ACCLAIM
LIGHTING
YOUR SOURCE FOR ADVANCED LED LIGHTING SOLUTIONS
Pixel Stick 5/10 (DMX-512)
Model: PSB
Indoor Fixtures
www.acclaimlighting.eu
Pixel Stick
Pixel Stick link cable
standard 100mm (0.32 ft)
Pixel Stick first cable
standard 300mm (1 ft)
Pixel Stick
Pixel Driver mini
DMX 512 in
5V DC in
DMX 512 out
Auto addressing
max. 6 fixtures in a chain
Indoor Fixtures
-xxx-xxxx
PSB
Control:
2 = DMX
Model Number
PSB-221-AAHN
PSB-221-BAHN
PSB-211-AAHN
PSB-211-BAHN
Housing:
1 = Black Color PCB
2 = White Color PCB
Product name
Pixel Stick 5 1,25W (White PCB)
Pixel Stick 10 2,5W (White PCB)
Pixel Stick 5 1,25W (Black PCB)
Pixel Stick 10 2,5W (Black PCB)
Cover:
1 = Clear
Beam
120º
120º
120º
120º
Model number
LED Config:
A = 5 LEDs 20cm
B = 10 LEDs 40cm
Color
RGB
RGB
RGB
RGB
System
Max in Chain
Cabling System
Control
Pixels
Pixel Pitch
DMX Channels
Addressing DMX
Power requirements
Current Consumption
Light Source
Power Consumption
Weight
Housing
Source Life
Operating Temp.
Storage Temp.
Including
Beam angle:
A = Open beam
Control
Pixel driver mini (5Vdc + DMX)
Pixel driver mini (5Vdc + DMX)
Pixel driver mini (5Vdc + DMX)
Pixel driver mini (5Vdc + DMX)
ACCLAIM
LIGHTING
5Vdc + DMX
6 pcs Pixel stick 10 / 12 pcs Pixel stick 5 (2,4 mtr)
6-wire cable + 6-pin connector
Pixel driver mini (DMX-512 or DMX-1000)
5 pixels / 10-pixels
40 mm
L=20 cm 15 chan. / L=40 cm 30 chan.
Auto DMX Addressing
5Vdc
Pixel-stick-5 250mA / Pixel-stick-10 500mA
5 x SMD 5050 / 10 x SMD 5050
1,25W / 2,5W
15 gr / 30 gr
Polycarbonate
50.000 hours
-0 °C ~ +40 °C
-20 °C ~ +70 °C
1 pc Mounting clip
Version:
Color:
C
= WW 3200k
G
= CW 6000k
H
= RGB
Delivery including
1 pc Mounting clip
1 pc Mounting clip
1 pc Mounting clip
1 pc Mounting clip
N = Normal
13mm [0.5 in]
9mm [0.3 in]
40mm [1.6 in]
Mounting clip
Dimensions
410mm [16.1 in]
392mm [15.4 in]
25mm [1.0 in]
Wiring diagram
9mm [0.4 in]
14mm [0.6 in]
9mm [0.4 in]
7mm [0.3 in]
www.acclaimlighting.eu
** All rights reserved. Improvements changes to specifications, design, and all contents in this catalog may be made at any time without prior notice.
