Acer Monitors

Value Line Value Line – Wide Screen

V173 B V193 X153 W V193W V203W V223W V243W

display

Part Number Display Size Display Dimensions Pixel Pitch Resolution Brightness (typ.) Contrast Ratio (typ.) Max. Refresh Rate Viewing Angle (typ.) Response Time (typ.) Input Signal Speaker

Power Adapter (100V-240V)

Power Consumption Dimensions (WxHxD

mm) Weight (kg)

Kensington Lock VESA Wall Mounting

ET.BV3RE.005

17” 19” 15.6” wide 19” wide 20” wide 22” wide 24” Wide

338 x 270 mm 376 x 301mm TBA 408 x 255mm 433 x 270 mm 473x296 mm 547x352mm

0.264mm 0.294mm 0.258mm 0.284mm 0.258 mm 0.282 mm 0.270 mm

1280 x 1024 1280 x 1024 1280x800 1440 x 900 1680 x 1050 1680x1050 1920 X 1200

300 cd/m2 300 cd/m2 200 cd/m2 300 nits (cd/m2 300 cd/m2 300 cd/m2

2000:1 (ACM) 2000:1 (ACM) 400:1 2000:1 (ACM) 2500:1 (ACM) 2500:1 (ACM) 3000:1 (ACM)

75Hz 75Hz 60Hz 75Hz 75Hz 75Hz 75MHz

160° (H), 160° (V) 160° (H), 160° (V) 90°(H),50°(V) 160° (H), 160° (V) 160° (H), 160° (V) 160°(H), 160°(V) 160° / 160°

5ms 5ms 8ms 5ms 5ms 5ms 5ms

VGA (Analog D-sub) VGA (Analog D-sub) VGA (Analog D-sub) VGA (Analog D-sub) VGA (Analog D-sub), DVI Optional VGA (Analog D-sub), DVI (optional) Analog (VGA)

No No No No No No No

Internal Internal Internal Internal Internal Internal Internal

<35W <35W TBA <37W <39W <45W <90W

370.2 x 376 x 160.2 mm 408 x 406.8 x 180.4 mm 377x320.5x159 441.8 x 360.1 x 161 471.5 x 376 x 108.3 506x399x180 562.4 x 368 x 210.3

3.75 3.91 2.73 4.3 5.5 5.2 6.55

Supported Supported Supported Supported Supported Supported Supported

75 x 75 mm 75 x 75 mm 75 x 75 mm 75 x 75 mm 100 x 100 mm 100 x 100 mm 101 x 100 mm

ET.CV3RE.005

ET.AX3WE.004

ET.CV3WE.005

ET.DV3WE.010

ET.EV3WE.010

ET.FV3WE.010

axiz product guide / Q4 2008 / october – december

41]

[

Page 2

monitors

axiz product guide / Q4 2008 / october – december

display

Part Number Display Size Display Dimensions Pixel Pitch Resolution Brightness (typ.) Contrast Ratio (typ.) Max. Refresh Rate Viewing Angle (typ.) Response Time (typ.) Input Signal Speaker Power Adapter (100V-240V) Power Consumption Dimensions (WxHxD mm) Weight (kg) Kensington Lock VESA Wall Mounting

Acer Monitors – Value Line Wide Screen

V173 B

ET.YX3WE.020

21.6”

473x296 mm

0.282mm

1680x1050

300 cd/m2

2500:1 (ACM)

60Hz

170°(H),160°(V)

5ms

VGA (Analog D-sub)

Internal

<45W

370.2 x 376 x 160.2 mm

3.75

Supported

75 x 75 mm

Notes

[42]

axiz product guide / Q4 2008 / october – december

Page 3

monitors

Acer Monitors – Premium Home Wide Screen

P193W P203W P223Wxd P223W P243WB

display

ET.CP3WE.014

19” Wide 20” Wide 22” Wide 22” Wide 24” wide

408x255mm 433x270mm 473x296 mm 473x296 mm 547x352 mm

0.284mm 0.258mm 0.282mm 0.282mm 0.270 mm

1440x900 1680x1050 1680x1050 1680x1050 1920x1200

300 cd/m2 300 cd/m2 200 cd/m2 200 cd/m2 400 cd/m2

2000:1 (ACM) 2500:1 (ACM) 2500:1 (ACM) 2500:1 (ACM) 3000:1 (ACM)

75Hz 75Hz 60Hz 60Hz 60Hz

160° (H), 160° (V) 160° (H), 160° (V) 170°(H),160°(V) 170°(H),160°(V) 170° (H), 160° (V)

5ms 5ms 5ms 2ms 2ms GTG/5ms

VGA and DVI / HDCP VGA and DVI / HDCP VGA and DVI / HDCP VGA and DVI / HDCP VGA and DVI / HDCP

No No No No No

Internal Internal Internal Internal Internal

<37W <49W <45W <45W <39W

454.3x359.2x163.7 mm 517.5x400.1x177.4 mm 517.5x400.1x177.4 517.5x400.1x177.4 572x431x190

4.4 5.25 5.25 5.25 7

Supported Supported Supported Supported Supported

100 x 100 mm 100 x 100 mm 100 x 100 mm 100 x 100 mm 100 x 100 mm

ET.CV3RE.005

ET.EP3WE.024

ET.FP3WE.A01

axiz product guide / Q4 2008 / october – december

43]

[

Page 4

HP TFT Monitors – Essential Series

17” 19" Wide 22" Wide

display

monitors

Model Number Product Number Resolution

Response Rate Front Bezel Colours

Technology Viewing Angle Brightness Interface TCO99/E-Star Warranty Multimedia USB Ports Pitch

Dimensions

Weight Speaker Bar Option

Unpacked 39.8 x 48 x 23 cm 34.5 x 44.3 x 8.7 cm Packed - 29.9 x 56.4 x 42.6 cm 35.2 x 67.2 x 46.4 cm 56.8 x 79.0 x 37.8 cm

Unpacked 7.06 kg 9.2 kg 9.1 kg 13.9 kg Packed 9.27 kg 11.95 kg 12 kg -

Model Number Product Number Resolution Front Bezel Colours Response Rate Technology Viewing Angle Brightness Interface TCO99/E-Star Warranty

Dimensions

Weight Speaker Bar Option

Unpacked 38.6 x 37.7 x 19.2 cm 37.0 x 44.6 x 18.7 cm 41.46 x 51.48 x 19.2 cm Packed 43.7 x 44.8 x 17.5 cm 42.3 x 53.6 x 17.4 cm 48.1 x 59.5 x 19 cm Unpacked 4.7 kg 5.63 kg 5.41 kg Packed 6.1 kg 6.45 kg 7.51 kg

L1710 L1908w L2208w

GS917AA

1280x1024 @ 60Hz 1440 x 900 @ 60 Hz 1680 x 1050 @ 60 Hz

Carbon & Silver Carbon & Silver Carbon & Silver

5 ms ≤5 ms 5 ms

Active Matrix TFT Wide-Aspect Active Matrix TFT Wide-Aspect Active Matrix TFT

160/160 160/160 160/160 300 nits 300 nits 300 nits

VGA VGA VGA 3/3 3/3 3/3 3/3/3 3/3/3 3/3/3

EE418AA

HP TFT Monitors – Performance Series

19” 20” 24” 30”

LP196 5 LP2065 LP2475w LP3065

RA374AA

1280x1024 @ 60Hz 1600x1200 @ 60Hz 1920x1200 @ 60Hz 2560X1600 @ 60 Hz

6 ms 8 ms

Carbon & Silver Carbon & Silver Carbon & Silver Carbon & Silver

Active Matrix TFT Active Matrix TFT Wide Active Matrix TFT Wide Active Matrix TFT

178/178 178/178 178/178 178/178

300 nits 300 nits 400 nits 300 nits

Dual DVI-I VGA/DVI-I Dual DVI-I 3 x Dual Link DVI-D

3/3 3/3 3/3 3/3 3/3/3 3/3/3 3/3/3 3/3/3

3 3 3 3

5 5 5 5

0.294mm 0.255mm 0.270mm 0.250mm

EE418AA

EF227A4

EE418AA

KD911A4

6 ms (gray to gray);

12 ms (on/off)

42.16 to 52.16 x 55.64 x

25.3 cm

EE418AA

EZ320A4

12 ms

45.5 x 69.2 x 8.4 cm

EE418AA

GP536AA

EE418AA

Model Number Product Number Resolution Response Rate Front Bezel Colours Technology Viewing Angle Brightness Interface TCO99/E-Star Warranty USB Ports Pitch

Dimensions

Weight Speaker Bar Option

Unpacked 37.8 x 41.4 x 30.1 cm 37.09 51.48 x 30.12 cm Packed 56.5 x 42.0 x 22.6 cm 41.7 x 61.2 x 22.7 cm Unpacked 7.3 kg 7.73 kg Packed 9.1 kg 9.27 kg

GX007AA

EE418AA

HP TFT Monitors – Advantage Series

19” 22" Wide

L19 50g L2245w

KR145AA

1280x1024 @ 75 Hz 1680 x 1050 @ 60Hz

5 ms 5 ms

Carbon & Silver Carbon & Silver

Active Matrix TFT Wide-Aspect Active Matrix

160/160 160/160

300 nits 300 nits

VGA/DVI-I VGA/DVI-D

3/3 3/3 3/3/3 3/3/3

2 2

0.294 0.282

EE418AA

GX008AA

EE418AA

axiz product guide / Q4 2008 / october – december

45]

[

Page 5

monitors

display

LG LCD Monitors - 4:3 format

4:3 Format Multi-Link Solution

17” 17” 19” 19” 20’W

Code

Colour

Brightness

Contrast Ratio

Response Time

Viewing Angle H/V

Supported Colours

Resolution

Connector Dimension (WxHxD)

(Box) Weight (Box)

Special features

LGL1734S-BN

Black Black Black Black Black and White

300 cd/m² (Typical) 300 cd/m² (Typical) 300 cd/m² (Typical) 300 cd/m² (Typical) 300 cd/m² (Typical)

700:1 (typical) 5000:1 (DFC) 700:1 (typical) 5000:1 (DFC) 5000:1 (DFC)

5ms 5ms 5ms 5ms 2ms

170/170 170/170 160/160 170/170 170/170

16.2M 16.2M 16.2M 16.2M 16.7M

1280x1024(SXGA) 1280x1024(SXGA) 1280x1024(SXGA) 1280x1024(SXGA) 1680 x 1050

15pin D-Sub 15pin D-Sub 15pin D-Sub 15pin D-Sub USB

420x132x378mm 376x180x380mm 478x131x429mm 469x116x394mm 557 x 244 x 379 mm

4Kg 6Kg 6Kg 5Kg 6Kg

Tilt, Wall Mount- (75x75) Tilt, Wall Mount- (75x75) Tilt, Wall Mount- (75x75) Tilt, Wall Mount- (75x75)

LG1719S-BF

LG1918S-BN

LG1919s-BF

LGL206WU-WF

F-engine, HDCP, 4:3 in wide, Pivot 90, height

adjustment, Tilt Swivel, Vesa (100 x 100)

[46]

axiz product guide / Q4 2008 / october – december

Page 6

monitors

display

LG LCD Monitors - Widescreen

W42 Series W52 Series

19”W 22” 19 ”W 19” W 22”

Code Colour Brightness Contrast Ratio Response Time Viewing Angle H/V Supported Colours Resolution Connector Dimension (WxHxD) (Box) Weight (Box)

Special features

LGW1934S-BN

Black Black Black Black Black

300 cd/m² (Typical) 300 cd/m² (Typical) 300 cd/m² (Typical) 300 cd/m² (Typical) 300 cd/m² (Typical)

1000:1 (DFC) 8000:1 (DFC) 8000:1 (DFC) 10000:1 (DFC) 10000:1 (DFC)

5ms 5ms 5ms 2ms 2ms

170/170 170/170 170/170 170/170 170/170

16.7M 16.7M 16.7M 16.7M 16.7M

1440 x 900(WXGA+) 1680 x 1050(WSXGA+) 1440 x 900(WXGA+) 1440 x 900(WSXGA+) 1680 x 1050(WSXGA+)

15pin D-Sub 15pin D-Sub 15pin D-Sub 15pin D-Sub, DVI-D 15pin D-Sub, DVI-D

514 x 141x 380mm 574 x 127 x 407 mm 511 x 119 x 395 mm 511 x 140 x 395 mm 582 x 127 x 449mm

4Kg 6Kg 4Kg 4Kg 5Kg

4:3 in wide, Tilt, Wall Mount (75 x 75)

F-engine, HDCP, 4:3 in wide, Tilt, Wall Mount- (75

LG-W2252WTQ-PF

x 75)

LG-W1942S-PF

F-engine, HDCP, 4:3 in wide, Tilt, Wall Mount- (75

x 75)

LGW1952TQ

F-engine, HDCP, 4:3 in wide, ez-Zooming, Photo

effect, Tilt

LGW2252TQ-PF

F-engine, HDCP, 4:3 in wide, ez-Zooming, Photo

effect, Wall Mount- (100 x 100)

[48]

axiz product guide / Q4 2008 / october – december

Page 7

monitors

display

Part Number

Screen size Brightness Contrast Ratio Resolution Response Time

Display

Viewing Angle(Horizontal/ Vertical) Colour Supported Video Signal

Sync. Signal

Input

Signal

Connector Power consumption Stand by Power(DPMS)

Power

Typ e Plug & Play USB powered hub option Mac compatibility Multimedia Speakers Wall-Mount TCO Cabinet Colour

Optional Accessories

Features

Special Features

Product Dimension (With Stand, Watt x H x D) mm Product Dimension (Without Stand, Watt x H x D) mm

Dimension

Shipment Dimension (Watt x H x D) mm

Product Weight

Shipment Weight

Weight

Typ e Function

Stand

632NW 720N 732NW 953BW 920NW 932GW 2053BW 2032GW

Samsung Monitors

LS16PENSF/ZAT

15.6" Wide 17" 17" Wide 19" 19" wide 19" Wide 20" Wide 20" Wide

250 cd/m

Static 500:1 (DC 2000:1) 700:1 600:1 DC 8000:1(1000:1)(Typ.) 700:1 1000:1 (DC 3000:1) DC 8000:1(1000:1) (Typ.) DC 3000:1 (1000:1)

1360x768 1280x1024 1440x900 1440 x 900 1440x900 1440x900 1680x1050 1680x1050

8ms 5ms 8ms 5ms, 2ms(GTG) 5ms 2ms(GTG) 5ms, 2ms(GTG) 2(GTG)

90/65 (CR≥10) 170˚/155˚(CR>5) 160˚/160˚ 170˚/160˚(CR>10) 160˚/160˚(CR>5)

16.7Mil. 16.2Mil. 16.2 Mil. 16.7 Mil. 16.2 Mil. 16.7 Mil. 16.7 Mil. 16.7 Mil.

Analog RGB Analog RGB Analog RGB Analog RGB, DVI Analog RGB Analog RGB, Digital Analog RGB, DVI Analog RGB, DVI

Separate H/V, Composite,

SOG

15pin D-sub 15pin D-sub 15pin D-sub 15pin D-SUB, DVI-D 15pin D-sub 15pin D-sub, DVI-D 15pin D-SUB, DVI-D 15pin D-SUB, DVI-D

18 Watt 34 Watt (Max) 20 Watt (Max) 34 Watt 42 Watt (Max) 42 Watt (Max) 40 Watt 50W

less than 1 watt <1W <1W <1W <1W

Built-in Built-in Built-in Built-in Built-in Built-in Built-in

DDC 2B DDC CI DDC 2B DDC 2B DDC 2B DDC 2B DDC 2B Built-in

3 3 3 7 3 7 7 3 7 7 3 7 3 3 7 3 3 3 7 3 7 7 3 3

- TCO ‘99 - - TCO99

High Glossy Black Silver High Glossy Black High Glossy Black Silver High Glossy Black High Glossy Black High Glossy Black

MagicTune, MagicBright 3, MagicBright

382 x 308 x 159 370 x 387.3 x 195 406 x 340 x 177 445.8 x 359.8 x 190 439 x 360.7 x 200 449 x 374 x 199 472.9 x 374.9 x 219 476 x 390 x 199

382 x 260 x 64 370 x 379 x 79 406 x 296 x 64 445.8 x 310 x 59.8 439 x 289 x 65.5 449 x 325 x 67 472.9 x 326.5 x 63 476 x 344 x 70

442 x 114 x 310 430 x 450 x 135 473 x 383 x 117 519 x 387 x 130 525 x 428 x 149 519 x 392 x 130 548 x 404 x 132 549 x 411 x 132

2.5 4.04kg (Net Weight) 2.8 3.9 kg 4.7 4.1 4.4 kg 4.74 kg

3.5 5.05kg (Gross Weight) 3.8 5.4 kg 6.3 5.4 5.9 kg 6.3 kg

Simple Simple Simple Simple Simple Simple Simple Simple

Tilt Tilt Tilt Swivel, Tilt Tilt

LS17MJVKS/ZAT

300 cd/m

Separate H/V, Composite,

SOG

VESA 100mm

Accessory, Signal Cable,

Power Cord

LS17PENSF/XSG

250 cd/m

Separate H/V, Composite ,

SOG

MagicTune, MagicBright2,

Narrow Bezel

LS19AQWKFV/ZAT

300 cd/m

Separate H/V, Composite,

SOG

VESA 75mm VESA 75mm

LS19HANKSM/EDC

300 cd/m

Separate H/V, Composite ,

SOG

LS19PEJSFL/ZAT

300 cd/m

160˚/160˚(CR>10),170˚/170˚

(CR>5)

Separate H/V, Composite ,

SOG

7 7

DVI-D cable DVI-D cable

MagicBright3, Off timer,

Image Size, Colour

Effect, Customized key,

MagicWizard & MagicTune with

AssetManagement, Windows

Vista Premium, DVI with HDCP,

Safe Mode (DownScaling in

UXGA)

MagicBright2, Narrow Bezel

MagicTune, MagicBright3,

Narrow Bezel

MagicWizard & MagicTune with

AssetManagement, Windows

Vista Premium, DVI with HDCP,

LS20AQWJFV/ZAT

300 cd/m

170˚/160˚(CR>10) 170˚/170˚(CR>5)

Separate H/V, Composite,

SOG

VESA 100mm

MagicBright3, Off timer,

Image Size, Colour

Effect, Customized key,

Safe Mode (DownScaling in

UXGA)

LS20PEJSFV/XSH

300 cd/m

Separate H/V, Composite ,

SOG

DVI (HDCP), MagicBright3,

High Glossy Black, Glare

3 3

[50]

axiz product guide / Q4 2008 / october – december

Page 8

projectors

display

Projection System Resolution

Computer Compatibility

Video Compatibility Aspect Ratio

Contrast Ratio Displayable Colours Brightness

Projection Lens Projection Screen Size

(Diagonal) Projection Distance Throw Ratio Horizontal Scan Rate Vertical Refresh Scan Rate Lamp Type Lamp Life Keystone Correction Projection Mode Ceiling Mounting Capability Audio Weight Dimensions Remote Control Digital Zoom PIP Wireless Power Supply Power Consumption Operating Temperature Noise Level Uniformity

Input Interface

Output Interface Control Interface

Standard Accessories

Acer X1160Z Acer P1165 Acer P1265 Acer P3250

Acer Projectors

DLP® DLP® DLP® DLP®

Maximum SXGA (1,280 x 1,024), WXGA+ (1,440 x 900)

IBM PC and Compatibles, Apple Macintosh, iMac, and VESA

Standards WXGA+ (1,440 x 900), WXGA (1,280 x 800, 1,280 x

768), SXGA (1,280 x 1,024), XGA (1,024 x 768), SVGA (800 x 600),

NTSC (3.58/4.43), PAL (B/D/G/H/I/M/N), SECAM (B/D/G/K/K1/L),

HDTV (720p, 1080i), EDTV (480p, 576p), SDTV (480i, 576i)

AC power cord; VGA cable; Composite video cable; Remote •

control; Battery for remote control; Lens cap; Carrying case; User’s

Native SVGA (800 x 600)

VGA (640 x 480)

4:3 (Native), 16:9 4:3 (Native), 16:9 4:3 (Native), 16:9 4:3 (Native), 16:9

2000:1 2000:1 2000:1 2000:1

16.7 Million Colours 16.7 Million Colours 16.7 Million Colours 134 Million Colours 2,000 ANSI Lumens 2,400 ANSI Lumens (Standard), 1,920 ANSI Lumens (ECO) 2,400 ANSI Lumens (Standard), 1,920 ANSI Lumens (ECO) 2,000 ANSI Lumens (Standard), 1,600 ANSI Lumens (ECO)

F = 2.41 ~ 2.55, f = 21.79mm ~ 23.99mm

1:1.1 Manual Zoom and Manual Focus

23 (58cm) ~ 300 (762cm) 23 (58cm) ~ 300 (762cm) 23 (58cm) ~ 300 (762cm) 23 (58cm) ~ 300 (762cm)

3.3’ (1.0m) ~ 39.0’ (11.9m) 3.3’ (1.0m) ~ 39.0’ (11.9m) 3.3’ (1.0m) ~ 39.0’ (11.9m) 3.3’ (1.0m) ~ 39.0’ (11.9m) 50@2m (1.95 ~ 2.15:1) 50@2m (1.95 ~ 2.15:1) 50@2m (1.95 ~ 2.15:1) 50@2m (1.95 ~ 2.15:1)

31k – 69k Hz 31.5 ~ 100 kHz 31.5 ~ 100 kHz 31.5 ~ 100 kHz

Osram 160 W user replaceable P-VIP lamp Osram 180 W user replaceable P-VIP lamp Osram 180 W user replaceable P-VIP lamp Osram 165 W user replaceable P-VIP lamp

Front, Rear, Front-Ceiling, Rear-Ceiling Front, Rear, Front-Ceiling, Rear-Ceiling Front, Rear, Front-Ceiling, Rear-Ceiling Front, Rear, Front-Ceiling, Rear-Ceiling

267 x 187 x 80 mm (10.5 x 7.4 x 3.1) 299 x 229 x 93 mm (11.8 x 9.0 x 3.7) 299 x 229 x 93 mm (11.8 x 9.0 x 3.7) 210 x 165 x 64 mm (8.3 x 6.5 x 2.5)

AC input 100~240V auto-switching power supply AC input 100~240V auto-switching power supply AC input 100~240V auto-switching power supply AC input 100~240V auto-switching power supply

255 Watts (Operation), <8 Watts (Standby) 230 Watts (Operation), 10 Watts (Standby) 230 Watts (Operation), 10 Watts (Standby) 255 Watts (Operation), <5 Watts (Standby)

Analog RGB/Component Video (D-sub) x 1•

guide (CD-ROM); Quick start guide; Security card

50 ~ 85 Hz 56 ~ 85 Hz 56 ~ 85 Hz 56 ~ 85 Hz

4,000 Hours 3,000 Hours (Standard), 4,000 Hours (ECO) 3,000 Hours (Standard), 4,000 Hours (ECO) 3,000 Hours (Standard), 4,000 Hours (ECO)

+/-40 Degrees (Vertical ) +/-40 Degrees (Vertical ) +/-40 Degrees (Vertical ) +/-40 Degrees (Vertical )

Yes Yes Yes N/A N/A One Internal Speaker with 2 watts Output One Internal Speaker with 2 watts Output One Internal Speaker with 2 watts Output

5 lbs (2.3 Kg) 6.6 lbs (3.0 Kg) 6.6 lbs (3.0 Kg) 2.6 lbs (1.2 Kg)

IR remote control IR remote control with laser pointer & PgUp/PgDn functions IR remote control with laser pointer & PgUp/PgDn functions IR remote control

2X 2X 2X 2X N/A N/A N/A N/A N/A N/A N/A N/A

5°C ~ 35°C / 41°F ~ 95°F 5°C ~ 35°C / 41°F ~ 95°F 5°C ~ 35°C / 41°F ~ 95°F 5°C ~ 35°C / 41°F ~ 95°F

33 dBA 28 dBA (Standard mode), 24 dBA (ECO mode) 28 dBA (Standard mode), 24 dBA (ECO mode) 36 dBA (Standard mode), 33 dBA (ECO mode)

85% 90% 0.9 0.85

Composite Video (RCA) x 1•

S-Video (Mini DIN) x1 •

USB (Type B) x 1

Maximum SXGA (1,280 x 1,024), WXGA+ (1,440 x 900)

IBM PC and Compatibles, Apple Macintosh, iMac, and VESA

Standards WXGA+ (1,440 x 900), WXGA (1,280 x 800, 1,280 x

768), SXGA (1,280 x 1,024), XGA (1,024 x 768), SVGA (800 x 600),

NTSC (3.58/4.43), PAL (B/D/G/H/I/M/N), SECAM (B/D/G/K/K1/L),

HDTV (720p, 1080i), EDTV (480p, 576p), SDTV (480i, 576i)

AC power cord; VGA cable; Composite video cable; Remote •

control; Battery x 2 for remote control; Carrying case; User’s guide

Native SVGA (800 x 600)

VGA (640 x 480)

F = 2.41 ~ 2.55, f = 21.79mm ~ 23.99mm

1:1.1 Manual Zoom and Manual Focus

Analog RGB/Component Video (D-sub) x 1•

Composite Video (RCA) x 1•

S-Video (Mini DIN) x1 •

DVI (HDCP) x 1•

PC Audio (Stereo mini jack) x 1•

Analog RGB (D-sub) x 1 Analog RGB (D-sub) x 1

USB (Type B) x 1

RS232 (Mini DIN) x 1

(CD-ROM); Quick start guide; Security card

Maximum SXGA+ (1,400 x 1,050), WXGA+ (1,440 x 900)

IBM PC and Compatibles, Apple Macintosh, iMac, and VESA

Standards WXGA+ (1,440 x 900), WXGA (1,280 x 800, 1,280 x

768), SXGA+ (1,400 x 1,050), SXGA (1,280 x 1,024), XGA (1,024 x

NTSC (3.58/4.43), PAL (B/D/G/H/I/M/N), SECAM (B/D/G/K/K1/L),

HDTV (720p, 1080i), EDTV (480p, 576p), SDTV (480i, 576i)

AC power cord; VGA cable; Composite video cable; Remote •

control; Battery x 2 for remote control; Carrying case; User’s guide

Native XGA (1,024 x 768)

768), SVGA (800 x 600), VGA (640 x 480)

F = 2.41 ~ 2.55, f = 21.79mm ~ 23.99mm

1:1.1 Manual Zoom and Manual Focus

Analog RGB/Component Video (D-sub) x 1•

Composite Video (RCA) x 1•

S-Video (Mini DIN) x1 •

PC Audio (Stereo mini jack) x 1•

RS232 (Mini DIN) x 1

(CD-ROM); Quick start guide; Security card

DVI (HDCP) x 1•

USB (Type B) x 1

Maximum UXGA (1,600 x 1,200), WSXGA+ (1,680 x 1,050)

IBM PC and Compatibles, Apple Macintosh, iMac, and VESA

Standards WSXGA+ (1,680 x 1,050), WXGA+ (1,440 x 900), WXGA (1,280 x 800, 1,280 x 768), UXGA (1,600 x 1,200), SXGA+ (1,400 x 1,050), SXGA (1,280 x 1,024), XGA (1,024 x 768), SVGA

NTSC (3.58/4.43), PAL (B/D/G/H/I/M/N), SECAM (B/D/G/K/K1/L),

HDTV (720p, 1080i, 1080p), EDTV (480p, 576p), SDTV (480i, 576i)

AC power cord; VGA cable; Composite video cable; Remote •

control; Battery for remote control; Lens cap; Carrying case; User’s

Native XGA (1,024 x 768)

(800 x 600), VGA (640 x 480)

F = 2.41 ~ 2.55, f = 21.79mm ~ 23.99mm

1:1.1 Manual Zoom and Manual Focus

Analog RGB/Component Video (D-sub) x 1•

Composite Video (RCA) x 1•

S-Video (Mini DIN) x1 •

HDMI (Video, HDCP) x 1•

PC Audio (Stereo mini jack) x 1•

USB (Type B) x 1

guide (CD-ROM); Quick start guide; Security card

axiz product guide / Q4 2008 / october – december

51]

[

Page 9

projectors

Projection System Resolution

display

Computer Compatibility

Video Compatibility Aspect Ratio

Contrast Ratio Displayable Colours Brightness

Projection Lens Projection Screen Size

Input Interface

Output Interface

Control Interface

Network Interface

Standard Accessories

Acer P5260i Acer P7270i Acer P7280

DLP® DLP® DLP®

IBM PC and Compatibles, Apple Macintosh and iMac (Wireless and Ethernet function exclusive),

and VESA Standards WSXGA+ (1,680 x 1,050), WXGA+ (1,440 x 900), WXGA (1,280 x 800,

1,280 x 768), UXGA (1,600 x 1,200), SXGA+ (1,400 x 1,050), SXGA (1,280 x 1,024), XGA (1,024 x

NTSC (3.58/4.43), PAL (B/D/G/H/I/M/N), SECAM (B/D/G/K/K1/L), HDTV (720p, 1080i,

Analog RGB/Component Video (D-sub) x 1; Composite Video (RCA) x 1; S-Video (Mini •

AC power cord; VGA cable; Composite video cable; DVI cable; Remote control; Battery x

2 for remote control; Detachable antenna; Wireless PnS token; PnS token holder; Carrying

Maximum UXGA (1,600 x 1,200), WSXGA+ (1,680 x 1,050)

2,700 ANSI Lumens (Standard), 2,160 ANSI Lumens (ECO) 4,000 ANSI Lumens (Standard), 3,200 ANSI Lumens (ECO) 4,500 ANSI Lumens (Standard), 3,600 ANSI Lumens (ECO)

IR remote control with laser pointer & PgUp/PgDn functions IR & wired remote control with laser pointer & mouse & PgUp/PgDn functions IR & wired remote control with laser pointer & mouse & PgUp/PgDn functions

DIN) x1 ; DVI (HDCP) x 1; HDMI (Video, HDCP) x 1; PC Audio (Stereo mini jack) x 1

case; Users guide (CD-ROM); Quick start guide; Security card

Native XGA (1,024 x 768)

768), SVGA (800 x 600), VGA (640 x 480)

1080p), EDTV (480p, 576p), SDTV (480i, 576i)

F = 2.41 ~ 2.55, f = 21.79mm ~ 23.99mm

Osram 200 W user replaceable P-VIP lamp Osram 280 W user replaceable P-VIP lamp Philips 330 W user replaceable P-VIP lamp

3,000 Hours (Standard), 4,000 Hours (ECO) 2,000 Hours (Standard), 3,000 Hours (ECO) 2,000 Hours (Standard), 3,000 Hours (ECO)

AC input 100~240V auto-switching power supply AC input 100~240V auto-switching power supply AC input 100~240V auto-switching power supply

275 Watts (Operation), 14 Watts (Standby) 360 Watts (Operation), 20 Watts (Standby) 410 Watts (Operation), 5 Watts (Standby)

31 dBA (Standard mode), 25 dBA (ECO mode) 29dBA(Standardmode),27dBA(ECOmode)-w/odustlter 33dBA(Standardmode),29dBA(ECOmode)-w/odustlter

4:3 (Native), 16:9 4:3 (Native), 16:9 4:3 (Native), 16:9

2000:1 2300:1 2300:1

134 Million Colours 1.07 Billion Colours 1.07 Billion Colours

1:1.1 Manual Zoom and Manual Focus

23 (58cm) ~ 300 (762cm) 31 (79cm) ~ 300 (762cm) 31 (79cm) ~ 300 (762cm)

3.3 (1.0m) ~ 39.0 (11.9m) 3.9 (1.2m) ~ 31.4 (9.6m) 3.9 (1.2m) ~ 31.4 (9.6m) 50@2m (1.95 ~ 2.15:1) 63@2m (1.57 ~ 1.89:1) 63@2m (1.57 ~ 1.89:1)

31.5 ~ 100 kHz 27 ~ 92 kHz 27 ~ 92 kHz 56 ~ 85 Hz 50 ~ 85 Hz 50 ~ 85 Hz

+/-40 Degrees (Vertical ) +/-40 Degrees (Vertical), +/-15 Degrees (Horizontal) +/-40 Degrees (Vertical), +/-15 Degrees (Horizontal)

Front, Rear, Front-Ceiling, Rear-Ceiling Front, Rear, Front-Ceiling, Rear-Ceiling Front, Rear, Front-Ceiling, Rear-Ceiling

One Internal Speaker with 2 watts Output Two Internal Speaker with 3 watts Output Two Internal Speaker with 3 watts Output

299 x 229 x 93 mm (11.8 x 9.0 x 3.7) 404 x 315 x 120 mm (15.9 x 12.4 x 4.7) 404 x 315 x 120 mm (15.9 x 12.4 x 4.7)

Network Audio (Stereo mini jack) x 1•

802.11b/g wireless technology•

Wireless antenna connector (SMA) x 1•

Yes Yes Yes

6.4 lbs (2.9 Kg) 11.9 lbs (5.4Kg) 12 lbs (5.4Kg)

2X 8X 8X N/A Yes Yes Yes Yes N/A

5°C ~ 35°C / 41°F ~ 95°F 5°C ~ 35°C / 41°F ~ 95°F 5°C ~ 35°C / 41°F ~ 95°F

0.9 0.9 0.9

Analog RGB (D-sub) x 1•

USB (Type B) x 1•

RS232 (Mini DIN) x 1•

Ethernet port (RJ45) x 1•

1,280 x 768), UXGA (1,600 x 1,200), SXGA+ (1,400 x 1,050), SXGA (1,280 x 1,024), XGA (1,024 x

AC power cord; VGA cable; Composite video cable; DVI cable; S-Video cable; Component

Acer Projectors

IBM PC and Compatibles, Apple Macintosh and iMac (Wireless and Ethernet function exclusive),

and VESA Standards WSXGA+ (1,680 x 1,050), WXGA+ (1,440 x 900), WXGA (1,280 x 800,

NTSC (3.58/4.43), PAL (B/D/G/H/I/M/N), SECAM (B/D/G/K/K1/L), HDTV (720p, 1080i,

Analog RGB/Component Video (D-sub) x 2; Composite Video (RCA) x 1; S-Video (Mini •

DIN) x1 ; Component (3 RCA) x 1; HDMI (Video, Audio, HDCP) x 1; DVI (HDCP) x 1; PC

cable; Remote control; Battery x 2 for remote control; Detachable antenna; Wireless PnS

token;PnStokenholder;Detachablecableholder;Dusterlterx2;Lenscap;Carrying

Maximum UXGA (1,600 x 1,200), WSXGA+ (1,680 x 1,050)

case; Users guide (CD-ROM); Quick start guide; Security card

Native XGA (1,024 x 768),

768), SVGA (800 x 600), VGA (640 x 480)

1080p), EDTV (480p, 576p), SDTV (480i, 576i)

F = 2.52 ~ 2.79, f = 22.55mm ~ 27.06mm

1:1.2 Manual Zoom and Manual Focus

Audio (Stereo mini jack) x 2

Analog RGB (D-sub) x 1•

PC Audio (Stereo mini jack) x 1•

SPDIF Audio (RCA) x 1•

Network Audio (Stereo mini jack) x 1•

USB (Type B) x 1•

RS232 (Mini DIN) x 1•

Wired remote control port (Mini jack) x 1•

802.11b/g wireless technology• Ethernet port (RJ45) x 1•

Wireless antenna connector (SMA) x 1•

Maximum UXGA (1,600 x 1,200), WSXGA+ (1,680 x 1,050)

IBM PC and Compatibles, Apple Macintosh, iMac, and VESA Standards WSXGA+ (1,680 x

1,050), WXGA+ (1,440 x 900), WXGA (1,280 x 800, 1,280 x 768), UXGA (1,600 x 1,200), SXGA+

(1,400 x 1,050), SXGA (1,280 x 1,024), XGA (1,024 x 768), SVGA (800 x 600), VGA (640 x 480)

NTSC (3.58/4.43), PAL (B/D/G/H/I/M/N), SECAM (B/D/G/K/K1/L), HDTV (720p, 1080i,

Analog RGB/Component Video (D-sub) x 2; Composite Video (RCA) x 1; S-Video (Mini •

DIN) x1 ; Component (3 RCA) x 1; HDMI (Video, Audio, HDCP) x 1; DVI (HDCP) x 1; PC

AC power cord; VGA cable; Composite video cable; DVI cable; S-Video cable; Component

cable; Remote control; Battery x 2 for remote control; Detachable cable holder; Duster

lterx2;Lenscap;Carryingcase;Usersguide(CD-ROM);Quickstartguide;Securitycard

Native XGA (1,024 x 768)

1080p), EDTV (480p, 576p), SDTV (480i, 576i)

F = 2.52 ~ 2.79, f = 22.55mm ~ 27.06mm

1:1.2 Manual Zoom and Manual Focus

Audio (Stereo mini jack) x 2

Analog RGB (D-sub) x 1•

PC Audio (Stereo mini jack) x 1•

SPDIF Audio (RCA) x 1•

USB (Type B) x 1•

RS232 (Mini DIN) x 1•

Wired remote control port (Mini jack) x 1•

[52]

axiz product guide / Q4 2008 / october – december

Page 10

projectors

Code Projection System

display

Display Technology Native Resolution Brightness (ANSI-Lumens) Contrast Ratio (FIFO)

Noise Uniformity (min) JBMA

Color wheel Projection Lens

Projection Image

Lens Shift Projection Offset

Lamp

Aspect Ratio Control Sound Dimension (mm) Weight (kg)

Power Consumption

Power Supply

Input Signal Compatibility

Input/Output Terminals

Special Features

Accessory

High Brightness Economic

Focus Zoom Screen Size Standard

Throw Ratio

Typ e

Life High Brightness Life Economic

Digital DIVX)

RGB

Component Video Composite Video

(incl. S-Video)

DX535 DX540 DX630 HS102 DX325 DX420 DS420

LG Projectors

LGPRO-DX535

DLP DLP DLP DLP DLP DLP DLP

0.7 DMD 0.7 DMD 0.55 DMD 0.55 DMD 0.55 DMD 0.55 DMD 0.55 DMD

XGA(1024x768) XGA(1024x768) XGA (1024 x 768) SVGA ( 800 x 600 ) XGA(1024x768) XGA(1024x768) SVGA(800x600)

3500 4000 3000 160 2500 2000 2000

2300:1 2800:1 2300:1 2000:1 2200:1 2000:1 2000:1

34dB 32dB 29dB 30dB 34dB 30dB 30dB 32dB 30dB 24dB 27dB 30dB 28dB 28dB

>90% >90% >95% >90% >90% >90% >90%

4 segment(RGBW) 4 segment(RGBW) 4 segment(RGBW) - 5 segment(RYGWB) 5 segment(RYGWB) 5 segment(RYGWB)

Manual Manual Manual Manual Manual Manual Manual

Manual 1.2x Manual 1.2x Manual 1.17x Fixed Manual 1.15x Manual 1.15x Fixed

40~300 40~300 40~250 15 ~ 80 34~260 23~255 36 ~ 246

100@3.2m 100@3.2m 100@4.0m 40@1.1m 100@3.86m 50@2m 50@2m

1.569 1.569 1.94/2.27(wide/tele) 1.4 1.9 ~ 2.2 1.93~2.16 2.0

- - - - - - 1 1 115% 100% 128% 128% 128%

230W 300W 230W LED RGB(Luminus PT39) 200W 180W 180W 2000 Hr 2000 Hr 2000 Hr 30,000 hours 2000 Hrs 3000Hrs 3000Hrs 2500 Hr 2500 Hr 3000 Hr - 3000 Hrs 4000Hrs 4000Hrs

Native 4:3, Support 16:9 Native 4:3, Support 16:9 Native 4:3, Support 16:9 4:3, 16:9 4:3; 16:9, Native, letter box 4:3, 16:9 4:3, 16:9

- - - 1W Speaker 1W Speaker 1W speaker 1W speaker

346x263x109 346x263x109 302x271x95(Leg제제) 154x117x50 220x178x71 280x205x80mm 280x205x80mm

4.4kg 4.5kg 3.4 kg 750 g 1.45kg 2.58kg 2.54kg

280W

AC 100~240V(Free Voltage),

50/60Hz

1080i/720p/576p/480p, up to

SXGA+(1400x1050@60Hz)

1080i/720p/576p/480p, up to

SXGA+(1400x1050@60Hz) 1080i/720p/576p/576i/480p/480i 1080i/720p/576p/576i/480p/480i NTSC-M/NTSC 4.43/PAL/PAL-M/

PAL-N/SECAM

1 x RGB in / 1 x RGB out / 1 x

S Video / 1 x Composite / 1 x

Component(thru RGB) / 1 x HDMI /

1 x DVI / 1 x USB(Type B / SVC)

1 x RS-232C

Digital Keystone Correction /

Picture Still

Power code/D-sub 15 pin cable

Remote Control/Lens Cap/CD

Manual

AAA * 2EA Battery

LGPRO-DX540

100Vac : 380W, 240Vac : 350W

Stand-By 5W under

AC 100~240V(Free Voltage),

50/60Hz

1080i/720p/576p/480p, up to

SXGA+(1400x1050@60Hz)

1080i/720p/576p/480p, up to

SXGA+(1400x1050@60Hz)

NTSC-M/NTSC 4.43/PAL/PAL-M/

PAL-N/SECAM

1 x RGB in / 1 x RGB out / 1 x

S Video / 1 x Composite / 1 x

Component(thru RGB) / 1 x HDMI /

1 x DVI / 1 x USB(Type B / SVC)

1 x RS-232C

Digital Keystone Correction / Picture

Still / Quick Power on/off / Auto

Sleep / Smart Picture Mode

Presentation Timer / Brilliant Color™

/ Expert control

VIDI™

Power code/D-sub 15 pin cable

Remote Control/Quick setup Guide/

Lens Cap

CD Manual/AAA * 2EA Battery

LGPRO-DX630

290W / Stand-By 5W under 100 W / Stand-By 5W under 260 W / Stand-By 5W under 230W 230W

AC 100 ~ 240V(Free Voltage),

50Hz/60Hz

Up to SXGA+(1400X1050@60Hz) USB - - -

Up to SXGA+(1400X1050@60Hz)

1080i / 720p / 576P / 576i / 480p

NTSC/PAL/SECAM/NTSC4.43/

1 x RGB in / 1 x RGB out / 1 x S

1 x Component(YPbPr) / 1 x HDMI /

Digital Keystone Correction / Picture

Still / Quick Power on/off / Auto

Auto Color ADJ / Presentation Timer

Brilliant Color™ / Expert control

Power code/D-sub 15 pin cable

Remote Control/Quick setup Guide/

CD Manual/AAA * 2EA Battery

/ 480i

PAL-M/PAL-N

Video / 1 x Composite

1 x USB(SVC)

1 x RS-232C

Sleep / Smart Picture Mode

Lens Cap

LGPRO-HS102

AC DC Adaptor / 100 ~ 240 Hz,

50/60Hz

1080i/720p/576p/480p(50/60Hz)

up to SXGA(1280x1024@60Hz)

1080i/720P/576P/576i/480P/480i 1080i/720P/576P/576i/480P/480i

NTSC/PAL/SECAM/NTSC4.43/

PAL-M/PAL-N

1 x RGB in / 1 x Composite / 1 x

Component(thru RGB)

1 x USB

Digital Keystone Correction / Picture

Still / Quick Power on / off (5 sec

in between)

Carry bag/Power code/D-sub 15

RGB to Component Adapter/Video

pin cable

CD Manual/AAA * 2EA Battery /

cable

Remote Control

LGPRO-DX325

Typical@110Vac (100~240)/±10% AC 100 ~ 240V(Free Voltage) AC 100 ~ 240V(Free Voltage)

up to UXGA(1600x1200@60Hz)

NTSC/NTSC 4.43, PAL B/G/H/I/

M/N 60, SECAM

1 x RGB in / 1 x Audio(Mini Jack) /

1 x S Video

1 x Composite / 1 x Component(Thru RGB) 1 x USB(Type B / SVC)

Digital Keystone Correction / Picture

Still / Quick Power on/off / Auto

Brilliant Color™ / Expert control

D-sub 15 pin cable/Remote Control

Sleep

Carry bag/Power code

CD Manual/Lens Cap

LGPRO-DX420

Up to SXGA 1280x1024@75 Hz Up to SXGA 1280x1024@75 Hz

1080i / 720p / 576P / 576i / 480p

NTSC/NTSC 4.43, PAL B/G/H/I/

1 x RGB in / 1 x Audio(Mini Jack) /

Digital Keystone Correction / Picture

Still / Quick Power on/off / Digital

D-sub 15 pin cable/Remote Control

/ 480i

M/N/60, SECAM

1 x S Video

1 x Composite / 1 x

Component(Thru RGB ) / 1 x

USB(SVC)

Zoom

Auto Sleep

Carry bag/Power code

CD Manual/Lens Cap

1080i / 720p / 576P / 576i / 480p

NTSC/NTSC 4.43, PAL B/G/H/I/

1 x RGB in / 1 x Audio(Mini Jack) /

1 x Composite / 1 x

Component(Thru RGB ) / 1 x

Digital Keystone Correction / Picture

Still / Quick Power on/off / Digital

Carry bag/Power code

D-sub 15 pin cable/Remote Control

CD Manual/Lens Cap

LGPRO-DS420

/ 480i

M/N/60, SECAM

1 x S Video

USB(SVC)

Zoom

Auto Sleep

[54]

axiz product guide / Q4 2008 / october – december
