L38I User's Manual
1 Packing List
2 Install APP
A B C D
A：Tracker module
B：Charger cradle
C：User Manual
D：USB-cable
Setting the wristband, reviewing and saving exercise data in the “3PLUS ELITE”APP.
Please log in http://appscomm.cn or scan the following QR codes to download the
“3PLUS ELITE”APP.
Device compatibility: apple’s device and android device with Bluetooth4.0
1
System compatibility： iOS7.0 and above， Android 4.3 and abov.
3 Charging
Low power
Charging process
Charging process
Charging
completed
4 Switch Interface
Screen is always light on during charging
When full charged, power icon is full. Screen keeps light on for 1min and then will be
off.
Move out the charger, the device will display full charging for 3s, and then in standby
interface.
Your wristband will show an icon device number 。
If there is no operation on the device, screen light off
If pairing is successful, your wristband will show a time icon 。
2
4.1 Device connected
1、turn on the Bluetooth on you mobile device.
5 Switch Interface
2、open the APP on your mobile device. please register or login with an existing
account .click”setup”after entering your personal information.
3、make sure that the band is nearby ,select APP from your Bluetooth menu.
4、The wristband will show pair requirement ，click to pair
5 If pairing is successful, your wristband will show a “connected” icon
； If pairing is failure，the wristband will show an “disconnected”
icon
When APP search out several devices, connect the right one, wristband will
automatically get into bluetooth pair interface. Click to pair. If fail to pair, it will
be back to bluetooth pair interface.
Main Interface
time steps exercise distance calories
Sport time hear
3
5.1 Time
After logging in the phone APP and binding the device successful, the tracker’s time
5.2 Flip screen
5.3 Restart
will be synchronized with the phone automatically.
Vertically rotatable screen display：
This function allows you to choose the orientation of the band which best suited
to your wrist. To flip the screen, enter the “Flip screen?” at the setting menu.
Flip the screen towards left Tap the “Flip screen?” option to
enter the confirmation screen to select either option.
Restarting allows users to restart their device
This function will not delete the data on your device.
To restart your device, enter the “Restart?” at the setting menu.
Restart device Tap on the “Restart？” option on the screen to
enter the confirmation screen to select either option.
4
