Desktop Virtualization Made Simple
Americas
APAC
Part Number: 5848qc
5848qc Zero Client for Citrix
Performance Class
At 10ZiG we are constantly evolving to meet the ever increasing demands of VDI, DaaS, and
Application Delivery.
The 5848qc is certifi ed Citrix Ready by Citrix and addresses all of your requirements for
Multi-Monitor Support, Full HD Multimedia Content, as well as NVIDIA GRID (Citrix HDX 3D Pro)
for use with 3D Graphics, CAD, and USB 3.0; giving YOU total power and performance in a
future-proof design.
Fueled by an industry leading Intel 2.0 GHz Quad Core Processor with "Boost" enabled speeds
up to 2.42 GHz, the 5848qc is the future of today's desktop.
► Citrix HDX Pro Technology Supported
CERTIFIED
► Backwards Compatible with 5800 Series
► 7 x USB Ports (1 x USB 3.0)
► Dual DVI Monitor Support (Standard)
► Supports Local Flash Redirection
► FREE Centralized Management
► Optional Wireless & VESA Mounting
Page 2
5848qc Zero Client for Citrix
Americas
APAC
System
Management
Form Factor
Processor
Processor Graphics
10ZiG Manager
Mini
Intel Quad Core 2.0 - 2.42 GHz (Boost)
Intel HD Graphics
Dimensions
Device
Weight
1.7"(W) x 7.8"(H) x 5.1"(D) - 42mm x 198mm x 140mm
2.53 lbs (1.15kg)
Connections
Ports
Video
USB 2.0 x 6, USB 3.0 x 1, Mic-In x 1, Line-Out x 1, RJ-45 LAN, DC Jack x 1
1920 x 1200, DVI-D x 1, DVI-I x 1 (VGA Supported with Included Adapter)
Networking
Wireless
Ethernet
Optional (802.11 a/b/g/n Internal Wireless)
10/100/1000 Base-T
Environmental
Operating Temp.
Power
WARRANTY: All Thin Clients include a 3-Year Advanced Exchange Warranty
32-105F (0-35C), 20-80% non-condensing humidity
10 Watt Consumption, 36 Watt, DC-12V/3A External Power Adapter
1
2
3
4
1. Power Button/Power HDD LED
2. Front USB (2)
3. Mic In
4. Line Out
5. Secure USB (1)
6. Back USB (4)
7. Ethernet -RJ45 LAN port
8. DVI-D
9. DVI-I
10. DC Jack
11. Kensington Lock
5
7
6
8
9
10
11
5848qc
Operating System
NOS
Memory
RAM
MIN: 2GB
MAX: 8GB
Software
VDI Connection Brokers Supported
Software Applications Citrix Receiver, VNC
Citrix VDI-in-a-Box
XenApp - XenDesktop w/ HDX
VESA Mounting Capable
