AAEON IMBI-QM57 User Manual

Industrial Motherboard IMBI-QM57

IMBI-QM57

Intel® Core

TM

i5/i7 Mobile Processor

Dual View VGA, DVI, HDMI, LVDS

Two 204-pin DDR3 800/1066 SODIMM

3 SATA2/ 1 PCI-Express[x4]/ 1 PCI

1 Mini PCI-Express

8 USB 2.0/ 3 RS-232/ 1 RS-232/422/485

IMBI-QM57 Manual Rev.A 3rd Ed.

December 2012

Industrial Motherboard IMBI-QM57

Copyright Notice

This document is copyrighted, 2012. All rights are reserved. The
original manufacturer reserves the right to make improvements to the
products described in this manual at any time without notice.

No part of this manual may be reproduced, copied, translated, or
transmitted in any form or by any means without the prior written
permission of the original manufacturer. Information provided in this
manual is intended to be accurate and reliable. However, the original
manufacturer assumes no responsibility for its use, or for any in­fringements upon the rights of third parties that may result from its
use.

The material in this document is for product information only and is
subject to change without notice. While reasonable efforts have been
made in the preparation of this document to assure its accuracy,
AAEON assumes no liabilities resulting from errors or omissions in
this document, or from the use of the information contained herein.

AAEON reserves the right to make changes in the product design
without notice to its users.

i

Industrial Motherboard IMBI-QM57

Acknowledgments

All other products’ name or trademarks are properties of their
respective owners.

 Award is a trademark of Award Software International, Inc.
 CompactFlash™ is a trademark of the Compact Flash

Association.

 Intel
 Microsoft Windows

 ITE is a trademark of Integrated Technology Express, Inc.
 IBM, PC/AT, PS/2, and VGA are trademarks of International

 SoundBlaster is a trademark of Creative Labs, Inc.

All other product names or trademarks are properties of their
respective owners.

®

, Core™ i5/i7 are trademarks of Intel® Corporation.

®

is a registered trademark of Microsoft Corp.

Business Machines Corporation.

ii

Industrial Motherboard IMBI-QM57

Packing List

Before you begin installing your card, please make sure that the
following materials have been shipped:

 1 IMBI-QM57 Mini-ITX Main Board
 1 SATA Signal Cable
 1 COM Port Cable with DB-9
 1 USB Cable
 1 I/O Shield
 1 CD-ROM for Manual (in PDF Format) and Drivers

If any of these items should be missing or damaged, please
contact your distributor or sales representative immediately.

iii

Industrial Motherboard IMBI-QM57

Contents

Chapter 1 General Information

1.1 Introduction................................................................ 1-2

1.2 Features....................................................................1-3

1.3 Specifications............................................................1-4

Chapter 2 Quick Installation Guide

2.1 Safety Precautions....................................................2-2

2.2 Location of Connectors and Jumpers ....................... 2-3

2.3 Mechanical Drawing..................................................2-5

2.4 List of Jumpers.......................................................... 2-7

2.5 List of Connectors ..................................................... 2-7

2.6 Setting Jumpers ........................................................ 2-9

2.7 CMOS Setting (CMOS1)......................................... 2-10

2.8 Auto PWRBTN Selection (JP1)...............................2-10

2.9 CFD Voltage 3.3V/5V Selection (JP2) .................... 2-10

2.10 TPM Setting (JP3)................................................. 2-10

2.11 LCD Power and Inverter Power Selection (JP4)... 2-10

2.12 COM1 +12V/+5V/RING Selection (JP5) ............... 2-11

2.13 COM2 +12V/+5V/RING Selection (JP6) ............... 2-11

2.14 Front Panel Connector (CN2) ............................... 2-11

2.15 SPI Programming Connector (CN3)...................... 2-11

2.16 LVDS Inverter (CN4)............................................. 2-12

2.17 LVDS Connector (CN5)......................................... 2-12

2.18 CD-IN Pin Header (CN6)....................................... 2-13

iv

Industrial Motherboard IMBI-QM57

2.19 COM1~2 Port LED Connector (CN8)....................2-13

2.20 COM3~4 Port LED Connector (CN9)....................2-13

2.21 LAN Port LED Connector (CN10) ......................... 2-14

2.22 RS-232/422/485 Pin Header (COM2)................... 2-14

2.23 RS-232 Pin Header (COM3~4)............................. 2-14

2.24 Pin Header (USB3, USB4).................................... 2-14

2.25 FAN Connector (FAN1, FAN2).............................. 2-15

2.26 4-pin ATX Power Connector (ATX1)..................... 2-15

2.27 24-pin ATX Power Connector (ATX2)...................2-15

2.28 SATA Connector (SATA 1~3) ............................... 2-15

2.29 Digital I/O Pin Header (DIO1)................................ 2-16

2.30 SATA Power Connector (PWR1)..........................2-16

Chapter 3 AMI BIOS Setup

3.1 System Test and Initialization. .................................. 3-2

3.2 AMI BIOS Setup........................................................3-3

Chapter 4 Driver Installation

4.1 Installation.................................................................4-3

Appendix A Programming The Watchdog Timer

A.1 Programming .........................................................A-2

A.2 ITE8781 Watchdog Timer Initial Program..............A-6

Appendix B I/O Information

B.1 I/O Address Map....................................................B-2

B.2 Memory Address Map............................................B-4

v

Industrial Motherboard IMBI-QM57

B.3 IRQ Mapping Chart................................................B-5

B.4 DMA Channel Assignments .................................B-5

Appendix C Mating Connector

C.1 List of Mating Connectors and Cables.................. C-2

Appendix D RAID & AHCI Settings

D.1 Setting RAID......................................................... D-2

D.2 Setting AHCI....................................................... D-12

vi

Industrial Motherboard IMBI-QM57

Chapter

1

Information

General

Chapter 1 General Information 1- 1

Industrial Motherboard IMBI-QM57

1.1 Introduction

The IMBI-QM57 supports Intel® CoreTM i5/i7 Mobile processor.
Moreover it supports DDR3 800/1066 memory up to 8GB. This
model accommodates two Intel
controllers that those are controlled by Intel

®

PCI-Express Gigabit Ethernet

®

82577LM and Intel®
82574L/82583V. This configuration provides outstanding
computing ability, fast network connections and multi-task data
transmission.

The graphic controller is integrated on Intel

®

Gen 6.0 that support
dual view with VGA, DVI, HDMI, and LVDS to meet the demand of
the media and high definition. In addition, IMBI-QM57 deploys 8
USB 2.0, 4 COMs, Keyboard & Mouse, and multiple extended bus
for a flexible expansion selection. The storage of IMBI-QM57
supports three SATA2 ports to support RAID 0, 1, 5, 10 function.

The IMBI-QM57 provides an ideal combination of high performance,
widely expandable interfaces and compact size that is easy to apply
for multiple applications. The IMBI-QM57 will be an ideal product
for your requirement.

Chapter 1 General Information 1- 2

Industrial Motherboard IMBI-QM57

1.2 Features

 Intel® 32/45nm Core™ i7/i5 rPGA988 CPU Integrated
 Graphics & Memory Controller
 Intel

®

QM57

 Dual-Channel DDR3 800/1066 Memory up to 8 GB
 Intel
 Intel

®

Gigabit Ethernet x 2 Support Intel® AMT 6.0

®

Gen 6.0 Integrated Graphics Engine Supports Dual

View With VGA, DVI, HDMI, LVDS

 HD Audio
 SATA2 x 3, RAID 0, 1, 5, 10
 USB 2.0 x 8, COM x 4
 PCI-Express [x4] x 1, Mini PCI-Express x 1, PCI x 1
 24-Pin ATX Power Connector

Chapter 1 General Information 1- 3

Industrial Motherboard IMBI-QM57

1.3 Specifications

System

 Form Factor Mini-ITX
 Processor Intel

®

32/45nm Core™ i5/i7

rPGA988 CPU, TDP: 35W Max.

 System Memory Supports Dual Channel with 2 x

204-pin DDR3 800/1066 SODIMM,
up to 8GB

 Chipset Intel
 Ethernet Intel

®

QM57

®

PCI-Express 10/100/
1000Base-TX, RJ-45 x 2
LAN1: Intel

®

Intel
LAN2: Intel

®

82577LM (supports

AMT 6.0);

®

82574L/82583V

 Audio HD Audio Codec with Realtek

ALC892

 BIOS AMI BIOS 64Mb SPI ROM
 I/O Chip ITE IT8781F I/O controller
 Storage SATA2 connector x 3,

support RAID 0,1,5,10 by riser
card

 DIO Programmable 8-bit digital I/O

interface (4 input/4 output)

 Watchdog Timer Reset: 1 sec.~255 min. and 1 sec.

Chapter 1 General Information 1- 4

Industrial Motherboard IMBI-QM57

or 1 min./step

 H/W Status Monitor Monitoring system temperature,

voltage, and cooling fan status

 Expansion Interface PCI-Express[x4] x 1, PCI x 1,

Mini PCI-Express x 1

 Power Requirement Standard ATX 24-pin connector
 Board Size (L x W) 6.7" x 6.7" (170 x 170 mm)
 Gross Weight 0.88 lb (0.4 Kg)
 Operating Temperature 32°F ~140°F (0°C ~60°C)
 Storage Temperature -4°F ~158°F (-20°C ~70°C)
 Storage Humidity 10~80%, non-condensing

Display



Chipset Intel

 Graphic Engine Intel

®

Core™ i5/i7

®

Gen 6.0 integrated
Graphics Engine

 Resolution Analog up to 2048x1536 @ 75

Hz; Flat panels up to 1920x1080
@ 60 Hz

 Output Interface VGA x 1, DVI-D x 1, HDMI x 1

(external), LVDS x 1 (internal)

I/O



Serial Port RS-232 x 1 (supports 5V/12V on

th

the 9

pin); RS-232/422/485 box

Chapter 1 General Information 1- 5

Industrial Motherboard IMBI-QM57

header x 3 support 5V/12V on the

th

9

pin

 Keyboard & Mouse Keyboard x 1 & Mouse x 1
 Universal Serial Bus USB 2.0 x 8 (four on the I/O side,

four with header)

 Audio Audio Jack x 3 with BTX Type

(Mic-in, Line-in, Line-out)

 Ethernet RJ-45 x 2
 Display VGA x 1, DVI-D x 1, HDMI x 1

(external), LVDS x 1 (internal)

Chapter 1 General Information 1- 6

Industrial Motherboard IMBI-QM57

Chapter

2

Installation

Quick

Guide

Chapter 2 Quick Installation Guide 2 - 1

Industrial Motherboard IMBI-QM57

2.1 Safety Precautions

Always completely disconnect the power cord
from your board whenever you are working on
it. Do not make connections while the power is
on, because a sudden rush of power can
damage sensitive electronic components.

Always ground yourself to remove any static
charge before touching the board. Modern
electronic devices are very sensitive to static
electric charges. Use a grounding wrist strap at
all times. Place all electronic components on a
static-dissipative surface or in a static-shielded
bag when they are not in the chassis

Chapter 2 Quick Installation Guide 2 - 2

Industrial Motherboard IMBI-QM57

2.2 Location of Connectors and Jumpers

Component Side

Chapter 2 Quick Installation Guide 2 - 3

Industrial Motherboard IMBI-QM57

Solder Side

Chapter 2 Quick Installation Guide 2 - 4

Industrial Motherboard IMBI-QM57

2.3 Mechanical Drawing

Component Side

Chapter 2 Quick Installation Guide 2 - 5

Industrial Motherboard IMBI-QM57

Solder Side

Chapter 2 Quick Installation Guide 2 - 6

Industrial Motherboard IMBI-QM57

2.4 List of Jumpers

The board has a number of jumpers that allow you to configure your
system to suit your application.

The table below shows the function of each of the board's jumpers:

Label Function

CMOS1 CMOS Setting Selection
JP1 Auto PWRBTN Selection
JP2 CFD Voltage 3.3V/5V Selection
JP3 TPM Setting Selection
JP4 LCD Power and Inverter Power Selection
JP5 COM1 +12V/+5V/RING Selection
JP6 COM2 +12V/+5V/RING Selection

2.5 List of Connectors

The board has a number of connectors that allow you to configure your
system to suit your application. The table below shows the function of
each board's connectors:

Label Function

CN1 DVI-I & COM Port Connector
CN2 Front Panel Connector
CN3 SPI Programming Connector
CN4 LCD Inverter Power Connector
CN5 LVDS Connector
CN6 CD-IN
CN8 COM1~2 Port LED
CN9 COM3~4 Port LED
CN10 LAN Port LED
COM2 RS-232/422/485 Pin header

Chapter 2 Quick Installation Guide 2 - 7

Industrial Motherboard IMBI-QM57

COM3~4 RS-232 Pin header
KM1 PS2 Keyboard/Mouse Connector

USB_LAN1

USB_LAN2
AUDIO1 Audio Lin-in/Lin-out/MIC

DIMM1,DIMM2 DDR3 DIMM Slot
USB3,USB4 USB Pin header
FAN1, FAN2 4-pin System Fan Connector
ATX1 4-pin AT X Power +12V Connector
ATX2 24-pin ATX Power
SATA1~SATA3 SATA Connector
DIO1 Digital I/O
PIC1 PCI Slot
PCIE1 PCIE Slot
CN11 Mini-PCIE Slot
PWR1 SATA Power Connector

100/1000Base-TX Ethernet & Dual USB
Connector

100/1000Base-TX Ethernet & Dual USB
Connector

Chapter 2 Quick Installation Guide 2 - 8

Industrial Motherboard IMBI-QM57

2.6 Setting Jumpers

You configure your card to match the needs of your application by
setting jumpers. A jumper is the simplest kind of electric switch. It
consists of two metal pins and a small metal clip (often protected by a
plastic cover) that slides over the pins to connect them. To “close” a
jumper you connect the pins with the clip.

To “open” a jumper you remove the clip. Sometimes a jumper will have
three pins, labeled 1, 2 and 3. In this case you would connect either
pins 1 and 2 or 2 and 3.

3

2

1

Open Closed Closed 2-3

A pair of needle-nose pliers may be helpful when working with jumpers.
If you have any doubts about the best hardware configuration for your

application, contact your local distributor or sales representative before
you make any change.

Generally, you simply need a standard cable to make most
connections.

Chapter 2 Quick Installation Guide 2 - 9

Industrial Motherboard IMBI-QM57

2.7 CMOS Setting (CMOS1)

JP1 Function

1-2 Normal (Default)
2-3 Clear CMOS

2.8 Auto PWRBTN Selection (JP1)

JP1 Function

1-2 Don’t use Auto PWRBTN (Default)
2-3 Use Auto PWRBTN

2.9 CFD Voltage 3.3V/5V Selection (JP2)

JP2 Function

1-2 +3.3V
2-3 +5V (Default)

2.10 TPM Setting (JP3)

JP3 Function

1-2 Save ME RTC Register (Default)
2-3 Clear ME RTC Register

2.11 LCD Power and Inverter Power Selection (JP4)

JP4 Function

1-3 Inverter Power +5V (Default)
3-5 Inverter Power +12V
4-6 LCD Power +3.3V (Default)
2-4 LCD Power +5V

Chapter 2 Quick Installation Guide 2 - 10

Industrial Motherboard IMBI-QM57

2.12 COM1 +12V/+5V/RING Selection (JP5)

JP5 Function

1-2 +12V
3-4 Ring (Default)
5-6 +5V

2.13 COM2 +12V/+5V/RING Selection (JP6)

JP6 Function

1-2 +12V
3-4 Ring (Default)
5-6 +5V

2.14 Front Panel Connector (CN2)

Pin Signal Pin Signal

1 Power On Button (-) 2 Power On Button (+)
3 HDD LED(-) 4 HDD LED(+)
5 External Speaker (-) 6 External Speaker (+)
7 Power LED (-) 8 Power LED (+)
9 Reset Switch (-) 10 Reset Switch (+)

2.15 SPI Programming Connector (CN3)

Pin Signal Pin Signal

1 +3.3V_SPI 2 GND
3 SPI_CE# 4 SPI_CLK
5 SPI_SO 6 SPI_SI
7 NC 8 NC

Chapter 2 Quick Installation Guide 2 - 11

Industrial Motherboard IMBI-QM57

2.16 LVDS Inverter (CN4)

Pin Signal

1 12V / 5V
2 VCON
3 GND
4 GND
5 INV_EN

2.17 LVDS Connector (CN5)

Pin Signal Pin Signal

1 BKL_EN 2 N.C.
3 VLCD 4 GND
5 LA_CLK# 6 LA_CLK
7 VLCD 8 GND
9 LA_DATA0# 10 LA_DATA0
11 LA_DATA1# 12 LA_DATA1
13 LA_DATA2# 14 LA_DATA2
15 LA_DATA3# 16 LA_DATA3
17 LVDS_DDC_DATA 18 LVDS_DDC_CLK
19 LB_DATA0# 20 LB_DATA0
21 LB_DATA1# 22 LB_DATA1
23 LB_DATA2# 24 LB_DATA2
25 LB_DATA3# 26 LB_DATA3
27 VLCD 28 GND
29 LB_CLK# 30 LB_CLK

Chapter 2 Quick Installation Guide 2 - 12

Industrial Motherboard IMBI-QM57

2.18 CD-IN Pin Header (CN6)

Pin Signal

1 CD-R
2 CD-GND
3 CD-GND
4 CD-L

2.19 COM1~2 Port LED Connector (CN8)

Pin Signal Pin Signal

1 COM1_RS232_PWR 2 GND
3 TX_LED_COM1 4 GND
5 RX_LED_COM1 6 GND
7 COM2_RS232_PWR 8 GND
9 TX_LED_COM2 10 GND
11 RX_LED_COM2 12 GND
13 COM2_RS485_PWR 14 COM2_RS422_PWR

2.20 COM3~4 Port LED Connector (CN9)

Pin Signal Pin Signal

1 COM3_RS232_PWR 2 GND
3 TX_LED_COM3 4 GND
5 RX_LED_COM3 6 GND
7 COM4_RS232_PWR 8 GND
9 TX_LED_COM4 10 GND
11 RX_LED_COM4 12 GND

Chapter 2 Quick Installation Guide 2 - 13

Industrial Motherboard IMBI-QM57

2.21 LAN Port LED Connector (CN10)

Pin Signal Pin Signal

1 LAN1_LED_D2 2 LAN1_LED_LNK#_ACT
3 LAN1_LED_1000# 4 LAN1_LED_100#
5 LAN2_LED_D2 6 ACT_2_LED
7 SPD1K_2_LED 8 SPD100_2_LED

2.22 RS-232/422/485 Pin Header (COM2)

Pin Signal Pin Signal

1 DCD 2 RXD
3 TXD 4 DTR
5 GND 6 DSR
7 RTS 8 CTS
9 RI

2.23 RS-232 Pin Header (COM3~4)

Pin Signal Pin Signal

1 DCD 2 RXD
3 TXD 4 DTR
5 GND 6 DSR
7 RTS 8 CTS
9 RI

2.24 Pin Header (USB3, USB4)

Pin Signal Pin Signal

1 +5V 2 GND
3 USBD1- 4 GND
5 USBD1+ 6 USBD2+
7 GND 8 USBD2-

Chapter 2 Quick Installation Guide 2 - 14

Industrial Motherboard IMBI-QM57

9 GND 10 +5V

2.25 FAN Connector (FAN1, FAN2)

Pin Signal Pin Signal

1 GND 2 +12V
3 FAN_TAC 4 FAN_CTL

2.26 4-pin ATX Power Connector (ATX1)

Pin Signal Pin Signal

1 GND 2 GND
3 +12V 4 +12V

2.27 24-pin ATX Power Connector (ATX2)

Pin Signal Pin Signal

1 +3.3V 2 +3.3V
3 GND 4 +5V
5 GND 6 +5V
7 GND 8 PWROK
9 +5VSB 10 +12V
11 +12V 12 +3.3V
13 +3.3V 14 -12V
15 GND 16 PS_ON
17 GND 18 GND
19 GND 20 NC
21 +5V 22 +5V
23 +5V 24 GND

2.28 SATA Connector (SATA 1~3)

Pin Signal Pin Signal

1 GND 2 TXP

Chapter 2 Quick Installation Guide 2 - 15

Industrial Motherboard IMBI-QM57

3 TXN 4 GND
5 RXN 6 RXP
7 GND

2.29 Digital I/O Pin Header (DIO1)

The Base Address are A40H, A42H, and A43H

Pin Signal Pin Signal

1 IN0 (U5 Pin34) 2 IN1 (U5 Pin33)
3 IN2 (U5 Pin32) 4 IN3 (U5 Pin31)
5 OUT0 (U5 Pin12) 6 OUT1 (U5 Pin11)
7 OUT2 (U5 Pin70) 8 OUT3 (U5 Pin66)
9 +5V 10 GND

BIOS
Setting

DIO_P#1 BC3 Pin 1 Bit 1(A40H) U5 Pin 34 (GPIO11)
DIO_P#2 BC3 Pin 2 Bit 2(A40H) U5 Pin 33 (GPIO12)
DIO_P#3 BC3 Pin 3 Bit 3(A40H) U5 Pin 32 (GPIO13)
DIO_P#4 BC3 Pin 4 Bit 4(A40H) U5 Pin 31 (GPIO14)
DIO_P#5 BC3 Pin 5 Bit 6(A42H) U5 Pin 12 (GPIO36)
DIO_P#6 BC3 Pin 6 Bit 7(A42H) U5 Pin 11 (GPIO37)
DIO_P#7 BC3 Pin 7 Bit 6(A43H) U5 Pin 70 (GPIO46)
DIO_P#8 BC3 Pin 8 Bit 7(A43H) U5 Pin 66 (GPIO47)

Note:

1. DIO_P#1, DIO_P#2, DIO_P#3, DIO_P#4 use Base Address: A40H

2. DIO_P#5, DIO_P#6 use Base Address: A42H

3. DIO_P#7, DIO_P#8 use Base Address: A43H

Connector
Definition

Address IT8781F GPIO Setting

2.30 SATA Power Connector (PWR1)

Pin Signal Pin Signal

1 +12V 2 GND
3 GND 4 +5V

Chapter 2 Quick Installation Guide 2 - 16

Industrial Motherboard IMBI-QM57

Below Table for China RoHS Requirements

产品中有毒有害物质或元素名称及含量

AAEON Main Board/ Daughter Board/ Backplane

有毒有害物质或元素

部件名称

铅

(Pb)汞 (Hg)镉 (Cd)

六价铬

(Cr(VI))

多溴联苯

(PBB)

多溴二苯醚

(PBDE)

印刷电路板

× ○ ○ ○ ○ ○

及其电子组件

外部信号

× ○ ○ ○ ○ ○

连接器及线材

O：表示该有毒有害物质在该部件所有均质材料中的含量均在

SJ/T 11363-2006 标准规定的限量要求以下。

X：表示该有毒有害物质至少在该部件的某一均质材料中的含量超出

SJ/T 11363-2006 标准规定的限量要求。

备注：此产品所标示之环保使用期限，系指在一般正常使用状况下。

Chapter 2 Quick Installation Guide 2 - 17

Industrial Motherboard IMBI-QM57

BIOS Setup

Chapter

3

AMI

Chapter 3 AMI BIOS Setup 3-1

Industrial Motherboard IMBI-QM57

3.1 System Test and Initialization

These routines test and initialize board hardware. If the routines
encounter an error during the tests, you will either hear a few short
beeps or see an error message on the screen. There are two kinds
of errors: fatal and non-fatal. The system can usually continue the
boot up sequence with non-fatal errors.
System configuration verification

These routines check the current system configuration against the
values stored in the CMOS memory. If they do not match, the
program outputs an error message. You will then need to run the
BIOS setup program to set the configuration information in memory.

There are three situations in which you will need to change the
CMOS settings:

1. You are starting your system for the first time

2. You have changed the hardware attached to your system

3. The CMOS memory has lost power and the configuration
information has been erased.

The IMBI-QM57 CMOS memory has an integral lithium battery
backup for data retention. However, you will need to replace the
complete unit when it finally runs down.

Chapter 3 AMI BIOS Setup 3-2

Industrial Motherboard IMBI-QM57

3.2 AMI BIOS Setup

AMI BIOS ROM has a built-in Setup program that allows users to
modify the basic system configuration. This type of information is
stored in battery-backed CMOS RAM so that it retains the Setup
information when the power is turned off.

Entering Setup

Power on the computer and press <Del> or <F2> immediately. This
will allow you to enter Setup.

Main

Set the date, use tab to switch between date elements.

Advanced

Enable disable boot option for legacy network devices.

Chipset

Host bridge parameters.

Boot

Enables/disable quiet boot option.

Security

Set setup administrator password.

Save&Exit

Exit system setup after saving the changes.

Chapter 3 AMI BIOS Setup 3-3

Industrial Motherboard IMBI-QM57

Chapter

4

Installation

Driver

Chapter 4 Driver Installation 4-1

Industrial Motherboard IMBI-QM57

The IMBI-QM57 comes with a CD-ROM that contains all drivers
your need.

Follow the sequence below to install the drivers:

Step 1 – Install INF Driver
Step 2 – Install VGA Driver
Step 3 – Install LAN Driver
Step 4 – Install AUDIO Driver
Step 5 – Install ME Driver
Step 6 – Install RAID Driver

Please read following instructions for detailed installations.

Chapter 4 Driver Installation 4-2

Industrial Motherboard IMBI-QM57

4.1 Installation:

Insert the IMBI-QM57 CD-ROM into the CD-ROM Drive. And install
the drivers from Step 1 to Step 6 in order.

Step 1 – Install INF Driver

1. Click on the Step1 - INF folder and then double click on the

Setup.exe

2. Follow the instructions that the window shows

3. The system will help you to install the driver automatically

Step 2 – Install VGA Driver

1. Click on the Step2 - VGA folder and select the OS your
system is

2. Double click on Setup.exe file located in each OS folder

3. Follow the instructions that the window shows

4. The system will help you to install the driver automatically

Step 3 – Install LAN Driver

1. Click on the Step3 - LAN folder and double click on

Autorun.exe file

2. Follow the instructions that the window shows

3. The system will help you to install the driver automatically

Step 4 – Install AUDIO Driver

1. Click on the Step4 - AUDIO folder and select the OS your

system is

2. Double click on .exe file located in each OS folder

Chapter4 Drivers Installation 4-3

Industrial Motherboard IMBI-QM57

3. Follow the instructions that the window shows

4. The system will help you to install the driver automatically

Step 5 – Install ME Driver

1. Click on the Step5 - ME folder and double click on

Setup.exe file

2. Follow the instructions that the window shows

3. The system will help you to install the driver automatically

Step 6 – Install RAID Driver

Please refer to Appendix D RAID & AHCI Settings

Chapter 4 Driver Installation 4-4

Industrial Motherboard IMBI-QM57

A

Appendix

Programming the

Watchdog Timer

Appendix A Programming the Watchdog Timer A-1

Industrial Motherboard IMBI-QM57

A.1 Programming

IMBI-QM57 utilizes ITE 8781 chipset as its watchdog
timer controller. Below are the procedures to complete its
configuration and the AAEON initial watchdog timer
program is also attached based on which you can
develop customized program to fit your application.

Configuring Sequence Description

After the hardware reset or power-on reset, the ITE 8781 enters the
normal mode with all logical devices disabled except
KBC. The initial state (enable bit ) of this logical device (KBC) is
determined by the state of pin 121 (DTR1#) at the falling edge of
the system reset during power-on reset.

Appendix A Programming the Watchdog Timer A-2

Industrial Motherboard IMBI-QM57

There are three steps to complete the configuration setup: (1) Enter
the MB PnP Mode; (2) Modify the data of configuration re gisters; (3)
Exit the MB PnP Mode. Undesired result may occur if the MB PnP
Mode is not exited normally.

(1) Enter the MB PnP Mode

To enter the MB PnP Mode, four special I/O write operations are to
be performed during Wait for Key st ate. To ensure the initial state of
the key-check logic, it is necessary to p erform four write opera-tio ns
to the Special Address port (2EH). Two different enter keys are
provided to select configuration ports (2Eh/2Fh) of the next step.

(2) Modify the Data of the Regist ers

All configuration registers can be accessed after entering the MB
PnP Mode. Before accessing a selected register, the content of
Index 07h must be changed to the LDN to which the register
belongs, except some Global registers.

(3) Exit the MB PnP Mode

Set bit 1 of the configure control register (Index=02h) to 1 to exit the
MB PnP Mode.

Appendix A Programming the Watchdog Timer A-3

Industrial Motherboard IMBI-QM57

WatchDog Ti mer Configuration Registers

Configure Control (Index=02h)

This register is write only. Its values are not sticky; that is to say, a
hardware reset will automatically clear the bits, and does not
require the software to clear them.

Watch Dog Timer 1, 2, 3 Control Register (Index=71h,81h,91h
Default=00h)

Appendix A Programming the Watchdog Timer A-4

Industrial Motherboard IMBI-QM57

Watch Dog Timer 1, 2, 3 Configuration Register (Index=72h,
82h, 92h Default=001s0000b)

Watch Dog Timer 1,2,3 Time-Out Value (LSB) Register
(Index=73h,83h,93h, Default=38h)

Watch Dog Timer 1,2,3 Time-Out Value (MSB) Register
(Index=74h,84h,94h Default=00h)

Appendix A Programming the Watchdog Timer A-5

Industrial Motherboard IMBI-QM57

A.2 ITE8781 Watchdog Timer Initial Program

.MODEL SMALL
.CODE
Main:
CALL Enter_Configuration_mode
CALL Check_Chip
mov cl, 7
call Set_Logic_Device
;time setting
mov cl, 10 ; 10 Sec
dec al
Watch_Dog_Setting:
;Timer setting
mov al, cl
mov cl, 73h
call Superio_Set_Reg
;Clear by keyboard or mouse interrupt
mov al, 0f0h
mov cl, 71h
call Superio_Set_Reg
;unit is second.
mov al, 0C0H
mov cl, 72h

Appendix A Programming the Watchdog Timer A-6

Industrial Motherboard IMBI-QM57

call Superio_Set_Reg
; game port enable
mov cl, 9
call Set_Logic_Device

Initial_OK:
CALL Exit_Configuration_mode
MOV AH,4Ch
INT 21h

Enter_Configuration_Mode PROC NEAR
MOV SI,WORD PTR CS:[Offset Cfg_Port]

MOV DX,02Eh
MOV CX,04h
Init_1:
MOV AL,BYTE PTR CS:[SI]
OUT DX,AL
INC SI
LOOP Init_1
RET
Enter_Configuration_Mode ENDP

Exit_Configuration_Mode PROC NEAR
MOV AX,0202h

Appendix A Programming the Watchdog Timer A-7

Industrial Motherboard IMBI-QM57

CALL Write_Configuratio n_Data
RET
Exit_Configuration_Mode ENDP

Check_Chip PROC NEAR

MOV AL,20h
CALL Read_Configuration_Data
CMP AL,87h
JNE Not_Initial

MOV AL,21h
CALL Read_Configuration_Data
CMP AL,81h
JNE Not_Initial

Need_Initial:
STC
RET
Not_Initial:
CLC
RET
Check_Chip ENDP
Read_Configuration_Data PROC NEAR
MOV DX,WORD PTR CS:[Cfg_Port+04h]

Appendix A Programming the Watchdog Timer A-8

Industrial Motherboard IMBI-QM57

OUT DX,AL
MOV DX,WORD PTR CS:[Cfg_Port+06h]
IN AL,DX
RET
Read_Configuration_Data ENDP

Write_Configuration_Data PROC NEAR
MOV DX,WORD PTR CS:[Cfg_Port+04h]
OUT DX,AL
XCHG AL,AH
MOV DX,WORD PTR CS:[Cfg_Port+06h]
OUT DX,AL
RET
Write_Configuration_Data ENDP

Superio_Set_Reg proc near
push ax
MOV DX,WORD PTR CS:[Cfg_Port+04h]
mov al,cl
out dx,al
pop ax
inc dx
out dx,al
ret
Superio_Set_Reg endp.Set_Logic_Device proc near

Appendix A Programming the Watchdog Timer A-9

Industrial Motherboard IMBI-QM57

Set_Logic_Device proc near
push ax
push cx
xchg al,cl
mov cl,07h
call Superio_Set_Reg
pop cx
pop ax
ret
Set_Logic_Device endp

;Select 02Eh->Index Port, 02Fh->Data Port
Cfg_Port DB 087h,001h,055h,055h
DW 02Eh,02Fh

END Main

Note: Interrupt level mapping
0Fh-Dh: not valid
0Ch: IRQ12
.
.
03h: IRQ3
02h: not valid
01h: IRQ1
00h: no interrupt selected

Appendix A Programming the Watchdog Timer A-10

Industrial Motherboard IMBI-QM57

Appendix

B

I/O Information

Appendix B I/O Information B-1

Industrial Motherboard IMBI-QM57

B.1 I/O Address Map

Appendix B I/O Information B-2

Industrial Motherboard IMBI-QM57

Appendix B I/O Information B-3

Industrial Motherboard IMBI-QM57

st

MB Memory Address Map

B.2 1

Appendix B I/O Information B-4

Industrial Motherboard IMBI-QM57

B.3 IRQ Mapping Chart

B.4 DMA Channel Assignments

Appendix B I/O Information B-5

Industrial Motherboard IMBI-QM57

Appendix

C

Mating Connector

Appendix C Mating Connector C - 1

Industrial Motherboard IMBI-QM57

C.1 List of Mating Connectors and Cables

The table notes mating connectors and available cables.

Connector

Label

Function

Mating Connector

Vendor Model no

Available

Cable

Cable P/N

SATA1 SATA

Connector

SATA2 SATA

Connector

SATA3 SATA

Connector

COM2 Serial Port

Box Header

COM3 Serial Port

Box Header

COM4 Serial Port

Box Header

USB3 USB Pin

Header

USB4 USB Pin

Header

DIO1 Digital I/O Box

Header

FAN1 FAN

Connector

FAN2 FAN

Connector

ATX1 4P Power

Connnector

ATX2 24P Power

Connector

LAN1 Ethernet

Connector

LAN2 Ethernet

Connector

TECHBEST 161S01-0

TECHBEST 161S01-0

TECHBEST 161S01-0

Catch
Electronics

Catch
Electronics

Catch
Electronics
Catch
Electronics
Catch
Electronics
Catch
Electronics
Catch
Electronics
Catch
Electronics
Catch
Electronics
Catch
Electronics
FOXCONN JFM38U1

FOXCONN JFM38U1

25A

25A

25A
1147-000-

10S
1147-000-

10MP
1147-000-

10MP
1147-000­10MSP
1147-000­10MSP
1147-000­10MSP
1190-700­042
1190-700­042
1121-700­04S
1121-700­24S

B-21U5-4
F

B-21U5-4
F

SATA
Cable

SATA
Cable

SATA
Cable

Serial Port
Cable

Serial Port
Cable

Serial Port
Cable
USB
Cable
USB
Cable
N/A N/A

N/A N/A
N/A N/A
N/A N/A
N/A N/A
N/A N/A

N/A N/A

1709070800

1709070800

1709070800

1701100305

170110030A

170110030A
1709100201
1709100201

Appendix C Mating Connector C - 2

Industrial Motherboard IMBI-QM57

KM1 Mini-Din PS/2

KB/MS Pin
Header

PWR1 WAFER.4P

Connector

CN1 COM1+DVI

Connector

CN2 Front Panel

Connector

CN4 LVDS Inverter

Connector

CN5 LVDS

Connector

CN6 CD-I 2.54mm

4Pin Header

CN7 CRT+HDMI

Connector

CN8 COM1~2_LED

Connector

CN9 COM3-4_LED

Connector

CN10 LAN_LED

Connector

Foxconn MH11061-

N/A N/A

P36-4F
HO-BASE P201-04 N/A N/A
TechBast

Electronics
Astron
Electronics

D205D1B

01012PN

27-24041-

205-1G-T

N/A N/A
N/A N/A

B1-R
Catch
Electronics
E-call 0110-01-5

1192-700-

05S

N/A N/A
N/A N/A

53-300
N/A N/A N/A N/A

TechBast
Electronics

D211HA3

101012P

N/A N/A

N
Astron
Electronics

26-4304-2

07-1G-TB

N/A N/A

1-R
Astron
Electronics

26-4304-2

06-1G-TB

N/A N/A

1-R
Astron
Electronics

26-4304-2

04-1G-TB

N/A N/A

1-R

Appendix C Mating Connector C - 3

Industrial Motherboard IMBI-QM57

A ppendix

D

RAID & AHCI

Settings

Appendix D RAID & AHCI Settings D-1

Industrial Motherboard IMBI-QM57

D.1 Setting RAID

OS installation to setup RAID Mode
Step 1: Copy the files below from “Driver CD -> Raid Driver -> F6 Floppy -
x86” to Disk

Step 2: Connect the USB Floppy (disk with RAID files) to the board

Appendix D RAID & AHCI Settings D-2

Industrial Motherboard IMBI-QM57

Step 3: The setting procedures “ In BIOS Setup Menu”
A: Advanced -> SATA Configuration -> SATA Mode -> RAID Mode

Step 4: The setting procedures “In BIOS Setup Menu”
B: Advanced -> Launch Storage OpROM -> Enabled

Appendix D RAID & AHCI Settings D-3

Industrial Motherboard IMBI-QM57

Step 5: The setting procedures “In BIOS Setup Menu”
C: Boot -> Boot Option #1 -> DVD-ROM Type

Step 6: The setting procedures “In BIOS Setup Menu”
D: Save & Exit -> Save Changes and Exit

Appendix D RAID & AHCI Settings D-4

Industrial Motherboard IMBI-QM57

Step 7: Press Ctrl-I to enter MAIN MENU

Step 8: Choose “1.Create RAID Volume”

Appendix D RAID & AHCI Settings D-5

Industrial Motherboard IMBI-QM57

Step 9: RAID Level -> RAID0(Stripe)

Step 10: Choose “Create Volume”

Appendix D RAID & AHCI Settings D-6

Industrial Motherboard IMBI-QM57

Step 11: Choose “Y”

Step 12: Choose “5. Exit”

Appendix D RAID & AHCI Settings D-7

Industrial Motherboard IMBI-QM57

Step 13: Choose “Y”

Step 14: Setup OS

Appendix D RAID & AHCI Settings D-8

Industrial Motherboard IMBI-QM57

Step 15: Press “F6”

Step 16: Choose “S”

Appendix D RAID & AHCI Settings D-9

Industrial Motherboard IMBI-QM57

Step 17: Choose “Intel(R) ICH8M-E/ICH9M-E/5 Series SATA RAID
Controller”

Step 18: It will show the model number you select and then press “ENTER”

Appendix D RAID & AHCI Settings D-10

Industrial Motherboard IMBI-QM57

Step 19: Setup is starting Windows

Appendix D RAID & AHCI Settings D-11

Industrial Motherboard IMBI-QM57

D.2 Setting AHCI

OS installation to setup AHCI Mode
Step 1: Copy the files below from “Driver CD -> Raid Driver -> F6 Floppy -

x86” to Disk

Step 2: Connect the USB Floppy (disk with RAID files) to the board

Appendix D RAID & AHCI Settings D-12

Industrial Motherboard IMBI-QM57

Step 3: The setting procedures “ In BIOS Setup Menu”
A: Advanced -> SATA Configuration -> SATA Configuration -> SATA
Mode -> AHCI Mode

Step 4: The setting procedures “In BIOS Setup Menu”
B: Boot -> Boot Option #1 -> DVD-ROM Type

Appendix D RAID & AHCI Settings D-13

Industrial Motherboard IMBI-QM57

Step 5: The setting procedures “In BIOS Setup Menu”
C: Save & Exit -> Save Changes and Exit

Step 6: Setup OS

Appendix D RAID & AHCI Settings D-14

Industrial Motherboard IMBI-QM57

Step 7: Press “F6”

Step 8: Choose “S”

Appendix D RAID & AHCI Settings D-15

Industrial Motherboard IMBI-QM57

Step 9: Choose “Intel(R) 5 Series 6 Port SATA AHCI Controller”

Step 10: It will show the model number you select and then press “ENTER”

Appendix D RAID & AHCI Settings D-16

Industrial Motherboard IMBI-QM57

Step 11: Setup is loading files

Appendix D RAID & AHCI Settings D-17
