3M™ Round Conductor Flat Cable
.025″ 30 AWG Stranded, PVC 3754 Series
• Close spacing permits higher signal density
• PVC insulation provides excellent flexibility
• 30 AWG stranded on .025 inch spacing allows
for mass termination as well as increased flexibility
• Recommended for use with the 82XXX-600X
Series .050
Socket (82XXX-600X) and Pak 25 (P25E-XXX-STGF)
• RoHS* compliant
Date Modified: March 29, 2005
″ x.100″ Tripolarized Wiremount Mini
TS-0875-11
Sheet 1 of 2
Physical
Insulation
Material:
Color:
Marking:
Standard:
Canadian Option:
Conductors:
Polyvinyl Chloride (PVC)
Gray
None
AWM 20596 105C 30V VW1 3M NU
C AWM IA 105C 30V FT1
30 AWG 7 X 38 [ 7 X 0.102 ] Tinned Stranded Copper
EU <50V
Electrical
Voltage Rating:
Insulation Resistance:
Characteristic Impedance:
Capacitance:
Inductance:
Propagation Delay:
Velocity of Propagation:
Note:Unbalanced is measured between ground-signal-ground conductors. Balanced is measured between signal conductors within a pair.
USA: 30V Canada: 30V EU: <50V
> 1 × 1010 Ω/10 ft. [ 3m ]
Unbalanced Balanced
73 Ω 122 Ω
20.8 pF/ft (68.2 pF/m) 12.0 pF/ft (39.4 pF/m)
.11 µH/ft (0.36 µH/m) .18 µΗ/ft (0.59 µΗ/m)
1.51 ns/ft (4.95 ns/m) 1.45 ns/ft (4.76 ns/m)
67% 70%
Environmental
Temperature Rating:
Flammability Rating:
UL File No.: E42769, Style No.: 20596
3M
Interconnect Solutions
http://www.3M.com/interconnects/
-20°C to +105°C
USA:VW-1 Canada:FT1
Restriction of the Use of Certain Hazardous Substances in Electrical and Electronic Equipment
*RoHS = Directive 2002/95/EC,
3M is a trademark of 3M Company.
For technical, sales or ordering information call
800-225-5373
3M™ Round Conductor Flat Cable
.025″ 30 AWG Stranded, PVC 3754 Series
(OPTIONAL)
Number of
Conductors
3M Part
Number
Dimension A Dimension B
20 3754/20 0.500 ± .006 [ 12.70 ] 0.475 ± .004 [ 12.07 ]
26 3754/26 0.650 ± .006 [ 16.51 ] 0.625 ± .004 [ 15.88 ]
30 3754/30 0.750 ± .006 [ 19.05 ] 0.725 ± .006 [ 18.42 ]
32 3754/32 0.800 ± .008 [ 20.32 ] 0.775 ± .006 [ 19.69 ]
34 3754/34 0.850 ± .009 [ 21.59 ] 0.825 ± .006 [ 20.96 ]
36 3754/36 0.900 ± .009 [ 22.86 ] 0.875 ± .006[ 22.23 ]
40 3754/40 1.000 ± .009[ 25.40 ] 0.975 ± .006 [ 24.77 ]
50 3754/50 1.250 ± .009 [ 31.75 ] 1.225 ± .006 [ 31.12 ]
52 3754/52 1.300 ± .009 [ 33.02 ] 1.275 ± .006 [ 32.39 ]
60 3754/60 1.500 ± .012 [ 38.10 ] 1.475 ± .009 [ 37.47 ]
68 3754/68 1.700 ± .012 [ 43.18 ] 1.675 ± .009 [ 42.55 ]
80 3754/80 2.000 ± .015 [ 50.80 ] 1.975 ± .011 [ 50.17 ]
100 3754/100 2.500 ± .015 [ 63.50 ] 2.475 ± .012 [ 62.87 ]
A
B
.013 ± .005
[ 0.33 ]
.025 ± .003
[ 0.64 ]
Note:
1. Red marking on one edge of cable designates wire #1.
Ordering Information
30 AWG 7 X 38 ( 7 X 0.102 ) Tinned
Stranded Copper Conductors
.025 ± .002 Typ
[ 0.64 ]
PVC Insulation
Inch
[mm]
Tolerance Unless Noted
.0 .00
Inch
[ ] Dimensions for
±.01
±.1
Reference only
.000
±.005
Note:
2. Standard lengths of 300 feet.
3M
Interconnect Solutions
http://www.3M.com/interconnects/
Blank = Standard
C = Canadian Certified Version
3754/XX
Number of Conductors
(See Table)
TS-0875-11
Sheet 2 of 2
3M is a trademark of 3M Company.
For technical, sales or ordering information call
800-225-5373
