Acer Projector

X1185/D203/EV-S55/V23S/AS306/

X1285/D213/EV-X55/V23X/AX306/

S1285/T213/XS-X14/P1185/M303/PE-

S35/F23S/AS326/P1285/M313/PE-

X35/F23X/AX326/P1385W/M323/PE-

W35/F23W/AW327/X1385WH/

D223D/EV-W55H/V23W/AW317/

P1520/M345/PE-845/H6515BD/

E341D/HE-813J

Series User's Guide

Acer Projector User's Guide Original Issue: 01/2015

Acer Projector

Acer and the Acer logo are registered trademarks of Acer Incorporated. Other companies' product names or trademarks are used herein for identification purposes only and belong to their respective companies.

"HDMI

, the HDMI logo and High-Definition Multimedia Interface are trademarks or

registered trademarks of HDMI Licensing LLC."

Changes may be made periodically to the information in this publication without obligation to notify any person of such revisions or changes. Such changes will be incorporated in new editions of this manual or supplementary documents and publications. This company makes no representations or warranties, either expressed or implied, with respect to the contents hereof and specifically disclaims the implied warranties of merchantability or fitness for a particular purpose.

Record the model number, serial number, purchase date and place of purchase information in the space provided below. The serial number and model number are recorded on the label affixed to your projector. All correspondence concerning your unit should include the serial number, model number and purchase information.

No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronically, mechanically, by photocopy, recording or otherwise, without the prior written permission of Acer Incorporated.

Model number: __________________________________

Serial number: ___________________________________

Date of purchase: ________________________________

Place of purchase: ________________________________

iii

Information for Your Safety and Comfort

Read these instructions carefully. Keep this document for future reference. Follow all warnings and instructions marked on the product.

Turning the product off before cleaning

Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.

Caution for plug as disconnecting device

Observe the following guidelines when connecting and disconnecting power to the external power supply unit:

• Install the power supply unit before connecting the power cord to the AC

power outlet.

• Unplug the power cord before removing the power supply unit from the

projector.

• If the system has multiple sources of power, disconnect power from the

system by unplugging all power cords from the power supplies.

Caution for Accessibility

Be sure that the power outlet you plug the power cord into is easily accessible and located as close to the equipment operator as possible. When you need to

disconnect power to the equipment, be sure to unplug the power cord from the electrical outlet.

Warnings!

• Do not use this product near water.

• Do not place this product on an unstable cart, stand or table. If the product

falls, it could be seriously damaged.

• Slots and openings are provided for ventilation to ensure reliable

operation of the product and to protect it from overheating. These openings must not be blocked or covered. The openings should never be blocked by placing the product on a bed, sofa, rug or other similar surface.

This product should never be placed near or over a radiator or heat register, or in a built-in installation unless proper ventilation is provided.

• Never push objects of any kind into this product through cabinet slots as

they may touch dangerous voltage points or short-out parts that could result in a fire or electric shock. Never spill liquid of any kind onto or into the product.

• To avoid damage of internal components and to prevent battery leakage,

do not place the product on a vibrating surface.

• Never use it under sporting, exercising, or any vibrating environment

which will probably cause unexpected short current or damage rotor devices or lamp.

Using electrical power

• This product should be operated from the type of power indicated on the

marking label. If you are not sure of the type of power available, consult your dealer or local power company.

• Do not allow anything to rest on the power cord. Do not locate this

product where people will walk on the cord.

• If an extension cord is used with this product, make sure that the total

ampere rating of the equipment plugged into the extension cord does not exceed the extension cord ampere rating. Also, make sure that the total rating of all products plugged into the wall outlet does not exceed the fuse rating.

• Do not overload a power outlet, strip or receptacle by plugging in too

many devices. The overall system load must not exceed 80% of the branch circuit rating. If power strips are used, the load should not exceed 80% of the power strip's input rating.

• This product's AC adapter is equipped with a three-wire grounded plug.

The plug only fits in a grounded power outlet. Make sure the power outlet is properly grounded before inserting the AC adapter plug. Do not insert the plug into a non-grounded power outlet. Contact your electrician for details.

Warning! The grounding pin is a safety feature. Using a power outlet that is not properly grounded may result in electric shock and/or injury.

Note: The grounding pin also provides good protection from unexpected noise produced by other nearby electrical devices that may interfere with the performance of this product.

• Use the product only with the supplied power supply cord set. If you need

to replace the power cord set, make sure that the new power cord meets the following requirements: detachable type, UL listed/CSA certified, VDE approved or its equivalent, 4.5 meters (14.76 feet) maximum length.

Product servicing

Do not attempt to service this product yourself, as opening or removing covers may expose you to dangerous voltage points or other risks. Refer all servicing to qualified service personnel.

Unplug this product from the wall outlet and refer servicing to qualified service personnel when:

• the power cord or plug is damaged, cut or frayed

• liquid was spilled into the product

• the product was exposed to rain or water

• the product has been dropped or the case has been damaged

• the product exhibits a distinct change in performance, indicating a need

for service

• the product does not operate normally after following the operating

instructions

Note: Adjust only those controls that are covered by the operating instructions, since improper adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore the product to normal condition.

Warning! For safety reasons, do not use non-compliant parts when adding or changing components. Consult your reseller for purchase options.

Your device and its enhancements may contain small parts. Keep them out of the reach of small children.

Additional safety information

• Do not look into the projector's lens when the lamp is on. The bright light

may hurt your eyes.

• Turn on the projector first and then signal sources.

• Do not place the product in the following environments:

• Space that is poorly ventilated or confined. At least 50cm clearance from walls and free flow of air around the projector are necessary.

• Locations where temperatures may become excessively high, such as inside of a car with all windows rolled up.

• Locations where excessive humidity, dust, or cigarette smoke may contaminate optical components, shorten the life span and darken the image.

• Locations near fire alarms.

• Locations with an ambient temperature above 40 ºC/104 ºF.

• Locations where the altitudes are higher than 10000 feet.

• Unplug immediately if there is something wrong with your projector. Do

not operate if smoke, strange noise or odor comes out of your projector. It

might cause fire or electric shock. In this case, unplug immediately and contact your dealer.

• Do not keep using this product to break or drop it. In this case contact your

dealer for inspection.

• Do not face the projector lens to the sun. It can lead to fire.

• When switching the projector off, please ensure the projector completes

its cooling cycle before disconnecting power.

• Do not frequently turn off the main power abruptly or unplug the

projector during operation. The best way is to wait for the fan to stop before turning main power off.

• Do not touch the air outlet grille and bottom plate which become hot.

• Clean the air filter frequently. The temperature inside may rise and cause

damage when the filter/ventilation slots are clogged with dirt or dust.

• Do not look into the air outlet grille when projector is operating. It may

hurt your eyes.

• Always open the lens shutter or remove the lens cap when the projector is

on.

• Do not block the projector lens with any object when the projector is

under operation as this could cause the object to become heated and deformed or even cause a fire. To temporarily turn off the lamp, press HIDE on the remote control.

• Do not operate lamps beyond the rated lamp life. It could cause it to break

on rare occasions.

• Contact your local dealer or Acer service center when you need to change

the lamp.

• The project will defect the life of the lamp itself. Please contact your local

dealer or Acer service center for changing the lamp, when lamp warming message displays.

• Do not attempt to disassemble this projector. There are dangerous high

voltages inside which may hurt you.

• Do not stand the projector on end vertically. It may cause the projector to

fall over, causing injury or damage.

• This product is capable of displaying inverted images for ceiling mount

installation. Only use acer ceiling mount kit for mounting the projector and ensure it is securely installed.

vii

Caution for Listening

To protect your hearing, follow these instructions.

• Increase the volume gradually until you can hear clearly and comfortably.

• Do not increase the volume level after your ears have adjusted.

• Do not listen to music at high volumes for extended periods.

• Do not increase the volume to block out noisy surroundings.

• Decrease the volume if you can't hear people speaking near you.

Disposal instructions

Do not throw this electronic device into the trash when discarding. To minimize pollution and ensure utmost protection of the global environment, please recycle. For more information on the Waste from Electrical and Electronics Equipment (WEEE) regulations, visit http://www.acer-group.com/public/ Sustainability/index.htm

Mercury advisory

For projectors or electronic products containing an LCD/CRT monitor or display:

Lamp(s) inside this product contain mercury and must be recycled or disposed of according to local, state or federal laws. For more information, contact the Electronic Industries Alliance at www.eiae.org. For lamp-specific disposal information, check www.lamprecycle.org

"Lamp(s) contain Mercury,

Dispose Properly."

viii

First Thing First

Usage Notes

Do:

• Turn off the product before cleaning.

• Use a soft cloth moistened with mild detergent to clean the display

housing.

• Disconnect the power plug from AC outlet if the product is not being used

for a long period of time.

Don't:

• Block the slots and openings on the projector provided for ventilation.

• Use abrasive cleaners, waxes or solvents to clean the unit.

• Use under the following conditions:

• In extremely hot, cold or humid environments.

• In areas susceptible to excessive dust and dirt.

• Near any appliance that generates a strong magnetic field.

• Place in direct sunlight.

Precautions

Follow all warnings, precautions and maintenance as recommended in this user's guide to maximize the life of your unit.

Warning:

• Do not look into the projector's lens when the lamp is on. The bright light may hurt

your eyes.

• To reduce the risk of fire or electric shock, do not expose this product to rain or

moisture.

• Please do not open or disassemble the product as this may cause electric shock.

• The project will defect the life of the lamp itself. Please contact your local dealer or

Acer service center for changing the lamp, when lamp warming message displays.

• Reset the "Lamp Hour Reset" function from the Onscreen Display "Management"

menu after replacing the lamp module.

• When switching the projector off, please ensure the projector completes its cooling

cycle before disconnecting power.

• Turn on the projector first and then the signal sources.

• Do not use lens cap when projector is in operation.

• When the lamp reaches the end of its life, it will burn out and may make a loud

popping sound. If this happens, the projector will not turn back on until the lamp module has been replaced. To replace the lamp, contact your local dealer or Acer service center.

Information for Your Safety and Comfort iii

First Thing First viii

Usage Notes viii

Precautions viii

Introduction 1

Product Features 1

Package Overview 2

Projector Overview 3

Projector Outlook 3

Control Panel 4

Remote Control Layout 5

MHL Feature Introduction 7

Getting Started 8

Connecting the Projector 8

Turning the Projector On/Off 13

Turning On the Projector 13

Turning Off the Projector 14

Adjusting the Projected Image 15

Adjusting the Height of the Projected Image 15

How to Optimize Image Size and Distance 16

How to Get a Preferred Image Size by Adjusting Distance and Zoom 21

User Controls 26

Installation Menu 26

Onscreen Display (OSD) Menus 27

Color 28

Image 30

Setting 32

Management 36

Audio 36

3D 37

Language 38

Appendices 39

Contents

Troubleshooting 39

LED & Alarm Definition Listing 43

Using the inner connector(s) 44

Ceiling Mount Installation 45

Specifications 48

Compatibility Modes 52

Regulations and safety notices 56

English

Introduction

Product Features

This product is a single-chip DLP® projector, including the following outstanding features:

• DLP

technology

• X1185/P1185: Native 800 x 600 SVGA resolution, Auto/4:3/16:9 aspect ratio

supported X1285/S1285/P1285: Native 1024 x 768 XGA resolution, Auto/4:3/16:9 aspect ratio supported P1385W/X1385WH: Native 1280 x 800 WXGA resolution,Auto/Full/4:3 /16:9/ L.Box aspect ratio supported P1520/H6515BD: Native 1920 x 1080 1080p resolution,Auto/Full/4:3/16:9/ L.Box aspect ratio supported

• Enables projecting 3D content via DLP Link Technology: Blu-Ray 3D

supported (P1185/P1285/P1385W/X1385WH/P1520/H6515BD)

• One-touch "3D" button on remote control allows quick and easy access to

the 3D functions

• Acer ColorBoost technology delivers vivid, life-like images

• High brightness and contrast ratio

• Versatile display modes enable optimum performance in any situation

• NTSC/PAL/SECAM compatible and HDTV (720p, 1080i, 1080p) supported

• Lower power consumption and economy (ECO) mode extends lamp life

• Dynamic Black / ExtremeEco functions help decrease lamp power

consumption and further extend lamp life.

- Dynamic Black: If turned on, the projector dynamically adjusts the power

consumption of the lamp according to the brightness of the image being projected. When projecting darker images the power consumption will be reduced and the contrast of the image will also be enhanced.

- ExtremeEco: The projector will decrease the power consumption of the

lamp by up to 70% when no input signal can be detected for 5 minutes.

• Acer EcoProjection Technology delivers Intelligent power management

approach and physical efficiency improvement

• Advanced keystone correction delivers optimum presentations

• Multi-language Onscreen Display (OSD) menus

• Manual focus/zoom projection lens

• 2X digital zoom and pan move function

• Microsoft

Windows® 2000, XP, 7, 8, 8.1, Vista®, Macintosh OS compliant

English

Package Overview

This projector comes with all the items shown below. Check to make sure you have them all. Contact your dealer immediately if any thing is missing.

Projector

Power cord VGA cable Security card

User’s guide (CD-ROM) Remote control Quick start guide

Battery x 2 Carrying case

(Optional)

Dust filter

(Optional)

WirelessHD dongle kit

(MWIHD1)

(Optional)

X1185/X1285/P1185/X1385WH P1285/P1385W/P1520/H6515BD S1285

English

Projector Overview

Projector Outlook

Front/upper side

Rear side

# Description # Description

1 Control panel 4 HDMI (MHL) connector

Micro USB cable 2 Power key and Power indicator LED 5 Projection lens 3 Zoom ring and Focus ring

Focus ring

6 Remote control receiver 7Lens cap

# Description # Description

1 Audio input connector

Audio output connector

7 Analog RGB signal/HDTV/

component video input connector

2 S-Video input connector

Composite video input connector

8 Monitor loop-through output

connector 3 DC 5V output 9 RS232 connector 4 Mini USB connector 10 Kensington™ lock port 5 HDMI (MHL) connector 11 Power socket 6 Component video input connector 12 Tilt adjusting wheel

X1185/X1285/P1185/X1385WH P1285/P1385W/P1520/H6515BD S1285

S-VIDEO

VGA IN -2 VGA IN -1 VGA-OUT RS232

USB

MINI-B

AUDIO IN -1

AUDIO IN -2

AUDIO OUT

VIDEO

S-VIDEO

VGA IN -2 VGA IN -1 VGA-OUT RS232

USB

MINI-B

AUDIO IN -1

AUDIO IN -2

AUDIO OUT

VIDEO

USB

MINI-B

AUDIO IN -1

AUDIO IN -2

AUDIO OUT

VGA IN -1

RS232

S-VIDEO

HDMI / MHL

VIDEO

USB

MINI-B

AUDIO IN -1

AUDIO IN -2

AUDIO OUT

VGA IN -2

VGA IN -1

VGA-OUT

RS232

S-VIDEO

DC 5V OUT HDMI / MHL

VIDEO

P1185/P1285/P1385W/X1385WH/P1520X1185/X1285/S1285

H6515BD

1 2 4 5 6 7 9

1 2 3 4 5 7 8 91 2 4 7 8 9

10 11 12

English

Control Panel

# Function Description 1 LAMP Lamp Indicator LED. 2POWER indicator

LED

Refer to the "Turning the Projector On/Off" section.

3 Keystone Adjusts image distortion caused by tilting projection

(±40 degrees). 4 Power key Refer to the "Turning the Projector On/Off" section. 5 MENU Launches the Onscreen Display (OSD) menu, returns to

the previous step for the OSD menu operation or exits

the OSD menu. 6 MODE Chooses a display mode. 7 TEMP Temp Indicator LED. 8 SOURCE Chooses RGB, component video, S-Video, composite

video, HDMI (MHL) or HDTV source. 9 Four directional

selection keys

Selects items or makes adjustments to your selection

10 RESYNC Automatically synchronizes the projector to the input

source.

English

Remote Control Layout

# Function Description 1 POWER Refer to the "Turning the Projector On/Off" section. 2 MEDIA SETUP (No function) 3 ZOOM Zooms the projector display in or out. 4 MODE Chooses a display mode. 5

Keystone

Adjusts image distortion caused by tilting projection (±40 degrees).

Four directional selection keys

Selects items or makes adjustments to your selection.

6 Keypad 0~9 Press "0~9" to input a password in the "Setting" >

"Security" OSD.

7 VGA To change source to VGA. This connection supports

analog RGB, YPbPr (480p/576p/720p/1080i/1080p), and YCbCr (480i/576i).

8 COMPONENT To change source to Component video. This connector

supports YPbPr/YCbCr. 9 S-VIDEO To change source to S-Video. 10 HDMI™/DVI To change source to HDMI™ (or DVI). (for the model

with HDMI™ or DVI connector) 11 Infrared

transmitter

Sends signals to the projector.

X1185/X1285/S1285 P1185/X1385WH H6515BD

P1285/P1385W/P1520

English

12 FREEZE To pause the screen image. 13 SOURCE Chooses RGB, component video, S-Video, composite

video, HDMI (MHL) or HDTV source.

14 HIDE Press "HIDE" to hide screen image; press again to

display the image.

15 MENU Launches the Onscreen Display (OSD) menu, returns to

the previous step for the OSD menu operation or exits the OSD menu.

16 PgUp/PgDn For computer mode only. Use this button to select the

next or previous page. This function is only available

when connected to a computer via a USB cable. 17 VIDEO To change source to composite video. 18 RATIO Chooses an aspect ratio. 19 WIRELESS;

LAN/WiFi

(No function)

Rewind Play/Pause Stop Fast-forward

(No function)

21 SD/USB A (No function) 22 USB B (No function) 23 3D Press to open the 3D menu for adjusting 3D settings. 24 Laser Emits visible laser pointer light for presentation

purposes. This function is not available for the

projectors sold in the Japanese market.

# Function Description

English

MHL Feature Introduction

When your smart device is connected to the projector, you can use some buttons on the remote control to control your smart device. Press "MODE" for one second to enter or leave the MHL control mode. After entering the MHL control mode, press "SOURCE" to switch between the navigation mode (default), media mode and numeric mode.

# Function

Description

Navigation

mode

Media mode Numeric mode

4 MODE Long press for one second to enter or leave the

MHL control mode.

13 SOURCE After entering the MHL control mode, press to

switch between the navigation mode (default), media mode and numeric mode.

5Four

directional select keys

Up Up (No function) (No function) down down (No function) (No function) Left Left Decreases the

volume.

(No function)

Right Right Increases the

volume.

(No function)

6 Keypad 0~9 (No function) (No function) Enters 0~9. 15 MENU Goes to the

root menu.

(No function) (No function)

Rewind

(No function)

Rewinds/Plays/

Pauses/Stops/

Fast-forwards

the playing

media files.

Enters 1.

Play/Pause

Selects or enters items.

Enters 2.

Stop

Exits current page.

Enters 3.

Fast-forward

(No function) (No function)

English

Getting Started

Connecting the Projector

• X1185/X1285/S1285

Note: To ensure the projector works well with your computer, please make sure the timing of the display mode is compatible with the projector.

# Description # Description

1 Power cord 6 S-Video cable

2 VGA cable 7 RS232 cable

3 VGA to component video/HDTV adapter 8 USB cable

4 Composite video cable 9 3 RCA component cable

5 Audio cable

S-VIDEO

VGA IN -2 VGA IN -1 VGA-OUT RS232

USB

MINI-B

AUDIO IN -1

AUDIO IN -2

AUDIO OUT

VIDEO

HDTV adapter

RB G

HDTV adapter

RB G

DVD player, Set-top box,

HDTV receiver

VGA

RS232

Video/S-Video

Output

Display

Speakers

English

• P1185/P1285/P1385W/X1385WH/P1520

# Description # Description

1 Power cord 7 RS232 cable

2 VGA cable 8 USB cable

3 VGA to component video/HDTV adapter 9 3 RCA component cable

4 Composite video cable 10 HDMI (MHL) cable

5 Audio cable 11 WirelessHD dongle

6 S-Video cable 12 Wireless dongle

USB

MINI-B

AUDIO IN -1

AUDIO IN -2

AUDIO OUT

VGA IN -2

VGA IN -1

VGA-OUT

RS232

S-VIDEO

DC 5V OUT HDMI / MHL

VIDEO

HDTV adapter

DVD player, Set-top box,

HDTV receiver

VGA

RS232

Video/S-Video

Output

Display

Speakers

(P1285/P1385W/P1520)

Smartphone/

tablet

English

Note: To ensure the projector works well with your computer, please make sure the timing of the display mode is compatible with the projector. Note: Some smart devices require a converter (supplied by the smart device maker) to enable the MHL function. Note: Compatible HDMI/MHL dongles: WirelessHD (MWIHD1), MWA3, Android (MWND1), Chromecast

English

• H6515BD

Note: To ensure the projector works well with your computer, please make sure the timing of the display mode is compatible

# Description # Description

1 Power cord 8 USB cable

2 VGA cable 9 3 RCA component cable

4 Composite video cable 10 HDMI (MHL) cable

5 Audio cable 11 WirelessHD dongle

6 S-Video cable 12 Wireless dongle

7 RS232 cable

USB

MINI-B

AUDIO IN -1

AUDIO IN -2

AUDIO OUT

VGA IN -1

RS232

S-VIDEO

HDMI / MHL

VIDEO

DVD player,

Set-top box,

HDTV receiver

VGA

RS232

Video/S-Video

Output

Speakers

Smartphone/

tablet

English

with the projector. Note: Some smart devices require a converter (supplied by the smart device maker) to enable the MHL function. Note: Compatible HDMI/MHL dongles: WirelessHD (MWIHD1), MWA3, Android (MWND1), Chromecast

English

Turning the Projector On/Off

Turning On the Projector

1 Ensure that the power cord and signal cable are securely connected.

The Power LED will light red.

2 Turn on the projector by pressing (POWER) on the control panel or

remote control, and the Power indicator LED will turn blue.

3 Turn on your source (computer, notebook, video player, etc.). The

projector will detect your source automatically (when the Source Lock function is disabled).

• If the screen displays "No Signal", please make sure the signal cables are securely connected.

• If you connect to multiple sources at the same time, use "SOURCE" on the control panel or remote control, or the direct source key on the remote control to switch between inputs.

X1185/X1285/P1185/X1385WH P1285/P1385W/P1520/H6515BD S1285

1 & 2

English

Turning Off the Projector

1 To turn the projector off, press the power button. This message

appears:

"Please press power button again to complete the shutdown process"

Press the power button again.

2 The LED Power indicator will turn solid red to indicate standby mode.

3 It is now safe to unplug the power cord.

When Instant Resume is selected:

1 The LED Power indicator will turn RED and blink rapidly after the

projector is turned off, and the fan(s) will continue to operate for about 2 minutes to ensure that the system cools properly.

2 As long as the power cord remains plugged in, you can press the

power button to turn the projector immediately back on anytime during the 2-minute shutdown process.

3 Once the system has finished cooling, the LED Power indicator will

stop blinking and turn solid red to indicate standby mode.

4 It is now safe to unplug the power cord.

Warning indicators:

• "Projector Overheated. Lamp will automatically turn off soon." This onscreen message indicates that the projector has overheated. The lamp will automatically turn off, the projector will automatically shut down, and the LED Temp indicator will turn solid red. Contact your local dealer or service center.

• "Fan failed. Lamp will automatically turn off soon." This onscreen message indicates that the fan has failed. The lamp will automatically turn off, the projector will automatically shut down, and the LED Temp indicator will blink. Contact your local dealer or service center.

Note: Whenever the projector automatically shuts down and

the

LED Temp indicator turns solid red, contact your local

reseller or service center

English

Adjusting the Projected Image

Adjusting the Height of the Projected Image

The projector is equipped with two elevator feet for adjusting the image height.

To raise the image:

1 Use the front Tilt adjusting wheel to raise the image to the desired

height and angle.

2 Use the rear Tilt adjusting wheel to fine-tune the display angle.

To lower the image:

1 Use the front Tilt adjusting wheel to lower the image to the desired

height angle.

2 Use the rear Tilt adjusting wheel to fine-tune the display angle.

Tilt adjusting wheel

English

How to Optimize Image Size and Distance

Consult the table below to find the optimal image sizes achievable when the projector is positioned at a desired distance from the screen.

• SVGA

If the projector is 3 m from the screen, good image quality is possible for image sizes between 87" and 95".

Note: Remind as below figure, the space of 160 cm height is required when the projector is located at 3 m distance.

Desired

Distance

(m)

< A >

Minimum Screen Size (Min zoom) Maximum Screen Size (Max zoom)

Diagonal

(inch)

W (cm) x H (cm)

From base to top of image

(cm)

< C >

Diagonal

(inch)

W (cm) x H (cm)

From base to top of image

(cm)

< C >

1 29 59 x 44 49 32 65 x 48 53

1.5 43 88 x 66 73 48 97 x 73 80 2 58 118 x 88 97 64 129 x 97 106

2.5 72 147 x 110 121 79 161 x 121 133 3 87 176 x 132 146 95 194 x 145 160

3.5 101 206 x 154 170 111 226 x 169 186 4 116 235 x 176 194 127 258 x 194 213

4.5 130 265 x 199 218 143 290 x 218 240 5 145 294 x 221 243 159 323 x 242 266 6 174 353 x 265 291 191 387 x 290 319 7 203 412 x 309 340 222 452 x 339 373 8 232 471 x 353 388 254 516 x 387 426 9 261 529 x 397 437 286 581 x 435 479

10 289 588 x 441 485 318 645 x 484 532 11 318 647 x 485 534 349 710 x 532 585 12 347 706 x 529 582 381 774 x 581 639

Zoom Ratio: 1.1 x

3 m Desired distance

Height: 146 cm

Height: 160 cm From base to top of image

87"

95"

English

• XGA

If the projector is 3 m from the screen, good image quality is possible for image sizes between 72" and 79".

Note: Remind as below figure, the space of 133 cm height is required when the projector is located at 3 m distance.

Desired

Distance

(m)

< A >

Minimum Screen Size (Min zoom) Maximum Screen Size (Max zoom)

Diagonal

(inch)

W (cm) x H (cm)

From base to top of image

(cm)

< C >

Diagonal

(inch)

W (cm) x H (cm)

From base to top of image

(cm)

< C >

1 24 49 x 37 40 26 54 x 40 44

1.5 36 74 x 55 61 40 81 x 60 67 2 48 98 x 74 81 53 108 x 81 89

2.5 60 123 x 92 101 66 134 x 101 111 3 72 147 x 110 121 79 161 x 121 133

3.5 84 172 x 129 142 93 188 x 141 155 4 96 196 x 147 162 106 215 x 161 177

4.5 109 221 x 165 182 119 242 x 181 200 5 121 245 x 184 202 132 269 x 202 222 6 145 294 x 221 243 159 323 x 242 266 7 169 343 x 257 283 185 376 x 282 310 8 193 392 x 294 324 212 430 x 323 355 9 217 441 x 331 364 238 484 x 363 399

10 241 490 x 368 404 265 538 x 403 444 11 265 539 x 404 445 291 591 x 444 488 12 289 588 x 441 485 318 645 x 484 532

Zoom Ratio: 1.1 x

3 m Desired distance

Height: 121 cm

Height: 133 cm From base to top of image

72"

79"

English

• XGA (fixed-zoom models)

If the projector is 3 m from the screen, good image quality is possible for image sizes around 242".

Note: Remind as below figure, the space of 424 cm height is required when located at 3 m distance.

Desired

Distance

(m)

< A >

Screen Size

Diagonal

(inch)

W (cm) x H (cm)

From base to top of image

(cm)

< C >

1 81 164 x 123 141

1.5 121 246 x 184 212

2 161 328 x 246 283

2.5 202 410 x 307 353

3 242 492 x 369 424

3.5 282 574 x 430 495

4 323 656 x 492 566

4.5 363 738 x 553 636

5 403 820 x 615 707

6 484 984 x 738 848

7 565 1148 x 861 990

8 645 1311 x 984 1131

9 726 1475 x 1107 1273

10 807 1639 x 1230 1414

11 887 1803 x 1352 1555

12 968 1967 x 1475 1697

Zoom Ratio: 1.0 x

3 m Desired distance

Height: 424 cm From base to top of image

242"

English

• WXGA

If the projector is 3 m from the screen, good image quality is possible for image sizes between 84" and 93".

Note: Remind as below figure, the space of 125 cm height is required when the projector is located at 3 m distance.

Desired

Distance

(m)

< A >

Minimum Screen Size (Min zoom) Maximum Screen Size (Max zoom)

Diagonal

(inch)

W (cm) x H (cm)

From base to top of image

(cm)

< C >

Diagonal

(inch)

W (cm) x H (cm)

From base to top of image

(cm)

< C >

1 28 61 x 38 38 31 67 x 42 42

1.5 42 91 x 57 57 46 100 x 63 63 2 56 121 x 76 76 62 133 x 83 83

2.5 70 152 x 95 95 77 167 x 104 104 3 84 182 x 114 114 93 200 x 125 125

3.5 98 212 x 133 133 108 233 x 146 146 4 113 242 x 152 152 124 267 x 167 167

4.5 127 273 x 170 170 139 300 x 188 188 5 141 303 x 189 189 155 333 x 208 208 6 169 364 x 227 227 186 400 x 250 250 7 197 424 x 265 265 217 467 x 292 292 8 225 485 x 303 303 248 533 x 333 333 9 253 545 x 341 341 279 600 x 375 375

10 281 606 x 379 379 310 667 x 417 417 11 310 667 x 417 417 340 733 x 458 458 12 338 727 x 455 455 371 800 x 500 500

Zoom Ratio: 1.1 x

3 m Desired distance

Height: 114 cm

Height: 125 cm From base to top of image

84"

93"

English

• 1080p

If the projector is 3 m from the screen, good image quality is possible for image sizes between 90" and 118".

Note: Remind as below figure, the space of 154 cm height is required when the projector is located at 3 m distance.

Desired

Distance

(m)

< A >

Minimum Screen Size (Min zoom) Maximum Screen Size (Max zoom)

Diagonal

(inch)

W (cm) x H (cm)

From base to top of image

(cm)

< C >

Diagonal

(inch)

W (cm) x H (cm)

From base to top of image

(cm)

< C >

130 67 x 38

39 39 87 x 49 51

1.5 45 100 x 56

59 59 130 x 73 77

2 60 133 x 75

79 79 174 x 98 103

2.5 75 167 x 94

98 98 217 x 122 128

3 90 200 x 113 118 118 261 x 147 154

3.5 105 233 x 131

138 137 304 x 171 180

4 120 267 x 150

158 157 348 x 196 205

4.5 136 300 x 169

177 177 391 x 220 231

5 151 333 x 188

197 196 435 x 245 257

6 181 400 x 225

236 236 522 x 293 308

7 211 467 x 263

276 275 609 x 342 360

8 241 533 x 300

315 314 696 x 391 411

9 271 600 x 338

354 354 783 x 440 462

10 301 667 x 375

394 393 870 x 489 514

11 331 733 x 413

433 432 957 x 538 565

12 361 800 x 450

473 471 1043 x 587 616

Zoom Ratio: 1.3 x

3 m Desired distance

Height: 118 cm

Height: 154 cm From base to top of image

90"

118"

English

How to Get a Preferred Image Size by Adjusting Distance and Zoom

The table below shows how to achieve a desired image size by adjusting either the position or the zoom ring.

• SVGA

To obtain an image size of 70", set the projector at a distance between 2.2 m and 2.4 m from the screen and adjust the zoom level accordingly.

Desired Image Size Distance (m) Top (cm)

Diagonal (inch)

< A >

W (cm) x H (cm)

Max zoom

Min zoom

< C >

From base to top of

image < D >

30 61 x 46 1.0

40 81 x 61 1.3 1.4

50 102 x 76 1.6 1.7

60 122 x 91 1.9 2.1

101

70 142 x 107 2.2 2.4 117

80 163 x 122 2.5 2.8

134

90 183 x 137 2.8 3.1

151

100 203 x 152 3.1 3.5

168

120 244 x 183 3.8 4.1

201

150 305 x 229 4.7 5.2

251

180 366 x 274 5.7 6.2

302

200 406 x 305 6.3 6.9

335

250 508 x 381 7.9 8.6

419

300 610 x 457 9.4

503

Zoom Ratio: 1.1 x

Desired distance

Height: 117 cm From base to top of image

70" Desired image size

2.2 m

2.4 m

English

• XGA

To obtain an image size of 70", set the projector at a distance between 2.6 m and 2.9 m from the screen and adjust the zoom level accordingly.

Desired Image Size Distance (m) Top (cm)

Diagonal (inch)

< A >

W (cm) x H (cm)

Max zoom

Min zoom

< C >

From base to top of

image < D >

30 61 x 46 1.2

40 81 x 61 1.5 1.7

50 102 x 76 1.9 2.1

60 122 x 91 2.3 2.5

101

70 142 x 107 2.6 2.9 117

80 163 x 122 3.0 3.3

134

90 183 x 137 3.4 3.7

151

100 203 x 152 3.8 4.1

168

120 244 x 183 4.5 5.0

201

150 305 x 229 5.7 6.2

251

180 366 x 274 6.8 7.5

302

200 406 x 305 7.6 8.3

335

250 508 x 381 9.4 10.4

419

300 610 x 457 11.3

503

Zoom Ratio: 1.1 x

Desired distance

Height: 117 cm From base to top of image

70" Desired image size

2.6 m

2.9 m

English

• XGA (fixed-zoom models)

To obtain an image size of 70" set the projector at a distance 0.9 m from the screen.

Desired Image Size Distance (m) Top (cm)

Diagonal (inch)

< A >

W (cm) x H (cm)

Max zoom

Min zoom

< C >

From base to top of

image < D >

30 61 x 46 0.4

40 81 x 61 0.5 0.5

50 102 x 76 0.6 0.6

60 122 x 91 0.7 0.7

105

70 142 x 107 0.9 0.9 123

80 163 x 122 1.0 1.0

140

90 183 x 137 1.1 1.1

158

100 203 x 152 1.2 1.2

175

120 244 x 183 1.5 1.5

210

150 305 x 229 1.9 1.9

263

180 366 x 274 2.2 2.2

315

200 406 x 305 2.5 2.5

351

250 508 x 381 3.1 3.1

438

300 610 x 457 3.7

526

Zoom Ratio: 1.0 x

Desired distance

Height: 123 cm From base to top of image

70" Desired image size

0.9 m

English

• WXGA

To obtain an image size of 70" set the projector at a distance between 2.3 m and 2.5 m from the screen and adjust the zoom level accordingly.

Desired Image Size Distance (m) Top (cm)

Diagonal (inch)

< A >

W (cm) x H (cm)

Max zoom

Min zoom

< C >

From base to top of

image < D >

30 65 x 40 1.1

40 86 x 54 1.3 1.4

50 108 x 67 1.6 1.8

60 129 x 81 1.9 2.1

70 151 x 94 2.3 2.5 94

80 172 x 108 2.6 2.8

108

90 194 x 121 2.9 3.2

121

100 215 x 135 3.2 3.6

135

120 258 x 162 3.9 4.3

162

150 323 x 202 4.8 5.3

202

180 388 x 242 5.8 6.4

242

200 431 x 269 6.5 7.1

269

250 538 x 337 8.1 8.9

337

300 646 x 404 9.7

404

Zoom Ratio: 1.1 x

Desired distance

Height: 94 cm From base to top of image

70" Desired image size

2.3 m

2.5 m

English

• 1080p

To obtain an image size of 70" set the projector at a distance between 1.8 m and 2.3 m from the screen and adjust the zoom level accordingly.

Desired Image Size Distance (m) Top (cm)

Diagonal (inch)

< A >

W (cm) x H (cm)

Max zoom

Min zoom

< C >

From base to top of

image < D >

30 66 x 37 1.0

40 89 x 50 1.0 1.3

50 111 x 62 1.3 1.7

60 133 x 75 1.5 2.0

70 155 x 87 1.8 2.3 92

80 177 x 100 2.0 2.7

105

90 199 x 112 2.3 3.0

118

100 221 x 125 2.5 3.3

131

120 266 x 149 3.1 4.0

157

150 332 x 187 3.8 5.0

196

180 398 x 224 4.6 6.0

235

200 443 x 249 5.1 6.6

262

250 553 x 311 6.4 8.3

327

300 664 x 374 7.6

392

Zoom Ratio: 1.3 x

Desired distance

Height: 92 cm From base to top of image

70" Desired image size

1.8 m

2.3 m

English

User Controls

Installation Menu

The Installation menu provides an Onscreen Display (OSD) for projector installation and maintenance. Use the OSD only when the message "No signal" is displayed on the screen.

1 Turn on the projector by pressing (POWER) on the control panel or

remote control.

2 Press "MENU" on the control panel or remote control to launch the

OSD for projector installation and maintenance.

3 The background pattern acts as a guide to adjusting the calibration

and alignment settings, such as screen size and distance, focus and more.

Note: The OSD screenshot is for reference only and may differ from the actual design.

4 The Installation menu includes several options.

Use the up and down arrow keys to select an option, the left and right arrow keys to adjust selected option settings, and the right arrow key to enter a submenu for feature setting. The new settings will be saved automatically upon exiting the menu.

5 Press "MENU" anytime to exit the menu and return to the Acer

welcome screen.

English

Onscreen Display (OSD) Menus

The projector has multilingual Onscreen Display (OSD) menus that allow you to make image adjustments and change a variety of settings.

Using the OSD menus

• To open the OSD menu, press "MENU" on the control panel or remote

control.

• When the OSD is displayed, use to select an item in the main menu.

After selecting the desired main menu item, press to enter a submenu for feature setting.

• Use to select the desired item and adjust the settings by using

• Select the next item to be adjusted in the submenu and adjust as described

above.

• Press "MENU" on the control panel or remote control, the screen will

return to the main menu.

• To exit the OSD menu, press "MENU" on the control panel or remote

control again. It will close and the projector will automatically save the new settings.

Note: Some of the following OSD settings may not be available. Please refer to the actual OSD of your projector.

Main menu

Submenu

Setting

English

Color

Display Mode

There are many factory presets optimized for various types of images.

• Bright: For brightness optimization.

• Presentation: For meeting presentation with higher

brightness.

• Standard: For common environment.

• Movie: For brighter and general movie/video/photo

playing.

• Dark Cinema: For dark movie content.

• Video: For playing video in a bright environment.

• Picture: For graphic picture.

• Game: For game content.

• Education: For education environment.

• Sport: For sport picture.

• User: Memorize user’s settings.

Wall Color

Use this function to choose a proper color according to the wall. There are several choices, including White, Light Yellow, Light Blue, Pink and Dark Green. It will compensate for the color deviation due to the wall color to show the correct image tone.

Brightness

Adjusts the brightness of the image.

• Press to darken the image.

• Press to lighten the image.

Contrast

Controls the degree of difference between the lightest and darkest parts of the picture. Adjusting the contrast changes the amount of black and white in the image.

• Press to decrease the contrast.

• Press to increase the contrast.

Saturation

Adjusts a video image from black and white to fully saturated colors.

• Press to decrease the amount of color in the

image.

• Press to increase the amount of color in the

image.

English

Note: "Saturation" and "Tint" functions are not supported under computer mode.

Tint

Adjusts the color balance of red and green.

• Press to increase the amount of green in the

image.

• Press to increase the amount of red in the image.

Color Temperature

Adjusts the color temperature. At higher color temperatures, the screen looks colder; at lower color temperatures, the screen looks warmer.

Dynamic Black

If turned on, the projector dynamically adjusts the power consumption of the lamp according to the brightness of the image being projected. When projecting darker images the power consumption will be reduced and the contrast of the image will also be enhanced.

Gamma

Effects the representation of dark scenery. With greater gamma value, dark scenery will look brighter.

Advanced

• Ind. Color Management: Adjusts the red, green, blue,

cyan, yellow and magenta colors.

• - Ind. Hue: Changes the hue of the color selected.

• - Ind. Saturation: Adjusts a video image from black

and white to fully saturated color.

• - Ind. Gain: Adjusts the contrast levels.

• Brilliant Color: Produces an expanded on-screen color

spectrum that delivers enhanced color saturation for bright, true-to-life images. This feature is "On" by default.

• White Peaking: Increases the brightness of whites that

are near 100%. (Video sources only)

• Film Mode: Sets the image optimized to 24-frame True

Film mode for more realistic cadence of film playback during motion sequences.

• Noise Reduction: Adjusts the level of noise reduction

that helps to eliminate unwanted noise in the picture.

• Black Extension: Analyzes the current input image and

calculates an offset value which is then added to the analog to digital converter black level value. This ensures optimum black level for each analog source.

English


Projection

• Front-Desktop: The factory default setting.

• Front-Ceiling: When you select this function, the

projector inverts the image for ceiling-mounted projection.

• Rear-Desktop: When you select this function, the

projector reverses the image so that you can project behind a translucent screen.

• Rear-Ceiling: When you select this function, the

projector reverses and inverts the image at same time. You can project from behind a translucent screen with ceiling mounted projection.

Projection Mode

• Front: The factory default setting.

• Rear: Reverses the image so you can project from

behind a translucent screen.

Projection Location

• Auto: Automatically adjusts projection location of

image.

• Desktop

• Ceiling: Turns the image upside down for ceiling-

mounted projection.

Aspect Ratio

Use this function to choose your desired aspect ratio.

• Auto: Keeps the image with original width-height ratio

and maximizes the image to fit native horizontal or vertical pixels.

• Full (for WXGA/1080p models): The image will be

displayed making full use of the horizontal and vertical pixels.

• 4:3: The image will be scaled to fit the screen and

displayed using a 4:3 ratio.

• 16:9: The image will be scaled to fit the screen and

displayed using a 16:9 ratio.

• L.Box (for WXGA/1080p models): Keeps the original

signal aspect ratio and zooms in by 1.333 times.

Auto Keystone

Automatically adjusts image distortion caused by tilting projection (±40 degrees).

English

Keystone Manually adjusts image distortion caused by tilting

projection (±40 degrees).

This function is unavailable when Auto Keystone is set to "On".

Manual Keystone

Sharpness

Adjusts the sharpness of the image.

• Press to decrease the sharpness.

• Press to increase the sharpness.

H. Position (Horizontal Position)

• Press to move the image left.

• Press to move the image right.

V. Position (Vertical Position)

• Press to move the image down.

• Press to move the image up.

Frequency

Changes the projector’s refresh rate to match the frequency of your computer’s graphics card. If you experience a vertical flickering bar in the projected image, use this function to correct it.

Tracking

Synchronizes the signal timing of the display with the graphics card. If you experience an unstable or flickering image, use this function to correct it.

HDMI Color Range

Adjusts the color range of the HDMI image data to prevent color display error.

• Auto: Automatically adjusts the color range by

information from the player.

• Limited Range: Processes the input image as limited

color range data.

• Full Range: Processes the input image as full color range

data.

HDMI Scan Info

Adjusts the overscan ratio of the HDMI image on screen.

• Auto: Automatically adjusts the overscan ratio by

information from the player.

• Underscan: Always no overscan on the HDMI image.

• Overscan: Always keep overscan on the HDMI image.

English

Note: "H. Position", "V. Position", "Frequency" and "Tracking" functions are not supported under video mode.

Note: "HDMI Color Range" and "HDMI Scan Info" are only available when the input signal is HDMI.

Setting

Startup Screen

Use this function to select your desired startup screen. If you change the setting, it will take effect when you exit the OSD menu.

• Acer: The default startup screen of your Acer projector.

• User: Use the memorized picture from the "Screen

Capture" function.

Screen Capture

Use this function to customize the startup screen. To capture the image that you want to use as the startup screen, follow the instructions below. Notice Before proceeding with the following steps, make sure that the "Keystone" is set to the default value "0", and the "Aspect Ratio" is set to "4:3". For details, refer to the "Image" section.

• Change the "Startup Screen" from the default setting

"Acer" to "User".

• Select "Screen Capture" to customize the startup screen.

• A dialog box appears to confirm the action. Choose

"Yes" to use the current image as your customized startup screen. Choose "No" to cancel the screen capture and exist the Onscreen Display (OSD).

• A message appears stating that the screen capture is in

progress.

• When the screen capture is finished, the message

disappears and the original display is shown.

Source Lock

Selecting "On" enables the function and when switching input signals, you need to press "SOURCE" on the control panel or remote control, or the direct source key on the remote control. When this function is disabled, the projector will detect your source automatically.

Closed Caption

Selects a preferred closed captioning mode from CC1, CC2, CC3, CC4 (CC1 displays captions in the primary language in your area). Select "Off" to turn off the captioning feature. This function is only available when a composite video or SVideo input signal is selected and its system format is NTSC.

English

VGA OUT (Standby)

Selecting "On" enables the function. The projector can output a VGA signal when it is in standby mode and the VGA IN (or VGA IN 1) and VGA OUT sockets are correctly connected to the devices.

Enabling this function slightly increases the standby power consumption.

DC 5V Out (Standby)

Selecting "On" enables the function. Both micro USB cable inside the projector and the DC 5V out port/USB A port (if available) on the back of the projector can output 5V power when it is in standby mode.

Enabling this function slightly increases the standby power consumption.

Reset

Press after choosing "Yes" to return the display

parameters on all menus to the factory default settings.

Security

Security This projector provides a useful security function for the administrator to manage the projector.

Press to change the "Security" setting. If the security

function is enabled, your must enter "Administrator Password" first before changing the security setting.

The factory default of "Administrator Password" is "1234".

• Select "On" to enable the security function. You have to

enter password depending on the "Security Mode". Please refer to "User Password" section for details.

• If "Off" is selected, you can switch on the projector

without password.

English

Security

Timeout (Min.) Once "Security" is set to "On", you can set timeout function.

• Press to select timeout duration.

• The range is from 10 to 990 minutes.

• When time is up, the projector will request you to enter

the password again.

• The factory default setting of "Timeout (Min.)" is "Off".

• Once the security function is enabled, the projector will

request you to enter password when switching on the projector. Both "User Password" and "Administrator Password" can be accepted for this dialogue.

User Password

• Press to set up or change "User Password".

• Use the numerical keys on the remote control to set the

password and press "MENU" to confirm.

• To delete the digits, Press .

• Enter the password again when you see "Confirm

Password" displayed.

• The password should be 4~8 digits in length.

• If you select "Request password only after plugging

power cord", you are requested to input the password every time the power cord is plugged.

• If you select "Always request password while projector

turns on", you are requested to input the password every time the projector is turned on.

English

Security

Administrator Password You can enter "Administrator Password" when the "Enter Administrator Password" or "Enter Password" dialogue box displays.

• Press to change "Administrator Password".

• The factory default of "Administrator Password" is

"1234". If you forget your administrator password, do the following to retrieve the administrator password:

• Enter the unique 6-digit "Universal Password" which is

printed on the Security Card that came with your

projector. This unique password will be accepted by the

projector no matter what the administrator password is.

• If the Security Card is lost, please contact your local Acer

service center. Lock User Startup Screen

This function is set to "OFF" by default. If set to "ON", the startup screen is locked and cannot be changed by the "Startup Screen" and "Screen Capture" functions.

English

Management

Audio

ECO Mode

Choose "On" to dim the projector lamp, which will also lower the power consumption, reduce noise, and extend the lamp life. Choose "Off" to return to the normal mode.

High Altitude

Choose "On" to turn on the High Altitude mode. When this function is turned on, the projector fans operate at full speed continuously to cool down the projector’s temperature.

Turn Off Mode

• Instant Off: Enables you to turn off the projector

immediately without fan cooling process by pressing the power button twice.

• Instant Resume: Enables you to restart the projector

immediately within 2 minutes after turning it off.

Auto Shutdown (Minutes)

The projector will automatically shut down while there is no signal input detected after the time you set.

AC Power On

Selecting "On" enables the function. The projector will automatically turn on when power is supplied via the power cord.

Lamp Hour Elapse Displays the lamp’s elapsed operating time (in hours).

Lamp Reminding

Choose this function to show or hide warning message when the changing lamp message is displayed. The message will show up 30 hours before end of life.

Lamp Hour Reset

Press after choosing "Yes" to reset the lamp hour

counter to 0 hours.

Volume

• Press to decrease the volume.

• Press to increase the volume.

BT Speaker Connection

• Bluetooth: Selecting "On" enables the function.

• Bluetooth Search: Press to search for available

devices. Select a device in the list of found devices. The projector will automatically try to connect to the last connected device the next time you enable the Bluetooth function.

Mute

• Choose "On" to turn mute on.

• Choose "Off" to turn mute off.

Alarm Volume

Select this function to adjust the volume of any warning notifications.

English

Note: Supported 3D signal timings:

Selects "On" to enable the 3D function supported by DLP 3D technology.

• On: Select this item while using DLP 3D glasses, quad

buffer (NVIDIA/ATI...) graphics card and HQFS format file or DVD with corresponding SW player.

• Off: Turns off the 3D mode.

2D to 3D

• 2D to 3D: Converts 2D contents to 3D. Note that DLP 3D

glasses are required to obtain the best 3D effect.

• Mode: Provides several preset 2D to 3D conversion

modes for your selection. You can also select User and use the "Convergence" and "Depth" functions described below to setup your customized conversion mode.

• Convergence: Changes the convergence effect that is

used when converting 2D contents to 3D.

• Depth: Adjusts the image depth of 3D objects.

"Depth" and "Convergence" are only available when "Mode" is set to "User".

3D Format

If the 3D content is not displayed correctly, you can select a 3D format that suits the 3D content you are viewing and obtain the best result.

3D Sync Invert

If you see a discrete or overlapping image while wearing DLP 3D glasses, you may need to execute "Invert" to get best match of left/right image sequence to get the correct image (for DLP 3D).

24P 3D Choose 96Hz or 144Hz for 24p 3D.

3D Warning Message

Choose "On" to display the 3D warning message.

Signal source type Supported timing

Video/S-Video/Component video

HQFS 3D (480i@60Hz), 576i@50Hz

English

It needs correct settings on graphics card 3D application program for correct 3D display.

The SW players, such as Stereoscopic Player and DDD TriDef Media Player can support 3D format files. You can download these players on the web page below.

- Stereoscopic Player (Trial): http://www.3dtv.at/Downloads/Index_en.aspx

- DDD TriDef Media Player (Trial): http://www.tridef.com/download/TriDef3-D-Experience-4.0.2.html

Note: "3D Sync Invert" and "3D Format" are only available when "3D" is enabled.

Language

VGA/HDMI (PC mode) 640 x 480@50/60/100/120Hz

800 x 600@50/60/100/120Hz 1024 x 768@50/60/100/120Hz 1280 x 800@50/60/100/120Hz (RB)

HDMI (Video mode) HQFS 3D (480i@60Hz) , 576i@50Hz,

Frame Packing (1080p@23.98/24Hz, 720p@50/60Hz) Side-by-Side Horizontal (1080i@50/60Hz, 1080p@50/60Hz) Top-and-Bottom (720p@50/60Hz, 1080p@23.97/24Hz, 1080p@50/60Hz)

Language

Sets a language for the OSD menus. Use to select your preferred language.

English

Appendices

Troubleshooting

If you experience a problem with your Acer projector, refer to the following troubleshooting guide. If the problem persists, please contact your local reseller or service center.

Image Problems and Solutions

# Problem Solution

1 No image appears

onscreen

• Make sure all the cables are correctly connected as

described in the "Getting Started" section.

• Ensure none of the connector pins are bent or

broken.

• Check if the projection lamp has been securely

installed. Please refer to the "Using the inner connector(s)" section.

• Make sure the projector is switched on.

2 Partial, scrolling

or incorrectly displayed image (For PC (Windows 95/98/2000/XP/ Win7/Vista))

• Press "RESYNC" on the control panel or remote

control.

• For an incorrectly displayed image:

• Open "My Computer > Control Panel," and

then double-click the "Display" icon.

• Select the "Settings" tab.

• Verify that your display resolution setting is

lower than or equal to 1600 x 1200 or 1920 x

1080.

• Click the "Advanced Properties" button.

If the problem still appears, change the monitor display you are using and follow the steps below:

• Verify that the resolution setting is lower than

or equal to 1600 x 1200 or 1920 x 1080.

• Click the "Change" button under the

"Monitor" tab.

• Click "Show all devices > Standard monitor

types" under the SP box, and choose the resolution mode you need under the "Models" box.

• Verify that the resolution setting of the

monitor display is lower than or equal to 1600 x 1200 or 1920 x 1080.

English

3 Partial, scrolling

or incorrectly displayed image (For notebooks)

• Press "RESYNC" on the control panel or remote

control.

• For an incorrectly displayed image:

• Follow the steps for item 2 (above) to adjust

the resolution of your computer.

• Press the toggle output settings. Example:

[Fn]+[F4], Compaq [Fn]+[F4], Dell [Fn]+[F8], Gateway [Fn]+[F4], IBM [Fn]+[F7], HP [Fn]+[F4], NEC [Fn]+[F3], Toshiba [Fn]+[F5]

• If you experience difficulty changing resolutions or

your monitor freezes, restart all equipment including the projector.

4 The screen of the

notebook computer is not displaying your presentation

• If you are using a Microsoft

Windows® based notebook: Some notebook PCs may deactivate their own screens when a second display device is in use. Each has a different way to be reactivated. Refer to your computer's manual for detailed information.

• If you are using an Apple

Mac® OS based notebook: In System Preferences, open Display and select Video Mirroring "On."

5 Image is unstable

or flickering

• Use "Tracking" to correct it. Refer to the "Image"

section for more information.

• Change the display color setting on your computer.

6 Image has vertical

flickering bar

• Use "Frequency" to make an adjustment. Refer to

the "Image" section for more information.

• Check and reconfigure the display mode of your

graphics card to make it compatible with the projector.

7 Image is out of

focus

• Adjust the focus ring on the projector lens.

• Make sure the projection screen is within the

required distance: X1185/P1185/X1285/P1285/P1385W/X1385WH:

4.6 to 24.9 feet (1.4 to 7.6 meters) S1285:

4.9 to 24.9 feet (1.5 to 7.6 meters) P1520/H6515BD:

3.8 to 24.9 feet (1.15 to 7.6 meters) Refer to the "How to Get a Preferred Image Size by

Adjusting Distance and Zoom" section for more information.

English

Problems with the Projector

8 Image is stretched

when displaying a "widescreen" DVD title

When you play a DVD encoded in anamorphic or 16:9 aspect ratio you may need to adjust the following settings:

• If you play a 4:3 format DVD title, please change the

format to 4:3 with the projector OSD.

• If the image is still stretched, you will also need to

adjust the aspect ratio. Set up the display format to 16:9 (wide) aspect ratio on your DVD player.

9 Image is too small

or too large

• Adjust the zoom lever on the top of the projector.

• Move the projector closer to or further from the

screen.

• Press "MENU" on the control panel or remote

control. Go to "Image" > "Aspect Ratio" and try different settings.

10 Image has slanted

sides

• If possible, reposition the projector so that it is

centered on the screen and below the bottom of the screen.

• Press the Keystone correction keys on the control

panel or remote control until the image becomes square.

• Press "MENU" on the control panel or remote

control to open the OSD menu. Go to "Image" > "Auto Keystone" or "Image" > "Keystone" to make adjustments.

11 Image is reversed

• Select "Image" > "Projection Mode", "Image" >

"Projection Location" on the OSD and adjust the projection direction.

# Condition Solution

1 The projector stops responding

to all controls

If possible, turn off the projector, then unplug the power cord and wait at least 30 seconds before reconnecting power.

2 Lamp burns out or makes a

popping sound

When the lamp reaches the end of its useful life, it will burn out and may make a loud popping sound. If this happens, the projector will not turn on until the lamp module has been replaced. To replace the lamp, contact your local dealer or Acer service center.

English

OSD Messages

# Condition Message Reminder

1 Message Fan Fail - the system fan is not working.

Projector Overheated - the projector has exceeded its recommended operating temperature and must be allowed to cool down before it is used. Please also check the dust filters if they are installed. If the dust filter is clogged with dust, please clean it.

Replace the lamp - the lamp is about to reach its maximum lifetime. Prepare to replace it soon.

Fan Fail.

Lamp will automatically turn off soon.

Projector Overheated.

Lamp will automatically turn off soon.

Lamp is approaching the end of its useful life in full power operation.

Replacement suggested!

English

LED & Alarm Definition Listing

LED Messages

Message Power LED LAMP LED TEMP LED

Red Blue Red Red

Standby (Power cord plugged in)

V-- -- --

Power on -- V -- --

Lamp retry -- Quick

flashing

-- --

Turning off (Cooling state)

Quick

flashing

-- -- --

Turning off (Cooling completed)

V-- -- --

Error (Thermal failure) -- V -- V

Error (Fan lock failure) -- V -- Quick

flashing

Error (Lamp breakdown) -- V V --

Error (Color wheel failure)

-- V Quick flashing

English

Using the inner connector(s)

Turn the projector off by pressing (POWER). Allow the projector at least 45 minutes to cool down. Disconnect the power cord.

1 Use a screwdriver to remove the screw(s) from the cover. (Illustration #1)

2 Push up and remove the cover. (Illustration #2)

3 Locate the HDMI (MHL) connector and/or USB Type A connector beside the

focus/zoom ring.

4 Insert the WirelessHD (MWIHD1) dongle or other HDMI/MHL dongle into

the HDMI (MHL) connector. (Illustration #3)

5 A micro USB cable is also available if you need to power the HDMI/MHL

dongle.

6 Replace the cover and tighten the screw(s). (Illustration #4 - #5)

English

Ceiling Mount Installation

If you wish to install the projector using a ceiling mount, please refer to the steps below:

1 Drill four holes into a solid, structurally sound part of the ceiling, and

secure the mount base.

Note: Screws are not included. Please obtain the appropriate screws for your type of ceiling.

2 Secure the ceiling rod using the appropriate type of cylinder screws.

8.4

130 mm

49.9

Short Rod

Screw Type A

50 mm length / 8 mm diameter -

Ceiling Mount Base

- Attach to ceiling

Long Rod

Extension Rod

Allen Key

- For tighten/loosen

Tightening Screw

Medium Rod

Large Cylinder Cap

English

3 Use the appropriate number of screws for the projector size to attach the

projector to the ceiling mount bracket.

Note: It is recommended that you keep a reasonable space between the bracket and the projector to allow for proper heat distribution. Use two washers for extra support, if deemed necessary.

4 Attach the ceiling bracket to the ceiling rod.

Smaller Washer

Large Washer

Projector Bracket Supports projector and allows for adjustments

Screw Type B

Spacer

- For heat dissipation

Screw Type A 50 mm length /8 mm diameter

Large Cylinder Cap

Allen Key

- For tighten/loosen

Tightening Screw

English

5 Adjust the angle and positioning as necessary.

Note: The appropriate type of screw and washer for each model is listed in the table below. 4 mm diameter screws are enclosed in the screw pack.

Screw Type B Washer Type

Diameter (mm) Length (mm) Large Small

425VV

Allen Key

Tightening Screw

Allen Key

Tightening Screw

121.61 mm

89.40 mm

19.23 mm

48.39 mm

English

Specifications

The specifications below are subject to change without notice. For final specs, please refer to Acer's marketing documentation.

Projection system

DLP

™

Resolution

• X1185/P1185:

Native: SVGA (800 x 600) Maximum: UXGA (1600 x 1200), 1080p (1920 x 1080),

WUXGA (1920 x 1200) (supports reduce blanking only)

• X1285/S1285/P1285:

Native: XGA (1024 x 768) Maximum: UXGA (1600 x 1200), 1080p (1920 x 1080),

WUXGA (1920 x 1200) (supports reduce blanking only)

• P1385W/X1385WH:

Native: WXGA (1280 x 800) Maximum: UXGA (1600 x 1200), 1080p (1920 x 1080),

WUXGA (1920 x 1200) (supports reduce blanking only)

• P1520/H6515BD

Native: 1080p (1920 x 1080) Maximum: WUXGA (1920 x 1200) (supports reduce

blanking only)

Computer compatibility Refer to the "Compatibility Modes" section for more

information.

Video compatibility NTSC (3.58/4.43), PAL (M/N), PAL 60, SECAM, HDTV

(720p, 1080i, 1080p), EDTV (480p, 576p), SDTV (480i, 576i)

Aspect ratio

• X1185/P1185/X1285/S1285/P1285:

Auto, 4:3 (native), 16:9

• P1385W/X1385WH/P1520/H6515BD:

Auto, 4:3, 16:9, Full, L.BOX

Displayable colors 1.07 billion colors

Projection lens

• X1185/P1185:

F = 2.56 - 2.68, f = 22.04 mm - 24.14 mm,

1:1.1 Manual Zoom and Manual Focus

• X1285/P1285:

F = 2.56 - 2.8, f = 21.00 mm - 23.10 mm,

1:1.1 Manual Zoom and Manual Focus

• S1285:

F = 2.6, f = 6.9 mm,

1:1.0 Manual Zoom and Manual Focus

• P1385W/X1385WH:

F = 2.56 - 2.8, f = 21.00 mm - 23.10 mm,

1:1.1 Manual Zoom and Manual Focus

• P1520/H6515BD:

F = 2.59 - 2.87, f = 16.88 mm - 21.88 mm,

1:1.3 Manual Zoom and Manual Focus

English

Projection screen size (diagonal) with clear focus

• X1185/P1185:

54" (138 cm) - 300" (762 cm)

• X1285/P1285:

55" (138 cm) - 300" (762 cm)

• S1285:

60" (152 cm) - 300" (762 cm)

• P1385W/X1385WH:

55" (139 cm) - 300" (762 cm)

• P1520/H6515BD:

45" (115 cm) - 300" (762 cm)

Projection distance with clear focus

• X1185/P1185:

7.8' (2.4 m) - 39.2' (11.9 m)

• X1285/P1285:

7.4' (2.3 m) - 37.2' (11.3 m)

• S1285:

2.4' (0.7 m) - 12.2' (3.7 m)

• P1385W/X1385WH:

6.4' (1.9 m) - 31.8' (9.7 m)

• P1520/H6515BD:

4.9' (1.5 m) - 25.1' (7.6 m)

Throw ratio

• X1185/P1185/X1285/P1285:

78"±3% @ 3.1 m (1.96 - 2.15)

• S1285:

78"±3% @ 0.96 m (0.61)

• P1385W/X1385WH:

87"±3% @ 2.9 m (1.55 - 1.7)

• P1520/H6515BD:

95"±3% @ 2.42 m (1.15 - 1.5)

Horizontal scan rate 31 - 99 KHz

Vertical refresh scan rate 23 - 120 Hz

Keystone correction

• P1185/P1285/P1385W/X1385WH/P1520/

H6515BD:

+/-40 Degrees (Vertical), Manual & Auto

• X1185/X1285/S1285:

+/-40 Degrees (Vertical), Manual

Digital zoom 2 X

Audio

• X1185/X1285/S1285/P1185/X1385WH:

3W x 1

• P1285/P1385W/P1520/H6515BD:

10W x 1

Weight Approximate 3.3 kg (7.26 lbs.)

Dimensions (W x D x H) 415 x 320 x 180 mm (13.6’ x 10.5’ x 5.9’)

Power supply Universal AC input 100 - 240 V, input frequency 50/60

English

Power consumption (typical)

• X1185/P1185/X1285/S1285/P1285/P1385W/

X1385WH:

190 W

• P1520/H6515BD:

210 W

Operating temperature 0ºC to 40ºC / 32ºF to 104ºF

I/O connectors X1185/X1285/S1285:

• Power socket x 1

• USB x 1 (Type mini B)

• VGA input x 2

• VGA output x 1

• RS232 x 1

• Composite video x 1

• S-Video x 1

• 3.5 mm audio jack input x 2

• 3.5 mm audio jack output x 1

P1185/X1385WH:

• Power socket x 1

• USB x 1 (Type mini B)

• VGA input x 2

• VGA output x 1

• RS232 x 1

• Composite video x 1

• S-Video x 1

• HDMI/MHL x 1

• USB Type A (DC 5V OUT) x 1

• 3.5 mm audio jack input x 2

• 3.5 mm audio jack output x 1

English

* Design and specifications are subject to change without notice.

P1285/P1385W/P1520:

• Power socket x 1

• USB x 1 (Type mini B)

• VGA input x 2

• VGA output x 1

• RS232 x 1

• Composite video x 1

• S-Video x 1

• HDMI/MHL x 2

• USB Type A (DC 5V OUT) x 1

• 3.5 mm audio jack input x 2

• 3.5 mm audio jack output x 1

• Micro USB cable x 1

H6515BD:

• Power socket x 1

• USB x 1 (Type mini B)

• VGA input x 1

• VGA output x 1

• Component video input x 1

• RS232 x 1

• Composite video x 1

• S-Video x 1

• HDMI/MHL x 2

• USB Type A (DC 5V OUT) x 1

• 3.5 mm audio jack input x 2

• 3.5 mm audio jack output x 1

• Micro USB cable x 1

Standard package contents

• AC power cord x 1

• VGA cable x 1

• Remote control x 1

• Battery x 2 (for the remote control)

• User's guide (CD-ROM) x 1

• Quick start guide x 1

• Security card x 1

Accessory (optional)

• Composite video cable x 1

• Carrying case x 1

• Dust filter x 1

• WirelessHD dongle kit (MWIHD1) x 1

English

Compatibility Modes

1 VGA Analog - PC Signal

Mode Resolution V.Frequency [Hz]

H.Frequency

[KHz]

VGA 640 x 480

60 31.47

72 37.86

75 37.50

85 43.27

120 61.91

SVGA 800 x 600

56 35.20

60 37.88

72 48.08

75 46.88

85 53.67

120 77.43

XGA 1024 x 768

60 48.36

70 56.48

75 60.02

85 68.68

120 98.96

SXGA

1152 x 864

70 63.85

75 67.50

85 77.10

1280 x 1024

60 63.98

72 76.97

75 79.98

85 91.15

QuadVGA

1280 x 960 60 60.00

1280 x 960 75 75.00

SXGA+ 1400 x 1050 60 65.32

UXGA 1600 x 1200 60 75.00

PowerBook G4

640 x 480 60 31.50

640 x 480 66.6 (67) 35.00

800 x 600 60 37.88

1024 x 768 60 48.36

1024 x 768 75 60.241

1152 x 870 75 68.681

English

2 HDMI - PC Signal

WXGA

1280 x 768 60 47.78

1280 x 768 75 60.29

1280 x 768 85 68.63

1280 x 720 60 45.00

1280 x 800 60 49.70

1280 x 800 - RB 120 101.6

1440 x 900 60 55.94

1680 x 1050 60 65.29

1366 x 768 60 47.71

1920 x 1080-RB 60 66.60

1920 x 1080-EIA 60 67.50

1024 x 600 60 37.50

1920 x 1200-RB 59.95 74.04

Mode Resolution V.Frequency [Hz]

H.Frequency

[KHz]

VGA_60

640 x 480

59.94 31.469

VGA_72 72.809 37.861

VGA_75 75 37.5

VGA_85 85.008 43.269

VGA_120 119.518 61.91

SVGA_56

800 x 600

56.25 35.156

SVGA_60 60.317 37.879

SVGA_72 72.188 48.077

SVGA_75 75 46.875

SVGA_85 85.061 53.674

SVGA_120 119.854 77.425

XGA_60

1024 x 768

60.004 48.363

XGA_70 70.069 56.476

XGA_75 75.029 60.023

XGA_120 119.804 98.958

SXGA_75

1152 x 864

75 67.5

SXGA_85 84.99 77.094

SXGA_60

1280 x 1024

60.02 63.981

SXGA_72 72 76.97

SXGA_75 75.025 79.976

SXGA_85 85.024 91.146

QuadVGA_75 1280 x 960 75 75

English

3 HDMI - Video Signal

SXGA+_60 1400 x 1050 59.978 65.317

UXGA_60 1600 x 1200 60 75

Mac G4 640 x 480@60Hz 59.94 31.469

MAC13 640 x 480@67Hz 66.667 35

Mac G4 800 x 600@60Hz 60.317 37.879

Mac G4 1024 x 768@60Hz 60.004 48.363

MAC19 1024 x 768@75Hz 75.02 60.241

MAC21 1152 x 870@75Hz 75.061 68.681

WXGA_60

1280 x 768

59.87 47.776

WXGA_75 74.893 60.289

WXGA_85 84.837 68.633

WXGA_60 1280 x 720 60 45

WXGA_60 1280 x 800 59.81 49.702

WXGA_120-RB 1280 x 800 119.909 101.563

WXGA+_60 1440 x 900 59.887 55.935

1680x1050_60 1680 x 1050 59.954 65.29

acer_16:9 1366 x 768 59.79 47.712

1920 x 1080_RB 1920 x1080 60 66.587

1920 x 1080_EIA 1920 x1080 60 67.5

acer_timing 1024 x 600 60 37.5

1920 x 1200-RB 1920 x 1200 59.95 74.038

Mode Resolution V.Frequency [Hz] H.Frequency [KHz]

480i

720 x 480

(1440 x 480)

60 15.73

480p 720 x 480 60 31.47

576i

720 x 576

(1440 x 576)

50 15.63

576p 720 x 576 50 31.25 720p 1280 x 720 60 45.00

720p 1280 x 720 50 37.50 1080i 1920 x 1080 60 33.75 1080i 1920 x 1080 50 28.13

1080p 1920 x 1080 60 67.50 1080p 1920 x 1080 50 56.26 1080p 1920 x 1080 24 27.00 1080p 1920 x 1080 23.98 26.97

English

4 MHL - Video Signal

5 YPbPr Signal

6 Video, S-Video Signal

Mode Resolution V.Frequency [Hz] H.Frequency [KHz]

480i

720 x 480

(1440 x 480)

60 15.73

480p 720 x 480 60 31.47

576i

720 x 576

(1440 x 576)

50 15.63

576p 720 x 576 50 31.25 720p 1280 x 720 60 45.00

720p 1280 x 720 50 37.50 1080i 1920 x 1080 60 33.75 1080i 1920 x 1080 50 28.13

1080p 1920 x 1080 24 27.00 1080p 1920 x 1080 23.98 26.97 1080p 1920 x 1080 30 33.75

Mode Resolution V.Frequency [Hz] H.Frequency [KHz]

480i

720 x 480

59.94 15.73

480p

720 x 480

59.94 31.47

576i

720 x 576

50.00 15.63

576p

720 x 576

50.00 31.25

720p

1280 x 720

60.00 45.00

720p

1280 x 720

50.00 37.50

1080i

1920 x 1080

60.00 33.75

1080i

1920 x 1080

50.00 28.13

1080p

1920 x 1080

60.00 67.5

1080p

1920 x 1080

50.00 56.26

1080p

1920 x 1080

24.00 27.00

1080p

1920 x 1080

23.98 26.97

Mode V.Frequency [Hz] H.Frequency [KHz] fsc (MHz)

NTSC 15.73 60

3.58

PAL 15.63 50

4.43

SECAM 15.63 50

4.25 or 4.41

PAL-M 15.73 60

3.58

PAL-N 15.63 50

3.58

PAL-60 15.73 60

4.43

NTSC4.43 15.73 60

4.43

English

Regulations and safety notices

FCC notice

This device has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This device generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If this device does cause harmful interference to radio or television reception, which can be determined by turning the device off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the device and receiver.

• Connect the device into an outlet on a circuit different from that to which

the receiver is connected.

• Consult the dealer or an experienced radio/television technician for help.

Notice: Shielded cables

All connections to other computing devices must be made using shielded cables to maintain compliance with FCC regulations.

Notice: Peripheral devices

Only peripherals (input/output devices, terminals, printers, etc.) certified to comply with the Class B limits may be attached to this equipment. Operation with non-certified peripherals is likely to result in interference to radio and TV reception.

Caution

Changes or modifications not expressly approved by the manufacturer could void the user's authority, which is granted by the Federal Communications Commission, to operate this device.

Operation conditions

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Notice: Canadian users

This Class B digital apparatus complies with Canadian ICES-003.

English

Remarque à l'intention des utilisateurs canadiens

Cet appareil numérique de la classe B est conforme a la norme NMB-003 du Canada.

Declaration of Conformity for EU countries

Acer hereby, declares that this projector series is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC.

Compliant with Russian regulatory certification

Radio device regulatory notice

Note: The regulatory information below is for models with wireless LAN and/or Bluetooth only.

General

This product complies with the radio frequency and safety standards of any country or region in which it has been approved for wireless use. Depending on configurations, this product may or may not contain wireless radio devices (such as wireless LAN and/or Bluetooth modules).

Canada — Low-power license-exempt radio communication devices (RSS-210)

a Common information

Operation is subject to the following two conditions:

1. This device may not cause interference, and

2. This device must accept any interference, including interference that may cause undesired operation of the device.

b Operation in 2.4 GHz band

To prevent radio interference to the licensed service, this device is intended to be operated indoors and installation outdoors is subject to licensing.

English

List of applicable countries

This device must be used in strict accordance with the regulations and constraints in the country of use. For further information, please contact a local office in the country of use. Please see http://ec.europa.eu/enterprise/rtte/implem.htm for the latest country list.

English

Acer Incorporated

8F, 88, Sec. 1, Xintai 5th Rd., Xizhi

New Taipei City 221, Taiwan

Declaration of Conformity

We,

Acer Incorporated

8F, 88, Sec. 1, Xintai 5th Rd., Xizhi, New Taipei City 221, Taiwan Contact Person: Mr. RU Jan, e-mail:ru_jan@acer.com.tw

And,

Acer Italy s.r.l

Via Lepetit, 40, 20020 Lainate (MI) Italy Tel: +39-02-939-921, Fax: +39-02 9399-2913 www.acer.it

Declare under our own responsibility that the product:

Product: DLP Projector Trade Name: Acer Model Number: X1185/D203/EV-S55/V23S/AS306/QSV1407/X1285/D213/EV-X55/

V23X/AX306/QNX1408/S1285/T213/XS-X14/QNX1419/P1185/M303/ PE-S35/F23S/AS326/QSV1410/P1285/M313/PE-X35/F23X/AX326/ QNX1411/P1385W/M323/PE-W35/F23W/AW327/QWX1413/ X1385WH/D223D/EV-W55H/V23W/AW317/QWX1409/P1520/M345/ PE-845/Q1P1415/H6515BD/E341D/HE-813J/H1P1418 series

To which this declaration refers conforms to the relevant standard or other standardizing documents:

• EN55022:2010 Class B; EN 55024:2010

• EN61000-3-2:2006+A1:2009+A2:2009, Class A

• EN61000-3-3:2008

• EN 60950-1:2006/A11:2009/A1:2010+A12:2011

• Regulation (EC) No. 1275/ 2008; EN 62301:2005

• EN50581:2012

We hereby declare above product is in compliance with the essential requirements and other relevant provisions of EMC Directive 2004/108/EC, Low Voltage Directive 2006/95/EC and RoHS Directive 2011/ 65/EU and Directive 2009/125/EC with regard to establishing a framework for the setting of ecodesign requirements for energy-related product.

Year to begin affixing CE marking 2015.

Jan. 26, 2015 -

RU Jan/Sr. Manager Date Regulation Center, Acer Inc.

English

Acer America Corporation

333 West San Carlos St.,

Suite 1500

San Jose, CA 95110

U. S. A.

Tel: 254-298-4000

Fax: 254-298-4147

www.acer.com

Federal Communications Commission

Declaration of Conformity

The following local Manufacturer /Importer is responsible for this declaration:

Product: DLP Projector

Model Number: QSV1407/QNX1408/QNX1419/

QSV1410/QNX1411/QWX1413/ QWX1409/Q1P1415/H1P1418 series

Name of Responsible Party: Acer America Corporation

Address of Responsible Party: 333 West San Carlos St.

Suite 1500 San Jose, CA 95110 U. S. A.

Contact Person: Acer Representative

Phone No.: 254-298-4000

Fax No.: 254-298-4147

Acer X1185, D203, EV-S55, V23S, AS306 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
