Abocom WMG2400 User Manual

802.11b/g Wireless miniPCI Card

The WMG2400 is a mini PCI card that connects
your notebook to a wireless local area notebook.
Incorporating the IEEE802.11g standard’s
mandatory modulation schemes, the WMG2400 is
backwards compatible with all the existing 802.11b
products already out there. Moreover, the high­speed transfer rate of up to 54Mbps makes it an
essence for today’s high-bandwidth demand.

The WMG2400 is a very small card that can fit into
any notebook, handheld or desktop computer
equipped with a Mini PCI (Type III B slot) interface
for wireless network applications. It allows you to
take full advantage of your notebook’s mobility with
access to real-time information and online services anytime and anywhere. It slides easily into the
MINI PCI expansion slot to enable a wireless connection to your network.

FEATURES

 Complies with IEEE 802.11b/802.11g standard for 2.4GHz Wireless LAN.
 Type III-b MiniPCI form factor for standard compatibility in a variety of mobile devices
 Works with all existing network infrastructure.
 Complies with specific wireless products and services.
 Up to 256-Bit WEP Encryption for data security.
 Freedom to roam while staying connected.
 22-Mbps Packet Binary Convolution Coding (PBCC)(according to the IEEE Std 802.11b high-rate

specification)

 High-speed transfer rate of up to 54 Mbps in 802.11g mode of operation
 Supports Windows98SE/2000/ME/XP
 Lower power consumption.
 Easy to install and configure.

1

1

Theoretical wireless signal rate based on IEEE standard 802.11g of chipset used. Actual throughput will vary.

Network conditions and environmental factors are likely to lower actual throughput rate.



SPECIFICATIONS

Standard

Host Interface

Operating Voltage

Power Requirement

Antenna Type

Frequency Range

Number of Selectable Channels

Modulation Technique

Data Rate

Preamble

IEEE 802.11b, IEEE 802.11g Standard

miniPCI Interface 1.0

3.3V ± 5%

Power consumption at 11g

  TX: 630mA, RX: 350mA

Power consumption at 11b

TX: 600mA, RX: 350mA

Internal diversity with connectors

2.412GHz-2.4835GHz



USA, Canada (FCC): 11 channels (2.412GHz~2.462GHz)



Europe (CE): 13 channels (2.412GHz~2.472GHz)



Japan (TELEC): 14 channels (2.412GHz~2.4835GHz)

802.11b: Direct Sequence Spread Spectrum (PBCC, CCK, DQPSK, DBPSK)

802.11g: Orthogonal frequency division multiplexing

802.11b(22Mbps, 11 Mbps, 5.5 Mbps, 2 Mbps, 1 Mbps)

802.11g(54 Mbps, 48 Mbps, 36 Mbps, 24 Mbps, 18 Mbps, 12 Mbps, 9
Mbps, 6 Mbps)

802.11b: Both Short and Long preamble

802.11g: Long preamble only

Modulation

Security

Output Power

Receiver Sensitivity

Range

Media Access Protocol

Physical Specifications

11g:Orthogonal Frequency Division Multiplexing (OFDM)



54Mbps/48Mbps:QAM-64



36Mbps/24Mbps:QAM-16



18Mbps/12Mbps:QPSK



9Mbps/6Mbps:BPSK

11b+: Packet Binary Convolution Coding (PBCC)



22Mbps/11Mbps/5.5Mbps:PBCC

11b:Direct Sequence Spread Spectrum (DSSS)



11Mbps/5.5Mbps:CCk



2Mbps:DQPSK



1Mbps:DBPSK
Hardware-Based Encryption/Decryption Using 64-, 128-, and 256-Bit
Wired-Equivalent Privacy (WEP) Keys

54Mbps OFDM: +12~ 14dBm; 11Mbps CCK: 18dBm

-72dBm at 54Mpbs, 10% PER

-72dBm at 48Mpbs, 10% PER

-75dBm at 36Mpbs, 10% PER

-79dBm at 24Mpbs, 10% PER

-82dBm at 18Mpbs, 10% PER

-83dBm at 22Mbps, 8% PER

-84dBm at 12Mpbs, 10% PER

-82dBm at 11Mpbs, 8% PER

-87dBm at 9Mpbs, 10% PER

-88dBm at 6Mbps, 10% PER

-85dBm at 5.5Mpbs, 8% PER

-86dBm at 2Mpbs, 8% PER

-89dBm at 1Mpbs, 8% PER

Indoors: up to 100meters; Outdoors: up to 400meters

CSMA/CA (Collision Avoidance) with ACK

  Weight: 10g

Dimension: 59.75 (L) x 44.6(W) mm



Operating Temperature: 0~60℃ ambient temperature



Environment Specifications

EMC Certification  FCC Part 15.247 in US

Storage Temperature: -20~70℃ ambient temperature



Operating humidity: 90% maximum (non-condensing)



Storage humidity: 90% maximum (non-condensing)
