PARTS LIST
LECTRIC MODULAR SKILLETS
E
MODELS: ACEMTS-30
ACEMTS-40
PART NUMBER 10002R4
ACCUTEMP PRODUCTS, INC.
8415 North Clinton Park Dr. · Fort Wayne, IN ·
46825 800 210-5907 Office · 260 493-0415 Fax
www.accutemp.net
1
2012-03-29
PARTS LIST, ELECTRIC MODULAR SKILLETS, MODELS ACEMTS-30, ACEMTS-40
FIGURE 1
PART NUMBER 10002R4 2 2012-03-29
PARTS LIST, ELECTRIC MODULAR SKILLETS, MODELS ACEMTS-30, ACEMTS-40
FIGURE 1
QUANTITY
ITEM PART NO. DESCRIPTION 30 40
1. 7386-2 Pan Cover with Vent 1
7387-2 Pan Cover with Vent 1
2. 7380-1 Pour Lip Strainer 1 1
3. 5877-1 Tilt Bracket 2 2
4. 3704-1 Bushing 2 2
5. 3209-1 Left Hand Door 1
3596-1 Left Hand Door 1
* 5-MC02 Magnetic Catch 2 2
6. 9-3443 Actuator Rod 18" 1 1
7. 9-3444 Actuator Rod Guide 1 1
8. 9-3345 Lock Collar 2 2
9. 9-3446 Spring 1 1
10. 4-M603-1 Limit Switch 1 1
11. 3838-1 Limit Switch Bracket 1 1
12. 3040-1 Control Panel Decal 1
3040-2 Control Panel Decal 1
13. 4-PL07-1 Pilot Light - Red 1 1
14. 4-TH47 Thermostat 1 1
15. 4-TB05 Bezel 1 1
** 16. 4-TK05 Dial, 1-10, Black 1 1
4737-1 Dial (C) 1 1
4736-1 Dial (F) 1 1
17. 9110-1 Power Switch 1 1
PART NUMBER 10002R4 3 2012-03-29
PARTS LIST, ELECTRIC MODULAR SKILLETS, MODELS ACEMTS-30, ACEMTS-40
QUANTITY
ITEM PART NO. DESCRIPTION 30 40
18. 9111-1 Up/Down Switch 1 1
19. 4-PL06-1 Pilot Light - Amber 1 1
20. 8068-1 Panel Sub Assembly 1 1
21. 4-70EU Ground Lug 1 1
22. 5-FS64-1 Bullet Leg 2 2
** 23. 4916-1 Contactor, 208-240V, 4-Pole 1 1
4-NG41 Contactor, 240/380/415/480V 1 1
24. 4-33TB Terminal Block Section,
(220/380V, 240/415V, 208-240V)
4-33TB Terminal Block Section,
(380, 415, 480V)
4-33ES End Section 1 1
25. 3684-1 Component Box Cover 1 1
26. 3571-1 Right Door 1
3597-1 Right Hand Door 1
27. 3201-1 Side Panel 2 2
28. S01X-12 Split Lock Washer, 1/2 2 2
29. M68P-1213-1 Socket Hd Screw, 1/2-13 UNC x 1 Lg. 2 2
30. 8-2029 Lock Pin 2 2
31. 8-2035L End Lock Plate 2 2
32. 5428-1 Stationary Disc 2 2
33. 5430-1 Core 2 2
4 4
3 3
34. 8-2026 Spring 2 2
35. 5429-1 Rotary Disc 2 2
36. 8-2021 End Stop Plate 2 2
PART NUMBER 10002R4 4 2012-03-29
PARTS LIST, ELECTRIC MODULAR SKILLETS, MODELS ACEMTS-30, ACEMTS-40
QUANTITY
ITEM PART NO. DESCRIPTION 30 40
37. 1-56S6 Cap Screws, 1/4 - 20 x 3/4, Stainless
Steel
38. 3699-2 Hinge Support Assembly 2 2
39. S01X-38 Split Lock Washer, 3/8 4 4
40. M68P-3816-1 Socket Hd. Screw, 3/8-16 UNC x 1 Lg. 4 4
41. 8078-1 Element Cover 1
8079-1 Element Cover 1
42. 8062-1 Yoke Assembly 1
8062-2 Yoke Assembly 1
43. S01X-38 Split Lock Washer, 3/8 4 4
44. M50S-3816-1 Hex Hd. Screw, 3/8 -16 UNC x 1 Lg. 2 2
45. M50S-3816-112 Hex Hd. Screw, 3/8-16 UNC x 1-1/2 Lg. 4 4
46. F05N-38 Flat Washer, 3/8 4 4
47. 4139-1 Vent Cover 1 1
8 8
48. 4355-1 Swivel Spacer 1 1
49. 5817-1 Arm 1 1
50. 9248-1 Knob 1 1
51. 4354-1 Swivel Base 1 1
52. F01S-14 Washer, Stainless Steel, 1/4" 1 1
53. 1-55S3 Hex Screw, 1/4 - 20 x 3/8 S.S. 1 1
54. M50S-3816-12 Hex Hd. Screw, 3/8-16 UNC x ½ Lg. 2 2
55. 8061-1 Terminal Enclosure Cover 1
8061-2 Terminal Enclosure Cover 1
56. 8054-1 Terminal Enclosure Box 1
8054-2 Terminal Enclosure Box 1
PART NUMBER 10002R4 5 2012-03-29
PARTS LIST,
ITEM PART NO. DESCRIPTION 30 40
57. 4874-1 High Limit Thermostat 2 3
58. 5952-1 Clamp 1 1
59. 1-69C0 Hex Nut, 5/16-18 UNC 64 80
60. 9063-1 Disc Springs 64 80
ELECTRIC MODULAR SKILLETS, MODELS ACEMTS-30, ACEMTS-40
QUANTITY
61. 9078-1 Flat Washer, 11/32 ID x 1-1/2 OD x 0.083
62. 3599-1 Element Block Spacer 32 40
63. 7545-208 Element Assembly, 208V, 6 kW 2
7545-220 Element Assembly, 220/380, 6 kW 2
7545-240 Element Assembly, 240/415V, 6 kW 2
7545-277 Element Assembly, 480 (277V), 6 kW 2
7547-208 Element Assembly, 208V, 6 kW 3
7547-220 Element Assembly, 220/380, 6 kW 3
7547-240 Element Assembly, 240/415V, 6 kW 3
7547-277 Element Assembly, 480 (277V), 6 kW 3
64. 8-1308 Leg Support, Flanged Foot 2 2
* NOT SHOWN.
32 40
Thick
** SELECT AS REQUIRED.
PART NUMBER 10002R4 6 2012-03-29
PARTS LIST, ELECTRIC MODULAR SKILLETS, MODELS ACEMTS-30, ACEMTS-40
FIGURE 2
PART NUMBER 10002R4 7 2012-03-29
PARTS LIST, ELECTRIC MODULAR SKILLETS, MODELS ACEMTS-30, ACEMTS-40
FIGURE 2
ITEM PART
NUMBER
1. 4511-1 Hose Assembly 2
2. 4512-1 Flow Control 2
3. 4513-1 Elbow 2
** 4. 4101-1 Motor 1/2 HP 115/208/230/1/60 1
4101-2 Motor 1/2 HP 380/480V, (Optional) 1
4101-3 Motor 1/2 HP, 220/50, (Optional) 1
** 5. 9119-1 Directional Valve, 110/120 VAC, 50/60 Hz 1
** 9119-2 Directional Valve, 220/240 VAC, 50/60 Hz 1
* ** 9118-1 Coil, 110/120 VAC, 50/60 Hz 2
* ** 9118-2 Coil, 220/240 VAC, 50/60 Hz 2
6. 9-3032 Pump complete with Integral Relief Valve 1
7. 4516-1 Manifold 1
DESCRIPTION QUANTITY
8. 9-3034 Breather 1
9. 9-3033 Tank, 1 Gallon 1
10. 9-3036 Pin complete with Retaining Rings 2
11. 1-R350 Retaining Ring, External 4
12. 4109-1 Street Elbow 2
13. 4112-1 Cylinder 1
9-3318 Cylinder Kit
14. 9-3035 Rod Clevis 1
* NOT SHOWN.
** SELECT AS REQUIRED.
PART NUMBER 10002R4 8 2012-03-29
