JNPS-0814
目 次 ／ CONTENTS
頁 / PAGE
1. 機能 ·················································································································1
FUNCTION············································································································6
2. 適合対象 ········································································································· 1
COMPATIBLE OBJECTS ····················································································· 6
3. 関連仕様図 ·····································································································1
RELATED SPECIFICATION DRAWINGS ························································ 6
4. 関連規格類 ·····································································································1
RELATED TEST STANDARDS ········································································· 6
5. 適用 ·················································································································2
APPLICATION······································································································7
6. 品質特性 ·······································································································3
QUALITY PERFORMANCE·················································································8
7. 製品上めっき仕様識別表示 ··········································································5
PLATING SPEC INDICATION ON CONNECTOR············································10
8. 包装＆表示 ·····································································································5
PACKAGE & IDENTIFICATION ······································································· 10
9. 保管 ·················································································································5
STORAGE············································································································10
10. 注意事項 ········································································································· 5
ATTENTIONS ····································································································· 10
i
Page 3
JNPS-0814
1. FUNCTION
This connector is one of MDR board mount receptacle straight series. And mating side has 2 rows of
female contacts with the pitch of 1.27mm and contact tails are arranged in 1.27mm
grid. This connector can be mounted on the compatible PC board and mating with MDR plug connector
enables to have the electrical performance.
This connector is grounded by screw lockdown.
2. COMPATIBLE OBJECTS
2-1 COMPATIBLE CONNECTORS
3M BRAND MDR PLUG : 101XX-XXXX XX
2-2 COMPAIBLE PC BOARDS
PCB with solder plating hole
See RELATED SPECIFICATION DRAWINGS recommended hole pattern.
4U-0010-0466-2
3. RELATED SPECIFICATION DRAWINGS
×1.905mm staggered
See the drawings described in JNPD-0814.
4. RELATED TEST STANDARDS
MIL-STD-202
JEIDA-38-1984
JIS C 0050
JNTM-0039, JNTM-0040
*JNTM: Test Method Standard of Sumitomo 3M for Electronic and Electrical Component Parts.
６
Page 4
JNPS-0814
5. APPLICATION
PRODUCT NUMBER INFORMATION
102 XX – 6 2 X 2 PX
SOLDER TAIL
2 : 3.4mm
PLATING THICKNESS SUFFIX
PL : under Nickel Plating
CONTACT AREA / Gold Plating 0.2 µm Min.
TAIL AREA / Gold Flash Plating
with Lubricant Treatment
PE : under Nickel Plating
CONTACT AREA / Gold Plating 0.5 µm Min.
TAIL AREA / Gold Flash Plating
PC : under Nickel Plating
CONTACT AREA / Gold Plating 0.76 µm Min.
TAIL AREA / Gold Flash Plating
RETENTION FEATURE
0 : Screw Lock (M2.6) for PC Board
1 : Screw Lock (M2.5) for PC Board
TYPE
2 : Standard Body
PIN CONFIGURATIONS
6 : Board Mount Straight Type
CONTACT QUANTITY
XX : XX Pos. (Exception: 100 pos. is shown "A0".)
PRODUCT SERIES NAME
102 : MDR Receptacle
７
Page 5
JNPS-0814
6. QUALITY PERFORMANCE
6-1 RATING
ITEM RATING
CURRENT
VOLTAGE
TEMPERATURE
AC: 150V Max. / DC: 200V Max.
0.5A Max.
-55°C ~ 85°C
6-2 PHYSICAL SPECIFICATIONS * The value in ( ) is reference.
TEST
DESCRIPTION
CONTACT
RETENTION FORCE
INSERTION &
WITHDRAWAL
FORCE
CONTACT
SOLDER ABILITY
SOLDERING HEAT
RESISTANCE
REQUIREMENT TEST CONDITION
7.85N (0.8 kgf) Min. Tensile speed 5mm / min.
Insertion Force:
1.47N (150 gf) Max.
Withdrawal Force:
0.39N (40 gf) Min.
Wetting: 95% Min.
or
Zero cross time:
3 seconds Max.
Connector should not have
any defect portions after test.
Tensile speed 5mm / min with
Compatible connector.
Spec. Value is estimated by one
contact pin.
Solder: Sn-3Ag-0.5Cu
- Wetting Measurement:
245°C, 3 seconds
- Wetting Balance Method:
245°C
Dip soldering:
260°C, 10 seconds, 2 times or
263°C, 5seconds, 2 times
* Pre-heat Condition:
Temp. of Components
100°C Max.
Duration 60 seconds Max.
Soldering iron:
390°C, 3 seconds, 2 times
RELATED
STANDARD
――――
――――
JNTM-0039
JIS C 0050
JNTM-0040
８
Page 6
JNPS-0814
6-3 ELECTRICAL SPECIFICATIONS
TEST
DESCRIPTION
DIELECTRIC
WITHSTANDING
VOLTAGE
INSULATION
RESIDENSE
DISCONTINUITY
CONTACT
RESISTANCE
REQUIREMENT TEST CONDITION
No appearance of arcing
and break down.
Leak current: 1mA Max.
500MΩ Min.
Impressed voltage is AC 500V rms.
between adjacent two contacts for one
minute.
Impressed voltage is DC 500V between
adjacent two contacts for one minute.
Less than 1µs
- Vibration test
* as the part of 3M SEQUENCE-II
- Mechanical sock test
Initial /
for each plating spec.
35mΩ Max.
Contact resistance is measured
at Short Circuit.
Current: 1.5mA
Open Circuit Voltage: 20mV
by 4 terminal method.
* Measurement values include
the resistance of contact pins
as conductive material.
Change of contact
resistance after
evaluation tests/
for each plating spec.
± 25mΩ Max.
(1) PL Plating
3M SEQUENCE -I /
mating (30 cycles) Æ moisture
Æ salt spray
3M SEQUENCE -II /
thermal shock Æ humidity
Æ vibration
3M SEQUENCE -III /
thermal life
S GAS SEQUENCE /
H
2
mating (30 cycles)Æ H
S gas
2
DURABILITY /
300 cycles
MECHANICAL SHOCK /
(2) PE Plating
and PC Plating
3M SEQUENCE -I /
mating (50 cycles) Æ moisture
Æ salt spray
3M SEQUENCE -II /
thermal shock Æ humidity
Æ vibration
3M SEQUENCE -III /
thermal life
S GAS SEQUENCE /
H
2
mating (50 cycles)Æ H
S gas
2
DURABILITY /
500 cycles
* NOTE: See Table 1.
for environmental tests.
RELATED
STANDARD
――――
――――
See Table 1.
See Table 1.
９
Page 7
JNPS-0814
Table 1: ENVIROMENTAL TEST
ITEM
TEST CONDITION RELATED STANDARD
MOISTURE
SALT SPRAY
THERMAL SHOCK
HUMIDITY
(STEADY STATE)
THERMAL LIFE
H2S GAS
VIBRATION
MECHANICAL
SHOCK
-10 ∼ 65°C, Relative Humidity 95% / 10 cycles
NaCl 5% solution, 35°C / 48 hours
-55°C→25°C→85°C→25°C / 5 cycles
40°C, Relative Humidity 95% / 96 hours
Steady Current: Current Rating × 110%, 85°C / 1000 hours
3 ± 1 ppm, 40°C, Relative Humidity 70 ∼ 80% / 96 hours
Sweep Freq.: 10 ∼ 55Hz, Amplitude: 1.52mm (or 98 m/s
Sweep Cycle: 1 min., Sweep time: 2 hours
Sweep Directions: X, Y, Z
490 m/s2, 11ms, Half sine shock pulse.
3 times / X,Y,Z directions (Total 9 times)
2
MIL-STD-202F106D
MIL-STD-202F101D
MIL-STD-202F107G
MIL-STD-202F103B
――――
JEIDA-38-1984
)
MIL-STD-202F201A
MIL-STD-202E213B
7. PLATING SPEC INDICATION ON CONNECTOR
The first letter, in stamped 3 letters on the connector body for lot numbering, identified the following
plating specs.
R
XX : PL plating
Z
XX : PE plating
Y
XX : PC plating
* XX : two alphabet letters
8. PACKAGE & IDENTIFICATION
These products are packed with plastic tray and carton box for transit.
Carton box is identified by part number, quantity, maker name and lot number.
9. STORAGE
This products shall be stored in a room, ambient temperature 5 ∼ 35°C, and ambient humidity
40 ∼ 70%.
