PRODUCT-DETAILS
Minimum Order Quantity
E463/3SL
E463/3SL On-off switch
General Information
Extended Product Type
Product ID
EAN
Catalog Description
Long Description
ON-off switsch E463/3SL in grey with 63 A and 3-poles 250/400 VACDCPDC according
to DIN EN 60669-1, VDE 0632 Part 1
E463/3SL On-off switch
E463/3SL
2CCE160301R0131
7612270932535
Ordering
7612270932535 EAN
1 piece
85365000 Customs Tariff Number
Dimensions
44 mm Product Net Width
85 mm Product Net Height
68 mm Product Net Length
Length
70 mm Product Net Depth /
207.3 g Product Net Weight
Page 2
E463/3SL
2
Container Information
box 1 piece Package Level 1 Units
56 mm Package Level 1 Width
77 mm Package Level 1 Height
Length
Weight
92 mm Package Level 1 Depth /
230.6 g Package Level 1 Gross
7612270932535 Package Level 1 EAN
Environmental
Following EU Directive 2002/95/EC August 18, 2005 and amendment RoHS Status
Additional Information
IP20 Degree of Protection
3 Number of Poles
Code
On-off switch Product Name
)
n
Voltage
Circuit Breaking
Capacity (I
)
cs
)
r
Minimum 24 V Rated Voltage (U
EN60669-1 Standards
Q Object Classification
5.4 W Power Loss
E463 Product Main Type
63 A Rated Current (I
230/400 V Rated Operational
10 kA Rated Service Short-
20170426 RoHS Date
Certificates and Declarations (Document Number)
Information
Conformity - CE
Information
Manuals
2CCC441003C0101 Data Sheet, Technical
2CCY442101D0601 Declaration of
2CCC441003C0201 Environmental
2CCC441001C0201 Instructions and
2CCC413008D0206 RoHS Information
Classifications
EC001545 - Main switch for distribution board ETIM 4
EC001545 - Main switch for distribution board ETIM 5
EC001545 - Main switch for distribution board ETIM 6
EC001545 - Main switch for distribution board ETIM 7
Code
5. Small Equipment (No External Dimension More Than 50 cm) WEEE Category
Q Object Classification
Page 3
E463/3SL
Categories
Low Voltage Products and Systems → Modular DIN Rail Products → Command and Signalling Devices → Switch Disconnectors
