ZyXEL Communications 128MH User Manual

Prestige 128MH

User's Manual

Version 1.0

ZyXEL

TOTAL INTERNET ACCESS SOLUTION

Prestige 128MH PSTN Router/Hub

Prestige 128MH

PSTN Router/Hub

Copyright

Copyright © 1998 by ZyXEL Communications Corporation.

The contents of this publication may not be reproduced in any part or as a whole, transcribed, stored in a retrieval
system, translated into any language, or transmitted in any form or by any means, electronic, mechanical, magnetic,
optical, chemical, photocopying, manual, or otherwise, without the prior written permission of ZyXEL
Communications Corporation.

Published by ZyXEL Communications Corporation. All rights reserved.

Disclaimer

ZyXEL does not assume any liability arising out of the application or use of any products, or software described herein.
Neither does it convey any license under its patent rights nor the patents rights of others. ZyXEL further reserves the
right to make changes in any products described herein without notice. This publication is subject to change without
notice.

Trademarks

Trademarks mentioned in this publication are used for identification purposes only and may be properties of their
respective owners.

ii

Prestige 128MH PSTN Router/Hub

FCC Interference Statement

Federal Communications Commission (FCC) Interference Statement

This device complies with Part 15 of FCC rules. Operation is subject to the following two conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference received, including interference that may cause undesired operations.

This equipment has been tested and found to comply with the limits for a CLASS B digital device pursuant to Part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy, and if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.

If this equipment does cause harmful interference to radio/television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the following
measures:

1. Reorient or relocate the receiving antenna.

2. Increase the separation between the equipment and the receiver.

3. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

4. Consult the dealer or an experienced radio/TV technician for help.

Notice 1

Changes or modifications not expressly approved by the party responsible for compliance could void the user's
authority to operate the equipment.

Notice 2

Shielded RS-232 cables are required to be used to ensure compliance with FCC Part 15, and it is the responsibility of
the user to provide and use shielded RS-232 cables.

iii

Prestige 128MH PSTN Router/Hub

Information for Canadian Users

Information for Canadian Users

The Industry Canada label identifies certified equipment. This certification means that the equipment meets certain
telecommunications network protective, operation, and safety requirements. The Industry Canada does not guarantee
that the equipment will operate to a user's satisfaction.

Before installing this equipment, users should ensure that it is permissible to be connected to the facilities of the local
telecommunications company. The equipment must also be installed using an acceptable method of connection. In some
cases, the company's inside wiring associated with a single line individual service may be extended by means of a
certified connector assembly. The customer should be aware that the compliance with the above conditions may not
prevent degradation of service in some situations.

Repairs to certified equipment should be made by an authorized Canadian maintenance facility designated by the
supplier. Any repairs or alterations made by the user to this equipment, or equipment malfunctions, may give the
telecommunications company cause to request the user to disconnect the equipment.

For their own protection, users should ensure that the electrical ground connections of the power utility, telephone lines,
and internal metallic water pipe system, if present, are connected together. This precaution may be particularly
important in rural areas.

Caution

Users should not attempt to make such connections themselves, but should contact the appropriate electrical inspection
authority, or electrician, as appropriate.

Note

This digital apparatus does not exceed the class A limits for radio noise emissions from digital apparatus set out in the
radio interference regulations of Industry Canada.

iv

Prestige 128MH PSTN Router/Hub

ZyXEL Limited Warranty

ZyXEL Limited Warranty

ZyXEL warrants to the original end user (purchaser) that this product is free from any defects in materials or
workmanship for a period of up to two (2) years from the date of purchase. During the warranty period, and upon proof
of purchase, should the product have indications of failure due to faulty workmanship and/or materials, ZyXEL will, at
its discretion, repair or replace the defective products or components without charge for either parts or labor, and to
whatever extent it shall deem necessary to restore the product or components to proper operating condition. Any
replacement will consist of a new or re-manufactured functionally equivalent product of equal value, and will be solely
at the discretion of ZyXEL. This warranty shall not apply if the product is modified, misused, tampered with, damaged
by an act of God, or subjected to abnormal working conditions.

Note

Repair or replacement, as provided under this warranty, is the exclusive remedy of the purchaser. This warranty is in
lieu of all other warranties, express or implied, including any implied warranty of merchantability or fitness for a
particular use or purpose. ZyXEL shall in no event be held liable for indirect or consequential damages of any kind of
character to the purchaser.

To obtain the services of this warranty, contact ZyXEL's Service Center; refer to the separate Warranty Card for your
Return Material Authorization number (RMA). Products must be returned Postage Prepaid. It is recommended that the
unit be insured when shipped. Any returned products without proof of purchase or those with an out-dated warranty
will be repaired or replaced (at the discretion of ZyXEL) and the customer will be billed for parts and labor. All
repaired or replaced products will be shipped by ZyXEL to the corresponding return address, Postage Paid (USA and
territories only). If the customer desires some other return destination beyond the U.S. borders, the customer shall bear
the cost of the return shipment. This warranty gives you specific legal rights, and you may also have other rights which
vary from state to state.

v

Prestige 128MH PSTN Router/Hub

Customer Support

Customer Support

If you have questions about your ZyXEL product or desire assistance, contact ZyXEL Communications Corporation
offices worldwide, in one of the following ways:

North America

ZyXEL Communications Inc.

4920 E. La Palma Avenue
Anaheim, CA 92807
USA
Telephone: [phone] (call between 8:00 AM and 5:00 PM PST)
Facsimile: [phone]
E-mail: - Sales Inquiries: [e-mail]

- Technical Support: [e-mail]

Worldwide Support

ZyXEL Communications Corporation

6, Innovation Road II, Science-Based Industrial Park
Hsinchu, Taiwan 300, R.O.C.
Telephone: [phone] Ext.: 266 (call between 8:00 AM and 5:00 PM [Taiwan time GMT+8:00])
Facsimile: 886-3-578-2439
E-mail: - Sales Inquiries: [e-mail]

- Technical Support: [e-mail]

Product Information

For product information, visit our site on the World Wide Web: http://www.zyxel.com.

FTP Information

Information such as ZyXEL software and ROM updates is available for download at these FTP addresses:

North America: ftp.zyxel.com
Europe: ftp.zyxel.co.at

vi

Prestige 128MH PSTN Router/Hub

Table of Contents

Table of Contents

List of Figures.......................................................................................................................... xi

List of Tables........................................................................................................................... xv

Preface................................................................................................................................... xvii

Chapter 1
Getting to Know Your Router/Hub

1.1 Prestige 128MH PSTN Bridge Router................................................................. 1-1

1.2 Front Panel LEDs and Back Panel Ports............................................................... 1-2

1.3 Features of Prestige 128MH ................................................................................. 1-5

1.4 Applications for Prestige 128MH ........................................................................... 1-8

Chapter 2
Hardware Installation & Initial Setup

2.1 Unpacking your Router/Hub.................................................................................. 2-1

2.2 Additional Installation Requirements...................................................................... 2-2

2.3 Connect your PSTN Router/Hub ........................................................................... 2-3

2.4 Power On Your Prestige........................................................................................2-6

2.5 Navigating the SMT Interface................................................................................ 2-8

2.6 Configure the SMT Password.............................................................................. 2-10

2.7 General Setup..................................................................................................... 2-12

2.8 WAN Setup......................................................................................................... 2-14

2.9 General Ethernet Setup ...................................................................................... 2-21

2.10 Protocol Dependent Ethernet Setup.................................................................... 2-22

Chapter 3
Internet Access Application

3.1 IP Addresses and the Internet............................................................................... 3-1

3.2 Route IP Setup ..................................................................................................... 3-5

3.3 TCP/IP Ethernet Setup and DHCP........................................................................ 3-6

3.4 Internet Access Configuration ............................................................................... 3-9

vii

Prestige 128MH PSTN Router/Hub

Table of Contents

3.5 Single User Account ........................................................................................... 3-12

3.6 Configuring Backup ISP Accounts....................................................................... 3-15

3.7 Editing Script Options.......................................................................................... 3-17

Chapter 4
Telecommuting

4.1 Telecommuting ..................................................................................................... 4-2

4.2 Dial-In Server Application...................................................................................... 4-3

4.3 Default Dial-In Setup ............................................................................................. 4-4

4.4 Dial-In Users Setup ............................................................................................... 4-8

4.5 More on CLID..................................................................................................... 4-10

Chapter 5
Remote Node Configuration for LAN-to-LAN

5.1 Remote Node Setup ............................................................................................. 5-1

5.2 Leased Line Connection ..................................................................................... 5-12

Chapter 6
TCP/IP Configuration for LAN-to-LAN

6.1 LAN-to-LAN Application........................................................................................ 6-1

Chapter 7
Novell IPX Configuration for LAN-to-LAN

7.1 IPX Network Environment..................................................................................... 7-1

7.2 Prestige Operating in IPX Environment................................................................. 7-2

7.3 IPX Spoofing......................................................................................................... 7-3

7.4 IPX Ethernet Setup............................................................................................... 7-4

7.5 LAN-to-LAN Application with Novell IPX................................................................ 7-6

Chapter 8
Bridge Configuration for LAN-to-LAN

8.1 IPX Spoofing......................................................................................................... 8-1

8.2 Bridge Ethernet Setup........................................................................................... 8-2

8.3 LAN-to-LAN Application........................................................................................ 8-4

viii

Prestige 128MH PSTN Router/Hub

Table of Contents

Chapter 9
Filter Configuration

9.1 Configuring a Filter Set ......................................................................................... 9-3

9.2 Configuring a Filter Rule ....................................................................................... 9-7

Chapter 10
Simple Network Management Protocol (SNMP)

10.1 Configuring Your Prestige For SNMP Support..................................................... 10-1

Chapter 11
System Security

11.1 Using RADIUS Authentication..............................................................................11-1

11.2 Configure the SMT Password............................................................................... 11-5

Chapter 12
Telnet Configuration and Capabilities

12.1 About Telnet Configuration.................................................................................. 12-1

12.2 Telnet Capabilities ............................................................................................... 12-2

Chapter 13
System Maintenance

13.1 System Status..................................................................................................... 13-2

13.2 Terminal Baud Rate ............................................................................................ 13-5

13.3 Log and Trace..................................................................................................... 13-5

13.4 Diagnostic........................................................................................................... 13-9

13.5 Backup Configuration........................................................................................ 13-12

13.6 Restore Configuration....................................................................................... 13-12

13.7 Software Update............................................................................................... 13-12

13.8 Command Interpreter Mode .............................................................................. 13-15

13.9 Call Control....................................................................................................... 13-16

ix

Prestige 128MH PSTN Router/Hub

Table of Contents

Chapter 14
Troubleshooting

14.1 Problems Starting Up the Prestige ...................................................................... 14-1

14.2 Problems With the WAN Ports ............................................................................ 14-2

14.3 Problems with the LAN Interface......................................................................... 14-2

14.4 Problems Connecting to a Remote Node or ISP.................................................. 14-3

14.5 Problems Connecting to a Remote User.............................................................. 14-4

Index........................................................................................................................................ I-1

x

Prestige 128MH PSTN Router/Hub

List of Figures

List of Figures

Figure 1-1. Prestige 128MH Front Panel LEDs.................................................................... 1-2

Figure 1-2. Prestige 128MH Back Panel Ports..................................................................... 1-4

Figure 1-3. Internet Access Application............................................................................... 1-8

Figure 1-4. LAN-to-LAN Connection Application.................................................................. 1-9

Figure 1-5. Telecommuting/Remote Access Application..................................................... 1-10

Figure 2-1. Connect Prestige 128MH .................................................................................. 2-3

Figure 2-2. Power-On Display............................................................................................. 2-6

Figure 2-3. Login Screen..................................................................................................... 2-7

Figure 2-4. SMT Main Menu................................................................................................ 2-9

Figure 2-5. Menu 23 - System Security ............................................................................. 2-10

Figure 2-6. Menu 23.1 - System Security - Change Password............................................2-11

Figure 2-7. Menu 1 - General Setup.................................................................................. 2-12

Figure 2-8. Menu 2 - WAN Port Setup............................................................................... 2-15

Figure 2-9a. Menu 2.1 - Async WAN Port Setup for Serial WAN Port 1................................ 2-15

Figure 2-9b. Menu 2.1 - Async WAN Port Setup for WAN Port 1,2 (LINE 1,2)...................... 2-16

Figure 2-10. Menu 2.1.1 - Advanced WAN Port Setup......................................................... 2-18

Figure 2-11. Menu 3 - Ethernet Setup................................................................................. 2-21

Figure 2-12. Menu 3.1 - General Ethernet Setup................................................................. 2-21

Figure 3-1. Menu 1 - General Setup.................................................................................... 3-5

Figure 3-2. Menu 3.2 - TCP/IP and DHCP Ethernet Setup................................................... 3-6

Figure 3-3. Menu 4 - Internet Access Setup......................................................................... 3-9

Figure 3-4. Single User Account Topology......................................................................... 3-12

Figure 3-5. Menu 4 - Internet Access Setup for Single User Account................................. 3-14

Figure 3-6. Menu 11.4 - Remote Node Script..................................................................... 3-17

Figure 4-1. Example of Remote User: Telecommuter........................................................... 4-2

Figure 4-2. Example of a Dial-in Server Application............................................................. 4-3

Figure 4-3. Menu 13 - Default Dial-in Setup......................................................................... 4-4

xi

Prestige 128MH PSTN Router/Hub

List of Figures

Figure 4-4. Menu 14 - Dial-in User Setup............................................................................ 4-8

Figure 4-5. Menu 14.1 - Edit Dial-in User ............................................................................ 4-8

Figure 5-1. Menu 11 - Remote Node Setup......................................................................... 5-2

Figure 5-2. Menu 11.1 - Remote Node Profile for Dial-up Line Applications ......................... 5-2

Figure 5-3. Menu 11.2 - Remote Node PPP Options............................................................ 5-9

Figure 5-4. Menu 11.1 - Remote Node Profile for Leased Line Applications....................... 5-13

Figure 5-5. Menu 11.2 - Remote Node PPP Options for Leased Line Applications............. 5-19

Figure 6-1. LAN-to-LAN Application with TCP/IP................................................................. 6-1

Figure 6-2. Menu 11.3- Remote Node Network Layer Options for a TCP/IP Application....... 6-2

Figure 6-3. Sample IP Addresses for a LAN-to-LAN Connection with TCPI/IP..................... 6-3

Figure 6-4. Example of Static Routing Topology.................................................................. 6-6

Figure 6-5. Menu 12 - Static Route Setup ........................................................................... 6-7

Figure 6-6. Menu 12.1 - Edit IP Static Route ....................................................................... 6-7

Figure 7-1. Prestige Operating in IPX Environment ............................................................. 7-2

Figure 7-2. Menu 3.3 - Novell IPX Ethernet Setup............................................................... 7-4

Figure 7-3. LAN-to-LAN Application with Novell IPX............................................................ 7-6

Figure 7-4. Menu 11.3 - Remote Node Network Layer Options for Novell IPX Application.... 7-7

Figure 7-5. Netware Servers or Both Sides of the Link ........................................................ 7-9

Figure 7-6. Menu 12.2 - Edit IPX Static Route................................................................... 7-10

Figure 8-1. Menu 3.5 - Bridge Ethernet Setup ..................................................................... 8-3

Figure 8-2. Menu 11.3 - Remote Node Network Layer Options for Bridging Configuration.... 8-4

Figure 8-3 Menu 12.3 - Edit Bridge Static Route ................................................................. 8-6

Figure 9-1. Outgoing Packet Filtering Process..................................................................... 9-2

Figure 9-2. Menu 21 - Filter Set Configuration..................................................................... 9-3

Figure 9-3. Menu 21.1 - Filter Rules Summary.................................................................... 9-4

Figure 9-4. Menu 21.1.1 - TCP/IP Filter Rule....................................................................... 9-7

Figure 9-5. Menu 21.1.2 - Generic Filter Rule.................................................................... 9-10

Figure 9-6. Menu 21.1.3 - IPX Filter Rule.......................................................................... 9-12

xii

Prestige 128MH PSTN Router/Hub

List of Figures

Figure 10-1. Menu 22 - SNMP Configuration....................................................................... 10-2

Figure 11-1. Menu 23.2 - System Security - External Server ................................................11-3

Figure 12-1. Telnet Configuration on a TCP/IP Network....................................................... 12-1

Figure 13-1. Menu 24 - System Maintenance...................................................................... 13-1

Figure 13-2. Menu 24.1 - System Maintenance - Status ...................................................... 13-2

Figure 13-3. LAN Packet Which Triggered Last Call............................................................ 13-4

Figure 13-4. Menu 24.2 - System Maintenance - Change Terminal Baud Rate .................... 13-5

Figure 13-5. Examples of Error and Information Messages.................................................. 13-6

Figure 13-6. Menu 24.3.2 - System Maintenance - Syslog and Accounting.......................... 13-7

Figure 13-7. Menu 24.4 - System Maintenance - Diagnostic................................................ 13-9

Figure 13-8. Trace Display for a Successful IPCP Connection Via Manual Call .................. 13-11

Figure 13-9. Trace Display for a Failed IPCP Connection Via Manual Call..........................13-11

Figure 13-10. Menu 24.7 - System Maintenance - Upload Firmaware .................................. 13-13

Figure 13-11. Menu 24.7.1 - Example of Uploading RAS Using PCPLUS............................ 13-13

Figure 13-12. Menu 24.7.2 - System Maintenance - Upload ROM File................................. 13-14

Figure 13-13. Menu 24.7.3 - System Maintenance - Upload WAN Port 2 Modem Firmware. 13-14
Figure 13-14. Menu 24.7.4 - System Maintenance - Upload WAN Port 2 Modem Firmware. 13-15

Figure 13-15. Menu 24.9 - System Maintenance - Call Control............................................ 13-16

Figure 13-16. Menu 24.9.2 - Blacklist.................................................................................. 13-17

Figure 13-17. Menu 24.9.3 - Budget Management .............................................................. 13-18

xiii

Prestige 128MH PSTN Router/Hub

List of Tables

List of Tables

Table 1-1. LED Functions ................................................................................................. 1-3

Table 2-1. Item Checklist .................................................................................................. 2-1

Table 2-2. Main Menu Commands .................................................................................... 2-8

Table 2-3. Main Menu Summary....................................................................................... 2-9

Table 2-4. General Setup Menu Fields............................................................................ 2-13

Table 2-5. Async WAN Port Setup Menu Fields............................................................... 2-16

Table 2-6. Advanced WAN Port Setup AT Commands Fields .......................................... 2-19

Table 2-7. Advanced WAN Port Setup Call Control Parameters ...................................... 2-20

Table 3-1. Subnet Mask Notation...................................................................................... 3-2

Table 3-2. Examples of IP Subnet Masks.......................................................................... 3-3

Table 3-3. Private Networks IP Addresses ........................................................................ 3-4

Table 3-4. DHCP Ethernet Setup Menu Fields .................................................................. 3-7

Table 3-5. TCP/IP Ethernet Setup Menu Fields................................................................. 3-8

Table 3-6. Internet Account Information ............................................................................ 3-9

Table 3-7. Internet Access Setup Menu Fields ................................................................ 3-10

Table 3-8. Single User Account Menu Fields................................................................... 3-15

Table 3-9. Remote Node Script Menu Fields................................................................... 3-17

Table 4-1. Remote Dial-in Users/Remote Nodes Comparison Chart.................................. 4-1

Table 4-2. Default Dial-in Setup Fields.............................................................................. 4-5

Table 4-3. Edit Dial-in User Menu Fields........................................................................... 4-9

Table 5-1. Remote Node Profile Menu Fields for Dial-up Line Applications........................ 5-3

Table 5-2. Remote Node PPP Options Menu Fields........................................................ 5-10

Table 5-3. Remote Node Profile Menu Fields for Leased Line Applications...................... 5-13

Table 5-4. Remote Node PPP Options Menu Fields for Leased Line Applications ........... 5-19

Table 6-1. Remote Node Network Layer Options for a TCP/IP Configuration..................... 6-4

Table 6-2. Edit IP Static Route Menu Fields...................................................................... 6-8

xv

Prestige 128MH PSTN Router/Hub

List of Tables

Table 7-1. Novell IPX Ethernet Setup Fields...................................................................... 7-5

Table 7-2. Remote Node Network Layer Options for Novell IPX Application...................... 7-8

Table 7-3. Edit IPX Static Route Menu Fields.................................................................. 7-10

Table 8-1. Handle IPX Field Settings................................................................................. 8-2

Table 8-2. Bridge Ethernet Setup Menu - Handle IPX Field Configuration ......................... 8-3

Table 8-3. Remote Node Network Layers Menu Bridge Options........................................ 8-5

Table 8-4. Default Dial-in Setup Field for Bridging Applications ......................................... 8-6

Table 8-5. Bridge Static Route Menu Fields ...................................................................... 8-7

Table 9-1. Abbreviations Used in the Filter Rules Summary Menu .................................... 9-4

Table 9-2. Abbreviations Used If Filter Type Is IP.............................................................. 9-5

Table 9-3. Abbreviations Used If Filter Type Is GEN.......................................................... 9-6

Table 9-4 Abbreviations Used If Filter Type Is IPX ............................................................ 9-6

Table 9-5. TCP/IP Filter Rule Menu Fields........................................................................ 9-8

Table 9-6. Generic Filter Rule Menu Fields ..................................................................... 9-10

Table 9-7. IPX Filter Rule Menu Fields............................................................................ 9-13

Table 10-1. SNMP Configuration Menu Fields................................................................... 10-3

Table 11-1. System Security - External Server Menu Fields...............................................11-3

Table 13-1. System Maintenance - Status Menu Fields..................................................... 13-3

Table 13-2. System Maintenance Menu Syslog Parameters.............................................. 13-7

Table 13-3. System Maintenance Menu Diagnostic Test Options......................................13-10

Table 14-1. Troubleshooting the Start-Up of your Prestige ................................................ 14-1

Table 14-2. Troubleshooting a WAN Port Connection........................................................ 14-2

Table 14-3. Troubleshooting the LAN Interface ................................................................. 14-2

Table 14-4. Troubleshooting a Connection to a Remote Node or ISP................................ 14-3

Table 14-5. Troubleshooting a Connection to a Remote User............................................ 14-4

xvi

Prestige 128MH PSTN Router/Hub

Preface

Preface

About Your Router/Hub

Congratulations on your purchase of the Prestige 128MH PSTN Router/Hub.

The Prestige 128MH is a high-performance Router/Hub that offers a complete solution for your
PSTN and WAN applications such as Internet access for the corporate office, multi-protocol
LAN-to-LAN connections, telecommuting and remote access. Your Prestige 128MH Router/Hub
is the ideal high-speed Internet Access solution for your whole office.

The Prestige 128MH is a universal router that can connect over PSTN (Public Switch Telephone
Network) and ISDN (Integrated Service Digital Network) lines. The Prestige 128MH can
accommodate both TCP/IP and Novell IPX protocols to provide multi-protocol routing and
transparent bridging. Your Prestige is also compatible with routers from other manufacturers such
as Ascend, Cisco, and 3Com.

Your Prestige 128MH is easy to install and to configure since you do not need to set any switch.
All functions of the Prestige 128MH are software configurable via the SMT (System Management
Terminal) Interface. The SMT Interface is a menu-driven software easily accessible from either a
VT100 compatible terminal or a terminal emulation program on a PC.

Versatile and packed with a number of advanced features the Prestige 128MH is designed to
provide the networking solutions adapted to your needs.

About This User's Manual

This user's manual covers all aspects of your Prestige 128MH operations and shows you how to
get the best out of the multiple advanced features of your Router/Hub.

This manual consists of fourteen chapters designed to guide you through a correct configuration
of your Prestige 128MH depending on your particular application.

xvii

Prestige 128MH PSTN Router/Hub

Preface

Structure of this Manual

This manual is divided into five parts:

1. Getting Started (Chapters 1-2), is structured as a step-by-step guide to help you connect,

install and setup your Prestige 128MH to operate on your network.

2. The Internet (Chapter 3), describes how to configure your Prestige 128MH to connect to

the Internet.

3. Setting Up Advanced Applications (Chapters 4-8), describes how to use your Prestige

for more advanced applications such as Telecommuting and LAN-to-LAN in TCP/IP, Novell
IPX, and Bridging environments.

4. Management & Maintenance (Chapters 9-13), provides information on access control

and logging features for network administrators.

5. Troubleshooting (Chapter 14), provides information about solving common problems.

Regardless of your particular application, it is important that you follow the steps outlined in
Chapters 1-2 to correctly connect your Prestige 128MH to your LAN. You can then refer the
appropriate chapters of the manual depending on which applications you wish to use.

Orientation Map

The following Orientation Map is designed to guide you through a quick and correct installation
of your Prestige 128MH. According to your particular application (Internet, Telecommuting,
Multi-protocol LAN-to-LAN Connection), follow the path outlined in this Orientation Map to
refer to the appropriate chapters in this manual. Read the instructions in each chapter carefully for
a successful configuration of your Prestige.

xviii

Preface

INSTALLATION

Chapter 1

Chapter 2

Chapter 3

Chapter 11

Chapter 10

Chapter 9

Chapter 8

Chapter 7

Chapter 4

Chapter 6

LAN-TO-LAN

Chapter 5

1

234

5

INTERNET ACCESS

ADVANCED
APPLICATIONS

Orientation Map

Getting to Know your

Bridge/Router

Hardware

Installation

Internet Access

Application

Prestige 128MH PSTN Router/Hub

TELCOMMUTING

MANAGEMENT &
MAINTENANCE

Filter Configuration

TROUBLESHOOTING

Telecommuting

Troubleshooting

APPLICATIONS

System Password

Telnet Configuration

and Capabilities

Remote Node Configuration

for LAN-to-LAN

TCPI/IP Configuration

for LAN-to-LAN

System

Maintenance

xix

Prestige 128MH PSTN Router/Hub

Chapter 1 Getting to Know Your Router/Hub

Chapter 1

Getting to Know Your Router/Hub

This chapter describes the key features and applications of your Prestige 128MH PSTN
Router/Hub, equipped with a 4-port 10Tbase-T hub, 2 built-in 56 Kbps analog modems, and 1
serial port connection to external modem or ISDN TA.

1.1 Prestige 128MH PSTN Bridge Router

Congratulations on the purchase of your ZyXEL Prestige 128MH Bridge Router. Your Prestige
integrates a 4-Port Router/Hub, Bridge and two high-speed 56K internal modems into a single
package. In a modem-sized box, your Prestige offers inexpensive yet complete
telecommunications and internetworking solutions for your home or branch office. The Prestige is
ideal for everything from Internet browsing to receiving calls from Remote Dial-in Users to
making LAN-to-LAN connections to Remote Nodes.

The Prestige 128MH features two 56 Kbps modem lines that can connect directly to your local
PSTN (Public Switch Telephone Network) network thereby saving you the cost of buying
additional external modems.

In addition, the Prestige 128MH offers one serial port that can connect to the PSTN network via
an external modems or to the ISDN network by using ISDN-TA (ISDN Terminal Adapter).

1-1

Prestige 128MH PSTN Router/Hub

Chapter 1 Getting to Know Your Router/Hub

Prestige 128MH

1.2 Front Panel LEDs and Back Panel Ports

1.2.1 Prestige 128MH Front Panel

À Á Ä ÅÂÃ

ETHERNET

PWR TST RDY TX/RXRDY TX/RX

WAN

1 2 3 4

MODEM-1 MODEM-2

À : PWR = Power LED
Á : TST = Test LED (Blinking)
 : ETHERNET (1, 2, 3, 4) = 4-PORT 10Base-T HUB (Active Ethernet Port #)
à : WAN = WAN port 1 Ready, Transmit/Receive
Ä : MODEM-1 (RDY, TX/RX) = Internal Modem-1 (on WAN port 2) Ready, Transmit/Receive
Å : MODEM-2 (RDY, TX/RX) = Internal Modem-2 (on WAN port 3) Ready, Transmit/Receive

Figure 1-1. Prestige 128MH Front Panel LEDs

1-2

Prestige 128MH PSTN Router/Hub

Chapter 1 Getting to Know Your Router/Hub

1.2.2 Front Panel LEDS

The LED indicator lights on the front panel of your Prestige indicate the Router/Hub functional
status. The following Table 1-1 describes the LED functions:

Table 1-1. LED Functions

LEDs Function Indicator

PWR Power LED Green On The power AC adapter is connected to the Prestige.

TST Test LED Green Blinking The Prestige is functioning properly.

WAN
(WAN 1)

ETHER­NET

(WAN 2)

(WAN 3)

1,2,3,4 LAN Transmit

RDY Ready Green On The internal modem connected to WAN port 2 is in use.MODEM-1

TX/RX Transmit/Receive Green Blinking Traffic is being transmitted or received on WAN port 2.

RDY Ready Green On The internal modem connected to WAN port 3 is in use.MODEM-2

TX/RX Transmit/Receive Green Blinking Traffic is being transmitted or received on WAN port 3.

Ready Green On The modem or IDSN TA connected to WAN port 1 is in

Transmit/Receive Green Blinking Traffic is being transmitted or received on WAN port 1.

LAN Receive

Status

Green

Active Description

use.

On The Prestige has successfully connected to LAN port

1,2,3,4 via the UTP Ethernet interface.

Blinking Traffic is being transmitted/received on LAN port 1,2,3,4,

1-3

Prestige 128MH PSTN Router/Hub

Chapter 1 Getting to Know Your Router/Hub

1.2.3 Prestige 128MH Back Panel

Figure 1-2 helps you identify the rear panel ports of your Prestige 128MH. Refer to this diagram
when attempting to make connections.

À Á Â

ETHERNET

POWER

4 3 2 1

CONSOLE

Ç

WAN

Æ

ÄÅ Ã

LINE1LINE2 PHONE1PHONE2

À : POWER = 16V-AC power outlet to connect the AC adapter.
Á : ETHERNET = 4 x RJ-45 socket HUB to connect ETHERNET 10Base-T cables.
 : CONSOLE = RJ-45 connector to plug the RJ45-RS232 female adapter and connect to the Console or SMT.
à : PHONE1 = RJ-11 socket to connect a phone or fax to Modem port 1.
Ä : LINE1 = RJ-11 socket to connect the PSTN telephone line to Modem-1 (on WAN port 2).
Å : PHONE2 = RJ-11 socket to connect a phone or fax to Modem port 2.

Æ : LINE2 = LINE1 = RJ-11 socket to connect the PSTN telephone line to Modem-2 (on WAN port 3).
Ç : WAN = RJ-45 socket to connect the RJ45-RS232 male adapter and plug a modem or ISDN TA to WAN port 1.

Figure 1-2. Prestige 128MH Back Panel Ports

1-4

Prestige 128MH PSTN Router/Hub

Chapter 1 Getting to Know Your Router/Hub

1.3 Features of Prestige 128MH

Your Prestige is packed with a number of features that give it the flexibility to provide a complete
networking solution for almost any user.

Ease of Installation

Your Prestige is quick and easy to install. Physically, it resembles an external modem except for
the fact that it is a router and uses an Ethernet cable to connect to the host network.

Multiple WAN Ports

Your Prestige 128MH has three WAN ports (WAN-1,2,3). WAN port 1 can be connected to a dial­up/leased line modem or to an ISDN TA (Terminal Adapter). WAN port 2,3 are internally
connected to two high-speed 56K modems that support dial-up configurations.

Leased Line/Dial Back-Up Support

Your Prestige 128MH supports a leased line connection to its serial port WAN port 1. The
Prestige can also support dial back-up function for the leased line connection.

Multiple Networking Protocol Support

The Prestige 128MH is a multi-protocol router that supports TCP/IP, Novell IPX, and Transparent
Bridging.

Dial-On-Demand

The Dial-On-Demand feature allows the Prestige 128MH to automatically place a call to a remote
node whenever there the traffic coming from any workstation on the LAN is directed to that
particular remote site.

Bandwidth-On-Demand

The Bandwidth-On-Demand feature provides flexible bandwidth when needed. The Prestige
128MH dynamically allocates bandwidth between the WAN ports, increasing or decreasing

speeds as needed to allow for greater efficiency in data transfer.

1-5

Prestige 128MH PSTN Router/Hub

Chapter 1 Getting to Know Your Router/Hub

By using the PPP/MP (Point-to-Point Protocol/Multilink Protocol), your Prestige 128MH can
bundle three WAN ports connected to three different internal and external modems in order to use
the maximum available bandwidth. The Prestige 128MH supports BAP (Bandwidth Allocation
Protocol) and BACP (Bandwidth Allocation Control Protocol) to manage the number of links in
multilink bundle.

Full Network Management

Your Prestige 128MH supports SNMP (Simple Network Management Protocol) and allows
menu-driven network management via an RS-232 or Telnet connection. Your Prestige is also
equipped with a Call Detail Record to help analyze and manage your telephone bill.

RADIUS

The RADIUS (Remote Authentication Dial-In User Service) feature allows you to use an external
and central Unix-based server to support thousands of users.

PAP and CHAP Security

The Prestige supports PAP (Password Authentication Protocol) and CHAP (Challenge Handshake
Authentication Protocol). With PAP authentication enabled, the user sends the name and password
in plain text. Generally, CHAP authentication is more secure since the password is scrambled
prior to transmission. However, PAP is readily available on more platforms.

DHCP Support

DHCP (Dynamic Host Configuration Protocol) allows you to dynamically and automatically
assign IP address settings to hosts on your network.

Call Control

Your Prestige provides budget management for outgoing calls and maintains a blacklist for
unreachable phone numbers in order to save you the expense of unnecessary charges.

1-6

Prestige 128MH PSTN Router/Hub

Chapter 1 Getting to Know Your Router/Hub

Data Compression

Your Prestige incorporates Stac data compression and CCP (Compression Control Protocol).

Networking Compatibility

Your Prestige is compatible with remote access products from other manufacturers such as
Ascend, Cisco, and 3Com. Furthermore, it supports Microsoft Windows 95 and Windows NT
remote access capability.

1-7

Prestige 128MH PSTN Router/Hub

Chapter 1 Getting to Know Your Router/Hub

ISP

PSTN Network

56 Kbps

56 Kbps

1.4 Applications for Prestige 128MH

The Prestige 128MH offers complete solutions for your WAN applications such as Corporate
Internet Access, Internet Single User Account, LAN-to-LAN Connections, Telecommuting and
Remote Node Access.

Internet Access

The Prestige 128MH is the ideal high-speed Internet Access solution for the corporate and branch
offices. Your Prestige 128MH supports the TCP/IP protocol, which is the language used for the
Internet. It is also compatible with access servers manufactured by major vendors such as Cisco
and Ascend. A typical Internet Access application is shown in Figure 1-3.

Coporate LAN

Modem/ISDN TA

Modem / ISDN TA

Ethernet LAN

Prestige 128MH

INTERNET

PSTN/ISDN Network

(Telephone Line)

Figure 1-3. Internet Access Application

Internet Single User Account

For a small office environment, your Prestige offers a Single User Internet Account from an ISP
(Internet Service Provider). This allows multiple users on the LAN (Local Area Network) to
access the Internet concurrently for the cost of a single user. Single User Account address
mapping can also be used for LAN to LAN connection.

1-8

Prestige 128MH PSTN Router/Hub

Chapter 1 Getting to Know Your Router/Hub

PSTN Network

Multiprotocol/Multiport LAN-to-LAN Connection

Your Prestige can dial to or answer calls from another remote access router connected to a
different network. The Prestige supports TCP/IP, Novell IPX, and has the capability to bridge any
Ethernet protocol. Your Prestige can also bundle several WAN ports in one LAN-to-LAN
connection for greater bandwidth. A typical LAN-to-LAN application for your Prestige 128MH is
to connect the Corporate Office LAN of your company with the Branch Office, as shown in
Figure 1-4.

Branch Office LAN

Ethernet LAN

(Telephone Line)

Prestige 128MH

Coporate LAN

WIN 95/NT
TCP/IP

NOVELL
IPX

Ethernet LAN

Prestige 128MH

BRIDGING

Figure 1-4. LAN-to-LAN Connection Application

Dial-On-Demand

Also, with the automatic Dial-On-Demand, your Prestige 128MH makes a connection only when
data is transferred between the Corporate LAN and the Branch Office. Dial-On-Demand
minimizes connection charges and user intervention.

1-9

Prestige 128MH PSTN Router/Hub

Chapter 1 Getting to Know Your Router/Hub

Telecommuter

PSTN Network

Telecommuting Server / Remote Access

Your Prestige allows Remote Dial-in Users to dial-in and gain access to your LAN. This feature
enables users that have workstations with remote access capabilities (for example, Windows 95),
to dial in using a modem or an ISDN terminal adapter (TA) to access the network resources
without physically being in the office. Figure 1-5 shows how a remote user or a telecommuter can
connect to its corporate office via a modem or ISDN TA and the PSTN/ISDN network.

Coporate LAN

Remote User

Modem / ISDN TA

Modem

(Telephone Line)

Ethernet LAN

Prestige 128MH

Figure 1-5. Telecommuting/Remote Access Application

Prestige 128MH allows up to three simultaneous remote-access connections or one PPP/MP
bundled connection. PAP or CHAP password checking may be used to control the access from
remote users to the corporate LAN. Also, call-back can be used to authenticate connections from
remote users

1-10

Prestige 128MH PSTN Router/Hub

Chapter 2 Hardware Installation & Initial Setup

Chapter 2

Hardware Installation & Initial Setup

2.1 Unpacking your Router/Hub

Before you proceed further, check all items you received with your Prestige against this list to
make sure nothing is missing. The complete package should include:

Table 2-1. Item Checklist

Package Contents Prestige 128MH

Prestige 128MH PSTN Router/Hub

Power Adapter

RS-232 cable

25-pin female to 9-pin male

adapter cable

LAN crossover cable (red tag)

LAN straight cable (white tag)

SMT RJ-45 to RS-232 female adapter cable

WAN RJ-45 to RS-232 male adapter cable

RJ-11 PSTN telephone line cable

Warranty Card

This Prestige 128MH

User's Manual

Quick Start Guide

1
1

1
1
1

1
1
1
2
1

1
1

2-1

Prestige 128MH PSTN Router/Hub

Chapter 2 Hardware Installation & Initial Setup

2.2 Additional Installation Requirements

In addition to the contents of your package, there are other hardware and software requirements
you need before you can install and use your Prestige. These requirements include:

l External Modems or ISDN TAs (Terminal adapters).
l An Ethernet 10Base-T connection to your computer.
l A computer equipped with communications software configured to the following parameters:

Ø VT100 terminal emulation.
Ø 9600 Baud rate.
Ø No parity, 8 Data bits, 1 Stop bit.

After the Prestige has been successfully connected to your network, you can make future changes
to the configuration by using a Telnet application.

2-2

Chapter 2 Hardware Installation & Initial Setup

2.3 Connect your PSTN Router/Hub

56 Kbps

56 Kbps

Power

Power

Computer

External Modem

PSTN Network

Abcdefg ghijkl mmn opqr

Abcdefg ghijkl mmn opqr

Abcdefg ghijkl mmn opqr

Abcdefg ghijkl mmn opqr

2.3.1 Prestige 128MH Connections

Prestige 128MH PSTN Router/Hub

Adapter

POWER

Outlet

ETHERNET

4 3 2 1

PSTN/ISDN Network

or

Modem / ISDN TA

ISDN TA

CONSOLE

(Telephone Line)

WAN

LINE1LINE2 PHONE1PHONE2

Ethernet LAN

Figure 2-1. Connect Prestige 128MH

Telephone

stuvw xyzasdsad aa s

stuvw xyzasdsad aa s

dddd . rrrr tttttt bbb

dddd . rrrr tttttt bbb

hhhhhh ffff bbbbb

hhhhhh ffff bbbbb

bbbbbbbb jjjjjjjj.jjjjjjjjj

bbbbbbbb jjjjjjjj.jjjjjjjjj

jjjjjjjj. Ee sdasd dsasad

jjjjjjjj. Ee sdasd dsasad

dsad sasad asdas er eqr q r

dsad sasad asdas er eqr q r

fg h fghfg hf ghf ghf h fgh

fg h fghfg hf ghf ghf h fgh

fgh fgh fh ffffgh ffffafd

fgh fgh fh ffffgh ffffafd

Fax

Telephone

stuvw xyzasdsad aa s

stuvw xyzasdsad aa s

dddd . rrrr tttttt bbb

dddd . rrrr tttttt bbb

hhhhhh ffff bbbbb

hhhhhh ffff bbbbb

bbbbbbbb jjjjjjjj.jjjjjjjjj

bbbbbbbb jjjjjjjj.jjjjjjjjj

jjjjjjjj. Ee sdasd dsasad

jjjjjjjj. Ee sdasd dsasad

dsad sasad asdas er eqr q r

dsad sasad asdas er eqr q r

fg h fghfg hf ghf ghf h fgh

fg h fghfg hf ghf ghf h fgh

fgh fgh fh ffffgh ffffafd

fgh fgh fh ffffgh ffffafd

Fax

2-3

Prestige 128MH PSTN Router/Hub

Chapter 2 Hardware Installation & Initial Setup

This section outlines how to connect your Prestige 128MH to the LAN and the WANs. Refer to
Figure 1-2 to identify all of the ports on your device. Then see Figure 2-1 when you attempt to
make the various connections.

Follow these steps designed to guide you through a quick and correct installation of your Prestige
128MH.

A Warning On Connection Cables

The SMT RS-232 cable, WAN modem line, and Ethernet cable are very similar to each other. It is
important that you use the correct cable for each connection; otherwise, your Prestige could be
damaged.

Step 1. Connect Your Computer and Your Prestige

For the initial setup and configuration of your Prestige 128MH, you must use RS-232 and
communications software.

After your Prestige has been successfully installed, you can modify the configuration through a
remote Telnet connection. See Chapter 12 - Telnet Configuration and Capabilities for detailed
instructions on using Telnet to configure your Prestige 128MH.

Note on Connecting the RS-232 Cable to your Prestige

One RJ45 to RS-232 female adapter cable is included in your package. To make a RS-232
connection, first connect the RJ45 end of the cable to the CONSOLE port on the back panel of the
Prestige. Connect the other end to the RS-232 cable attached to the serial port (COM1, COM2, or
any other COM port) of your computer.

Step 2. Connect the Serial WAN Port

The Prestige 128MH has one serial WAN port (WAN port 1) which can be connected to a Dial-up
modem, a Leased Line modem, or ISDN TA (Terminal Adapter). The serial WAN port uses a
RJ45 connector. A cable is provided to convert RJ-45 to DB-25.

2-4

Prestige 128MH PSTN Router/Hub

Chapter 2 Hardware Installation & Initial Setup

Step 3. Connect the Internal 56K Modem Ports

The Prestige 128MH has two modem ports (LINE 1,2) which can be connected directly to your
local PSTN (Public Switch Telephone Network) via a telephone line. Use the RJ11 cables
included in the package to connect the modem ports labeled LINE 1 and LINE 2 directly to the
PSTN telephone line.

Step 4. Telephone/Fax Connection

The ports labeled PHONE 1 and PHONE 2 at the rear panel of your Prestige 128MH can be used
to connect a telephone and fax that will share the same lines, LINE 1 and LINE 2 respectively, as
the internal modems. Therefore, when the internal modem on LINE 1 or LINE 2 is not in use, you
can dial-out and place a call or send a fax by using the telephone or fax connected to PHONE 1 or
PHONE 2 ports of your Prestige.

Step 5. Connect an Ethernet Cable to your Prestige

The LAN ports 1,2,3, and 4 at the rear panel of your Prestige are used to connect to 10Base-T
Ethernet networks. 10Base-T networks use Unshielded Twisted Pair (UTP) cable and RJ-45
connectors that look like a bigger telephone plug with 8 pins. Two types of gray Ethernet cables
come with the package:

Ø Straight through cable (white tag): Connect your Prestige to your computer directly without a

hub.

Ø Crossover cable (red tag): Connect your Prestige to another 10Base-T Switch/Hub.

Step 6. Connect the Power Adapter to your Prestige

Plug a 16VAC 1200mA power adapter into the outlet labeled POWER on the rear panel of your
Prestige.

2-5

Prestige 128MH PSTN Router/Hub

Chapter 2 Hardware Installation & Initial Setup

2.4 Power On Your Prestige

At this point, you should have connected the computer, the external modem or ISDN TA (WAN),
the telephone lines (LINE 1,2), the Ethernet cable, and the power supply. You can now power on
your Prestige by plugging the AC adapter to the appropriate power outlet.

Step 1. Initialize SMT

When you power on your Prestige, the Router/Hub will perform several internal tests and will
also perform a PSTN/ISDN line initialization. After this initialization, the Prestige will display
the SMT (System Management Terminal) interface and ask you to press [Enter] to continue, as
shown in Figure 2-2.

Copyright (c) 1994 - 1997 ZyXEL Communications Corp.
ethernet address: 00:a0:c5:01:23:45
Wan port init ... done
Modem 0 init . inactive
Modem 1 init . inactive
Modem 2 init . inactive

Press ENTER to continue...

Figure 2-2. Power-On Display

2-6

Prestige 128MH PSTN Router/Hub

Chapter 2 Hardware Installation & Initial Setup

Step 2. Enter Password

The Login screen appears prompting you to enter the password, as shown in Figure 2-3.

For your first login, enter the default password 1234 to get into the Main Menu of the System
Management Terminal (SMT). As you type a password, the screen displays an (X) for each
character you typed.

Enter Password : XXXX

Figure 2-3. Login Screen

Note that once you are in the SMT and if there is no activity for longer than 5 minutes, your
Prestige will automatically log you out and will display a blank screen. If you see a blank screen,
press [Enter] to bring up the password screen.

2-7

Prestige 128MH PSTN Router/Hub

Chapter 2 Hardware Installation & Initial Setup

2.5 Navigating the SMT Interface

The SMT (System Management Terminal) is the interface that you use to configure your Prestige.

Several operations that you should be familiar with before you attempt to modify the
configuration are listed in Table 2-2.

Table 2-2. Main Menu Commands

Operation Press/<read> Description

Move forward to
another menu

Move backward to
a previous menu

Move the cursor

Enter information Fill in, or

Required fields

N/A fields <N/A> Some of the fields in the SMT will show a <N/A>. This symbol refers to

Save your
configuration

Exit the SMT

[Enter] To move forward to a sub-menu, type in the number of the desired

sub-menu and press [Enter].

[Esc] Press the [Esc] key to move back to the previous menu.

[Enter] or
[Up]/[Down]

arrow keys

Press the
[Space bar] to
toggle

<?>

[Enter] Save your configuration by pressing [Enter] at the message:[Press

Type 99, then
press [Enter].

Within a menu, press [Enter] to move to the next field. You can also
use the [Up]/[Down] arrow keys to move to the previous and the next
field, respectively.

There are two types of fields that you will need to fill in. The first
requires you to type in the appropriate information. The second gives
you choices to choose from. In the second case, press the [Space
bar] to cycle through the available choices.

All fields with the symbol <?> must be filled in order be able to save
the new configuration.

an option that is not available.

ENTER to confirm or ESC to cancel]. Saving the data on the screen
will take you, in most cases to the previous menu.

Type 99 at the Main Menu prompt and press [Enter] to exit the SMT
interface.

2-8

Chapter 2 Hardware Installation & Initial Setup

The SMT displays the Main Menu, as shown in Figure 2-4.

Prestige 128MH PSTN Router/Hub

Copyright (c) 1994 - 1997 ZyXEL Communications Corp.

Getting Started

1. General Setup

2. WAN Setup

3. Ethernet Setup

4. Internet Access Setup

Advanced Applications

11. Remote Node Setup

12. Static Routing Setup

13. Default Dial-in Setup

14. Dial-in User Setup

Prestige 128MH Main Menu

Advanced Management

21. Filter Set Configuration

22. SNMP Configuration

23. System Security

24. System Maintenance

99. Exit

Enter Menu Selection Number:

Figure 2-4. SMT Main Menu

System Management Terminal Interface Summary

Table 2-3. Main Menu Summary

# Menu Title Description

1 General Setup Access this menu to setup general information and enable routing or

bridging of specific protocols.
2 WAN Setup Access this menu to setup WAN port configuration.
3 Ethernet Setup Access this menu to setup Ethernet configuration.
4 Internet Access Setup A quick and easy way to setup Internet connection.

11 Remote Node Setup Access this menu to setup the Remote Node for LAN-to-LAN connection,

including Internet connection. Prestige supports up to four Remote Nodes.

12 Static Routing Setup Access this menu to setup static route for different protocols. There are

four static routes for each protocol.

13 Default Dial-in Setup Access this menu to setup default dial-in parameters so that your Prestige

can be a dial-in server for the Remote Node and Remote Dial-in User.

14 Dial-in User Setup Setup Remote Dial-in User. Prestige has eight Remote Dial-in Users.
21 Filter Set Configuration Setup filters to be used in Menu 3 and Menu 11 to provide security, call

control, etc.

22 SNMP Configuration Access this menu to setup SNMP related parameters
23 System Security Access this menu to setup security related parameters.
24 System Maintenance Provides system status, diagnostics, firmware upload, etc.
99 Exit To exit from SMT and return to the blank screen.

2-9

Prestige 128MH PSTN Router/Hub

Chapter 2 Hardware Installation & Initial Setup

2.6 Configure the SMT Password

The following steps describe a simple setup procedure for configuring the SMT password.

Step 1. Select option [23. System Security] in the Main Menu. This will open Menu 23 -

System Security as shown in Figure 2-5.

Menu 23 - System Security

1. Change Password

2. External Server

Enter Menu Selection Number: 1

Figure 2-5. Menu 23 - System Security

Step 2. From the System Security Menu, select option [1. Change Password] to bring up

Menu 23.1 - System Security - Change Password.

2-10

Prestige 128MH PSTN Router/Hub

Chapter 2 Hardware Installation & Initial Setup

Step 3. When the Submenu 23.1- System Security-Change Password appears, as shown in

Figure 2-6, type in your previous system password, then press [Enter].

Menu 23.1 - System Security - Change Password

Old Password= XXXX
New Password= XXXX
Retype to confirm= XXXX

Enter here to CONFIRM or ESC to CANCEL:

Figure 2-6. Menu 23.1 - System Security - Change Password

Step 4. Enter your new system password and press [Enter].
Step 5. Re-type your new system password for confirmation and press [Enter].

You will now need to enter this password every time you attempt to access the SMT. In addition,
the password is required when a network administrator attempts to access your Prestige via a
Telnet connection.

Note on Password Display

As you type a password, the screen displays a (X) for each character you type.

2-11

Prestige 128MH PSTN Router/Hub

Chapter 2 Hardware Installation & Initial Setup

2.7 General Setup

The Menu 1 - General Setup contains administrative and system-related information.

To enter Menu 1 and fill in the required information, follow these steps:

Step 1. Select option [1. General Setup] in the Main Menu by typing 1 at the menu selection

number prompt.

Step 2. The Menu 1 - General Setup screen appears, as shown in Figure 2-7. Fill in the required

fields marked [?] and turn on the individual protocols for your particular application, as
explained in Table 2-4.

Menu 1 - General Setup

System Name= p128MH
Location= location
Contact Person's Name= name

Route IP= Yes
Route IPX= No
Bridge= No

Press ENTER to Confirm or ESC to Cancel:

Figure 2-7. Menu 1 - General Setup

2-12

Prestige 128MH PSTN Router/Hub

Chapter 2 Hardware Installation & Initial Setup

Table 2-4. General Setup Menu Fields

Field Description Example

System Name Choose a descriptive name for identification purposes. This name can be

up to 8 alphanumeric characters long. Spaces are not allowed, but dashes
“-” and underscores "_" are accepted. This name can be retrieved
remotely via SNMP, used for CHAP authentication, and will be displayed
at the prompt in the Command Mode.

Location (optional) Enter the geographic location (up to 31 characters) of your Prestige. location

Contact Person's
Name (optional)

Protocols: Turn on or off the individual protocols for your particular application.

Route IP
Route IPX
Bridge

Enter the name (up to 8 characters) of the person in charge of this
Prestige.

Unsupported protocols will display a [N/A] in their fields.

Set this field to [Yes] if you are configuring your Prestige for Internet
Access.

Selecting [Yes] will let your Prestige route IPX protocol applications.
Bridging is used for protocols that are not supported (for example, SNA) or

not turned on in the previous Route fields.

P128MH

name

Press

space-bar

to toggle

[Yes/No]
[Yes/No]
[Yes/No]

Note on Route IP, IPX Protocols and Bridge

Your Prestige 128MH is a multi-protocol Router/Hub that can support any combinations of Route
IP, Route IPX, and Bridge.

If Route IP is set to [Yes] and Bridge set to [Yes] your Prestige functions as a Router & Bridge.
If Route IP is set to [Yes] and Bridge set to [No] your Prestige functions as a Router Only.
If Bridge is set to [Yes] and Route IP set to [No] your Prestige function as a Bridge Only.

Note on Bridge

When bridging is enabled, your Prestige will forward any packet that it does not recognize.
Otherwise, the unrecognized packets are discarded. The disadvantage of bridging is that it usually
generates large amounts of traffic.

2-13

Prestige 128MH PSTN Router/Hub

Chapter 2 Hardware Installation & Initial Setup

2.8 WAN Setup

This section describes how to configure the WAN ports on your Prestige 128MH by using Menu
2- WAN Setup. The Menu 2 - WAN Setup is used for entering information about your Modem or
ISDN TA connected to the serial port WAN Port 1 and the modem line connected internally to
WAN port 2 or 3 (LINE 1,2). Select a WAN Port (# 1,2, or3) that you wish to configure first.
Then configure the WAN Port from Submenu 2.1. If advanced setup is required, go into Menu 2.2.
When you are finished, press [Enter] in Menu 2.1. Your Prestige will save the information to
ROM first; then use this information to initialize the Wan Port and the attached modem or ISDN
TA.

Note on WAN Setup

Before you connect a leased line modem or ISDN TA to your Prestige, make sure to configure the
device accordingly. To configure the modem or ISDN TA, refer to the instructions provided by the
manufacturer

2.8.1 Prestige 128MH WAN Port Setup

Prestige 128MH supports three WAN port connections with Modems or ISDN TAs.

To configure the WAN ports on Prestige 128MH, follow these steps:

Step 1. Select option [2. WAN Setup] in the Main Menu by typing 2 at the menu selection

number prompt.

Step 2. In Menu 2 - WAN Port Setup, as shown in Figure 2-8, enter the number (1,2, or 3) of

the WAN port you wish to configure.

l Select option [1. Wan Port 1(External)] to setup the WAN port 1 with external

modem or ISDN TA parameters.

l Select options [2,3 Wan Port 2,3(Internal)] to configure the Internal 56K

Modems on WAN Port 2 and 3.

2-14

Prestige 128MH PSTN Router/Hub

Chapter 2 Hardware Installation & Initial Setup

Menu 2 - WAN Port Setup

1. Wan Port 1(External)

2. Wan Port 2(Internal)

3. Wan Port 3(Internal)

Enter Menu Selection Number:

Figure 2-8. Menu 2 - WAN Port Setup

Step 3. This will bring up Menu 2.1 - Async WAN Port Setup, as shown in Figures 2-9a, 2-9b.

In Menu 2.1 you can set the configuration parameters for the selected WAN port.

l Figure 2-9a shows how to configure WAN port 1 connected to an external modem

or ISDN TA.

Modem Name= ZyXEL
Active= Yes
Connection Type= Switch
Phone Number=

Device Type= 56K Modem
Port Speed= 115200
AT Command String:
Init= ats0=0

Advanced Setup= No

Press ENTER to Confirm or ESC to Cancel:

Figure 2-9a. Menu 2.1 - Async WAN Port Setup for Serial WAN Port 1

Menu 2.1 - Async WAN Port Setup

2-15

Prestige 128MH PSTN Router/Hub

Chapter 2 Hardware Installation & Initial Setup

l Figure 2-9b displays Menu 2.1 when configuring WAN port 2 and 3 internally

connected to the built-in 56K modem LINE 1 and LINE 2 respectively.

Menu 2.1 - Async WAN Port Setup

Modem Name= ZyXEL
Active= Yes
Connection Type= Switch (r.o.)
Phone Number=

Device Type= 56K Modem (r.o.)
Port Speed= 115200
AT Command String:
Init=ats0=0W2&fs95=1

Advanced Setup= No

Press ENTER to Confirm or ESC to Cancel:

Figure 2-9b. Menu 2.1 - Async WAN Port Setup for WAN Port 1,2 (LINE 1,2)

Table 2-5 describes how to configure the WAN port 1 with the external modem or ISDN TA
parameters, and WAN port 2 and 3 with the internal 56K modem line parameters.

Table 2-5. Async WAN Port Setup Menu Fields

Field Description Example

Modem Name Enter a descriptive name for the Modem or ISDN TA connected to this

WAN Port.

Active Set to [Yes] to activate a WAN port, then your Prestige will initialize the

WAN Port and the attached Modem or ISDN TA. When a WAN Port is
deactivated, it has no effect on the operation of your Prestige, even
though its profile is still kept in the database, and can be activated in the
future.

Connection
Type

For WAN Port 1 (Serial WAN port connected to external modem or
ISDN TA), select the connection type for your particular application.

Select [Switch] for Dial-up application or [Leased] for Leased Line
Modem application.

2-16

ZyXEL

Press space-bar

to toggle
[Yes/No]

Press space-bar

to toggle

[Switch/Leased]

Prestige 128MH PSTN Router/Hub

Chapter 2 Hardware Installation & Initial Setup

Table 2-5. Async WAN Port Setup Menu Fields (continued)

Connection
Type

Phone
Number

Device Type For WAN Port 1 (Serial WAN port connected to external modem or

Device Type For WAN Port 2 and 3 (LINE 1 and LINE 2 ports with internal 56K

Port Speed Use the space bar to select the maximum speed of your Modem or ISDN

For WAN Port 2 and 3 (LINE 1 and LINE 2 ports with internal 56K
modems), this field is read only (r.o.). The connection type is set to

[Switch] for Dial-up line applications only.

Enter the telephone number assigned to your modem line by your
telephone company. Note that your Prestige only accepts digits; do not
include dashes and spaces in this field.

ISDN TA), use the space bar to select one of the following devices:
[Modem / ISDN TA / X.25 PAD / 56K Modem]. A Device Type is selected
for the WAN Port such that a Remote Node only picks up a free device of
the selected type to dial out. Only the WAN Ports of the same device
type can be bundled. This field is not applicable if the Connection Type is
set to [Leased].

modems), this field is read only (r.o.). The device type is set to [56K
Modem] which corresponds to the 56K modems built in your Prestige
128MH.

TA. Available speeds are:
9600 / 19200 / 38400 / 57600 / 115200 / 230000 bps

Note that the port speed is set to 56Kps for WAN port 2 and 3 with
internal modems.

[Switch (r.o.)]

5551212

(example)

Space-bar to

toggle

[Modem]

[ISDN TA]

[X.25 PAD]

[56K Modem]

[56K Modem

(r.o.)]

115200

(default)

AT Command
String: Init

Advanced
Setup

When you complete this menu, press [Enter] to save your selections, or [Esc] to cancel. After you press
[Enter], the Prestige uses the information you have saved to initialize the WAN Port and the connected
Modem/ISDN TA.

Enter an AT command string to initialize the modem or ISDN TA attached
to the WAN Port. When the Connection Type is set to [Switch], you must
enter an AT command (ats0=0) to disable auto answer (i.e. ats0=0) or
your Prestige will answer the incoming phone call.

Note the default AT command string [at&s95=1] for dial-up
applications with internal 56K modem.

To edit the Advanced Setup for this Modem/ISDN TA, move the cursor to
this field, use the space bar to select [Yes] and press [Enter]. This will
bring you to Menu 2.1.1 - Advanced Setup.

(Default: ats0=0)

[Yes/No]

2-17

Prestige 128MH PSTN Router/Hub

Chapter 2 Hardware Installation & Initial Setup

2.8.2 Advanced WAN Port Setup

The Advanced WAN Port Setup Menu allows you to configure the AT Commands for the external
modem/ISDN TA connected to WAN port 1 and for the built-in 56K modems internally connected
to WAN port 2 and 3. Also, this menu lets you configure the call control parameters. For all of
Prestige 128MH WAN ports, follow the common Advanced WAN Port Setup procedure outlined
in this section.

Step 1. In Menu 2.1, move the cursor to the Advanced Setup field and press the space bar to

select [Yes], then press [Enter].

Step 2. When Menu 2.1.1 appears, fill in the appropriate AT commands and call control

parameters for the external modem or ISDN TA connected to the WAN port 1 and for
the internal modems on WAN port 2 and 3, as shown in Figure 2-10.

Menu 2.1.1 - Advanced WAN Port Setup

AT Command Strings:

Dial= atd
Drop= ~+++~ath
Answer= ata

Drop DTR When Hang Up= Yes

AT Response String:

CLID= NMBR
Called Id= TO
Speed= CONNECT

Enter here to CONFIRM or ESC to CANCEL:

Figure 2-10. Menu 2.1.1 - Advanced WAN Port Setup

2-18

Call Control

Dial Timeout(sec)= 60
Retry Counter= 0
Retry Interval(sec)= N/A
Drop Timeout(sec)= 20
Call Back Delay(sec)= 15

Prestige 128MH PSTN Router/Hub

Chapter 2 Hardware Installation & Initial Setup

Refer to Table 2-6 for details on how to fill in the AT commands fields.

Table 2-6. Advanced WAN Port Setup AT Commands Fields

Field Description Default

AT Command Strings:

Dial

Enter the AT Command string to make a modem/ISDN TA
connection.

Drop

Enter the AT Command string to drop a modem/ISDN TA
connection. [~] represents a one second wait.

[atd]

[~+++~ath]

Answer

Drop DTR When HangUpWhen [Yes] is selected, your Prestige will drop the DTR signal

AT Response Strings:

CLID (Caller Line

Identification)

Called ID Enter the keyword to capture Called ID from AT Response String. [TO]

Speed Enter the keyword to capture the Connection Speed from AT

When you have completed this menu, press [Enter] to return to Menu 2.1.

Enter the AT Command string to answer a phone call and make a
modem/ISDN TA connection.

after sending out [AT Command String: Drop].

Enter the keyword to capture Caller ID from the AT Response
String. Your Prestige will capture CLID from the AT Response
String, if they are available. The keyword just before CLID is
recognized first; then captures CLID. CLID is required for Prestige
callback function or CLID authentication. Not every modem
supports CLID.

Response String.

[ata]

Toggle

[Yes/No]

(Default=[Yes])

[NMBR]

[CONNECT]

2-19

Prestige 128MH PSTN Router/Hub

Chapter 2 Hardware Installation & Initial Setup

Table 2-7 below describes the call control parameters.

Table 2-7. Advanced WAN Port Setup Call Control Parameters

Field Description Default

Dial Timeout (sec) The Prestige will timeout if it can not set up an outgoing

modem call within the timeout value.

Retry Counter How many times a busy or no-answer phone number is

retried before it is put on the blacklist.

Retry Interval (sec) Elapsed time after a call fails before another call may be

retried. Applies before a phone number is blacklisted.

Drop Timeout (sec) The Prestige will timeout if it can not drop a call within the

timeout value.

Call Back Delay
(sec)

Elapsed time between dropping a callback request call and
dialing a callback call.

[60] seconds

[0] to disable the

blacklist control

[20] seconds

[15] seconds

2-20

Prestige 128MH PSTN Router/Hub

Chapter 2 Hardware Installation & Initial Setup

2.9 General Ethernet Setup

This section describes the Ethernet Setup Menu that you will configure depending on the
particular protocol TCP/IP, IPX, or Bridge you are using on your LAN. From the Main Menu,
enter 3, then the Menu 3- Ethernet Setup displays as shown in Figure 2-11.

Menu 3 - Ethernet Setup

1. General Setup

2. TCP/IP and DHCP Setup

3. Novell IPX Setup

4. Bridge Setup

Enter Menu Selection Number:

Figure 2-11. Menu 3 - Ethernet Setup

This menu determines the type of the filter sets you wish to implement to monitor your Ethernet
traffic. From Menu 3 - Ethernet Setup, enter 1 to go to Menu 3.1 -General Ethernet Setup.

Figure 2-12. Menu 3.1 - General Ethernet Setup

Menu 3.1 - General Ethernet Setup

Input Filter Sets=
Output Filter Sets=

Press ENTER to Confirm or ESC to Cancel:

2-21

Prestige 128MH PSTN Router/Hub

Chapter 2 Hardware Installation & Initial Setup

Filters are not required for your Prestige 128MH to function properly. However, input and output
filter sets may be useful to block certain packets, reduce traffic, and prevent a security breach.

If you have a usage for filters, read about Chapter 9- Filter Set Configuration, then return to
this menu to define the appropriate filter sets.

2.10 Protocol Dependent Ethernet Setup

Depending upon the type of protocol TCP/IP, IPX, or Bridge you are using for your applications,
you will be required to configure the Ethernet Setup accordingly.

l For TCP/IP and DHCP Ethernet Setup refer to Chapter 3 - Internet Access Application.
l For Novell IPX Ethernet Setup refer to Section 7.4 - IPX Ethernet Setup in Chapter 7 -

Novell IPX Configuration for LAN-to-LAN.

l For Bridge Ethernet Setup refer to Chapter 8 - Bridge Configuration for LAN-to-LAN.

2-22

Prestige 128MH PSTN Router/Hub

Chapter 3 Internet Access Application

Chapter 3

Internet Access Application

This chapter shows you how to configure your Prestige 128MH for Internet Access.

3.1 IP Addresses and the Internet

If you are setting up and configuring your network for Internet Access for the first time, read
before proceeding. This section contains important information on how to assign IP addresses for
your network.

About the Internet

Conventionally, the "Internet" (with a capital I) refers the large-scale interconnected networks
across the world. The Internet uses exclusively the TCP/IP suite of protocols. The term "internet"
(lower case i), however, refers to any interconnected networks using any protocol. An internet can
be as simple as two hosts on a LAN, or it can be as complex as the Internet itself.

IP Addresses

Every machine on the Internet must have a unique address within that internet. An IP Address is
required for TCP/IP protocol and usually assigned by your ISP (Internet Service Provider) The IP
Address is the unique 32-bit number assigned to your Prestige. This address is typically expressed
as a sequence of four 8-bit numbers (0-255) in dotted decimal notation (separated by decimal
points), for example, 192.68.203.5.

Record the IP Address assigned by your network administrator or MIS specialist.

3-1

Prestige 128MH PSTN Router/Hub

Chapter 3 Internet Access Application

Note on IP Address Assignment

A unique 32-bit IP address is assigned to each host on the Internet. Similarly, every machine on
an internet must have a unique IP address. Do not assign an arbitrary address to any machine on
your network without prior consulting your network administrator.

IP Subnet Mask

A subnet mask is a 32-bit quantity that, when logically ANDed with an IP address, yields the
network number. For instance, the subnet masks for class A, B and C without subnetting are

255.0.0.0, 255.255.0.0 and 255.255.255.0, respectively.

The subnet mask is used to split the IP network addresses to create more network numbers. More
network numbers can be created by shifting some bits from the host ID to the network ID. For
instance, to partition a class C network number 192.68.135.0 into two, you shift 1 bit from the
host ID to the network ID. Thus the new subnet mask will be 255.255.255.128; the first subnet
will have network number 192.68.135.0 with hosts 192.68.135.1 to 192.68.135.126 and the
second subnet will have network number 192.68.135.128 with hosts 192.68.135.129 to

192.68.135.254.

It is recommended that you use the same subnet mask for all physical networks that share an IP
network number. Table 3-1 below lists the additional subnet mask bits in dot decimal notations.
To use Table 3-1, write down the original subnet mask and substitute the higher order 0s with the
dot decimal of the additional subnet bits. For instance, to partition your class C network

204.247.203.0 with subnet mask 255.255.255.0 into 16 subnets (4 bits), the new subnet mask
becomes 255.255.255.240.

Table 3-1. Subnet Mask Notation

Additional Subnet Mask Bits in Dot Decimal Notation

Number of Bits Dot Decimal Value

1

2

3-2

128

192

Chapter 3 Internet Access Application

Table 3-1. Subnet Mask Notation (continued)

Number of Bits Dot Decimal Value

Prestige 128MH PSTN Router/Hub

3

4

5

6

7

8

224

240

248

252

254

255

Table 3-2 lists some examples of IP subnet masks and the number of hosts that are allowed.
Consult your network administrator or MIS specialist if you are unsure of this value.

Table 3-2. Examples of IP Subnet Masks

IP Subnet Mask Number of Host IDs Number of Bits

255.255.255.0 254 24

255.255.255.128 126 25

255.255.255.192 62 26

255.255.255.224 30 27

255.255.255.255 1 32

An IP address consists of two parts, the network ID and the host ID. The IP Subnet Mask is used
to specify the network ID portion of the address, expressed in dotted decimal notation.The
Prestige will automatically calculate this mask based on the IP address that you assign. Unless
you have special need for subnetting, use the default mask as calculated by the Prestige.

3-3

Prestige 128MH PSTN Router/Hub

Chapter 3 Internet Access Application

Private IP Adresses

If your networks are isolated from the Internet (for example, only between your two branch
offices) you can assign arbitrarily any IP addresses to the hosts without problems. However, the
Internet Assigned Numbers Authority (IANA) has reserved the following three blocks of IP
addresses specifically for private networks, as shown in Table 3-2.

For this reason, it is recommended that you choose your private network number from the list
provided in Table 3-3.

Table 3-3. Private Networks IP Addresses

Private IP Addresses

10.0.0.0 - 10.255.255.255

172.16.0.0 - 172.31.255.255

192.168.0.0 - 192.168.255.255

Assigning IP Addresses

You can obtain your IP address from the IANA, from an ISP, or assigned from a private network.
If you belong to a small organization and your Internet access is through an ISP, the ISP can
provide you with the Internet addresses for your local networks. On the other hand, if you are part
of a much larger organization, you should consult your network administrator for the appropriate
IP addresses.

Note on IP Address Assignment

Regardless of your particular situation, do not create an arbitrary IP Address, always follow the
guidelines above. For more information on address assignment, refer to RFC 1597, Address
Allocation for Private Internets, and RFC 1466, Guidelines for Management of IP Address Space.

3-4

Prestige 128MH PSTN Router/Hub

Chapter 3 Internet Access Application

3.2 Route IP Setup

The first step in configuring your Prestige for Internet Access is to enable the Route IP function in
Menu 1 - General Setup.

To edit Menu 1, select the menu option [1. General Setup] in the Main Menu and press [Enter].

When Menu 1 appears, fill in the required fields marked [?] and set the Route IP field to
[Yes], as shown in Figure 3-1.

Menu 1 - General Setup

System Name= p128MH
Location= location
Contact Person's Name= name

Route IP= Yes
Route IPX= No
Bridge= No

Press ENTER to Confirm or ESC to Cancel:

Figure 3-1. Menu 1 - General Setup

3-5

Prestige 128MH PSTN Router/Hub

Chapter 3 Internet Access Application

Press Space Bar to Toggle.

3.3 TCP/IP Ethernet Setup and DHCP

You will now configure in Menu 3.2 the Ethernet port of your Prestige for a TCP/IP connection.

To edit Menu 3.2, select the menu option [3. Ethernet Setup] in the Main Menu. When Menu 3
appears, select the submenu option [2. TCP/IP and DHCP Setup] and press [Enter]. The screen

now displays Menu 3.2 - TCP/IP and DHCP Ethernet Setup, as shown in Figure 3-2.

Menu 3.2 - TCP/IP and DHCP Ethernet Setup

DHCP Setup:

DHCP= None
Client IP Pool Starting Address= N/A
Size of Client IP Pool= N/A
Primary DNS Server= N/A
Secondary DNS Server= N/A

TCP/IP Setup:

IP Address= 192.68.0.1
IP Subnet Mask= 255.255.255.0
RIP Direction= Both

Version= RIP-2B

Figure 3-2. Menu 3.2 - TCP/IP and DHCP Ethernet Setup

3-6

Enter here to CONFIRM or ESC to CANCEL:

Prestige 128MH PSTN Router/Hub

Chapter 3 Internet Access Application

Prestige

Follow the instructions in Table 3-4.on how to configure the DHCP fields.

Table 3-4. DHCP Ethernet Setup Menu Fields

Field Description Example

DHCP

If DHCP=Server:

Client IP Pool Starting

Address

Size of Client IP Pool Gives the size of the block of addresses reserved for DHCP

Primary DNS Server
Secondary DNS
Server

This field determines the mode of DHCP (Dynamic Host
Configuration Protocol) support. If set to [None], DHCP will not
be used. If it is set to [Server], your Prestige will act as a DHCP
server, capable of automatically assigning IP addresses to
Windows 95, Windows NT, and other systems that support the
DHCP client.

When DHCP is used, the following four items need to be set:
DHCP can assign IP addresses to hosts dynamically instead of

requiring that each system have a fixed IP address. IP
addresses are allocated from a block of addresses, usually
assigned by your Internet provider. The Client IP Pool Starting
Address gives the first address in the reserved block, which is
also used as the LAN network address of the
address will also serve as the default gateway for DHCP clients.

address assignment. The Prestige itself uses the first address in
the block, and the remaining addresses in the pool are assigned
to clients.

These two fields are used by DHCP clients (such as Windows
95 and Windows NT systems) for Domain Name Servers.
Usually your Internet provider will provide one or more name
service hosts.

itself. This

[None]

(default)

[Server]

Note on DHCP

Once you have determined the IP address range for your local network, you may want to use
DHCP to assign addresses to individual hosts on the network, as an alternative to manually
configuring the IP setting for each host.

3-7

Prestige 128MH PSTN Router/Hub

Chapter 3 Internet Access Application

Prestige

Prestige

Table 3-5 contains instructions on how to configure your Prestige for TCP/IP Ethernet Setup.

Table 3-5. TCP/IP Ethernet Setup Menu Fields

Field Description Example

TCP/IP Setup

IP Address Enter the IP address of your Prestige in dotted decimal notation

(four 8-bit numbers, between 0 and 255, separated by periods)Note
that every machine on the TCP/IP network must have a unique IP
address.

IP Subnet
Mask

RIP Direction This parameter determines how your Prestige handles RIP

An IP address consists of two parts, the network ID and the host ID.
The IP Subnet Mask is used to specify the network ID portion of the
address, expressed in dotted decimal notation. Your Prestige will
automatically calculate this mask based on the IP address that you
assign. Unless you have special need for subnetting, use the
default subnet mask.

(Routing Information Protocol). If set to [Both] (default), your

will broadcast its routing table on the LAN, and incorporate
RIP broadcasts by other routers into the routing table. If set to In
Only, your
set to Out Only, your Prestige will broadcast the routing table but
ignores any RIP broadcast packets that it receives. If set to None,
your Prestige will not participate in any RIP exchange with other
routers.

Version: The default is [RIP-2B]

Note: Usually, you should use the default RIP [Both], and let
RIP propagate the routing information automatically.

will not broadcast its routing table on the LAN, if

192.68.135.5
(example)

255.255.255.0
(default)

[Both]

(default)

When you have completed this menu, press [Enter] at the prompt [Press ENTER to Confirm…] to save your
selections, or press [Esc] at any time to cancel.

3-8

Prestige 128MH PSTN Router/Hub

Chapter 3 Internet Access Application

3.4 Internet Access Configuration

Menu 4 of the SMT allows you to configure Internet Access on one screen. Before you configure
your Prestige for Internet Access, you need to collect your Internet account information from your
ISP (Internet Service Provider).

Use Table 3-6 to record your Internet Account Information.

Table 3-6. Internet Account Information

Internet Account Information Write your account information here

IP Address of the ISP's Gateway (Optional)

Telephone Number(s) of your ISP

Login Name

Password for ISP authentication
Domain Name Server (DNS) for your workstation

-

-

-

-

-

From the Main Menu, enter option [4. Internet Access Setup] to go to Menu 4 - Internet Access
Setup, as displayed in Figure 3-3.

Menu 4 - Internet Access Setup

ISP's Name= ?
ISP Gateway IP Addr=
Connection Type= Switch

Leased Ports= N/A
Pri Phone #= ?
Sec Phone #=
My Login=
My Password= ********
Single User Account= No

Local IP Addr= N/A

Server IP Addr= N/A
Edit Script Options= No
Device Type= 56K Modem

Figure 3-3. Menu 4 - Internet Access Setup

Enter here to CONFIRM or ESC to CANCEL:

3-9

Prestige 128MH PSTN Router/Hub

Chapter 3 Internet Access Application

If [Leased] is selected in Connection Type

Table 3-7 contain instructions on how to configure your Prestige for Internet Access.

Table 3-7. Internet Access Setup Menu Fields

Field Description Observation

ISP's Name Enter the name of your Internet Service Provider. (This information

is for identification purposes only.)

ISP IP Addr Enter the IP Address of the remote gateway at the ISP's site. If you

do not have this data, just leave it blank.

Connection Type Select [Switch] if a Dail-up modem is used to connect to your ISP.

Select [Leased] if a Leased Line Modem is used to connect to your
ISP.

Leased Ports

WAN port that supports Leased Line connections.
This field is read only (r.o.), since only the serial port WAN port 1

supports, enter the WAN Port numbers in the Leased Line
connection.

Note: The Connection Type of WAN Port 1 also must be
specified as [Leased] in Menu 2.1 - Async WAN Port Setup.

Pri(mary) Phone #

Sec(ondary) Phone#If the Primary Phone number is busy or does not answer, your

My Login Name Enter the login name assigned to you by your ISP. (required)

The first number your Prestige will dial to connect to the ISP. Once
connected, your Prestige will use the BACP (Bandwidth Allocation
Control Protocol) to establish the second B-channel if PPP/MP is
enabled, and the ISP also supports MP and BACP.

Prestige will call the Secondary Phone number if available.

, this field displays the

Myisp

(optional)

Space-bar to

toggle

[Switch/Leased]

[1 (r.o.)]

(required)

(optional)

My Password Enter the password associated with the login name above. Note

that this login name/password pair is only for your Prestige to
connect to the ISP's gateway. When you use TCP/IP applications
(for example, FTP) to access the Internet from your workstation,
you will need a separate login name and password for each server.

3-10

(required)

Prestige 128MH PSTN Router/Hub

Chapter 3 Internet Access Application

Table 3-7. Internet Access Setup Menu Fields (continued)

Field Description Observation

Single User Account See Section 3.5 for a more detailed discussion on the Single User

Account feature.

Edit Script Option To edit the parameters, select [Yes] and press [Enter]. This will

bring you to Menu 4.1 - Remote Node Script Options. This field is
not applicable if the Connection Type is [Leased].

Device Type A Remote Node only picks up a free device of the selected Device

Type to dial out. This field is not applicable if the Connection Type
is [Leased]. Selections:[Modem/ISDN TA/X.25 PAD/56K Modem]

Press [Enter] at the message [Press ENTER to Confirm ...] to confirm your selections, or press [Esc] at any
time to cancel your selections.

[Yes/No]

Space-bar to

toggle

At this point, the SMT will ask if you wish to test the Internet connection. If you select [Yes],
your Prestige will call the ISP to test the Internet connection. If the test fails, note the error
message that you receive on screen and take the appropriate troubleshooting steps.

3-11

Prestige 128MH PSTN Router/Hub

Chapter 3 Internet Access Application

192.168.0.4

192.168.0.5

192.168.0.6

192.168.0.7

192.168.0.1

3.5 Single User Account

Typically, if there are multiple users on the LAN wanting to concurrently access the Internet, they
will have to subscribe to multiple IP addresses or a Class C sub-network from the ISP. In either
case, these two approaches will cost more than a single user account.

The Single User Account (SUA) feature allows customers to have the same benefits as having a
Class C address, but still only pay for one IP address, thus saving significantly on subscription
fees. (Check with your ISP before you enable this feature).

Figure 3-4 illustrates a typical Single User Account topology.

Same Network
Addresses

IP Address
Assigned by ISP

Prestige 128MH

INTERNET

Prestige 128MH

Ethernet LAN

Figure 3-4. Single User Account Topology

The Single User Account feature may also be used to connect to TCP/IP remote nodes other than
the ISP. For example, this feature can be used to simplify the allocation of IP addresses when
connecting branch offices to the corporate network.

3-12

Prestige 128MH PSTN Router/Hub

Chapter 3 Internet Access Application

The IP address for the SUA can be either fixed or dynamically assigned by the ISP (or other
remote node). In addition, you can also configure a server (for example, a Web server) on your
local network and make it accessible by outside users.

If you do not set a server IP address, SUA offers the additional benefit of firewall protection. With
SUA, even if no server is defined, all incoming inquiries will be filtered out by your Prestige even
if you do have a server on your network. This can prevent intruders from probing your system.

Your Prestige accomplishes this address sharing by translating the internal LAN IP addresses to a
single address that is globally unique on the Internet. For more information on IP address
translation, refer to RFC 1631, The IP Network Address Translator (NAT).

3.5.1 Advantages of SUA

In summary:
l SUA is an ideal cost-effective solution for small offices with less than 20 hosts using a LAN

to concurrently access the Internet or other remote TCP/IP network.

l SUA can provide one server address to be accessed by Remote Dial-in Users, thus

controlling the incoming packets.

l SUA can provide firewall protection if you do not configure a server IP address. All

incoming inquiries will be filtered out by your Prestige protecting the servers on your
network.

l UDP and TCP datagrams can be routed. In addition, ICMP echo can also be routed.

Figure 3-4 shows an example of a small office connected to the Internet via a SUA using the
Prestige. Note that if you enable the SUA feature, your local IP address MUST be selected from
the list of IP addresses for private networks as defined by the IANA.

3-13

Prestige 128MH PSTN Router/Hub

Chapter 3 Internet Access Application

3.5.2 Configuration for Single User Account

The steps for configuring your Prestige for Single User Internet Access are identical to
conventional Internet Access (See configuration instructions in Table 3-7) with the exception that
you need to fill in three extra fields in Menu 4 - Internet Access Setup, as shown in Figure 3-5.

Menu 4 - Internet Access Setup

ISP's Name= ?
ISP Gateway IP Addr=
Connection Type= Switch

Leased Ports= N/A

Pri Phone #= ?

SUA

Sec Phone #=
My Login=
My Password= ********
Single User Account= Yes

Local IP Addr=

Server IP Addr=
Edit Script Options= No
Device Type= 56K Modem

Enter here to CONFIRM or ESC to CANCEL:

Figure 3-5. Menu 4 - Internet Access Setup for Single User Account

To enable the SUA feature in Menu 4, move the cursor to the [Single User Account] field and
select [Yes] (or [No] to disable SUA). Then follow the instructions on how to configure the SUA
fields in Table 3-8.

3-14

Prestige 128MH PSTN Router/Hub

Chapter 3 Internet Access Application

Table 3-8. Single User Account Menu Fields

Field Decription

Single User Account Select [Yes] to enable SUA.

Local IP Addr. If your ISP assigns you a dynamic IP address, enter [0.0.0.0] here.

If your ISP assigns you a static IP address, enter that IP address here.

Server IP Addr. If you want to make a single server (for example, a Web server) accessible

to outside users, enter that server's IP address here.

Press [Enter] at the message [Press ENTER to Confirm ...] to save your selections, or press [Esc] at
any time to cancel your selections.

At this point, your Prestige will ask if you wish to test the Internet connection. If you select [Yes],
the ISP will be called, and the connection tested. If the test fails, note the error message that you
receive and take the appropriate troubleshooting steps.

3.6 Configuring Backup ISP Accounts

Sometimes it may be desirable to configure more than one ISP account for backup purposes. The
SUA feature can be enabled for all of these accounts, making it convenient to switch Internet
Service Providers in the event of a failure.

3.6.1 Configure a Backup ISP

To configure a backup ISP Account, follow these steps:

Step 1. Configure your primary ISP using Menu 4, as described earlier in this chapter.

Step 2. Enter Menu 11, then select the number of an unused remote node.

3-15

Prestige 128MH PSTN Router/Hub

Chapter 3 Internet Access Application

Step 3. In Menu 11.1, choose a name for your backup ISP account, then set the Active field to

[No], and enter your outgoing login name, password, and phone number(s). The
Remote IP Address field should be set to [1.1.1.1].

Step 4. In Menu 11.3, set the remote node's subnet mask to [0.0.0.0], and set RIP to [None].

Step 5. Save the new configuration.

3.6.2 To Switch ISP

Once you have done this, if you need to switch from your primary ISP to a backup ISP follow
these steps:

Step 1. Enter Menu 11 and select your Primary ISP.

Step 2. In Menu 11.1, set the Active field to [No].

Step 3. Enter Menu 11 again and select your Backup ISP.

Step 4. In Menu 11.1, set the Active field to [Yes].

You will now be able to access the Internet through the backup ISP Remote Node.

3-16

Prestige 128MH PSTN Router/Hub

Chapter 3 Internet Access Application

Press Space Bar to Toggle.

3.7 Editing Script Options

For some ISP, login script handshaking is required after a call connection. The Prestige provides
four set of programming scripts for this purpose. Each set of script is composed of an ‘expect’
string and a ‘send’ string. After capturing of the string in the field of ‘ expect’ , the Prestige will
send out the string in the field of ‘send’. If both of Expect and Send fields are empty, the Prestige
will terminate script handshaking. The Script Options display as shown in Figure 3-6.

Menu 11.4 - Remote Node Script

Active= No

Set 1:

Expect=
Send=

Set 2:

Expect=
Send=

Set 3:

Expect=
Send=

Set 4:

Expect=
Send=

Press ENTER to CONFIRM or ESC to CANCEL:

Set 5:

Expect=
Send=

Set 6:

Expect=
Send=

Figure 3-6. Menu 11.4 - Remote Node Script

The following Table 3-9 describes each field in Menu 11.4 - Remote Node Script.

Table 3-9. Remote Node Script Menu Fields

Field Description Option

Active Press the space bar to toggle between [Yes] and [No].

When a Remote Node Script is deactivated, it has no effect on the
operation of your Prestige, even though it is still kept in the database,
and can be activated in the future.

Set 1-6: Expect Enter an Expect string to capture. After capturing the Expect string,

the Prestige will send out the string in the [Send] field.

Set 1-6: Send Enter a string to send out after the Expect string is captured.

Press space
bar to toggle

[Yes/No]

3-17

Prestige 128MH PSTN Router/Hub

Chapter 4 Telecommuting

Chapter 4

Telecommuting

You can configure your Prestige to receive calls from Remote Dial-in Users (for example,
Telecommuters) and Remote Nodes. There are several differences between Remote Dial-in Users
and Remote Nodes, as summarized in Table 4-1.

Table 4-1. Remote Dial-in Users/Remote Nodes Comparison Chart

Remote Dial-in Users Remote Nodes

Your Prestige will only answer calls from Remote
Dial-in Users.

All Remote Dial-in Users share one common set of
parameters, as defined in the Default Dial In Setup
(Menu 13).

Remote Dial-in Users are individual users who dial
in to your Prestige directly from their workstations.

Your Prestige can make calls to or answer calls from
the Remote Node.

Each Remote Node can have its own set of
parameters such as Bandwidth On Demand,
Protocol, Security, etc.

Remote Nodes represent networks and are used for
LAN-to-LAN connections.

This chapter discusses how to setup Default Dial-in parameters for both Remote Node and
Remote Dial-in Users. The following sections give two examples of how your Prestige can be
configured as a dial-in server for either or both.

By default, your Prestige allows information for up to eight users to be kept. If more than eight
remote dial-in users can access your Prestige, you can use a separate RADIUS server to provide
remote authentication services. For details on using a separate RADIUS server, see the Using
RADIUS Authentication section in Chapter 11 - System Security.

4-1

Prestige 128MH PSTN Router/Hub

Chapter 4 Telecommuting

Telecommuter

PSTN Network

4.1 Telecommuting

Telecommuting enables people to work at remote sites and yet still have access to the resources in
the business office. Typically, a telecommuter will use a client workstation with TCP/IP or IPX
and dial-out capabilities (for example, a Windows 95 PC or a Macintosh) connected to a Modem
or an ISDN Terminal Adapter (ISDN TA). For telecommuters to call in to your LAN, you need to
configure a Dial-In User Profile for each telecommuter. Additionally, you need to configure the
Default Dial-In Setup to set the operational parameters for all dial-in users. You can configure up
to eight Remote Dial-in Users for your Prestige.

An example of Remote Dial-in User application, telecommuting, is shown in Figure 4-1.

Coporate LAN

Remote User

4-2

Ethernet LAN

Modem / ISDN TA

Modem

Figure 4-1. Example of Remote User: Telecommuter

(Telephone Line)

Prestige 128MH

Prestige 128MH PSTN Router/Hub

Chapter 4 Telecommuting

4.2 Dial-In Server Application

Your Prestige can also be used as a dial-in server. This application allows your Prestige to provide
services for workstations on a remote network. For your Prestige to be set up as a dial-in server,
you need to configure the Default Dial-In Setup to set the operational parameters for incoming
calls. Additionally, you will have to create a Remote Node for the router on the remote network
(see Chapter 5 - Remote Node Configuration for LAN-to-LAN).

An example of your Prestige being used as a dial-in server is shown in Figure 4-2.

Remote Network Local Network

Prestige 128MH

Prestige 128MHPrestige 128MH

Figure 4-2. Example of a Dial-in Server Application

4-3

Prestige 128MH PSTN Router/Hub

Chapter 4 Telecommuting

4.3 Default Dial-In Setup

This section covers the default dial-in parameters. The parameters in Menu 13 affect incoming
calls from all Remote Dial-in Users and Remote Nodes before authentication is completed. Once
authentication is completed, and if it matches a Remote Node, your Prestige will use parameters
from that particular Remote Node.

Menu 13 - Default Dial-in Setup

Telco Options:

CLID Authen= None

PPP Options:

Recv Authen= CHAP/PAP
Compression= Yes
Mutual Authen= No

PAP Login= N/A
PAP Password= N/A

Multiple Link Options:

Max Ports= 2

Callback Budget Management:

Allocated Budget(min)=
Period(hr)=

IP Address Supplied By:

Dial-in User= Yes
IP Pool= No

IP Start Addr= N/A
IP Count(1,3)= N/A

IPX Net Num Supplied By:

IPX Pool= No

IPX Start Net Num= N/A
IPX Count(2,16)= N/A

Session Options:

Input Filter Sets=
Output Filter Sets=
Idle Timeout= 300

Press ENTER to CONFIRM or ESC to CANCEL:

Press Space Bar to Toggle.

Figure 4-3. Menu 13 - Default Dial-in Setup

From the Main Menu, enter 13 to go to Menu 13 - Default Dial-in Setup. This section will
describe how to configure the protocol-independent fields in this menu. For the protocol­dependent fields, refer to the appropriate chapters.

Table 4-2 describes and contains information on how to configure each parameter in Menu 13 ­Default Dial-in Setup.

4-4

Prestige 128MH PSTN Router/Hub

Chapter 4 Telecommuting

Table 4-2. Default Dial-in Setup Fields

Field Description Option

Telco Options: CLID Authen This field sets the CLID authentication parameter for all

incoming calls. There are three options for this field:

l None - No CLID is required.
l Required - Must provide CLID, or call is

disconnected.

l Preferred - If the CLID is available then CLID will be

used to do authentication. If the CLID is not
available the call will continue.

PPP Options: Recv. Authen This field sets the authentication protocol used for

incoming calls. User names and passwords are
configured in the next section (Remote users/Dial-in
Users Setup). Options for this field are:

l CHAP/PAP - Your Prestige will try CHAP first, but

PAP will be used if CHAP is not available.

l CHAP - Use CHAP only.
l PAP - Use PAP only.
l None - Your Prestige tries to acquire CHAP/PAP

first, but no authentication is required if CHAP/PAP
is not available.

[None]

[Required]

[Preferred]

[CHAP/PAP]

[CHAP]

[PAP]

[None]

PPP Options: Mutual
Authen

PAP Login This field will only be enabled if the Mutual Authen. Field

PAP Password This field will only be enabled if the Mutual Authen. Field

Some vendors (for example, Cisco) implement a type of
mutual authentication. That is, the node that initiates the
call will request a user name and password from the far
end that they are dialing to. If the Remote Node that is
dialing in implements this type of authentication, set this
field to Yes.

is set to [Yes]. Enter in the login name to be used to
respond to the far end’ s PAP authentication request. This
field does not apply to CHAP authentication.

is set to [Yes]. Enter in the PAP password to be used to
respond to the far end’ s authentication request. This field
does not apply to CHAP authentication.

[Yes/No]

4-5

Prestige 128MH PSTN Router/Hub

Chapter 4 Telecommuting

Table 4-2. Default Dial-in Setup Fields (continued)

Field Description Option

Multiple Link Options: Max
Port

Callback Budget
Management: Allocated
Budget (min)

Callback Budget
Management: Period (hr)

Dial-In IP Address Supplied
By: Dial-in User

Dial-In IP Address Supplied
By: IP Pool

Enter the maximum number of ports in a connection
between your Prestige and the Remote Dial-in User.

This field will set a budget callback time for all the
Remote Dial-in Users. The default for this field is [0] for
no budget control.

This field will set the time interval to reset the above
callback budget control.

If set to [Yes], it tells your Prestige to allow a remote host
to specify its own IP address. This is to prevent the
remote host from using an invalid IP address and
potentially disrupting the whole network.

If set to [No], the remote host must use the IP address
assigned by your Prestige from the IP pool, configured
below.

This field tells your Prestige to provide the remote host
with an IP address from the pool. This field is required if
Dial-In IP Address Supplied By: Dial-in User is set to [No].
You can configure this field even if Dial-in User is set to
[Yes], in which case your Prestige will accept the IP
address if the remote peer specifies one; otherwise, an IP
address is assigned from the pool.

Default = 1

Default = 0

(Default = Yes)

[Yes/No]

[Yes/No]

(Default = No)

IP Pool: IP Start Addr This field is active only if you selected [Yes] in the Dial-In

IP Count (1-3) In this field, enter the number ([1], [2], or [3]) of the

4-6

IP Address Supplied By: IP Pool field.
The IP pool contains contiguous IP addresses and this

field specifies the first one in the pool.

[1], [2], [3]
addresses in the IP Pool. For example, if the starting
address is 192.168.135.5 and the count is [2], then the
pool will have 192.68.135.5 and 192.68.135.6

Prestige 128MH PSTN Router/Hub

Chapter 4 Telecommuting

Table 4-2. Default Dial-in Setup Fields (continued)

Field Description Option

Dial-In IPX Net. Num.
Supplied By: IPX Pool

IPX Start Net. Num. This field is active only if you selected [Yes] in the Dial-In IPX

IPX Count (1,16) In this field, enter the number ([1] - [16]) of network numbers in

Session Options:

Input Filter Sets
Output Filter Sets

This field tells your Prestige to provide the remote host with an
IPX network number from the pool. Otherwise, your Prestige will
generate a random IPX network number.

Net. Num. Supplied By: IPX Pool field. The IPX pool contains
contiguous IPX network numbers and this field specifies the first
one in the pool.

the IPX Pool. For example, if the starting number is 12345678,
and the count is [2], then the IPX pool will have 12345678 and

12345679.

In these fields, you need to select the filter set(s) to filter the
incoming and outgoing traffic between your Prestige and the
Remote Dial-in User. Keep in mind that these filter set(s) will
only apply to all Remote Dial-in Users but not the Remote
Nodes.

You can choose from 12 different filter sets. In addition, you can
link up to 4 filter sets together for further customization (for
example, 1, 5, 9, 12).

Note that spaces and [-] symbol, are accepted in this field. For
more information on customizing your filter sets, see Chapter 9 -
Filter Configuration. The default is blank, i.e., no filters.

[Yes/No]

(Default = No)

[1] to [16]

Default = blank

Session Options:

Idle Timeout

Once you have completed filling in Menu 13 - Default Dial-in Setup, press [Enter] at the message [Press
ENTER to Confirm…] to save your selections, or press [Esc] at any time to cancel your selections.

This value is the number of idle seconds that elapses before the
dial-in user is automatically disconnected. Idle Timeout is the
period of time when there is no data traffic between the dial-in
user or Remote Node and your Prestige.

This field will only be used if the Recv. Authen field is set to
[None] and the call is not mapped to any Remote Node or
Remote Dial-in User or your Prestige calls back to the Remote
Dial-in User.

4-7

Prestige 128MH PSTN Router/Hub

Chapter 4 Telecommuting

4.4 Dial-In Users Setup

The following steps describe the setup procedure for adding a Remote Dial-in User.

Step 1. From the Main Menu, enter option 14 to go to Menu 14 - Dial-in User Setup, as shown

in Figure 4-4.

Menu 14 - Dial-in User Setup

1. johndoe

2. ________

3. ________

4. ________

5. ________

6. ________

7. ________

8. ________

Enter Menu Selection Number:

Figure 4-4. Menu 14 - Dial-in User Setup

Step 2. Select one of eight users by number, this will bring you to Menu 14.1 - Edit Dial-in

User, as shown in Figure 4-5.

Menu 14.1 - Edit Dial-in User

User Name= ?
Active= Yes
Password= ?
Callback= No

Phone # Supplied by Caller= N/A

Callback Phone #= N/A
Rem CLID=
Idle Timeout= 300

Press ENTER to Confirm or ESC to Cancel:

Figure 4-5. Menu 14.1 - Edit Dial-in User

4-8

Prestige 128MH PSTN Router/Hub

Chapter 4 Telecommuting

Table 4-3 provides instructions on how to fill in the Edit Dial-In User fields.

Table 4-3. Edit Dial-in User Menu Fields

Field Description Option

User
Name

Active You can disallow dial-in access to this user by setting this field to [Inactive].

Password Enter the password for the Remote Dial-in User.

Callback This field determines if your Prestige will allow call back to the Remote Dial-in

Phone #
Supplied
by Caller

This is a required field. This will be used as the login name for authentication.
Choose a descriptive word for login, for example, [johndoe].

When set to [inactive], the user record is still kept in the database for later
activation. Deactivated users are displayed with a [-] (minus sign) at the
beginning of the name in Menu 14.

User upon dial-in. If this option is enabled, your Prestige will be able to call
back to the Remote Dial-in User if they request it. In such a case, your
Prestige will disconnect the initial call from this user and dial back to the
specified callback number (see below).

l [No] - The default is [no callback].
l [Optional] - The user can choose to disable callback.
l [Mandatory] - The user can not disable callback.

This option allows the Remote Dial-in User to specify the call back telephone
number on a call-by-call basis. This is useful for when your Prestige returns a
call back to a mobile user at different numbers (for example, a Sales Rep. in a
hotel).

l If the setting is [Yes], the user can specify and send to the Prestige the

callback number of his/her choice.

l Note that the default is [No], that is your Prestige always calls back to

the fixed callback number.

[Active]

[Inactive]

Default=No

[No]

[Optional]

[Mandatory]

Default=No

[Yes]

[No]

Callback
Phone #

If [Phone # Supplied by Caller] is [Yes], then this is a required field. Otherwise,
a [N/A] will appear in the field. Enter the telephone number to which your
Prestige will call back.

4-9

Prestige 128MH PSTN Router/Hub

Chapter 4 Telecommuting

Table 4-3. Edit Dial-in User Menu Fields (continued)

Field Description Option

Rem CLID If you have enabled the CLID Authen field in Menu 13, then you need to

specify the telephone number from which this Remote Dial-in User calls. Your
Prestige will check this number against the CLID in the incoming call. If they
do not match and the CLID Authen is Required, then your Prestige will reject
the call.

Idle Time­out

Once you have completed filling in Menu 14.1 - Edit Dial-in User, press [Enter] at the message [Press
ENTER to Confirm…] to save your selections, or press [Esc] at any time to cancel your selections.

Enter the idle time (in seconds). This time-out determines how long the dial-in
user can be idle before your Prestige disconnects the call.

Idle time is defined as the period of time where there is no data traffic between
the dial-in user and your Prestige. The default is 300 seconds (5 minutes).

Default=300

seconds

4.5 More on CLID

CLID allows your Prestige to authenticate the caller before a call is answered, thus saving the cost
of a connection. Your Prestige uses the caller ID in call setup message to match against the CLID
in the database.

Note on CLID and Modems

For your Prestige to use the CLID authentication, it is necessary that your modem also support
caller CLID.

Besides authentication, another application of CLID is to combine it with callback. For instance,
your company pays for the connection charges for telecommuting employees and you use your
Prestige as the dial in server. You can turn on both the CLID authentication and call back options
for the dial-in users. By doing so, all usage are charged to the company instead of the employees,
and your accounting department can avoid the hassles of accountability and reimbursement.

4-10

Prestige 128MH PSTN Router/Hub

Chapter 5 Remote Node Configuration for LAN-to-LAN

Chapter 5

Remote Node Configuration for LAN-to-LAN

A Remote Node represents both a remote gateway and the internet behind it, across a WAN
connection. A Remote Node is required for placing calls to or answering calls from a remote
network. Note that when you use Menu 4 to configure the Internet, your Prestige will
automatically add a Remote Node for you. Once a Remote Node is configured properly, traffic to
the remote LAN will trigger your Prestige to make a call automatically (i.e., Dial On Demand).
Similarly, calls from the remote LAN will be answered automatically and security will be
checked.

In this chapter, we will discuss the parameters that are protocol independent. The protocol­dependent configuration will be covered in subsequent chapters. For TCP/IP, see Chapter 6. For
IPX, see Chapter 7. For Bridging, see Chapter 8.

5.1 Remote Node Setup

This section describes the configuration of protocol-independent parameters for the Remote
Node.

5.1.1 Remote Node Profile

To configure the Remote Node parameters, follow these steps:

Step 1. From the Main Menu, select menu option [11. Remote Node Setup]

Step 2. When Menu 11 appears, as shown in Figure 5-1, enter the number of the Remote Node

(1-4) that you wish to configure.

5-1

Prestige 128MH PSTN Router/Hub

Chapter 5 Remote Node Configuration for LAN-to-LAN

IP Address
Assigned by ISP

1. ________

2. ________

3. ________

4. ________

Menu 11 - Remote Node Setup

Enter Node # to Edit:

Figure 5-1. Menu 11 - Remote Node Setup

Step 3. When Submenu 11.1. - Remote Node Profile appears, select the connection type

depending on your particular application (dial-up line or leased line application). Move
the cursor to the Connection Type field and use the space bar to toggle (Switch/Leased).
Set the Connection Type to one of the following values:

l [Switch]: for Dial-up Line Application, as shown in Figure 5-2.
l [Leased]: for Leased Line Application. Selecting [Leased] will bring you to the

Submenu 11.1.2 - Remote Node Profile for leased line application.

Menu 11.1 - Remote Node Profile

Rem Node Name= ?
Active= Yes
Connection Type= Switch
Call Direction= Both
Incoming:

Rem Login= ?
Rem Password= ?
Rem CLID=
Call Back= No

Outgoing:

My Login= ?
My Password= ?
Authen= CHAP/PAP
Pri Phone #= ?
Sec Phone #=

Device Type= 56K Modem
Route= IP
Bridge= No
Edit PPP Options= No
Rem IP Addr= ?
Edit IP/IPX/Bridge= No
Edit Script Options= No
Telco Option:

Allocated Budget(min)= 0
Period(hr)= 0

Session Options:

Input Filter Sets=
Output Filter Sets=
Call Filter Sets=
Idle Timeout(sec)= 300

Press ENTER to CONFIRM or ESC to CANCEL:

Figure 5-2. Menu 11.1 - Remote Node Profile for Dial-up Line Applications

5-2

Prestige 128MH PSTN Router/Hub

Chapter 5 Remote Node Configuration for LAN-to-LAN

Table 5-1 contains the instructions on how to configure the Remote Node Menu for Dial-up Line
applications.

Table 5-1. Remote Node Profile Menu Fields for Dial-up Line Applications

Field Description Options

Rem Node Name This is a required field [?]. Enter a descriptive name for the

Remote Node, for example, SJHQ.
This field can support up to eight characters. This name

must be unique from any other Remote Node name or
Remote Dial-in User name.

Active Press the space bar to toggle between [Yes] and [No].

When a Remote Node is deactivated, it has no effect on
the operation of your Prestige, even though it is still kept in
the database, and can be activated in the future.

Deactivated nodes are displayed with a minus sign (-) at
the beginning of the name in Menu 11.

Connection Type Use the space bar to toggle between [Switch] and

[Leased]. After [Leased] is selected, moving the cursor to
the next field will bring you to Submenu 11.1.2 for a
Leased Line Modem application.

Call Direction

l If this parameter is set to [Both], your Prestige can

both place and receive calls to/from a Remote Node.

l If set to Incoming, your Prestige will not place a call

to a Remote Node.

l If set to Outgoing, your Prestige will drop any call

from a Remote Node.

Several other fields in this menu depend on this
parameter. For example, in order to enable [Call Back], the
Call Direction must be [Both].

Press space
bar to toggle

[Yes/No]

Press space
bar to toggle

[Switch/Leased]

[Both]

[Incoming]

[Outgoing]

5-3

Prestige 128MH PSTN Router/Hub

Chapter 5 Remote Node Configuration for LAN-to-LAN

Table 5-1. Remote Node Profile Menu Fields for Dial-up Line Applications (continued)

Field Description Options

Incoming: Rem Node

Login Name

Incoming: Rem Node

Password

Incoming: Rem CLID This field is active only if [Call Direction] is either [Both] or

Incoming: Call Back This field will be valid only if [Call Direction] is [Both].

Enter the login name that this Remote Node will use when
it calls into your Prestige.

The login name in this field combined with the Rem Node
Password will be used to authenticate the incoming calls
from this node.

Enter the password used when this Remote Node calls
into your Prestige.

[Incoming]. Otherwise, an [N/A] appears in the field.
This is the Calling Line ID (the telephone number of the

calling party) of this Remote Node.
If you enable the CLID Authen field in Menu 13 - Default

Dial In, your Prestige will check this number against the
CLID in the incoming call. If they do not match and the
CLID Authen is Required, the call will be rejected.

Otherwise, an [N/A] appears in the field.
This field determines whether or not your Prestige will call

back after receiving a call from this Remote Node.

[Both]

[Incoming]

[N/A]

[Enable]

[Disable]

If this option is enabled, your Prestige will disconnect the
initial call from this node and call it back at the Outgoing
Primary Phone Number (see below).

Outgoing: My Login

Name

This is a required field [?] if [Call Direction] is either [Both]
or [Outgoing]. Enter the login name for your Prestige when
it calls this Remote Node.

5-4

Prestige 128MH PSTN Router/Hub

Chapter 5 Remote Node Configuration for LAN-to-LAN

Table 5-1. Remote Node Profile Menu Fields for Dial-up Line Applications (continued)

Field Description Options

Outgoing: My

Password

Outgoing: Authen

This is a required field [?] if [Call Direction] is either [Both]
or [Outgoing]. Enter the password for your Prestige when it
calls this Remote Node.

This field sets the authentication protocol used for
outgoing calls.

Your Prestige supports two authentication protocols:
PAP (Password Authentication Protocol) and CHAP

(Challenge Handshake Authentication Protocol).

l PAP sends the user name and password in plain text.
l CHAP scrambles the password before it is sent over

the wire.

Generally speaking, CHAP is more secure than PAP;
however, PAP is readily available on more platforms.

The recommendation is to use CHAP whenever possible.
Turning off the authentication is STRONGLY discouraged.

Options for this field are:

l CHAP/PAP - Your Prestige will try CHAP when

CHAP is requested by the Remote Node or PAP
when PAP is requested by the Remote Node.

[CHAP/PAP]

l CHAP - use CHAP only. [CHAP]

l PAP - use PAP only. [PAP]

5-5

Prestige 128MH PSTN Router/Hub

Chapter 5 Remote Node Configuration for LAN-to-LAN

Table 5-1. Remote Node Profile Menu Fields for Dial-up Line Applications (continued)

Field Description Options

Outgoing: Pri(mary)

Sec(ondary)
Phone
Numbers

Device Type Use the space bar to choose the following selections:

Route This fields determines the protocols that your Prestige

Both the Primary Phone number and the Secondary
Phone number refer to the number that your Prestige will
dial to connect to the Remote Node. Your Prestige will
always call the Remote Node using the Primary Phone
number first.

If the Primary Phone number is busy or does not answer,
your Prestige will call the Secondary Phone number if
available. Once connected, your Prestige will use the
BACP (Bandwidth Allocation Control Protocol) to
establish the second B-channel if Multilink PPP is
enabled, and the Remote Node supports MP and BACP.

Some areas require dialing the pound sign # before the
phone number for local calls. A # symbol may be
included at the beginning of the Primary Phone number
or Secondary Phone number as required.

Modem / ISDN TA / X.25 PAD / 56K Modem.
A Remote Node only picks up a free device of the

selected Device Type to dial out. Only the devices of the
same device type will be bundled.

will route. The choices for this field are determined by
the features enabled on your Prestige.

[Modem]

[ISDN TA]

[X25 PAD]

[56K Modem]

Bridge Bridging is used for protocols that are not supported or

not turned on in the previous Route field by your
Prestige, for example, SNA. When bridging is enabled,
your Prestige will forward any packet that it does not
recognize to this Remote Node; otherwise, the
unrecognized packets are discarded.

The disadvantage of bridging is that it usually generates
large amounts of traffic.

5-6

Press space bar

to toggle

[Yes/No]

Prestige 128MH PSTN Router/Hub

Chapter 5 Remote Node Configuration for LAN-to-LAN

Table 5-1. Remote Node Profile Menu Fields for Dial-up Line Applications (continued)

Field Description Options

Edit PPP Options To edit the PPP options for this Remote Node, move the

cursor to this field, use the space bar to select [Yes] and
press [Enter] . This will bring you to Menu 11.2 ­Remote Node PPP Options. For more information on
configuring PPP options, see the section Editing PPP
Options.

IP Addr This is a required field [?] if [Route] is set to [IP]. Enter

the IP address of this Remote Node.

Edit IP/IPX/Bridge Options To edit the parameters, select [Yes] and press [Enter].

This will bring you to Menu 11.3 - Remote Node Network
Layer Options. For more information on this screen,
refer to the chapter pertaining to your specific protocol.

Edit Script Option To edit the parameters, select [Yes] and press [Enter].

This will bring you to Menu 11.4 - Remote Node Script
Options.

Telco Options:

Allocated Budget
(min)

Period (hr) This field will set the time interval to reset the above

This field will set a budget outgoing call time for the
Remote Node. The default for this field is [0] for no
budget control.

outgoing call budget control.

Press space bar

to toggle

[Yes]

then press

[Enter]

Press space bar

to toggle

[Yes]

then press

[Enter]

[Yes]

then press

[Enter]

Default = 0

Session Option:

Input Filter Sets,
Output Filter Sets and
Call Filter Sets

In these fields, select which filter set(s) you would like to
implement to filter the incoming and outgoing traffic
between this Remote Node and your Prestige. You can
choose from 12 different filter sets. In addition, you can
link up to 4 filter sets together for further customization
(for example, 1, 5, 9, 12).

Note that spaces are accepted in this field.

For more information on customizing your filter sets, see
Chapter 9. The default is blank, that is, no filters defined.

Default=Blank

5-7

Prestige 128MH PSTN Router/Hub

Chapter 5 Remote Node Configuration for LAN-to-LAN

Table 5-1. Remote Node Profile Menu Fields for Dial-up Line Applications (continued)

Field Description Options

Session Option:

Idle Timeout (sec)

Once you have completed filling in Menu 11.1.1 - Remote Node Profile, press [Enter] at the message
[Press ENTER to Confirm…] to save your selections, or press [Esc] at any time to cancel your selections.

This value specifies the number of idle seconds that
elapses before the Remote Node is automatically
disconnected. Idle seconds is the period of time where
no data is passed between the Remote Node and your
Prestige. Administrative packets such as RIP are not
counted as data. The default is 300 seconds (5
minutes).

Default=300sec

5.1.2 Bandwidth on Demand

The Bandwidth on Demand (BOD) feature allows you to bundle two or three WAN Ports in one
connection. The additional ports are added and subtracted dynamically according to traffic
demand. The Prestige uses the Bandwidth Allocation Control Protocol (BACP) and the Multilink
Protocol (MP) to implement bandwidth on demand.

The configuration of bandwidth on demand is based on the Minimum and Maximum Ports of a
Remote Node. If Minimum and Maximum Ports are 1, BOD is disabled. Otherwise, BOD is
enabled.

When bandwidth on demand is enabled, a second port will be brought up if traffic on the initial
channel is higher than the high Target Utility number (for second port) for longer than the
specified Add Persist value. Similarly, the second port will be dropped if the traffic level falls
below the low Target Utility number for longer than the Subtract Persist value.

The Target Utility for a second port specifies the line utilization range at which you want your
Prestige to add or subtract bandwidth. The parameters are separated by a -. For example, 10-20
means the add threshold is 20 kbps and the subtract threshold is 10 kbps. Your Prestige will
perform bandwidth on demand only if it initiates the call. Addition and subtraction are based on
the value set in the BOD Calculation field. If this field is set to Transmit or Receive, then traffic in
either direction will be calculated to determine if a link should be added or dropped. Transmit will

5-8

Prestige 128MH PSTN Router/Hub

Chapter 5 Remote Node Configuration for LAN-to-LAN

Press Space Bar to Toggle.

only use outgoing traffic to make this determination, and Receive will only use incoming traffic to
make this determination.

If, after making the call to bring up a second port, the second port does not succeed in joining the
Multilink Protocol bundle (because the remote device does not recognize the second call as
coming from the same device), your Prestige will hang up the second port and continue with the
first port alone.

Similarly, a third port will be brought up or dropped based on the target utility for the third port.
The target utility for the third port is based on the Target Utility for the second port and
Bandwidth Increment for Additional Ports. For example, when Bandwidth Increment for an
Additional Port is 5 (Kbps) and the Target Utility for a second Port is 10-20; then the Target
Utility for a third port is 15-25.

See Menu 11.2 - Remote Node PPP Options in Figure 5-3 for a detailed description of BOD fields
and instructions on how to configure the PPP Options.

5.1.3 Editing PPP Options

To edit the remote node PPP Options, move the cursor to the [Edit PPP Options] field in Menu

11.1 - Remote Node Profile, and use the space bar to toggle and select [Yes], then press [Enter].
Menu 11.2 appears as shown in Figure 5-3.

Menu 11.2 - Remote Node PPP Options

Encapsulation= Standard PPP
Compression= No

Multiple Link Options:

BOD Calculation= Transmit or Receive
Min. Ports= 1
Max. Ports= 1
Target Utility for 2nd Port(Kbps) 32-48
Bandwidth increment for Additional Ports(Kbps)= 0
Add Persist(sec)= 5
Subtract Persist(sec)= 5

Press ENTER to CONFIRM or ESC to CANCEL:

Figure 5-3. Menu 11.2 - Remote Node PPP Options

5-9

Prestige 128MH PSTN Router/Hub

Chapter 5 Remote Node Configuration for LAN-to-LAN

Table 5-2 describes the Remote Node PPP Options Menu, and contain instructions on how to
configure the PPP options fields.

Table 5-2. Remote Node PPP Options Menu Fields

Field Description Option

Encapsulation

Compression Turn on the Stac Compression. The default for this

Multiple Link Options:

BOD Calculation Select the direction of the traffic you wish to

Min. Ports Enter the minimum number of ports for this Remote

Max. Ports Enter the maximum number of ports for this Remote

Target Utility for 2nd Port
(kbps)

Select CCP (Compression Control Protocol) for the
PPP or MP link. There are two options in this field.

l Standard PPP - Standard PPP options will be

used.

l CISCO PPP - Cisco PPP options will be used. [CISCO PPP]

field is Off.

calculate in order to determine when to add or
subtract a link. The default for this field is [Transmit
or Receive].

Node when a packet triggers a connection.

Node when a packet triggers a connection.
Enter the two thresholds separated by a [-] for

subtracting and adding the second port.

[Standard PPP]

[On/Off]

(Default = Off)

Default =

Transmit or

Receive

Default=10-20

Bandwidth Increment for
Additional Ports (Kbps)

Enter the Bandwidth Increment to define the two
thresholds for subtracting and adding the third port.

5-10

Prestige 128MH PSTN Router/Hub

Chapter 5 Remote Node Configuration for LAN-to-LAN

Table 5-2. Remote Node PPP Options Menu Fields (continued)

Field Description Option

Add Persist This parameter specifies the number of seconds

where traffic is above the adding threshold before
the Prestige will bring up the second channel.

Subtract Persist This parameter specifies the number of seconds

where traffic is below the subtraction threshold
before your Prestige drops the second channel.

Once you have completed filling in Menu 11.2 - Remote Node PPP Options, press [Enter] at the message
[Press ENTER to Confirm…] to save your selections, or press [Esc] at any time to cancel your selections.

Default = 5 sec

Default = 5 sec

5-11

Prestige 128MH PSTN Router/Hub

Chapter 5 Remote Node Configuration for LAN-to-LAN

5.2 Leased Line Connection

The Leased Line Modem Connection feature allows you to connect the serial port WAN Port 1 to
a Leased Line Modem (Async). The Connection Type of WAN port 1 must be selected as [Leased]
in Menu 2.1 - Async WAN Port Setup.

Note on PPP Echo Request/Reply

In a Leased Line Connection, a [PPP Echo Request] packet is sent periodically to every link
(WAN Port). This is to verify if the link is up. When your Prestige receives a [PPP Echo Request]
packet, it will send another [PPP Echo Reply] packet back to the sender through the same link.
When [PPP Echo Reply] packets are not received for several times, your Prestige will drop the
link.

Note on Backup Function for Leased Line

You can also enable a Backup function for a Leased Line connection. When all the links in a
Leased Line Connection drop, your Prestige will pick up any available [Switch] WAN port to
place a phone call to establish a Backup connection. When any link (WAN port) in the Leased
Line Connection becomes available again, your Prestige will drop the backup connection. The
Backup function is usually enabled in a Leased Line Connection for LAN-to-LAN applications.

5.2.1 Leased Line Remote Node Profile

From Submenu 11.1.2, select [Leased] in the Connection Type field to go to Submenu 11.1.2 ­Remote Node Profile for Leased Line application, as shown below in Figure 5-4.

5-12

Prestige 128MH PSTN Router/Hub

Chapter 5 Remote Node Configuration for LAN-to-LAN

Menu 11.1 - Remote Node Profile

Rem Node Name= ?
Active= Yes
Connection Type= Leased
Leased Ports= 1 (r.o.)
Incoming:

Rem Login= ?
Rem Password= ?

Outgoing:

My Login= ?
My Password= ?
Authen= CHAP/PAP

Backup Line Call Direction= Both

Device Type= 56K Modem
Pri Backup Phone #= ?
Sec Backup Phone #=

Press ENTER to CONFIRM or ESC to CANCEL:

Route= IP
Bridge= No

Edit PPP Options= No
Rem IP Addr= ?
Edit IP/IPX/Bridge= No

Session Options:

Input Filter Sets=
Output Filter Sets=
Idle Timeout(sec)= 300

Figure 5-4. Menu 11.1 - Remote Node Profile for Leased Line Applications

Table 5-3 describes each field in Menu 11.1.2 - Remote Node Profile for Leased Line
applications.

Table 5-3. Remote Node Profile Menu Fields for Leased Line Applications

Field Description Option

Rem Node Name This is a required field [?]. Enter a descriptive name

for the Remote Node, for example, SJHQ.

This field can support up to eight characters. This

name must be unique from any other Remote Node

name or Remote Dial-in User name.

Active Press the space bar to toggle between [Yes] and [No].

When a Remote Node is deactivated, it has no effect

on the operation of your Prestige, even though it is still

kept in the database, and can be activated in the

future.

Deactivated nodes are displayed with a minus sign [-]

at the beginning of the name in Menu 11.

Press space bar

to toggle
[Yes/No]

5-13

Prestige 128MH PSTN Router/Hub

Chapter 5 Remote Node Configuration for LAN-to-LAN

Table 5-3. Remote Node Profile Menu Fields for Leased Line Applications (continued)

Field Description Option

Connection Type: [Leased] Use space bar to toggle [Switch/Leased], and select

[Leased] and press [Enter].

Leased Port(s) If [Leased] is selected in Connection Type, this

field displays the WAN port that supports Leased
Line connections.

This field is read only (r.o.), since only the serial
port WAN port 1 supports, enter the WAN Port
numbers in the Leased Line connection.

Note: The Connection Type of WAN Port 1 also
must be specified as [Leased] in Menu 2.1 - Async
WAN Port Setup.

Incoming: Rem Node Login
Name

(*for backup line only)

Incoming: Rem Node
Password

(*for backup line only)

Outgoing: My Login Name

(*for backup line only)

Enter the login name that this Remote Node will use
when it calls into your Prestige. The login name in this
field combined with the Rem Node Password will be
used to authenticate the incoming calls from this
node.

Enter the password used when this Remote Node
calls into your Prestige.

This is a required field [?] if [Call Direction] is either
[Both] or [Outgoing]. Enter the login name for your
Prestige when it calls this Remote Node.

[Leased]

[1 (r.o.)]

Outgoing: My Password

(*for backup line only)

This is a required field [?] if [Call Direction] is either
[Both] or [Outgoing]. Enter the password for your
Prestige when it calls this Remote Node.

5-14

Prestige 128MH PSTN Router/Hub

Chapter 5 Remote Node Configuration for LAN-to-LAN

Table 5-3. Remote Node Profile Menu Fields for Leased Line Applications (continued)

Field Description Option

Outgoing: Authen

(*for backup line only)

This field sets the authentication protocol used for

outgoing calls.

Your Prestige supports two authentication protocols:

PAP (Password Authentication Protocol) and CHAP

(Challenge Handshake Authentication Protocol).

l PAP sends the user name and password in plain

text.

l CHAP scrambles the password before it is sent

over the wire.

Generally speaking, CHAP is more secure than PAP;

however, PAP is readily available on more platforms.

The recommendation is to use CHAP whenever

possible. Turning off the authentication is STRONGLY

discouraged.

Options for this field are:

l CHAP/PAP - Your Prestige will try CHAP when

CHAP is requested by the Remote Node or PAP
when PAP is requested by the Remote Node.

l CHAP - use CHAP only. [CHAP]

CHAP/PAP

CHAP

PAP

[CHAP/PAP]

l PAP - use PAP only. [PAP]

5-15

Prestige 128MH PSTN Router/Hub

Chapter 5 Remote Node Configuration for LAN-to-LAN

Table 5-3. Remote Node Profile Menu Fields for Leased Line Applications (continued)

Field Description Option

Backup Line Call Direction When the Backup Line function is enabled and if all

links (WAN Ports) in a Leased Line Modem
connections drop, your Prestige will pick up an
available Dial-up WAN port to trigger a backup
connection.

l If this parameter is set to [Both], your Prestige

can both place and receive calls to/from a
Remote Node.

l Set this parameter to [None] to de-activate the

Backup Line function.

l If set to Incoming, your Prestige will not place a

call to a Remote Node.

l If set to Outgoing, your Prestige will drop any call

from a Remote Node.

Device Type

(*for backup line only)

Pri(mary) Backup Phone #

(*for backup line only)

Use the space bar to choose the following selections:
Modem / ISDN TA / X.25 PAD / 56K Modem.

Your Prestige only picks up a free device of the
selected Device Type to dial up.

Enter the primary telephone number that your
Prestige will dial when the Backup Line function is
triggered.

Press space bar

to toggle

[Both/None/Out

going/Incoming]

[Both]

(default)

[None]

[Incoming]

[Outgoing]

[Modem]
[ISDN TA]
[X25 PAD]

[56K Modem]

Sec(ondary) Backup Phone #

(*for backup line only)

Enter the secondary telephone number that your
Prestige will dial when the Backup Line function is
triggered.

5-16

Prestige 128MH PSTN Router/Hub

Chapter 5 Remote Node Configuration for LAN-to-LAN

Table 5-3. Remote Node Profile Menu Fields for Leased Line Applications (continued)

Field Description Option

Route This field determines the protocols that your Prestige

will route. The choices for this field are determined by
the features enabled on your Prestige.

Bridge Bridging is used for protocols that are not supported

or not turned on in the previous Route field by your
Prestige, for example, SNA. When bridging is
enabled, your Prestige will forward any packet that it
does not recognize to this Remote Node; otherwise,
the unrecognized packets are discarded.

The disadvantage of bridging is that it usually
generates large amounts of traffic.

Edit PPP Options To edit the PPP options for this Remote Node, move

the cursor to this field, use the space bar to select
[Yes] and press [Enter] . This will bring you to Menu

11.2 - Remote Node PPP Options. For more
information on configuring PPP options, see the
section Editing PPP Options.

Rem IP Addr This is a required field [?] if [Route] is set to [IP]. Enter

the IP address of this Remote Node.

Edit IP/IPX/Bridge Options To edit the parameters, select [Yes] and press [Enter].

This will bring you to Menu 11.3 - Remote Node
Network Layer Options. For more information on this
screen, refer to the chapter pertaining to your specific
protocol.

Rem Password This is a required field [?] if [Route] is set to [IP]. Enter

the password used when this Remote Node calls into
your Prestige.

Press space bar

to toggle
[Yes/No]

Press space bar

to toggle

[Yes]

then press

[Enter]

Press space bar

to toggle

[Yes]

then press

[Enter]

5-17

Prestige 128MH PSTN Router/Hub

Chapter 5 Remote Node Configuration for LAN-to-LAN

Table 5-3. Remote Node Profile Menu Fields for Leased Line Applications (continued)

Field Description Option

Session Option:

Input Filter Sets, Output
Filter Sets and Call Filter
Sets

Session Option:

Idle Timeout (sec)

Once you have completed filling in Menu 11.1.2 - Remote Node Profile for Leased Line Connection, press
[Enter] at the message [Press ENTER to Confirm…] to save your selections, or press [Esc] at any time to
cancel your selections.

In these fields, select which filter set(s) you would like
to implement to filter the incoming and outgoing traffic
between this Remote Node and your Prestige. You
can choose from 12 different filter sets. In addition,
you can link up to 4 filter sets together for further
customization (for example, 1, 5, 9, 12).

Note that spaces are accepted in this field.
For more information on customizing your filter sets,

see Chapter 9. The default is blank, that is, no filters
defined.

This value specifies the number of idle seconds that
elapses before the Remote Node is automatically
disconnected. Idle seconds is the period of time where
no data is passed between the Remote Node and
your Prestige. Administrative packets such as RIP are
not counted as data. The default is 300 seconds (5
minutes).

Default=Blank

Default=300sec

5-18

Prestige 128MH PSTN Router/Hub

Chapter 5 Remote Node Configuration for LAN-to-LAN

Press Space Bar to Toggle.

5.2.2 Editing Leased Line PPP Options

To edit the remote node PPP Options in the case of a Leased Line connection, move the cursor to
the [Edit PPP Options] field in Menu 11.2 - Remote Node Profile, and use the space bar to
toggle and select [Yes], then press [Enter]. Menu 11.2 appears as shown in Figure 5-5.

Menu 11.2 - Remote Node PPP Options

Encapsulation= Standard PPP
Compression= No

Press ENTER to CONFIRM or ESC to CANCEL:

Figure 5-5. Menu 11.2 - Remote Node PPP Options for Leased Line Applications

Table 5-4 describes the Remote Node PPP Options Menu for Leased Line applications, and
contains instructions on how to configure the PPP options fields.

Table 5-4. Remote Node PPP Options Menu Fields for Leased Line Applications

Field Description Option

Encapsulation

Compression Turn on the Stac Compression. The default for this

Select CCP (Compression Control Protocol) for the
PPP or MP link. There are two options in this field.

l Standard PPP - Standard PPP options will be

used.

l CISCO PPP - Cisco PPP options will be used. [CISCO PPP]

field is Off.

[Standard PPP]

[On/Off]

(Default = Off)

5-19
