Abocom ARM904 User Manual

802.11g 2.4GHz Wireless Router
With 4 Port 10/100 Switch

DESCRIPTION

The ARM904 is an IEEE 802.11g compliant wireless router with a

built in four-port fast Ethernet switch. It brings the latest wireless

technology with high speeds up to 54Mbps, which is almost five times faster than the 802.11b wireless

network. This high transfer rate provides relief from the pain of waiting while you are downloading large files,

web surfing, having a video-conference, playing stream high-quality digital movies, etc.

The ARM904 is interoperable with all other 802.11b wireless devices, so that you can use it with both your

already purchased 802.11b devices and newly 802.11g investments.

This high-performance IEEE 802.11g standard-based router allows you to connect all of your wireless

equipped PCs, while an integrated built-in 4-port fast Ethernet switch connects your devices that need

Ethernet wiring. It’s the easiest way to share and extend your high-speed xDSL/cable modem Internet

connection; either with or without wires.

The ARM904 provides not only the ease of Internet access, but also the privacy of data transmission.

Network Address Translation (NAT) provides your network with protection from intruders, while 64 and 128-

bit WEP (Wired Equivalent Privacy) encryption guard your wireless network for maximum privacy. Additional

security features include pass-through of multiple concurrent IPSec and PPTP VPN sessions for

telecommuters or for anyone who needs to transmit sensitive information more securely.

FEATURES

 Data rate up to 54 Mbps

 Backwards compatible

 128-bit WEP encryption

 1 port 10/100 Mbps N-Way WAN

 4 ports 10/100Mbps N-Way LAN

 Web-Based management

 Remote management

 Supports PPPoE

 Support VPN

 Natural firewall

 Auto detects & configures ISP

 Exposed Host (DMZ)

 MAC Address authentication

 URL Content Filtering

SPECIFICATIONS

System

● Operating System

Web-based Management, Remote Management

● Protocols

Static & Dynamic Routing with TCP/IP, NAT, PPPoE, DHCP (client & server); HTTP, UDP, PAP, CHAP, RIP1, DDNS

● VPN Pass Through

PPTP, IPSec, L2TP

● Power

External DC 12V 800mA

Data Communications

● Wireless Local Area

IEEE 802.11g or IEEE 802.11b

● Data Rate

1 ~ 54 Mbps

● Operating Ranges: (Max)

Outdoors: 150M @ 11 Mbps, 250M @ 5.5Mbps or lower
Indoors: 25M @ 11 Mbps, 100M @5.5Mbps or lower

● WEP

64 Bit, 128 Bit

● Frequency Band

2.4GHz (11g & b) ISM Band

USA (FCC): 2.412GHz ~ 2.462GHz (Ch1-11)
Europe (CE): 2.412GHz ~2.472GHz (Ch1-13)
Japan (TELEC): 2.412GHz ~ 2.484GHz (Ch1-14)

● Antenna Connector

2 Hirose UFL connectors

RF Output Power

●

64QAM: 14dBm
16QAM: 16dBm
QPSK: 17dBm
BPSK: 17dBm
DBPSK, DQPSK, CCK: 17dBm

● Sensitivity

11g@PER<10%
54Mbps: -65dBm
48Mbps: -66dBm
36Mbps: -70dBm
24Mbps: -72dBm

Connections

● WAN

1 port x 10/100 Mbps (auto-sensing) Ethernet (RJ45)

Physical Characteristics

18Mbps: -77dBm
12Mbps: -79dBm
9Mbps: -81dBm
6Mbps: -82dBm

11b@PER<8%
11Mbps: -80dBm

5.5Mbps: -83dBm
2Mbps: -84dBm
1Mbps: -87dBm

Modulation:

●

Orthogonal Frequency Division Multiplexing (11g)
48/54 Mbps (QAM-64)
24/36 Mbps (QAM-16)
12/18 Mbps (QPSK)
6/9 Mbps (BPSK)

Direct Sequence Spread Spectrum (11b)

5.5/11 Mbps (CCK)
2 Mbps (DQPSK)
1 Mbps (DBPSK)

● Operation Mode

I). Infrastructure mode:

Seamless roaming within the IEEE802.11g & 11b

wireless LAN infrastructure

Supports WEP encryption: 64/128 Bit

II). Ad-Hoc mode: Peer to peer connection

● Modulation Type

Direct Sequence Spread Spectrum (DSSS)

● LAN

4 ports x 10/100Mbps (auto-sensing) Ethernet (RJ45)

● Dimensions

160mm (6.3in) x 108mm (4.25in) x30mm (1.18in)

● Weight

235g (0.52lb)
