10Zig V1200-QPD Product Data Sheet

Part Number: V1200-PD, V1200-QPD - Display Port
(10/100/1000 Base-T Gigabit Ethernet)

V1200 Series Zero Clients for VMware

Next-Generation Tera2 PCoIP Portal Processor

The V1200 Series is 10ZiG's next-generation TERA2 PCoIP Zero Client. This device supports the eciency and
security of centralized computing and oers an uncompromised desktop experience. The V1200's latest chip
set (TERA2 PCoIP Portal Processor) provides a powerful, secure and easy to manage PCoIP Zero Client. The
Zero Client oers a seamless solution with dynamic features and a performance that will meet the needs of
any expanding VDI environment.

Specically designed with a small footprint, the V1200 Series only consumes between 6-12 Watts of power.
This is half the power of the previous generations, thus helping any organization lower their power con­sumption and general virus exposure resulting in a much lower total cost of ownership.

The Zero Client eliminates the need for running, managing, maintaining or securing enterprise desktops
while still delivering high end user elements. With four USB ports, rich multimedia playback, HD audio and
multiple monitor support, the V1200 is the perfect t for any VMware VDI environment.

► TERA2 PCoIP Portal Processor

► Digital Fiber Connections

► Dual/Quad - Display Ports

Americas P: 866-865-5250 E: [e-mail] W: www.10ZiG.com
EMEA P: [phone] E: [e-mail] W: www.10ZiG.eu
APAC P: 1300 768 799 E: [e-mail] W: www.10ZiG.com.au

► 2x 2560x1600 Res 4x 1920x1200 Res

► VESA Mounting capability

► Free Centralized Management

Learn More

TERA2 PCoIP Zero Clients

With Fiber Connectivity

V1200-PD and V1200-QPD

System V1200-PD V1200-QPD

Management Teradici Management Teradici Management

Form Factor Slim Line Slim Line

Processor Teradici PCoIP™ Portal Processor -TERA2 Teradici PCoIP™ Portal Processor-TERA2

Chipset TERA2321 PCoIP™ TERA2140 PCoIP™

Dimensions

Device 6.89" (Height) x 5.20" (Length) x 1.42" (Thinness) 7.21" (Height) x 5.22" (Length) x 1.76" (Thinness)

Weight 1.0lbs - 0.4kgs 1.25lbs - 0.6kgs

Connections

Ports

Video 1 x (2560 x 1600) - 2 x (1920 x 1200) 2 x (2560 x 1600) - 4 x (1920 x 1200)

Imaging 50 Mpps (VDI) - 150 Mpps (WS)* 50 Mpps (VDI) - 300 Mpps (WS)*

4 Display Ports - 4 External USB 2.0 Ports (2 Front, 2 Back)
DVI-I x 1, DVI-D x 1*, Mic-In x 1, Line-Out x 1

4 Display Ports - 4 External USB 2.0 Ports (2 Front, 2 Back)
DVI-I x 1, DVI-D x 1*, Mic-In x 1, Line-Out x 1

Network

Connectivity 10/100/1000 Base-T Gigabit Ethernet 10/100/1000 Base-T Gigabit Ethernet

Environmental

Operating Temp.

Power

50~104F (10~40C), 10-95%
non-condensing humidity

6 Watt Consumption, 36 Watt,
DC-12V/3A Input

50~104F (10~40C), 10-95%
non-condensing humidity

12 Watt Consumption, 36 Watt,
DC-12V/3A Input
