Z-Wave PSP05 operation manual

Motion Sensor PSP05

The motion sensor PSP05 has PIR function, based on Z-Wave

TM

technology.
This device is a Security Enabled Z-Wave Plus Product. Z-WaveTM is a
wireless communication protocol designed for home automation,
specifically to remotely control applications in residential and light
commercial environments. The technology uses a low-power RF radio
embedded or retrofitted into home electronics devices and systems,
such as lighting, home access control, entertainment systems and
household appliances.

This product can be included and operated in any Z-WaveTM network
with other Z-WaveTM certified devices from other manufacturers and/or
other applications. All non-battery operated nodes within the network
will act as repeaters regardless of vendor to increase reliability of the
network.

The device adopt the Z-WaveTM 500 series chip, when your Z-Wave

TM

network system is all made by Z-WaveTM 500 series devices. The
network system will have the advantages as below.

• Concurrent multi-channel support reduces external interference.

• Better RF range, improve about 10 meters in indoor.

• Support 100 Kbps transmit speed, speed up communication.

Add to/Remove from Z-WaveTM Network

There are two keys in the device, one is tamper key, another is a
button. Button can add, remove, reset or association from Z-Wave

TM

network.

In the first time, add the device into the Z-WaveTM network. First, make
sure the primary controller is in the add mode. And then power on the
device, just take out the insulation Mylar in the back side of the device.
The device will auto start the NWI (Network Wide Inclusion) mode. And
it should be included in 5 seconds. You will see the LED light ON one
second.

Notice: Including a node ID allocated by Z-WaveTM Controller means
“Add” or “Inclusion”. Excluding a node ID allocated by Z-WaveTM
Controller means “Remove” or “Exclusion”.

Function

Description

Add

1. Have Z-WaveTM Controller entered inclusion mode.

2. Pressing button once to enter the inclusion mode.

3. After add successful, the device will wake to
receive the setting command from Z-WaveTM
Controller about 20 seconds.

Remove

1. Have Z-WaveTM Controller entered exclusion mode.

2. Pressing button once to enter the exclusion mode.
Node ID has been excluded.

1

Reset

Notice: Use this procedure only in the event
that the primary controller is lost or
otherwise inoperable.

1. Pressing button for about 5 seconds.

2. IDs are excluded and all settings will reset to
factory default.

Association

1. Have Z-WaveTM Controller entered association
mode.

2. Pressing button one time to enter the association
mode.

Note: The device support 2 groups. The group 1 is for
receiving the report message, like triggered event,
temperature, illumination etc. The group 2 is for light
control, the device will send the “Basic Set” command
to this group. And each group support 8 nodes
maximum.

• Failed or success in add/remove the node ID can be viewed
from Z-WaveTM Controller.

Notice 1: Always RESET a Z-WaveTM device before trying to add it to a
Z-WaveTM network

Notice 2: When the device into NWI mode, the sensor functionality
will useless. The NWI mode will timeout after 30 seconds. You can
press the button one time to abort the NWI mode.

Z-WaveTM Notification

After the device adding to the network, it will wake-up once per day in
default. When it wake-up it will broadcast the “Wake Up Notification”
message to the network, and wake-up 10 seconds for receive the
setting commands.
The wake-up interval minimum setting is 30 minutes, and maximum
setting is 120 hours. And the interval step is 30 minutes.

If the user want to wake-up the device immediately, please remove the
front cover, and press the button once. The device will wake-up 10
seconds.

Z-WaveTM Message Report

When the PIR motion triggered, the device will report the trigger event
and also report the battery status.
In default the device will using Notification Report to represent the
trigger event, it can be changed to Sensor Binary Report by setting the
configuration NO. 7 Bit4 to 1.

* Motion Report:

When the PIR motion detected, the device will unsolicited to send the
report to the nodes in the group 1.

Notification Report (V4)

Notification Type: Home Security (0x07)
Event: Motion Detection, Unknown Location (0x08)

Sensor Binary Report (V2)

Sensor Type: Motion (0x0C)
Sensor Value: 0xFF

* Tamper Report:

When tamper key are pressed over 5 seconds. The device will into the
alarm state. In that state, if the tamper key is released, the device will
unsolicited to send the report to the nodes in the group 1.

Notification Report (V4)

Notification Type: Home Security (0x07)
Event: Tampering. Product covering removed (0x03)

Sensor Binary Report (V2)

2

Sensor Type: Tamper (0x08)
Sensor Value: 0xFF

* Timing Report:

Beside the event triggered could report message, the device also
support the timing unsolicited report of the status.

• Battery level report: Every 6 hours report once in default.
It could be changed by setting the configuration NO. 10.

• Low battery report: When the battery level is too low, every 30
minutes will report once.

Notice: The configuration NO. 10 could be setting to zero to disable
the auto report. And the configuration NO. 20 could change the tick
interval, the default value is 30, if setting to 1, that means the
minimum auto report interval will be one minute. And please notice if
setting this value to zero, that means disable all of the timing report
except the low battery detection.

Power Up Procedure

* Battery Power Check

When the device power up, the device will detect the power level of the
battery immediately. If the power level is too low, the LED will continue
flash about 5 seconds. Please change another new battery.

* PIR Warm Up

When the device power on, the PIR need to warm up before the
operation. The warm up time about 1 minute, the LED will flash in
every 2 seconds. After finish the procedure the LED will light ON three
times.

* NWI

When the device power on, the device will check is it already adding to
the network? If doesn't, it will auto start the NWI mode. The LED will
flash in every second and continue 30 seconds. Until timeout or the

device successful to inclusion by controller. The use can presses button
once to abort the NWI mode.

* Wake

When the device power on, the device will wake about 20 seconds. In
this duration, the controller can communicate with the device. Normally
the device is always sleeping to save the battery energy.

Security Network

The device support the security function. When the device included
with a security controller, the device will auto switch to the security
mode. In the security mode, the follow commands need using Security
CC wrapped to communicate, otherwise it will not response.
Note: A “Security Enabled Z-Wave Controller” must be used in order to
fully utilize this function.

COMMAND_CLASS_BATTERY
COMMAND_CLASS_NOTIFICATION_V4
COMMAND_CLASS_ASSOCIATION_V2
COMMAND_CLASS_CONFIGURATION
COMMAND_CLASS_SENSOR_BINARY_V2
COMMAND_CLASS_WAKE_UP_V2

Operation Mode

There are two modes “Test” and “Normal”. “Test Mode” is for the user
test the sensor function when installation.“Normal Mode” is for the
normal operation.
Operation Mode can be switched by pressing tamper key three times.
LED can indicate which mode it is. Lighting on one second means
entering test mode, flashing once means entering normal mode.

3

When the event triggered, normally the LED won't indicated, unless the
battery is in the low level, the LED will flash once. But in the “Test
Mode” the LED also will light ON one second.
When the event triggered, the device will report the messages to the
nodes in the group 1. The messages also include the battery level. The
user can switch the report by setting the configuration NO. 7 bit6
(battery).

When the event triggered, the device will emit the signal to turn ON the
lighting equipment, those nodes are in the group 2. And delay a while
to turn OFF the lighting equipment. The delay time is setting by the
configuration NO. 9.

The PIR motion re-detected interval, in the “Test Mode” fixed to 6
seconds. In the “Normal Mode”, it according to the setting of the
configuration NO. 8.

Choosing a Suitable Location

1. The recommended mounting height is 160cm

2. Don't let the device facing the window or the sunlight.

3. Don't let the device facing the source of heat. For instance the
heater or the air-condition.

Z-Wave Configuration Settings

Notice:

* All of the configuration, the data size is 1.
* The configuration mark with star(*), means after the remove the setting
still keep, don't reset to factory default. Unless the user execute the
“RESET” procedure.
* The reserve bit or not supported bit is allowed any value, but no effect.

Z-Wave Supported Command Class

COMMAND_CLASS_ZWAVEPLUS_INFO_V2
COMMAND_CLASS_BATTERY
COMMAND_CLASS_NOTIFICATION_V4
COMMAND_CLASS_ASSOCIATION_V2
COMMAND_CLASS_CONFIGURATION
COMMAND_CLASS_MANUFACTURER_SPECIFIC_V2
COMMAND_CLASS_VERSION_V2
COMMAND_CLASS_SENSOR_BINARY_V2
COMMAND_CLASS_WAKE_UP_V2
COMMAND_CLASS_ASSOCIATION_GRP_INFO
COMMAND_CLASS_POWERLEVEL
COMMAND_CLASS_DEVICE_RESET_LOCALLY
COMMAND_CLASS_MULTI_CMD
COMMAND_CLASS_SECURITY

4

NO

.

Name Def. Valid Description

2

Basic Set
Level

-1 All

Setting the BASIC command value to turn on
the light. -1(0xFF) means turn on the light.
For dimmer equipment 1 to 100 means the
light strength.
0 means turn off the light.

Caution: The range is from 0x00~0xFF
using hexadecimal notation.

3

(*)

PIR
Sensitivity

80 0 ~ 99

PIR sensitivity setting.
0 means disable the PIR motion.
1 means the lowest sensitivity,
99 means the highest sensitivity.
High sensitivity means can detected long
distance, but if there is more noise signal in
the environment, it will re-trigger too
frequency.

6

(*)

Mult­Sensor
Function
Switch

5 All

Multisensor function switch. Using bit to
control.

Caution: The range is from 0x00~0xFF
using hexadecimal notation.

0 Bit0: Reserve.

0 Bit1: Reserve.

1 Bit2: Reserve.

0 Bit3: When Bit2 is 0 (Enable), Are the device

and the lighting in the same room?
0: In the same room(Default),
1: In the different room.
Notice: If this bit is 1, it is recommended
also set the Bit1 to 1, cause the PIR
triggered, doesn't mean the people in that
room.

NO

.

Name Def. Valid Description

0

Bit4: Disable delay 5 seconds to turn off the
light, when door/window closed. (1:Disable,
0:Enable)

0

Bit5: Disable auto turn off the light, after
door/window opened to turn on the light.
(1:Disable, 0:Enable)

Notice: If bit2 is zero, this setting is useless.
Notice: If the configuration No.9 is zero,

this setting is useless.

0 Bit6: Reserve.

0 Bit7: Reserve.

7

(*)

Customer
Function 4 All

Customer function switch, using bit control.

Caution: The range is from 0x00~0xFF
using hexadecimal notation.

0 Bit0: Reserve.

0

Bit1: Enable sending motion OFF report.
(0:Disable, 1:Enable)
Note: Depends on the Bit4,
0: Report Notification CC,
Type: 0x07, Event: 0xFE
1: Sensor Binary Report,
Type: 0x0C, Value: 0x00

1

Bit2: Enable PIR super sensitivity mode.
(0:Disable, 1:Enable)

0 Bit3: Reserve.

0 Bit4: Notification Type,

0: Using Notification Report.
1: Using Sensor Binary Report.

5

NO

.

Name Def. Valid Description

0

Bit5: Disable Multi CC in auto report.
(1:Disable, 0:Enable)

0

Bit6: Disable to report battery state when
the device triggered. (1:Disable, 0:Enable)

0 Bit7: Reserve.

8

PIR Re­Detect
Interval
Time

3 1 ~ 127

In the normal mode, after the PIR motion
detected, setting the re-detect time. 8
seconds per tick, default tick is 3 (24
seconds).
Setting the suitable value to prevent received
the trigger signal too frequently. Also can
save the battery energy.
Notice: If this value bigger than the
configuration setting NO. 9. There is a period
after the light turned off and the PIR not
start detecting.

9

Turn Off
Light
Time

4 0 ~ 127

After turn on the lighting, setting the delay
time to turn off the lighting when the PIR
motion is not detected. 8 seconds per tick,
default tick is 4 (32 seconds).
0 means never send turn off light command.

10

Auto
Report
Battery
Time

12 0 ~ 127

The interval time for auto report the battery
level.
0 means turn off auto report battery.
The default value is 12. The tick time can
setting by the configuration No.20.

20

Auto Report
Tick
Interval

30 -128~127

The interval time for auto report each tick.
Setting this configuration will effect
configuration No.10.

NO

.

Name Def. Valid Description

The unit is 1 minute.
Caution1:

Setting to 0 means turn off all
auto report function.
Caution2: The range is from 0x00~0xFF
using hexadecimal notation.

Specifications

Power by CR123A lithium battery.
Signal (Frequency):

868.40 MHz, 869.85 MHz(EU),

908.40 MHz, 916.00 MHz(US),
922~927 MHz(JP/TW),

921.40 MHz, 919.80 MHz(ANZ),

869.00 MHz(RU),

865.20 MHz(IN),

916.00 MHz(IL),

Range:

Minimum 40 meters indoor,

100 meters outdoor line of sight.
Operating Temperature: -10oC ~ 40oC
For indoor use only.

Specifications subject to change without notice due to continuing
product improvement.

6

FCC Interference Statement

This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one of the following
measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from

that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for
help.

This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including
interference that may cause undesired operation.

FCC Caution: Any changes or modifications not expressly approved by
the party responsible for compliance could void the user's authority to
operate this equipment.

This transmitter must not be co-located or operating in conjunction
with any other antenna or transmitter.

Warning

Do not dispose of electrical appliances as unsorted municipal waste,
use separate collection facilities. Contact your local government for
information regarding the collection systems available. If electrical
appliances are disposed of in landfills or dumps, hazardous substances
can leak into the groundwater and get into the food chain, damaging
your health and well-being.

When replacing old appliances with new once, the retailer is legally
obligated to take back your old appliance for disposal at least for free
of charge.

7
