ABUS SPI User Manual

SPI
ABUS TECHNOLOGIES INC.
Smart Programmable Isolator
User Manual
Isolator
WARNING
This manual should be passed on to the end user.
The contents of this manual are subject to change without prior notice.
All rights reserved.
ABUS gives no warranty of any kind with regard to this manual, including, but not limited to, fitness
for a particular purpose.
If any question arises or errors are found, or if any information is missing from this manual, please
Smart
inform your supplier or inform at info@abustek.com
The specifications mentioned in this manual are limited to those for the standard type under the
specified model number break-down and do not necessarily apply for customized instruments.
Please note that changes in the specifications, construction, or component parts of the instrument
may not immediately be reflected in this manual at the time of change.
If the customer or any third party is harmed by the use of this product, ABUS assumes no
responsibility for any such harm owing to any defects in the product which were not predictable, or
for any indirect damages.
Although Warning hazards are related to personal injury, and Caution hazards are associated with equipment or property damage, it must be understood that operation of damaged equipment could, under certain operational conditions, result in degraded process system performance leading to personal injury or death. Therefore, comply fully with all Warning and Caution notices.
Information in this manual is intended only to assist our customers in the efficient operation of our equipment. Use of this manual for any other purpose is specifically prohibited and its contents are not to be reproduced in full or part without prior approval of Technical Communications Department, ABUS Technologies
.
HEALTH AND SAFETY
To ensure that our products are safe and without risk to health, the following points must be noted:
1. The relevant sections of these instructions must be read carefully before proceeding.
2. Warning labels on containers and packages must be observed.
3. Installation, operation, maintenance and servicing must only be carried out by suitably trained
personnel and in accordance with the information given. Any deviation from these instructions will transfer the complete liability to the user.
4. Normal safety precautions must be taken to avoid the possibility of an accident occurring when
operating in conditions of high pressure and/or temperature.
5. Chemicals must be stored away from heat, protected from temperature extremes and powders kept
dry. Normal safe handling procedures must be used.
6. When disposing of chemicals ensure that no two chemicals are mixed.
Safety advice concerning the use of the equipment described in this manual or any relevant hazard data sheets (where applicable) may be obtained from the Company address on the back cover, together with servicing and spares information.
ABUS TECHNOLOGIES INC.
2
Isolator
8. Operation
8
.
Smart
CATALOGUE
Contents Page No.
1. Introduction 4
2. Presentation
1. Features Technical Parameters
2.
3. Dimensions 5
4. Ordering Details 6
5. Connections 6
6. Installation 8
7. Configuration
Programming Instruction
9. Maintenance
1. Calibration of Instrument
2. Operation Environment
3.
Troubleshooting
10. Safety Precautions 10
11. Warranty 10
4
4 5
8
8
9 9 9 9
ABUS TECHNOLOGIES INC.
3
Isolator
1. INTRODUCTION
The Smart Isolator being programmable through Handheld communicator
Model 1001 can be fit into major of industrial applications operating with different
signals. It can be ordered to accept up to 2 inputs and provide up to 3 outputs. The
input signals can be non-linear input such as resistance temperature detector,
thermocouple or linear current or voltage. Signal of one-way, two-way or three-way
current or voltage, isolated by transmitting output provides good electric isolation
between input, output and power. It can be used as a temperature transmitter,
convertor, signal isolator or signal conditioner according to the application.
2. PRESENTATION
2.1 Features
This product uses a special chip. It has many advanced performances which traditional
Smart
analogue isolator and many digital isolators don’t possess. This chip provides restrict and process from
software to high/ low-frequency interference signal in input signals. Even in high-power frequency
conversion system it can keep reliable performance. With the help of strong function of this chip
instrument can carry on digitalized automatic/ manual regulation to signal without the help of outside
zero and full-scale potentiometer. Meanwhile it can go on automatic compensation to input signals.
This series of products can also use integrated communication protocol, with the help of the
connection of communicational methods, observing input and output values on line. The integrated
smart isolator using an special chip, besides universal functions, can support the logical process to
signal and set alarm output to condition.
Unique and strong functions of software of the chip and excellent electric performance of
hardware of isolator itself provide firm assurance for stability and reliability of products. And it makes
overall performances of products lead of international advanced standard.
Series of instruments can be used with unit group instruments and DCS, PLC, etc. They are
widely used in all kinds of industries such as oil, chemical, petro-chemical, power, food, steel,
pharmaceutical industries etc...
ABUS TECHNOLOGIES INC.
4
Isolator
2.2 Technical Parameters
System Accuracy Class: ± 0.25 % x F.S.
Temperature Drift: ≤ 0.0015 % F.S °C
Operation Temperature: Industry-class standard -10 ~ 55°C
Input Impedance: Current: ≤ 250 Ω; Voltage: ≥ 500 KΩ
Current Outputs the Load Impedance Allowing Outside Connection:
At 4 ~ 20mA output: ≥ 750 Ω;
At 0 ~ 10mA output: ≥ 1.5 KΩ;
If load is needed, please enclose additional illustration.
Inside Load at Outputting Voltage: ≤ 1 Ω
Input/ Output/ Power/ Communication/ Insulation Strength between Two-Way: ≥ 1500 V AC.
Ambient Temperature for Storage and Transportation: -40 ~ +80°C.
Power Supply: AC: 85V ~ 260V DC: 18V ~ 36V (opposing protection)
Figure & Size: Width x Height x Depth: 22.5 x 100 x 115mm
Smart
Net Weight: 130g ±10g.
3. DIMENSIONS
ABUS TECHNOLOGIES INC.
5
Isolator
Input
4. ORDERING DETAILS
TYPE DESCRIPTION
Product
Channel
Type
First
Output
Second
Output
Third
Output
Power
Supply
SPI
S Single Input 1 Input
D Double Input 2 Input
L
T Thermocouple or RTD
B1 B2 B3 B4
Example: SPI > S > L > B1 > C1 > N > A
Smart Programmable Isolator
Linear Signal such as, 4~20mA, 0~10V
4 – 20 mA
C1 C2 1 – 5 V C3 0 – 10 mA C4 0 – 5 V
D1 D2 1 – 5 V D3 0 – 10 mA
D4 0 – 5 V
N None
D 24 VDC A 220 VAC
1 – 5 V 0 – 10 mA 0 – 5 V 4 – 20 mA
4 – 20 mA
Smart
Illustration:
1. Single circuit input at most correspondingly has four output;
2. Types of input and output signals can be selected;
3. Frequency signals can be input and output.
5. CONNECTIONS
Connection Diagram: Current & Voltage
ABUS TECHNOLOGIES INC.
6
Isolator
Smart
Connection Diagram: Thermocouple & RTD
Illustration of Instruments Wiring:
1. First Way Input: EXT1 (-), EXT2 (+)
2. Second Way Input: EXT3 (-), EXT4 (+)
3. First Way Output: EXT10 (-), EXT9 (+)
4. Second Way Output: EXT12 (-), EXT11 (+)
5. Third Way Output: EXT14 (-), EXT13 (+)
6. Power (220V AC or 24VDC): EXT15 (-), EXT ** (+).
Remarks: If smart signal transmitter directly connects with two-wire system transmitter, then
press first way input.
ABUS TECHNOLOGIES INC.
7
Isolator
6. INSTALLATION
First Input: EXT2 (-), EXT6 (+24) to connect wire. At this time smart signal processor doesn’t
have the function of protecting of protecting outside short circuit.
Second Input: EXT4 (-), EXT8 (+24V) to connect wire. At this time smart signal processor doesn’t
have the function of protecting outside short circuit.
Mounting Way: Please use guide-way type mounting. At mounting make sure the card position is
stable and firm. In order to make instruments have good heat dissipation please
vertically installs and reserve draught room as possible as you can.
7. CONFIGURATION
Programming Instructions
1. Five-core Communication Interface: For communication connection through
Smart
private data wire Handheld Communicator Model-1001.
2. Indicating Light: Power: indicating light (continuously lighted) in power
condition indicating light (communicating, fast flickering) in communication
condition indicating light (trouble, slow flickering) in trouble condition.
ALM1: At satisfying alarm conditions, indicating light lights for long time
ALM2: At satisfying alarm conditions, indicating light lights for long time
Under trouble of input/ output signal, indicating light flickers.
8. OPERATION
For best results, you may use the shielded signal cable to avoid power spikes.
Check all the wires before operating the instrument. Series of instruments can be used
with instrument for isolation and distribution of signal regarding to your application may
be for recording, controlling through DCS, PLC, etc. They are widely used in all kinds
ABUS TECHNOLOGIES INC.
8
Isolator
of industries such as oil, chemical, petro-chemical, power, food, steel, pharmaceutical
industries etc.
S.NO. FUNCTION DESCRIPTION
1 Alarms For indication only. 2 Alarms For indication only 3 Calibration Through Model-1001
9. MAINTENANCE
9.1 Calibration of Instruments
The operation can be realized through ABUS-1001 Operator. The set parameters use the same
calibration way as that of 585 and support automatic calibration.
Smart
9.2 Operation Environment
At mounting position strong vibration or strong electromagnetic impact from signal terminal,
power terminal, power terminal and room is not allowed. In operation environment, poisonous or harmful
matters which will corrode metals and plastics are not allowed to exist. Please keep the operation
environment dry for the precise output.
9.3 Troubleshooting
There are two kinds of trouble in input signals: input trouble (open circuit, short circuit) and
beyond span trouble.
Output ways at input trouble: Instruments can select beyond-span gain output and general output.
Gain Output
At the condition of beyond upper limit, output signal has a gain exceeding 5% of normal output
value;
At the condition of beyond lower limit, output signal has an output lower than 5% of lower limit; if
lower limit is zero (i.e.0 ~ 5 V ) then output is 0 V.
General Output
At the condition of beyond upper limit, output maximum value or setting value;
At the condition of beyond lower limit, output minimum value or setting value;
At the condition of trouble, keep output value or setting value before output trouble;
Under trouble of input signal, trouble light of instrument flickers to indicate signal trouble.
ABUS TECHNOLOGIES INC.
9
Isolator
10. SAFETY PRECAUTIONS
1. The unit should be powered for 15 minutes before use.
2. Use in ambient temperature of 0-60˚C.
3. Avoid vibrations, shock, excessive dust, corrosive chemical materials or gaseous
environment.
4. Input wire should not be too long. If measured signal have to be far away from the
unit, please use 2-core shielded cable.
5. Use this instrument in the scope of its specifications, otherwise fire or malfunctions
may result.
6. Contact of the instrument, with organic solvents or oils should be avoided.
7. Do not turn on the power supply until all of the wiring is completed. Otherwise
Smart
electrical shock, fire or malfunction may result.
8. Do not disassemble, repair or modify the instrument.
9. All connections should be tightened properly.
10. Power supply should be constant, should not be fluctuating.
11. WARRANTY
ABUS provides the original purchaser of this instrument a one (1) year warranty
against defects in material and workmanship under the following terms:
The one year warranty begins on the day of shipment as stated on the sales bill.
During the warranty period all costs of material and labor will be free of charge
provided that the instrument does not show any evidence of misuse.
For maintenance, return the instrument with a copy of the sales bill to our factory.
All transportation and insurance costs should be covered by the owner of the
equipment.
Should any sign of electrical or mechanical shock, abuse, bad handling or misuse
be evident the warranty voids and maintenance costs will be charged.
ABUS TECHNOLOGIES INC.
www.abustek.com, E-M ail: info@abustek.com
