Acer AT350 F1 Specifications
Product Front View
Product Overview
The Acer AT350 F1 is a dual socket Tower Server that can be converted to rack mount use for
flexible deployments requiring blazing performance and exceptional expansion capability. Offering
high reliability features, leading edge technologies, cost-effective scalability features, and a
comprehensive list of management features the Acer AT350 F1 delivers high-availability with
optimal power efficiency for demanding departmental and medium enterprise deployments.
Product Inside View
Product Inside View
1. 18 x ECC DDR3 1066/1333 MHz registered or unbuffered memory slots
2. 2 x Intel® Xeon® 5600 series processors supporting up to 6-cores per processor
3. Hot-plug redundant system cooling fans
4. 2 x USB 2.0 Front-mounted connectors
5. Power button, System ID button, LED indicators (Power, HDD activity, LAN 1-2 status, system
ID/status/fault)
6. Support for up to sixteen 2.5” or eight 3.5” hot-plug SATA or SAS hard disk drives
7. 3 x Optical drive bays
8.
6 x PCI Express® slots with risers
1
Acer AT350 F1 Specifications
Product Rear View
6. Video connector
7. 2 x Gigabit LAN connector
s
1. PS2 keyboard connector
2. PS2 mouse connector
3. 4 x USB 2.0 connectors
4. Management IPMI LAN connector
5. COM (Serial) connector
8. ID LED
What's New
New Intel® Xeon® 5600 Series processors
2 x 720 W 80PLUS® gold-level efficient power supply units (1+1 redundant, hot-pluggable)
DDR3 memory
Energy Star Certified
Product Specifications
Processors and Chipset
Up to two Intel® Xeon® 5600 series processors
Chipset: Intel® 5520
Memory1
Memory capacity:
Registered DIMM: 2, 4, 8, 16 GB2
Unbuffered DIMM: 2, 4 GB
Up to 192 GB registered DIMMs when fully populated with 2 DIMMs per channel in 12 slots
Up to 48 GB unbuffered DIMMs when fully populated with 2 DIMMs per channel in 12 slots
Network Controllers
Integrated Intel® 82576EB dual-port Gigabit Ethernet Controller (2 ports total)
1
Mixed use of registered memory and unbuffered ECC memory not supported.
2
16 GB memory modules available by special request only.
2
Acer AT350 F1 Specifications
Storage
Hard disk form factor: 2.5” or 3.5”
Type: SAS/ SATA/ SSD with hot plug capability
HDD Capacity (enterprise level):
3.5” SAS HDD capacity: 300 GB, 450 GB, 600 GB
3.5” SATA HDD capacity: 250 GB, 500 GB, 1TB, 2TB
2.5” SAS HDD capacity: 73 GB, 146 GB, 300 GB, 450 GB, 600 GB
2.5” SATA HDD capacity: 150 GB, 300 GB, 500 GB
2.5” SSD capacity: 32 GB and 64 GB
3.5” Maximum capacity:
Up to 16 TB SATA HDD (2 TB 3.5" x 8 HDDs)
Up to 4.8 TB SAS (600 GB 3.5” x 8 HDDs)
2.5” Maximum capacity:
Up to 8 TB SATA HDD (500 GB 2.5" x 16 HDDs)
Up to 9.6 TB SAS (600 GB 2.5” x 16 HDDs)
Storage Controllers
Integrated Intel® ICH10R Serial ATA host controller (six 3 Gb/s SATA ports) with RAID 0, 1, 5, 10
support
Optional PCIe® 4-port/8-port and 16-port 6Gb/s SAS RAID card (standard on some models)
Expansion slots
Two full height PCI-E 2.0 x16 slot (with x8 link)
Two full height PCI-E 2.0 x8 slots (with x4 link)
One full height PCI-E 1.0 x8 slot (with x4 link)
One Acer Flex I/O (PCI-E 2.0 x8) slot
Management
Acer Smart Server Manager
System ID LED buttons, System Health LED
Acer Smart Console for server management and KVM over IP remote management
Deployment/Serviceability
Acer Smart Setup
BIOS Update Tool
IPMI Firmware Update Tool
Operating Systems
• Windows Server® 2008
• Windows Server® 2008 R2
• Windows Server® 2003
• Red Hat® Enterprise Linux 5.4
• SUSE® Linux Enterprise Server 11
• VMware ESXi™ 4
• VMware ESX™ 4
3
Acer AT350 F1 Specifications
Input/output interface
Front
One Power/off button
LED indicators: power, HDD activity, LAN port 1 through 2, and ID
Two USB ports
Rear
PS2 keyboard port
PS2 mouse port
Four USB 2.0 ports
Two RJ-45 ports (dual Gigabit NIC) with activity and link indicators
RJ-45 port (dedicated for management NIC) with activity and link indicators
Serial (DB-9) port
SVGA (DB-15) port
ID LED
Optical drive
5.25" half height SATA DVD/RW
Chassis/Form Factor
Tower/ 4U (convertible for rack mounting)
Power Supply
1 Power Supply Standard, 2nd optional
Up to 2 x 720 W 80 PLUS® Gold-level efficient hot-swap power supplies (1+1 redundant)
Regulatory Compliant Standards
EMC
FCC (Class A)
CE (Class A)
BSMI (Class A)
Safety
UL/cUL
CB
Nemko/GS
4
Acer AT350 F1 Specifications
Form factor
4U tower, rack mountable
sustained sunlight. Maximum rate of change is 10°C/hr.
FCC rating
Class A
Technical Specifications
Dimensions
(with bezel)
434 (W) x 648 (D) x 178 (H) mm (17.2 x 25.5 x 7 inches)
System inlet
temperature
Non-operating -40° - 70° C (-40° - 158° F) Maximum rate of change is
Relative humidity
(non-condensing)
Non-operating 5 - 95 % relative humidity (Rh), 38.7° C (101.7° F)
Emissions
classification
(EMC)
Power supply Rated Steady –state power 720 W
BTU rating 2456.64 BTU/hr. at 100 - 240 VAC
Operating 10° - 35° C (50° - 95° F) at sea level with an altitude
derating of 1° C per 305 m (1.8° F per 1000 ft.) above
sea level to a maximum of 3050 m (10,000 ft.) no direct
(18°F/hr.). The upper limit depends on the type and
number of options installed. System performance may
be reduced if operating with a fan fault or above 30°C
(86°F).
20°C/hr. (36°F/hr.).
Operating 8 - 90 % relative humidity (Rh), 28° C (82.4° F)
maximum wet bulb temperature, non-condensing
maximum wet bulb temperature, non-condensing
Normative standards
Maximum Peak Power 728 W
EN55022, EN 61000-3-2, EN 61000-3-3, CISPR 22
Class A
5
Acer AT350 F1 Specifications
Intel®
Xeon
®
Quad
-
Core processor
Chipset
Memory
3
Type
Capacity
Standard Features
Processors
Intel® Xeon® Six-Core processor
X5675 (12 MB L3 cache, 3.06 GHz, 6.4 GT/s, DDR3-1333 MHz, 95 W)
E5620 (12 MB L3 cache, 2.40 GHz, 5.86 GT/s, DDR3-1066 MHz, 80 W)
L5630 (12 MB L3 cache, 2.13 GHz, 5.86 GT/s, DDR3-1066 MHz, 40 W)
E5606 (8 MB L3 cache, 2.13 GHz, 4.8 GT/s, DDR3-1066 MHz, 80 W)
Intel® 5520
DIMM sockets 18
Maximum capacity Registered DIMM: 192 GB
Memory protection ECC, Mirroring, Sparing, Lockstep Mode, x4/x8 SDDC
Network controller Integrated dual Intel® 82576EB Gigabit Ethernet Controller (two ports)
DDR3 1066/1333 MHz Registered memory
DDR3 1066/1333 MHz Unbuffered ECC memory
Registered DIMM: 2 / 4 / 8 / 16 GB4
Unbuffered ECC DIMM: 2 / 4 GB
Unbuffered DIMM: 48 GB
3
Mixed use of registered memory and unbuffered ECC memory not supported.
4
16 GB memory modules available by special request only.
6
Acer AT350 F1 Specifications
PCIe
®
2
PCIe
®
Gen 2
x8
3.3V
x16 Full height
controller
transfer channels
•
Expansion slots
The primary I/O bus for the main board is PCIe® Gen2. The following table lists the characteristics of the
PCI-E bus segments.
PCI express® Bus Segment Characteristics of PCI Express® Topology
Expansion Slot # # of
slots
Type Bus
Width1
Vol. Con.
Width
Length
PCIe® 2 PCIe® Gen 2 x4 3.3V x8 Full height
PCIe® 1 PCIe® Gen 1 x4 3.3V x8 Full height
Acer Flex I/O 1 PCIe® Gen 2 x8 3.3V x8
NOTE:
1. Indicates the number of physical electrical lanes running to a PCIe® connector.
2. Inserting cards with PCI™ bridges may alter the actual bus assignment number.
3. Slots are enumerated differently based on the operating system. Microsoft® operating systems
enumerate Device ID by bus starting from the lowest bus to the highest.
Storage controllers Intel 82801JR (ICH10R) I/O Controller Hub
Note: Onboard SATA software RAID cannot be enabled when add-on SAS RAID is
enabled.
Integrated Serial ATA
Transfer rate
Simultaneous drive
6 channels
3 GB/s per channel
synchronous
(maximum theoretical)
Data transfer method non-RAID mode
RAID mode
Drive support Serial ATA
Data transfer modes Legacy mode
Combined mode
Protocol Serial ATA
Feature NCQ (Native Command Queuing)
AHCI (Advanced Host Controller Interface)
RAID levels supported 0, 1, 5, 10 (Windows®)
0, 1, 10 (Linux)
RAID features
Supports multiple logical volumes
• Supports setup through ROM based array
configuration utility installation scripting
NOTE: This controller requires the software RAID driver to
support hot-plug functions.
RAID OS support Windows Server® 2008
Windows Server® 2008 R2
Red Hat® Enterprise Linux 5.4
SUSE® Linux Enterprise Server 11
7
Acer AT350 F1 Specifications
Gigabit server adapter
(Intel
82576EB)
1000Base
-TX
Network transfer rate
10Base
-
T (full
-
duplex)
20 Mb/s
Cable support
CAT 5e wire
•
•
Embedded dual-port
®
Compatibility IEEE 802.3 10Base-T
Data transfer method Four lane (x4), 100 MHz PCI Express reference clock
Connector RJ-45
Network interface 10Base-T
100Base-TX
IEEE 802.3ab 1000Base-T
IEEE 802.3u 100Base-TX
10Base-T (half-duplex) 10 Mb/s
100Base-TX (half-duplex) 100 Mb/s
100Base-TX (full-duplex) 200 Mb/s
1000Base-TX (half- and full-duplex) 2000 Mb/s
Virtualization
acceleration
Manageability NC-SI SMBus, PXE, iSCSI boot
Storage
Maximum internal
storage
3.5” Maximum capacity
Hard disk drive
2.5” Maximum capacity
Intel® I/O Acceleration Technology
Virtual Machine Device Queues (VMDq)
PCI-SIG® SR-IOV implementation
Up to 8 hot-pluggable 3.5" SATA/SAS HDD
• Up to 16 hot-pluggable 2.5” SATA/SAS/SSD
HDD
Up to 16 TB SATA
• Up to 4.8 TB SAS
• Up to 8 TB SATA
• Up to 9.6 TB SAS
• Up to 1 TB SSD
8
Acer AT350 F1 Specifications
Drive Support
– Optical and Hard Disk Drive
Supported
16 SAS/SATA/SSD HDD’s*
9 10 11 12 13 14 15
Optical drive support
A
B
C
A
B
C
0 1 2 3 4 5 6 7
Drive Quantity
5.25” SATA DVD/RW Optical
Drive
Hard Disk Drive Support
Drive Quantity
2.5” SATA/SAS/SAS hard drive Up to 16 0 – 15
Up to 3 A, B, C Integrated SATA controller
Supported
Bay Supported Required Controller
Bay Supported Required Controller
Integrated SATA controller for
up to 4 SATA HDD’s
4-port SAS RAID card for up to 4
SAS/SATA/SSD HDD’s*
8-port SAS RAID card for up to 8
SAS/SATA/SSD HDD’s*
16-port SAS RAID card for up to
9
Acer AT350 F1 Specifications
Tape Backup Support
3.5” SATA/SAS hard drive Up to 8 0 – 7
Integrated SATA controller for
up to 4 SATA HDD’s
4-port SAS RAID card for up to 4
SAS/SATA HDD’s*
8-port SAS RAID card for up to 8
SAS/SATA HDD’s*
*standard on some models.
NOTE: Transfer rates of drives are dependent on the maximum transfer rate supported by the host bus
adapter (HBA) or controller.
Drive Bay Supported Required Controller
LTO-3 1U SAS Rackmount (external)
Tape Drive kit
LTO-4 1U SAS Rackmount (external)
Tape Drive kit
160/320 GB, DAT320, 5.25”, internal half
height, USB interface
External SAS card
External SAS card
B and C Internal USB 2.0 ports
80/160 GB, DAT160, 5.25”, internal half
height, USB interface
36/72 GB, DAT72 (DDS Gen-5), 5.25”,
internal half height, USB interface
B and C Internal USB 2.0 ports
B and C Internal USB 2.0 ports
10
Acer AT350 F1 Specifications
•
Graphics BMC chip embedded
• 1280 x 1024
• 16 M colors
• 16 MB video memory
Industry standard
compliance
Security HDD carrier mechanical lock
System cooling
Operating systems
and virtualization
software support
IPMI 2.0 Compliant (iBMC)
APM 1.2 compliant
SMBUS 2.0
SMBIOS 2.61 compliant
ACPI v3.0b Compliant
PCI-E 1.1 for Gen 1 and PCI-E 2.0 for Gen 2
PXE 2.1 support
TPM cer1.2 compliance (through optional module)
WOL support
Microsoft Windows® Hardware Logo Program Requirements
Energy Start 1.0 Compliant
Chassis intrusion alert
Administrator / user password
Keyboard password
Power-on password
USB port control
TPM controller (TPM v1.2 compliant) (manufacturing option)
2 x CPU heat sinks supporting Intel® Xeon® processors with up to TDP 95 W
• Two 1+1 hot-plug/redundant system rear fans with PWM control
• Three 1+1 hot-plug/redundant system front fans with PWM control on fan wall
Windows Server® 2008
Windows Server® 2008 R2
Windows Server® 2003 R2
Red Hat® Enterprise Linux 5.4
SUSE® Linux Enterprise Server 11
VMware ESX™ 4
11
Acer AT350 F1 Specifications
Intelligent
approach
of in a responsible manner.
Server Management Utilities and Applications
Comprehensive management solutions deliver powerful and intuitive management features to
simplify server set ups, configuration, management, monitoring, and reporting for the entire
lifecycle of servers. Centralized administration and automatic management with remote access
control free the IT resources and meet the complex business environment. Proactive monitoring
and notification lead higher customers’ satisfaction and higher levels of operational efficiency.
Smart Setup 2.0 Easy deployment via the latest version of Acer’s Smart Setup. Smart Setup is
available both in box as a driver packed installation DVD or a downloadable file
to be put into a USB 2.0 device, and eases the deployment of Acer servers for
any certified OS. Through its unique interface, users may select to have all the
correct drivers be pre-deployed for the OS of their choosing, as well as setup
hardware RAID devices, BMC settings (where available), and even clone the
pre-settings to a bootable USB device to ease mass server deployments.
Smart Console Web-based management utility to simplify system management with embedded
iBMC, system monitoring and alerting, event handling, remote power control
and KVM-over-IP. Smart Console is OS independent and offers virtual media
through floppy, ODD, and removable disk.
Smart Server
Manager v1.1
manageability
Environment-friendly
products and
Offering 24-7 monitoring for system health and performance.
Delivers proactive event management features including system event logging,
event handling from e-mail and SNMP Trap (PET) alerting.
Monitors onboard hardware, operating systems and virtual machines
Allows remote control from KVM and Power control
Satisfies management in web-based UI, role-based administration, and
automated management scripts.
Automatic Server Recovery (ASR)
Integrated Management Log
Front and Rear Unit ID (UID) button/LED
BIOS Update tool for DOS supporting DOS and Windows OS
IPMI Firmware Update tool supporting DOS and Windows OS
Backplane firmware update tool, supporting DOS and Windows OS
Acer offers end-of-life product return, trade-in, and recycling programs in many
geographic areas. Products returned to will be recycled, recovered or disposed
12
Acer AT350 F1 Specifications
Memory Support Specification
Registered Type DDR3 1066/ 1333 MHz
Capacity: 2, 4, 8, 16 GB
Voltage: 1.5 V
Maximum: 192 GB (16 GBx12 DIMMs)
Unbuffered Type DDR3 1066/ 1333 MHz
Capacity: 2, 4 GB
Voltage: 1.5 V
Maximum: 48 GB (4 GB x 12 DIMMs)
Memory protection ECC, Mirroring, Sparing, Lockstep Mode, x4/x8 SDDC
Note: Mixing of registered memory and unbuffered ECC memory is not supported.
16 GB memory modules available by special request only.
Memory Population
The systems have eighteen DIMM slots. Each CPU controls nine slots. The DIMM slots support DDR31333 registered/unbuffered ECC memory modules. For single rank and dual rank RDIMM the system
supports a maximum of 3 DIMMs per channel and a total of 18 DIMMs can be supported. For UDIMM and
quad rank RDIMM, the system supports 2 DIMMs per channel and a total of 12 DIMMs can be supported.
• Each CPU has three memory channels (channel 1, 2 and 3).
• Each channel has 3 slots.
To maximize the memory performance, the DIMM modules should be installed as balanced as possible
among processors and memory channels. Slots with the same slot number across memory channels
should be populated with identical DIMMs.
13
Acer AT350 F1 Specifications
16GB*
16GB
48GB*
16GB 16GB 16GB
64GB*
16GB 16GB
16GB 16GB
96GB*
16GB 16GB
16GB 16GB
16GB 16GB
Independent mode (please refer to the User Guide for more information)
• In this mode all memory is accessible and ECC protected
Single processor configuration
No. of
DIMMs
1 X
2 X X
3 X X X
4 X X X X
6 X X X X X X
9* X X X X X X X X X
*
Single Ranked(SR)/Double Ranked(DR) RDIMM only.
Total
Memory
2GB 2GB
4GB 2GB 2GB
6GB 2GB 2GB 2GB
8GB 2GB 2GB 2GB 2GB
12GB 2GB 2GB 2GB 2GB 2GB 2GB
18GB 2GB 2GB 2GB 2GB 2GB 2GB 2GB 2GB 2GB
4GB 4GB
8GB 4GB 4GB
12GB 4GB 4GB 4GB
16GB 4GB 4GB 4GB 4GB
24GB 4GB 4GB 4GB 4GB 4GB 4GB
36GB 4GB 4GB 4GB 4GB 4GB 4GB 4GB 4GB 4GB
8GB 8GB
16GB 8GB 8GB
24GB 8GB 8GB 8GB
32GB
48GB
P1
DIMM 1C
P1
DIMM 1C
P1
DIMM 1B
P1
DIMM 1B
8GB 8GB 8GB 8GB
8GB 8GB 8GB 8GB 8GB 8GB
P1
DIMM 1A
P1
DIMM 1A
P1
DIMM 2C
P1
DIMM 2C
P1
DIMM 2B
P1
DIMM 2B
P1
DIMM 2A
P1
DIMM 2A
P1
DIMM 3C
P1
DIMM 3C
P1
DIMM 3B
P1
DIMM 3B
P1
DIMM 3A
DIMM 3A
P1
32GB* 16GB 16GB
* 16 GB memory modules available by special request only.
14
Acer AT350 F1 Specifications
Memory
1C
1B
1A
2C
2B
2A
3C
3B
3A
1C
1B
1A
2C
2B
2A
3C
3B
3A
Dual processor configuration
No. of
DIMMs
18* X X X X X X X X X X X X X X X X X X
*
Single Ranked (SR)/Double Ranked (DR) RDIMM only.
P1
P1
P1
1C
1B
1A
2 X X
4 X X X X
6 X X X X X X
8 X X X X X X X X
9 X X X X X X X X X
12 X X X X X X X X X X X X
Total
4GB 2 2
8GB 2 2 2 2
12GB 2 2 2 2 2 2
16GB 2 2 2 2 2 2 2 2
18GB 2 2 2 2 2 2 2 2 2
24GB 2 2 2 2 2 2 2 2 2 2 2 2
36GB 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2
8GB 4 4
16GB 4 4 4 4
24GB 4 4 4 4 4 4
32GB 4 4 4 4 4 4 4 4
36GB 4 4 4 4 4 4 4 4 4
48GB 4 4 4 4 4 4 4 4 4 4 4 4
72GB 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4
16GB 8 8
32GB 8 8 8 8
48GB 8 8 8 8 8 8
64GB 8 8 8 8 8 8 8 8
72GB 8 8 8 8 8 8 8 8 8
96GB 8 8 8 8 8 8 8 8 8 8 8 8
144GB 8 8 8 8 8 8 8 8 8 8 8 8 8 8 8 8 8 8
32GB* 16 16
64GB* 16 16 16 16
96GB* 16 16 16 16 16 16
128GB* 16 16 16 16 16 16 16 16
144GB* 16 16 16 16 16 16 16 16 16
192GB* 16 16 16 16 16 16 16 16 16 16 16 16
P1
P1
P1
* 16 GB memory modules available by special request only.
CPU1 CPU2
P1
P1
P1
P1
P1
P1
P2
P2
P2
P2
2C
2B
2A
3C
3B
3A
1C
1B
1A
2C
CPU1 CPU2
P1
P1
P1
P1
P1
P1
P2
P2
P2
P2
P2
2B
P2
P2
2A
P2
P2
3C
P2
P2
3B
P2
P2
3A
P2
15
Acer AT350 F1 Specifications
Mirroring mode:
• In mirroring mode, the memory contains a primary image and a copy of the primary image therefore the
effective size of memory is reduced by one half.
• Channel 3 has no function in these modes.
• Follow the population rules described in independent mode.
• Mirroring mode needs the channel 1 & channel 2 DIMMs to be identical. DIMM slot populations within a
channel do not have to be identical but the same DIMM slot location across channel 1 and channel 2
must be the same. DIMM1A and DIMM2A should be the same type, size and manufacturer. DIMM1B
and DIMM2B memory should be the same type, size and manufacturer. DIMM1C and DIMM2C
memory should be the same type, size and manufacturer.
• Same rules apply to CPU2.
• 3 DIMMs per channel configuration is only available for single/dual rank RDIMM.
• Please refer to the User Guide for complete population rules for both single and dual processor
configurations.
Lockstep mode:
• In Lockstep Channel Mode, each memory access is 128-bit data access that spans Channel 1 and
Channel 2. This is done to support SDDC for DRAM devices with 8-bit wide data ports. The same
address is used on both channels such that an address error on any channel is detectable.
• Lockstep Channel mode is the only RAS mode that supports x8 SDDC.
• Channel 3 has no function in these modes.
• Follow the population rules described in independent mode.
• Lockstep mode needs the channel 1 & channel 2 DIMMs to be identical. DIMM slot populations within a
channel do not have to be identical but the same DIMM slot location across channel 1 and channel 2
must be the same. DIMM1A and DIMM2A should be the same type, size and manufacturer. DIMM1B
and DIMM2B memory should be the same type, size and manufacturer. DIMM1C and DIMM2C
memory should be the same type, size and manufacturer.
• Same rules apply to CPU2.
• 3 DIMMs per channel configuration is only available for single/dual rank RDIMM.
• Please refer to the User Guide for complete population rules for both single and dual processor
configurations.
Sparing mode:
• In sparing mode, if the system detects degrading memory, the data in the failed channel will be copied to
the spare channel. The failed channel is then isolated and the spare channel becomes active. Any
uncorrectable error detected before the isolation will cause the system to stop normal operation.
• Channel 3 is the spare channel. Therefore, the effective size will be reduced by one-third.
• Follow the population rules described in independent mode.
• Sparing mode needs all three channels to utilize identical DIMMs. 1A, 2A and 3A should be the same
type, size and manufacturer. 1B, 2B and 3B memory should be the same type, size and manufacturer.
1C, 2C and 3C memory should be the same type, size and manufacturer.
• Same rule is applied to CPU2.
• 3 DIMMs per channel configuration is only available for single/dual rank RDIMM.
• Please refer to the User Guide for complete population rules for both single and dual processor
configurations.
16
Acer AT350 F1 Specifications
Memory Identification
Generally, there is memory information printed on the label of the DIMM, but different vendors may have
different formats. For example:
4GB 2Rx4 PC3-10600R xx xx xxx
1. Density
• 2GB, 4GB, 8GB, 16GB
• Intel® Xeon® 5600 series processors support DIMMs organized by 1Gb, 2Gb or 4Gb DRAM chips
2. Rank
• 1R = Single Rank
• 2R = Dual Rank
• 4R = Quad Rank
• Note: if any quad rank DIMM is used, maximum only 2 DIMMs per channel can be supported
3. Bit Organization
• This platform supports x4 and x8
• Note: It is not recommended to mix DIMMs with different bit organizations in one system
4. Speed
• PC3 – 6400 => DDR3- 800
• PC3 – 8500 => DDR3- 1066
• PC3 – 10600 => DDR3- 1333
17
Acer AT350 F1 Specifications
720W Power Supply
Power Supply Specification
Operational
Input Voltage
Range (Vrms)
Frequency
Range
(Nominal) (Hz)
Nominal Input
Voltage (Vrms)
Max. Rated
Output Wattage
Nominal Input
Current (A rms)
Max. Rated
Input Wattage
Rating (Watts)
Max. Rated VA
(Volt-Amp)
Efficiency (%) at
Max. Rated
Output Wattage
100 to 240 VAC
50 / 60
100 120 208 200 220 230 240
720 720 720 720 720 720 720
8.6114 7.0132 3.951 4.0993 3.7458 3.5995 3.4697
851.6 837.58 811.51 811.88 809.78 808.82 807.77
859.0739 841.0282 822.7821 821.1591 825.2115 828.9638 834.0423
84.55% 85.96% 88.72% 88.68% 88.91% 89.02% 89.13%
Power Factor
Leakage
Current (mA)
Max. Inrush
Current (A
peak)
Max. Inrush
Current
Duration (mS)
Max. British
Thermal Unit
Rating (BTU/hr.)
1 KW = 3412 BTU/hr.
0.9913 0.9959 0.9863 0.9887 0.9813 0.9757 0.9685
Less
than 3.5
Less
than 25A
Less
than 10
2903.956 2856.148 2767.249 2768.511 2761.35 2758.076 2754.496
Less than
3.5
Less than
25A
Less than
10
Less than
3.5
Less than
25A
Less than
10
Less than
3.5
Less than
25A
Less than
10
Less than
3.5
Less than
25A
Less than
10
Less than
3.5
Less than
25A
Less than
10
Less
than 3.5
Less
than 25A
Less
than 10
18
Acer AT350 F1 Specifications
•
•
•
•
•
TPM
Optical Drive
Flash memory
Hardware Key Options
CPU
HDD
Memory
SAS HBA
SAS RAID
Intel® Xeon® 5600 series
SAS 2.5”: 73 GB, 146 GB, 300 GB, 450 GB, 600 GB
• SAS 3.5”: 300 GB, 450 GB, 600 GB
• SATA 2.5”: 150 GB, 300 GB, 500 GB
• SATA 3.5”: 250 GB, 500 GB, 1TB, 2 TB
• SATA SSD 2.5”: 32GB, 64GB
DDR3 1333 MHz Unbuffered ECC 2/ 4 GB
• DDR3 1333 MHz Registered ECC 2/ 4/ 8/ 16 GB
SAS HBA, internal 2-ports/external 2-ports, PCI-E x1 interface
MegaRAID® SAS 9240-4i, 4 internal ports, PCIe x8, supporting RAID 0/1/10/5
• MegaRAID® SAS 9260-8i, 8 internal ports, 512 MB PCIe x8, supporting RAID
0/1/10/5/50/6/60
• MegaRAID® SAS 9260-16i, 16 internal ports, 512 MB PCIe x8, supporting RAID
0/1/10/5/50/6/60
• LSI® BBU07/ Battery Backup Unit for MegaRAID® SAS 9260-8i and 9260-16i
Networking
Fibre Channel HBA
Gigabit CT Desktop Adapter, Gigabit Adapter 10/100/1000 Mbps
Gigabit ET Server Adapter, Gigabit 10/100/1000 Mbps, PCIe, dual-port
Gigabit ET2 Server Adapter, Gigabit Adapter 10/100/1000 Mbps, PCIe, quad-port
Ethernet Server Adapter X520-DA2, 10 Gb, Dual ports, direct attach
Ethernet Server Adapter X520-LR1, single port, LR
Ethernet Server Adapter X520-SR1, single port, SR
Ethernet Server Adapter X520-SR2, dual ports, SR
Qlogic SANblade® QLE2460 single port fibre channel to PCI express host bus
adapter, 1 ch, 8 Gb FC HBA, PCIe x8, single LC port (std & low-profile bracket)
Qlogic SANblade® QLE2462 dual ports fibre channel to PCI express host bus
adapter, 2ch, 8 Gb FC HBA, PCIe x8, dual LC port (std & low-profile bracket)
Server Additional Options/Accessories
TPM module (TPM 1.2)
Half height SATA DVD/RW
USB low profile flash memory for VMware embedded
HDD cage/
backplanes
Tape & Disk based
backup
Rackmount kits
2.5” 4-bay HDD cage (std in some models)
3.5” 6-bay HDD cage (std in some models)
LTO-3 1U SAS Rackmount (external) Tape Drive kit
LTO-4 1U SAS Rackmount (external) Tape Drive kit
36/72 GB, DAT72 (DDS Gen-5), 5.25”, internal half height, USB interface
80/160 GB, DAT160, 5.25”, internal half height, USB interface
160/320 GB, DAT320, 5.25”, internal half height, USB interface
Sliding rails for 4U rack conversion
19
Acer AT350 F1 Specifications
Service and Support
Acer Servers offer a comprehensive service suite to take care of daily IT needs. Users can select the 3year standard warranty or choose extended warranties and services5.
The standard warranty for the AT350 F1 includes three years Parts coverage only.
Warranty repairs may be accomplished through the use of Customer Replacement Unit (CRU) parts. CRU
parts include: Hot Plug Hard Drives and Hot Plug Power Supplies. These parts are designed for easy
replacement without tools. Travel and labor charges may apply if customers decline to replace a CRU part.
In a continuing effort to improve the quality of our products, information in this document is subject to change without notice.
Images shown are only representations of some of the configurations available for this model. Availability may vary depending on
region.
Microsoft and Windows are registered trademarks of Microsoft Corporation. Intel, the Intel® logo, Pentium, Xeon® and Xeon®
Inside are trademarks of Intel® Corporation.
© 2010. All rights reserved.
5
Extension warranty services may vary by country. Please contact Acer authorized resellers for more information.
20
Acer AT350 F1 Specifications
Acer Standard Server Models
Acer AT350 LFF Models
Acer AT350F1 Xeon E5606, 1x4GB DDR3 Reg, No HDD, 4x3,5" HDD bay (second optional), onboard
SATA, DVD-RW, 1x720W 80+ Gold PSU (second optional), 2x GBit LAN onboard, Acer Smart Setup,
Acer Smart Manager, US Power Cable, USB Mouse, USB Keyboard TT.R5900.085
Acer AT350F1 Xeon E5620, 2x4GB DDR3 Reg, No HDD, 4x3.5" HDD bay (second optional), 4 Port
6G SAS RAID Controller , DVD-RW, 1x720W 80+ Gold PSU (second optional), 2x GBit LAN onboard,
Acer Smart Setup, Acer Smart Manager, US Power Cable, USB Mouse, USB Keyboard TT.R5900.082
Acer AT350 SFF Models
Acer AT350F1 Xeon E5620, 2x4GB DDR3 Reg, No HDD, 8x2.5" HDD bay (second optional), 8 Port
6G SAS RAID Controller with 512MB Cache, DVD-RW, 1x720W 80+ Gold PSU (second optional), 2x
GBit LAN onboard, Acer Smart Setup, Acer Smart Manager, US Power Cable, USB Mouse, USB
Keyboard TT.R5900.081
Acer AT350F1 Xeon L5630, 2x4GB DDR3 Reg, No HDD, 8x2.5" HDD bay (second optional), 8 Port 6G
SAS RAID Controller with 512MB Cache, DVD-RW, 1x720W 80+ Gold PSU (second optional), 2x GBit
LAN onboard, Acer Smart Setup, Acer Smart Manager, US Power Cable, USB Mouse, USB Keyboard
TT.R5900.083
Acer AT350F1 Xeon E5645, 2x4GB DDR3 Reg, No HDD, 8x2.5" HDD bay (second optional), 8 Port
6G SAS RAID Controller with 512MB Cache, DVD-RW, 1x720W 80+ Gold PSU (second optional), 2x
GBit LAN onboard, Acer Smart Setup, Acer Smart Manager, US Power Cable, USB Mouse, USB
Keyboard TT.R5900.101
Acer AT350F1 Xeon X5675, 2x4GB DDR3 Reg, No HDD, 8x2.5" HDD bay (second optional), 8 Port
6G SAS RAID Controller with 512MB Cache, DVD-RW, 1x720W 80+ Gold PSU (second optional), 2x
GBit LAN onboard, Acer Smart Setup, Acer Smart Manager, US Power Cable, USB Mouse, USB
Keyboard TT.R5900.086
Part Number
Acer Key Options
Acer CPU Heatsink
Note: one heatsink required for each processor option kit
Acer Intel CPU heat-sink (TDP 95W supported) for DP tower server TC.34900.006
Acer Processor upgrade kits
Note: one heatsink required for each processor option kit
Note: all processors in a system must match
Acer Intel® Xeon® processor E5606 (B-1) Kit TC.32500.041
Acer Intel® Xeon® processor E5620 (B-1) Kit TC.32500.024
Acer Intel® Xeon® processor L5630 (B-1) Kit TC.32500.026
Acer Intel® Xeon® processor E5645 (B-1) Kit TC.32500.037
Acer Intel® Xeon® processor X5675 (B-1) Kit TC.32500.039
Acer Memory
Note: cannot mix Unbuffered memory with Registered memory
Note: please refer to "Memory Support" Section for details on configuring memory
Acer Unbuffered Memory
Acer 2GB DDR3-1333 Unbuffered Memory Kit (1 pc.) TC.33100.035
Acer 4GB DDR3-1333 Unbuffered Memory Kit (1 pc.) TC.33100.037
Acer Registered Memory
Acer 2GB DDR3-1333 Registered Memory Kit (1 pc.) TC.33100.029
Acer 4GB DDR3-1333 Registered Memory Kit (1 pc.) TC.33100.031
Acer 8GB DDR3-1333 Registered Memory Kit (1 pc.) TC.33100.042
Acer Storage
Acer SATA Hot Plug LFF (3.5-inch) Midline (MDL) Drives
Note: LFF drives are supported only on AT350 models with the 6x3.5" HDD Bay
Acer 250GB 3Gb/s 7.2K 3.5-inch Enterprise SATA HDD Kit TC.32700.068
Acer 500GB 3Gb/s 7.2K 3.5-inch Enterprise SATA HDD Kit TC.32700.066
Acer 1TB 3Gb/s 7.2K 3.5-inch Enterprise SATA HDD Kit TC.32700.064
Acer 2TB 3Gb/s 7.2K 3.5-inch Enterprise SATA HDD Kit TC.32700.062
Part Number
21
Acer AT350 F1 Specifications
Acer 16
-
port 6Gb/s SAS RAID Adapter (w/ mSAS
-
mSAS cable) Kit
TC.32300.042
Acer SAS Hot Plug LFF (3.5-inch) Enterprise Drives
Note: LFF drives are supported only on AT350 models with the 6x3.5" HDD Bay
Acer 300GB 6Gb/s 15K 3.5-inch Enterprise SAS HDD Kit TC.32700.079
Acer 450GB 6Gb/s 15K 3.5-inch Enterprise SAS HDD Kit TC.32700.077
Acer 600GB 6Gb/s 15K 3.5-inch Enterprise SAS HDD Kit TC.32700.075
Acer SATA Hot Plug SFF (2.5-inch) Midline (MDL) Drives
Note: SFF drives are supported only on AT350 models with the 8x2.5" HDD Bay
Acer 150GB 3Gb/s 10K 2.5-inch Enterprise SATA HDD Kit TC.32700.090
Acer 300GB 3Gb/s 10K 2.5-inch Enterprise SATA HDD Kit TC.32700.088
Acer 500GB 3Gb/s 7.2K 2.5-inch Enterprise SATA HDD Kit TC.32700.046
Acer SAS Hot Plug SFF (2.5-inch) 10K Enterprise Drives
Note: SFF drives are supported only on AT350 models with the 8x2.5" HDD Bay
Acer 146GB 6Gb/s 10K 2.5-inch Enterprise SAS HDD Kit TC.32700.083
Acer 300GB 6Gb/s 10K 2.5-inch Enterprise SAS HDD Kit TC.32700.081
Acer 450GB 6Gb/s 10K 2.5-inch Enterprise SAS HDD Kit TC.32700.072
Acer 600GB 6Gb/s 10K 2.5-inch Enterprise SAS HDD Kit TC.32700.070
Acer SAS Hot Plug SFF (2.5-inch) 15K Enterprise Drives
Note: SFF drives are supported only on AT350 models with the 8x2.5" HDD Bay
Acer 73GB 6Gb/s 15K 2.5-inch Enterprise SAS HDD Kit TC.32700.087
Acer 146GB 6Gb/s 15K 2.5-inch Enterprise SAS HDD Kit TC.32700.085
Acer SATA Hot Plug SFF (2.5-inch) Enterprise SSD Drives
Note: SFF drives are supported only on AT350 models with the 8x2.5" HDD Bay
Acer 32GB SLC SATA 2.5-inch Enterprise SSD Kit TC.33900.003
Acer 64GB SLC SATA 2.5-inch Enterprise SSD Kit TC.33900.004
Acer SAS Storage Controllers
Acer 4-port (2 int., 2 ext.) 3Gb/s SAS HBA TC.32300.008
Acer 4-port 6Gb/s SAS RAID Adapter (w/ mSAS-mSAS cable) Kit TC.32300.028
Acer 8-port 6Gb/s SAS RAID Adapter (w/ mSAS-mSAS cable) Kit TC.32300.034
Acer Battery Backup Kit for Cache module in 8port/16port SAS RAID Card TC.34800.006
Acer Redundant Power Supply
Acer 720 W Power Supply Module (GOLD level) TC.33600.005
Acer Fibre Channel Storage Controllers
Acer 8Gb/s Single Port Fibre Channel HBA Kit TC.32300.024
Acer 8Gb/s Dual Port Fibre Channel HBA Kit TC.32300.026
Acer Tape Drives
Acer 36/72GB, DAT72 (DDS Gen-5), 5.25", internal, half-height, default USB cable TC.34000.026
Acer 80/160GB, DAT160, 5.25", internal, half-height, interface USB, default USB cable TC.34000.028
Acer 160G/320G ,DAT 320, 5.25" Internal Half-Height ,Interface USB, default USB cable TC.34000.030
Acer LTO-3/LTO-4 1U Rackmount (ext.) Chassis Kit TC.34000.040
Acer LTO-3 HH (int.) Tape Drive Kit - Compatible with Acer Servers which support Internal LTO drives
(or) 1U external Rackmount chassis kit
Acer LTO-4 HH (int.) Tape Drive Kit -Compatible with Acer Servers which support internal LTO drives
(or) 1U external Rackmount chassis kit
TC.34000.022
TC.34000.024
22
Acer AT350 F1 Specifications
Acer Additional Upgrades
Acer 4-bay 3.5-inch Hot-plug HDD Cage Kit TC.32800.004
Acer 8-bay 2.5-inch Hot-plug HDD Cage Kit TC.32800.006
Acer DVD-SuperMultidriveKit TC.33500.002
Acer Sliding Rail (AT150 F1/AT350 F1) Kit (900mm or 1000mm Rack required) TC.33700.012
Acer Gigabit Single Port LAN Adapter Kit TC.32200.011
Acer Gigabit Dual Port Server LAN Adapter Kit TC.32200.009
Acer Gigabit Quad Port Server LAN Adapter Kit TC.32200.010
Acer 10 Gigabit Dual Port (DA) Server LAN Adapter Kit TC.32200.012
Acer 10 Gigabit Single Port (SR) Server LAN Adapter Kit TC.32200.014
Acer 10 Gigabit Single Port (LR) Server LAN Adapter Kit TC.32200.013
Acer 10 Gigabit Dual Port (SR) Server LAN Adapter Kit TC.32200.015
Acer Operating Systems
Windows Server Enterprise 2008
Acer ROK Windows SVR 2008 R2 Enterprise (64bit,25Clt,EN) TC.34400.035
Acer ROK MICROSOFT Win SVR 2008 64bit Ent R2 10 Clt EN W/COA W/CD/DVD ACER 1-8CPU TC.34400.034
Windows Server Standard 2008
Acer ROK MICROSOFT Win SVR 2008 64bit Std R2 5 Clt EN W/COA W/CD/DVD ACER 1-4CPU TC.34400.033
Microsoft Windows SBS Server Standard
Acer ROK MICROSOFT Win SBS 2008 64bit Std w/SP2 5 Clt EN W/COA W/CD/DVD ACER 1-4CPU TC.34400.041
Acer ROK MICROSOFT Win SBS 2008 64bit Prem w/SP2 5 Clt EN W/COA W/CD/DVD ACER 14CPU TC.34400.043
Acer ROK Win SBS 2011 Standard (64bit, 5Clt, EN) Kit TC.34400.136
Acer ROK Win SBS 2011 Premium (64bit,5Clt,EN) Kit TC.34400.138
Microsoft CAL's
Acer Windows Server 2008 CAL EN (5 Device) TC.34400.061
Acer Windows Server 2008 CAL EN (5 User) TC.34400.063
Acer Windows SBS 2008 Prem CAL EN (5 Device) TC.34400.065
Acer Windows SBS 2008 Prem CAL EN (5 User) TC.34400.066
Acer Windows SBS 2008 Std CAL EN (5 Device) TC.34400.067
Acer Windows SBS 2008 Std CAL EN (5 User) TC.34400.068
Acer Services
Acer Upgrade from 3 years Parts only to 3 years Parts/Labor/On-site Service (AT310/AR320/AT350) 146.AD314.001
Acer Upgrade from 3 years Parts only to 3 years Parts/Labor/On-site Service w/4hr response
(AT310/AR320/AT350) 146.AD316.004
Acer Upgrade from 3 years Parts only to 5 years Parts/Labor/On-site Service w/4hr response
(AT310/AR320/AT350) 146.AD317.004
23
Loading...
