta Hue
Cyan Hue
Reset
Enter
Mode - Standard
Back
Standard
50
50
50
50
X
50
50
• 6-axis Saturate: Adjust the Red Saturate, Green Saturate, Blue Saturate, Yellow Saturate,
Magenta Saturate, Cyan Saturation or Reset.
Color
Audio
Performance
OSD
System
Move
Mode
Color Space
6-axis Hue
6-axis Saturate
Enter
Mode - Standard
Standard
OffGrayscale Mode
Color
Audio
Performance
OSD
X
System
Move
6-axis Saturate
Red Saturate
Green Saturate
Blue Saturate
Yellow Saturate
Magenta Saturate
Cyan Saturate
Reset
Enter
Mode - Standard
Back
Standard
50
50
50
50
X
50
50
Audio
XV273K User Guide English 17
• Volume: Adjust the volume
Mode - Standard
OSD
System
Color
Over Drive
Audio
Normal
On
FreeSync
Off
Refresh Rate Num
Enter
Move
X
Gaming
OffVRB
OffAim point
• Mute: Toggles the monitor sound between on and off. The default is off.
Gaming
• Over Driver: Select Off, Normal, or Extreme.
• FreeSync: To control support FreeSync or not, default is On.
-----------------------------------------------------------------------------------------------------------
Note:
If FreeSync is “ON”, then the Over Drive selection is set to “Normal” automatically.
1.
If FreeSync is “OFF”, then the user can set Over Drive to either one of the three
2.
settings including: (a) Extreme (b) Normal (c) Off.
DP is support “FreeSync”, HDMI is not support “FreeSync”
3.
.
• Refresh Rate Num: Display the panel’s current refresh rate on the screen.
• VRB: To choose whether to support dynamic picture more clean control, default is Off.
------------------------------------------------------------------------------------------------------------
Note:
HDR setting = (Auto or HDR-400) is not support VRB,.
1.
VRB function does not affect the (Logo, Aim Point, Message and Input Icon)
2.
brightness.
VRB set "Normal or Extreme", when to turn on
3.
VRB set "Normal or Extreme", when to adjustment (
4.
FreeSync
, will auto set VRB is "Off".
Brightness, Blue Light, ACM
will auto set VRB is "Off".
VRB setting "Normal or Extreme", when detection of Input Timing <75Hz, will auto off
5.
the VRB and gray out to disable.
VRB = (Normal or Extreme), because the IC control dynamic picture is cleaner, so the
6.
overall Brightness will be dark, "Extreme" will be darker than “Normal”.
• Aim point: Show an Aim point on the screen for shooting games.
--------------------------------------------------------------------------------------------------------------
Note: If hot key menu or main menu is trigger the "Aim point" temporarily closed.
XV273K User Guide English 18
),
OSD
Mode - Standard
10
English
System
OSD Timeout
Color
Language
Audio
OSD
Off
Transparency
Enter
Move
X
OSD Lock
Off
Gaming
• Language: Set the OSD menu language.
• OSD timeout: Adjust the delay before turning off the OSD menu.
• Transparency: Select the transparency when using gaming mode. The transparency can
be 0% (OFF), 20%, 40%, 60%, or 80%.
• OSD Lock: To choose OSD lock On/Off.
------------------------------------------------------------------------------------------------------------
Note:
OSD Locked:
Set the OSD Lock to "On" by the OSD option and press "Enter" to execute the All Key
1.
lock function.
The "OSD Locked" message will be displayed in the middle of the screen.
2.
LED lights will be changed from blue light to orange light.
3.
Press any Key screen to prompt "OSD Locked" message.
4.
OSD Unlocked:
In normal display condition to press the "Navi Key" in the middle of more than 3
1.
seconds to trigger "OSD Unlock".
The "OSD Unlock" message will be displayed in the middle of the screen.
2.
LED lights will be restored to blue light.
3.
XV273K User Guide English 19
System
Mode - Standard
HDMI1(2.0)
Color
Input
Audio
OSD
Full
Wide Mode
System
PIP/PBP
Ambient Light
Hot Key Assignment
X
Enter
Move
DP1.2
DP Format
On
Auto Source
Mode - Standard
Color
Audio
OSD
X
Enter
Move
Off
Quick start mode
Off
4K-144Hz Mode
Off
Power-off
USB Charge
LED Control 10
System
Gaming
Gaming
DDC/CI
HDMI Black Level
On
Normal
• Input: Select the source from HDMI1 (2.0), HDMI2 (2.0),
DP1, DP2
.
• Auto Source:The default is “On”, can support auto search for signal source in order.
------------------------------------------------------------------------------------------------------
Note: Surround application must set Auto Source is “Off”.
• DP Format: Default is DP1.4, can selection DP support DP1.1, DP1.2 or DP1.4 format.
------------------------------------------------------------------------------------------------------------
Note:
The default is "DP1.4", can support high-bandwidth video.
1.
(DP1.1/DP1.2) supports most video formats, so DP there is no video output can
2.
change (DP1.1/DP1.2) checked.
DP input and set 4K-144Hz Mode is On, the DP Format auto change to DP1.4 and
3.
• Wide Mode: You can select which screen aspect you are using. The options are Full,
Aspect, and 1:1.
• Ambient Light: Ambient Light at bottom, the composite table of functions is as Note.
gray out unavailable.
DP input and set HDR = (Auto or HDR-400), If contents is HDR format the DP Format
4.
auto change DP1.4 and gray out unavailable.
------------------------------------------------------------------------------------------------------
Note:
XV273K User Guide English 20
• Hotkey Assigment: Select the function of shortcut key 1 or shortcut keys2:(Modes,
Brightness, Volume, Gamma, Contrast, Blue Light, Over Drive,VRB).
------------------------------------------------------------------------------------------------------
Note: Hot Key 1 and Hot Key 2 can’t repeat the same function.
• DDC/CI: Allows the monitor settings to be set through the software on the PC.
------------------------------------------------------------------------------------------------------
Note: DDC/CI, short for Display Data Channel/Command Interface, which allows
monitor controls to be sent via software.
• HDMI Black level: Select to set HDMI black level.
• Quick start mode: Select Off or On. Turn on to speed up boot speed.
• LED Control: Controls the brightness of the Key LED.
• 4K-144Hz Mode: Default is “Off” (Support DP Only).
Off: Support 4K-120Hz (Support HDR and FreeSync).
On: Support 4K-144Hz (Not Support HDR and FreeSync).
------------------------------------------------------------------------------------------------------
Note: Want to support 4K-144Hz, Graphic Card must be able to support 4K-144Hz
and both DP1 and DP2 must be connected at the same time to enable this feature.
To support display 4K-144Hz.
1. Min requirement is AMD RX470 or above graphic card
2. To connect both DP1 + DP2 port, need to use in box DP cables or VESA certied
DP cables.
3. Must to turn on the 4K-144Hz mode in system page of OSD.
XV273K User Guide English 21
Mode - Standard
Color
Audio
OSD
X
Enter
Move
Off
Quick Start Mode
Off
Power-off
USB Charge
LED Control
10
System
Gaming
Off
4K-144Hz Mode
Mode - User
System
Color
Audio
OSD
Enter
Move
X
Save seng to...
Gaming
Game Mode: Sports
• Power-off USB charge: Turn On or Off. On: DC off/Saving mode can to electrify for USB
port. Off: DC off/Saving mode can't to electrify for USB port.
Save Setting to…(User mode only)
• Press the MENU key to open the OSD.
• Toggle the joystick to the up or down to select "Save Setting to..." from the OSD.Then
toggle to the right to navigate to the element you wish to adjust and press the joystick to
enter it.
• Save Setting to Game mode: There are three user-dened proles available. When you
have decided what settings suit you, save them and system will be able to recall the
settings in the future when you turn on gaming mode .
XV273K User Guide English 22
Troubleshooting
Before sending your LCD monitor for servicing, please check the troubleshooting list below
to see if you can self-diagnose the problem.
HDMI/DP Mode (Optional)
Problem LED status Remedy
No picture visible Blue Using the OSD menu, adjust brightness and contrast
to maximum or reset to their default setting.
Off Check the power switch.
Check if the AC power cord is properly connected to
the monitor.
Amber Check if the video signal cable is properly connected
at the back of monitor.
Check if the computer system is switched on and in
power saving/standby mode.
OSD Locked: If OSD Lock is on, the LED status set
Amber.
Note: Acer monitor is purposed for video and visual display of information obtained from
electronic devices.
XV273K User Guide English 23
Loading...
