AAEON AGD-315D User Manual

Download

LCD Display AGD-315D

AGD-315D

15” XGA Rugged Touch Display

On Screen Display Control

IP-65 Front Bezel

5-wire Resistive Touch Screen

AGD-315D Manual 1

August 2011

LCD Display AGD-315D

This document is copyrighted, 2011. All rights are reserved. The original manufacturer reserves the right to make improvements to the products described in this manual at any time without notice.

No part of this manual may be reproduced, copied, translated, or transmitted in any form or by any means without the prior written permission of the original manufacturer. Information provided in this manual is intended to be accurate and reliable. However, the original manufacturer assumes no responsibility for its use, nor for any infringements upon the rights of third parties, which may result from its use.

The material in this document is for product information only and is subject to change without notice. While reasonable efforts have been made in the preparation of this document to assure its accuracy, AAEON, assumes no liabilities resulting from errors or omissions in this document, or from the use of the information contained herein.

AAEON reserves the right to make changes in the product design without notice to its users.

LCD Display AGD-315D

Acknowledgments

 Intel  IBM, PC/AT, PS/2 are trademarks of International Business

is registered trademarks of Intel® Corporation.

Machines Corporation.

 Microsoft

Windows is a registered trademark of Microsoft®

Corporation.

 RTL is a trademark of Realtek Semi-Conductor Co., Ltd.  C&T is a trademark of Chips and Technologies, Inc.  UMC is a trademark of United Microelectronics Corporation.  ITE is a trademark of Integrated Technology Express, Inc.  SiS is a trademark of Silicon Integrated Systems Corp.  VIA is a trademark of VIA Technology, Inc.

All other product names or trademarks are properties of their respective owners.

LCD Display AGD-315D

Packing List

The LCD monitor comes with the following standard parts shown as below. Check and make sure they are included and in good condition. If anything is missing or damaged, contact the dealer immediately.

 1 AGD-315D  1 Utility CD-ROM

Contains User’s Manual (in PDF format), Drivers and Utilities

 1 VGA Cable  1 USB Cable  1 RS-232 Cable

If any of these items are missing or damaged, you should cont act y our distributor or sales representative immediately.

iii

LCD Display AGD-315D

Safety & Warranty

1. Read these safety instructions carefully.

2. Keep this user's manual for later reference.

3. Disconnect this equipment from any AC outlet before cleaning. Do not use liquid or spray detergents for cleaning. Use a damp cl oth.

4. For pluggable equipment, the power outlet must be installed near the equipment and must be easily accessible.

5. Keep this equipment away from humidity.

6. Put this equipment on a reliable surface during installation.

Dropping it or letting it fall could cause damage.

7. The openings on the enclosure are for air convection. Protect the equipment from overheating. DO NOT COVER THE OPENINGS.

8. Make sure the voltage of the power source is correct before connecting the equipment to the power outlet.

9. Position the power cord so that people cannot step on it. Do not place anything over the power cord.

10. All cautions and warnings on the equipment should be noted.

11. If the equipment is not used for a long time, disconnect it from the power source to avoid damage by transient over-voltage.

12. Never pour any liquid into an opening. This could cause fire or

electrical shock.

13. Never open the equipment. For safety reasons, only qualified

service personnel should open the equipment.

LCD Display AGD-315D

14. If any of the following situations arises, get the equipment

checked by service personnel:

a. The power cord or plug is damaged. b. Liquid has penetrated into the equipment. c. The equipment has been exposed to moisture. d. The equipment does not work well, or you cannot get it to

work according to the users manual. e. The equipment has been dropped and damaged. f. The equipment has obvious signs of breakage.

15. DO NOT LEAVE THIS EQUIPMENT IN AN UNCONTROLLED

ENVIRONMENT WHERE THE STORAGE TEMPERATURE IS BELOW -20° C (-4°F) OR ABOVE 60°C (140° F). IT MAY DAMAGE THE EQUIPMENT

FCC

Cautio

This device complies with Part 15 FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received including interference that may cause undesired operation.

It may cause the danger of explosion if battery is incorrectly replaced. Replace only with same or equivalent type recommended by the manufacturer.

LCD Display AGD-315D

Below Table for China RoHS Requirements

产品中有毒有害物质或元素名称及含量

AAEON Display

有毒有害物质或元素

部件名称

印刷电路板

及其电子组件

外部信号

连接器及线材

外壳 × ○ ○ ○ ○ ○ 液晶模块 × ○ ○ ○ ○ ○ 触控模块 × ○ ○ ○ ○ ○

电源 × ○ ○ ○ ○ ○

O：表示该有毒有害物质在该部件所有均质材料中的含量均在

SJ/T 11363-2006 标准规定的限量要求以下。

X：表示该有毒有害物质至少在该部件的某一均质材料中的含量超出

SJ/T 11363-2006 标准规定的限量要求。

备注：一、此产品所标示之环保使用期限，系指在一般正常使用状况下。二、上述部件物质触控模块为选购品。

铅

(Pb)汞 (Hg)镉 (Cd)

× ○ ○ ○ ○ ○

六价铬

(Cr(VI))

多溴联苯

(PBB)

多溴二苯醚

(PBDE)

LCD Display AGD-315D

Contents

Chapter 1 General Information

1.1 Introduction................................................................ 1-2

1.2 Features....................................................................1-3

1.3 General Specification................................................1-4

1.4 Dimension .................................................................1-6

1.5 Waterproof Sponge Position.....................................1-8

Chapter 2 Hardware Installation

2.1 Before Unpacking...................................................... 2-2

2.2 Connecting Power..................................................... 2-3

2.3 Connecting to the Computer.....................................2-4

2.4 VGA Port Connector..................................................2-5

2.5 DVI Port Connector...................................................2-6

2.6 Serial Port Connector For Touch Screen..................2-7

2.7 Mini USB Connector For Touch Screen....................2-8

2.8 Panel Mounting ......................................................... 2-9

2.9 Easy Stand, Swing-ARM Mounting........................... 2-11

2.10 VESA Wall Mounting...............................................2-12

Chapter 3 On Screen Display Control

3.1 On Screen Display (OSD) Board Description. .......... 3-2

3.2 OSD Main Menu: Push The MENU Keys..................3-3

3.3 Select Input Source................................................... 3-4

vii

LCD Display AGD-315D

3.4 Contrast/ Brightness- Submenu................................ 3-5

3.5 Geometry Menu.........................................................3-6

3.6 Color Temperature- Submenu OSD Main Menu: Push

The MENU Keys.............................................................. 3-7

3.7 RGB Color- Submenu. .............................................. 3-8

3.8 Language- Submenu................................................. 3-9

3.9 Auto Config- Submenu..............................................3-10

3.10 Mode Resolution- Submenu Chapter...................... 3-11

3.11 Exit Menu- Submenu............................................... 3-12

Chapter 4 Touch Screen Driver Installation

4.1 Introduction................................................................ 4-2

4.2 Resistive Touch screen Driver Installation................ 4-5

4.3 Installing Driver for Windows

® XP/ Windows® 7 / Linux

.........................................................................................4-7

viii

LCD Display AGD-315D

Chapter

General

Information

Chapter 1 General Information 1-1

LCD Display AGD-315D

1.1 Introduction

Thank you for purchasing of the Industry Display Panel TFT LCD monitor - a marvelous contribution of cutting-edge technology.

The LCD monitor has been designed with serious thoughts to present the best performance for most applications. Symbol of elegance, its compact and slim profile are well suited in working locations where space is at a premium.

The TFT LCD monitor displays sharper, more brilliant, crisper and flicker-free images. Complying with the power management regulations of VESA DPMS, the LCD monitor is extremely energy efficient and a power saver. Plus, the LCD monitor has extremely low radiation emissions and near zero electromagnetic fields which are supreme benefits.

Fully compatible with PC system, the LCD monitor provides full interface for all sorts of related standards. Supported by “Plug & Play” complying with DDC1/DDC2B, installing the LCD monitor is absolutely trouble free.

The On Screen Display menu provides user a convenient interface to make right adjustment for optimum display performance.

Chapter 1 General Information 1-2

LCD Display AGD-315D

1.2 Features

 15” XGA (1024 x 768) TFT LCD Display  Wide Temperature Operation (0°C ~ 50°C)  Easy to Maintain: Front Accessible USB Ports  Sunlight Readable: 1000 Nits XGA LED Backlight  Rugged IP-65 Aluminum Die Cast Front Bezel  Reliable On Screen Display (OSD) button  Wide Power Input Range: 9-30V DC With 3-Pin Terminal

Block

 Flexible Touch Screen Interface: RS-232 or USB  Panel/ VESA/ Wallmount: VESA 75/100 standard

Chapter 1 General Information 1-3

LCD Display AGD-315D

1.3 General Specification

 Type  Size  Construction  Mounting  Input signal  Control  Power Supply  Dimension AGD-315D

Color TFT 15" TFT LCD IP-65 Aluminum Die Cast Front Bezel Panel/ VESA/ Wallmount VGA, DVI OSD (On Screen Display) on the rear panel External power adapter

15.35” (W) x 12.74”(H) x 4.91”(D) (390mm x

323.5mm x 124.7mm)

Cutout Size

14.8”(W) x 12.03”(H) (376mm x 305.5mm)

 Gross Weight  Power

Consumption

 Brightness

9 lb (4.1 Kg) Input : 9V~30V DC, 4~1.2A Output: 3.33A @ DC 12V (Max.) HTT : 250 cd/m

STT : 800 cd/m

(TYP.)

 MTBF  Pixel Pitch

 Viewing Angle

 Resolution

Chapter 1 General Information 1-4

50,000 hrs HTT: 0.3075(H)x0.3075(V)

STT: 0.240(H)x0.240(V) HTT:170°(H)/160°(V) STT:160°(H)/140°(V) 1024 x 768

LCD Display AGD-315D

 Display Modes

Full Screen in 640x480, 800x600, 1024x768, 1280x1024 Modes

 Color

Touchscreen

 Type  Resolution  Light

transmission

 Controller

Environmental

 Operating

temperature

 Vibration  Shock  EMC

16.7M colors

5-wire resistive 2048 x 2048 88 ± 2% (Pure)

RS-232 & USB interface (optional)

32°F~ 122°F (0°C to 50°C)

1g rms/5-500Hz/random operation 20 G peak acceleration (11 msec. duration) CE/FCC Class A

Chapter 1 General Information 1-5

LCD Display AGD-315D

1.4 Dimension

Chapter 1 General Information 1-6

LCD Display AGD-315D

Chapter 1 General Information 1-7

LCD Display AGD-315D

1.5 Waterproof Sponge Position Inside sponge:

A. Tear off the protection paper on the self-adhesive side of

the inside sponge.

B. Stick the sponge on the recessed area of the Aluminum

bezel or customer’s own bezel.

Back side of the Front

Adhesive

Inner Sponge

Chapter 1 General Information 1-8

LCD Display AGD-315D

Chapter

Chapter 2 Hardware Installation 2-1

ardware

Inst

allation

LCD Display AGD-315D

2.1 Before Unpacking

It is very important to place the LCD Display in a suitable environment.

 The surface for placing the LCD Display should be

stable and level.

 Make sure the place has good ventilation, and out of

direct sunlight; away form sources of excessive dust, dirt, heat, water, moisture and vibration.

 Convenience for connecting the LCD Display the

related facilities should be well considered too.

Chapter 2 Hardware Installation 2-2

LCD Display AGD-315D

2.2 Connecting Power

To power on the LCD Display, use the provided AC-DC adapter and the power cord to connect to the power output socket of the monitor. Fasten the connector securely.

A ”Surge Protection” device plugged between the AC-DC adapter and the wall outlet is recommended to prevent the effect s of su dden current variations from reaching the LCD Display. The sudden peaks of electricity may harm the LCD Display.

Chapter 2 Hardware Installation 2-3

LCD Display AGD-315D

2.3 Connecting to the Computer

Turn off the computer and the LCD Display before connecting.

 Use the Monitor-to-PC VGA、DVI cable to connect the LCD

Display to your computer. The cable heads are the same on either side.

 Fasten the connectors securely.

Chapter 2 Hardware Installation 2-4

LCD Display AGD-315D

2.4 VGA Port Connector

This DB-15 connector can be connected to the system via the external 15-pin DB-15 connector through the I/O from this unit.

Pin Signal Pin Signal 1

3 5 7 9 11 13 15

Red Blue GND

GND N.C. N.C. HSYNC SCL

Green

N.C.

GND

SDA

VSYNC

Chapter 2 Hardware Installation 2-5

LCD Display AGD-315D

2.5 DVI Port Connector

Connecting a standard DVI-D connector through I/O port of this unit. This connector supports digital signals only

Pin Signal Pin Signal 1 N.C. 2 TMDS Data 2+

3 TMDS Data 2/4 shield 4 TMDS Data 45 TMDS Data 4+ 6 DDC clock 7 DDC data 8 N.C. 9 TMDS Data 1- 10 TMDS Data 1 11 TMDS Data 1/3 shield 12 TMDS Data 313 TMDS Data 3+ 14 +5V 15 Ground 16 Hot plug detect 17 TMDS data 0- 18 TMDS data 0+ 19 TMDS data 0/5 shield 20 TMDS data 521 TMDS data 5+ 22 TMDS clock shield 23 TMDS clock+ 24 TMDS clockC1 N.C. C2 N.C. C3 N.C. C4 N.C. C5 N.C.

Chapter 2 Hardware Installation 2-6

LCD Display AGD-315D

2.6 Serial Port Connector For Touch Screen

This pin d e f i n i t i o n o f t h e connector will be referred w h e n a touch screen has been in stalled. It must be connected to the RS-232 port of the PC. The touch screen cable is included with all orders which include the optional RS-232 Touch Screen.

Pin Signal Pin Signal 1 Not Used 2 RXD, Receive Data

3 TXD, Transmit Data 4 Not Used 5 GND, Ground 6 Not Used 7 Not Used 8 Not Used 9 Not Used 10 Not Used

Chapter 2 Hardware Installation 2-7

LCD Display AGD-315D

2.7 Mini USB Connector For Touch Screen

This pin d e f i n i t i o n o f t h e connector will be referred w h e n a touch screen has been in stalled. It must be connected to the Mini USB port of the PC. The touch screen cable is included with all orders which include the optional Mini USB Touch Screen.

Pin Signal Pin Signal 1 +5V 2 DATA (-)

3 DATA (+) 4 N.C. 5 GND, Ground

Note:

Touch Screen can be switched to USB or COM by adjusting the

DIP-switch

Chapter 2 Hardware Installation 2-8

LCD Display AGD-315D

2.8 Panel Mounting

This LCD Display can be placed on a shelf or table, or mounted onto the wall. To mount it onto the wall, you need the mounting brackets, which you will find them in the accessory box. Follow the steps described below:

100

Chapter 2 Hardware Installation 2-9

LCD Display AGD-315D

AGD-315D series can be mounted to the industrial standard 15" rack directly. There are four screw holes on each side of the panel.

Chapter 2 Hardware Installation 2-10

Analog Rackmount

LCD Display AGD-315D

2.9 Easy Stand, Swing-ARM Mounting

The AGD-315D series can be mounted in different ways. You can place the desktop stand for desktop use or attach it on a swing-arm bracket.

Easy Stand

The brackets of easy stand are attached to the rear of AGD-315D. First of all, loosen the screw of point A. Then, unscrew the screw of point B. Pull down the bracket and use the screw got from point A to fasten the bracket in point B. There should be no screw in point A.

Chapter 2 Hardware Installation 2-11

LCD Display AGD-315D

2.10 VESA Wall Mounting

Mounting the LCD Display with UL Listed Wallmount Bracket only. The LCD Display can be mounted on a monitor arm or wallmount plate.

Caution: When mounting the LCD Display, take care to tighten the

retention screws or bolts until fully secured, but do not over tighten. Over tighting the retention screws or bolts may cause them to become stripped, rendering them useless.

Monitor Arm or Wallmount Plate Installation

The LCD Display has Video Electronics Standards Association (VESA) standard mounting holes tapped into the rear panel. The standard holes are M4 set at 100mm x 100mm apart.

Chapter 2 Hardware Installation 2-12

LCD Display AGD-315D

VESA Mounting Holes

To mount the LCD Display onto a monitor arm or wallmount plate, please follow the steps below.

Step 1: Line up the threaded holes on the monitor rear panel with

the screw holes on the monitor arm or wallmount plate.

Step 2: Secure the monitor to the arm or stand with the retention

screws supplied with the monitor arm or stand.

Chapter 2 Hardware Installation 2-13

LCD Display AGD-315D

Chapter

On Screen

Display Control

Chapter 3 On Screen Display Control 3-1

LCD Display AGD-315D

3.1 On Screen Display (OSD) Board Description

Buttons Description

Power  Turn the monitor power ON or OFF.

Menu / Enter

UP / Right / Increase / Input select

Down/ Left / Decrease

Auto

 Activate the OSD menu.  Enter/confirm the selected option.  Move the selector to the next option.  Increase the gauge value of the

selected option.

 Change input source.  Move the selector to the previous

option.

 Decrease the gauge value of the

selected option.

 Automatically adjust the clock,

phase, H-position and V-position.

 Value to the most optimal settings.

Use full screen when enabling this function.

Chapter 3 On Screen Display Control 3-2
