32 Degrees Rebel User Manual

Operation Guide

Instruction Manual

Safety

Play Safe

1. Never point a paintball marker at anyone not wearing paintball approved goggles. Even at the lowest possible operating velocity, a paintball will cause serious injury should it hit someone in the eye area.

Congratulations on your purchase of the 32 Degrees Rebel semi-auto. Before you use this marker, please read this manual in its entirety. Please follow all safety instructions as described in this manual.

Warning

This paintball marker is not a toy. Misuse or mishandling can result in serious injury or death. The Rebel is to be used by adults 18 years of age or older,or under the direct supervision of an adult. Please follow all local, state, and federal laws concerning paintball markers and playing paintball. By purchasing this marker you assume all liability. 32 Degrees accepts no liability for injury or death due to misuse or mishandling of this marker.

Rebel Specifications

Model Rebel Semi-Auto Caliber .68 Action Blow Back Semi-Auto Power C02 or Compressed air Cycle Rate Up to 6 balls per second Effective Range 150+ feet Length 16.5 inches Height 10.5 inches

2. Never look down the barrel of your marker with or without wearing paintball approved goggles.

3. Always disconnect your air-source and dry fire the marker before working on or cleaning it. Always have a qualified air smith do repairs or modifications to your Rebel.

4. Always leave the Rebel uncocked and turn the power feed plug to the “off” position.

5. Only play at commercial playing fields that have a chronograph, referees and clearly marked safe fields. Chronograph your marker before each game to ensure your gun is operating at safe velocities. Safe velocities are considered to be below 280 feet per second.

Always wear

Paintball Approved

Goggles

maintenance

Getting Started

General Description and Basic Use Instructions Included with your Rebel semi-auto should be the following items:

• Rebel Semi-Auto

• Barrel

• Low Pressure Chamber

• Packet with o-rings, velocity thumb screw, and allen wrench

• Separate Allen wrench

The 32 Degrees Rebel is almost ready to use out of the box. All that is needed is a C02 tank, paintballs, and a feeder, and then you are ready use your marker. First screw in your barrel (hand tight). Now that your barrel is in, insert the barrel plug into the front of the barrel. With your barrel plug in, you are ready to work on your marker. Next push the safety in the “safe” position and attach your feeder elbow and feeder to the power feed tube. Turn the power feed plug so that it does not allow paintballs to enter the chamber. Screw the low pressure chamber into the front end of the marker, just below the barrel. Now that you have everything connected you are ready to gas up the gun. Before you gas up the marker you should always wear paintball approved goggles.

Now that the goggles are on make sure your marker is in the cocked position. Install the C02 tank and your Rebel is ready to fire. Make sure you chronograph your marker before you use it. Like any other paint marker, maintenance is the key to keeping the Rebel shooting consistently. This chapter is a basic overview of what it takes to keep the Rebel functioning properly.

Lubrication: To keep your Rebel’s internal

components operating smoothly, place about four drops of oil in your gun’s C02 adapter and dry fire the gun (after removing the barrel). This will spread the oil throughout the gun. After cleaning your Rebel internally, lube the hammer/push strut assembly as well--be careful not to over-oil this area.

Warning: Some petroleum based oils can damage

your gun’s o-rings. Use only oil manufactured specifically for paintball markers.If you expect any degree of consistency from your Rebel, you must keep it clean internally and externally. The two external areas you’ll need to be the most careful with are the power feed/feed tube and the barrel. If you break a ball in the barrel, you will lose most of your accuracy until you clean it completely. On the field, remove the barrel and run a pull-through squeegee through it. For a more complete cleaning (off the field) you’ll need to clean the barrel with warm water or barrel cleaner/treatment and squeegee it until it is dry. A pull-through squeegee can also be used to clean the power feed once the plug is removed.
