DELUXE FOLDING
ALUMINIUM
ZT-600-710
WHEELCHAIR
USER MANUAL
Please ensure that this manual is read and understood
before using the wheelchair
Z-Tec Mobility
Unit 1B Albion Works, Moor Street, Brierley Hill, West Midlands DY5 3SZ
Available Models:
ZT-600-710-SP16 (Self-Propelled with 41cm seat width)
ZT-600-710-SP18 (Self-Propelled with 46cm seat width)
ZT-600-710-TR16 (Transit with 41cm seat width)
ZT-600-710-TR18 (Transit with 46cm seat width)
•
1. Maximum weight capacity 120KG
•
2. Seat width 41cm and 46cm
•
3. Frame colour silver
•
4. Upholstery colour black
•
5. Seat cushion attached to seat with Velcro strips
•
6. Both heel strap and calf strap on footrests
•
7. 41cm solid rear wheels
•
8. Storage pocket in back upholstery
•
9. Seat Belt
•
10. Half folding backrest
•
1. Maximum weight capacity 120KG
•
2. Seat width 41cm and 46cm
•
3. Frame colour silver
•
4. Upholstery colour black
•
5. Seat cushion attached to seat with Velcro strips
•
6. Both heel strap and calf strap on footrests
•
7. Quick Release 56cm solid rear wheels
•
8. Storage pocket in back upholstery
•
9. Seat belt
•
10. Half folding backrest
Self-propelled
M o b i l i t y F o r L i f e
Transit
Introduction
These wheelchairs have been designed for persons with limited or no personal
mobility for transport only.
This user’s manual is compiled from the latest specifications and product information available at the time of publication. We reserve the right to make
changes as they become necessary. Any changes to our products may cause
slight variations between the illustrations and explanations in this manual and
the product you have purchased.
Safety Tips
•
The engineering and construction of this wheelchair have been designed to
provide maximum safety.
•
International safety standards currently in force have either been fulfilled
or exceeded. Nevertheless users may put themselves at risk by improperly
using their wheelchairs.
•
The wheelchair is designed to be used by a single person only.
•
For your own safety the following guidelines must be observed.
•
Unprofessional or incorrect adaptation or adjustment work could increase
the risk of accidents.
•
Be careful during your first ride in this wheelchair.
•
Get to know your wheelchair.
•
Practice using your wheelchair on level ground as well as going up and
down hill.
•
DO NOT attempt to reach objects if you have to pick them up from the
floor by reaching down between your knees.
•
DO NOT attempt to reach objects if you have to move forward in the seat.
•
DO NOT operate on roads or highways.
•
DO NOT operate on an incline if covered in ice or a film of water or oil.
•
DO NOT use the footplate as a platform when getting in or out of the
wheelchair.
•
DO NOT stand on the frame of the wheelchair.
SAFETY TIPS
Regular checks before use
Please check the following before each use:
•
Quick release axles on the rear wheels
•
Tyres and brakes. Brakes will not function properly if the tyres are worn
or damaged, or if the gap between the tyre and brake is too big.
•
The maximum user weight is 120kg. The wheelchair should be used exclusively to transport one person at a time in the seat. Any other use beyond this limit is in violation of safety regulations.
•
Users should not sit in the wheelchair whilst riding in any means of transport.
Parts Description
Flip up Armrest
Swing away Footrest
release lever
Flip-up Footplate
Solid front castors
Quick Release 56cm rear
wheel with solid tyres
(Self-propelled) & Fixed
41cm rear wheels with solid
tyres (Transit)
Parking Brake
Attendant Handbrake
Cross brace
Self-propelled model shown
41cm & 46cm Seat widths
