Operating instructions
Combair XSE | XSEP
Oven
Page 2
Thank you for choosing to buy one of our products. Your appliance is made to high
standards and is easy to use. Nevertheless, please take the time to read these operating
instructions in order to familiarise yourself with the appliance and get the best use out of
it.
Please follow the safety precautions.
Modifications
Text, diagrams and data correspond to the technical standard of the appliance at the
time these operating instructions went to press. The right to make technical modifications
for the purpose of the further development of the appliance is reserved.
Validity
The product family (model number) corresponds to the first alphanumerics on the identification plate. These operating instructions apply to:
Type Product family Size system
BCXSE60 21017 60-450
BCXSEP60 21027 60-450
Variations depending on the model are noted in the text.
Colour operating instructions can be downloaded from the internet from www.vzug.com.
© V-ZUG Ltd, CH-6301 Zug, 2017
2
Page 3
3
Table of contents
1 Safety precautions 5
1.1 Symbols used......................................................... 5
1.2 General safety precautions.................................. 5
1.3 Appliance-specific safety precautions .............. 6
1.4 Instructions for use................................................ 7
2 Using for the first time 9
3 Appliance description 10
3.1 Construction .........................................................10
3.2 Operating and display elements.......................10
3.3 Cooking space.....................................................11
3.4 Accessories ..........................................................11
3.5 Plate warmer.........................................................12
4 Operating modes 12
4.1 Overview of operating modes ........................... 12
4.2 Top/Bottom heat.................................................. 13
4.3 Hot air ....................................................................13
4.4 PizzaPlus ...............................................................13
4.5 Grill .........................................................................14
4.6 Grill-forced convection........................................14
4.7 Top/Bottom heat humid .....................................14
4.8 Hot air humid........................................................15
4.9 Bottom heat ..........................................................15
4.10 Fast heating .......................................................... 15
5 Using the appliance 16
5.1 Selecting and starting the operating mode ....16
5.2 Checking and changing the settings...............17
5.3 Setting a duration ................................................17
5.4 Setting a delayed start / end time.................... 17
5.5 Food probe temperature .................................... 18
5.6 Cancelling/ending the operating mode before
time.........................................................................19
5.7 Changing the operating mode ..........................19
5.8 Timer ......................................................................20
5.9 End of operation ..................................................21
5.10 Switching the appliance off................................21
6 GourmetGuide 22
6.1 Recipe book ..........................................................22
6.2 Own recipes...........................................................23
6.3 Soft roasting...........................................................26
6.4 Keep warm *..........................................................28
7 EasyCook 28
7.1 Overview of food groups.....................................28
7.2 Selecting and starting foods...............................28
8 Favourites 29
8.1 Creating favourites ...............................................29
8.2 Selecting and starting favourites .......................29
8.3 Changing favourites .............................................29
8.4 Deleting favourites................................................30
9 Tips and tricks 30
9.1 Unsatisfactory cooking result... ..........................30
9.2 Saving energy........................................................31
10 User settings 31
10.1 Overview of user settings....................................31
10.2 Adjusting user settings ........................................31
10.3 Language ...............................................................31
10.4 Display ....................................................................32
10.5 Date.........................................................................32
10.6 Clock .......................................................................32
10.7 Notifications ...........................................................33
10.8 Pyrolytic cleaning of appliance ..........................33
10.9 Loudness................................................................33
10.10 Assistance functions ............................................33
10.11 Temperature ..........................................................34
10.12 Childproof lock......................................................34
10.13 Appliance information ..........................................34
10.14 Demo mode...........................................................34
10.15 Factory settings.....................................................34
11 Care and maintenance 34
11.1 Cleaning the exterior............................................35
11.2 Cleaning the cooking space...............................35
11.3 Cleaning the appliance door ..............................35
11.4 Cleaning the door seal ........................................36
Page 4
4
11.5 Replacing the door seal .....................................36
11.6 Replacing the door seal on pyrolysis appliances
37
11.7 Replacing the halogen light bulb .....................37
11.8 Cleaning the accessories and shelf guides ...38
11.9 Pyrolytic self-cleaning .........................................38
12 Trouble-shooting 40
12.1 What to do if ….....................................................40
12.2 After a power failure............................................ 42
13 Accessories and spare parts 43
13.1 Accessories ..........................................................43
13.2 Special accessories ............................................44
13.3 Spare parts ...........................................................44
14 Technical data 44
14.1 Note for testing institutes ...................................44
14.2 Temperature measurement ...............................45
14.3 Product fiche ........................................................45
14.4 EcoStandby...........................................................45
14.5 Reference to «Open Source» licence..............46
15 Disposal 46
16 Index 47
17 Notes 49
18 Service & Support 51
Page 5
5
1 Safety precautions
1.1 Symbols used
Denotes important safety precautions.
Failure to observe said precautions
can result in injury or in damage to
the appliance or fittings!
Information and precautions that
should be observed.
Information on disposal
Information about the operating instructions
▸ Indicates step-by-step instructions.
– Describes how the appliance reacts
to the steps taken.
▪ Indicates a list.
1.2 General safety precautions
▪ Read the operating instruc-
tions before using the appliance for the first time!
▪ This appliance can be used
by children aged 8 and above
and by persons with reduced
physical, sensory or mental
capabilities, or lack of experience and/or knowledge,
provided they are supervised
or have been instructed on
the safe use of the appliance
and have understood the hazards involved. Children shall
not play with the appliance.
Cleaning and user maintenance shall not be undertaken
by children without supervision.
▪ If an appliance is not
equipped with a mains cable
and a plug or other means for
disconnecting from the mains
with a contact opening on
each pole complying with the
conditions of overvoltage category III for full isolation, an
isolating device must be incorporated into the perman-
Page 6
1 Safety precautions
6
ently installed electrical installation in accordance with the
installation regulations.
▪ If the mains cable of this ap-
pliance is damaged, it must
be replaced by the manufacturer or its Customer Services
or a similarly qualified person
in order to avoid hazard.
1.3 Appliance-specific safety
precautions
▪ READ THE IMPORTANT
SAFETY PRECAUTIONS
CAREFULLY AND RETAIN
FOR FUTURE USE.
▪ WARNING: The appliance
and its accessible parts get
hot during use. Be careful not
to touch the heating elements. Children under 8
years of age must be kept
away from the appliance unless they are constantly supervised.
▪ WARNING: Accessible parts
can get hot during use. Keep
young children away from the
appliance.
▪ This appliance is intended for
use in the home and similar
settings such as: in staff kitchens in shops, offices and
other commercial establishments; in agricultural estab-
lishments; by guests in hotels,
motels and other accommodation establishments; in bed
and breakfast establishments.
▪ A heatable appliance drawer
and its contents get hot.
▪ Do not use aggressive or ab-
rasive cleaning agents or
sharp metal scrapers for
cleaning the glass in the oven
door as they could scratch
the surface. This can destroy
the glass.
▪ For appliances with pyrolytic
self-cleaning: Excessive soiling and any and all accessories (tableware, baking trays,
runners, shelf guides) must
be removed before carrying
out pyrolytic self-cleaning.
▪ Only use the food probe re-
commended for this oven.
▪ Under no circumstances use
a steam cleaner to clean the
appliance.
▪ WARNING: Before replacing
the light bulb, ensure the appliance is switched off and
disconnected from the mains
power supply to avoid possible electric shock.
▪ To avoid overheating, the ap-
pliance must not be installed
behind a decor door.
▪ This appliance is not intended
for use in vehicles or on
board ships or aircraft or in
Page 7
1 Safety precautions
7
rooms where there are special conditions such as, for instance, a corrosive or explosive atmosphere (dust, steam
or gas) or condensing moisture.
▪ WARNING: Never heat food
or liquids in sealed containers
such as cans or bottles as
they are liable to explode due
to overpressure.
▪ See the «Accessories» sec-
tion for the proper use of insertable parts.
1.4 Instructions for use
Before using for the first time
▪ The appliance must be installed and
connected to the electricity supply in
accordance with the separate installation instructions. Have a qualified fitter/
electrician carry out the necessary
work.
Correct use
▪ The appliance is designed for use in
the home for preparing food. Under no
circumstances flambé or cook food using a lot of fat in the cooking space! No
liability is assumed for any damage
caused by improper use or incorrect
handling.
▪ Never use the appliance to dry animals,
textiles or paper, etc.
▪ Do not use the appliance as a room
heater.
▪ The appliance should only be installed
and operated at an ambient temperature of 5 °C to 35 °C.
▪ Any repairs, modifications or manipula-
tions to the appliance, especially any
electrically live parts, may only be carried out by the manufacturer, its Customer Services or a similarly qualified
person. Repairs if carried out incorrectly
may cause serious injury, damage to
the appliance and fittings, as well as affect the functioning of the appliance. If
the appliance is not working properly or
in case of a repair order, follow the instructions given in the «Service & Support» section. Please contact our Customer Services if necessary.
▪ Use original spare parts only.
▪ Retain these operating instructions for
future reference.
▪ The appliance corresponds to recog-
nized technology standards and the relevant safety regulations. Proper use of
the appliance is essential to avoid damage and accidents. Please therefore follow the precautions given in these operating instructions.
Note on use
▪ Use the childproof locking facility.
▪ If the appliance is visibly damaged, do
not use it. Contact our Customer Services.
▪ If the appliance is not operating prop-
erly, disconnect it from the power supply immediately.
▪ Ensure there are no foreign bodies or
pets in the cooking space before closing the appliance door.
▪ Objects that could pose a danger if the
appliance were accidentally switched
on should not be stored in the cooking
space or the heatable appliance
drawer. Do not store food or any temperature-sensitive or inflammable materials, e.g. cleaning agents, oven sprays,
etc., in the cooking space or the heatable appliance drawer.
▪ For appliances with grill: Leave the ap-
pliance door closed when grilling. The
heat could otherwise damage the operating and display elements or the fitted
units above.
Page 8
1 Safety precautions
8
Caution: Risk of burns!
▪ The appliance gets very hot when in
use. The appliance door also gets hot.
▪ Steam and/or hot air may escape from
the cooking space when the appliance
door is opened.
▪ The appliance will remain hot for some
time after it is switched off and will only
cool down slowly to room temperature.
Allow sufficient time for the appliance to
cool down before, for instance, cleaning
it.
▪ Overheated fat and oil can easily catch
fire. Heating oil in the cooking space to
sear meat is dangerous and should not
be done. Never attempt to extinguish
burning oil or fat with water. Danger of
explosion! Smother the flames with a
fire blanket. Keep doors and windows
closed.
▪ Do not pour spirits (brandy, whisky,
schnapps, etc.) over hot food. Danger
of explosion!
▪ Do not leave the appliance unattended
when drying herbs, bread, mushrooms,
etc. If the foodstuff dries out too much,
it can pose a fire hazard.
▪ If you notice smoke possibly coming
from the appliance itself or from inside
the cooking space, keep the appliance
door closed. Disconnect the appliance
from the power supply.
▪ Accessories get hot in the cooking
space. Use protective gloves or oven
cloths.
Caution: Risk of injury!
▪ Be careful not to put fingers in the door
hinges, there is otherwise a risk of injury if the appliance door is moved. Particular care should be taken when children are around.
▪ Only leave the appliance door open in
the at-rest position. An open appliance
door poses a danger of tripping or injury! Do not sit or rest on the appliance
door or use it as a storage surface.
▪ For hobs: A hob guard can be fitted to
protect small children. Hob guards are
available from specialist retailers.
Caution: Risk to life!
▪ Danger of suffocation! Keep packaging
material, e.g. plastic film and polystyrene, away from children. Packaging
material can be dangerous for children.
How to avoid damaging the appliance
▪ Close the appliance door carefully.
▪ For appliances with visible bottom heat-
ing element: Do not place any objects
directly on the bottom heating element.
▪ Do not use protective aluminium inserts
with appliances with no visible bottom
heating element.
▪ Do not use objects that can rust in the
cooking space.
▪ Using knives or cutting wheels on the
baking tray will visibly damage the surface.
▪ To prevent corrosion, leave the appli-
ance door open in the at-rest position
until the cooking space has cooled
down.
▪ When cleaning the appliance, make
sure no water gets inside it. Use a moderately damp cloth. Do not spray the
outside or the inside of the appliance
with water. If water gets inside the appliance, it will cause damage.
Page 9
2 Using for the first time
Before operating the newly installed appliance for the first time, the following steps
should be taken:
▸ Remove packaging and transport materials as well as any protective blue film from
out of the cooking space.
▸ Clean the cooking space and the accessories.
▸ Press the power button.
– The appliance switches on.
Version 1 *
* Depending on the software version
– Various user settings necessary for operation, such as language, time and temper-
ature unit, appear in the display one after the other.
▸ Make the settings and confirm.
Language and time must be set so that the appliance can be operated.
Version 2 *
* Depending on the software version
▸ Set the time (see page 32).
Completing the initial set-up
▸ Heat the empty cooking space (without wire shelves, baking trays, etc.) using the
operating mode at 230°C for about 30minutes.
As there is likely to be some smoke and odour given off, we recommend ventilating the room well during this phase.
All temperatures in these operating instructions are in degrees Celsius. Apply the
corresponding conversions via the user setting «Degrees Fahrenheit» (see page
34).
9
Page 10
3 Appliance description
3 Appliance description
3.1 Construction
1
3
4
2
1
Operating and display elements
2
Ventilation opening
3
Door handle
4
Appliance door
3.2 Operating and display elements
12:00
7RSERWWRPKHDW
곋2SHUDWLQJPRGHV
2 3
4
1
5
1
Display
4
Action buttons
2
Digital display
(duration/timer/time)
5
Adjusting knob / switching on
appliance
3
Menu buttons
Overview of touch buttons
Operating modes
GourmetGuide
EasyCook
User settings
Favourites
Plate warmer
Timer
Cooking space illumination
Switching off
10
Page 11
3 Appliance description
3.3 Cooking space
Using protective inserts or aluminium foil can damage the appliance.
Do not place any protective insert or aluminium foil on the floor of the cooking
space.
6
7
8
1
3
1
2
3
4
5
2
1
Appliance door
5
Cooking space ventilation
2
Door seal
6
Temperature sensor
3
Hot air blower
7
Grill/top heat
4
Cooking space illumination
8
Levels (labelled)
The bottom heating element is beneath the cooking space floor.
3.4 Accessories
Incorrect handling can cause damage!
Do not use knives or cutting wheels on the accessories.
TopClean baking tray
▪ Baking tin for flans and biscuits
▪ Use together with the wire shelf as a drip tray
▪ If not fully covered, its shape can become distorted dur-
ing baking. This is normal. It will go back to its original
form as it cools down.
1
▸ Ensure that the «sloped» side 1 of the baking tray is to
the back of the cooking space.
▸ Only use the normal way round – not upside down.
Wire shelf
1
▪ For standing roasting and baking tins on
▪ For standing meat, frozen pizza, etc. on
▸ Ensure that the cross strut 1 is to the back of the cook-
ing space. It enables the food to be removed safely
from the cooking space.
11
Page 12
4 Operating modes
▪ Serves as a cooling rack
If you use your oven in combination with a Combi-Steam XSL or XSLF:
Do not use the wire rack from the oven in the combi-steam cooker. Risk of corrosion.
To differentiate between the two, the wire shelf from the combi-steam cooker is fitted with a badge with a steam symbol.
Food probe
▪ For measuring the core temperature of food
For recommended food probe temperatures, see «EasyCook».
Not suitable for temperatures of over 230°C. There must be a distance between
the food probe and the roof of the cooking space of at least 5cm.
Special accessories
Place any accessories not included in the scope of delivery on the wire shelf.
▸ Special accessories can be found at: www.vzug.com
3.5 Plate warmer
▸ If the appliance is switched off, first press the adjusting knob.
▸ Put the wire shelf at level 1 and place the tableware on it.
▸ Press the touch button.
▸ Set the required duration.
Select a duration of at least 1 hour.
▸ Set the end time if necessary.
▸ Switch on the «Plate warmer» by selecting .
– The «Plate warmer» switches off automatically when the set duration is over.
4 Operating modes
4.1 Overview of operating modes
All the operating modes and fast heating are described below.
Follow the advice given in «Tips and tricks» (see page 30) and in «EasyCook».
12
Page 13
4 Operating modes
4.2 Top/Bottom heat
Temperature range 30–280 °C
Recommended value 200 °C
Level 1 or 2
The cooking space is heated by the top and bottom heating elements.
Uses
▪ Classic operating mode for cooking and baking on one level
▪ Cakes, biscuits, bread and roasts
Use a dark enamelled tray or a black tray or tin for crispy results.
4.3 Hot air
Temperature range 30–250 °C
Recommended value 180 °C
Level 2 or 1 + 3
A heating element behind the back wall of the cooking space heats up the air inside the
cooking space, which is circulated evenly.
Uses
▪ Particularly suitable for baking savouries and biscuits on several levels at the same
time
▪ Cakes, bread and roasts
Select a lower temperature (reduce by approximately 20°C) than for as the
heat transfer is more efficient.
4.4 PizzaPlus
Temperature range 30–250 °C
Recommended value 200 °C
Level 2 (or 1)
The cooking space is heated by hot air and bottom heat. The base of the food is baked
particularly intensively.
Uses
▪ Pizza
▪ Flans and quiches
13
Page 14
4 Operating modes
Use a dark enamelled tray or a black tray or tin without baking paper for very
crispy results.
4.5 Grill
Temperature range 5 levels
Recommended value Level 3
Level 3
The cooking space is heated by the grill element.
Uses
▪ Flat food for grilling, e.g. steaks, chops, chicken parts, fish and sausages
▪ Gratinating
▪ Toast
▸ Place the food to be grilled directly on the wire shelf.
▸ Line the baking tray with aluminium foil and then place it underneath the wire shelf.
For best results, preheat the cooking space for 3 minutes before introducing the
food.
4.6 Grill-forced convection
Temperature range 30–250 °C
Recommended value 200 °C
Level 2 or 3
The cooking space is heated by the grill element. The hot air fan distributes the air
evenly in the cooking space.
Uses
▪ Suitable for a whole chicken
▪ Large, bulky food for grilling
▸ Put food for grilling in a porcelain or glass dish or directly on the wire shelf.
▸ Line the baking tray with aluminium foil and then place it underneath the wire shelf.
4.7 Top/Bottom heat humid
Temperature range 30–250 °C
Recommended value 200 °C
Level 1 or 2
The cooking space is heated by the top and bottom heating elements. The steam produced is largely retained in the cooking space. The food retains its moisture.
14
Page 15
4 Operating modes
Uses
▪ Bread, plaited bread, roasts and gratins on one level
▪ Low temperature cooking
4.8 Hot air humid
Temperature range 30–250 °C
Recommended value 180 °C
Level 1 + 3 or 2
A heating element behind the back wall of the cooking space heats up the air inside the
cooking space, which is circulated evenly. The steam produced is largely retained in the
cooking space. The food retains its moisture.
Uses
▪ For savouries and biscuits on two levels at the same time
▪ For yeast pastries and bread on two levels at the same time
▪ Gratins and baked dishes
Select a lower temperature (reduce by approximately 20°C) than for as the
heat transfer is more efficient.
4.9 Bottom heat
Temperature range 6 levels
Recommended value Level 3
Level 2 (or 1)
The cooking space is heated by the bottom heating element.
Uses
▪ Baking flan bases
▪ Making preserves
Use a dark enamelled tray or a black tray or tin for crispy results.
4.10 Fast heating
For fast heating , the cooking space is heated using hot air and bottom heat, which
shortens the preheating time. Fast heating can be used with the following operating
modes: and .
▸ Select the desired operating mode and adjust the settings.
▸ To start the operating mode, select .
▸ Select «Switch fast heating on» in the settings for the operating mode.
– Above , the symbol illuminates.
As soon as an acoustic signal is emitted:
– put the food into the cooking space.
15
Page 16
5 Using the appliance
5 Using the appliance
The different main menus and functions are selected by pressing the corresponding
touch button. Selected touch buttons and functions are illuminated in white; other selectable functions are illuminated in orange.
Settings and functions that cannot be selected or changed are greyed out in the various
menus.
The following touch buttons with the following main menus and functions are available:
Operating modes
GourmetGuide
EasyCook
User settings
Favourites
Plate warmer
Timer
Cooking space illumination
Switching off
Adjusting knob functions
Press ▪ Switching on the appliance
▪ Selecting/opening a submenu, setting, etc.
▪ Confirming/closing a message
▪ Activating/deactivating a user setting
Turn ▪ Navigating within the submenus
▪ Changing/setting a value, user setting
5.1 Selecting and starting the operating mode
▸ If the appliance is switched off: first press the adjusting knob.
▸ If the appliance is in another menu: press the touch button.
– The selection of operating modes appears in the display.
▸ Select the operating mode.
– The operating mode settings appear in the display; a recommended value appears
above the temperature.
▸ Set the values for duration, end time, temperature or temperature level and target tem-
perature as required and confirm.
Press and go
Once all the necessary settings for the operating mode have been made, a bar appears
in the display and counts down 20seconds. If no further settings are made during this
time, operation starts automatically. If a setting is changed, Press and go starts again.
The duration of Press and go can be adjusted (see page 33) or it can be deactivated in the user settings.
16
Page 17
5 Using the appliance
▸ To start operation immediately, i.e. without Press and go, select .
– If set, the countdown to the time remaining appears in the display and in the digital
display.
The operating mode selected cannot be changed once it has started.
Display overview
곍6HWWHPSHUDWXUH
굴굵굶
K
3
1
2
4
6
5
1
Operating mode settings
2
Press and go
3
Operating mode with symbol
4
Current position of the adjusting knob /
selected setting
5
Set values / recommended values
6
Symbols for settings
5.2 Checking and changing the settings
▸ Select the symbol for the desired setting.
▸ To change the value, turn the adjusting knob to the right or left.
▸ Press the adjusting knob to confirm the setting.
– The operating mode settings are displayed.
– The changed value can be seen above the corresponding symbol.
The end time can only be changed during the first 60seconds of
operation.
5.3 Setting a duration
The operating mode selected ends automatically when the operating time is up.
▸ Select the desired operating mode.
▸ Select in the operating mode settings.
▸ Set the desired duration – max. 9 hours and 59 minutes – and confirm.
– The duration is displayed in the operating mode settings as well as the end time
which is calculated based on this value.
– End of operation / duration finished (see page 21)
5.4 Setting a delayed start / end time
The delayed start is activated when for the operating mode selected both the duration
and the end time are set.
The appliance switches automatically on and off again at the desired times.
If you use the food probe, you will need to estimate and set the duration. You will find a
guide on times in «EasyCook». The appliance switches on with a delay and switches off
again when the set target temperature is reached. Depending on the estimated duration,
this can occur earlier or later than the set end time.
Perishables should not be kept unrefrigerated.
17
Page 18
5 Using the appliance
Before setting the delayed start
▸ Place the food in the cooking space.
▸ Select the desired operating mode.
▸ Set the temperature.
▸ Set the duration.
Setting a delayed start
▸ Select in the operating mode settings.
– The current end time calculated using the duration is displayed.
▸ Set the desired end and confirm.
– The time remaining to the start of operation is displayed.
– After 3 minutes, the display goes out and the touch button is illuminated in
white. The display can be called up again at any time by pressing the adjusting
knob.
– The appliance remains switched off until 3 minutes before the automatic start of op-
eration.
▸ Check and change the settings (see page 17).
Example
▸ Select the operating mode and 180°C.
▸ At 8:00, set a duration of 1hour and 15minutes.
▸ Set the end time to 11:30.
– The appliance will automatically switch on at 10:15 and off again at 11:30.
5.5 Food probe temperature
Only use the supplied food probe.
Do not clean the food probe in the dishwasher. Always keep the plug clean.
The food probe is used to measure the temperature inside the food (referred to as the
food probe temperature). As soon as the food reaches the target temperature (the food
probe temperature that should be attained at the end of the cooking process), operation
stops automatically. It is also possible to simply measure the food probe temperature
without stopping operation.
The food probe must be inserted as far into the middle of the meat as possible to
get a correct reading of the food probe temperature.
The optimal target temperature is dependent on the cut of meat and on the degree
of doneness.
Refer to the information on target temperatures in «EasyCook».
Setting
▸ Select the desired operating mode and set the temperature.
▸ Select in the operating mode settings.
▸ Set the desired target temperature and confirm.
▸ To start operation, select .
Operation can only be started when the food probe is plugged in.
18
Page 19
5 Using the appliance
▸ Check and change the settings (see page 17).
– The current food probe temperature is shown in the top part of the display when
cooking.
– The set target temperature is displayed above .
– Operation ends automatically once the target temperature has been reached – see
also End of operation (see page 21).
If the meat is left in the cooking space after having switched off the appliance, the
food probe temperature will continue to rise due to the residual heat.
Measuring the food probe temperature
If you only wish to measure the food probe temperature without operation stopping automatically when the target temperature is reached, proceed as follows:
▸ Select the desired operating mode and set the temperature and, if you wish, the dura-
tion.
▸ Plug in the food probe.
▸ Start the operating mode.
– As soon as the cooking space has reached the desired temperature, the current
food probe temperature is shown in the top part of the display when cooking.
5.6 Cancelling/ending the operating mode before time
▸ In the operating mode settings, select or press the touch button.
– An acoustic signal is emitted.
– The selected operating mode is cancelled.
– The following appears in the display: « Residual heat» and, for example: « Hot
air cancelled».
– If the food probe is plugged in, the food probe temperature is displayed. *
* Depending on the software version
▸ If you wish to start a new operating mode, press the touch button.
▸ If you wish to switch off the appliance, press the touch button.
5.7 Changing the operating mode
If no operating mode is running:
▸ Select in the settings of the current operating mode.
– The operating modes menu is displayed.
If an operating mode is already running:
▸ Select or press the touch button.
– The set operating mode is cancelled.
▸ Press the touch button and select a new operating mode.
19
Page 20
5 Using the appliance
5.8 Timer
The timer functions like an egg timer. It can be used at any time and independently of all
other functions.
Setting and starting the timer
▸ Press the touch button.
– A suggested value of «10min» appears in the display.
▸ Turn the adjusting knob and set the desired duration.
– The duration and the end time for the timer appear in the display.
The timer can be set for:
▪ up to 10minutes in 10-second intervals, e.g. = 9minutes and 50seconds;
▪ over 10 minutes in 1-minute intervals, e.g. = 1hour and 12minutes;
▪ over 10 hours in 1-hour intervals, e.g. = 18hours.
The maximum timer duration is 99 hours.
▸ Press the adjusting knob to confirm.
– The timer starts.
– If there is no operating mode running with a set duration, the remaining time on the
timer will be displayed in the digital display.
– The touch button is illuminated in white.
– If the appliance was in another menu before the timer was set, e.g. operating
modes: the menu or the submenu selected within it, e.g. a running operating mode,
appears.
– If the appliance was not in another menu: the display goes black.
Checking and changing
▸ Press the touch button.
– The countdown to the time remaining appears in the display.
▸ Shorten or extend the time by turning the adjusting knob.
▸ Confirm this shortening or extending of the time.
When the timer finishes
When the set duration is up:
– An acoustic signal is emitted.
– «Timer finished» appears in the display.
▸ To close the message, select .
Switching the timer off before time
▸ Press the touch button.
– The countdown to the time remaining appears in the display.
▸ Set the timer to 0 by turning the adjusting knob and confirm.
Or, if the timer is the only active function:
▸ Press the touch button.
Or, to switch off the appliance:
▸ Press the touch button 2×.
20
Page 21
5 Using the appliance
5.9 End of operation
When the set duration is up or, if the food probe is being used, when the set target temperature is reached:
– The selected operating mode ends automatically.
– An acoustic signal is emitted.
– Three options are displayed:
▪ Select to choose a new operating mode
▪ Select to extend the operation
▪ Select to switch the appliance off.
– The appliance switches off automatically after 3 minutes without interaction.
You can adjust the appliance end time individually (see page 32).
– As long as the temperature is above 80°C, « Residual heat» appears in the dis-
play.
– If the food probe is plugged in, the food probe temperature is displayed. *
The food can be kept warm with residual heat for some time. As soon as the temperature falls below 80 °C, all the displays go out. If at this point the food probe is
still plugged in, the displays only go out when the food probe is unplugged. *
The cooling fan can continue to run.
* Depending on the software version
Removing food from cooking space
Risk of burns!
Hot air may escape from the cooking space when the appliance door is opened.
The accessories get hot. Use protective gloves or oven cloths.
▸ Take the food out of the cooking space when done.
▸ Wipe away traces of water or soiling with a soft cloth to prevent corrosion and un-
pleasant odours.
▸ Leave the appliance door open in the at-rest position until the cooking space has
cooled down and dried out.
5.10 Switching the appliance off
▸ Press the touch button.
– An acoustic signal is emitted.
– Any running operating mode or application is ended; if switched on, the timer,
cooking space illumination or plate warmer will remain active.
– « Residual heat» appears in the display.
– If the food probe is plugged in, the food probe temperature is displayed. *
* Depending on the software version
▸ Press the touch button again.
– All touch buttons go out.
– All functions are ended and switched off.
21
Page 22
6 GourmetGuide
Or at the end of operation:
▸ Select the option in the display.
– An acoustic signal is emitted.
– Any running operating mode or application is ended; if switched on, the timer,
cooking space illumination or plate warmer will remain active.
– The following appears in the display: « Residual heat».
– If the food probe is plugged in, the food probe temperature is displayed. *
* Depending on the software version
▸ Press the touch button.
– All touch buttons go out.
– All functions are ended and switched off.
The appliance is switched off if none of the touch buttons are illuminated any more
and the display is dark.
The cooling fan can continue to run.
6 GourmetGuide
The GourmetGuide encompasses several programmes which make preparing meals
as easy as possible for you. The following programmes can be called up:
Recipes Keep warm *
Soft roasting
* Depending on the software version
6.1 Recipe book
A recipe book contains recipes which are tailored to suit the particular appliance. These
are already programmed into the appliance and run automatically once started.
The «Recipe book» function allows you to cook by following a recipe. To use this function, you must first order the recipe book (subject to charge) before you are able to activate it in the appliance.
The following recipe books are available for your appliance:
▪ Baking treats
Unlocking a recipe book
When you buy a recipe book, you receive a password which is used to unlock the recipe
book in the appliance. After it has been unlocked, the recipes are displayed in the appliance.
▸ If the appliance is switched off, first press the adjusting knob.
▸ Press the touch button.
▸ Select .
▸ Select the recipe book that you wish to unlock.
– The following appears in the display: «Do you want to unlock the recipe book?».
▸ Select «Yes».
▸ Enter the password using the on-screen keypad and confirm by selecting .
– The recipe book is now unlocked.
22
Page 23
6 GourmetGuide
Starting a recipe
For recipes that do not require preheating, place the food in the cold cooking
space.
▸ If the appliance is switched off, first press the adjusting knob.
▸ Press the touch button.
▸ Select .
▸ Select the desired recipe book or «Own recipes».
▸ To select a recipe, choose .
▸ Select a recipe.
– The recipe settings are displayed.
▸ If you wish, set the end time or delayed start.
When cooking recipes from recipe books, a delayed start is only possible if the
cooking space does not need to be preheated and the food does not need to be
stirred or turned partway through, for example.
▸ To start the recipe, select .
– The recipe starts.
– The display shows the current recipe step, the time remaining in this step and the
entire duration of the recipe.
– The digital display shows the remaining time for the current recipe step.
In the course of the recipe
In the course of the recipe, it may be necessary to open the appliance door, e.g. to turn
over the food or to spread a topping over it. In such an instance, operation is paused
and the display shows instructions on what to do next.
To continue the recipe, proceed as follows:
▸ Open the appliance door.
▸ Carry out the action, e.g. turn over food.
▸ Close appliance door and select in the display.
– The recipe will continue to run.
Cancelling the recipe
▸ In the recipe settings, select .
– The following appears in the display: «Should the current recipe be cancelled?»
▸ To abort the recipe, select «Yes».
– The recipe is cancelled.
6.2 Own recipes
Up to 24 of your own favourite recipes can be created and saved. A recipe can consist
of several steps with any operating modes, pauses and hold times, which run automatically once started. You can also change and save existing recipes.
Creating your own recipe
▸ If the appliance is switched off: first press the adjusting knob.
▸ Press the touch button.
▸ Select .
▸ Select .
23
Page 24
6 GourmetGuide
▸ To create a new recipe, select .
– The selection of operating modes appears in the display.
▸ Select the desired operating mode.
▸ Set the target temperature, duration, temperature or temperature level for step1.
If you are only making temperature settings, this step takes as long as is necessary for the cooking space to reach the required temperature.
▸ To confirm the settings, select .
▸ To add a new step, select .
▸ Set an operating mode, pause or hold time for step 2.
For the intermediate step «Hold», the heating continues to run and the cooking
space temperature remains constant. For the intermediate step «Pause», the
cooking space is not heated any more and the temperature drops.
After a hold or pause step, a preheating stage can be set.
▸ To save the settings, select .
– The overview of the set steps is displayed.
▸ Set additional steps in the same way. A recipe can consist of up to 9 steps.
▸ To save the recipe, select .
– The overview of the available storage spaces is displayed.
▸ Select the desired (empty) storage space and confirm.
▸ Enter the recipe name using the on-screen keypad and confirm by pressing .
– The recipe is now saved.
– The following appears in the display: «Do you want to run the recipe?» If you do not
wish to run the recipe, you will return to the recipes main menu.
Step duration
The duration of a step depends on whether values have been set for the target temperature, duration, temperature or temperature level. If multiple values have been set, e.g. the
duration and the temperature, only one of these takes priority for the step duration.
The table below shows the priorities in descending order:
Setting
1 Target temperature
2 Duration
3 Temperature / temperature level
Cancelling recipe entry/change
▸ Select in the overview of the set steps.
– The following appears in the display: «Do you really want to cancel the recipe
entry?»
▸ To cancel the recipe entry, select «Yes».
– The menu for your own recipes or, if a recipe from a recipe book was changed, the
menu for the recipe book is displayed.
Ending a step before time
This is only possible for «Own recipes». If, for example when a recipe is running, you
realize that the food or the cooking space is ready for the next step in the recipe even
though the current step is still in progress, you can end the step before time.
24
Page 25
6 GourmetGuide
▸ Select the symbol for target temperature, duration, temperature or temperature level in
the operating mode settings. Pay attention to the priorities for the step duration as de-
scribed under «Step duration».
▸ Set the displayed value to 0 or reduce it until it is less than the currently measured
value.
▸ Press the adjusting knob to confirm.
– The step is ended.
– If it was the final step, the recipe ends too.
– If it was not the final step, the next step starts.
Changing recipes
Any recipe – from a recipe book as well as your own recipes – can be copied and
changed.
▸ Select the desired recipe book or .
▸ Select .
▸ Choose a recipe.
– An overview of the steps in the recipe is displayed.
Changing a step
▸ Select the step to be changed.
▸ Make the settings and confirm with .
Adding a step
▸ Select .
▸ Make the settings and confirm with .
Deleting a step
▸ Select .
– An overview of the steps in the recipe is displayed.
▸ Select the step.
– The following appears in the display: «Do you want to delete this step?»
▸ To delete the step, select «Yes».
– The step is deleted.
Saving a changed recipe
▸ Select .
▸ Select storage space, enter the recipe name and confirm by pressing .
– The changed recipe is now saved.
A storage space that is already being used can be overwritten.
Recipes that have been amended from recipe books are not saved in the recipe
book, but under «Own recipes». The original recipe remains in the corresponding recipe book.
Deleting your own recipe
Any recipe in «Own recipes» can be deleted.
▸ Select «Own recipes».
▸ Select .
▸ Select the recipe to be deleted.
– The following appears in the display: «Do you want to delete this recipe?»
25
Page 26
6 GourmetGuide
▸ To delete the recipe, select «Yes».
– The recipe is deleted.
6.3 Soft roasting
How it functions
The soft roasting function allows high-quality cuts of meat to be prepared gently. You
can select exactly when the cooking process is complete, irrespective of the weight and
thickness of the meat. The temperature is automatically regulated.
Tips for an optimal result
▪ Take the meat out of the refrigerator some 30–60 minutes before soft roasting.
▪ Weight of meat: 500–2000g
▪ Meat thickness: at least 4cm
▪ Quality: lean, high-quality meat
Soft roasting table for «Soft roasting seared»
Cut of meat Degree of doneness Recommended target
temperature°C
Fillet of veal rare
medium
58
62
Rump or loin of veal medium 63
Shoulder of veal medium 72
Neck of veal medium 78
Fillet of beef rare
medium
53
57
Rib-eye or sirloin rare
medium
53
57
Rump of beef medium 63
Chuck of beef medium 68
Shoulder of beef medium 72
Rump or loin of pork medium 65
Neck of pork medium 80
Leg of lamb rare
medium
63
67
Freely select meat type – 70
«Soft roasting seared»
▸ Season or marinate the meat.
Remove any marinade made with herbs, mustard, etc. from the meat before searing. These ingredients burn easily.
▸ Salt the meat immediately before searing.
▸ Briefly sear the meat all over for no longer than 5minutes.
▸ Then place the meat in a glass or porcelain roasting dish.
26
Page 27
6 GourmetGuide
If you do not intend to sear the meat until after the soft roasting, lower the recommended target temperature by around 3–4°C.
▸ Insert the food probe into the meat so that the tip is in the centre of the thickest part.
The food probe must be inserted as far into the middle of the meat as possible to
get a correct reading of the food probe temperature. The temperature inside the
meat is crucial for optimal results at the end of cooking.
▸ Put the wire shelf at level 2 and place the dish on it.
▸ Insert the food probe plug into the socket.
▸ Start «Soft roasting seared» (see page 27).
Selecting and starting soft roasting
The longer the meat is cooked, the more tender and succulent it becomes. This
applies particularly for thicker pieces of meat.
The target temperature cannot be changed once soft roasting has started.
▸ If the appliance is switched off, first press the adjusting knob.
▸ Press the touch button.
▸ Select .
▸ Select the desired soft roasting method.
▸ Select the desired type of meat.
▸ Select the desired cut.
▸ If the desired type of meat or cut cannot be selected, select the «Freely se-
lect meat type» option.
▸ Select the degree of doneness (not possible for «Freely select meat type»).
– The operating mode settings are displayed.
– A recommended value appears above the target temperature.
▸ Adjust the recommended value if necessary and set a delayed start if you wish.
▸ To start soft roasting, select .
The food probe must be plugged in.
– Soft roasting starts.
– The set target temperature, the current food probe temperature and the remaining
time are displayed.
– The remaining time appears in the digital display.
The appliance door must be closed during operation. If the appliance door is
opened while soft roasting is running, the operation is interrupted and then, after a
short time, cancelled.
Inadvertently interrupting the programme
▸ If the touch button is pressed, the soft roasting programme is interrupted.
– The following appears in the display: «Should be cancelled?»
▸ To continue soft roasting, select «No».
– Operation is continued.
27
Page 28
7 EasyCook
Cancelling / ending soft roasting before time
▸ Select in the soft roasting settings or press the touch button.
– The following appears in the display: «Should be cancelled?».
▸ Select «Yes».
– Operation is cancelled.
▸ To switch off the appliance, press the touch button.
If you accidentally pressed «Yes» or you wish to finish cooking the meat, you must
press the touch button and select an operating mode. «Soft roasting» is not
suitable for already cooked meat.
6.4 Keep warm *
* Depending on the software version
Cooked foods can be kept warm using the «Keep warm» setting.
If the cooking space is already hot, open the appliance door and allow the cooking
space to cool down for 3 to 4 minutes before starting the «Keep warm» function.
This ensures that the food does not overcook.
The longer the food is kept warm, the greater the changes may be to the consistency of the food.
7 EasyCook
EasyCook helps you to prepare any food simply and conveniently. After choosing the
food group and food, the appliance suggests the suitable operating modes or GourmetGuide applications, including the settings and accessories.
The brochure of the same name, which you received with the operating instructions, contains the same settings information in paper form.
The values given for temperature or temperature levels and duration serve only as
guide. They may vary depending on the type and size of the food as well as on individual preference.
7.1 Overview of food groups
Foods are categorized into different groups; an item of food can appear in more than
one group.
The following food groups can be selected:
Fruit Fish and seafood
Mushrooms Flans and pizza
Potatoes Bakery products
Meat Baked dishes and gratins
Poultry
7.2 Selecting and starting foods
A delayed start is only possible for applications where preheating is not required
and is only suitable for food that does not need to be refrigerated or to rise.
28
Page 29
8 Favourites
▸ If the appliance is switched off: first press the adjusting knob.
▸ Press the touch button.
– The overview of food groups is displayed.
▸ Select the food group.
▸ Chose the desired type of food.
▸ If necessary: select the shape (whole, pieces, etc).
▸ If necessary: select the preparation method (cooking, baking, etc.).
▪ The display contains information about:
– Temperature
– Duration
– Preheating necessary / not necessary
– Accessories needed
– Level
– Possible tips
▸ Select .
▸ The operating mode summary is displayed.
▸ To start operation, select .
You can change the set values to a limited extent.
8 Favourites
Up to 24 operating modes, GourmetGuide and EasyCook applications together with the
settings made can be saved as favourites.
8.1 Creating favourites
▸ Select an operating mode, GourmetGuide or EasyCook application.
▸ Make the settings.
▸ Press the touch button.
– The favourites menu opens.
▸ Select a storage space and confirm.
▸ Enter the name of the favourite using the on-screen keypad and confirm.
– The favourite is saved.
8.2 Selecting and starting favourites
▸ Press the touch button.
▸ Choose the desired favourite and select «Yes».
▸ To start the favourite, select .
– The favourite starts.
8.3 Changing favourites
▸ Select the desired favourites.
▸ Adjust the settings as required.
▸ Press the touch button.
▸ Select the storage space or favourite that is to be overwritten.
▸ Enter the favourite name or overwrite as appropriate.
– The changed favourite is saved.
29
Page 30
9 Tips and tricks
8.4 Deleting favourites
▸ If the appliance has another menu open, press the touch button.
▸ Select .
▸ Select the favourite to be deleted.
– The following appears in the display: «Do you want to delete this favourite?».
▸ To delete the favourite, select «Yes».
– The favourite is deleted.
9 Tips and tricks
9.1 Unsatisfactory cooking result...
… when baking and roasting
Result Solution
▪ The baking or roast looks
good on the outside but is still
doughy or raw on the inside.
▸ Next time, set a lower temperature and lengthen
the operating time.
▪ The cake collapses. ▸ Check that the settings used correspond to those
recommended in «EasyCook».
▸ Next time, set a lower temperature and lengthen
the operating time.
▸ Stir the cake mixture well. When finished, bake im-
mediately.
▸ For whisked sponges, beat the egg yolks / egg
whites to a foam a little longer and then carefully
fold into the mixture. When finished, bake immediately.
▸ Follow the instructions on how much baking
powder to add.
Result Solution
▪ The baking has browned un-
evenly.
▸ Next time, set a lower temperature and adjust the
operating time.
▸ If using , and , check that the levels
used correspond to «EasyCook».
▸ Do not push baking tins or bulky foodstuffs right to
the back of the cooking space.
▪ The baked goods have come
out lighter on one baking tray
than on the other.
▸ Check that the settings used correspond to those
recommended in «EasyCook».
Some uneven browning is normal. More even browning is generally achieved at
lower temperatures.
30
Page 31
10 User settings
9.2 Saving energy
The and operating modes consume less energy than the and operating
modes.
▸ Avoid opening the appliance door frequently.
▸ Only switch the illumination on when needed.
▸ For gratins, use the residual heat: for cooking times over 30 minutes, switch the appli-
ance off 5–10 minutes before the end of the operating time.
▸ Minimize preheating.
▸ Only preheat the cooking space if the cooking or baking results depend on it.
Power consumption can be reduced to a minimum by selecting «Hide time» in the
user settings. Despite EcoStandby, all safety functions remain active.
10 User settings
10.1 Overview of user settings
Language Assistance functions
Display Temperature
Date Childproof lock
Clock Appliance information
Notifications Demo mode
Pyrolytic self-cleaning (depending
on model)
Factory settings
Loudness
10.2 Adjusting user settings
▸ If the appliance is switched off, first press the adjusting knob.
▸ Press the touch button.
▪ The user settings main menu appears in
the display:
괫8VHUVHWWLQJV
6HWODQJXDJH
▸ Select the desired user setting or submenu.
▸ Adjust the desired user setting and press the adjusting knob to confirm.
– Either the user settings main menu or the relevant submenu appears in the display.
▸ To exit a submenu and return to the user settings main menu, select .
▸ To exit the user settings, press a different touch button or the touch button.
All user settings are retained in the event of a power failure.
10.3 Language
The language in the display can be changed. Different languages are available for selection.
31
Page 32
10 User settings
10.4 Display
Contrast
With this function, the readability of the display can be adjusted based on how the appliance is installed.
Brightness
The brightness of the display can be changed.
Start screen *
* Depending on the software version
With this user setting, you can determine the menu that is displayed when you start the
appliance. The following menus can be selected:
▪ Operating modes (factory setting)
▪ GourmetGuide
▪ EasyCook
▪ Favourites
Appliance switch-off time
If no operating mode is running but the appliance is switched on, it is automatically
switched off after a certain period of time without any user interaction. Example: After the
end of an operating mode.
The appliance switch-off time can be set between 3 and 30 minutes; the factory setting is
15minutes.
10.5 Date
The date can be called up and changed.
10.6 Clock
The following time functions are available:
▪ Time
▪ Time format
▪ Time display
▪ Mains synchronization
Time format
The time can be displayed in the European 24-hour time format or the US 12‑hour format
(a.m./p.m.).
The «12 h» setting cannot be activated if the summer/winter function is activated.
Time display
With the «Show time» setting (factory setting), the time is dimmed between 00:00 and
06:00 (24-hour format) or 12:00 a.m. and 06:00 a.m. (12-hour format).
If «Hide time» is selected, the displays are not illuminated when the appliance is off.
To reduce power consumption to a minimum, select «Hide time» in the user settings. Despite EcoStandby, all safety functions remain active.
32
Page 33
10 User settings
Mains synchronization
Mains synchronization synchronizes the appliance clock with the mains frequency. Irregular mains frequency can cause the clock to not run correctly. A pulse generator inside
the appliance is used when mains synchronization is switched off.
10.7 Notifications
Acoustic signals and instruction messages can be switched off or disabled. Essential
acoustic signals (such as the timer, end of operation and switch appliance off) cannot be
switched off or disabled.
10.8 Pyrolytic cleaning of appliance
This function enables pyrolytic cleaning of the cooking space.
See Pyrolytic self-cleaning (see page 38).
10.9 Loudness
The acoustic signal can be set at one of two levels of loudness or can be completely
switched off.
An acoustic signal is emitted in the event of a malfunction even if the setting is set
to «off».
A short acoustic signal is emitted when the appliance is switched off even if the
setting is set to «off» (safety function).
10.10 Assistance functions
Illumination
The «Automatic» setting switches on the cooking space illumination:
▪ 3 minutes before a cooking process ends, e.g. in the case of an automatic pro-
gramme or an operating mode with a set duration, or
▪ if the operation is ended before time, i.e. cancelled (using or the touch button).
Depending on the model, the illumination also switches on when the appliance door is
opened.
Press the touch button to switch the illumination on or off at any time.
If the illumination is not switched off, it will go off automatically within 5 minutes to
save energy.
Fast heating
With the «Automatic» setting, fast heating is switched on automatically wherever possible.
Press and go
«Press and go» refers to the period of time after which an operating mode/programme starts automatically as long as all necessary settings are available or have been
made. Adjusting the settings restarts the countdown.
«Press and go» can be switched on or off.
When «Press and go» is activated, values between 10 seconds and
1 minute are possible; the factory setting is 20 seconds.
33
Page 34
11 Care and maintenance
10.11 Temperature
Temperature unit
The temperature can be displayed in «°C» or «°F».
▪ °C: Degrees Celsius
▪ °F: Degrees Fahrenheit
Default value for soft roasting
The default value is the target temperature that is automatically set when soft roasting.
With this user setting, it can be increased or decreased by up to 4°C; the setting then
applies for all cuts of meat.
Example: When using «Soft roasting seared» with a 2°C increase in the default value, a
«medium» fillet of beef is cooked to a target temperature of 59°C instead of 57°C.
10.12 Childproof lock
The childproof lock is to prevent children accidentally switching on the appliance.
When the childproof lock is activated, the appliance can only be operated after first entering a code. The code is displayed in reverse order when unlocking.
The childproof lock activates 3 minutes after the appliance is switched off.
10.13 Appliance information
Under «Appliance information», you will find:
▪ The article number and serial number (FN) of your appliance
▪ The software versions of your appliance as well as the acoustic signals and back-
ground images currently being used (depending on model)
10.14 Demo mode
In demo mode, almost all the appliance functions are available but it is not possible to
cook with the appliance. This ensures operating safety during product demonstrations
and consultations.
It is only possible to switch demo mode on and off with a safety code.
10.15 Factory settings
If one or more user settings have been changed, these can be reset to the factory settings.
11 Care and maintenance
Risk of burns from hot surfaces!
Allow the appliance and the accessories to cool down before cleaning them.
Damage to the appliance from incorrect treatment!
Do not use any abrasive or caustic cleaning agents, metal scrapers that are sharp
or scratch, steel wool, abrasive scouring pads, etc. These products will damage
the surfaces. Glass surfaces that are scratched can crack.
Never use a steam cleaner to clean the appliance.
34
Page 35
11 Care and maintenance
11.1 Cleaning the exterior
▸ Remove any soiling or excess cleaning solution immediately.
▸ Clean the surfaces with a soft cloth dampened with water and a little washing-up liquid
– for metallic surfaces rub in the direction of the original polish lines.
▸ Wipe dry with a soft cloth.
11.2 Cleaning the cooking space
Damage to the appliance from incorrect treatment!
Do not bend the temperature sensor or heating elements.
Do not scour the surface. Scouring will damage the surface.
▸ Remove any soiling from the cooking space while still hand warm using a soft cloth
dampened with water and a little washing-up liquid. Wipe dry with a soft cloth.
In the case of appliances without pyrolysis:
▸ Use a commercially available oven cleaner and follow the manufacturer’s instructions.
Never clean appliances with pyrolysis using oven cleaner
as the surface could otherwise be damaged.
► Carry out pyrolysis in the case of stubborn dirt
deposits (see page 38).
11.3 Cleaning the appliance door
▸ Clean the appliance door with a soft cloth dampened with water and a little washing-
up liquid.
▸ Dry with a soft cloth.
Removing the appliance door
Risk of injury from moving parts!
Be careful not to put fingers in the door hinges. The appliance door is heavy.
When removing and reassembling the appliance door, hold it firmly at the sides
with both hands.
▸ Open the appliance door as far as it will go.
▸ Fold the clips 2 on both door hinges 1 forward.
2
3
1
35
Page 36
11 Care and maintenance
▸ Close the appliance door as far as its at-rest position
(about 30°).
▸ Lift the appliance door out at an angle.
Reassembling the appliance door
▸ From the front, push both hinges 1 into the opening 3.
▸ Open the appliance door as far as it will go and close
back the clips 2.
30°
11.4 Cleaning the door seal
▸ Clean the door seal with a soft cloth dampened with water, but do not use any clean-
ing agent.
▸ Wipe dry with a soft cloth.
11.5 Replacing the door seal
▸ Remove the damaged door seal.
▸ Clean the groove 1 with a slightly damp
cloth.
▸ Press the ends of the new door seal 2
into the groove in the centre of the frame
at the bottom.
3
4
2
1
The ends must touch each other
but not overlap.
▸ Ensure that only the thinner part 3 of the
seal is pressed into the groove; the
thicker part 4 must not be in the groove.
36
Page 37
11 Care and maintenance
▸ Starting from the bottom, press the seal
evenly into the groove.
11.6 Replacing the door seal on pyrolysis appliances
▸ Remove the damaged door seal.
▸ Clean the groove 3 with a slightly damp cloth.
▸ Press the new door seal 1 into the groove, with the
seam joint 2 not at centre bottom of the frame
2
31
▸ Ensure that only the thinner part 4 of the seal is
pressed into the groove; the thicker part 5 must
not be in the groove.
4
5
▸ Starting from the bottom, press the seal evenly into
the groove.
11.7 Replacing the halogen light bulb
WARNING: Risk of electric shock!
Disconnect the appliance from the mains power supply before replacing the halogen light bulb.
Risk of burns from hot surfaces!
Allow the halogen light bulb and the appliance to cool down before replacing the
halogen light bulb.
37
Page 38
11 Care and maintenance
▸ Remove the left shelf guide.
▸ Place the screw driver along the middle
of the edge of the glass and carefully remove the glass light cover 1 from its fixture.
▸ Take out the defective halogen light
bulb.
▸ Carefully fit the new halogen light bulb.
1
Do not touch the halogen light bulb with bare hands. Instead, use a fine, dry,
grease-free cloth.
▸ Press the glass light cover 1 back into its fixture.
▸ Replace the shelf guides.
▸ Reconnect the power supply.
11.8 Cleaning the accessories and shelf guides
Incorrect handling can cause damage!
Do not clean the food probe in the dishwasher.
▪ The wire shelf and shelf guides can be cleaned in the dishwasher.
▪ The baking tray can be cleaned in the dishwasher; however, this will affect its non-
stick properties.
▸ Clean the food probe with a soft cloth dampened with water and a little washing-up li-
quid.
Removing and reassembling the shelf guides
▸ Swing the shelf guides 1 at the front into the middle of the
cooking space.
▸ Take the shelf guides out of the opening at the back.
▸ Put back in reverse order.
1
11.9 Pyrolytic self-cleaning
Danger of explosion through deposits and cleaning agents!
Remove grease or oil deposits. Do not use any chemical cleaning agents. Deposits could give rise to chemical reactions and destroy the enamel. Poisonous fumes
could escape.
Do not leave the appliance unattended.
Risk of burns from hot surfaces! The appliance front gets hotter than during normal
operation.
There is likely to be some smoke given off for a short period of time so ventilate
the room during pyrolysis.
In pyrolytic self-cleaning, any soiling is burned off at a high temperature.
38
Page 39
11 Care and maintenance
Possible settings
▪
Lightly soiled Cleaning duration: 1½ hrs.
▪
Medium soiled Cleaning duration: 2 hrs.
▪
Heavily soiled Cleaning duration: 2½ hrs.
The pyrolytic self-cleaning process – including cooling down – takes about4–
5hours.
As long as the temperature is over 300°C, the illumination switches off and cannot be switched back on.
Over time with use the cooking space can turn matt. Fruit acid and fatty acid deposits
can leave stains. This will not affect the cooking or baking characteristics of the appliance nor affect its functioning.
Selecting and starting pyrolytic self-cleaning
Damage to accessories from self-cleaning!
Remove accessories, shelf guides, full extension roller runners, cookware and any
other objects from out of the cooking space. Otherwise they can become discoloured and their surface rough. The rolling properties of full extension roller runners
deteriorate.
▸ Close the appliance door.
▸ If the appliance is switched off: first press the adjusting knob.
▸ Press the touch button.
▸ Select .
▸ Select the degree of soiling.
– The calculated end time for the pyrolytic self-cleaning process is shown in the dis-
play above .
▸ To start the pyrolytic self-cleaning process, select .
– The appliance door locks.
Delayed start
The start of pyrolytic self-cleaning can be delayed, for example, to take advantage of
lower electricity tariffs.
▸ Select before starting.
▸ Set the desired end time.
▸ Select .
– The appliance remains switched off until the calculated automatic start.
Cancelling
▸ Select in the display.
– Pyrolytic self-cleaning is cancelled.
▸ The residual heat appears in the display.
▸ The appliance door remains locked until the temperature drops below 300°C.
End
The appliance door cannot be opened until the temperature has dropped below 300°C.
▸ Wait until the appliance has cooled to hand warm to remove any residue left behind
using a soft cloth dampened with water. Do not use cleaning agents.
39
Page 40
12 Trouble-shooting
12 Trouble-shooting
12.1 What to do if …
This section lists faults that can be solved simply by following the instructions given. If
another fault is displayed or the fault cannot be remedied, please call Customer Services.
Before calling Customer Services, please note down the error message in full.
Fxx/Exxx see operating instructions
FNxxxxx xxxxxx.
… the appliance is not working
Possible cause Solution
▪ A household fuse or circuit
breaker has tripped.
▸ Change the fuse.
▸ Reset the circuit breaker.
▪ The fuse or circuit breaker
keeps blowing.
▸ Call Customer Services.
▪ An interruption in the mains
power supply.
▸ Check the power supply.
▪ Demo mode is switched on. It is only possible to switch off demo mode with a
safety code.
▸ Call Customer Services.
▪ The appliance is faulty. ▸ Call Customer Services.
… the appliance door cannot be opened
Possible cause Solution
▪ The temperature of the cook-
ing space is over 300°C.
▸ Wait for it to cool down.
The appliance door cannot be opened until the temperature of the cooking space has dropped below
300°C.
▪ Pyrolytic self-cleaning is run-
ning.
▸ Wait until pyrolytic self-cleaning has finished.
… just the illumination is not working
Possible cause Solution
▪ The halogen light is defective. ▸ Switch off the oven.
▸ Disconnect the appliance from the electricity sup-
ply.
▸ Replace the halogen light bulb.
... the cooking time seems unusually long
Possible cause Solution
▪ The appliance only has a
single-phase connection.
▸ Establish a two-phase connection.
40
Page 41
12 Trouble-shooting
… when grilling, thick smoke is given off
Possible cause Solution
▪ The food is too near to the
heating elements.
▸ Check that the level selected corresponds to the
«EasyCook».
▪ Grill setting is too high. ▸ Reduce the grill setting.
... the food probe temperature is not displayed
Possible cause Solution
▪ The food probe is not plugged
in correctly.
▸ Check whether the food probe is correctly plugged
into the socket.
▸ Check whether the food probe is correctly inserted
in the food: The tip must be in the centre of the
thickest part.
▪ In the selected automatic pro-
gramme, the food probe cannot be used; the symbol
is illuminated in grey.
▸ If you wish to use the food probe in spite of this,
change to the operating mode menu and set a
suitable operating mode.
▪ The food probe or the socket
is defective.
▸ Call Customer Services.
The food probe temperature is never displayed during the heating process.
… the appliance makes noises during operation
Possible cause Solution
▪ The appliance may emit noise
when operating (e.g. switching
and pumping noises).
Such noise is normal.
… the clock is not running correctly
Possible cause Solution
▪ Irregular mains frequency ▸ Switch off the mains synchronization.
▪ Internal pulse generator is im-
precise when mains synchronization is switched off.
▸ Call Customer Services.
41
Page 42
12 Trouble-shooting
… the following appears in the display
FX/EXX see operating instructions
FN XXX XXXXXX
Possible cause Solution
▪ Various situations can lead to
an error message.
▸ Cancel the error message by pressing the touch
button.
▸ Disconnect from the power supply for
about1minute.
▸ Reconnect the power supply.
▸ If the error appears again, note down the error
message in full along with the serial number (FN;
see identification plate).
▸ Disconnect from the power supply.
▸ Call Customer Services.
… the following appears in the display
UX/EXX see operating instructions
FN XXX XXXXXX
Possible cause Solution
▪ An interruption in the power
supply.
▸ Cancel the error message by pressing the but-
ton.
▸ Disconnect from the power supply for
about1minute.
▸ Reconnect the power supply.
▸ If the error appears again, note down the error
message in full along with the serial number (FN;
see identification plate).
▸ Disconnect from the power supply.
▸ Call Customer Services.
12.2 After a power failure
The user settings remain unchanged.
Brief power failure during operation
– The current operation of the appliance is cancelled.
– The following appears in the display when the appliance is switched on: «Power
failure. Operation cancelled».
▸ To cancel the message, select .
– The operating modes menu appears in the display.
Prolonged power failure
Variant 1 *
* Depending on the software version
42
Page 43
13 Accessories and spare parts
The appliance goes through its initial set-up process after a prolonged power failure.
However, only the language and time need to be reset to enable the appliance to be operated again. It is not necessary to make any other settings.
Variant 2 *
* Depending on the software version
The appliance goes through its initial set-up process after a prolonged power failure.
However, only the time needs to be reset to enable the appliance to be operated again.
It is not necessary to make any other settings.
– The following appears in the display when the appliance is switched on: «Power
failure. Set time.»
▸ To confirm the message, select .
– The «Clock» menu in the user settings appears in the display.
▸ Select , set the time and confirm.
– The «Clock» menu appears again in the display.
▸ Select .
– The following appears in the display: «Do you want to continue with the initial start-
up?»
▸ To change other user settings, select «Yes».
– The relevant user settings menu appears in the display.
▸ If no other user settings are to be changed, select «No».
– The appliance is ready for operation again.
13 Accessories and spare parts
The accessories listed below, as well as spare parts, can be ordered in addition to the
scope of delivery of the appliance. Ordering is subject to charge, except in the event of
warranty claims. Please give product family of the appliance and exact designation of the
accessory or spare part when ordering parts.
13.1 Accessories
TopClean baking tray
Wire shelf
Food probe
with straight handle
EasyCook brochure
Bedienungsanleitung … Einstelltipps
43
Page 44
14 Technical data
Recipe book
13.2 Special accessories
For information see: www.vzug.com
13.3 Spare parts
Shelf guides
left/right
Halogen light bulb
Door seal
Door seal for
pyrolytic appliances
The halogen light bulb is also available from specialist retailers.
14 Technical data
External dimensions
▸ See installation instructions
1
Electrical connection
▸ See identification plate 1
14.1 Note for testing institutes
The energy efficiency class according to EN 50304 / EN 60350 is determined using the
and operating modes.
44
Page 45
14 Technical data
Placing thermocouples between the appliance door and the seal can cause lack of leaktightness and thus measuring errors.
The usable volume within the meaning of EN 50304 / EN 60350 is obtained with the
shelf guides disassembled.
14.2 Temperature measurement
The temperature inside the cooking space is measured when the cooking space is
empty according to an internationally accepted standard. Own measurements can be imprecise and are not suitable for checking the accuracy of the temperature.
14.3 Product fiche
In accordance with EU Regulation No.: 66/2014
Brand – V-ZUG Ltd
Type of appliance – Compact oven
Model designation – BCXSE | BCXSEP
Mass of MS 55 appliance kg –
Mass of EURO 60 appliance kg 36 | 37
Number of cavities – 1
Heat source per cavity – Electricity
Volume per cavity l 50
Energy consumption in conventional mode 1) kWh/cycle 0.81 | 0.88
Energy consumption in hot air / forced convection
mode 2)
kWh/cycle 0.69 | 0.7
Energy Efficiency Index per cavity 3) – 90.8 | 92.1
Measurement and calculation methods used – IEC 60350
1) Required to heat a standardized load per cavity
2) Required to heat a standardized load per cavity
3) Measurement methods: see EU Regulation No. 66/2014, Annex II, Chpt. 1
Saving energy while cooking
The and operating modes consume less energy than the and operating
modes.
▸ Avoid opening the appliance door frequently.
▸ For gratins, use the residual heat: for cooking times over 30 minutes, switch the appli-
ance off 5–10 minutes before the end of the operating time.
▸ Minimize preheating.
▸ Only preheat the cooking space if the cooking or baking results depend on it.
14.4 EcoStandby
To prevent unnecessary energy consumption, the appliance is equipped with the automatic energy-saving «EcoStandby» function.
To reduce power consumption to a minimum, select «Hide time» in the user settings. Despite EcoStandby, all safety functions remain active.
45
Page 46
15 Disposal
14.5 Reference to «Open Source» licence
Your appliance contains Newlib open-source software. This is subject to the licensing
conditions specified in Section 4.1 (4.1.1-4.1.8; 4.1.9; 4.1.10; 4.1.14-4.1.16) of the enclosed open-source software licence text document.
15 Disposal
15.1 Packaging
Never allow children to play with packaging material due to the danger of injury or
suffocation. Store the packaging material in a safe location or dispose of it in an
environmentally-friendly way.
15.2 Safety
Render the appliance unusable to prevent accidents caused by improper use (e.g.
through children playing):
▸ Disconnect the appliance from the mains. With a fixed appliance, this is to be carried
out by a qualified electrician. Then cut the mains cable off flush with the appliance.
15.3 Disposal
▪ The «crossed‐out wheeled bin» symbol requires the separate collection of waste
electrical and electronic equipment (WEEE). Such equipment can contain hazardous,
environmentally harmful materials.
▪ These appliances are to be handed over to a designated collection point for the recyc-
ling of electrical and electronic equipment and must not be disposed of with unsorted
household waste. And in this way, you will be helping to protect resources and the en-
vironment.
▪ For more information, please contact the local authorities.
46
Page 47
16 Index
A
Accessories ............................................... 11, 43
Cleaning ........................................................ 38
Acoustic signals ............................................... 33
Appliance disposal .......................................... 46
Appliance door
Cleaning ........................................................ 35
Removing ...................................................... 35
Appliance information ..................................... 34
Appliance switch-off time ............................... 32
B
Baking tray ........................................................ 11
Before using for the first time........................... 7
Bottom heat ............................................... 11, 15
Brightness ......................................................... 32
C
Cancelling
Changing recipe .......................................... 24
Creating own recipe.................................... 24
Operating mode........................................... 19
Recipes.......................................................... 23
Cleaning............................................................. 35
Accessories .................................................. 38
Cooking space............................................. 35
Door seal....................................................... 36
Food probe ................................................... 38
Shelf guides.................................................. 38
Cleaning the exterior ....................................... 35
Clock .................................................................. 32
Construction...................................................... 10
Contrast ............................................................. 32
Cooking space
Cleaning ........................................................ 35
Temperature measurement ....................... 45
D
Delayed start..................................................... 17
Pyrolytic self-cleaning ................................. 39
Deleting
Favourites...................................................... 30
Own recipe.................................................... 25
Demo mode ...................................................... 34
Disposal............................................................. 46
Door seal
Cleaning ........................................................ 36
Replacing ...................................................... 36
Replacing on pyrolysis appliance ............ 37
Duration ............................................................. 17
Recipe step................................................... 24
E
EasyCook ................................................... 28, 43
Food groups ................................................. 28
EcoStandby....................................................... 45
Electrical connection ....................................... 44
End ..................................................................... 17
Extending operation ........................................ 21
External dimensions ........................................ 44
F
F and E messages .......................................... 42
Factory settings................................................ 34
Fast heating ............................................... 15, 33
Automatic switch-on .................................... 33
Favourites.......................................................... 29
Changing....................................................... 29
Creating ......................................................... 29
Deleting ......................................................... 30
Starting........................................................... 29
FN ....................................................................... 34
Food probe ................................................ 12, 18
Cleaning ........................................................ 38
Food probe temperature ................................ 18
Measure only ................................................ 19
G
Grill ..................................................................... 14
Grill-forced convection .................................... 14
H
Halogen light bulb ........................................... 37
Hold .................................................................... 24
Hot air ................................................................ 13
Hot air humid .................................................... 15
Hot air with bottom heat ................................. 13
I
Identification plate............................................ 44
Illumination ................................................. 33, 40
Initial set-up ..................................................... 7, 9
Instruction message ........................................ 33
Instructions for use ............................................. 7
K
Keep warm........................................................ 28
L
Language........................................................... 31
Levels ................................................................. 11
Long cooking time........................................... 40
Loudness ........................................................... 33
47
Page 48
M
Mains synchronization .................................... 33
Maintenance ..................................................... 34
Model number .............................................. 2, 34
N
Notes.................................................................. 49
O
Operating and display elements................... 10
Operating mode
Cancelling ..................................................... 19
Changing....................................................... 19
Selecting........................................................ 16
Operating mode settings................................ 17
Changing....................................................... 17
Checking ....................................................... 17
Operation........................................................... 16
Own recipes...................................................... 23
Creating ......................................................... 23
Deleting ......................................................... 25
P
Pause ................................................................. 24
Plate warmer..................................................... 12
Power failure ..................................................... 42
Preheating .................................................. 31, 45
Press and go ............................................. 17, 33
Product family...................................................... 2
Pyrolytic self-cleaning...................................... 38
Cancelling ..................................................... 39
Starting........................................................... 39
Q
Queries .............................................................. 51
Quick instructions ............................................ 52
R
Recipe book .............................................. 22, 44
Unlocking ...................................................... 22
Recipes.............................................................. 22
Action required............................................. 23
Changing....................................................... 25
Copying ......................................................... 25
Creating own ................................................ 23
Ending a step before time ......................... 24
Step duration ................................................ 24
S
Safety precautions
Appliance-specific .......................................... 6
Before using for the first time....................... 7
Correct use ......................................................7
General .............................................................5
Saving energy............................................ 31, 45
Self-cleaning ..................................................... 38
Cancelling ..................................................... 39
Starting........................................................... 39
Service & Support................................... 51
Service agreement........................................... 51
Setting the time ................................................ 31
Shelf guides
Cleaning ........................................................ 38
Removing ...................................................... 38
Soft roasting...................................................... 26
Default value................................................. 34
Positioning the food probe ........................ 27
Seared ........................................................... 26
Starting........................................................... 27
Switching off before time ........................... 28
Software versions............................................. 34
Spare parts ................................................ 43, 44
Special accessories ................................. 12, 44
Start screen....................................................... 32
Switching off before time................................ 19
Symbols ................................................................ 5
T
Target temperature .......................................... 18
Technical data .................................................. 44
Temperature sensor ........................................ 11
Temperature unit.............................................. 34
Testing institutes .............................................. 45
Time display...................................................... 32
Time format ....................................................... 32
Timer .................................................................. 20
Tips and tricks .................................................. 30
Top/bottom heat .............................................. 13
Top/bottom heat humid.................................. 14
Touch buttons................................................... 10
Type....................................................................... 2
U
U and E messages.......................................... 42
Uneven browning............................................. 30
User settings..................................................... 31
Adjusting........................................................ 31
Overview........................................................ 31
Using for the first time........................................ 9
V
Validity................................................................... 2
W
Wire shelf........................................................... 11
48
Page 49
49
17 Notes
Page 50
50
Page 51
18 Service & Support
The «Trouble-shooting» section gives you valuable tips on how to deal with minor
malfunctions yourself, saving you the time and trouble of calling out a service technician and any cost that goes along with it.
Information on the V-ZUG warranty can be found at www.vzug.com →Service
→Warranty information. Please read this information carefully.
Please register your V-ZUG appliance immediately:
▪ online at www.vzug.com →Service →Online warranty registration or
▪ using the enclosed registration card.
This will allow you to take advantage of the best possible support in the event of a fault
in the appliance during the guarantee period. You will require the serial number (FN) and
appliance designation to register your appliance. You will find them on the identification
plate of your appliance.
My appliance information:
FN: ___________________ Appliance: _____________________
Please have this appliance information to hand when contacting V-ZUG. Thank you.
▸ Open the appliance door.
– The identification plate is located on the left-side panel.
Your repair order
Call the free service number 0800 850 850 to contact your nearest
V-ZUG service centre. You can arrange an onsite visit by us by phone if you wish.
General queries, accessories and service agreement
V-ZUG will be happy to help you with any general administrative or technical queries, to
accept your orders for accessories and spare parts and to inform you about our progressive service agreements. You can contact us by calling Tel. + 41 58 767 67 67 or
by going to our website at www.vzug.com.
51
Page 52
Quick instructions
Here you will find an overview of key operating information.
Active menu
Action buttons
Menu buttons
12:00
7RSERWWRPKHDW
곋2SHUDWLQJPRGHV
Press to switch on the appliance or
to select/confirm
Turn to set the temperature and time
or to navigate within the menu
Adjusting knob as a central
operating element
►
►
Menu and action buttons
The menu buttons contain a selection of preparation options and user settings. These
can be selected by pressing the relevant button. The active menu is shown in the display. You can use the adjusting knob to operate and navigate within the menu; additional
submenus can also be called up.
The function buttons give you direct access to independent functions such as the timer
or switching off the appliance .
V-ZUG Ltd, Industriestrasse 66, CH-6301 Zug
Tel. +41 58 767 67 67, Fax +41 58 767 61 61
[email protected], www.vzug.com
Service Centre: Tel. 0800 850 850
J21017013-R09
Loading...
