Driver Version:

1.03

A Sierra Monitor Company

Driver Manual

(Supplement to the FieldServer Instruction Manual)

FS-8700-48 Fike Cheetah

APPLICABILITY & EFFECTIVITY

Effective for all systems manufactured after August 2008

Document Revision: 7

FS-8700-48 Fike Cheetah Manual Table of Contents

TABLE OF CONTENTS

1.

CHEETAH DEVICE DESCRIPTION................................................................................. 3

2.

DRIVER SCOPE OF SUPPLY ......................................................................................... 4

2.1.

Supplied by FieldServer Technologies for this driver.................................................. 4

2.2.

Provided by Supplier of 3rd Party Equipment .............................................................. 4

3.

HARDWARE CONNECTIONS......................................................................................... 5

3.1.

RS-232 Connection to Fike Cheetah Panel................................................................ 5

3.2.

RS-485 Connection to Fike Cheetah Panel................................................................ 6

3.3.

RS-485 Connection to Fike Cheetah XI Panel ........................................................... 7

3.4.

RS-232 Connection to Fike Cheetah XI Panel ........................................................... 8

3.4.1. Connection Notes: .................................................................................................. 8

4.

CONFIGURING THE FIELDSERVER AS A CHEETAH DEVICE CLIENT....................... 9

4.1.

Data Arrays................................................................................................................ 9

4.2.

Client Side Connection Descriptors...........................................................................10

4.3.

Client Side Node Descriptors ....................................................................................11

4.4.

Client Side Map Descriptors......................................................................................11

4.4.1. FieldServer Specific Map Descriptor Parameters...................................................11

4.4.2. Driver Specific Map Descriptor Parameters ...........................................................12

4.5.

Map Descriptor Examples .........................................................................................13

4.5.1. Map Descriptor Example 1. (All Zones Data) .........................................................15

4.5.2. Map Descriptor Example 2.(Specific Zone Data)....................................................16

4.5.3. Map Descriptor Example 3 – Zone Status as a numeric value ...............................17

4.5.4. Map Descriptor Example 4 – All Devices ...............................................................18

4.5.5. Map Descriptor Example 5 (Specific Device) .........................................................19

4.5.6. Map Descriptor Example 6 - Device States as a Numeric Value............................20

4.5.7. Map Descriptor Example 7 – Panel Data ...............................................................20

4.5.8. Map Descriptor Example 8 – History Data (All Devices).........................................21

4.5.9. Map Descriptor Example 9 – Full History Event Record – Specific Device.............22

4.5.10. Map Descriptor Example 10 – Full History Event Record – Any Device..............22

4.5.11. Map Descriptor Example 11 – Alarm Ack............................................................23

5.

CONFIGURING THE FIELDSERVER AS A CHEETAH DEVICE SERVER....................24

APPENDIX A. DRIVER NOTES.............................................................................................25

Appendix A.1. Driver Scope ................................................................................................25

Appendix A.2. Map Descriptor Specific Errors.....................................................................25

Appendix A.3. Multiple Cheetah Panels ..............................................................................25

Appendix A.4. How History Events are Stored ....................................................................25

Appendix A.5. Storing Panel Data.......................................................................................32

Appendix A.6. Acknowledging Alarms.................................................................................33

Appendix A.7. Panel Firmware Versions .............................................................................33

APPENDIX B. DRIVER ERROR MESSAGES .......................................................................34

Appendix B.1. Driver Stats ..................................................................................................36

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com

Tel: [phone] Fax: [phone] Toll Free: 888-509-1970 email: [e-mail]

FS-8700-48 Fike Cheetah Manual Page 3 of 36

1. Cheetah Device Description

The Cheetah Protocol driver allows the FieldServer to transfer data to and from devices over
either RS-232 or RS-485 using the Cheetah device protocol. The Cheetah system provides fire
detection/monitoring equipment and is manufactured by the Fike Corporation (www.fike.com).
The driver is also able to be used with the newer Fike XI panel.

The FieldServer can emulate either a Server or Client but it should be noted that it can only
process unsolicited messages from the Cheetah devices. Thus, it does not provide an active
Client driver. It is best to consider this driver as a consumer only driver with the data being
produced by a Cheetah controller.

The driver supports messages sent from the Cybercat panel. Specifically, the driver supports
message 1.02 which reports panel, zone and device states.

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com

Tel: [phone] Fax: [phone] Toll Free: 888-509-1970 email: [e-mail]

FS-8700-48 Fike Cheetah Manual Page 4 of 36

2. Driver Scope of Supply

2.1. Supplied by FieldServer Technologies for this driver

FieldServer Technologies
PART #

Flat 6 way cable (7 foot) for RJ11 connection
FS-8915-10 UTP cable (7 foot) for RS-232 use
RJ45 to DB25F connector adapter
RJ11 to DB25M connection adapter
FS-8700-48 Driver Manual.

Description

2.2. Provided by Supplier of 3rd Party Equipment

PART # DESCRIPTION

Fike Cheetah panel and power supply.
RS-485 cable, if required.
Longer UTP cable, if required.

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com

Tel: [phone] Fax: [phone] Toll Free: 888-509-1970 email: [e-mail]

FS-8700-48 Fike Cheetah Manual Page 5 of 36

3. Hardware Connections1

The FieldServer is connected to the Cheetah panel's Peripheral Port (see below).

This port is either a serial port (identified as jack 4) or RS-485 port (use the terminals adjacent
to jack 4).

Configure the Cheetah Panel according to manufacturer’s instructions

3.1. RS-232 Connection to Fike Cheetah Panel

1

T

he connection diagrams are for Non Cybercat Panels. Connection info was not available at the time

this document was last updated.

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com

Tel: [phone] Fax: [phone] Toll Free: 888-509-1970 email: [e-mail]

FS-8700-48 Fike Cheetah Manual Page 6 of 36

3.2. RS-485 Connection to Fike Cheetah Panel

Sy s

Ac t

Ru n

Pw r

Co m

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com

Tel: [phone] Fax: [phone] Toll Free: 888-509-1970 email: [e-mail]

FS-8700-48 Fike Cheetah Manual Page 7 of 36

3.3. RS-485 Connection to Fike Cheetah XI Panel

-

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com

Tel: [phone] Fax: [phone] Toll Free: 888-509-1970 email: [e-mail]

FS-8700-48 Fike Cheetah Manual Page 8 of 36

08

3.4. RS-232 Connection to Fike Cheetah XI Panel

CHEETAH XI

PANEL

P5

Terminal

Block

FS-8917-16

RJ45 Connector

EIA232

RJ45 to

Connector

RJ45

FieldServer

Tx
Rx

Gnd

Pinouts

P5

Cheetah XI

Rx

8
1
4

4

Tx

2

Gnd

1

(408)-262-2299

FIELDSERVER

RS-232 to CHEETAH XI PANE L

CONNECTION DIAGRAM

BASE NAME:
FILE NAME: FS-8700-48.VSD

DATE: 4/29/
BY: MC

3.4.1. Connection Notes:

• Communication on the RS-232 port is untested.

• We recommend that a RS-232 optical isolator is used on the connection between the

FieldServer and the Cheetah XI panel to isolate any potential ground differential
issues.

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com

Tel: [phone] Fax: [phone] Toll Free: 888-509-1970 email: [e-mail]

FS-8700-48 Fike Cheetah Manual Page 9 of 36

4. Configuring the FieldServer as a Cheetah Device Client

For a detailed discussion on FieldServer configuration, please refer to the FieldServer
configuration manual. The information that follows describes how to expand upon the factory
defaults provided in the configuration files included with the FieldServer. (See “.csv” sample
files provided with the FieldServer)

This section documents and describes the parameters necessary for configuring the FieldServer
to communicate with a Cheetah Device Server.

The configuration file tells the FieldServer about its interfaces, and the routing of data required.
In order to enable the FieldServer for Cheetah Device communications, the driver independent
FieldServer buffers need to be declared in the “Data Arrays” section, the destination device
addresses need to be declared in the “Client Side Nodes” section, and the data required from
the Servers needs to be mapped in the “Client Side Map Descriptors” section. Details on how to
do this can be found below.

Note that in the tables, * indicates an optional parameter, with the bold legal value being the
default.

4.1. Data Arrays

Section Title

Data_Arrays

Column Title Function Legal Values

Data_Array_Name

Provide name for Data
Array

Up to 15 alphanumeric characters

FLOAT, BIT, UInt16, SInt16,
Packed_Bit, Byte, Packed_Byte,
Swapped_Byte

The Cheetah driver always sets Data
Array elements to a zero or one. Thus,

Data_Format

Provide data format. Each
Data Array can only take
on one format.

the use of bit arrays is suggested but is
not mandatory.

Data_Array_Length

Number of Data Objects.
Must be larger than the
data storage area required
for the data being placed in
this array.

1-10,000. If you use the 'All' keyword
when setting the parameter
Cheet_Zone/Device then the minimum
length is 128.

Example

// Data Arrays

Data_Arrays
Data_Array_Name, Data_Format, Data_Array_Length
DA_AI_01, UInt16, 200
DA_AO_01, UInt16, 200
DA_DI_01, Bit, 200
DA_DO_01, Bit, 200

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com

Tel: [phone] Fax: [phone] Toll Free: 888-509-1970 email: [e-mail]

FS-8700-48 Fike Cheetah Manual Page 10 of 36

4.2. Client Side Connection Descriptors

Section Title

Connections

Column Title Function Legal Values

Specify which port the

Port

Baud* Specify baud rate 9600
Parity* Specify parity
Data_Bits*

Stop_Bits*

Protocol

Handshaking*

Poll Delay*

Example

// Client Side Connections

Connections
Port, Baud, Protocol, Poll_Delay
P8, 9600, Cheetah, 0.100s

device is connected to
the FieldServer

Specify data bits

Specify stop bits

Specify protocol used

Specify hardware
handshaking
Time between internal
polls

P1-P8, R1-R22

None, (Vendor limitation)
8 (Vendor limitation)

1 (Vendor limitation)

Cheetah (makes the port the exclusive domain
of Cheetah devices.) This keyword is not
required when specifying the port.

None

0-32000 seconds, 1 second

2

Not all ports shown are necessarily supported by the hardware. Consult the appropriate Instruction

manual for details of the ports available on specific hardware.

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com

Tel: [phone] Fax: [phone] Toll Free: 888-509-1970 email: [e-mail]

FS-8700-48 Fike Cheetah Manual Page 11 of 36

4.3. Client Side Node Descriptors

Section Title

Nodes

Column Title Function Legal Values

Node_Name Provide name for node

Node_ID

Modbus station address of
physical Server node

Protocol Specify protocol used Cheetah

Specify which port the device

Port

is connected to the
FieldServer
This parameter tells the
driver what type of panel you

PLC_TYPE

are connecting to. If not
specified, the driver expects
that you are connecting to a
legacy Cheetah panel.

Example

// Client Side Nodes

Nodes
Node_Name, Protocol, Port
Cheet_Master1, Cheetah, P8

Up to 32 alphanumeric
characters
This parameter is not
required for Cheetah devices.

P1-P8, R1-R23

'Cybercat' , 'Cheetah'

4.4. Client Side Map Descriptors

4.4.1. FieldServer Specific Map Descriptor Parameters

Column Title Function Legal Values

Map_Descriptor_Name Name of this Map Descriptor

Name of Data Array where

Data_Array_Name

data is to be stored in the
FieldServer

Data_Array_Location Starting location in Data Array

Function

Function of Client Map
Descriptor

Node_Name Provide name for node

3

Not all ports shown are necessarily supported by the hardware. Consult the appropriate Instruction

manual for details of the ports available on specific hardware.

Up to 32 alphanumeric
characters
One of the Data Array names
from “Data Array” section
above
0 to maximum specified in
“Data Array” section above
RDBC, WRBC, WRBX,
PASSIVE

Only the keyword passive may
be used for Cheetah devices.
Up to 32 alphanumeric
characters

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com

Tel: [phone] Fax: [phone] Toll Free: 888-509-1970 email: [e-mail]

FS-8700-48 Fike Cheetah Manual Page 12 of 36

4.4.2. Driver Specific Map Descriptor Parameters

Column Title Function Legal Values

You can use a Map Descriptor to store
data for one, all or no zones. If you require
data from multiple zones then you must
define multiple Map Descriptors each
specifying the zone of interest. When
specifying “All”, the data for zone 0 is
stored in the first element of the Data Array

Cheet_Zone

Cheet_Device

Cheet_Loop

pointed to by the Data_Array_Name &
Data_Array_Location and the data for
zone 127 in the 128th element of the Data
Array.
Depending on the firmware version of the
Cheetah panel some or all of the following
states are available. To have the driver
store data for multiple states you must
define multiple Map Descriptors - One per
state of interest.
Abort, Trouble, Supervisory, Zone Disable,
Pre-Alarm, Alarm, Pre-Discharge, Release,
Process.
Define one or more Map Descriptors to
store data from the 0-127 addressable
devices. Each Map Descriptor must have
the Cheet_Zone set to None.

Devices belong to one of 4 possible loops.
Thus when you set Cheet_Device to All or
to a specific device number you must also
set the Cheet_Loop number to a value
from 1 to 4.

If you set Cheet_Device to All then 128
states are stored. The data for device 0 is
stored in the first element of the Data Array
pointed to by the Data_Array_Name &
Data_Array_Location and the data for
device 127 in the 128th element of the
Data Array.

Specify this parameter when the value of
Cheet_Device is not equal to none.

None, All, 0-127
Must be None when

Cheet_Device is not equal
to None.

None, All, 0-127

Must be None when
Cheet_Zone is not equal
to None.

None, 1-3
Must be None when
Cheet_Zone is not equal
to None.

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com

Tel: [phone] Fax: [phone] Toll Free: 888-509-1970 email: [e-mail]

FS-8700-48 Fike Cheetah Manual Page 13 of 36

Column Title Function Legal Values

Abort, Trouble,
Supervisory, Disable, Pre­Alarm, Alarm, Pre-Dis,
Release, Process, Any,
All, History, Panel

Only Alarm and Trouble

Cheet_DT

Data Type. If you require multiple states to
be stored in one/more Data Arrays then
you must make multiple Map Descriptors.

are valid when storing
device data
(Cheet_Device not equal
to None).
Port Response

These additional keywords
are valid but are used for
testing the driver and must
not be used in a

Cheet_Func Use for active Map Descriptors only

configuration to be used
for communication with a
Cheetah panel.

Iscan_g_update
Panel Status
History Event
Port Supervision

4.5. Map Descriptor Examples

The driver processes messages from the panel that relay the panel’s current status as well
as new history events. These messages contain composite data and the contents cannot
simply be stored in a Data Array and then be read by some downstream device.

The Map Descriptors tell the driver how to store portions of this composite data from the
following categories. At least one Map Descriptor is required for each category.

1. Zone Status
The driver can store the state (trouble, alarm, pre-alarm...) of each zone in a separate array
as a 1 or zero state. See examples 1 & 2. The driver can also store a number in a separate
Data Array to indicate normal or abnormal state of each zone. (The value of the number
indicates the states.) See example 3.

2. Device Status
The driver can store the state (trouble, alarm, pre-alarm...) of each device in a separate
array as a bit state (1 or 0) . See examples 4 & 5
The driver can also store a number in a separate Data Array to indicate normal or abnormal
state of each device. See example 6

3. Panel Information

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com

Tel: [phone] Fax: [phone] Toll Free: 888-509-1970 email: [e-mail]

FS-8700-48 Fike Cheetah Manual Page 14 of 36

Information over and above the device and zone states is available such as the number of
events in alarm state, whether the alarm is silent or on … This data is stored in consecutive
array locations. Appendix A.5 of this manual maps the layout of this data. See example 7

4. History Events
Every time the panel sees an event it will place in its own history buffer it transmits a
message. This driver processes the message and stores the event code (most recent) in a
location based on the source device’s address. This gives an array of the most recent
events for all devices. See example 8

The driver can also store the entire history event record in a Data Array. Appendix A.4 maps
the layout of this data. This record includes data such as the time and date. See examples
9 & 10

5. Acknowledging Alarms
There are significant limitations on the driver’s ability to send alarm acknowledgements to
the panel. Refer to Appendix A.6 this manual for more information. See example 11 for a
Map Descriptor which can be used to get the driver to acknowledge alarms.

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com

Tel: [phone] Fax: [phone] Toll Free: 888-509-1970 email: [e-mail]

Starting at

element zero.

The data is stored in

Data Array DA_3.

Release state data is

stored by the first Map

Descriptor and Alarm

state data is stored by

the second Map

Descriptor.

Data for All Zones

is stored (128 data

elements)

Tel: [phone] Fax: [phone] Toll Free: 888-509-1970 email: [e-mail]

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com

4.5.1. Map Descriptor Example 1. (All Zones Data)

You can give each Map Descriptor a

unique name or as in this example,

leave them with a generic name

FS-8700-48 Fike Cheetah Manual Page 15 of 36

In this example the driver will use this Map Descriptor to store zone data sent by the panel. The message sent by the panel is

dependent on the panel’s firmware version. This Map Descriptor will use 128 consecutive array locations to store ‘Release’ state

data for the zones. Zone 0’s data will be stored at the first location and Zone 127’s state will be stored at the 128th location. The

// Client Side Map Descriptors

Map Descriptors

Map_Descriptor_Name, Cheet_Zone, Cheet_DT, Data_Array_Name, Data_Array_Offset, Function, Node_Name

Zone_Alarms, All, Release, DA_3, 0, Passive, Node_A

base location in the array is determined by the Data Array offset,

Starting at

element zero.

The data is stored

into a Data Array

called DA_1 for

zone 1 and DA_2

for zone 2...

Release state data is

stored.

Data for the specified

zone is stored.

Tel: [phone] Fax: [phone] Toll Free: 888-509-1970 email: [e-mail]

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com

4.5.2. Map Descriptor Example 2.(Specific Zone Data)

You can allocate each

Map Descriptor a unique

name or as in this

example, leave them

with a generic name

describing the action

they perform. It is best to

use unique names as

some driver error

messages report the

offending Map

Descriptor’s name.

FS-8700-48 Fike Cheetah Manual Page 16 of 36

In this example the Map Descriptors store data for one zone each. This variation is offered to allow you manipulate the arrangement

of data in Data Arrays if you are constrained by some downstream device.

// Client Side Map Descriptors

Map Descriptors

Map_Descriptor_Name, Cheet_Zone Cheet_DT, Data_Array_Name, Data_Array_Offset, Function, Node_Name

Zone_Alarms1, 1, Release, DA_1, 0, Passive, Node_A

Zone_Alarms2, 2, Release, DA_2, 0, Passive, Node_A

The driver writes a number into the array location for each device.

The value of number indicates the status of the zone. The value

is based on which bits in the binary number are set.

Bit 0: Abort State

Bit 1: Trouble State

Bit 2: Supervisory State

Bit 3: Zone is disabled

Bit 4: Pre Alarm State

Bit 5: Alarm State

Bit 6: Pre-Discharge State

Bit 7: Release State

This data type tells the driver that this Map Descriptor must be

used to store zone status data of any type.

Bit 8: Process State Example : Value = 32 indicates an alarm state

Example : Value = 96 indicates an alarm & pre-discharge state

Tel: [phone] Fax: [phone] Toll Free: 888-509-1970 email: [e-mail]

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com

4.5.3. Map Descriptor Example 3 – Zone Status as a numeric value

For the driver to effectively report the

status as a number the Data Array

format must be suitable for storing the

number. You can use UINT16, UINT32

FS-8700-48 Fike Cheetah Manual Page 17 of 36

zones. It will store this information by storing a number in the Data Array. The number can be inspected to determine which states

In this example, the driver stores zone data for any zone. It will store data for all possible states that the panel reports for each of the

are active.

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, Cheet_Device, Cheet_DT, Cheet_Zone

Device1_L1_Alm, DA_DI1, 20, Passive, Node_A, None Any, All

and FLOAT formats.

Descriptors are

required for each loop.

Additional Map

The Data Type is different

for these Map Descriptors

so that the driver knows

which Map Descriptor to

use for each device state’s

storage. If the device state

doesn’t match one of

these data types then the

message will be ignored.

Since we are storing

device data, the

Cheet_Zone must

be set to None.

Tel: [phone] Fax: [phone] Toll Free: 888-509-1970 email: [e-mail]

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com

4.5.4. Map Descriptor Example 4 – All Devices

is used for each

state. Another

strategy could

have been to

use the same

A different array

were also interested in monitoring the pre-alarm state for these devices then an additional Map Descriptor is required because if your

FS-8700-48 Fike Cheetah Manual Page 18 of 36

configuration only contains the two Map Descriptor’s shown below the driver will ignore reports for other possible device states.

In this example two Map Descriptors are provided to store the Alarm and Trouble States of all devices on loop 1. If, for example, you

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_name, Cheet_Zone, Cheet_DT, Cheet_Device, Cheet_Loop

Device_L1_Alm, DA_DI1, 0, Passive, Node_A, None, Alarm, All, 1

Device_L1_Trbl, DA_DI2, 0, Passive, Node_A, None, Trouble, All, 1

array but vary

The Device

The device

belongs to loop1

The alarm state is

number is 20.

We are storing device

data so the

Cheet_Zone must be

set to None.

Even though the driver is node

independent, Node_A ties this Map

Descriptor to a Node Descriptor which thus

connects the Map Descriptor to a protocol

and to a port.

They are passive

because this driver

is a data consumer.

Each Map Descriptor in this example

reads data for one device only. Thus

each Map Descriptor must point to a

different Data Array or as is the case in

this example, to a different location in

Tel: [phone] Fax: [phone] Toll Free: 888-509-1970 email: [e-mail]

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com

4.5.5. Map Descriptor Example 5 (Specific Device)

You can give each Map

Descriptor a unique name or

as in this example, leave

them with a generic name

describing the action they

FS-8700-48 Fike Cheetah Manual Page 19 of 36

This example shows how you can define a Map Descriptor for the storage of the state of one specific device. (Device 20 in this

example)

// Server side Map Descriptors

Map Descriptors

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_name, Cheet_Zone, Cheet_DT, Cheet_Device, Cheet_Loop

Device20_L1_Alm, DA_DI1, 20, Passive, Node_A, None, Alarm, 20, 1

perform.

The Any keyword tells the driver to store the device state as a

number

The value of the number indicates the device state. The number is a

binary number and its value is determined by which bits are set.

Bit 0: Alarm

Bit 1: Pre-Alarm

Bit 2: Trouble Example: Value 4 indicates the device is in a trouble state.

The Panel keyword

tells the driver to store

the panel data using

this Map Descriptor.

Tel: [phone] Fax: [phone] Toll Free: 888-509-1970 email: [e-mail]

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com

4.5.6. Map Descriptor Example 6 - Device States as a Numeric Value

The array’s format must be suitable for

storing the state number which can

range from 0-15.

Thus BYTE, UINT16, UINT32 and

FLOAT are suitable formats for the

Data Array.

FS-8700-48 Fike Cheetah Manual Page 20 of 36

state stored at the 64th location of the Data Array specified.

In this example all the devices of loop 1 have the state storage defined by this Map Descriptor. Device 63, for example would have its

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, Cheet_Zone, Cheet_DT, Cheet_Device, Cheet_Loop

Device1_L1_Any, DA_DI1, 0, Passive, Node_A, None, Any, All, 1

4.5.7. Map Descriptor Example 7 – Panel Data

This example provides a Map Descriptor which tells the driver where to store the non-zone/device specific data obtained from a

panel. Appendix A.5 of the manual maps how the data is stored. Ensure that the Data Array is long enough to store all the data.

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_name, Cheet_Zone, Cheet_Device, Cheet_DT

Panel_Data, DA_PANEL, 0, Passive, Node_A, None, None, Panel

One Map Descriptor is

required per loop.

This is how you tell the

driver to use this Map

Descriptor to store history

data as opposed to device

status data (see examples

4-6)

History events relate to

devices and thus the zone

must be set to None.

Tel: [phone] Fax: [phone] Toll Free: 888-509-1970 email: [e-mail]

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com

4.5.8. Map Descriptor Example 8 – History Data (All Devices)

FS-8700-48 Fike Cheetah Manual Page 21 of 36

In this example, 4 Map Descriptors process all history events on all four loops. One Data Array is used and loop #2’s data is stored at

an offset location of 240 (max number of devices per loop) in the Data Array. The Device is set to ALL to tell the driver to process all

devices on the loop using this Map Descriptor. If a history event for device 100 on loop 3 is received then the driver will store the

event code at location 480(=base offset for loop 3)+100 (=device address). The event code will be stored as a number and the

meaning of the number may be obtained by reading Appendix A.4

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, Cheet_Zone, Cheet_DT, Cheet_Device, Cheet_Loop

Device1_L1_Hist, DA_HIST, 0, Passive, Node_A, None, History, All, 1

Device1_L2_Hist, DA_HIST, 240, Passive, Node_A, None, History, All, 2

Device1_L3_Hist, DA_HIST, 480, Passive, Node_A, None, History, All, 3

Device1_L4_Hist, DA_HIST, 720, Passive, Node_A, None, History, All, 4

Event history records are stored in

this Data Array. The contents of the

Data Array locations are described in

section 6.6

Each event record uses at least 65

consecutive elements of the array so

the choice of an offset must be made

carefully.

Differs from Example 9 in that

the device is specified as ALL -

now the driver stores the event

for any device at the same

location.

One device is processed using this

Map Descriptor. Thus only events

relating to device 20 of loop 1 will be

stored using this Map Descriptor.

Events relating to other devices will

be discarded unless additional Map

Descriptors are defined.

Tel: [phone] Fax: [phone] Toll Free: 888-509-1970 email: [e-mail]

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com

4.5.9. Map Descriptor Example 9 – Full History Event Record – Specific Device

FS-8700-48 Fike Cheetah Manual Page 22 of 36

Full History Event records contain composite data which require at least 65 consecutive Data Array locations for storage. If the

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, Cheet_Zone, Cheet_DT, Cheet_Device, Cheet_Loop, DA_Byte_Name

Device1_L1_Hist, DA_HIST, 20, Passive, Node_A, None, History, 20, 1, DA_HIST_EVENT

Data_Array_offset is not carefully specified the storage areas will overlap.

Event codes are stored in

this Data Array.

4.5.10. Map Descriptor Example 10 – Full History Event Record – Any Device

Only the most recent history event is stored using this Map Descriptor. The full record is stored but is overwritten when a new event

is received irrespective of the event’s device address.

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, Cheet_Zone, Cheet_DT, Cheet_Device, Cheet_Loop, DA_Byte_Name

Device1_L1_Hist, DA_HIST, 0, Passive, Node_A, None, History, ALL, 1, DA_HIST_EVENT

This tells the driver

that this Map

Descriptor is to be

used for

acknowledging

alarms.

The Map Descriptor

must always be

passive. This is

because this Map

Descriptor is used to

respond to the port

supervision query.

Tel: [phone] Fax: [phone] Toll Free: 888-509-1970 email: [e-mail]

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com

4.5.11. Map Descriptor Example 11 – Alarm Ack

Only one element of this

Data Array is used.

The value determines how

the Cheetah panel will be

affected. If bit 0 is set then the panel

FS-8700-48 Fike Cheetah Manual Page 23 of 36

This example illustrates a Map Descriptor which can be used to acknowledge / silence or reset the panel. Read Appendix A.6 to

understand the limitations of this functionality. The value of the array element at offset zero in the array named DA_ACK is used to

send a signal to the Cheetah panel.

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function Node_Name, Cheet_Func

Ack_Mapdesc, DA_ACK, 0, Passive, Node_A, Port Response

will be reset. If bit 1 is set then the panel

will be silenced.

If bit 2 is set then the panel

will be acknowledged.

FS-8700-48 Fike Cheetah Manual Page 24 of 36

5. Configuring the FieldServer as a Cheetah Device Server

This driver cannot act as a data Server, i.e. it cannot write data to the Cheetah controller or
devices. Thus it cannot be used to acknowledge alarms or reset states.

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com

Tel: [phone] Fax: [phone] Toll Free: 888-509-1970 email: [e-mail]

FS-8700-48 Fike Cheetah Manual Page 25 of 36

Appendix A. Driver Notes

Appendix A.1. Driver Scope

This driver has implemented cheetah command #6.0. These messages are produced by a
Cheetah device controller and are consumed by this driver. The driver has no control on the
frequency of the messages and thus cannot guarantee fresh data. In addition the protocol
has no method for acknowledging messages so that in the event of this driver having to
discard a corrupt message, the message producer does not know and will not re-send.

Appendix A.2. Map Descriptor Specific Errors

Some errors produced by the driver are Map Descriptor specific. They can only be seen
when using the Ruidebug program and looking at the Map Descriptor debugging screens.
For more information on how to do this please refer to the FieldServer Utilities manual.

Appendix A.3. Multiple Cheetah Panels

Some of the broadcast messages produced by the Cheetah panel are node-less. This
means that these messages do not identify the node of origin. Unfortunately, the message
this driver uses to determine zone and device alarms is a node-less message. This limits
the number of Cheetah panels per port to one. (If there were more than one the driver would
not be able to determine the node of origin.)

Appendix A.4. How History Events are Stored

History events records are send by the panel each time an event occurs. The driver can
parse these messages and store the data in either of two ways.

• The first method stores the event code at an array location that is based on the device
address and loop number. See Map Descriptor example 8

• The second method stores a large number of additional event data such as the time &
date in a secondary Data Array. See Map Descriptor example 9

The array locations of the additional data are indicated below

Location Contents Notes

0 Month
1 Day of Month
2 Year less 1900
3 Day of Week (1..7)
4 Hour (0-12)
5 AM-PM (A,P)
6 Minute
7 Second
8 Event Data (0-65535)
9 Custom Message 20 bytes
29 Fire Point
30 Zero Point
31 Device Type
32 Device Function
33 Zones device belongs to 32 bytes. Bit 0 -> Zone1 …. Bit 17->zone 18 …
65 Current History Counter (0-65535)

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com

Tel: [phone] Fax: [phone] Toll Free: 888-509-1970 email: [e-mail]

FS-8700-48 Fike Cheetah Manual Page 26 of 36

addr device trouble: communication to device has errors (parity checksum

addr device trouble: correct kind of device has been restored to this

config menu

The event codes are defined in the table below.

# Description Notes

0 no record ­1 aux power unconfig auxiliary power module present but unconfigured.
2 aux power corrected auxiliary power module replaced after being missing.
3 aux power missing auxiliary power module not present but configured.
4 ac1 power restored ac for main board input restored.
5 ac1 power trouble ac for main board input missing/brownout.
6 ac2 power restored ac for power module input restored.
7 ac2 power trouble ac for power module input missing/brownout.
8 batttery1 restored battery for main board input restored.
9 batttery1 trouble battery for main board input missing.
10 battery2 restored battery for power module input restored.
11 battery2 trouble battery for power module input missing.
12 aud1 trb restored audible #1 restored.
13 aud1 open trouble audible #1 open circuit.
14 aud1 short trouble audible #1 short circuit.
15 aud2 trb restored audible #2 restored.
16 aud2 open trouble audible #2 open circuit.
17 aud2 short trouble audible #2 short circuit.
18 gnd fault restored ground fault trouble restored to normal.
19 gnd fault present ground fault present.
20 device present addr device trouble: device returns canceling missing trouble
21 device missing addr device trouble: device was polled but not found
22 commun restored addr device trouble: communication to device has returned to normal

23 bad communication

24 restored multiple addr device trouble: multiple devices trouble has cleared
25 multiple devices addr device trouble: multiple devices detected at this address

26 restored device kind

27 wrong device kind addr device trouble: wrong kind of devices has been found
28 contaminated device addr device trouble: analog device is contaminated
29 loop module restored loop mod missing trouble has cleared
30 loop module missing loop module not in place but there are configured devices on the loops.

31

accessed

32 factory initialized history stored when a factory initialization has been invoked

33 uart failure

34 uart restored history stored when preceding trouble has cleared.
35 system reset complete reset including power-down of loops for ten seconds.
36 trouble restored trouble function input restore.
37 trouble input active trouble function input present.
38 process restored process control function input restored.
39 process input active process control function input present.
40 supervisory restored supervisory function input restore.
41 supervisory active supervisory function input present.
42 remote reset release remote reset function input released.
43 trouble unsilence all troubles unsilenced for all zones.

etc.)

address

trouble stored when the configuration menu has been entered

history stored when the uart has been corrupted by esd and then re­initialized.

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com

Tel: [phone] Fax: [phone] Toll Free: 888-509-1970 email: [e-mail]

FS-8700-48 Fike Cheetah Manual Page 27 of 36

alarm1 threshold. analog data appended to this

alarm1 threshold. analog data appended to this

og data appended to this

alarm2 threshold. analog data appended to this

device has reached the alarm threshold. analog data appended to this

ed when an acknowledge command is recorded from cheetah

net member#a

# Description Notes

44 trouble silence all troubles silenced for all zones.

supervisory

45

unsilence
46 supervisory silence all supervisory silenced for all zones.
47 power-up reset reset record when panel is powered up
48 external reset reset record when external reset switch pressed or esd hit causes reset
49 remote reset active remote reset switch activated
50 drill input restored drill function input restore.
51 drill input active drill function input present.
52 alarm unsilence all alarm states unsilenced for all zones.
53 alarm silence all alarm states silenced for all zones.
54 abort pressed abort function input present.
55 abort released abort function input restored.

56 palarm1 restore-----

57 palarm1 active -----

58 palarm2 restore-----

59 palarm2 active -----

all supervisory unsilenced for all zones.

device restored below pre­message

device above pre­message

device restored below pre-alarm2 threshold. anal
message

device above pre­message

60 alarm active -----

61 manual alarm manual pull function input present.

manual pre­62

discharge
63 manual release manual release function input present.
64 waterflow active waterflow input function activated.
65 waterflow restored waterflow input function restored to normal.
66 invalid abort active abort switch pressed in zone without an alarm present
67 inv abort restored abort switch released in zone without an alarm present
68 cfg resto 9: mr----- config error #9 restored. zone number appended to this message.
69 cfg error 9: mr----- config error #9: manual release is in an alarm only zone.
70 network reset history stored when a reset command is recorded from cheetah net

network
71

acknowledge
72 process restored process state for this zone de-activated.
73 process present process state for this zone activated.
74 trouble restored trouble state for this zone de-activated.
75 trouble present trouble state for this zone activated.
76 supervisory restored supervisory state for this zone de-activated.
77 supervisory present supervisory state for this zone activated.
78 drill restored drill state for this zone de-activated.
79 drill present drill state for this zone activated.

80

missing
81 net member#a return network member #a has returned on line.
82 net manager missing network manager is missing.
83 net manager return network manager has returned on line.
84 network silence history stored when a silence command is recorded from cheetah net

message

pre-discharge function input present.

history stor
net

network member #a is missing.

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com

Tel: [phone] Fax: [phone] Toll Free: 888-509-1970 email: [e-mail]

FS-8700-48 Fike Cheetah Manual Page 28 of 36

to

zone configuration checksum error. zone number appended to this

# Description Notes

85 network drill presnt drill state activated from network - all zone only.
86 abort restored abort state for this zone de-activated.
87 abort present abort state for this zone activated.
88 pre-alarm1 restored pre-alarm 1 state for this zone de-activated.
89 pre-alarm1 present pre-alarm 1 state for this zone activated.
90 pre-alarm2 restored pre-alarm 2 state for this zone de-activated.
91 pre-alarm2 present pre-alarm 2 state for this zone activated.
92 network drill restor drill state restored from network - all zone only.
93 alarm present alarm state for this zone activated.
94 periph #aa missing peripheral device of id#aa is missing.
95 pre-discharge pre-discharge state for this zone activated.
96 periph #aa return peripheral device of id#aa has returned on line.
97 release release state for this zone activated.
98 zone enabled zone disable state for this zone de-activated.
99 zone disabled zone disable state for this zone activated.
100 watermist inactive not used since release state never clears
101 watermist active watermist state for this zone activated
102 network alarm unsil network command - unsilence alarms
103 network superv unsil network command - unsilence supervisories

104 checksum ok -----

zone configuration checksum error restored. zone number appended
this message.

105 checksum error -----

106 network troubl unsil network command - unsilence troubles
107 vesda not configured trouble event stored when the hli is present but no vesda is configured.
108 vesda configur clear trouble clear event for the above trouble.
109 config menu exited trouble clear event when the configuration menu has been exited
110 aux1 power restored auxiliary power input trouble restored - main board
111 aux1 power trouble auxiliary power input trouble - main board
112 aux2 power restored auxiliary power input trouble restored - power module
113 aux2 power trouble auxiliary power input trouble - power module
114 aud switch disabled enable/disable switch for audibles is in the disable position
115 aud switch restored enable/disable switch for audibles has returned to the enable position
116 diagnostics entered indicates the operator has accessed the diagnostic menu selections
117 zone disable restore frcm assigned to zone disable function has cleared
118 zone disable active frcm assigned to zone disable function has activated
119 internal fault device trouble from the 0x08 polling command
120 int fault restored trouble restored from the 0x08 polling command
121 wiring fault-open open circuit fault on supervised circuit: frcm/som/srm
122 wiring fault-short short circuit fault on frcm/som/srm
123 acknowledge switch acknowledge switch pressed.
124 test point bad analog device fire test point is out of hochiki specified range.
125 calibration restored calibration fault has been restored. device now has valid calibration data.
126 calibration fault fault detected during calibration of this device.
127 configure restored fault restored from som/r2m/srm configuration trouble.
128 configure fault fault detected when configuring som/r2m/srm.
129 reconfigured device addressable device has been configured
130 enabled device addressable device has been enabled.
131 disabled device addressable device has been disabled.

message.

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com

Tel: [phone] Fax: [phone] Toll Free: 888-509-1970 email: [e-mail]

FS-8700-48 Fike Cheetah Manual Page 29 of 36

board level output circuit enabled. circuit number appended to this

board level output circuit disabled. circuit number appended to this

zone number appended to this

config error #1 (no manrel in this zone). zone number appended to this

config error #3 (alarm verification on device in a suppression zone)

config checksum error trouble: devices & loops (loop number

config checksum error trouble restored: devices & loops (loop number

board level output config checksum restored. circuit number appended to

board level output config checksum error. circuit number appended to

# Description Notes

132 enabled loop 1 loop 1 has been enabled.
133 disabled loop 1 loop 1 has been disabled.
134 enabled loop 2 loop 2 has been enabled.
135 disabled loop 2 loop 2 has been disabled.
136 enabled loop 3 loop 3 has been enabled.
137 disabled loop 3 loop 3 has been disabled.
138 enabled loop 4 loop 4 has been enabled.
139 disabled loop 4 loop 4 has been disabled.
140 enabled zone ----- zone enabled. zone number appended to this message.
141 disabled zone ----- zone disabled. zone number appended to this message.

142 enabled ckt -----

143 disabled ckt -----

144 loop 1 calibration all configured analog devices on loop 1 have been calibrated.
145 loop 2 calibration all configured analog devices on loop 2 have been calibrated.
146 loop 3 calibration all configured analog devices on loop 3 have been calibrated.
147 loop 4 calibration all configured analog devices on loop 4 have been calibrated.
148 l1 open class a class a wiring has an open circuit trouble - loop 1.
149 l2 open class a class a wiring has an open circuit trouble - loop 2.
150 l3 open class a class a wiring has an open circuit trouble - loop 3.
151 l4 open class a class a wiring has an open circuit trouble - loop 4.
152 l1 class a restored class a wiring trouble has restored to noramal - loop 1.
153 l2 class a restored class a wiring trouble has restored to noramal - loop 2.
154 l3 class a restored class a wiring trouble has restored to noramal - loop 3.
155 l4 class a restored class a wiring trouble has restored to noramal - loop 4.
156 walktest active panel has enterred the walktest mode.
157 walktest expired walktest mode has expired.

158 cfg resto 1: mr-----

159 cfg error 1: mr-----

160 cheetah network device clear
161 cheetah network device activation
162 config resto 3: al v config error #3 restored.

message.

message.

config error #1 restored.
message.

message.

163 config error 3: al v

164 system power low system power below voltage level for reliable operation.
165 system power ok system power low trouble restored.

166 checksum error -----

167 checksum ok -----

168 checksum ok -----

169 checksum error -----

170 password level 1 password level 1 enterred.
171 password level 2 password level 2 enterred.
172 password level 3 password level 3 enterred.

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com

Tel: [phone] Fax: [phone] Toll Free: 888-509-1970 email: [e-mail]

trouble.

appended).

appended).

this message.

this message.

FS-8700-48 Fike Cheetah Manual Page 30 of 36

vesda commun error

vesda commun

vesda detector alert level restored. analog data appended to this

vesda detector alert level activated. analog data appended to this

vesda detector action level restored. analog data appended to this

vesda detector action level activated. analog data appended to this

level activated. analog data appended to this

vesda detector fire 2 level activated. analog data appended to this

# Description Notes

173 password level 4 password level 4 enterred.
174 password level 5 password level 5 enterred.
175 password expired password has timed-out.
176 software error erroneous interrupt source or illegal program instruction fetched.
177 keyword error erroneous program flow.
178 wiring fault restore frcm/som/srm wiring fault restored to normal.
179 config resto 4: sens config error #4 restored
180 config error 4: sens config error #4 (analog phot has too high alarm sensitivity)
181 bat1 charge volt low battery #1 charger has a low voltage output
182 bat1 charge restored battery #1 chrager has returned to normal voltage output
183 bat2 charge volt low battery #2 charger has a low voltage output
184 bat2 charge restored battery #2 chrager has returned to normal voltage output
185 cfg resto 5: w------ config error #5 restored. zone number appended.
186 cfg error 5: w------ config error #5 (watermist zone needs an srm). zone number appended.
187 cfg resto 6: w------ config error #6 restored. zone number appended.
188 cfg error 6: w------ config error #6 (watermist zone has an abort). zone number appended.
189 cfg resto 7: on-time config error #7 restored
190 cfg error 7: on-time config error #7 (srm assigned to watermist & zone has no on-time)
191 cfg resto 8: zn-type config error #8 restored.
192 cfg error 8: zn-type config error #8 (srm assigned to watermist & alarm type of zone).
193 pc configuring panel configuration is currently being changed by the pc
194 pc configuring done the pc has finished configuring the panel
195 history is erased the history buffers have been erased
196 cfg resto 10: vesda# config error #10 restored
197

communication to the vesda hli device has failed

198

restore
199 cfg error 10: vesda# config error #10 (two vesda's with the same unit number)

200 alert level restore

201 alert 0.000%/0.000%

202 action level restore

action
203

0.000%/0.000%

fire-1
204

0.000%/0.000%

fire-2
205

0.000%/0.000%
206 vesda fault: major vesda detector trouble
207 vesda clear: major vesda detector trouble
208 vesda fault: minor vesda detector trouble
209 vesda clear: minor vesda detector trouble
210 vesda fault: isolate vesda detector trouble
211 vesda clear: isolate vesda detector trouble
212 vesda fault: system vesda detector trouble
213 vesda clear: system vesda detector trouble
214 vesda fault: zone vesda detector trouble
215 vesda clear: zone vesda detector trouble

communication to the vesda hli device has restored to normal

message

message

message

message
vesda detector fire 1

message

message

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com

Tel: [phone] Fax: [phone] Toll Free: 888-509-1970 email: [e-mail]

FS-8700-48 Fike Cheetah Manual Page 31 of 36

match with cheetah

# Description Notes

216 vesda fault: urgent vesda detector trouble
217 vesda clear: urgent vesda detector trouble
218 vesda fault: power vesda detector trouble
219 vesda clear: power vesda detector trouble
220 vesda fault: network vesda detector trouble
221 vesda clear: network vesda detector trouble
222 vesda fault: airflow vesda detector trouble
223 vesda clear: airflow vesda detector trouble
224 vesda fault: filter vesda detector trouble
225 vesda clear: filter vesda detector trouble
226 vesda fault id = ---
227 vesda clear id = ---
228 invalid vesda zone vesda zone configured but not present on the vesdanet.
229 invalid v-zone clear clear message for above fault.
230 invalid vesda fault fault code 201 message purpose unclear at this time.
231 invalid fault clear clear message for above fault.
232 grnd fault disabled ground fault detection has been disabled.
233 grnd fault enabled clear message for above fault.
234 network clr: ------- network event message: zone-state has cleared
235 network act: ------- network event message: zone-state has activated
236 periph #aa reset peripheral device of id#aa has active reset sw.
237 periph #aa silence peripheral device of id#aa has active silence sw.
238 periph #aa acknowl peripheral device of id#aa has active acknowledge sw.
239 periph #aa trouble peripheral device of id#aa has an active trouble.
240 periph #aa trb clear peripheral device of id#aa trouble has cleared.

241 periph #aa zone err

242 periph #aa zone clr peripheral device of id#aa zone mis-match trouble has cleared
243
244 alert sect-n 0.000% vesda detector has reached alert level in sector 'n'
245 periph #aa drill on peripheral device of id#aa has active drill sw.
246 periph #aa drill off peripheral device of id#aa has de-active drill sw.
247 network module trubl trouble detected on the network card
248 network module clear trouble restored from the network card
249 device needed reset output device required reset to restore its configuration
250 action sect-n 0.000% vesda detector has reached alert level in sector 'n'
251 fire-1 sect-n 0.000% vesda detector has reached action level in sector 'n'
252 fire-2 sect-n 0.000% vesda detector has reached alarm level in sector 'n'
253 event 253 reserved for the history module
254 event 254 reserved for the history module
255 event 255 reserved for the history module

peripheral device of id#aa has a zone mis­configuration

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com

Tel: [phone] Fax: [phone] Toll Free: 888-509-1970 email: [e-mail]

FS-8700-48 Fike Cheetah Manual Page 32 of 36

Appendix A.5. Storing Panel Data

Panel data is stored in consecutive locations as described in the map below. For additional
explanations on the meaning of each data element contact FIKE directly.

Array Location Data Category Data stored at this location

0 Active Counter (0..65535) Active events in normal state

1

2 Active events in Trouble state
3 Active events in Supervisory state
4 Active events in Drill state
5 Active events in ? state
6 Active events in ? state
7 Active events in ? state
8 Active events in Abort state
9 Active events in Pre-Alarm1 state
10 Active events in Pre-Alarm2 state
11 Active events in Alarm state
12 Active events in Pre-Discharge state
13 Active events in Release state
14 Active events in Zone Discharge state
15 Active events in Water Mist state
16 Board Status Indicators (0 or 1) Alarm silence active 1=yes
17 Supervisory Silence Active 1=yes
18 Trouble Silence Active 1=yes
19 AC Power on Main Board 1=ok
20 AC Power on Aux Board 1=ok
21 Walk test Condition 1=on
22 Ground Fault Condition 1=ok
23 Ack Condition 1=on
24 Date & Time Month
25 Day of Month
26 Year
27 Day of Week
28 Hour
29 AM/PM
30 Minute
31 Second
32 Current Event Counter Number of current events present on cheetah
33 LED Status Indicators Pre-Alarm
34 Fire Alarm
35 Supervisory Alarm
36 Trouble
37 AC Power
38 Alarm Silence
39 Supervisory Silence
40 Trouble Silence

Active events in Process state

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com

Tel: [phone] Fax: [phone] Toll Free: 888-509-1970 email: [e-mail]

FS-8700-48 Fike Cheetah Manual Page 33 of 36

Appendix A.6. Acknowledging Alarms

This driver can be used to acknowledge alarms, reset or silence the Cheetah panel.

This functionality is limited. For this function to operate the Cheetah panel must be
configured to supervise the port that the FieldServer is connected to. In addition to enabling
this function, port supervision means that the panel will go into alarm if the FieldServer does
not respond to the supervision messages. In fact the request to ack /reset/ silence the panel
is included in the driver’s response to the supervision poll from the panel. The panel ignores
unsolicited messages. A consequence of this is that the driver cannot control the timing of
when the ack /reset/ silence message is sent to the panel.

In using this functionality you should also understand that the Cheetah panel protocol does
not acknowledge message receipt so this driver cannot report whether the message was
received by the panel and whether it was acted on.

The port supervision response message is sent even if you do not define a Port Response
Map Descriptor in the CSV file. In this case the command data will always be zero. Once
you define a Map Descriptor then the driver uses one Data Array element to determine the
command data to send to the panel. The value from this array element determines the
action the panel will take.

Bit Action Decimal Value

0 Reset 1
1 Silence 2
2 Acknowledge 4

Example: If you wish to Silence the Panel, then set the value of the Data Array element to 2.

Appendix A.7. Panel Firmware Versions

The driver supports older versions of panel firmware which transmit a shorter version of the
Panel Status command. This shorter version contains only panel data whereas the newer
version contains panel, zone & device data.

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com

Tel: [phone] Fax: [phone] Toll Free: 888-509-1970 email: [e-mail]

FS-8700-48 Fike Cheetah Manual Page 34 of 36

Appendix B. Driver Error Messages

Multiple protocol drivers may exist on a FieldServer. Each driver may produce its own error
messages and the FieldServer itself may produce error messages.

All messages produced by this driver begin "Cheetah:"

Error Message Action Required

Cheetah:#1 Unknown
simulation function.
Cheetah:#2 Simulation
function unknown.
Cheetah:#3 Protocol Error
(Start), Incoming msg
ignored - Waiting for next
msg.
Cheetah:#4 Protocol Error
(Stop), Incoming msg
ignored - Waiting for next
msg.
Cheetah:#5 Protocol Error
(Chksum), Incoming msg
ignored - Waiting for next
msg.
Cheetah:#6 Protocol Error
(Unknown), Incoming msg
ignored - Waiting for next
msg.
Cheetah:#7a Err. Zone=%d
Max=%d
Cheetah:#7b MapDesc
Error. Zone value error.
(%d)
Cheetah:#7c FYI. Warning.
Zone=%d. Max zone is
panel type dependent. Read
Manual.
Cheetah:#8 MapDesc Error.
Device value error. (%d)

Cheetah:#9 MapDesc Error.
Loop value error. (%d)

Cheetah:#10 MapDesc
Error. Zone & Device
Specified.

Cheetah:#11 MapDesc
Error. With devices only
alarm & trouble available.
Cheetah:#12 Message on
Cheetah port but no
mapDesc found.

Report these messages to FieldServer Technologies.

Warning messages only. An incoming message was discarded
because the identifiers which mark the beginning of a message could
not be found. You cannot take any action to correct this message. If it
occurs often check wiring, noise and installation.

Report this error to FieldServer Technologies.

An invalid zone has been specified. The zone causing the problem is
printed in parenthesis.4
The largest possible zone number is 255. Only Cybercat panels support
this number of zones. Legacy panels support up to zone 239. Very old
panels that can only send message #6 can only report information for
127 panels.
If you are connected to a Cybercat panel and you get the FYI message
you can ignore it. If you are connected to some other panel and you get
either the Err or FYI message then you will need to correct the CSV file.
An invalid device has been specified. The device causing the problem
is printed in parenthesis.4
An invalid loop has been specified. The loop causing the problem is
printed in parenthesis.4
One Map Descriptor cannot be used to store data for zones and
devices. Either the keyword Cheet_Zone or Cheet_Device must be set
to None4.

For devices only the alarm & trouble states are available. Set the
Cheet_DT values appropriately in the configuration file.4

A port has been reserved for the Cheetah protocol and a message has
been received on this port but there is no Map Descriptor defined for this
port.5

4

Modify the CSV file, download to the FieldServer and restart the FieldServer for the changes to take

effect.

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com

Tel: [phone] Fax: [phone] Toll Free: 888-509-1970 email: [e-mail]

FS-8700-48 Fike Cheetah Manual Page 35 of 36

The message has been rejected because it starts with the reported byte.

Error Message Action Required

The Data Array associated with the Map Descriptor in question is too

Cheetah:#13 Data Array to
short. MapDesc=<%s>
RQD=%d.

Cheetah:#15 Err. MD length
is required - defaulting to 1

Cheetah:#17. Err.
DIAG_USER_1

short. Adjust the length as required by the error message. Note that the
error may be repeated for a single Map Descriptor when a new zone or
device is stored because the storage location may be based on the
zone or device number. Generally for zone storage the array must have
at least 240 locations (and 128 for older Cheetah firmware.)5
The Map Descriptor length must be sufficient to store all the data. The
maximum device number is 255 and the maximum zone number is 255,
therefore to store all zones and devices the MD's must be 256 elements
long. Some legacy panels and message don’t support the full number
of devices/zones. For example some panels only support 241 zones.
Try and determine the correct length otherwise please use 256. If you
are unsure ask tech support to provide the template file server.csv
An internal diagnostic has been activated. This should not happen on a
live system. Take a log and contact tech support
Messages are expected to begin with a Carriage return or SOH (0x01).

Cheetah:# 18 Err. Bad msg
start= %#x

Cheetah:#19 FYI. Ignoring
0x0100 messages from
Cybercat.

Cheetah:#20 Err. DA too
short. Zone=%d MD=<%s>
RQD=%d

Cheetah:#21. Err. DA too
short. MapDesc=<%s>
RQD=%d DA=%s
Cheetah:#22 FYI. Node=%s
is a Cybercat panel.
Cheetah:#23 FYI. Node=%s
is a Cheetah panel.

Perhaps the vendor has changed firmware. If this error occurs
repeatedly then take a log and contact tech support. If it occurs rarely
then assume it is noise and ignore it if you are satisfied you are getting
good data updates.
Cybercat panels transmit lagacy message which must be ignored. This
message confirms the driver is ignoring them. No corrective action is
required. If you are connected to a Cybercat panel and never see this
message printed (checked the system and driver error message screen)
then please take a log and contact Tech support.
The driver is attempting to store zone status information from a
Cybercat panel. The Data Array is too short. Adjust the length of the
Data Array and the length of the Map Descriptor.5
The driver is attempting to store device status information from a
Cybercat panel. The Data Array is too short. Adjust the length of the
Data Array and the length of the Map Descriptor.5
These messages report the type of panel that the configuration is
suitable for. If this isn’t what you expect, review the configuration
against the manual and make changes as required. Refer to section 4.3
for more information.5

5

Modify the CSV file, download to the FieldServer and restart the FieldServer for the changes to take

effect.

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com

Tel: [phone] Fax: [phone] Toll Free: 888-509-1970 email: [e-mail]

FS-8700-48 Fike Cheetah Manual Page 36 of 36

Appendix B.1. Driver Stats

Cheetah panels produce data messages for slave devices to consume. The type and
frequency of the messages depends on the Cheetah firmware revision.

The driver counts all incoming messages of interest as the PLC_READ_MSG_RECD
statistic. Other legal messages which do not contain the data this driver is interested in are
discarded and are counted as the MSG_IGNORED statistic.

The PLC_READ_MSG_RECD statistic is incremented once by each Map Descriptor which
extracts data from an incoming message. Thus, one incoming message and three
associated Map Descriptors would cause the statistic to increase by three (when viewed
from the connection's point of view.)

The driver ignores messages 0x0100 from Cybercat panels. These lagacy messages
contain contradictory information. If the node is configured as a Cybercat panel then the
driver ignores the messages and increases the Ignored Messages stat on the connection.

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com

Tel: [phone] Fax: [phone] Toll Free: 888-509-1970 email: [e-mail]
