10Zig V1200-QP Product Data Sheet

Americas P: [phone] E: [e-mail]
EMEA P: [phone] E: [e-mail] W: www.10ZiG.com
APAC P: [phone] E: [e-mail]
DE P: [phone] E: [e-mail]

Cutting Edge Thin & Zero Clients

V1200-QP Zero Client for VMware and Amazon WorkSpaces

TERA2 PCoIP® Portal Processor

Industry Leading VDI Performance

Model Numbers: V1200-QP, V1200-QPS, V1200-QPD

The 10ZiG V1200-QP is part of our V1200 Tera2 PCoIP® Zero Client Series optimized for VMware and Amazon
WorkSpaces environments. With no operating system and no local storage, the V1200 Series line provides
an ultra-secure yet powerful and easy to manage endpoint that eliminates the chance of viruses and provides
extensive USB security and authentication features. With options ranging from dual through quad screen, PoE,
Fiber, DVI-I, DVI-D, 4 DisplayPort and Internal Smart Card (CAC) with up to 6 USB 2.0 ports as well as standard TAA
Compliance on all V1200 Series Zero Clients, you can be confident in finding a device that will fit your ideal use
case environment.

The V1200-QP model highlighted below supports quad screens and comes equipped with either 4 x DVI-D or 4 x
DisplayPort and 4 x USB 2.0, along with an optional Internal (CAC) Smart Card Reader and Fiber. All 10ZiG V1200
Series PCoIP® Zero Clients receive a one-year, free subscription to the Teradici Desktop Access Plan. The Desktop
Access Plan includes the Teradici Management Console with a subscription to firmware and security updates as
well as tech support.

DVI-D Model Internal (CAC) Smart Card Model DisplayPort Model

► Tera2 PCoIP Portal Processor, Tera2140 PCoIP Chipset

► 4 x DVI-D or 4 x DisplayPort

► 4 x USB 2.0

► Optional Internal (CAC) Smart Card Reader

► Optional Fiber

► TAA Compliant

► 1 year free subscription to Teradici Desktop Access Plan

V1200-QP Zero Client

Americas P: [phone] E: [e-mail]
EMEA P: [phone] E: [e-mail] W: www.10ZiG.com
APAC P: [phone] E: [e-mail]
DE P: [phone] E: [e-mail]

Tera2 PCoIP Zero Client Series

1

2

3

4

5

System Specifications

6

7

8

9

10

11

S

1. Power On Indicator Light

2. Power Button

3. USB 2.0 (2)

4. Front Line Out

5. Mic In

6. USB 2.0 (2)

7. RJ45 LAN Port

8. DVI-D (4) or DisplayPort (4)

9. Kensington Lock

10. Rear Line Out

11. DC Jack

Management Utility Teradici Management

Form Factor Slim Line

Processor Teradici PCoIP® Portal Processor - TERA2

Chipset TERA2140 PCoIP®

Dimensions

Device 5.22"(D) x 1.76"(W) x 7.21"(H) - 150mm x 130mm x 45mm

Weight 1.81 lbs (0.82 kg)

Connections

Ports

4 x USB 2.0, 4 x DVI-D or 4 x DisplayPort 1 x Mic In, 2 x Line Out, RJ-45
LAN, 1 x DC Jack

Video Resolution 2 Monitors at 2560 x 1600* or 4 Monitors at 1920 x 1200

Networking

Ethernet 10/100/1000 Base-T

Fiber Optional SFP Fiber Connector (100/1000Mbps)

Environmental

Operating Temp. 32-104F (0-40C), 10-90% non-condensing humidity

Power 12 Watts, DC-12V/3A External Power Adapter

Certifications

CE, FCC, CAN ICES-3/NMB-3, VCCI, UL, TUV-GS, C-Tick, GOST, BSMI, RoHS

* 2 x 2560 x 1600 requires the Hi-Res Video Cable (Part No: 9017)
