Important Safety Instructions
1. Please read these instructions thoroughly.
2. Please keep this guide for future use.
3. Please disconnect the device from the main power supply before cleaning. Do not use any liquids or aerosol
sprays to clean this device. Use a clean dampened cloth in stead.
4. To avoid damaging t he device, only use factory-approved accessories.
5. Protect the device against moisture.
6. In order to set up the device, first place it on a stable surface . Tipping it over or dropping can harm the
monitor and cause injuries. Please follow the setup instructions of the manufacturer while setting up your
monitor.
7. The ventilation openings are used for air circulation to protect the device against overheating.
8. When connect ing the device, obey the maximum connected load values of the main power supply.
9. T he wall socket must be equipped with a non-fused grounded conductor contact for electrical safety.
10. The power cable must be laid in such a way nobody can trip over it. Please do not place any objects on the
cable.
11. Follow all instructions and warning remarks that are printed on the device.
12. If the device will not be used for a long period of time, please disconnect it from the main power supply to
avoid power surge damage such as lightning.
13. Make sure no sharp objects or liquids enter the device via its air circulation openings. This could result in a
fire or an electric shock.
14. Never open the device casing yourself, there are no user serviceable parts inside . Only authorized technical
service personnel should open the casing of this device.
15. If any of the following conditions occur, the device must be disconnected from the main supply, and be
checked by a qualified service center:
a- Power cable or power plug are damaged;
b- Liquid has entered the device;
c- The device was exposed to moisture;
d- The device does not operate according t o the user’s guide, or you do not achieve any improvement with
the aid of this guide;
e- The device has been dropped and/or the casing is damaged;
f- The device shows obvious signs of a defect.
16. Use only approved original spare parts, or parts in accordance with the original parts, for repairs. The use of
incorrect/unauthorized spare parts may cause further damage.
17. Please contact your service center for any questions regarding service and repairs to guarantee the device’s
performance and reliability.
18. The power socket must be installed near the equipment to be easily accessible.
1
type video signal cable is required in order to meet the FCC emission limits and also
hat only the
Causing
lement sur le matériel
Place the monitor with its tube down on a stable
hear the spring lock
Federal Communications Commission
( FCC Statement )
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. T hese limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio frequency energy, and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following measures:
Any changes or modifications not expressly approved by the manufacturers may void t he user’s authority to
operate this equipment.
n Reorientate or relocate the receiving antenna;
n Increase the separation between the equipment and receiver;
n Connect the equipment with a power socket on a circuit different from that to which the receiver is
connected;
n Consult the dealer or an experienced radio/TV technician for help.
A shieldedto prevent interference to nearby radio and television reception. It is essential t
supplied power cord be used.
Use only shielded cables to connect I/O devices to this equipment.
Canadian DOC Notice
For Class B Computing Devices
This Class B digital apparatus meets all requirements of the Canadian InterferenceEquipment Regulations.
Cet appareil numérique de la classe B respecte toutes les exigences du Règ
brouilleur du Canada.
Connecting the Monitor and Swivel Base
1.
surface.
2. Align the four tabs of the swivel base with the
slots in the bottom of the monitor.
3. Insert the tabs into the slots of the monitor
4. Now slowly slide the swivel base toward the
front of the monitor till you
click into place.
Removing the Monitor and Swivel Base
If you need to remove the swivel base, push the spring lock and then pull the swivel base away from the monitor.
NOTE:Special attention should be paid to the control knobs and LED indicators on the front panel
when you place the monitor with its tube down. This will prevent damage to these control knobs and
LED indicators from excessive pressure.
2
1
Introduction
Congratulations on your purchase of this new high performance 17” Monitor. Using state-of-the-art
electronics, this monitor supports a 1280 x 1024 resolution. The on-screen display allows you to
customize the display settings to suit your individual taste.
Features
Ø 17-inch monitor with a large, viewable screen
for comfortable viewing.
Ø OSD user controls for easy and accurate
adjustment of the screen image.
Ø Energy Star compliant for reduced power
consumption.
Package Overview
Please make sure the following items are in the packing it was shipped in, and found in good
working condition:
Please contact your dealer or nearest service centers if any of the above items is missing or damaged.
n 17” Monitor
n Power Cord
n Tilt and Swivel Base
n This User’s manual
Installation
1. Connect the monitor signal cable
15-pin mini D-sub (VGA) on the back of
the computer.
2. Connect the power cord to the power
connector on the back panel of the monitor,
then plug the other end into an electrical
outlet that is easily accessible, and close to
the monitor.
3. First turn on the power of the computer,
then that of the monitor.
4. Adjust the tilt of the swivel base for
maximum viewing comfort.
The installation of your monitor is now
complete.
to the
3
Backward button (left arrow) moves
ntil
to increase or decrease the
icon if you want to exit the OSD
User Controls
1. Power Switch 2. Power LED Indicator
LED color Status
Turns the monitor on
3. Select Button 4. Backward and Forward Buttons
• Launches On -Screen Display
• Make sure the select functions
or adjustments
• Exit menus and On-Screen
Display
•
Green On
Amber
• Forward button (right arrow)
Sleep
backward through menu options or
decreases adjustment levels.
moves forward through menu
options or increases adjustment
levels.
OSD Function Description
1. Press the
2. To select a function, press the
the desired function is highlighted.
3. Press the
4. Use the
parameter level of the setting.
5. Press the
6. Select the
function, and then press the select the key once.
key to display the OSD menu.
and keys u
key to choose the function.
and keys
key to save the new setting.
4
OSD Icon Summary
Icon
Function Function Description
Brightness Adjusts display brightness
Contrast Adjusts display contrast
H. Size Increases and decreases screen width
H. Position Shifts display image right or left
V. Size Increase and decrease screen height
V. Position Shifts display image up or down
Pin. Balance Adjusts each side of Pincushion
Pincushion Adjusts concave and convex portion of pincushion effect
Parallelogram Adjusts the tilt of the display sides to the left or right
Trapezoid Adjusts the top and bottom display widths
Rotation Adjusts the rotation of the display clock or anti-clockwise
Color Temp. Adjusts the warmth of the displayed colors
Reset Resets to default values
Degauss Demagnetizes the screen to reduce color impurities
Exit Exits the OSD menu
Specification
Screen Size 17” CRT
Dot Pitch (mm) 0.27
Surface Non –glare
Viewable Image Area 16.14” (41.0 cm)
Input Signal Video Sync. RGB Analog 0.7Vp-p/75 Ohm
a. Separate H/V,TTL(+/-)
b. Composite H+V,TTL(+/-)
Scanning Frequency Horizontal (KHz) 30-70
Vertical (Hz) 50-160
Max. Resolution 1280 x 1024
Signal Cable 15-pin mini D-sub
Power Consumption Max. 75 W
Power Supply
Power Management Complies with EPA Energy Star ,VESA,
Display Modes Preset 6
By User 14
Operating Operating Temperature 0-40°C
Relative Humidity 10-90 %
Dimensions (L x W x H) 419 x 405 x 427 (mm)
Weight Unpacked 14.9 Kgs (32.85 lbs)
100 - 240VAC (W/I CE Mark) 50/60Hz
Nutek
5
Packed in box 16.8 Kgs (37.04 lbs)
6
Troubleshooting
Please refer to the following solutions for the failure symptoms that occur the most frequent. If the
symptom remains after trying these suggested solutions, please contact your local authorized service
center.
Problem: Power LED is not lit when monitor is powered on.
@ Check to make sure that the power cord is connected properly.
@ Make sure that the extension cord or the surge protector is turned on if the monitor is plugged
into a power extension cord or a surge protector.
Problem: No display appears on screen.
@ Make sure that the computer switch is in the “On” position.
@ Make sure that the video cable’s D-shaped connector is properly connected to the video
adapter port on the back of the PC.
@ Check to make sure that the brightness and contrast controls are not turned to their dimmest
position.
Problem: Display image is either flickering or unstable.
@ Make sure that the video cable’s D-shaped connector is connected properly to the video
adapter port on the back of the PC.
Problem: Image is bouncing or in a wave pattern.
@ Move any electrical devices that can cause interference away from the monitor.
(Note: Please refers to the FCC statement at the beginning of the manual for more details on
display interference.)
