1. Remove reservoir cover and fill with
distilled or de-ionized water.
2. Replace reservoir cover.
Up & Running
Up and Running
1. Make sure the wet bulb’s wick is clean. Fill the reservoir with distilled water.
2. Place the QUESTemp in the work area in a safe location approximately 3.5 feet
off the ground.
3. Turn the unit ON. If the battery voltage displayed during the power-on sequence
is less than or equal to 6.4 volts, replace or recharge the batteries.
4. Use the arrow keys to set the display to the desired items.
5. Allow 10 minutes for the sensors to stabilize to the environment before taking
readings.
Check Wick and Fill Natural Wet Bulb
The QUESTemp uses a cotton wick immersed into a reservoir containing distilled water.
Ordinary tap water should not be used, as the contaminants that are left behind after
evaporation will shorten the life of the wick and cause high readings. If the wick is
discolored it should be replaced. To replace the wick, slide the old wick off the top of the
sensor. Place a new wick over the sensor, making sure that the bottom of the wick is
down in the reservoir.
Figure 1-1: Filling wet bulb reservoir
2 Measurements
WBGT (indoor) = 0.7WB + 0.3G (denoted as “WBGTi” on the display)
WBGT (outdoor) = 0.7WB + 0.2G + 0.1DB (denoted as “WBGTo” on the display)
Measurements
Measurements
QUESTemp32
The QUESTemp32 portable area heat stress monitor computes the Wet Bulb Globe
Temperature (WBGT). The WBGT is an accepted measurement for determining the heat
stress level imposed on an individual in a given environment. The QUESTemp32
measures three parameters: ambient or dry bulb temperature (DB), natural wet bulb
temperature (WB), and globe temperature (G).
In addition to the WBGT, the QUESTemp32 measures relative humidity (RH) and
computes the Heat Index (HI) or Humidex. The QUESTemp32, using inputs on the side
of the instrument, has the ability to connect to two additional sensor arrays for monitoring
up to three locations simultaneously.
Wet Bulb Globe Temperature
The WBGT is a weighted average of the three temperature sensors using the following
formulas:
NOTE: The resulting WBGT can be compared to indices of work-rest regimens (stay
times) based upon the work loads. (Please see Appendix A for published heat
exposure tables.)
Heat Index / Humidex
The Heat Index is determined using the dry bulb temperature and relative humidity.
Based upon charts available from the U.S. National Weather Service, Heat Index
represents how an average person feels relative to climate conditions. For a constant
temperature, if the humidity rises, so does the heat index.
The Heat Index is defined over a temperature range of 70F - 120F (21C - 49C) and a
relative humidity range of 30% - 99%. Outside of this range, the instrument will show
dashes in the display for the Heat Index.
The Humidex is used primarily in Canada and is very similar to the Heat Index. The
values are slightly different. The Humidex is defined over a temperature range of 70F -
109F (21C - 43C) and a relative humidity range of 20% - 99%. Outside of this range,
the instrument will show dashes in the display for the Humidex.
3 Keypad Operation
WET 80.5F 1
DRY 92.2F
Keypad
Operation
Keypad Operation
The unit operates using a membrane keypad with 4 keys. The I/O ENTER key
responds when the key is released while all other keys respond when the key is
pressed.
I/O Enter
The unit turns on with a single key press. The unit turns off by holding the key down
while a countdown of 3-2-1 occurs in the lower right corner of the display. This key is
also used to enter setup changes.
While viewing live readings, pressing and releasing the key will cause the display to
view the next available sensor bar (indicated in the upper right corner of the display).
Up Arrow
Changes which items appear in the display. Scrolls up.
Down Arrow
Changes which items appear in the display. Scrolls down.
Setup
Allows changing the setup parameters. Three parameters are available: Celsius or
Fahrenheit, the language, and Heat Index or Humidex. Press setup to access the
parameters. Use the arrow keys to switch between the two parameters. Use the
enter key to change the parameters. Press setup again to exit.
Displayed Items
The number in the upper right corner indicates which sensor bar’s data is displayed.
1 indicates the sensor bar placed on (or attached to) the top of the instrument.
Sensors 2 and 3 are labeled on the side of the unit. W indicates the weighted average
which only appears if a WBGT is displayed and all three sensor bars are attached.
The following measurements can be accessed on the display:
