ABB AF265-30-11-13 Data Sheet
Extended Product Type:
Product ID:
EAN:
Catalog Description:
Long Description:
Minimum Order Quantity:
Customs Tariff Number:
EAN:
Product Net Depth:
Product Net Height:
Product Net Weight:
Product Net Width:
Package Level 1 Width:
Package Level 1 Length:
Package Level 1 Height:
Package Level 1 Gross Weight:
Package Level 1 EAN:
Package Level 1 Units:
Number of Main Contacts NC:
Number of Auxiliary Contacts NO:
Number of Auxiliary Contacts NC:
Rated Operational Voltage:
Rated Frequency (f):
Conventional Free-air Thermal
Current (Ith):
Rated Operational Current AC-1 (Ie):
Rated Operational Current AC-3 (Ie):
Rated Operational Power AC-3 (Pe):
Rated Breaking Capacity AC-3 acc.
to IEC 60947-4-1:
Rated Making Capacity AC-3 acc. to
IEC 60947-4-1:
Short-Circuit Protective Devices:
Rated Short-time Withstand Current
(Icw):
General Information
AF265-30-11-13 100-250V 50/60Hz / DC
1SFL547002R1311
7320500481189
AF265-30-11-13 Contactor
A 3-phase Contactor suitable for various applications such as Motor starting, Isolation, Bypass and Distribution application up to max 1000 V. Operated with wide control voltage
range 100-250 V, 50/60 Hz and DC
Categories
Products » Low Voltage Products and Systems » Control Products » Contactors » Block Contactors
Ordering
1 piece
85364900
7320500481189
Dimensions
180.0 mm
225.0 mm
4.640 kg
140.0 mm
Container Information
223 mm
175 mm
270 mm
5.31 kg
7320500481189
1 piece
Technical
011
Main Circuit 1000 V
Main Circuit 50/60 Hz
acc. to IEC 60947-4-1, Open Contactors q = 40 °C 400 A
(690 V) 55 °C 350 A
(690 V) 40 °C 400 A
(1000 V) 40 °C 350 A
(1000 V) 55 °C 300 A
(690 V) 70 °C 290 A
(1000 V) 70 °C 240 A
(1000 V) 55 °C 100 A
(220 / 230 / 240 V) 55 °C 265 A
(690 V) 55 °C 250 A
(415 V) 55 °C 265 A
(440 V) 55 °C 265 A
(380 / 400 V) 55 °C 265 A
(500 V) 55 °C 250 A
(500 V) 200 kW
(1000 V) 132 kW
(690 V) 200 kW
(220 / 230 / 240 V) 75 kW
(380 / 400 V) 132 kW
(440 V) 160 kW
(415 V) 132 kW
8 x Ie AC-3
10 x Ie AC-3
gG Type Fuses 500 A
at 40 °C Ambient Temp, in Free Air, from a Cold State 15 min 400 A
at 40 °C Ambient Temp, in Free Air, from a Cold State 30 s 1224 A
AF265-30-11-13 100-250V 50/60Hz / DC
Maximum Breaking Capacity:
Maximum Electrical Switching
Frequency:
Rated Operational Current DC-1 (Ie):
Rated Operational Current DC-3 (Ie):
Rated Operational Current DC-5 (Ie):
Rated Insulation Voltage (Ui):
Rated Impulse Withstand Voltage
(U
imp
):
Mechanical Durability:
Maximum Mechanical Switching
Frequency:
Coil Operating Limits:
Rated Control Circuit Voltage (Uc):
Coil Consumption:
Operate Time:
Connecting Capacity Main Circuit:
Connecting Capacity Auxiliary
Circuit:
Degree of Protection:
Terminal Type:
Number of Main Contacts NO:
Maximum Operating Altitude
Permissible:
RoHS Status:
Ambient Air Temperature:
General Use Rating UL/CSA:
Horsepower Rating UL/CSA:
Maximum Operating Voltage
UL/CSA:
Instructions and Manuals:
CB Certificate:
Data Sheet, Technical Information:
Declaration of Conformity - CE:
RINA Certificate:
RoHS Information:
at 40 °C Ambient Temp, in Free Air, from a Cold State 10 s 2120 A
at 40 °C Ambient Temp, in Free Air, from a Cold State 1 s 2650 A
at 40 °C Ambient Temp, in Free Air, from a Cold State 1 min 865 A
cos phi=0.45 (cos phi=0.35 for Ie > 100 A) at 440 V 3800 A
cos phi=0.45 (cos phi=0.35 for Ie > 100 A) at 690 V 3300 A
AC-3 300 cycles per hour
AC-1 300 cycles per hour
AC-2 / AC-4 150 cycles per hour
(110 V) 2 Poles in Series, 40 °C 350 A
(220 V) 3 Poles in Series, 40 °C 350 A
(110 V) 2 Poles in Series, 40 °C 350 A
(220 V) 3 Poles in Series, 40 °C 350 A
(110 V) 2 Poles in Series, 40 °C 350 A
(220 V) 3 Poles in Series, 40 °C 350 A
acc. to UL/CSA 600 V
acc. to IEC 60947-4-1 and VDE 0110 (Gr. C) 1000 V
Main Circuit 8 kV
5 million
300 cycles per hour
(acc. to IEC 60947-4-1) 0.85 x Uc Min. ... 1.1 x Uc Max. (at θ ≤ 70 °C) °C
60 Hz 100…250 V
50 Hz 100…250 V
DC Operation 100…250 V
Pull-in at Max. Rated Control Circuit Voltage 60 Hz 385 V·A
Holding at Max. Rated Control Circuit Voltage DC 4.5 W
Holding at Max. Rated Control Circuit Voltage 50 Hz 17.5 V·A
Pull-in at Max. Rated Control Circuit Voltage DC 410 W
Pull-in at Max. Rated Control Circuit Voltage 50 Hz 385 V·A
Holding at Max. Rated Control Circuit Voltage 60 Hz 17.5 V·A
Between Coil Energization and NO Contact Closing 25…55 ms
Between Coil De-energization and NO Contact Opening 37…47 ms
Rigid Al-Cable 1x185…240 mm²
Rigid Cu-Cable 2x70…185 mm²
Flexible 2x70…185 mm²
Solid 2x1…4 mm²
Flexible with Insulated Ferrule 2x0.75…2.5 mm²
Stranded 1x1…4 mm²
Flexible 2x0.75…2.5 mm²
Flexible with Ferrule 2x0.75…2.5 mm²
acc. to IEC 60529, IEC 60947-1, EN 60529 Coil Terminals IP20
acc. to IEC 60529, IEC 60947-1, EN 60529 Main Terminals IP00
Main Circuit: Bars
3
Environmental
3000 m
Following EU Directive 2002/95/EC August 18, 2005 and amendment
Close to Contactor Fitted with Thermal O/L Relay (0.85 ... 1.1 Uc) -25…+50 °C
Close to Contactor without Thermal O/L Relay (0.85 ... 1.1 Uc) -40…+70 °C
Close to Contactor for Storage -40…+70 °C
Technical UL/CSA
(600 V AC) 350 A
(208 V AC) Three Phase 75 Hp
(440 ... 480 V AC) Three Phase 200 Hp
(550 ... 600 V AC) Three Phase 250 Hp
(220 ... 240 V AC) Three Phase 100 Hp
(200 V AC) Three Phase 75 Hp
Main Circuit 600 V
Certificates and Declarations (Document Number)
1SFC100008M0201
SE-73042M1
1SFC101070D0201
2CMT004749
ELE060313XG/002
1SFC101055D0202
