ZUCCHETTI 1100TL, 1600TL, 2200TL, 2700TL, 3000TL User Manual

Identificazione: MD-AL-GI-00
Rev. 4.0 del 31.01.18 - Applicazione:
GID
Reg. Pile IT12110P00002965 - Capitale Sociale € 100.000,00 I.V. Reg. Impr. AR n.03225010481 - REA AR - 94189 Azienda Certificata ISO 9001 - Certificato n. 9151 - CNS0 - IT-17778
Grid-connected inverter
1.1K – 3K TL
User Manual
V2.1 (07-06-2019)
Identification: MD-AL-GI-00 Rev. 4.0 of 31.01.18 - Application: GID
Manual of 07/06/2019 Rev. 2.1 “User Manual for 1.1K-3K TL”
Table of Contents
1. Preliminary safety instructions…...………………………………………….…………………………………………………………….6
1.1. Safety instructions……………………………………………………………..…………………………………………………………..6
1.2. Symbols and icons…..……..…………………………………………………….…………………………………………………………9
2. Product features……………….……………………………………………………….………….……………………………………………10
2.1. Product presentation………..…………………………………………………...……………………………………………………..10
2.2. Description of functions……………………………………………………………………………………….……………………....12
2.3. Efficiency curve…..……………………………………………………………………..…………………………………………………13
3. Installation………..………………………………………………………………………………………………………………………………14
3.1. Installation process……...………………………………………………………………...……………………………………………14
3.2. Checks before installation……………….……………………………………………………………………………………………14
3.3. Installation tools…………………………………………………………………………….……………………………………………16
3.4. Installation position………………………………………………………………………….….………………………………………18
3.5. Moving the ZCS 1.1-3K TL inverter………..……………………………………………….………...……………………………19
3.6. Installing the ZCS 1.1-3K TL inverter…….……………………………………………….………...……………………………20
4. Electrical connections………..………………………………………………………………………….……………………………….…..21
4.1. Electrical connections……………..…………………………………………………………………..……………………….……....22
4.2. Ground cable connections (PNGD).……………………………………………………..…………………………………….…..22
4.3. Connecting the DC input power cable………………………...…………………………………….…………………………...24
4.4. Connecting the AC output power cables…...………………………………………..………………………………………….27
4.5. Connecting the communication cables……………………...…………………………………………..………………………30
4.6. Communication systems....………………………………………………………………………………………...…………………33
5. Commissioning the inverter……………………………..………………………………..…………………………….………………....36
5.1. Safety inspection before commissioning………………..……………………………………………………….……………..36
5.2. Starting the inverter………………………………………………………………………………………………………………….….36
6. Operating interface…………………………………………………………………………………………………………………………….37
6.1. Operating interface and display….………………………………………………………………………….…………..………….37
6.2. Main interface………………………………………………………………..…………………..…………………………………..…….38
6.3. Main menu……….………………………………………………………………………………………………….……………………....40
2 / 61
Identification: MD-AL-GI-00 Rev. 4.0 of 31.01.18 - Application: GID
Manual of 07/06/2019 Rev. 2.1 “User Manual for 1.1K-3K TL”
7. Troubleshooting and maintenance..………..……………………………………………………………………………..…………....54
7.1. Troubleshooting…………………………………………………………………………………….…………………………………….54
7.2. Maintenance……………………………………………………………………………………………...…………………………………59
8. Uninstalling…………………………………………………………………………………….……………...………………………………….59
8.1. Steps for uninstalling the inverter…..…………………………………………………………………..…………………………59
8.2. Packaging…………………………………………………………………………………………………………………………………….59
8.3. Storage…..………………………………………………………………………………………………………………….………………...59
8.4. Disposal…….………………………………………………………………………..…………………………………….…………………59
9. Technical specifications………………………………………………………………………………………………………..…………….60
10. Warranty.…………….………………………………………………………………………………………………………………..……………62
3 / 61
Identification: MD-AL-GI-00 Rev. 4.0 of 31.01.18 - Application: GID
Manual of 07/06/2019 Rev. 2.1 “User Manual for 1.1K-3K TL”
General instructions
This manual contains important safety instructions that must be followed during installation and maintenance of the equipment.
Please keep these instructions!
This manual must be considered an integral part of the equipment and must always be available to everyone who interacts with this equipment. The manual must always accompany the equipment, even when it is transferred to another user or plant.
Copyright statement
The copyright of this manual belongs to Zucchetti Centro Sistemi S.p.A. No part of this manual may be copied (including the software), reproduced or distributed in any form or by any means without the permission of Zucchetti Centro Sistemi S.p.A. All rights reserved. ZCS reserves the right to final interpretation. This manual is subject to change based on feedback from users, installers or customers. Please check our website at
http://www.zcsazzurro.com for the latest version.
Zucchetti Centro Sistemi Via Lungarno 305/A 52028, Terranuova Bracciolini (AR) +39 055 91971
info@zcscompany.com http://www.zcscompany.com
4 / 61
Identification: MD-AL-GI-00 Rev. 4.0 of 31.01.18 - Application: GID
Manual of 07/06/2019 Rev. 2.1 “User Manual for 1.1K-3K TL”
Danger: indicates a hazardous situation which, if not resolved or avoided, could result in serious injury or death.
Danger
Warning: indicates a hazardous situation which, if not resolved or avoided, could result in serious injury or death.
Warning
Caution: indicates a hazardous situation which, if not resolved or avoided, could result in minor or moderate injury.
Caution
Attention: indicates a potentially hazardous situation which, if not resolved or avoided, could result in damage to the system, or other property.
Attention
Note: provides important tips on the correct and optimal operation of the product.
Note
Preface
General information
Please read this manual carefully before installation, operation or maintenance. This manual contains important safety instructions that must be followed during installation and maintenance of the system.
Scope
This manual describes the assembly, installation, electrical connections, commissioning, maintenance and troubleshooting of the following inverters:
1100TL / 1600TL / 2200TL / 2700TL / 3000TL
Keep this manual so that it is accessible at all times.
Recipients
This manual is intended for qualified technical personnel (installers, technicians, electricians, technical support personnel or anyone who is qualified and certified to operate a photovoltaic system), who are responsible for installing and starting up the inverter in the photovoltaic energy system and for operators of the photovoltaic system.
Symbols used
This manual provides information for safe operation and uses certain symbols to ensure the safety of personnel and materials, and for efficient use of the equipment during normal operation. It is important to understand this information to avoid accidents and damage to property. Please take note of the following symbols used in this manual.
5 / 61
Identification: MD-AL-GI-00 Rev. 4.0 of 31.01.18 - Application: GID
Manual of 07/06/2019 Rev. 2.1 “User Manual for 1.1K-3K TL”
If you have problems or questions regarding the reading and understanding of the following information, please contact Zucchetti Centro Sistemi S.p.A. through the appropriate channels.
Note
1. Preliminary safety instructions
General information in this chapter
Safety instructions
It mainly highlights the safety instructions to be followed during installation and use of the equipment.
Symbols and icons Introduces the main safety symbols on the inverter.
1.1. Safety instructions
Before installing and using the equipment, make sure you read and understand the instructions in this manual and familiarise yourself with the relative safety symbols shown in this chapter.
Depending on national and local requirements, permission must be obtained from your local provider before connecting to the electrical grid, making sure that the connections are carried out by a qualified electrician.
Contact the nearest authorised service centre for any repairs or maintenance. Contact your distributor for information on the nearest authorised service centre. DO NOT carry out repairs yourself, as this may result in injury or damage.
Qualified personnel
Ensure that the operator has the necessary skills and training to operate the equipment. Personnel responsible for the use and maintenance of the equipment must be skilled and capable of performing the activities described, and must also have appropriate knowledge on how to correctly interpret the contents of this manual. For safety reasons, this inverter can only be installed by a qualified electrician with the necessary training and/or skills and knowledge. Zucchetti Centro Sistemi S.p.A. declines all responsibility for damage to property or personal injury caused by incorrect use or the device.
Installation requirements
Install and start the inverter according to the following instructions. Place the inverter on suitable load­bearing supports with sufficient load capacity (such as walls or photovoltaic racks) and make sure that the inverter is positioned vertically. Choose a suitable location for the installation of the electrical equipment. Make sure there is sufficient space for heat dispersion and to accommodate future maintenance. Maintain adequate ventilation and ensure that there is enough air circulation for cooling.
6 / 61
Identification: MD-AL-GI-00 Rev. 4.0 of 31.01.18 - Application: GID
Manual of 07/06/2019 Rev. 2.1 “User Manual for 1.1K-3K TL”
Before connecting the mains power, be sure to disconnect the photovoltaic modules by disconnecting all the DC switches of the generator. When exposed to the sun, the photovoltaic generator produces a voltage that can be dangerous!
Danger
All installation operations must be carried out by a professional electrician, who must:
be prepared. carefully read this manual and understand its contents.
Warning
Before connecting the inverter to the grid, make sure that all the necessary permits have been obtained from the local grid operator and that all the electrical connections are made by a professional electrician.
Attention
Figure 1 – Do not lose or damage this manual
Transport requirements
If you have problems with the packaging that could cause damage to the inverter or if you find any visible damage, immediately notify the transport company. If necessary, request assistance from an installer of photovoltaic systems or from Zucchetti Centro Sistemi SpA. Transport of the equipment, especially by road, must be carried out with vehicles suitable to protect the components (in particular, electronic components) against violent knocks, humidity, vibrations, etc.
Electrical connections
Please comply with all the electrical regulations on the prevention of accidents related to photovoltaic inverters.
7 / 61
Identification: MD-AL-GI-00 Rev. 4.0 of 31.01.18 - Application: GID
Manual of 07/06/2019 Rev. 2.1 “User Manual for 1.1K-3K TL”
Do not remove the information label or open the inverter. Otherwise, ZCS will not provide any warranty or maintenance.
Note
Contact with the electrical grid or the terminal of the equipment may cause electrocution or fire!
•
Do not touch the terminal or the conductor connected to the electrical grid.
•
Follow all the instructions and safety requirements relating to the mains connection.
Danger
Some internal components reach very high temperatures when the inverter is in operation. Wear protective gloves!
Attention
Before carrying out any repairs, disconnect the inverter from the mains network (AC
side) and from the photovoltaic system (DC side).
After switching off the AC and DC switches, wait 5 minutes before carrying out any
repairs or maintenance on the inverter!
Danger
The inverter should start working again after any faults have been fixed. For any
repairs, contact your local authorised service centre;
Do not disassemble the internal components of the inverter without permission. This
will void the warranty. Zucchetti Centro Sistemi S.p.A. shall not be responsible for any damage or loss caused by these actions.
Attention
Operation
Maintenance and repair
8 / 61
Identification: MD-AL-GI-00 Rev. 4.0 of 31.01.18 - Application: GID
Manual of 07/06/2019 Rev. 2.1 “User Manual for 1.1K-3K TL”
Pay attention to possible burns due to hot parts.
Only touch the screen or press the keys while the inverter is in operation.
Caution
The PV strings should be connected to the ground in accordance with the local regulations.
• To ensure the safety of the system and people, the inverter
and photovoltaic strings must be securely connected to the ground.
Attention
Ensure the correct DC input voltage; this must be below the maximum allowable DC voltage. Overvoltage can cause permanent damage to the inverter that is not covered by the warranty!
Warning
Residual voltage may be present on the inverter! Before opening the inverter, wait 5 minutes to ensure that the capacitors are completely discharged.
Be careful of high voltage
Be careful of high temperatures
Complies with the European Standards (CE)
Grounding point
1.2. Symbols and icons
Safety signals
Symbols on the inverter
Some safety symbols are located on the inverter. Read and understand the contents of the
symbols before installing the inverter.
9 / 61
Identification: MD-AL-GI-00 Rev. 4.0 of 31.01.18 - Application: GID
Manual of 07/06/2019 Rev. 2.1 “User Manual for 1.1K-3K TL”
Read this manual before installing the inverter.
Indication of the allowable temperature range
Degree of protection of the equipment according to the IEC 70-1 standard (EN 60529 June 1997).
Positive pole and negative pole of the input voltage (DC).
2. Product features
General information in this chapter Product dimensions
The field of use and overall dimensions of the 1.1K-3K TL inverters are indicated in this section.
Function description
It describes how the 1.1K-3K TL inverters and their internal operating modules work.
Efficiency curve
It describes the efficiency curves of the inverter.
2.1. Product presentation
Field of use
The 1.1K-3K TL inverters are grid-connected photovoltaic inverters equipped with a single MPPT channel, capable of converting the direct current generated by the photovoltaic strings into single-phase sine wave alternating current and feeding the energy to the public electricity grid. An AC circuit breaker (see chapter 4.4) and DC circuit breaker must be used as disconnecting devices and must always be easily accessible.
10 / 61
Identification: MD-AL-GI-00 Rev. 4.0 of 31.01.18 - Application: GID
Manual of 07/06/2019 Rev. 2.1 “User Manual for 1.1K-3K TL”
Figure 2 – Grid-connected photovoltaic system
The 1.1K-3K TL inverters can only be used with photovoltaic modules that do not require one of the poles to be grounded. The input current and voltage of the PV strings must not exceed the limits specified in the technical specifications. Only photovoltaic modules can be connected to the input of the inverter (do not connect batteries or other power supply sources).
• Accessories and optional components of the inverter should be chosen by a qualified technician who is
familiar with the installation conditions.
• Overall dimensions: L x W x H = 405.5 mm x 314 mm x 135.5 mm
Figure 3 – Front, side and back view of the inverter and bracket
11 / 61
Identification: MD-AL-GI-00 Rev. 4.0 of 31.01.18 - Application: GID
Manual of 07/06/2019 Rev. 2.1 “User Manual for 1.1K-3K TL”
Labels on the inverter
Figure 4 – Do not remove the label on the side of the inverter
2.2. Description of functions
The DC power generated by the PV modules is filtered through the input board before entering the power board. The input board also has the function of detecting the insulation impedance and the DC input voltage/current. The power board converts the DC power into AC power. The current converted into AC is filtered through the output board and is then fed into the grid. The output board also has the function of measuring the grid and GFCI voltage/current, and acts as an output insulation relay. The control provides the auxiliary power supply, controls the operating status of the inverter and shows it on the display. The display also shows the error codes when the inverter is not functioning properly. At the same time, the control board can activate the protection relay in order to disconnect the inverter from the grid and protect the internal components.
Inverter functions
A. Feeding reactive power into the grid
The inverter is able to produce reactive power and feed it into the grid through the setting of the Power Factor. The feed-in management can be controlled directly by the grid company through a dedicated RS485 interface.
B. Limiting the active power fed into the grid
If enabled, the inverter can limit the amount of active power fed into the grid at the desired value (expressed as a percentage).
C. Automatic power reduction when grid is over frequency
When the grid frequency is higher than the limit set, the inverter reduces the output power in order to ensure the stability of the grid.
D. Data transmission
The inverter (or a group of inverters) can be monitored remotely via an advanced communication system based on a RS485 interface or via Wi-Fi.
E. Software update
A microSD card is used to update the firmware.
12 / 61
Identification: MD-AL-GI-00 Rev. 4.0 of 31.01.18 - Application: GID
Manual of 07/06/2019 Rev. 2.1 “User Manual for 1.1K-3K TL”
Wiring diagram
Figure 5 – Block diagram of the 1.1K-3K TL inverter
2.3. Efficiency curve
Efficiency curve for a Azzurro ZCS 3000 TL model
Figure 1 – Efficiency curve for an Azzurro ZCS 3000 TL inverter
13 / 61
Identification: MD-AL-GI-00 Rev. 4.0 of 31.01.18 - Application: GID
Manual of 07/06/2019 Rev. 2.1 “User Manual for 1.1K-3K TL”
DO NOT install 1.1K-3K TL inverters near flammable materials. DO NOT install 1.1K-3K TL inverters in an area where flammable or explosive
materials are stored.
Danger
The housing and heat sink may become very hot while the inverter is running, DO NOT install the inverter in places where they may be touched inadvertently.
Warning
Consider the weight of the inverter during transportation and installation. Choose an appropriate mounting position and surface.
Attention
3. Installation
General information in this chapter
This chapter describes how to install the 1.1K-3K TL inverter.
Installation notes:
3.1. Installation process
Figure 7 – Installation steps
3.2. Checks before installation
Checking the outer packaging
The packaging materials and components may be damaged during transportation. Therefore, please check the materials of the outer packaging before installing the inverter. Check the surface of the box for external damage such as holes or tears. If any kind of damage is detected, do not open the box containing the inverter and contact the supplier and transport company as soon as possible. It is recommended to remove the packaged materials from the box 24 hours before installing the inverter.
Checking the product
After removing the inverter from its packaging, check that the product is intact and complete. If any damage is found or there are no components, contact the supplier and transport company.
14 / 61
Identification: MD-AL-GI-00 Rev. 4.0 of 31.01.18 - Application: GID
Manual of 07/06/2019 Rev. 2.1 “User Manual for 1.1K-3K TL”
1 Photovoltaic inverter
1 mounting bracket
1 + input terminal
1 - input terminal
1 Metal terminal for + DC
power cables
1 Metal terminal for - DC
power cables
2 M5 hexagonal screws
10 M6 flat washers
7 expansion plugs (2
spares)
5 self-tapping screws
1 user manual
1 warranty
1 certificate
1 AC output connector
Contents of the packaging
Carefully check the contents of the packaging before installation, making sure that no element inside the packaging is missing or damaged. The package will contain the following components:
15 / 61
Identification: MD-AL-GI-00 Rev. 4.0 of 31.01.18 - Application: GID
Manual of 07/06/2019 Rev. 2.1 “User Manual for 1.1K-3K TL”
No.
Tool
Function
1
Drill
Recommended drill bit: 6 mm
To drill holes in the wall for
fixing the bracket
2 Screwdriver
To screw and unscrew screws for
the various connections
3 Wire stripping tool
To prepare the cables for wiring
4
Adjustable spanner (opening
greater than 32 mm)
To tighten the bolts
5 4 mm Allen key
To screw the inverter to the wall-
mounting bracket and to open
the front cover of the inverter
6 RJ45 crimping tool
To crimp the RJ45 connectors for
the communication cables
7 Rubber hammer
To insert the expansion plugs
into the wall holes
8 MC4 removal tool
To remove the DC connectors
from the inverter
9 Diagonal pliers
To cut and tighten the cable ends
3.3. Installation tools
The following tools are required for installation of the inverter and electrical connections; therefore, they must be prepared before installation.
16 / 61
Identification: MD-AL-GI-00 Rev. 4.0 of 31.01.18 - Application: GID
Manual of 07/06/2019 Rev. 2.1 “User Manual for 1.1K-3K TL”
10 Wire stripping tool
To remove the outer sheath of
the cables
11 Cable cutter
To cut the power cables
12 Crimping tool
To crimp the power cables
13 Multi-meter
To check the voltage and current
values
14 Marking pen
To mark the wall for better fixing
precision
15 Measuring tape
To measure the distances
16
Level
To make sure the bracket is level
17 ESD gloves
Protective clothing
18 Safety goggles
Protective clothing
19 Protection mask
Protective clothing
17 / 61
Identification: MD-AL-GI-00 Rev. 4.0 of 31.01.18 - Application: GID
Manual of 07/06/2019 Rev. 2.1 “User Manual for 1.1K-3K TL”
3.4. Installation position
Choose an appropriate installation location for the inverter. Follow the requirements below to determine the installation position.
Figure 8 – Requirements for installing a single inverter
18 / 61
Identification: MD-AL-GI-00 Rev. 4.0 of 31.01.18 - Application: GID
Manual of 07/06/2019 Rev. 2.1 “User Manual for 1.1K-3K TL”
Figure 9 – Requirements for installing multiple inverters
For safety reasons, ZCS Spa and/or its partners may not carry out any technical repairs or maintenance work, or move the inverter from and to the ground, if it is installed at a height of more than 180 cm from the ground. Inverters installed at higher heights must be moved to the ground before they can be repaired or serviced.
3.5. Moving the 1.1K-3K TL inverter
This section describes how to move the inverter correctly
1) Open the packaging and remove the protective cover in polystyrene, insert your hands into the slots on
both sides of the inverter and take a hold of it, as shown in figures 10 and 11.
Figure 10 – Removing the polystyrene protections
19 / 61
Loading...
+ 42 hidden pages
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
