ZyXEL Communications P-2302R-P1 User Manual

P-2302R-P1 Series

VoIP ATA / Station Gateway

Quick Start Guide

Version 3.60

Edition 1

5/2006

P-2302R-P1 Series Quick Start Guide

Overview

This guide explains how to set up your P-2302R-P1 Series device (“P-2302R-P1“) to make phone calls over the Internet. For the P-2302RL-P1, it also explains how to set up regular phone services that do not use the Internet.

The following figure shows a typical way to use your P-2302R-P1.

When you make a phone call over the Internet, you use one of your telephones (A) to dial the number. The telephones are connected to your P-2302R-P1 (C), which is connected to the broadband modem or router that provides Internet access (D).

When you want to use the Internet, you use your computer (B). Your computer is connected to your P-2302RP1 (C), which is connected to the broadband modem or router that provides Internet access (D).

When you want to configure the P-2302R-P1 (C), you also use your computer (B).

1 Requirements

Make sure you have the following things before you set up your P-2302R-P1.

• Internet access - account information provided by your ISP, such as user name, password, and so on.

• VoIP account - You need the account information provided by your VoIP service provider (the company that lets you make phone calls over the Internet). This information might include your URI, number, and so on.

• Internet Explorer 6.0 or later or Netscape Navigator 7.0 or later, with JavaScript enabled.

P-2302R-P1 Series Quick Start Guide

2 Hardware Connections

1LINE (P-2302RL-P1 only): Use a telephone cable to connect the telephone jack to this port.

2 PHONE 1-2: Use a telephone cable (and any telephone adaptors provided with your P-2302R-P1) to

connect your telephones to these ports. If you only have one telephone, you should only use one port.

3ETHERNET: Use an Ethernet cable to connect your computer to this port.

4WAN: Use an Ethernet cable to connect your broadband modem or router to this port.

5POWER: Use the power adaptor provided with your P-2302R-P1 to connect an appropriate power source

to this port.

On the front panel, the POWER light flashes green while your P-2302R-P1 starts up and stays green once it is ready. The WAN and ETHERNET lights turn on if the WAN and ETHERNET ports are properly connected. These lights flash when the P-2302R-P1 is sending or receiving data.

P-2302R-P1 Series Quick Start Guide

3 Initial Configuration

Use a web browser on your computer to set up your P-2302R-P1. See Troubleshooting if you have any problems.

3.1 Open the Wizard Setup Screen

1 Launch your web browser. 2 Enter http://192.168.1.1 as the address or URL.

3 Click Login. 4 Type a new password, re-type it to confirm, and

click Apply. (The next time you log in, you should not see this screen.)

5 Click Go to Advanced setup. 6 In the main screen, click the Wizard icon in the

upper right corner.

If the INTERNET light is green, go to section 3.3. Otherwise, go to section 3.2.

P-2302R-P1 Series Quick Start Guide

3.2 Connection Wizard

If you subscribe to a Roadrunner service, you cannot use the Connection Wizard to set up your Internet connection. In this case, please see the User’s Guide for instructions.

Note: You must have Internet access before you can complete this section.

1 In the Wizard Setup screen, click Connection

Wizard.

3 System Name is used to identify the P-2302R-P1

in the network. Use the default value, unless you know the name is already used in the network.

Domain Name (optional): Enter the appropriate name, if there is one, or use the default value.

Click Next.

2 Click Next.

4 This screen has different fields, depending on the

connection type (encapsulation) your ISP uses. Select Ethernet or PPP over Ethernet (PPPoE). If you are not sure and if your ISP gave you a user name and password, select PPP over Ethernet. Then, follow the instructions in the appropriate section below.

+ 9 hidden pages
