Acer Aspire 1450, Ferrary 3000 Schematics POWER SEQUENCE

VIA Technologies, Inc. Application Note AN228A 1045 Mission Court. 8th. Fl., No. 533 Fremont, CA 94539 Chung-cheng Rd.,Hsin-tien

USA Taipei, Taiwan, R.O.C

: 1-510-683-3300

TEL

__________________________________________________________________________

Title

: 1-510-683-3301

FAX

: 886-2-218-5452

TEL

: 886-2-218-5453

FAX

The power sequence of VT8235

Released Date

Disclaimer Notice:

May 23, 2003

No license is granted, implied or otherwise, under any patent or patent rights of VIA

Technologies. VIA Technologies makes no warranties, implied or otherwise, in

regard to this document and to the products described in this document. The

information provided by this document is believed to be accurate and reliable to the

publication date of this document. However, VIA Technologies assumes no

responsibility for any errors in this document. Furthermore, VIA Technologies

assumes no responsibility for the use or misuse of the information in this document

and for any patent infringements that may arise from the use of this document. The

information and product specifications within this document are subject to change at

any time, without notice and without obligation to notify any person of such change.

Revision History

Document

Release

AP228 07/09/2002 Initial release MJ

AP228A 05/23/2003 Update item4,5,11,12,13 and 14 of table1. MJ

Date Revision Initials

Power On Sequence with default OFF

RTC power llllrhhhhhhhhhhhhhhhhhhhhhhh Suspend power lllllllrhhhhhhhhhhhhhhhhhhhh RSMRST# lllllllllrhhhhhhhhhhhhhhhhhh Core power llllllllllllllllrhhhhhhhhhhh PWRGD lllllllllllllllllllrhhhhhhhh PWRBTN# hhhhhhhhhhflrhhhhhhhhhhhhhhh SUS[A-C]

llllllllllllllrhhhhhhhhhhhhh

Power On Sequence with default ON

1 of 3

VIA Technologies, Inc. Application Note AN228A 1045 Mission Court. 8th. Fl., No. 533 Fremont, CA 94539 Chung-cheng Rd.,Hsin-tien

USA Taipei, Taiwan, R.O.C

: 1-510-683-3300

TEL

__________________________________________________________________________

: 1-510-683-3301

FAX

: 886-2-218-5452

TEL

: 886-2-218-5453

FAX

Power On Suspend sequence without RESET (S1)

Power hhhhhhhhhhhhhhhhhhhhhhhhhhhhhh POS command zznozzzzzzzzzzzzzzzzzzzzzzzzzz Stop Grant zzzznozzzzzzzzzzzzzzzzzzzzzzzz Resume event zzzzzzzzzzzzzzzznozzzzzzzzzzzz STPCLK# hhhfllllllllllllllllllllrhhhhh SLP# hhhhhhfllllllllllllllllrhhhhhh SUSTAT# hhhhhhhfllllllllllllllrhhhhhhh CPUSTP# hhhhhhhhfllllllllllrhhhhhhhhhh PCISTP# hhhhhhhhfllllllllllrhhhhhhhhhh SUSA hhhhhhhhhfllllllllrhhhhhhhhhhh SUS[B-C] hhhhhhhhhhhhhhhhhhhhhhhhhhhhhh

Power On Suspend sequence with CPU/PCI RESET

Power hhhhhhhhhhhhhhhhhhhhhhhhhhhh POS command zzznozzzzzzzzzzzzzzzzzzzzzzz Resume event zzzzzzzzzzzzzzzznozzzzzzzzzz STPCLK# hhhhhfllllllllllllrhhhhhhhhh SLP# hhhhhhflllllllllllrhhhhhhhhh SUSTAT# hhhhhhhhhhhhhhhhhhhhhhhhhhhh CPUSTP# hhhhhhhhfllllllllllrhhhhhhhh PCISTP# SUSA hhhhhhhhhfllllllllrhhhhhhhhh SUS[B-C] hhhhhhhhhhhhhhhhhhhhhhhhhhhh PCIRST# hhhhhhhhhhhhhhhhhhflllllllrh

hhhhhhhhfllllllllllrhhhhhhhh

Suspend to RAM sequence

PWRGD hhhhhhhhhhfllllllllllllrhhhh Power hhhhhhhhhhhhfllllllllrhhhhhh POS command zzznozzzzzzzzzzzzzzzzzzzzzzz Resume event zzzzzzzzzzzzzzzzzznozzzzzzzz STPCLK# hhhhhflllllrh”””””””””hhhhhh SLP# hhhhhhfllllrh”””””””””hhhhhh SUSTAT# hhhhhhhflllllllllllllllllrhh CPUSTP# hhhhhhhhfllll”””””””””llrhhh PCISTP# hhhhhhhhfllll”””””””””llrhhh SUS[A-B] hhhhhhhhhfllllllllllrhhhhhhh SUSC hhhhhhhhhhhhhhhhhhhhhhhhhhhh PCIRST# hhhhhhhhhhhfl”””””””””llllrh

2 of 3
