PARTS LIST
ELECTRIC COUNTER TILTING SKILLET
MODEL ACECTS-12
PART NUMBER 10000R4
ACCUTEMP PRODUCTS, INC.
8415 North Clinton Park Dr. · Fort Wayne, IN ·
46825 800 210-5907 Office · 260 493-0415 Fax ·
www.accutemp.net
1
2013-01-14
PARTS LIST, ELECTRIC TILTING SKILLET, MODEL ACECTS-12
FIGURE 1
PART NUMBER 10000R4 2 2013-01-14
PARTS LIST, ELECTRIC TILTING SKILLET, MODEL ACECTS-12
ITEM
* * 8. 4736-1 Dial (°F) 1
10. 4-TH47 Thermostat 1
11. 4-PL08 Pilot Light 1
PART NO. DESCRIPTION
1. 3059-1 Lift Off Cover 1
2. 9-3303 Strainer 1
3. 4172-1 Bottom Cover (9-1003) 1
4. 1-33CA Screw 10 - 32 x 1/2 4
5. 3052-2 Console Cover, Left Hand 1
6. 4874-1 High-Limit Thermostat 1
7. 3828-1 Thermostat Bulb Clamp 1
4737-1 Dial (°C) 1
9. 4-TB05 Bezel 1
QUANTITY
12. 9110-1 Power Switch 1
13. 1-33C4 Screw, 10 - 32 x 1/2 2
14. 2-KB01 Knob 2
15. 3965-1 Rest Bar 1
16. 4473-1 Thermostat Mounting Bracket 1
17. 3968-1 Bearing 2
18. 3413-1 Bearing 2
19. 4188-1 Earth I.D. Tag 1
20. 4-70EU Ground Lug 1
21. 3052-1 Console Cover, Right Hand 1
* * 22. 4-NG41 Contactor (208, 220, 240V) 2
4-NG41 Contactor
(380, 415, 220/380, 240/415, 480, 600V)
23. 9-3217 Component Mounting Plate 1
1
PART NUMBER 10000R4 3 2013-01-14
PARTS LIST, ELECTRIC TILTING SKILLET, MODEL ACECTS-12
ITEM PART NO. DESCRIPTION QUANTITY
** 24. 4-22TB Terminal Block Section 3
4-22TB Terminal Block Section (240/415, 220/380V) 4
25. 4-22ES End Section 1
26. 1-69C0 Hex Nut, 5/16 - 18 32
27. 9063-1 Bellville Washer 32
28. F01S-516 Flat Washer, 5/16 x 1" OD 16
29. 6973-1 Insulation 1
30. 3599-1 Spacer 16
** 31. 7-70580 Element Block, 9 kW, 208V 1
7-70582 Element Block, 9 kW, 220 (380)V 1
7-70581 Element Block, 9 kW, 240 (415)V 1
7-70583 Element Block, 9 kW, 480V 1
7-70585 Element Block, 9 kW, 347 (600)V 1
32. 1-7850 Acorn Nut 1
33. 3589-1 Tilt Handle 1
34. 3964-1 Locking Knob 1
35. 9320-1 Compression Spring 1
36. 9047-31 External Retaining Ring, 5/16 1
37. 3174-1 Operating Console Decal 1
38. 7155-1 Left Console Decal 1
* 39. 3931-1 Faucet Bracket (Optional) 1
* ** 40. 4-T251 Transformer, 380-220, 50/60 Hz, 100VA 1
4-T251 Transformer, 415-220, 50/60 Hz, 100VA 1
4-T255 Transformer, 480-240, 60 Hz, 100VA 1
4-T260 Transformer, 600-240, 60 Hz, 100VA 1
* ** 41. 9092-3 Fuse, 250V, 3A, (208 - 240V Units) 2
PART NUMBER 10000R4 4 2013-01-14
PARTS LIST, ELECTRIC TILTING SKILLET, MODEL ACECTS-12
ITEM PART NO. DESCRIPTION QUANTITY
* ** 41. 9092-3 Fuse, 250V, 3A, (220/380V and 240/415V
Units)
9001-2 Fuse, 600V, 1/2A, (380 - 600V Units) 2
* ** 42. 9068-1 Fuse Holder, (208 - 240V Units) 2
9068-1 Fuse Holder, (220/380V and 240/415V Units) 1
9002-1 Fuse Holder, 600V, (380 - 600V Units) 2
* NOT SHOWN.
** SELECT AS REQUIRED.
1
