Mini-ITX EMB-945T Rev.B
EMB-945T Rev.B
Intel® CoreTM 2 Duo (Merom)/
TM
Core
6CH AC 97 Audio & Mini PCI
Duo/ Celeron® M (Yonah)
Processor,
Up to 2.16 GHz
Mini-ITX
Intel 82573L Ethernet
EMB-945T Manual Rev.B 3rd Ed.
Mar. 2008
Mini-ITX EMB-945T Rev.B
Copyright Notice
This document is copyrighted, 2008. All rights are reserved.
The original manufacturer reserves the right to make
improvements to the products described in this manual at any
time without notice.
No part of this manual may be reproduced, copied, translated,
or transmitted in any form or by any means without the prior
written permission of the original manufacturer. Information
provided in this manual is intended to be accurate and reliable.
However, the original manufacturer assumes no responsibility
for its use, or for any infringements upon the rights of third
parties that may result from its use.
The material in this document is for product information only
and is subject to change without notice. While reasonable
efforts have been made in the preparation of this document to
assure its accuracy, AAEON assumes no liabilities resulting
from errors or omissions in this document, or from the use of
the information contained herein.
AAEON reserves the right to make changes in the product
design without notice to its users.
i
Mini-ITX EMB-945T Rev.B
Acknowledgments
All other products’ name or trademarks are properties of their
respective owners.
Award is a trademark of Award Software International, Inc.
CompactFlash
™ is a trademark of the Compact Flash
Association.
Intel
Microsoft Windows
®
, CoreTM 2 Duo/ CoreTM Duo/ CoreTM Solo and Celeron®
M are trademarks of Intel
®
®
Corporation.
is a registered trademark of Microsoft
Corp.
ITE is a trademark of Integrated Technology Express, Inc.
IBM, PC/AT, PS/2, and VGA are trademarks of International
Business Machines Corporation.
SoundBlaster is a trademark of Creative Labs, Inc.
Please be notified that all other products’ name or trademarks
not be mentioned above are properties of their respective
owners.
ii
Mini-ITX EMB-945T Rev.B
Packing List
Before you begin installing your card, please make sure that
the following materials have been shipped:
1 1701440050 44-pin ATA33 Cable
1 1709070500 Serial ATA Cable
1 1702150150 Serial ATA Power Cable
1 9657666600 Jumper Cap
1 Quick Installation Guide
1 Utility CD
1 EMB-945T Rev.B
If any of these items should be missing or damaged, please
contact your distributor or sales representative immediately.
iii
Mini-ITX EMB-945T Rev.B
Contents
Chapter 1 General Information
1.1 Introduction................................................................ 1-2
1.2 Features....................................................................1-3
1.3 Specifications............................................................1-4
Chapter 2 Quick Installation Guide
2.1 Safety Precautions ..................................................2-2
2.2 Location of Connectors and Jumpers ...................... 2-3
2.3 Mechanical Drawing ................................................2-5
2.4 List of Jumpers ........................................................2-7
2.5 List of Connectors .....................................................2-8
2.6 Setting Jumpers .....................................................2-10
2.7 LVDS (1)-LCD (CN12) Voltage Selection (JP1)...... 2-11
2.8 LVDS (2)-LCD (CN10) Voltage Selection (JP2)...... 2-11
2.9 COM2 Ring/+5V/+12V Selection (JP3)................... 2-11
2.10 LCD INVERTER Voltage Selection (JP4).............2-11
2.11 Clear CMOS (JP6) ................................................ 2-11
2.12 CD-IN Connector (CN1)........................................2-12
2.13 Digital I/O Connector (CN2).................................. 2-12
2.14 TV-Out Connector (CN3) ...................................... 2-13
2.15 Internal Keyboard Connector (CN4)......................2-13
2.16 Fan2 Connector (CN5).......................................... 2-13
2.17 Audio 5.1 Channel / SPDIF Connector (CN6) ..... 2-14
iv
Mini-ITX EMB-945T Rev.B
2.18 Internal Mouse Connector (CN7)..........................2-14
2.19 LCD Inverter Connector (CN8) ............................2-14
2.20 LVDS (2)-LCD Connector (CN10).........................2-14
2.21 DVI Connector (CN11) ........................................2-15
2.22 LVDS (1)-LCD Connector (CN12).........................2-16
2.23 COM6 RS-232 Serial Port Connector (CN13) ......2-16
2.24 COM3 RS-232 Serial Port Connector (CN14) ......2-16
2.25 Fan1 Connector (CN15)........................................ 2-17
2.26 COM5 RS-232 Serial Port Connector (CN16) ......2-17
2.27 COM4 RS-232 Serial Port Connector (CN17)…….2-17
2.28 IrDA Port Connector (CN18).................................2-18
2.29 ATX Power Connector(CN19)...............................2-18
2.30 USB Connector (CN20)......................................... 2-18
2.31 USB Connector (CN21)......................................... 2-19
2.32 EIDE Connector (CN22)........................................ 2-19
2.33 Front Panel Connector (CN23) ............................. 2-20
2.34 PCI-Express Slot (CN25) ...................................... 2-20
2.35 Audio Speaker Output Connector (CN26) ............2-22
2.36 COM2 RS-232/422/485 Serial Port Connector
(PCON1)........................................................................ 2-22
Chapter 3 Award BIOS Setup
3.1 System Test and Initialization. .................................. 3-2
3.2 Award BIOS Setup....................................................3-3
v
Mini-ITX EMB-945T Rev.B
Chapter 4 Driver Installation
4.1 Installation……………………………………………..4-3
Appendix A Programming The Watchdog Timer
A.1 Programming .........................................................A-2
A.2 ITE 8712 Watchdog Timer Initial Program.............A-6
Appendix B I/O Information
B.1 I/O Address Map....................................................B-2
B.2 Memory Address Map............................................B-3
B.3 IRQ Mapping Chart................................................B-4
B.4 DMA Channel Assignments.……………………….B-4
Appendix C Mating Connector
C.1 List of Mating Connectors and Cables.................. C-2
vi
Mini-ITX EMB-945T Rev.B
Chapter
1
General
Information
Chapter 1 General Information 1- 1
Mini-ITX EMB-945T Rev.B
1.1 Introduction
The EMB-945T Rev.B adopts the latest Intel® Core™ 2 Duo
(Merom)/ Core™ Duo/ Core™ Solo/ Celeron
processors and Mobile Intel
®
945GM Express chipset for better
®
M (Yonah)
power-management capabilities and enhanced performance.
EMB-945T Rev.B with mobile-optimized Intel dual-core
processors is the latest embedded motherboard designed to
cope with increasingly heavily work-loaded embedded systems
found in POS (Point-of-Sale) machines, automated kiosks,
medical instruments, advanced automation for buildings and
homes, and gaming machines.
The EMB-945T Rev.B features one PCI slot, one PCI-E slot,
one Mini PCI slot, six COM ports, six USB 2.0 ports, multiple
Digital I/O ports, and Type II CFD storage, providing versatile
expansion options for many embedded applications.
The Front Side Bus of EMB-945T Rev.B is up to 667MHz and
graphic performance has been enhanced from 20 to 30%. In
addition, the EMB-945T Rev.B supports DX9L appropriate to
the DirectX and LVD/iDCT MPEG2 Hardware Decode.
Chapter 1 General Information 1-2
Mini-ITX EMB-945T Rev.B
1.2 Features
• Socket 478 or Onboard Intel® Core™ 2 Duo (Merom)/
Core™ Duo/ Core™ Solo/ Celeron M (Yonah)
Processors up to 2.0 GHz
• Two SODIMM Slots Support DDRII Memory up to
4GB
• Up to 24-bit Dual-channel LVDS LCD, Shared
Memory up to 224MB with DVMT
• Intel 82573L Gigabit Ethernet
• 6CH AC97 Audio, Type II CompactFlash
• One PCI Slot, Two PCI-E［x1］Slots (Optional) and
One Mini PCI Socket
• Six Serial Ports, One Parallel Port, Two SATA Slots,
One ATA33, Six USB 2.0 Ports and Digital I/O
• LCD Inverter Connector with Brightness Control
®
• Enhanced Intel
SpeedStep Technology
Chapter 1 General Information
1-3
Mini-ITX EMB-945T Rev.B
1.3 Specifications
System
Processor Supports Socket 478 or
onboard Intel
®
Core 2 Duo
(Merom)/ Core Duo/ Core
Solo/ Celeron M (Yonah)
Processors up to 2.16 GHz
with FSB 533/667 MHz
System Memory 200-pin DDR II SODIMM
Socket x 2, total up to 4GB
Chipset
I/O Chipset ITE 8712 + Fintek F81216D
Ethernet Intel 82573L
Intel® 945GM + ICH7M
10/100/1000Base-TX, RJ-45
x 1
BIOS Award Plug & Play BIOS –
1MB ROM
Watchdog Timer ITE 8712
H/W Status Monitoring Supports power supply
voltages, fan speed and
Expansion Interface
temperature monitoring
PCI x 1, PCI-E［x1］ x 2
(optional), Mini PCI x 1
Power Requirement ATX (+3.3V, +5V, +12V)
Chapter 1 General Information 1-4
Mini-ITX EMB-945T Rev.B
Power Consumption T7400 2.16GHz, DDRII 667
1GB
+12V @ 2.59A, +5V @
2.88A, +3.3V @ 0.6A
Board Size 6.7”(L) x 6.7”(W) (170 mm x
Operating Temperature
Storage Temperature
Operating Humidity
170 mm)
32˚F~ 140˚F (0˚C ~ 60˚C)
-40˚F~ 176˚F (-40˚C ~ 80˚C)
0%~90% relative humidity,
non-condensing
Display: Supports CRT/LCD, CRT/TV and CRT/DVI simultaneous display and dual view
®
Chipset
VGA/LCD Controller
945GM
Intel
®
1. Intel
945GM integrated
Graphics, Shared memory up
to 224MB with DVMT, LCD
supports 24-bit dual-channel
LVDS
2. Chrontel 7307 for DVI
support
3. Chrontel 7308 for 24-bit
dual-channel LVDS
support
TV-out Supports NTSC and PAL
Chapter 1 General Information
1-5
I/O
Mini-ITX EMB-945T Rev.B
standard
Storage
Serial Port
IrDA One IrDA Tx/Rx header
Audio Realtek ALC655 CODEC
EIDE x 1 (UDMA33), SATA x 2,
Type II CompactFlash x 1
RS-232 x 5, RS-232/422/485 x 1
MIC-In/ Line-In/ Line-out, S/PDIF
In/Out
USB Six USB 2.0 Ports, Two 5x2 pin
header for Internal, Two Type-A
USB connector for External
Parallel Port Supports SPP/ EPP/ ECP mode
K/B and Mouse Mini-DIN PS/2 Keyboard and
Mouse connector x1
Digital I/O Supports 8-bit (Programmable)
Chapter 1 General Information 1-6
Mini-ITX EMB-945T Rev.B
d
f
r
r
e
p
Chapter
2
Quick
Installation
Guide
Part No. 2007945T22 Printed in Taiwan Mar. 2008
The Quick Installation Guide is derive
rom Chapter 2 of user manual. For othe
chapters and further installation
instructions, please refer to the use
manual CD-ROM that came with th
roduct.
Chapter 2 Quick Installation Guide 2 - 1
Notice:
Mini-ITX EMB-945T Rev.B
2.1 Safety Precautions
Always completely disconnect the power cord
from your board whenever you are working on
it. Do not make connections while the power is
on, because a sudden rush of power can
damage sensitive electronic components.
Always ground yourself to remove any static
charge before touching the board. Modern
electronic devices are very sensitive to static
electric charges. Use a grounding wrist strap at
all times. Place all electronic components on a
static-dissipative surface or in a static-shielded
bag when they are not in the chassis
Chapter 2 Quick Installation Guide 2 - 2
Mini-ITX EMB-945T Rev.B
2.2 Location of Connectors and Jumpers
Component Side
Chapter 2 Quick Installation Guide 2 - 3
Solder Side
Mini-ITX EMB-945T Rev.B
Chapter 2 Quick Installation Guide 2 - 4
Mini-ITX EMB-945T Rev.B
2.3 Mechanical Drawing
Component Side
Chapter 2 Quick Installation Guide 2 - 5
Solder Side
Mini-ITX EMB-945T Rev.B
Chapter 2 Quick Installation Guide 2 - 6
Mini-ITX EMB-945T Rev.B
2.4 List of Jumpers
The board has a number of jumpers that allow you to configure
your system to suit your application.
The table below shows the function of each of the board's
jumpers:
Jumpers
Label Function
JP1 LVDS(1)-LCD(CN12) Voltage Selection
JP2 LVDS(2)-LCD(CN10) Voltage Selection
JP3 COM2 Ring/+5V/+12V Selection
JP4 LCD INVERTER Voltage Selection
JP6 Clear CMOS
Chapter 2 Quick Installation Guide 2 - 7
Mini-ITX EMB-945T Rev.B
2.5 List of Connectors
The board has a number of connectors that allow you to
configure your system to suit your application.
The table below shows the function of each of the board's
connectors:
Connectors
Label Function
CN1 CD-IN Connector
CN2 Digital I/O Connector
CN3 TV-Out Connector
CN4 Internal Keyboard Co nnector
CN5 Fan2 Connector
CN6 Audio 5.1 Channel / SPDIF Connector
CN7 Internal Mouse Connector
CN8 LCD Inverter Connector
CN10 LVDS (2)-LCD Connector for 24/48 bit
CN11 DVI Connector
CN12 LVDS (1)-LCD Connector for 18/36 bit
CN13 COM6 RS-232 Serial Port Connector
CN14 COM3 RS-232 Serial Port Connector
CN15 Fan1 Connector
CN16 COM5 RS-232 Serial Port Connector
CN17 COM4 RS-232 Serial Port Connector
CN18 IrDA Connector
CN19 ATX Power Connector
CN20 USB Connector
CN21
CN22 EIDE Connector
CN23 Front Panel Connector
CN24 CompactFlash Slot
USB Connector
Chapter 2 Quick Installation Guide 2 - 8
Mini-ITX EMB-945T Rev.B
r
CN25 PCI Express Slot
CN26 Audio Speaker Output
CRTAUD1 VGA Display Connector / Audio Connector
KBMS1 PS2 Keyboard / Mouse Connector
PCON1 COM1 RS-232 & COM2 RS-232/422/485 Serial Port
RJUSB1 USB Connector / 10 /100 /1000 Base-TX Ethernet
MPCI1 Mini PCI Slot
PCI1 PCI Slot
SATA1 Primary Serial ATA Connector
SATA2 Secondary Serial ATA Connector
DIMM1 DDR2 SODIMM Slot
DIMM2 DDR2 SODIMM Slot
Connector / LPT Port Connecto
Connector
Chapter 2 Quick Installation Guide 2 - 9
Mini-ITX EMB-945T Rev.B
2.6 Setting Jumpers
You configure your card to match the needs of your application by
setting jumpers. A jumper is the simplest kind of electric switch. It
consists of two metal pins and a small metal clip (often protected by a
plastic cover) that slides over the pins to connect them. To “close” a
jumper you connect the pins with the clip.
To “open” a jumper you remove the clip. Sometimes a jumper will
have three pins, labeled 1, 2 and 3. In this case you would connect
either pins 1 and 2 or 2 and 3.
3
2
1
Open Closed Closed 2-3
A pair of needle-nose pliers may be helpful when working with
jumpers.
If you have any doubts about the best hardware configuration for your
application, contact your local distributor or sales representative
before you make any change.
Generally, you simply need a standard cable to make most
connections.
Chapter 2 Quick Installation Guide 2 - 10
Mini-ITX EMB-945T Rev.B
2.7 LVDS(1)-LCD(CN12) Voltage Selection (JP1)
JP1 Function
1-2 +5V
2-3 +3.3V (Default)
2.8 LVDS (2)-LCD(CN10) Voltage Selection (JP2)
JP2 Function
1-2 +5V
2-3 +3.3V (Default)
2.9 COM2 Ring/+5V/+12V Selection (JP3)
JP3 Function
1-2 +12V
3-4 +5V
5-6 Ring (Default)
2.10 LCD INVERTER Voltage Selection (JP4)
JP4 LCD Function
1-2 +5V (Default)
2-3 +12V
2.11 Clear CMOS (JP6)
JP6 Function
1-2 Protected (Default)
2-3 Clear
Chapter 2 Quick Installation Guide 2 - 11
Mini-ITX EMB-945T Rev.B
2.12 CD-IN Connector (CN1)
Pin Signal
1 CD_IN_L
2 CD_GND
3 CD_GND
4 CD_IN_R
2.13 Digital I/O Connector (CN2)
This connector offers 4-pair of digital I/O functions and address is set
in BIOS. The default address is 2A1H. The pin definitions are
illustrated below:
Pin Signal
1 Digital-IN/ OUT 2 Digital-IN/OUT
3 Digital-IN/ OUT 4 Digital-IN/ OUT
5 Digital-IN/ OUT 6 Digital-IN/ OUT
7 Digital-IN/ OUT 8 Digital-IN/ OUT
9 +5V 10 GND
The pin definitions and registers mapping are illustrated below:
4 in / 4 out
Pin8 Pin7 Pin6 Pin5 Pin4 Pin3 Pin2 Pin1
GPI 27 GPI 26 GPI 25 GPI 24 GPO 23 GPO 22 GPO 21 GPO 20
MSB LSB
8 in
Pin8 Pin7 Pin6 Pin5 Pin4 Pin3 Pin2 Pin1
GPI 27 GPI 26 GPI 25 GPI 24 GPI 23 GPI 22 GPI 21 GPI 20
MSB LSB
Chapter 2 Quick Installation Guide 2 - 12
Mini-ITX EMB-945T Rev.B
8 out
Pin8 Pin7 Pin6 Pin5 Pin4 Pin3 Pin2 Pin1
GPO 27 GPO 26 GPO 25 GPO 24 GPO 23 GPO 22 GPO 21 GPO 20
MSB LSB
2.14 TV_Out Connector (CN3)
Pin Signal Pin Signal
1 Y 2 CVBS
3 GND 4 GND
5 C 6 N.C.
7 GND 8 N.C.
2.15 Internal Keyboard Connector (CN4)
Pin Signal
1 KB_CLK
2 KB_DATA
3 N.C.
4 GND
5 +5V
2.16 Fan2 Connector (CN5)
Pin Signal
1 GND
2 +12V
3 Speed Sense
4 Speed Control
Chapter 2 Quick Installation Guide 2 - 13
Mini-ITX EMB-945T Rev.B
2.17 Audio 5.1 Channel / SPDIF Connector (CN6)
Pin Signal Pin Signal
1 Front-OUT-R 2 GND
3 Front-OUT-L 4 GND
5 Surr-OUT-R 6 GND
7 Surr-OUT-L 8 GND
9 LFE-OUT 10 GND
11 CNE-OUT 12 GND
13 SPDIF-OUT 14 SPDIF-IN
2.18 Internal Mouse Connector (CN7)
Pin Signal
1 MS_CLK
2 MS_DATA
3 GND
4 +5V
2.19 LCD Inverter Connector (CN8)
Pin Signal
1 VCC of LCD inverter (+5V/+12V)
2 Adjust backlight
3 GND
4 GND
5 ENBKL
2.20 LVDS (2)-LCD Connector (CN10)
Pin Signal Pin Signal
1 ENBKL 2 N.C.
Chapter 2 Quick Installation Guide 2 - 14
Mini-ITX EMB-945T Rev.B
3 PPVCC 4 GND
5 LVDS1_TXCLK- 6 LVDS1_TXCLK+
7 PPVCC 8 GND
9 LVDS1_TX0- 10 LVDS1_TX0+
11 LVDS1_TX1- 12 LVDS1_TX1+
13 LVDS1_TX2- 14 LVDS1_TX2+
15 LVDS1_TX3- 16 LVDS1_TX3+
17 I2C_DATA 18 I2C_CLK
19 LVDS2_TX0- 20 LVDS2_TX0+
21 LVDS2_TX1- 22 LVDS2_TX1+
23 LVDS2_TX2- 24 LVDS2_TX2+
25 LVDS2_TX3- 26 LVDS2_TX3+
27 PPVCC 28 GND
29 LVDS2_TXCLK- 30 LVDS2_TXCLK+
2.21 DVI Connector (CN11)
Pin Signal Pin Signal
1 DVI_TX1+ 2 LVDS_TX13 GND 4 GND
5 DVI_TXCLK+ 6 DVI_TXCLK7 GND 8 +5V
9 HotPlug_Detect 10 +5V
11 DVI_TX2+ 12 DVI_TX213 GND 14 GND
15 DVI_TX0+ 16 DVI_TX017 N.C. 18 N.C.
19 I2C_DATA 20 I2C_CLK
Chapter 2 Quick Installation Guide 2 - 15
Mini-ITX EMB-945T Rev.B
2.22 LVDS(1)-LCD Connector (CN12)
Pin Signal Pin Signal
1 ENBKL 2 N.C.
3 PPVCC 4 GND
5 LVDS1_TXCLK- 6 LVDS1_TXCLK+
7 PPVCC 8 GND
9 LVDS1_TX0- 10 LVDS1_TX0+
11 LVDS1_TX1- 12 LVDS1_TX1+
13 LVDS1_TX2- 14 LVDS1_TX2+
15 N.C. 16 N.C.
17 I2C_DATA 18 I2C_CLK
19 LVDS2_TX0- 20 LVDS2_TX0+
21 LVDS2_TX1- 22 LVDS2_TX1+
23 LVDS2_TX2- 24 LVDS2_TX2+
25 N.C. 26 N.C.
27 PPVCC 28 GND
29 LVDS2_TXCLK- 30 LVDS2_TXCLK+
2.23 COM6 RS-232 Serial Port Connector (CN13)
Pin Signal Pin Signal
1 DCD 2 RXD
3 TXD 4 DTR
5 GND 6 DSR
7 RTS 8 CTS
9 RI 10 N.C.
2.24 COM3 RS-232 Serial Port Connector (CN14)
Pin Signal Pin Signal
1 DCD 2 RXD
Chapter 2 Quick Installation Guide 2 - 16
Mini-ITX EMB-945T Rev.B
3 TXD 4 DTR
5 GND 6 DSR
7 RTS 8 CTS
9 RI 10 N.C.
2.25 Fan1 Connector (CN15)
Pin Signal
1 GND
2 +12V
3 Speed Sense
4 Speed Control
2.26 COM5 RS-232 Serial Port Connector (CN16)
Pin Signal Pin Signal
1 DCD 2 RXD
3 TXD 4 DTR
5 GND 6 DSR
7 RTS 8 CTS
9 RI 10 N.C.
2.27 COM4 RS-232 Serial Port Connector (CN17)
Pin Signal Pin Signal
1 DCD 2 RXD
3 TXD 4 DTR
5 GND 6 DSR
7 RTS 8 CTS
9 RI 10 N.C.
Chapter 2 Quick Installation Guide 2 - 17
Mini-ITX EMB-945T Rev.B
2.28 IrDA Connector (CN18)
Pin Signal
1 +5V
2 N.C.
3 IRRX
4 GND
5 IRTX
6 N.C.
2.29 ATX Power Connector (CN19)
Pin Signal Pin Signal
1 +3.3V 11 +3.3V
2 +3.3V 12 -12V
3 GND 13 GND
4 +5V 14 PS_ON
5 GND 15 GND
6 +5V 16 GND
7 GND 17 GND
8 POWER OK 18 -5V
9 +5VSB 19 +5V
10 +12V 20 +5V
2.30 USB Connector (CN20)
Pin Signal Pin Signal
1 +5V 2 GND
3 USBD1- 4 GND
5 USBD1+ 6 USBD2+
7 GND 8 USBD2-
Chapter 2 Quick Installation Guide 2 - 18
Mini-ITX EMB-945T Rev.B
9 GND 10 +5V
2.31 USB Connector (CN21)
Pin Signal Pin Signal
1 +5V 2 GND
3 USBD1- 4 GND
5 USBD1+ 6 USBD2+
7 GND 8 USBD29 GND 10 +5V
2.32 EIDE Connector (CN22)
Pin Signal Pin Signal
1 IDE RESET 2 GND
3 DATA7 4 DATA8
5 DATA6 6 DATA9
7 DATA5 8 DATA10
9 DATA4 10 DATA11
11 DATA3 12 DATA12
13 DATA2 14 DATA13
15 DATA1 16 DATA14
17 DATA0 18 DATA15
19 GND 20 N.C.
21 REQ 22 GND
23 IO WRITE 24 GND
25 IO READ 26 GND
27 IO READY 28 GND
29 DACK 30 GND
31 IRQ14 32 N.C.
Chapter 2 Quick Installation Guide 2 - 19
Mini-ITX EMB-945T Rev.B
33 ADDR1 34 UDMA DETECT
35 ADDR0 36 ADDR2
37 CS#1 38 CS#3
39 LED 40 GND
41 +5V 42 +5V
43 GND 44 N.C.
2.33 Front Panel Connector (CN23)
Pin Signal Pin Signal
1 Power On Button (-) 2 Power On Button (+)
3 IDE LED (-) 4 IDE LED (+)
5 External Buzzer (-) 6 External Buzzer (+)
7 Power LED (-) 8 Power LED (+)
9 Reset Switch (-) 10 Reset Switch (+)
2.34 PCI-Express Slot (CN25)
Pin Signal Pin Signal
A1 N.C. B1 +12V
A2 +12V B2 +12V
A3 +12V B3 +12V
A4 GND B4 GND
A5 N.C. B5 SMBCLK
A6 N.C. B6 SMBDAT
A7 N.C. B7 GND
A8 N.C. B8 +3.3V
A9 +3.3V B9 N.C.
A10 +3.3V B10 +3.3VSB
Chapter 2 Quick Installation Guide 2 - 20
Mini-ITX EMB-945T Rev.B
A11 PCIE_RESET# B11 PCIE_WAKE#
A12 GND B12 N.C.
A13 PCIE1_CLKP B13 GND
A14 PCIE1_CLKN B14 PCIE1_TXP
A15 GND B15 PCIE1_TXN
A16 PCIE1_RXP B16 GND
A17 PCIE1_RXN B17 N.C.
A18 GND B18 GND
A19 N.C. B19 PCIE2_TXP
A20 GND B20 PCIE2_TXN
A21 PCIE2_RXP B21 GND
A22 PCIE2_RXN B22 GND
A23 GND B23 PCIE3_TXP
A24 GND B24 PCIE3_TXN
A25 PCIE3_RXP B25 GND
A26 PCIE3_RXN B26 GND
A27 GND B27 PCIE4_TXP
A28 GND B28 PCIE4_TXN
A29 PCIE4_RXP B29 GND
A30 PCIE4_RXN B30 PCIE2_CLKN
A31 GND B31 N.C.
A32 PCIE2_CLKP B32 GND
Chapter 2 Quick Installation Guide 2 - 21
Mini-ITX EMB-945T Rev.B
2.35 Audio Speaker Output Connector (CN26)
Pin Signal Pin Signal
1 SPK-R+ 2 SPK-R3 SPK-L+ 4 SPK-L-
2.36 COM2 RS-232/422/485 Serial Port Connector (PCON1)
COM2 RS-232/422/485 selection for EMB-945 Rev.B is set in BIOS
setting as following:
Entering BIOS Setting Menu: Choose "Integrated Peripherals
Super IO device
Æ
COM2 select". (Default setting is at "RS-232")
Æ
Different devices implement the RS-232/422/485 standard in
different ways. If you have problems with a serial device, check the
pin assignments below for the connector.
Pin Signal Pin Signal
DCD
1
(422TXD-/485DATA-)
TXD
3
(422TXD+/485DATA+)
5 GND 6 DSR
7 RTS 8 CTS
9 RI 10 N.C.
2 RXD (422RXD+)
4 DTR (422RXD-)
Chapter 2 Quick Installation Guide 2 - 22
Mini-ITX EMB-945T Rev.B
Below Table for China RoHS Requirements
产品中有毒有害物质或元素名称及含量
AAEON Main Board/ Daughter Board/ Backplane
有毒有害物质或元素
部件名称
印刷电路板
及其电子组件
外部信号
连接器及线材
O：表示该有毒有害物质在该部件所有均质材料中的含量均在
SJ/T 11363-2006 标准规定的限量要求以下。
X：表示该有毒有害物质至少在该部件的某一均质材料中的含量超出
SJ/T 11363-2006 标准规定的限量要求。
备注：此产品所标示之环保使用期限，系指在一般正常使用状况下。
铅
(Pb)汞 (Hg)镉 (Cd)
× ○ ○ ○ ○ ○
× ○ ○ ○ ○ ○
六价铬
(Cr(VI))
多溴联苯
(PBB)
多溴二苯醚
(PBDE)
Chapter 2 Quick Installation Guide 2 - 23
Mini-ITX EMB-945T Rev.B
Chapter
3
Award
BIOS Setup
Chapter 3 Award BIOS Setup 3-1
Mini-ITX EMB-945T Rev.B
3.1 System Test and Initialization
These routines test and initialize board hardware. If the
routines encounter an error during the tests, you will either
hear a few short beeps or see an error message on the
screen. There are two kinds of errors: fatal and non-fatal. The
system can usually continue the boot up sequence with
non-fatal errors. Non-fatal error messages usually appear on
the screen along with the following instructions:
Press <F1> to RESUME
Write down the message and press the F1 key to continue
the boot up sequence.
System configuration verification
These routines check the current system configuration
against the values stored in the CMOS memory. If they do
not match, the program outputs an error message. You will
then need to run the BIOS setup program to set the
configuration information in memory.
There are three situations in which you will need to change
the CMOS settings:
1. You are starting your system for the first time
2. You have changed the hardware attached to your system
3. The CMOS memory has lost power and the configuration
information has been erased.
The EMB-945T Rev.B CMOS memory has an integral lithium
battery backup for data retention. However, you will need to
replace the complete unit when it finally runs down.
Chapter 3 Award BIOS Setup 3-2
Mini-ITX EMB-945T Rev.B
3.2 Award BIOS Setup
Awards BIOS ROM has a built-in Setup program that allows
users to modify the basic system configuration. This type of
information is stored in battery-backed CMOS RAM so that it
retains the Setup information when the power is turned off.
Entering Setup
Power on the computer and press <Del> immediately. This
will allow you to enter Setup.
Standard CMOS Features
Use this menu for basic system configuration. (Date, time,
IDE, etc.)
Advanced BIOS Features
Use this menu to set the advanced features available on your
system.
Chapter 3 Award BIOS Setup 3-3
Mini-ITX EMB-945T Rev.B
Advanced Chipset Features
Use this menu to change the values in the chipset registers
and optimize your system performance.
Integrated Peripherals
Use this menu to specify your settings for integrated
peripherals. (Primary slave, secondary slave, keyboard,
mouse etc.)
Power Management Setup
Use this menu to specify your settings for power
management. (HDD power down, power on by ring, KB wa ke
up, etc.)
PnP/PCI Configurations
This entry appears if your system supports PnP/PCI.
PC Health Status
This menu allows you to set the shutdown temperature for
your system.
Frequency/Voltage Control
Use this menu to specify your settings for auto detect
DIMM/PCI clock and spread spectrum.
Load Fail-Safe Defaults
Use this menu to load the BIOS default values for the
minimal/stable performance for your system to operate.
Chapter 3 Award BIOS Setup 3-4
Mini-ITX EMB-945T Rev.B
Load Optimized Defaults
Use this menu to load the BIOS default values that are
factory settings for optimal performance system operations.
While AWARD has designated the custom BIOS t o maximize
performance, the factory has the right to change these
defaults to meet their needs.
Set Supervisor/User Password
Use this menu to set Supervisor/User Passwords.
Save and Exit Setup
Save CMOS value changes to CMOS and exit setup.
Exit Without Saving
Abandon all CMOS value changes and exit setup.
You can refer to the “ AAEON BIOS Item
Description.pdf” file in the CD for the meaning of each
setting in this chapter.
Chapter 3 Award BIOS Setup 3-5
Mini-ITX EMB-945T Rev.B
Chapter
4
Driver
Installation
Chapter 4 Driver Installation 4-1
Mini-ITX EMB-945T Rev.B
The EMB-945T Rev.B comes with a AutoRun CD-ROM that
contains all drivers and utilities that can help you to install the driver
automatically.
Insert the driver CD, the driver CD-title will auto start and show the
installation guide. If not, please follow the sequence below to install
the drivers.
Follow the sequence below to install the drivers:
Step 1 – Install Chip Driver
Step 2 – Install VGA Driver
Step 3 – Install LAN Driver
Step 4 – Install Audio Driver
®
USB 2.0 Drivers are available for download using Windows
Update for both Windows
information regarding USB 2.0 support in Windows
Windows
®
2000, please visit www.microsoft.com/hwdev/usb/.
®
XP and Windows® 2000. For additional
®
XP and
Please read instructions below for further detailed installations.
Chapter 4 Driver Installation 4-2
Mini-ITX EMB-945T Rev.B
4.1 Installation:
Insert the EMB-945T Rev.B CD-ROM into the CD-ROM drive.
And install the drivers from Step 1 to Step 4 in order.
Step 1 – Install Chip Driver
1. Click on the Step 1-chip folder and then double click on
the Setup.exe
2. Follow the instructions that the window shows
3. The system will help you install the driver automatically
4. Please re-start your computer
Step 2 – Install VGA Driver
1. Click on the Step 2-vga folder and choose the folder your
system is
2. Double click on .exe file located in each OS folder
3. Follow the instructions that the window shows
4. The system will help you install the driver automatically
5. Please re-start your computer
Step 3 – Install LAN Driver
1. Click on the Step 3-LAN driver folder
2. Select the Windows folder and then double click on
Autorun.exe
3. Follow the instructions that the window shows
4. The system will help you install the driver automatically
Chapter 4 Driver Installation 4-3
Mini-ITX EMB-945T Rev.B
Step 4 – Install Audio Driver
1. Click on the Step 4- AC97 folder and choose the folder
your system is
2. Double click on .exe file located in each OS folder
3. Follow the instructions that the window shows
4. The system will help you install the driver automatically
Note:
Under the Window OS environment, if the CRT connector is
connected to display monitor by the data switch device, the
user need to set the color and resolution from Intel Graphic
utility (VGA driver) instead of setting from the control panel in
case of the wrong display appearance.
Chapter 4 Driver Installation 4-4
Mini-ITX EMB-945T Rev.B
A
Appendix
Programming the
Watchdog Timer
Appendix A Programming the Watchdog Timer A-1
Mini-ITX EMB-945T Rev.B
A.1 Programming
EMB-945T Rev.B utilizes ITE 8712 chipset as its watchdog timer
controller.
Below are the procedures to complete its configuration and the
AAEON intial watchdog timer program is also attached based on
which you can develop customized program to fit your application.
Configuring Sequence Description
After the hardware reset or power-on reset, the ITE 8712 enters the
normal mode with all logical devices disabled except KBC. The
initial state (enable bit ) of this logical device (KBC) is determined
by the state of pin 121 (DTR1#) at the falling edge of the system
reset during power-on reset.
Appendix A Programming the Watchdog Timer A-2
Mini-ITX EMB-945T Rev.B
There are three steps to complete the configuration setup: (1) Enter
the MB PnP Mode; (2) Modify the data of configuration registers; (3)
Exit the MB PnP Mode. Undesired result may occur if the MB PnP
Mode is not exited normally.
(1) Enter the MB PnP Mode
To enter the MB PnP Mode, four special I/O write operations are to
be performed during Wait for Key state. To ensure the initial state of
the key-check logic, it is necessary to perform four write opera -tions
to the Special Address port (2EH). Two different enter keys are
provided to select configuration ports (2Eh/2Fh) of the next step.
(2) Modify the Data of the Registers
All configuration registers can be accessed after entering the MB
PnP Mode. Before accessing a selected register, the content of
Index 07h must be changed to the LDN to which the register
belongs, except some Global registers.
(3) Exit the MB PnP Mode
Set bit 1 of the configure control register (Index=02h) to 1 to exit the
MB PnP Mode.
Appendix A Programming the Watchdog Timer A-3
Mini-ITX EMB-945T Rev.B
WatchDog Timer Configuration Registers
Configure Control (Index=02h)
This register is write only. Its values are not sticky; that is to say, a
hardware reset will automatically clear the bits, and does not
require the software to clear them.
WatchDog Timer Control Register (Index=71h, Default=00h)
Appendix A Programming the Watchdog Timer A-4
Mini-ITX EMB-945T Rev.B
WatchDog Timer Configuration Register (Index=72h,
Default=00h)
WatchDog Timer Time-out Value Register (Index=73h,
Default=00h)
Appendix A Programming the Watchdog Timer A-5
Mini-ITX EMB-945T Rev.B
A.2 IT8712 Watchdog Timer Initial Program
.MODEL SMALL
.CODE
Main:
CALL Enter_Configuration_mode
CALL Check_Chip
mov cl, 7
call Set_Logic_Device
;time setting
mov cl, 10 ; 10 Sec
dec al
Watch_Dog_Setting:
;Timer setting
mov al, cl
mov cl, 73h
call Superio_Set_Reg
;Clear by keyboard or mouse interrupt
mov al, 0f0h
mov cl, 71h
call Superio_Set_Reg
;unit is second.
mov al, 0C0H
mov cl, 72h
call Superio_Set_Reg
Appendix A Programming the Watchdog Timer A-6
Mini-ITX EMB-945T Rev.B
; game port enable
mov cl, 9
call Set_Logic_Device
Initial_OK:
CALL Exit_Configuration_mode
MOV AH,4Ch
INT 21h
Enter_Configuration_Mode PROC NEAR
MOV SI,WORD PTR CS:[Offset Cfg_Port]
MOV DX,02Eh
MOV CX,04h
Init_1:
MOV AL,BYTE PTR CS:[SI]
OUT DX,AL
INC SI
LOOP Init_1
RET
Enter_Configuration_Mode ENDP
Exit_Configuration_Mode PROC NEAR
MOV AX,0202h
CALL Write_Configuration_Data
Appendix A Programming the Watchdog Timer A-7
Mini-ITX EMB-945T Rev.B
RET
Exit_Configuration_Mode ENDP
Check_Chip PROC NEAR
MOV AL,20h
CALL Read_Configuration_Data
CMP AL,87h
JNE Not_Initial
MOV AL,21h
CALL Read_Configuration_Data
CMP AL,12h
JNE Not_Initial
Need_Initial:
STC
RET
Not_Initial:
CLC
RET
Check_Chip ENDP
Read_Configuration_Data PROC NEAR
MOV DX,WORD PTR CS:[Cfg_Port+04h]
OUT DX,AL
Appendix A Programming the Watchdog Timer A-8
Mini-ITX EMB-945T Rev.B
MOV DX,WORD PTR CS:[Cfg_Port+06h]
IN AL,DX
RET
Read_Configuration_Data ENDP
Write_Configuration_Data PROC NEAR
MOV DX,WORD PTR CS:[Cfg_Port+04h]
OUT DX,AL
XCHG AL,AH
MOV DX,WORD PTR CS:[Cfg_Port+06h]
OUT DX,AL
RET
Write_Configuration_Data ENDP
Superio_Set_Reg proc near
push ax
MOV DX,WORD PTR CS:[Cfg_Port+04h]
mov al,cl
out dx,al
pop ax
inc dx
out dx,al
ret
Superio_Set_Reg endp.Set_Logic_Device proc near
Set_Logic_Device proc near
Appendix A Programming the Watchdog Timer A-9
push ax
push cx
xchg al,cl
mov cl,07h
call Superio_Set_Reg
pop cx
pop ax
ret
Set_Logic_Device endp
;Select 02Eh->Index Port, 02Fh->Data Port
Cfg_Port DB 087h,001h,055h,055h
DW 02Eh,02Fh
END Main
Mini-ITX EMB-945T Rev.B
Note: Interrupt level mapping
0Fh-Dh: not valid
0Ch: IRQ12
.
.
03h: IRQ3
02h: not valid
01h: IRQ1
00h: no interrupt selected
Appendix A Programming the Watchdog Timer A-10
Mini-ITX EMB-945T Rev.B
Appendix
B
I/O Information
Appendix B I/O Information B-1
Mini-ITX EMB-945T Rev.B
B.1 I/O Address Map
Appendix B I/O Information B-2
Mini-ITX EMB-945T Rev.B
B.2 Memory Address Map
Appendix B I/O Information B-3
Mini-ITX EMB-945T Rev.B
B.3 IRQ Mapping Chart
B.4 DMA Channel Assignments
Appendix B I/O Information B-4
Mini-ITX EMB-945T Rev.B
x Appendi
C
Mating Connecotor
Appendix C Mating Connector C - 1
Mini-ITX EMB-945T Rev.B
C.1 List of Mating Connectors and Cables
The table notes mating connectors and available cables.
Function
Label
CN1 CD-IN HO
CN2 Digital I/O Catch 2.00mm Pitch 10
CN3 TV-Out Catch 2.00mm Pitch 8
CN4 Internal
Keyboard
CN5 Fan Catch 2.54mm Pitch 3
CN6 Audio 5.1
Channel/
SPDIF
CN7 Internal
Mouse
CN8 LCD
Inverter
Mating Connector Connector
Vendor Model no
2.54mm Pitch 4
BASE
HO
BASE
Catch 2.00mm Pitch 14
HO
BASE
HO
BASE
pins (HO-BASE
2541-1H-4 or
compatible)
pins ( Catch
H754-2x5 or
compatible)
pins ( Catch
H754-2x4 or
compatible)
2.54mm Pitch 5
pins (HO-BASE
2503-H-5 or
compatible)
pins (Catch
1190-700-03S or
compatible)
pins ( Catch
H709-2 or
compatible)
2.0mm Pitch 4
pins (HO-BASE
2002-H-4 or
compatible)
2.0mm Pitch 5
pins (HO-BASE
2002-H-5 or
compatible)
Available
Cable
CDROM
Cable
NA NA
TV-Out
Cable
NA NA
NA NA
Audio
Cable
NA NA
NA NA
Cable P/N
1703040400
1700080180
1700140164
Appendix C Mating Connector C - 2
Mini-ITX EMB-945T Rev.B
p
CN10 LVDS
LCD
CN11 DVI Catch 2.00mm Pitch 8
CN12 LVDS
LCD
CN13 RS-232
Serial Port
CN14 RS-232
Serial Port
CN15 Fan Catch 2.54mm Pitch 3
CN16 RS-232
Serial Port
CN17 RS-232
Serial Port
CN18 IrDA HO
CN19 ATX
Power
Socket
CN20 USB Port Catch 2.00mm Pitch 10
Com
Weal
1.25mm Pitch 30
Pins(ComWeal
103-303M or
compatible)
pins ( Catch
H754-2x10 or
compatible)
Com
Weal
1.25mm Pitch 30
Pins(ComWeal
103-303M or
compatible)
Catch 2.00mm Pitch 10
pins ( Catch
H754-2x5 or
compatible)
Catch 2.00mm Pitch 10
pins ( Catch
H754-2x5 or
compatible)
pins (Catch
1190-700-03S or
compatible)
Catch 2.00mm Pitch 10
pins ( Catch
H754-2x5 or
compatible)
Catch 2.00mm Pitch 10
pins ( Catch
H754-2x5 or
compatible)
2.0mm Pitch 6
BASE
pins (HO-BASE
2000-1H-6 or
compatible)
Catch 3.50 mm Pitch 20
pins (Catch
1121-700-20S or
compatible)
ins ( Catch
Appendix C Mating Connector C - 3
NA NA
DVI Cable 17002 00200
NA NA
Serial Port
Cable
Serial Port
Cable
NA NA
Serial Port
Cable
Serial Port
Cable
NA NA
NA NA
USB Cable 17091002 01
1701100206
1701100206
1701100206
1701100206
Mini-ITX EMB-945T Rev.B
H754-2x5 or
compatible)
CN21 USB Port Catch 2.00mm Pitch 10
pins ( Catch
H754-2x5 or
compatible)
CN22 EIDE
Connector
CN23 Front
Pannel
Catch 2.00mm Pitch 44
pins ( Catch
H820-2 or
compatible)
HO
BASE
2.54mm Pitch 10
pins (HO-BASE
2541-2H-2X5 or
compatible)
USB Cable 17091002 01
EIDE
1701440500
Cable
NA NA
Appendix C Mating Connector C - 4
Loading...
