Acer P1266N, P1266I, P1270, P1266P, P1166P User Manual

Acer Projector

P1166/P1166P/P1266/P1266P/

P1266n/P1266i/P1270 Series

User's Guide

Copyright © 2008. Acer Incorporated.
All Rights Reserved.

Acer Projector P1166/P1166P/P1266/P1266P/P1266n/P1266i/P1270 Series User's Guide
Original Issue: 01/2009

Changes may be made periodically to the information in this publication without obligation
to notify any person of such revisions or changes. Such changes will be incorporated in new
editions of this manual or supplementary documents and publications. This company makes
no representations or warranties, either expressed or implied, with respect to the contents
hereof and specifically disclaims the implied warranties of merchantability or fitness for a
particular purpose.

Record the model number, serial number, purchase date and place of purchase information in
the space provided below. The serial number and model number are recorded on the label
affixed to your projector. All correspondence concerning your unit should include the serial
number, model number and purchase information.

No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in
any form or by any means, electronically, mechanically, by photocopy, recording or otherwise,
without the prior written permission of Acer Incorporated.

Acer Projector P1166/P1166P/P1266/P1266P/P1266n/P1266i/P1270 Series

Model number: __________________________________

Serial number: ___________________________________

Date of purchase: ________________________________

Place of purchase: ________________________________

Acer and the Acer logo are registered trademarks of Acer Incorporated. Other companies' product
names or trademarks are used herein for identification purposes only and belong to their respective
companies.

TM

, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered

"HDMI
trademarks of HDMI Licensing LLC."

Information for your safety and comfort

Read these instructions carefully. Keep this document for future reference.
Follow all warnings and instructions marked on the product.

Turning the product off before cleaning

Unplug this product from the wall outlet before cleaning. Do not use liquid
cleaners or aerosol cleaners. Use a damp cloth for cleaning.

Caution for plug as disconnecting device

Observe the following guidelines when connecting and disconnecting power to
the external power supply unit:

• Install the power supply unit before connecting the power cord to the AC

power outlet.

• Unplug the power cord before removing the power supply unit from the

projector.

• If the system has multiple sources of power, disconnect power from the

system by unplugging all power cords from the power supplies.

Caution for Accessibility

Be sure that the power outlet you plug the power cord into is easily accessible
and located as close to the equipment operator as possible. When you need to

disconnect power to the equipment, be sure to unplug the power cord from the
electrical outlet.

iii

Warnings!

• Do not use this product near water.

• Do not place this product on an unstable cart, stand or table. If the product

falls, it could be seriously damaged.

• Slots and openings are provided for ventilation to ensure reliable

operation of the product and to protect it from overheating. These
openings must not be blocked or covered. The openings should never be
blocked by placing the product on a bed, sofa, rug or other similar surface.

This product should never be placed near or over a radiator or heat register, or
in a built-in installation unless proper ventilation is provided.

• Never push objects of any kind into this product through cabinet slots as

they may touch dangerous voltage points or short-out parts that could
result in a fire or electric shock. Never spill liquid of any kind onto or into
the product.

iv

• To avoid damage of internal components and to prevent battery leakage,

do not place the product on a vibrating surface.

• Never use it under sporting, exercising, or any vibrating environment

which will probably cause unexpected short current or damage rotor
devices, lamp.

Using electrical power

• This product should be operated from the type of power indicated on the

marking label. If you are not sure of the type of power available, consult
your dealer or local power company.

• Do not allow anything to rest on the power cord. Do not locate this

product where people will walk on the cord.

• If an extension cord is used with this product, make sure that the total

ampere rating of the equipment plugged into the extension cord does not
exceed the extension cord ampere rating. Also, make sure that the total
rating of all products plugged into the wall outlet does not exceed the fuse
rating.

• Do not overload a power outlet, strip or receptacle by plugging in too

many devices. The overall system load must not exceed 80% of the branch
circuit rating. If power strips are used, the load should not exceed 80% of
the power strip's input rating.

• This product's AC adapter is equipped with a three-wire grounded plug.

The plug only fits in a grounded power outlet. Make sure the power outlet
is properly grounded before inserting the AC adapter plug. Do not insert
the plug into a non-grounded power outlet. Contact your electrician for
details.

Warning! The grounding pin is a safety feature. Using a power outlet that is
not properly grounded may result in electric shock and/or injury.

Note: The grounding pin also provides good protection from unexpected
noise produced by other nearby electrical devices that may interfere with
the performance of this product.

• Use the product only with the supplied power supply cord set. If you need

to replace the power cord set, make sure that the new power cord meets
the following requirements: detachable type, UL listed/CSA certified, type
SPT-2, rated 7A 125V minimum, VDE approved or its equivalent, 4.6 meters
(15 feet) maximum length.

Product servicing

Do not attempt to service this product yourself, as opening or removing covers
may expose you to dangerous voltage points or other risks. Refer all servicing to
qualified service personnel.

Unplug this product from the wall outlet and refer servicing to qualified service
personnel when:

• the power cord or plug is damaged, cut or frayed

• liquid was spilled into the product

• the product was exposed to rain or water

• the product has been dropped or the case has been damaged

• the product exhibits a distinct change in performance, indicating a need

for service

• the product does not operate normally after following the operating

instructions

Note: Adjust only those controls that are covered by the operating
instructions, since improper adjustment of other controls may result in
damage and will often require extensive work by a qualified technician to
restore the product to normal condition.

Warning! For safety reasons, do not use non-compliant parts when adding
or changing components. Consult your reseller for purchase options.

v

Your device and its enhancements may contain small parts. Keep them out of
the reach of small children.

Additional safety information

• Do not look into the projector's lens when the lamp is on. The bright may

hurt your eyes.

• Turn on the projector first and then signal sources

• Do not place the product in following environments:

• Space that is poorly ventilated or confined. At least 50cm clearance from walls
and free flow of air around the projector is necessary.

• Locations where temperatures may become excessively high, such as inside of a
car with all windows rolled up.

• Locations where excessive humidity, dust, or cigarette smoke may contaminate
optical components, shortening the life span and darkening the image.

• Locations near fire alarms.

• Locations with an ambient temperature above 40 ºC/104 ºF.

• Locations where the altitudes are higher than 10000 feet.

• Unplug immediately if there is something wrong with your projector. Do

not operate if smoke, strange noise or odor comes out of your projector. It

vi

might cause fire or electric shock. In this case, unplug immediately and
contact your dealer.

• Do not keep using this product to break or drop it. In this case contact your

dealer for inspection.

• Do not face the projector lens to the sun. It can lead to fire.

• When switching the projector off, sugges to ensure the projector

completes its cooling cycle before disconnecting power.

• Do not turn off the main power abruptly or unplug the projector during

operation. It can lead to lamp breakage, fire, electric shock or other
trouble. The best way is to wait for the fan to turn off before turning main
power off.

• Do not touch air outlet grille and bottom plate which becomes hot.

• Clean the air filter frequently if have. The temperature inside may rise and

cause damage when the filter/ventilation slots clogged with dirt or dust.

• Do not look into the air outlet grille when projector is operating. It may

hurt your eyes.

• Always open the lens shutter or remove the lens cap when the projector is

on.

• Do not block the projector lens with any object when the projector is

under operation as this could cause the object to become heated and
deformed or even cause a fire. To temporarily turn off the lamp, press HIDE
on the projector or remote controller.

• The lamp becomes extremely hot during operation. Allow the projector to

cool for approximately 45 minutes prior to removing the lamp assembly for
replacement.

• Do not operate lamps beyond the rated lamp life. It could cause it to break

on rare occasions.

• Never replace the lamp assembly or any electronic components unless the

projector is unplugged.

• The product will detect the life of the lamp itself. Please be sure to change

the lamp when is showing warning message.

• When changing the lamp, please allow unit to cool down, and follow all

changing instructions.

• Reset the "Lamp Hour Reset" function from the Onscreen display

"Management" menu after replacing the lamp module.

• Do not attempt to disassemble this projector. There are dangerous high

voltages inside which may hurt you. The only user serviceable part is the
lamp which has its own removable cover. Refer servicing only to suitable
qualified professional service personnel.

• Do not stand the projector on end vertically. It may cause the projector to

fall over, causing injury or damage.

• This product is capable of displaying inverted images for ceiling mount

installation. Only use acer ceiling mount kit for mounting the projector
and ensure it is securely installed.

vii

Operating environment for using wireless function
(Optional)

Warning! For safety reasons, turn off all wireless or radio transmitting
devices when using your machine under the following conditions. These
devices may include, but are not limited to: wireless LAN (WLAN), Bluetooth
and/or 3G.

Remember to follow any special regulations in force in any area, and always
switch off your device when its use is prohibited or when it may cause
interference or danger. Use the device only in its normal operating positions.
This device meets RF exposure guidelines when used normally, and it and its
antenna are positioned at least 1.5 centimeters (5/8 inches) away from your
body. It should not contain metal and you should position the device the above­stated distance from your body.

To successfully transmit data files or messages, this device requires a good
quality connection to the network. In some cases, transmission of data files or
messages may be delayed until such a connection is available.

Ensure that the above separation distance instructions are followed until the
transmission is completed.

Parts of the device are magnetic. Metallic materials may be attracted to the
device, and persons with hearing aids should not hold the device to the ear with
the hearing aid. Do not place credit cards or other magnetic storage media near
the device, because information stored on them may be erased.

Medical devices

Operation of any radio transmitting equipment, including wireless phones, may
interfere with the functionality of inadequately protected medical devices.
Consult a physician or the manufacturer of the medical device to determine if
they are adequately shielded from external RF energy or if you have any
questions. Switch off your device in health care facilities when any regulations
posted in these areas instruct you to do so. Hospitals or health care facilities
may be using equipment that could be sensitive to external RF transmissions.

Pacemakers. Pacemaker manufacturers recommend that a minimum separation
of 15.3 centimeters (6 inches) be maintained between wireless devices and a
pacemaker to avoid potential interference with the pacemaker. These
recommendations are consistent with the independent research by and
recommendations of Wireless Technology Research. Persons with pacemakers
should do the following:

• Always keep the device more than 15.3 centimeters (6 inches) from the

pacemaker.

• Not carry the device near your pacemaker when the device is switched on.

If you suspect interference, switch off your device, and move it.

viii

Hearing aids. Some digital wireless devices may interfere with some hearing
aids. If interference occurs, consult your service provider.

Vehicles

RF signals may affect improperly installed or inadequately shielded electronic
systems in motor vehicles such as electronic fuel injection systems, electronic
antiskid (antilock) braking systems, electronic speed control systems, and air bag
systems. For more information, check with the manufacturer, or its
representative, of your vehicle or any equipment that has been added. Only
qualified personnel should service the device, or install the device in a vehicle.
Faulty installation or service may be dangerous and may invalidate any
warranty that may apply to the device. Check regularly that all wireless
equipment in your vehicle is mounted and operating properly. Do not store or
carry flammable liquids, gases, or explosive materials in the same compartment
as the device, its parts, or enhancements. For vehicles equipped with an air bag,
remember that air bags inflate with great force. Do not place objects, including
installed or portable wireless equipment in the area over the air bag or in the
air bag deployment area. If in-vehicle wireless equipment is improperly
installed, and the air bag inflates, serious injury could result.

Using your device while flying in aircraft is prohibited. Switch off your device
before boarding an aircraft. The use of wireless teledevices in an aircraft may be
dangerous to the operation of the aircraft, disrupt the wireless telephone
network, and may be illegal.

Potentially explosive environments

Switch off your device when in any area with a potentially explosive
atmosphere and obey all signs and instructions. Potentially explosive
atmospheres include areas where you would normally be advised to turn off
your vehicle engine. Sparks in such areas could cause an explosion or fire
resulting in bodily injury or even death. Switch off the device at refueling points
such as near gas pumps at service stations. Observe restrictions on the use of
radio equipment in fuel depots, storage, and distribution areas; chemical plants;
or where blasting operations are in progress. Areas with a potentially explosive
atmosphere are often, but not always, clearly marked. They include below deck
on boats, chemical transfer or storage facilities, vehicles using liquefied
petroleum gas (such as propane or butane), and areas where the air contains
chemicals or particles such as grain, dust or metal powders.

Caution for Listening

To protect your hearing, follow these instructions.

• Increase the volume gradually until you can hear clearly and comfortably.

• Do not increase the volume level after your ears have adjusted.

• Do not listen to music at high volumes for extended periods.

• Do not increase the volume to block out noisy surroundings.

• Decrease the volume if you can't hear people speaking near you.

Disposal instructions

Do not throw this electronic device into the trash when discarding. To minimize
pollution and ensure utmost protection of the global environment, please
recycle. For more information on the Waste from Electrical and Electronics
Equipment (WEEE) regulations, visit http://global.acer.com/about/
sustainability.htm

Mercury advisory

For projectors or electronic products containing an LCD/CRT monitor or display:

“Lamp(s) contain Mercury,
Dispose Properly.”

Lamp(s) inside this product contain mercury and must be recycled or disposed of
according to local, state or federal laws. For more information, contact the
Electronic Industries Alliance at www.eiae.org. For lamp-specific disposal
information, check www.lamprecycle.org

ix

x

First things first

Usage Notes

Do:

• Turn off the product before cleaning.

• Use a soft cloth moistened with mild detergent to clean the display

housing.

• Disconnect the power plug from AC outlet if the product is not being used

for a long period of time.

Don't:

• Block the slots and openings on the unit provided for ventilation.

• Use abrasive cleaners, waxes or solvents to clean the unit.

• Use under the following conditions:

• In extremely hot, cold or humid environments.

• In areas susceptible to excessive dust and dirt.

• Near any appliance that generates a strong magnetic field.

• Place In direct sunlight.

Precautions

Follow all warnings, precautions and maintenance as recommended in this
user's guide to maximize the life of your unit.

Warning:

• Do not look into the projector's lens when the lamp is on. The bright light may hurt

your eyes.

• To reduce the risk of fire or electric shock, do not expose this product to rain or

moisture.

• Please do not open or disassemble the product as this may cause electric shock.

• When changing the lamp, please allow unit to cool down, and follow all changing

instructions.

• This product will detect the life of the lamp itself. Please be sure to change the lamp

when it shows warning messages.

• Reset the "Lamp Hour Reset" function from the Onscreen display "Management"

menu after replacing the lamp module.

• When switching the projector off, please ensure the projector completes its cooling

cycle before disconnecting power.

• Turn on the projector first and then the signal sources.

• Do not use lens cap when projector is in operation.

• When the lamp reaches the end of its life, it will burn out and may make a loud

popping sound. If this happens, the projector will not turn back on until the lamp
module has been replaced. To replace the lamp, follow the procedures listed under
"Replacing the Lamp".

Information for your safety and comfort iii

First things first x

Usage Notes x

Precautions x

Introduction 1

Product Features 1

Package Overview 2

Projector Overview 3

Projector Outlook 3

Control Panel 4

Remote Control Layout 5

Getting Started 7

Connecting the Projector 7

Connecting the Projector for Wireless Function 8

Turning the Projector On/Off 9

Turning on the Projector 9

Turning off the Projector 10

Adjusting the Projected Image 11

Adjusting the Height of Projected Image 11

How to optimize image size and distance 12

How to get a preferred image size by adjusting
distance and zoom 14

Contents

User Controls 16

Installation menu 16

Acer Empowering Technology 17

Onscreen Display (OSD) Menus 18

Color 19

Image 20

Management 22

Setting 22

Audio 25

Timer 25

Language 26

Appendices 27

Troubleshooting 27

LED & Alarm Definition Listing 31

Replacing the Lamp 32

Ceiling Mount Installation 33

Specifications 36

Compatibility modes 38

Regulations and safety notices 42

1

Introduction

Product Features

This product is a single-chip DLP® projector. Outstanding features include:

• DLP

• P1166/P1166P: Native 800 x 600 SVGA resolution

• Acer ColorBoost technology delivers nature’s true colors for vivid, life-like

• High brightness and contrast ratio

• Versatile display modes (Bright, Standard, Video, Blackboard, User 1, User

• NTSC / PAL / SECAM compatible and HDTV (720p, 1080i, 1080p) supported

• Lower power consumption and economy (ECO) mode extends lamp life

• Acer EcoProjeciton Technology delivers Intelligent power management

®

technology

P1266/P1266P/P1266n/P1266i/P1270: Native 1024 x 768 XGA resolution
4:3 / 16:9 aspect ratio supported

images

2) enable optimum performance in any situation

approach and physical efficiency improvement

English

• Empowering Key reveals Acer Empowering Technology utilities (Acer

eView, eTimer, eOpening, ePower Management) for easy adjustment of
settings

• Equipped with HDMI

TM

connection supporting HDCP

• Advanced digital keystone correction optimizes presentations

• Multi-language onscreen display (OSD) menus

• Full-function remote control

• Manual focus projection lens zooms up to 1.2x

• 2x digital zoom and pan move function

• Microsoft

®

Windows® 2000, XP, Vista® OS compliant

English

2

Package Overview

This projector comes with all the items shown below. Check to make sure your
unit is complete. Contact your dealer immediately if any thing is missing.

Projector with lens cap Power cord VGA cable

Compostive video cable Security card 2 x User's Guide (Wireless CD

Acer Projector

Quick Start Guide

Remote control 2 x Quick start guide

Wireless antenna

(P1266i series)

(Wireless Quick Start Guide

for P1266i Series )

Carrying case

for P1266i Series)

2 x Batteries

3

Projector Overview

Projector Outlook

Front / upper side

# Description # Description

1

Power button

2

Zoom ring

3

Focus ring

4

Remote control receiver

Rear side

7

8

5

Zoom Lens

6

Elevator button

7

Control panel

8

Lens cap

2

3

4 5 678 11

1

1

2

3

4

5

6

English

91213 14 10

# Description # Description

1 USB connector 10

Kensington

2 HDMI connector Below items are for P1266n series only:

PC analog signal/HDTV/component

3

video input connector (VGA IN )

Monitor loop-through output

4

connector (VGA-Out)

14 Lan (RJ45 Port for 10/100M Ethernet)

Below items are for P1266i series only:

5 Composite video input connector 11 Antenna

6 S-Video input connector 12 Power LED for wireless

7 Audio input connector 13 Reset button

8 RS232 connector 14 Lan (RJ45 Port for 10/100M Ethernet)

9 Power socket

TM

lock port

4

Control Panel

English

1

2

3

4

5

6

7

8

9

2

# Function Description

1 LAMP Lamp Indicator LED

2KEYSTONE

3RESYNC

4 MENU

5POWER

6 TEMP Temp Indicator LED

7 Four directional select keys

8 SOURCE

9 Empowering key

Adjusts the image to compensate for distortion
caused by tilting the projector.

Automatically synchronizes the projector to the
input source.

• Press "MENU" to launch the Onscreen display
(OSD) menu, back to the previous step for the
OSD menu operation or exit the OSD menu.

• Confirm your selection of items.

See the contents in "Turning the Projector On/
Off" section.

Use to select items or make
adjustments to your selection.

Press "SOURCE" to choose RGB, Component, S­Video, Composite, HDTV and HDMI™ sources.

Unique Acer functions: eOpening, eView, eTimer,
ePower Management.

5

Remote Control Layout

# Icon Function Description

1 Infrared

(#)

2
3

4 HIDE Momentarily turns off the video. Press "HIDE" to hide the

5 RESYNC Automatically synchronizes the projector to the input source.
6 SOURCE Press "SOURCE" to choose from RGB, Component-p,

7 POWER Refer to the "Turning the Projector On/Off" section.

transmitter

Laser pointer Aim the remote at the viewing screen.

FREEZE To pause the screen image.

Sends signals to the projector.

image, press again to display the image.

Component-i, S-Video, Composite, Video and HDTV sources.

English

8 ASPECT RATIO To choose the desired aspect ratio (Auto/4:3/16:9)
9 ZOOM Zooms the projector display in or out.

(#)

10

11 Empowering key Unique Acer functions: eOpening, eView, eTimer, ePower

12 KEYSTONE Adjusts the image to compensate for distortion caused by

12 Four directional

Laser button Aim the remote at the viewing screen, press and hold this

select keys

button to activate the laser pointer.
This function is not supported in Japanese market.

Management.

tilting the projector (± 40 degrees).
Use up, down, left, right buttons to select items or make

adjustments to your selection.

English

6

# Icon Function Description

13 MENU

• Press "MENU" to launch the Onscreen display (OSD)

menu, back to the previous step for the OSD menu
operation or exit the OSD menu.

• Confirm your selection of items.

14 PAGE For computer mode only. Use this button to select the next or

15 RGB Press "RGB" for true-color optimization.
16 BRIGHTNESS Press "BRIGHTNESS" to adjust the brightness of the image.
17 CONTRAST Use the "CONTRAST" option to control the difference

18 COLOR Press "COLOR" to adjust the color temperature of image.
19 VGA Press "VGA" to change source to the VGA connector. This

20 COMPONENT Press "COMPONENT" to change source to Component video.

21 S-VIDEO To change source to S-Video.
22 VIDEO To change source to COMPOSITE VIDEO.
23 DVI No function.
24 HDMI™ To change source to HDMI™. (for the model if with HDMI™

25

(*)

26

27 KeyPad 0~9 Press "0~9" to input a password in the "Security".

MUTE To turn on/off the volume.
WIRELESS Press "WIRELESS" to display the image which is wirelessly

previous page. This function is only available when connected
to a computer via a USB cable.

between the lightest and darkest parts of the picture.

connector supports analog RGB, YPbPr (480p/576p/720p/
1080i), YCbCr (480i/576i) and RGBsync.

This connection supports YPbPr (480p/576p/720p/1080i) and
YCbCr (480i/576i).

connector)

transmitted from the PC to the projector via the "Acer
eProjection Management" utility. (for wireless model)

Note: "*" Only for P1266i series.

"#" Japan area is not supported.

7

Getting Started

Connecting the Projector

DVD player,

Set-top Box,

HDTV receiver

4

1

VGA

USB

DVD player

HDMI

9

USB

D-Sub

HDMI

D-Sub

RBG

10

RBG

2

5

HDTV adapter

D-Sub

Video Output

D-Sub

Y

S-Video Output

Y

3

8

English

VGA

6

RS232

RS232

7

# Description # Description

1Power cord 6S-Video cable

2 VGA cable 7 Audio cable jack/jack

3 Composite video cable 8 RS232 cable

4 USB cable 9 HDMI cable

5 VGA to component/HDTV adapter 10 3 RCA component cable

Note: To ensure the projector works well with your computer,
please make sure the timing of the display mode is compatible
with the projector.

English

8

Connecting the Projector for Wireless Function

Internet

1

Power

# Description

1Power cord

2Lan cable

3 Antenna

Note: For P1266i only

2

WLAN

3

9

Turning the Projector On/Off

Turning on the Projector

1 Remove the lens cap.(Illustration #1)

2 Ensure that the power cord and signal cable are securely connected. The

Power indicator LED will flash red.

3 Turn on the projector by pressing "Power" button on the control panel,

and the Power indicator LED will turn blue.(Illustration #2)

4 Turn on your source (computer, notebook, video player ,etc.). The

projector will detect your source automatically.

• If the screen displays "Lock" and "Source" icons, it means the
projector is locked onto a specific source type and there is no such
type of input signal detected.

• If the screen displays "No Signal", please make sure the signal cables
are securely connected.

• If you connect to multiple sources at the same time, use the "Source"
button on either control panel or the remote control or direct source
key on the remote control to switch between inputs.

2

Power button

English

1

Lens cap

English

10

Turning the projector off

1 To turn the projector off, press the power button. This message appears:

"Please press the power button again to complete the shutdown process."
Press the power button again.

2 The LED power indicator will turn RED and blink rapidly after the projector

is turned off, and the fan(s) will continue to operate for about 2 minutes to
ensure that the system cools properly.

3 As long as the power cord remains plugged in, you can press the power

button to turn the projector immediately back on anytime during the 2­minute shutdown process.

4 Once the system has finished cooling, the LED power indicator will stop

blinking and turn solid red to indicate standby mode.

5 It is now safe to unplug the power cord.

Warning indicators:

• "Projector Overheated. Lamp will automatically turn off soon."
This onscreen message indicates that the projector has overheated.
The lamp with automatically turn off, the projector will automatically
shut down, and the LED temp indicator will turn solid red. Contact
your local dealer or service center.

• "Fan failed. Lamp will automatically turn off soon."
This onscreen message indicates that the fan has failed. The lamp will
automatically turn off, the projector will automatically shut down,
and the LED temp indicator will blink. Contact your local dealer or
service center.

Note: Whenever the projector automatically shuts down and the
LED lamp indicator turns solid red, contact your local reseller or
service center.

11

Adjusting the Projected Image

Adjusting the Height of Projected Image

The projector is equipped with elevator feet for adjusting the height of image.

To raise the image:

1 Press the elevator foot release. (Illustration #1)

2 Raise the image to the desired height angle (Illustration #2), then release

the button to lock the elevator foot into position.

3 Use Tilt adjusting wheel (Illustration #3) to fine-tune the display angle.

To lower the image:

1 Press the elevator foot release. (Illustration #1)

2 Lower the image to the desired height angle (Illustration #2) , then release

the button to lock the elevator foot into position.

3 Use Tilt adjusting wheel (Illustration #3) to fine-tune the display angle.

English

3

Tilt adjusting wheel

2

Elevator foot

1

Elevator foot
release button

12

Min screen size
77"

How to optimize image size and distance

English

Consult the table below to find the optimal image sizes achievable when the
projector is positioned at a desired distance from the screen. Example: If the
projector is 3 m from the screen, good image quality is possible for image sizes
between 77" and 92".

Note: Remind as below figure, the space of 162 cm height is
required when located at 3m distance.

Max screen size

Min screen size

92"

B

77"

Height: 162cm
Form base to

top of image
Height:
135cm

C

A

3m
Desired Distance

Figure: Fixed distance with different zoom and screen size.

Diagonal

(inch)

<B>

Screen size

W (cm) x H (cm)

Screen size

Desired

Distance

(m)

Diagonal

<A>

Zoom Ratio: 1.2x

(inch)

<B>

1 26 52 x 39 45 31 63 x 47 54

2 51 104 x 78 90 62 125 x 94 108

2.5 64 130 x 98 112 77 156 x 117 135

3 77 156 x 117 135 92 188 x 141 162

3.5 90 182 x 137 157 108 219 x 164 189

4 103 208 x 156 180 123 250 x 188 216

4.5 115 234 x 176 202 138 281 x 211 243

5 128 260 x 195 225 154 313 x 234 270

6 154 313 x 234 270 185 375 x 281 323

7 179 365 x 273 314 215 438 x 328 377

8 205 417 x 313 359 246 500 x 375 431

9 231 469 x 352 404 277 563 x 422 485

9.8 250 508 x 381 438 300 609 x 457 526

(Min zoom) (Max zoom)

W (cm) x H (cm)

Top

From base

to top of

image (cm)

<C>

Top

From base to
top of image

(cm)

<C>

13

English

English

14

How to get a preferred image size by adjusting
distance and zoom

A

50"

Desired
image size

D

Height

Form base to
top of image

1.6m

2.0m

C

B

Desired Distance

The table below shows how to achieve a desired image size by adjusting either
the position or the zoom ring. For example: to obtain an image size of 50" set
the projector at a distance 1.6 m and 2.0 m from the screen and adjust the zoom
level accordingly.

Desired Image Size Distance (m) Top (cm)

Diagonal (inch)

<A>

26 53 X 40 *** 1.0 46

30 61 X 46 1.0 1.2 53

40 81 x 61 1.3 1.6 70

50 102 x 76 1.6 2.0 88

60 122 x 91 2.0 2.3 105

70 142 x 107 2.3 2.7 123

80 163 x 122 2.6 3.1 140

90 183 x 137 2.9 3.5 158

100 203 x 152 3.3 3.9 175

120 244 x 183 3.9 4.7 210

150 305 x 229 4.9 5.9 263

180 366 x 274 5.9 7.0 315

200 406 x 305 6.5 7.8 351

250 508 x 381 8.1 9.8 438

300 610 x 457 9.8 *** 526

Zoom Ratio: 1.2x

W (cm) x H (cm)

Max zoom

<B>

Min zoom

<C>

From base to top of


<D>

15

English

16

User Controls

English

Installation menu

The installation menu provides an onscreen display (OSD) for projector
installation and maintenance. Use the OSD only when the message "No signal
input" is displayed on the screen.

The menu options include settings and adjustments for screen size and distance,
focus, keystone correction and more .

1 Turn on the projector by pressing "Power" button on the control pad.

2 Press the menu button on the control pad to launch the OSD for projector

installation and maintenance.

3 The background pattern acts as a guide to adjusting the calibration and

alignment settings, such as screen size and distance, focus and more .

4 The Installation menu includes the following options:

•Projection method

•Menu location

•Keystone settings

•Language settings

•Reset to factory default function

Use the up and down arrow keys to select an option, the left and right
arrow keys to adjust selected option settings, and the right arrow key to
enter a submenu for feature setting. The new settings will be saved
automatically upon exiting the menu.

5 Push the menu button anytime to exit the menu and return to the Acer

welcome screen.

17

Acer Empowering Technology

Empowering Key

Acer eView Management

Acer eTimer Management

Acer Empowering Key provides four
Acer unique functions, they are "Acer
eView Management", "Acer eTimer
Management", "Acer eOpening
Management" and "Acer ePower

Management" respectively. Press " "
key for more than one second to launch
the Onscreen display main menu to
modify its function.

Press " " to launch "Acer eView
Management" submenu.

"Acer eView Management" is for
display mode selection. Please refer to
Onscreen Display Menus section for
more detail.

Press " " to launch "Acer eTimer
Management" submenu.
"Acer eTimer Management" provides
the reminding function for presentation
time control. Please refer to Onscreen
Display Menus section for more detail.

English

Acer eOpening Management

Acer ePower Management

Press " " to launch "Acer eOpening
Management".
"Acer eOpening Management" allows
user to change the Startup screen to
their personalized image. Please refer to
Onscreen Display section for more
detail.

Press " " to launch "Acer ePower
Management".
"Acer ePower Management" provides
user one shortcut to save lamp and
projector life. Please refer to Onscreen
Display section for more detail.

18

Onscreen Display (OSD) Menus

English

The projector has multilingual OSD that allow you to make image adjustments
and change a variety of settings.

Using the OSD menus

• To open the OSD menu, press "MENU" on the remote control or control

panel.

• When the OSD is displayed, use the keys to select any item in the

main menu. After selecting the desired main menu item, press to enter
submenu for feature setting.

• Use the keys to select the desired item and adjust the settings by

using the keys.

• Select the next item to be adjusted in the submenu and adjust as described

above.

• Press "MENU" on the remote control or control panel, the screen will

return to the main menu.

• To exit OSD, press "MENU" on the remote control or control panel again.

The OSD menu will close and the projector will automatically save the new
settings.

Main menu

Sub menu

Setting

19

Color

Display Mode

Brightness

Contrast

Color
Temperature

Degamma

Color R
Color G
Color B
Saturation

There are many factory presets optimized for various types of
images.

• Bright: For brightness optimization.

• Standard: For common environment.

• Video: For playing video in a bright environment.

• Blackboard: Blackboard mode can improve displayed color

when you project onto darker surfaces.

• User 1: Memorize user’s settings.

• User 2: Memorize user’s settings.

Adjust the brightness of the image.

• Press to darken image.

• Press to lighten the image.

"Contrast" controls the difference between the lightest and
darkest parts of the picture. Adjusting the contrast changes the
amount of black and white in the image.

• Press to decrease the contrast.

• Press to increase the contrast.

Adjust the color temperature. At higher color temperatures, the
screen looks colder; at lower color temperatures, the screen looks
warmer.

Effects the representation of dark scenery. With greater gamma
value, dark scenery will look brighter.

Adjusts the red color.

Adjusts the green color.

Adjusts the blue color.

Adjusts a video image from black and white to fully saturated
color.

• Press to decrease the amount of color in the image.

• Press to increase the amount of color in the image.

English

20

English

Tint

Adjusts the color balance of red and green.

• Press to increase the amount of green in the image.

• Press to increase the amount of red in the image.

Note: "Saturation" and "Tint" functions are not supported under computer
mode or HDMI mode.


Projection Front-Desktop

• The factory default setting.

Front-Ceiling

• When you select this function, the projector inverts the image for

ceiling-mounted projection.

Rear-Desktop

• When you select this function, the projector reverses the image so

you can project from behind a translucent screen.

Rear-Ceiling

• When you select this function, the projector reverses and inverts

the image at same time. You can project from behind a
translucent screen with ceiling mounted projection.

Keystone Adjust image distortion caused by tilting projection. (±40 degrees)

Aspect Ratio

Use this function to choose your desired aspect ratio.

• Auto: Keep the image with original width-higth ratio and maxi

• 4:3: The image will be scaled to fit the screen and displayed using

mize the image to fit native horizontal or vertical pixels.

• 16:9: The image will be scaled to fit the width of the screen and

a 4:3 ratio.

the height adjusted to display the image using a 16:9 ratio.

21

English

H. Position
(Horizontal
position)

V. Position
(Vertical position)

• Press to move the image left.

• Press to to move the image right.

• Press to move the image down.

• Press to move the image up.

Frequency "Frequency" changes the projector's refresh rate to match the

Tracking Synchronizes the signal timing of the projector with the graphics card.

Sharpeness Adjusts the sharpness of the image.

frequency of your computer’s graphics card. If you can see a vertical
flickering bar in the projected image, use this function to make the
necessary adjustments.

If you experience an unstable or flickering image, use this function to
correct it.

• Press to decrease the sharpness.

• Press to increase the sharpness.

Note: "H. Position", "V. Position", "Frequency" and "Tracking" functions
are not supported under HDMI or Video mode.

Note: "Sharpness" functions is not supported under HDMI and Computer
mode.

English

22

Management

ECO Mode Choose "On" to dim the projector lamp which will lower power

High Altitude Choose "On" to turn on High Altitude mode. Operate the fans at

Auto Shutdown The projector will automatically shutdown when there is no signal

Lamp Hour Elapse Displays the lamp’s elapsed operating time (in hours).

Lamp Reminding Activate this function to display a reminder to change the lamp 30

Lamp Hour Reset

consumption, extend the lamp life and reduce noise. Choose "Off"
to return normal mode.

full speed continuously to allow for proper high altitude cooling of
the projector.

input after the allocated time. (in minutes)

hours before its expected end-of-life.

Press the button after choosing "Yes" to turn the lamp hour
counter to 0 hours.

Setting

Menu Location Choose the menu location on the display screen.

Source Lock When source lock is turned "off", the projector will search for

Startup Screen Use this function to select your desired startup screen. If you

other signals if the current input signal is lost. When source lock is
turned "on", it will "lock" the current source channel unless you
press "Source" button on the remote control for the next channel.

change the setting, the changes will take effect when you exit the
OSD menu.

• Acer: The default startup screen of your Acer projector.

• User: Use memorize picture from "Screen Capture" function.

23

Screen Capture Use this function to customize the startup screen. To capture the

Security Security

image that you want to use as the startup screen, follow the
instructions below.
Notice:
Before proceeding with the following steps, make sure that the
"Keystone" is set to the default value 0 and the aspect ratio is set
to 4:3. For details, refer to the "Image" section.

• Change the "Startup Screen" from the default setting "Acer"
to "User".

• Press "Screen Capture" to customize the startup screen.

• A dialog box appears to confirm the action. Choose "Yes" to
use the current image as your customized startup screen. The
capture range is the red rectangular area. Choose "No" to
cancel the screen capture and exit the onscreen display (OSD).

• A message appears, stating that the screen capture is in
progress.

• When the screen capture is finished, the message disappears
and the original display is shown.

• The customized startup screen, as shown below, takes effect
when there is a new input signal or when you restart the
projector.

This projector provides a useful security function for the
administrator to manage usage of the projector .

Press to change the "Security" setting. If the security function
is enabled, your must enter the "Administrator Password" first

before changing the security settings.

• Select "On" to enable the security function. The user has to

enter a password to operate the projector. Please refer to the
"User Password" section for details.

• If "Off" is selected, then the user can turn on the projector

without password.

Timeout(Min.)
Once "Security" is activated to "On", the administrator can set

timeout function.

• Press or to select the timeout interval.

• The range is from 10 minute to 990 minutes.

• When the time is up, the projector will prompt the user to

enter the password again.

• The factory default setting of "Timeout(Min.)" is "Off".

• Once the security function is enabled, the projector will

request user to enter password when switch on the projector .
Both "User Password" and "Administrator Password" can be
accepted for this dialogue.

English

Note: This screen capture function is limited by 4:3 aspect ratio only.
Note: For XGA models, to get best quality for you desired image, suggest
end-user set PC resolution to 1024 x 768 before you use this function.
Note: For SVGA models, to get best quality for you desired image, suggest
end-user set PC resolution to 800 x 600 before you use this function.

English

24

Reset

Wireless

LAN

LAN IP/Mask

User password

• Press to setup or change the "User Password".

• Press number keys to set your password on the remote control

and press "MENU" to confirm.

• Press to delete character.

• Enter the password when you see "Confirm Password"

displayed.

• The password should be between 4 and 8 characters long.

• If you select "Request password only after plugging power

cord", the projector will prompt the user to enter the
password every time the power cord is plugged.

• If you select "Always request password while projector turns

on", the user has to enter the password every time when the
projector is turned on.

Administrator Password

The "Administrator Password" can be used in both the "Enter
Administrator Password" and "Enter Password" dialog boxes.

• Press to change the "Administrator Password".

• The factory default of "Administrator Password" is "1234".

If you forgot your administrator password, do the following to
retrieve the administrator password:

• An unique 6-digit "Universal Password" which is printed on

the Security Card (please check accessory in the box). This
unique password is the number which will be accepted by
projector anytime no matter what the Administrator
Password is.

• If losing this security card and number, please contact with an

Acer service center.

Lock User Startup Screen

• Default Lock User Startup Screen is "OFF". If lock user startup

screen is "ON", users cannot change startup screen anymore
and avoid other users change that arbitrarily. Choose "OFF"
to unlock startup screen.

• Press the button after choosing "Yes" to return the

parameters on all menus to the factory default settings.

• Please refer to wireless booklet for details. (For P1266i series

only)

• Default is "On". Choose "off" to disable LAN connection (For

P1266n series only)

• Identify IP and Mask address.

25

Audio

Volume

Mute

Power On/Off Volume

Alarm Volume

Timer

English

• Press to decrease the volume.

• Press to increase the volume.

• Choose "On" to mute the volume.

• Choose "Off" to restore the volume.

• Select this function to adjust the notification volume when

turning the projector on/off.

• Select this function to adjust the volume of any warning

notifications.

Timer Location

Timer Start

Timer Period

Timer Volume

Timer Display

• Choose the location of the timer on the screen.

• Press to start or stop the timer.

• Press or to adjust the timer period.

• Select this function to adjust the notification volume when

the timer function is enabled and time is up.

• Press or to which timer mode to display on the

screen.

English

26

Language

Language

Choose the multilingual OSD menu. Use the or key

to select your preferred menu language.

• Press to confirm the selection.

27

Appendices

Troubleshooting

If you experience a problem with your Acer projector, refer to the following
troubleshooting guide. If the problem persists, please contact your local reseller
or service center.

Image Problems and Solutions

# Problem Solution

1 No image appears

onscreen

2 Partial, scrolling

or incorrectly
displayed
image(For PC
(Windows 95/98/
2000/XP))

• Connected as described in the "Getting Started"

section.

• Ensure none of the connector pins are bent or

broken.

• Check if the projector lamp has been securely

installed. Please refer to the "Replacing the Lamp"
section.

• Make sure you have removed the lens cap and the

projector is switched on.

•

Press "RESYNC" on the remote control or control panel.

• For an incorrectly displayed image:

• Open "My Computer," open the "Control

Panel," and then double-click the "Display"
icon.

• Select the "Settings" tab.

• Verify that your display resolution setting is

lower than or equal to UXGA (1600 x 1200).

• Click the "Advanced Properties" button.

If the problem still appears, change the monitor display
you are using and follow the steps below:

• Verify that the resolution setting is lower than

or equal to UXGA (1600 x 1200).

• Click the "Change" button under the

"Monitor" tab.

• Click "Show all devices". Next, select "Standard

monitor types" under the SP box, and choose
the resolution mode you need under the
"Models" box.

• Verify that the resolution setting of the

monitor display is lower than or equal to UXGA
(1600 x 1200).

English

28

English

3 Partial, scrolling

or incorrectly
displayed image
(For notebooks)

4 The screen of the

notebook
computer is not
displaying your
presentation

5 Image is unstable

or flickering

6 Image has vertical

flickering bar

• Press "RESYNC" on the remote control or control

panel.

• For an incorrectly displayed image:

• Follow the steps for item 2 (above) to adjust

the resolution of your computer.

• Press the toggle output settings. Example:

[Fn]+[F4], Compaq [Fn]+[F4], Dell [Fn]+[F8],
Gateway [Fn]+[F4], IBM [Fn]+[F7], HP
[Fn]+[F4], NEC [Fn]+[F3], Toshiba [Fn]+[F5 ]

• If you experience difficulty changing resolutions or

your monitor freezes, restart all equipment
including the projector.

• If you are using a Microsoft

notebook: Some notebook PCs may deactivate their
own screens when a second display device is in use.
Each has a different way to be reactivated. Refer to
your computer's manual for detailed information.

• If you are using an Apple

notebook: In System Preferences, open Display and
select Video Mirroring "On".

®

Windows® based

®

Mac® OS based

• Adjust the "Tracking" to correct it. Refer to the

"Image" section for more information.

• Change the display color depth settings on your

computer.

• Use "Frequency" to make an adjustment. Refer to

the "Image" section for more information.

• Check and reconfigure the display mode of your

graphics card to make it compatible with the
projector.

7 Image is out of

focus

8 Image is stretched

when displaying a
"widescreen"
DVD title

• Make sure the lens cap is removed.

• Adjusts the focus ring on the projector lens.

• Make sure the projection screen is within the

required distance of 3.3 to 32.0 feet (1.0 to 9.8
meters) from the projector. Refer to the "How to
Get a Preferred Image Size by Adjusting Distance
and Zoom" section for more information.

When you play a DVD encoded in anamorphic or 16:9
aspect ratio you may need to adjust the following
settings:

• If you play a 4:3 format DVD title, please change the

format to 4:3 in the projector OSD.

• If the image is still stretched, you will also need to

adjust the aspect ratio. Set up the display format to
16:9 (wide) aspect ratio on your DVD player.

29

9 Image is too small

or too large

• Adjust the zoom ring on the top of the projector.

• Move the projector closer to or further from the

screen.

• Press "MENU" on the remote control or on the

control panel. Go to "Image --> Aspect Ratio" and
try different settings.

10 Image has slanted

sides

• If possible, reposition the projector so that it is

centered on the screen.

• Press the "Keystone / / / " on the OSD or the

remote control until the sides are vertical.

11 Image is reversed

• Select "Image --> Projection" on the OSD and adjust

the projection direction.

Problems with the Projector

# Condition Solution

1 The projector stops responding

to all controls

2 Lamp burns out or makes a

popping sound

If possible, turn off the projector, then
unplug the power cord and wait at least 30
seconds before reconnecting power.

When the lamp reaches the end of its useful
life, it will burn out and may make a loud
popping sound. If this happens, the projector
will not turn on until the lamp module has
been replaced. To replace the lamp, follow
the procedures in the "Replacing the Lamp"
section.

English

30

OSD Messages

English

# Condition Message Reminder

1 Message Fan Fail - the system fan is not working.

Projector Overheated - the projector has exceeded its
recommended operating temperature and must be allowed to
cool down before it may be used. Please also check the dust
filters if they are installed. If the dust filter is clogged with
dust, please clean it. Please refer to "Cleaning and replacing
the dust filter" for details.

Replace the lamp - the lamp is about to reach its maximum
lifetime. Prepare to replace it soon.

31

LED & Alarm Definition Listing

LED Messages

Message

Standby
(power cord plugged in)

Power button ON -- -- -- V

Lamp retry -- -- -- Quick

Turning off
(cooling state)

Turning off
(cooling completed)

Error (thermal failure) -- V -- V

Error (fan lock failure) -- Quick

Error (lamp breakdown) V -- -- V

Error (color Wheel fail) Quick

Lamp LED Temp LED Power LED

Red Red Red Blue

-- -- V --

-- -- Quick

-- -- V --

flashing

-- -- V

flashing

flashing

-- V

flashing

English

--

English

32

Replacing the Lamp

Use a screwdriver to remove the screw(s) from the cover, and then pull out the
lamp.

The projector will detect the lamp life. You will be shown a warning message
"Lamp is approaching the end of its useful life in full power operation.
Replacement Suggested!" When you see this message, change the lamp as soon
as possible. Make sure the projector has been cooling down for at least 30
minutes before changing the lamp.

Warning: The lamp compartment is hot! Allow it to cool down
before changing the lamp.

1

2

3

4

To Change the Lamp
1 Turn off the projector by pressing the power button.
2 Allow the projector at least 30 mins to cool down.
3 Disconnect the power cord.
4 Use a screwdriver to remove the screw from the cover. (Illustration #1)
5 Push up and remove the cover.
6 Remove the two screws that secure the lamp module (Illustration #2) and

pull up the lamp bar.(Illustration #3)

7 Pull out the lamp module by force. (Illustration #4)

To replace the lamp module, reverse the previous step.

Warning: To reduce the risk of personal injury, do not drop the
lamp module or touch the lamp bulb. The bulb may shatter and
cause injury if it is dropped.

33

i
