CAPTURE
THE MAGIC
Z986DL
USER
MANUAL
Z079584508304
ZTEUSA.COM
About This Manual
Thank you for choosing this ZTE mobile device. In order to keep your device in its best condition,
please read this manual and keep it for future reference.
Copyright © 2017 ZTE CORPORATION
All rights reserved.
No part of this publication may be quoted, reproduced, translated or used in any form or by any
means, electronic or mechanical, including photocopying and microlm, without the prior written
permission of ZTE Corporation.
Notice
ZTE Corporation reserves the right to make modications on print errors or update specications in
this manual without prior notice. This manual has been designed with the utmost care to ensure the
accuracy of its content. However, all statements, information and recommendations contained therein
do not constitute a warranty of any kind, either expressed or implied. Please refer to chapter For Your
Safety to be sure to use your phone properly and safely.
We oer self-service for our smart terminal device users. Please visit the ZTE ocial website
(at www.zteusa.com) for more information on self-service and supported product models. Information
on the website takes precedence.
Disclaimer
ZTE Corporation expressly disclaims any liability for faults and damages caused by unauthorized
modications of the software.
Images and screenshots used in this manual may dier from the actual product. Content in this
manual may dier from the actual product or software.
Trademarks
ZTE, MAX, and the ZTE logos are trademarks of ZTE Corporation.
LTE is a trademark of ETSI.
Google and Android are trademarks of Google, Inc.
The Bluetooth® trademark and logos are owned by the Bluetooth SIG, Inc.
and any use of such trademarks by ZTE Corporation is under license.
Manufactured under license from Dolby Laboratories. Dolby, Dolby Audio,
and the double-D symbol are trademarks of Dolby Laboratories.
The microSDXC™ logo is a trademark of SD-3C, LLC.
Qualcomm and Snapdragon are trademarks of Qualcomm Incorporated,
registered in the United States and other countries. Used with permission.
Other trademarks and trade names are the property of their respective owners.
Edition Time: February 2017
Table of Contents
Getting Started ..................5
Installing the Nano-SIM Card and a
microSDXC Card .......................5
Charging the Battery ...................5
Extending the Battery Life ..............6
Powering Your Phone On/O ...........6
Setting Up Your Phone for the
First Time ..............................7
Locking/Unlocking the Screen
and Keys ...............................7
Using the Touch Screen ................8
Getting to Know Your Phone ...........9
Getting to Know the Home Screen .....11
Personalizing ...................13
Changing the System Language .......13
Setting the Date and Time .............13
Changing the Ringtone and
Notication Sound ....................13
Turning System Sounds On/O ........14
Adjusting Volumes ....................14
Switching to Silent or Vibration Mode ..14
Using Do Not Disturb Mode ...........14
Applying New Wallpapers .............15
Setting the Theme ....................16
Setting the Home Screen
Transition Eect .......................16
Changing the Screen Brightness .......16
Protecting Your Phone With
Screen Locks ..........................16
Using Your Fingerprint ................17
Protecting Your Phone With
Screen Pinning ........................18
Knowing the Basics .............20
Monitoring the Phone Status ..........20
Managing Notications ...............21
Managing Shortcuts and Widgets .....24
Organizing With Folders ...............25
Rearranging the Primary Shortcuts ....25
Entering Text. . . . . . . . . . . . . . . . . . . . . . . . . .26
Changing Input Methods ..............26
TouchPal Keyboard ....................26
Google™ Keyboard ....................30
Google Voice Typing ..................32
Editing Text ...........................32
Opening and Switching Apps .........33
Connecting to Networks
and Devices .....................35
Connecting to Mobile Networks .......35
Connecting to Wi-Fi® ..................35
Connecting to Bluetooth® Devices .....38
Connecting to Your Computer
via USB ...............................40
1
1
Table of ContentsTable of Contents
Using the microSDXC Card as
Portable Storage ......................41
Using USB On-the-Go (OTG) ...........42
Sharing Your Mobile Data
Connection ...........................42
Connecting to Virtual Private
Networks .............................43
Phone Calls ..................... 45
Placing and Ending Calls ..............45
Answering or Rejecting Calls ..........45
Working With the Call History .........46
Calling Your Contacts .................47
Checking Voicemail ...................47
Using Options During a Call ...........48
Managing Multi-party Calls ............48
Adjusting Your Call Settings ...........49
Contacts ........................ 55
Checking Contact Details ..............55
Adding a New Contact ................55
Setting Up Your Own Prole ...........55
Importing, Exporting, and
Sharing Contacts ......................56
Working With Favorite Contacts .......56
Working With Groups .................57
Searching for a Contact ...............58
Editing Contacts ......................58
2
Accounts ........................60
Adding or Removing Accounts ........60
Conguring Account Sync .............60
Email ............................ 62
Setting Up the First Email Account .....62
Checking Your Emails .................62
Responding to an Email ...............62
Writing and Sending an Email .........63
Adding a Signature to Your Emails .....64
Adding and Editing Email Accounts ....64
Changing General Email Settings ......65
Messaging ......................66
Opening the Messaging Screen. . . . . . . . 66
Sending a Message ...................66
Replying to a Message ................67
Forwarding a Message ................67
Deleting Messages or Threads .........67
Copying a Message ...................68
Changing Message Settings ...........68
Calendar ........................69
Viewing Your Calendars and Events ....69
Creating an Event .....................70
Editing, Deleting, or Sharing an Event ..70
Changing Calendar Settings ...........70
Searching an Event ....................71
Browser .........................72
Opening the Browser .................72
Setting the Home Page ................72
Using Multiple Browser Windows ......72
Downloading Files ....................73
Changing Browser Settings ............73
Camera .........................74
Capturing a Photo ....................74
Using Dual-Camera Mode .............75
Using Manual Camera Mode ..........76
Using Other Camera Modes ...........76
Recording a Video .....................77
Customizing Camera and
Video Settings ........................77
Gallery .......................... 79
Opening the Gallery ..................79
Working With Albums .................79
Working With Pictures .................80
Playing Videos ........................82
Music ...........................83
Viewing Your Music Library ............83
Playing Music .........................84
Managing Playlists ....................85
Video Player ....................86
Opening the Video Library ............86
Playing and Controlling Videos ........86
Managing Video Files .................87
Sound Recorder ................. 89
Recording a Voice Memo ..............89
Playing a Voice Memo .................89
More Apps ......................90
Calculator ............................90
Clock .................................90
Dolby Audio™ .........................91
Downloads ...........................91
File Manager ..........................91
Wi-Fi Utility ...........................92
Google™ Apps ........................92
Settings ......................... 94
Wireless & Networks ..................94
Personal ..............................95
Device ................................99
Accounts ............................102
System ..............................102
Upgrading the Phone
Software .......................103
3
Table of Contents
Getting Started
Troubleshooting ...............104
For Your Safety .................108
General Safety .......................108
Radio Frequency (RF) Energy .........109
FCC Regulations .....................110
Hearing Aid Compatibility (HAC)
Regulations for Mobile Phones .......111
Distraction ...........................112
Product Handling ....................112
Electrical Safety ......................115
Radio Frequency Interference ........117
Explosive Environments ..............118
Specications ..................119
4
Installing the Nano-SIM Card (Included) and a
microSDXC Card (Not Included)
Power o your phone before installing or removing the
nano-SIM card or the microSDXC card. Unmount the microSDXC
card before removing it (see Connecting to Networks and Devices –
Using the microSDXC Card as Portable Storage).
NOTE: Your phone will come with the nano-SIM card already installed.
WARNING! To avoid damage to the phone,
do not use any other kind of SIM cards, or any
non-standard nano-SIM card cut from a SIM
card. You can get a standard nano-SIM card
from your service provider.
1. Insert the tip of the tray eject tool into the hole next to the
card tray and pull the tray out.
2. Place the nano-SIM card and the microSDXC card on the tray, as shown.
3. Carefully slide the tray back into place.
Charging the Battery
Your phone’s battery should have enough power for the phone to
turn on, nd a signal, and make a few calls. You should fully charge
the battery as soon as possible.
Do not change the built-in rechargeable battery in your phone by
yourself. The battery can only be changed by ZTE or a ZTE authorized
service provider.
WARNINGS!
• Use only ZTE-approved chargers and cables. The use of unapproved
accessories could damage your phone or cause the battery to explode.
• Do not remove the back cover. The battery is not removable. Removal may
cause re or explosion.
5
Getting Started
Getting Started
NOTE: Use the USB Type-C™ charger that comes in-box with your phone to charge the
battery. It’s specially built to support Qualcomm® Quick Charge™ 2.0.
1.
Connect the adapter to the charging port.
2. Connect the charger to a standard AC wall outlet. If the phone is on, you’ll see a
charging icon, such as or , appear in the Status Bar.
3. Disconnect the charger when the battery is fully charged.
NOTE: If the battery is extremely low, you may be unable to power on the phone even when
it is being charged. In this case, try again after charging the phone for at least 20 minutes.
Contact customer service if you still cannot power on the phone after prolonged charging.
This device contains a nonremovable battery. Attempting to remove will void
your warranty and could cause serious injury. Do not damage, alter, or try to
remove the battery.
Extending the Battery Life
Active applications, screen brightness levels, Bluetooth and Wi-Fi usage, and GPS
functionality can drain your battery. You can follow the helpful tips below to conserve
your battery power:
• Reduce the screen backlight time.
• Lower the screen brightness.
• Turn auto-sync, Wi-Fi, and Bluetooth o when not in use.
• Disable the GPS function when not in use. Most applications using this function
will periodically query the GPS satellites for your current location; each query drains
your battery.
Powering Your Phone On/O
• Press and hold the Power/Lock Key to turn on your phone.
6
• To turn it o, press and hold the Power/Lock Key to open the options menu. Tap
Power o > OK.
NOTE: If the phone freezes or takes too long to respond, press and hold the Power/Lock
Key for about 10 seconds to restart the phone.
Setting Up Your Phone for the First Time
When you rst power on your phone after you purchase it or reset it to factory settings
(see Settings – Device – Backup & Reset), you will need to set it up before using it. Select
the language and then follow the prompts to set up your phone.
Locking/Unlocking the Screen and Keys
Your phone allows you to quickly lock the screen and keys (put the phone into Sleep mode)
when not in use and also to turn the screen back on and unlock it when you need it.
Locking the Screen and Keys
To quickly turn the screen o and lock the keys, press the Power/Lock Key.
NOTE: To save battery power, the phone automatically turns o the screen after a certain
period of time when you leave it idle. You will still be able to receive messages and calls
while the phone screen is o.
Unlocking the Screen and Keys
1. Press the Power/Lock Key to turn the screen on.
2. Press and hold a blank area of the screen to unlock the phone, press and hold at
the bottom right to open the Camera app, or press and hold
Google voice commands. You can also double-tap a notication to open the related app.
NOTE: If you have set a ngerprint, an unlock pattern, a PIN, or a password for your
phone (see Personalizing – Protecting Your Phone With Screen Locks or Using Your
Fingerprint), you’ll need to press your nger against the sensor, draw the pattern, or enter
the PIN/password to unlock your screen.
at the bottom left to use
7
Getting Started Getting Started
Getting to Know Your Phone Using the Touch Screen
Your phone’s touch screen lets you control actions through a variety of touch gestures.
• Tap – When you want to type using the on-screen keyboard, select on-screen items
(such as application and settings icons), or press on-screen buttons, simply tap them
with your nger.
• Press and Hold – To open the available options for an item (for example, a message or
link in a web page), press and hold the item.
• Swipe or Slide – To swipe or slide means to quickly drag your nger vertically or
horizontally across the screen.
• Drag – To drag, press and hold your nger with some pressure before you start to
move your nger. While dragging, do not release your nger until you have reached
the target position.
• Pinch – In some apps (such as Maps, Browser, and Gallery), you can zoom in and out
by placing two ngers on the screen at once and pinching them together (to zoom
out) or spreading them apart (to zoom in).
• Rotate the Screen – For most screens, you can automatically change the screen
orientation from portrait to landscape by turning the phone sideways.
NOTES:
• The Auto-rotate screen option needs to be turned on for the screen orientation
to automatically change. Press the Home Key > > Settings > Display >
Auto-rotate screen.
• You can also access the screen rotation control by sliding down the Status Bar twice
and tapping Auto-rotate or Portrait.
8 9
3.5 mm
Headset
Jack
Microphone
Nano-SIM/
microSDXC
Card Tray
Touch
Screen
Back Key*
* You can switch the positions of the Back Key and Recent Apps Key. Press the Home Key >
> Settings > Navigation key and select one option.
Earpiece
Charging/USB
Type-C Port
Proximity &
Light Sensor
Front
Camera
Volume
Up/Down
Key
Home
Key
Recent
Apps
Key*
Dual Flash
Power/
Lock Key
Dual-Lens
Camera
Speaker
Fingerprint
Sensor
Microphone
Getting Started Getting Started
Key Functions
Key Description
Press and hold to turn Airplane mode on or o, restart, or to
Power/Lock Key
Home Key
Recent
Apps Key
Back Key Press to go to the previous screen.
Volume Up/
Down Key
power o.
Press to change your phone to Sleep mode.
Press to wake up your phone.
Press to return to the home screen from any application or screen.
Press and hold to access Google Now™.
Press to see recently used applications.
Press or hold to turn the volume up or down.
Getting to Know the Home Screen
The home screen is the starting point for your phone’s applications, functions, and menus.
You can customize your home screen by adding application icons, shortcuts, folders,
widgets, and more.
Status &
Widget
Shortcut
Primary
Shortcuts
Notications
Wallpaper
Folder
Extended Home Screen Panels
Your home screen is extendable, providing more space for shortcuts, widgets, and more.
Simply swipe left or right on the home screen to see the extended panels. You can add or
remove home screen panels, or adjust their order.
10 11
Getting Started
Personalizing
To add a new home screen panel:
1. Press the Home Key > , or press and hold an empty area of the home screen and
select Widgets.
2. Press and hold an application icon or a widget and drag it to the right edge of the
screen to create a new home screen panel and put the icon or widget on it.
To delete a home screen panel:
1. Press and hold an empty area of the home screen and slide left or right to view the
home screen thumbnails.
2. Tap on the top right corner of a thumbnail.
3. Tap OK. The items on the panel will also be removed.
NOTES:
• A home screen panel cannot be left empty. If the icon, widget, or folder is the only
item on the current home screen panel, the panel will be deleted as you remove
the item.
• When there are only three home screen panels, you cannot delete any of them.
To adjust the order of a home screen panel:
1. Press and hold an empty area of the home screen and slide left or right to view
the home screen thumbnails.
2. Press and hold a thumbnail and drag it left or right to the place you need.
NOTE: Tap at the bottom of a home screen thumbnail to set it as the main
home screen.
12 13
Changing the System Language
1. Press the Home Key > > Settings > Language & input > Language.
2. Select the language you need.
Setting the Date and Time
1. Press the Home Key > > Settings > Date & time.
2. Set the date, time, time zone, and time format.
• To adjust the date and time automatically, tap to turn on Automatic date & time.
• To adjust the date and time manually, tap to turn o Automatic date & time and
tap Set date / Set time to change the date and time.
• To adjust the time zone automatically, tap to turn on Automatic time zone.
• To adjust the time zone manually, tap to turn o Automatic time zone and tap
Select time zone to set the correct time zone.
•
To adjust the time format,
tap to turn on
Use 24-hour format.
Changing the Ringtone and Notication Sound
You can quickly customize the default ringtone for incoming calls and the default
notication sound.
1. Press the Home Key > > Settings > Sound & notication.
2. Tap Phone ringtone or Default notication ringtone.
3. Scroll through the list and select the ringtone you’d like to use.
4. Tap OK.
NOTE: See Contacts – Editing Contacts – Setting a Ringtone for a Contact for how to assign
a special ringtone to an individual contact.
PersonalizingPersonalizing
Turning System Sounds On/O
1. Press the Home Key > > Settings > Sound & notication > Other sounds.
2. Tap the switch beside each option to turn it on or o.
Adjusting Volumes
1. Press the Home Key > > Settings > Sound & notication.
2. Drag the sliders below Media volume, Alarm volume, Ring volume, and
Notication volume to adjust the volume for each type of audio.
NOTE: You can adjust the media volume when a media application is in use by pressing
the Volume Up/Down Key. If no media application is active, press the Volume Up/Down
Key to adjust ringtone volume (or the earpiece volume during a call).
Switching to Silent or Vibration Mode
You can set the phone to silent or vibration mode by using one of the following methods.
• Press the Volume Up/Down Key when no media application is active to show the
volume management window. Drag the slider to the left or keep pressing the Volume
Down Key to switch the phone to vibration mode. Press the key again in vibration
mode to switch the phone to silent mode.
• Swipe down from the top of the screen to open the Notication Panel and drag
the panel downward. Tap Sound or Vibrate to switch the phone to vibration or
silent mode.
• Press the Home Key > > Settings > Sound & notication > Notication mode
and select Vibrate or Mute to switch to vibration or silent mode.
NOTE: To restore normal sound settings, press or hold the Volume Up Key.
Using Do Not Disturb Mode
You can limit interruptions with Do not disturb mode. This mode silences your phone so
that it doesn’t make sounds or vibrate when you don’t want it to.
Turning on Do Not Disturb Mode
1. Press the Home Key > > Settings > Sound & notication > Do not disturb.
2. Tap Do not disturb and select Always or Scheduled.
3. Set the detailed settings.
• If you have selected Scheduled, set the days and start/end time you’d like your
phone to be in Do not disturb mode.
• Tap Disturb rules to choose if you’d like to allow certain notications or not.
– Priority only: Only notications you have marked as priority are allowed.
– Alarms only: Only alarms are allowed.
– Total silence: No notications are allowed.
• If you have allowed priority interruptions, you can customize the types of allowed
sounds or vibration under Priority interruptions.
NOTE: To turn o Do not disturb mode quickly, press the Volume Up/Down Key and
then tap END NOW.
Applying New Wallpapers
You can set the wallpaper for the home screen or lock screen.
1. Press and hold an empty place on the home screen.
2. Tap Wallpapers.
3. Swipe left or right on the wallpaper panel to select a wallpaper, or tap GALLERY or
LIVE WALLPAPER to choose the image or animation you want to use as the wallpaper.
4. For Gallery images, tap , , or and tap to set the image as the lock screen
wallpaper, the home screen wallpaper, or both.
NOTES:
• In addition, you can press the Home Key > > Settings > Display > Wallpaper
to pick an image from Gallery, Photos, or Wallpapers, or an animation from
Live Wallpapers.
• Some cropping may be needed for Gallery and Photos images.
1514
PersonalizingPersonalizing
Setting the Theme
1. Press and hold an empty place on the home screen.
2. Tap Themes.
3. Tap a theme to select it.
Setting the Home Screen Transition Eect
1. Press and hold an empty place on the home screen.
2. Tap Eects.
3. Tap an eect and the phone will demonstrate how it works. When you have found one
you like, press the Home Key to exit.
Changing the Screen Brightness
1. Press the Home Key > > Settings > Display > Brightness level.
2. Drag the slider to manually adjust the screen brightness.
NOTE: With the proximity and light sensor, your phone can automatically adjust the
screen brightness for available light. Tap Adaptive brightness in the Display settings
screen to turn the feature on or o.
Protecting Your Phone With Screen Locks
You can protect your phone by creating a screen lock. When enabled, you can press and
hold a blank area on the home screen, and then draw a pattern or enter a numeric PIN or
password to unlock the phone’s screen and keys.
1. Press the Home Key > > Settings > Security.
2. Tap Screen lock.
3. Tap None, Long press, Pattern, PIN, or Password.
• Tap None to disable screen lock protection.
• Tap Long press to enable screen lock and allow unlocking with a “press and hold”
gesture. You can unlock the screen by tapping and holding a blank area on the
lock screen.
16 17
• Tap Pattern to create a pattern that you must draw to unlock the screen.
• Tap PIN or Password to set a numeric PIN or a password that you must enter to
unlock the screen.
4. For Pattern, PIN, or Password lock, select whether to protect your phone by requiring
your pattern, PIN, or password before it starts up. Tap CONTINUE.
NOTE: When this feature is enabled, your phone cannot receive calls, messages, or
notications until it starts up.
5. For Pattern, PIN, or Password lock, select how you would like notications and their
contents to show when the phone is locked, then tap DONE.
NOTES:
• Screen lock options are listed in the approximate order of the strength of their security,
starting with None and Long press, which provide no security. A pattern provides
minimal security, although it can be more convenient than the stronger options.
• Remember the pattern, PIN, or password you set. Otherwise, you will have to upgrade
the phone software to use the phone (see Upgrading the Phone Software).
Using Your Fingerprint
With the ngerprint sensor on the back of your phone, you can register up to ve
ngerprints and use them to unlock the phone, or simply press the ngerprint sensor to
take photos, answer calls, or open a bound app when the screen is o or locked.
NOTE: The ngerprint feature is available only when a screen lock (Pattern, PIN, or
Password) is enabled. When the screen lock is reset to None or Long press, all registered
ngerprints are erased.
Registering a Fingerprint
1. Press the Home Key > > Settings > Security > Fingerprint.
2. Enter the screen lock pattern, PIN, or password you set. If you haven’t set a screen lock,
follow the prompts to set it.
3. Tap Register or Fingerprint > Add ngerprint.
Personalizing
Personalizing
4. Follow the prompts to record the center and edges of a nger.
5. Tap OK.
NOTE: Tap an existing ngerprint record to change its name or delete it.
Setting Fingerprint Actions
1. Press the Home Key > > Settings > Security > Fingerprint.
2. Enter the screen lock pattern, PIN, or password you set.
3. Tap the switches to adjust the following settings:
• Wake up and unlock your phone: Press the ngerprint sensor to wake up the
phone and unlock it with a registered ngerprint.
• Quick-open app: Press the ngerprint sensor to open the bound app when the
screen is o or locked with a registered ngerprint.
• Take photo: Press the ngerprint sensor to take a photo when the Camera app is
open. No ngerprint verication is needed.
• Answer call: Press the ngerprint sensor to answer incoming calls. No ngerprint
verication is needed.
Pinning a Screen
1. Ensure that screen pinning is turned on.
2. Open the app you want to keep in view.
3. Press the Recent Apps Key.
4. If there are many app tabs, swipe up to nd on the front-most tab.
5. Tap .
Unpinning the Screen
1. To unpin the screen and return to normal use, press and hold the Recent Apps Key.
2. If you have checked Ask for unlock pattern/PIN/password before unpinning when
pinning the screen, press and hold on the lock screen and draw the pattern or enter
the PIN/password.
Protecting Your Phone With Screen Pinning
You can use the screen pinning feature to keep an app in view, so others cannot switch to
other apps or access your personal information.
Turning on Screen Pinning
1. Press the Home Key > > Settings > Security > Screen pinning.
2. Tap the On/O switch.
3. If you have set a screen lock, you can tap Ask for unlock pattern/PIN/password
before unpinning. You will need to draw the pattern or enter the PIN/password to
unpin the screen.
18 19
Knowing the Basics
Knowing the Basics
Monitoring the Phone Status
The Status Bar at the top of the home screen provides phone and service status icons on
the right side. Below are some of the icons you may see.
Indicators and Icons
Indicator What it means
2G connected
/
4G / 3G connected
/
4G LTE™ connected
Do not disturb mode on
(Alarms only or Priority only)
Do not disturb mode on
(Total silence)
Ringer o
Vibration on
Battery low
Battery full
Battery charging
/
Alarm set
20 21
Indicator What it means
No signal
Signal strength
Airplane mode
Bluetooth on
Connected to a Wi-Fi
network
Wi-Fi in use
Portable Wi-Fi hotspot is on
Mobile data in use
Speaker on
Phone microphone o
GPS on
Managing Notications
The Status Bar at the top of the home screen provides notication icons on the left side.
Below are some of the icons you may see.
Indicators and Icons
Indicator What it means
New SMS / MMS
/
New email message(s)
/
New Gmail message(s)
/
Missed call
Call in progress / Call on hold
/
microSDXC card mounted
Indicator What it means
Song playing
/
Upcoming event
New Wi-Fi network detected
Downloading / sending data
/
USB connected
Wired headset connected
Knowing the Basics
Knowing the Basics
Opening/Closing the Notication Panel
Notications report the arrival of new messages, calendar events, and alarms, as well as
ongoing events. You can open the Notication Panel to view the details of notications.
• To open the Notication Panel, swipe your nger down from the top of the screen.
• To close the Notication Panel, swipe your nger up
press the Back Key.
from the bottom of the screen or
Responding to or Removing a Notication
In the Notication Panel, you can respond to a notication or remove the notications.
The Notication Panel also supports expandable notications that let you perform
additional actions right from the notication itself.
• To respond to a notication, tap it.
• Slide down with one nger to expand certain notications. You can also swipe two
ngers vertically or pinch-zoom to expand or collapse certain notications.
• To remove a notication, swipe it right.
• To block notications from an app, swipe the app's notication left and tap . The
notications of some apps cannot be blocked.
• To remove all notications, tap .
• To manage notications you have received, press and hold a notication to identify
the application that created it. You can then tap and turn on/o some or all of the
following settings:
– Block all: Hide future notications from this app.
– Treat as priority: Show notications from this app when Do not disturb mode is
set to Priority only.
– Allow peeking: Allow this app to show certain notications briey in the
current screen.
– Hide sensitive content: Hide content in this app’s notications when the phone
is locked.
• Most apps that send notications, such as Gmail, have notication settings that you
can adjust.
NOTE: If you turn o notications for an app, you may miss its important alerts and
updates. The notications of some apps cannot be turned o.
Using Quick Settings
The Quick Settings in the Notication Panel make it convenient to view or change the
most common settings for your phone.
Swipe down with two ngers from the top of the screen, or open the Notication Panel
and drag the panel downward to view the following Quick Settings.
• Auto-rotate/Portrait: Tap to turn on or o the auto-rotate screen feature.
• Battery Saver: Tap to turn on or o Battery Saver. Press and hold to access the Battery
saver menu. See Settings – Device – Battery.
• Sound/Vibrate/Silent: Tap to switch between sound, vibration, and silent mode. See
Personalizing – Switching to Silent or Vibration Mode.
•
Hotspot: Tap to enable the mobile hotspot feature and create a portable Wi-Fi hotspot.
Press and hold to access the Wi-Fi hotspot menu. See Connecting to Networks and
Devices – Sharing Your Mobile Data Connection.
• Airplane mode: Tap to turn on or o airplane mode.
• Flashlight: Tap to turn on or o the ashlight.
• Sync: Tap to turn on or o auto-syncing of accounts data. Press and hold to access the
Accounts menu. See Accounts or Settings – Accounts.
• Do not disturb/Priority only/Alarms only/Total silence: Tap to access the Do not
disturb menu and change its settings. See Personalizing – Using Do Not Disturb Mode.
• Bluetooth: Tap to turn on or o Bluetooth. Press and hold to access the Bluetooth menu.
See Connecting to Networks and Devices – Connecting to Bluetooth Devices.
• Wi-Fi: Tap to turn on or o Wi-Fi. Press and hold to access the Wi-Fi menu. See
Connecting to Networks and Devices – Connecting to Wi-Fi.
2322
Knowing the Basics
Knowing the Basics
• Data: Tap to enable or disable data access over the mobile network. Press and hold to
access the Data usage menu. See Settings – Wireless and Networks – Data Usage.
• Location: Tap to turn location services on or o. Press and hold to access the Location
menu. See Settings – Device – Location.
• Brightness: Drag the brightness slider to adjust the screen brightness. Check AUTO to
make the phone adjust the brightness automatically.
NOTE: In the Quick Settings screen, tap at the top to access the Settings menu; tap
to view your prole in the Contacts app; tap to change control switch position.
Managing Shortcuts and Widgets
Adding Shortcuts and Widgets
1. Press the Home Key > to add shortcuts.
Or, to add widgets, press and hold an empty area of the home screen and
select Widgets.
2. Slide to browse the available applications or widgets.
3. Press and hold a widget or an application icon and drag it to a home screen panel.
NOTE: While holding the item, you can drag it to the right edge of the screen to create a
new home screen panel and put the item on it.
Moving Shortcuts or Widgets
1. Press and hold a widget or shortcut on the home screen.
2. Drag it to the place you need.
Removing Shortcuts or Widgets
1. Press and hold a widget or shortcut on the home screen.
2. Drag it to to remove it.
24
Adjusting Widget Size
1. Press and hold a widget on the home screen and then release it.
2. An outline appears around the widget. Drag the outline to resize the widget.
NOTE: Not all widgets can be resized.
Organizing With Folders
You can create folders on the home screen and add several shortcuts to a folder.
You can move or remove folders the same way as moving or removing shortcuts.
1. On the home screen, press and hold the shortcut you want to add into a folder.
2. Drag the shortcut to . A new folder will be created, and the shortcut is added into
the folder.
3. To add more shortcuts into the folder, press and hold each shortcut and drag it over
the folder before releasing it.
4. To remove a shortcut from a folder, tap the folder to open it. Press and hold the
shortcut and drag it to the home screen.
NOTES:
• Tap the folder and then tap the name eld to rename the folder.
• Drag the folder to to delete the folder and replace its shortcuts on the last
home screen.
Rearranging the Primary Shortcuts
The home screen includes a customizable primary shortcuts area at the bottom of all home
screens. You can keep up to four items in the primary shortcuts area. Drag shortcuts or
folders in or out of the area to rearrange the area.
25
Knowing the Basics
Knowing the Basics
Entering Text
You can enter text using the on-screen keyboard. Some apps open it automatically. In
others, you open it by tapping where you want to type. You can press the Back Key to
hide the on-screen keyboard. You can also enter text by speaking with the Google voice
typing feature.
Enabling or Disabling Input Methods
1. Press the Home Key > > Settings > Language & input.
2. Tap Current Keyboard > CHOOSE KEYBOARDS.
3. Tap a keyboard in the list to enable/disable it as an option for entering text.
NOTE: Some default input methods may not be disabled.
Changing Input Methods
1. When you use the on-screen keyboard to enter text, the icon appears in the
Status Bar.
NOTE: The icon appears only when more than one input method is installed and
enabled for use.
2. Open the Notication Panel and tap Change keyboard.
3. Select the input method you need.
TouchPal Keyboard
The TouchPal keyboard oers three layouts: FULL, PHONEPAD, and T+. You can tap to
select a layout or an input language.
You can also use Curve® and Wave™ to speed up text input by replacing the key tapping
operation with a tracing gesture where you move your nger from letter to letter without
lifting the nger until you reach the end of the word.
26
The FULL Layout
The FULL layout oers an input experience similar to a computer keyboard.
• The alphabetic keys: Tap the keys to enter letters. You can also press and hold a key
and slide to choose more characters.
• The capital key: Tap to use uppercase. Double tap to lock uppercase. This
key also changes to indicate the current case you are using: for lowercase, for
uppercase, and when locked in uppercase.
•
Word prediction: Press and hold and tap the Prediction switch to turn o or on .
• Pre-dened texts: Tap to enter digits, symbols, and more. You can tap the arrow
keys to turn pages, or tap to go back to the alphabetic keys. Slide up on the space
key or tap to enter emojis and emoticons.
• The delete key: Tap to delete text before the cursor. You can also press and hold
the key to quickly delete multiple characters, or slide left on the key to delete a
whole word.
• Voice input: Press and hold the space bar and speak into the microphone.
• More options: Tap to access the quick settings of TouchPal keyboard, use voice
input, edit text, resize the keyboard, change keyboard themes, and more.
27
Knowing the Basics Knowing the Basics
The PHONEPAD Layout
The PHONEPAD layout is similar to a phone pad.
Tap an alphabetic key repeatedly until the desired letter
or number appears. Press and hold the key and slide left
or right to choose the text you need.
If word prediction is enabled, just tap the keys once and
choose the right word.
Start of the word
End of the word
The T+ Layout
If word prediction is disabled, tap to enter the left letter
on the key. Double tap to enter the right letter/symbol
on the key. Press and hold a key and slide left or right
to choose more letters and symbols.
If word prediction is enabled, just tap the keys and
choose the right word.
Curve - Word Gesture
Curve - Word gesture allows you to enter text by sliding your nger on the screen from
letter to letter to enter each word.
To enable and use Curve - Word gesture:
1. On the TouchPal keyboard screen, tap > Settings > Smart input and check
Curve® - Word gesture.
2. Tap > and tap inside a text eld to open the keyboard, and then tap > FULL
to switch to the FULL layout.
3. Move your nger from letter to letter on the keyboard to trace a word without lifting
the nger until you reach the end of the word.
NOTE: Curve - Word gesture is only available in the FULL layout.
NOTES:
• Tap to type when you want to. If you want to enter a single letter, simply tap the
key once.
• Lift your nger at the end of the word. A space is added automatically when you begin
to trace the next word.
Wave - Sentence Gesture
Wave - Sentence gesture allows you to enter words by dragging candidate words to the
space key.
To enable and use Wave - Sentence gesture:
1. On the TouchPal keyboard screen, tap > Settings > Smart input and check
Wave™ - Sentence gesture.
2. Tap > and tap inside a text eld to open the keyboard, and then tap > FULL
to switch to the FULL layout.
3. Tap or use Curve to enter the rst word. As the rst word appears on the text eld,
candidate words appear on the keyboard for you to choose from as the following word.
4. Drag the correct candidate word to the space key to add the word to the text eld.
28 29
Knowing the Basics Knowing the Basics
• Tap to delete the text before the cursor.
• Tap to select numbers and symbols. You can then tap to nd more or tap
to enter miniature icons.
• Tap to enter miniature icons such as expressions, astrological signs, and animals.
• Tap to use Google voice typing.
• Press and hold to change the input language or set up the Google Keyboard.
NOTES:
• If none of the suggested words are correct, type the word as you normally would.
• Wave - Sentence gesture is only available in the FULL layout.
Google Keyboard
The Google Keyboard provides a layout similar to a desktop computer keyboard. When
screen auto-rotation is enabled, turn the phone sideways and the keyboard will change
from portrait to landscape. The landscape keyboard is not supported in all applications.
• Press and hold and slide to to change to a smaller keyboard for easier onehanded typing. Tap / to switch to the right-hand or left-hand keyboard,
respectively. Tap to switch back to the full-sized keyboard.
Gesture Typing
The Google Keyboard supports the gesture typing feature. You use this feature to input a
word by sliding through the letters.
To enable and use gesture typing:
1. On the Google Keyboard, press and hold > Google Keyboard settings.
Or, press the Home Key > > Settings > Language & input > Google Keyboard.
2. Tap Gesture typing > Enable gesture typing if the feature is turned o.
3. Move your nger from letter to letter on the keyboard to trace a word without lifting
the nger until you reach the end of the word.
• Tap the alphabetic keys to enter letters. Press and hold some specic keys to enter
associated accented letters or numbers. For example, to enter È, press and hold and
the available accented letters and number 3 appear. Then slide to choose È.
• As you enter a word, candidates appear above the keyboard. Tap the correct one to
select it.
• Tap to use uppercase. Double-tap to lock uppercase. This key also changes color
to indicate the current case you are using.
30 31
Start of the word
End of the word
Knowing the Basics Knowing the Basics
NOTES:
• Tap when you want to. If you want to enter a single letter, go ahead and tap.
• Lift your nger at the end of the word. A space is added automatically when you begin
to input the next word.
Google Voice Typing
Google voice typing uses the Google voice recognition service to convert speech to text.
You must have a data connection on a mobile or Wi-Fi network to use it.
1.
Tap to access voice typing when you are using the Google Keyboard, or ick down
the Status Bar when entering text and tap Change keyboard > Google voice typing.
2. When you see the microphone image, speak what you want to type.
3. You can continue entering text or tap an underlined word to change or delete it.
NOTE: Say “comma,” “period,” “question mark,” “exclamation mark,” or “exclamation point”
to enter punctuation.
Input Method Settings
Choose the input method settings by pressing the Home Key > > Settings >
Language & input.
In the Keyboard & input methods section, you can set the current input method and
choose the settings for input methods.
Editing Text
• Move the insertion point: Tap where you want to type. The cursor blinks in the new
position, and a tab appears below it. Drag the tab to move the cursor.
• Select text: Press and hold or double-tap within the text. The nearest word highlights,
with a tab at each end of the selection. Drag the tabs to change the selection. Tap >
SELECT ALL to select all the text, tap SHARE and choose an option, or tap ASSIST to
open Google Now.
32 33
• Cut or copy: Select the text you want to manipulate. Then tap CUT or COPY to cut or
copy the text to the clipboard.
• Replace text with the clipboard text: Select the text you want to replace.
Then tap PASTE.
• Insert clipboard text in the text eld: Press and hold the tab below the cursor. Then
tap PASTE.
Opening and Switching Apps
Opening an App
1. Press the Home Key > .
2. Slide up or down on the screen and tap an app to open it.
NOTE: Drag the slider on the right side of the screen to the initial letter of the app you
need, or tap the search box at the top to search for apps.
Switching Between Recently Opened Apps
1. Press the Recent Apps Key. A list of the names and thumbnails of apps you’ve recently
used opens. If you’ve been using more apps recently than can t on the screen, you
can scroll the list up and down.
2. Tap a thumbnail to open that app.
NOTE: You can swipe a thumbnail left or right or tap on the thumbnail to remove it
from the list. Tap Clear all to remove all thumbnails.
Knowing the Basics
Connecting to Networks and Devices
Uninstalling or Disabling an Application
1. Press the Home Key > to open the application list screen.
2.
Press and hold an application icon and drag the icon to or at the top of the screen.
3. Tap OK to uninstall or disable the app.
NOTES:
• Preinstalled apps cannot be uninstalled, and not all apps can be disabled.
• To nd the disabled applications, press the Home Key > > Settings > Apps. Tap
All apps and select Disabled. You can then tap an application and tap ENABLE to
enable it.
Connecting to Mobile Networks
Controlling Mobile Data Use
To enable or disable data access:
1. Press the Home Key > > Settings > Data usage.
2. Slide the Mobile data switch to enable or disable mobile data use.
To get data services when roaming:
1.
Press the Home Key > > Settings > Mobile networks.
2. Slide the Data roaming switch to enable or disable roaming.
NOTE: Data roaming may incur signicant roaming charges.
Setting Access Point Names
You can use the default Access Point Names (APNs) to connect to the Internet. To add a
new APN, you may need to contact your service provider for the required information.
1. Press the Home Key > > Settings > Mobile networks > Access Point Names.
2. Tap .
3. Tap each item to enter the required information.
4. Tap > Save.
NOTE: To set the APN to default settings, tap > Reset to default > CONTINUE.
Connecting to Wi-Fi
Wi-Fi is a wireless networking technology that can provide Internet access at distances of
up to 300 feet (100 meters), depending on the Wi-Fi router and your surroundings.
Turning Wi-Fi On and Connecting to a Wi-Fi Network
1. Press the Home Key > > Settings > Wi-Fi.
2. Slide the Wi-Fi switch to the On position to turn on Wi-Fi.
34 35
3. Tap a network name to connect to it.
Connecting to Networks and DevicesConnecting to Networks and Devices
4. If the network is secured, enter the password and tap CONNECT.
NOTE: Your phone automatically connects to previously used Wi-Fi networks when they
are in range.
Getting Notied of Open Networks
1. Press the Home Key > > Settings > Wi-Fi.
2. Slide the Wi-Fi switch to the On position.
3. Tap > Advanced.
4. Slide the Network notication switch to the On position.
When Wi-Fi is on, you receive notications in the Status Bar when your phone detects an
open Wi-Fi network. Slide the Network notication switch to the O position to
turn o notications.
Adding a Wi-Fi Network
You can add a Wi-Fi network if the network does not broadcast its name (SSID) or add a
Wi-Fi network when you are out of range.
To connect to a secured network, you rst need to get the security details from the
network’s administrator.
1. Press the Home Key > > Settings > Wi-Fi.
2. Slide the Wi-Fi switch to the On position.
3. Tap > Add network.
4. Enter the network SSID (name). If necessary, enter security or other network
conguration details.
5. Tap SAVE.
Forgetting a Wi-Fi Network
You can make your phone forget the details of a Wi-Fi network that you added—for
example, if you don’t want the phone to connect to it automatically or if it is a network
that you no longer use.
1. Press the Home Key > > Settings > Wi-Fi.
2. Slide the Wi-Fi switch to the On position.
3. Tap the Wi-Fi network name and then tap FORGET.
Connecting to a WPS Network
Wi-Fi Protected Setup (WPS) is a feature that makes it easy to add your phone to the
access points that supply WPS.
You can use one of the following methods to connect your phone to a wireless network
using WPS.
Method one: WPS button (Recommended)
1. Press the Home Key > > Settings > Wi-Fi.
2. Slide the Wi-Fi switch to the On position.
3. Tap > Advanced > WPS Push Button.
4. Press the WPS button on the wireless router and the access point will recognize your
phone and add it to the network.
Method two: PIN
1. Press the Home Key > > Settings > Wi-Fi.
2. Slide the Wi-Fi switch to the On position.
3. Tap > Advanced > WPS Pin Entry.
4. The WPS PIN displays on the screen. Enter the PIN into the access point’s setup page.
After entering the PIN, your phone automatically
the connection.
NOTE: For detailed information about the WPS feature of the access point, please refer to
its documentation.
nds the access point and congures
Adjusting Advanced Wi-Fi Settings
1. Press the Home Key > > Settings > Wi-Fi.
3736
Connecting to Networks and DevicesConnecting to Networks and Devices
2. Tap > Advanced to adjust the following settings.
• Network notication: Get notications in the status bar when Wi-Fi is on and an
open network is available.
• Scanning always available: Allow Google location services and other apps to scan
for networks even when Wi-Fi is turned o.
• Keep Wi-Fi on during sleep: Choose whether or not to keep Wi-Fi on in Sleep mode.
• Install certicates:
• WPS Push Button: Connect to a WPS network via the push button method.
• WPS Pin Entry: Connect to a WPS network via the phone PIN method.
• MAC address: Check the MAC address.
• IP address: Check the phone’s IP address.
Install certicates needed for connecting to certain Wi-Fi networks.
Connecting to Bluetooth Devices
Bluetooth is a short-range wireless communication technology. Phones or other
devices with Bluetooth capabilities can exchange information wirelessly within a
distance of about 30 feet (10 meters). The Bluetooth devices must be paired before
the communication is performed.
Turning Bluetooth On/O
1. Press the Home Key > > Settings > Bluetooth.
2. Slide the Bluetooth switch to the On or O position.
When Bluetooth is on, the icon will appear in the Status Bar.
Changing the Device Name
1. Press the Home Key > > Settings > Bluetooth.
2. Slide the Bluetooth switch to the On position if Bluetooth is o.
3. Tap > Rename this device.
4. Edit the name and tap RENAME.
38 39
Pairing With Another Bluetooth Device
1. Press the Home Key > > Settings > Bluetooth.
2. Slide the Bluetooth switch to the On position if Bluetooth is o.
Your phone automatically scans for and displays the IDs of all available Bluetooth
devices in range. Tap > Refresh if you want to scan again.
3. Tap the device you want to pair with.
4. If necessary, conrm that the Bluetooth passkeys are the same between the two
devices and tap PAIR. Alternately, enter a Bluetooth passkey and tap PAIR.
Pairing is successfully completed when the other device accepts the connection or
the same passkey is entered.
NOTE: The Bluetooth passkey may be xed for certain devices, such as headsets and
hands-free car kits. You can try entering 0000 or 1234 (the most common passkeys) or
refer to the documents for that device.
Forgetting a Bluetooth Device
You can make your phone forget its pairing connection with another Bluetooth device.
To connect to the device again, you need to search for it and enter or conrm a
passkey again.
1. Press the Home Key > > Settings > Bluetooth and ensure that Bluetooth is
turned on.
2. In the list of paired devices, tap beside the Bluetooth device you want to forget.
3. Tap FORGET.
Sending Data via Bluetooth
1. Open the appropriate application and select the le or item you want to share.
2. Select the option for sharing via Bluetooth. The method may vary by application and
data type.
3. Tap a Bluetooth device the phone has paired with or wait for it to search for new
devices and tap one of them.
Connecting to Networks and DevicesConnecting to Networks and Devices
Receiving Data via Bluetooth
1. Turn Bluetooth on before trying to receive data via Bluetooth.
2. Swipe down on the Status Bar and tap .
3. Tap ACCEPT to start receiving the data.
Depending on your storage setting and whether a microSDXC card is installed, received
les are stored automatically in a dedicated folder (Bluetooth, for instance). You can
access them with the File Manager app.
Connecting to Your Computer via USB
You can connect your phone to a computer with a USB cable and transfer music, pictures,
and other les in both directions. Your phone stores these les in internal storage or on a
removable microSDXC card.
Connecting Your Phone to a Computer via USB
1. Connect your phone to the PC with a USB cable.
2. Choose one of the following options:
• Charge only: Charge your phone via USB.
• Install driver: Install the driver needed for some USB connection modes (such as
MTP). You only need to install the driver on the same PC once.
NOTE: You can also install the driver on the PC by running the executable le in the
CD-ROM drive.
•
Media device (MTP): Transfer media les on Windows®, or using Android™ File
Transfer on Mac®.
NOTE: For Windows XP, install the drivers and Windows Media® Player 11 (or later
version) when you use Media device (MTP) for the rst time.
• Camera (PTP): Transfer photos using camera software.
NOTE: To make your phone connect to the computer automatically using the selected
connection type, check Don’t ask me again.
40 41
Disconnecting Your Phone From the Computer
To disconnect the phone from the computer, simply unplug the USB cable when
you’re nished.
Using the microSDXC Card as Portable Storage
You can use your microSDXC card as portable storage to save photos, music, videos,
downloaded les, and more.
Removing the microSDXC Card From Your Phone
If you need to remove the microSDXC card, you should unmount it rst.
1. Press the Home Key > > Settings > Storage.
2. Tap next to the SD card name in the Portable storage section.
NOTE: Before ejecting the card, ensure that you have moved data and apps to the
internal storage.
3. When the SD card’s state is Ejected, you can remove it from the phone.
Mounting the microSDXC Card
1. If the microSDXC card is ejected, press the Home Key > > Settings > Storage.
2. Tap the SD card name and then tap MOUNT.
Erasing and Formatting the microSDXC Card
1. Press the Home Key > > Settings > Storage.
2. Tap the SD card name in the Portable storage section.
3. Tap Format > ERASE & FORMAT > DONE.
CAUTION: The formatting procedure erases all the data on the microSDXC card, after
which the les CANNOT be retrieved.
Connecting to Networks and Devices
Connecting to Networks and Devices
Using USB On-the-Go (OTG)
Your phone supports USB On-The-Go. You can connect the phone and a USB peripheral
device (such as a USB ash drive, a USB mouse, or a USB keyboard) with an OTG adapter
cable.
For example, if you connect the phone to a USB ash drive, you can browse the les on
the ash drive; if you connect the phone to a USB mouse, you can navigate the phone
with the mouse.
Sharing Your Mobile Data Connection
Sharing Mobile Data Through a Wi-Fi Hotspot
You can share your phone’s data connection with other devices by turning your phone
into a portable Wi-Fi hotspot. This feature requires a data connection on a mobile
network and may result in data charges.
NOTE: When the portable Wi-Fi hotspot feature is enabled, you cannot use your phone’s
Wi-Fi capability to access the Internet. You still remain connected to the Internet via your
mobile data network.
1. Press the Home Key > > Settings > Wi-Fi hotspot.
2. Slide the switch to the On position. (If Wi-Fi was active, tap OK to deactivate it.)
After a moment, the phone starts broadcasting its Wi-Fi network name (SSID).
3. On another device, locate your phone via Wi-Fi and connect with it to start using the
phone’s mobile data.
NOTE: To stop sharing your data connection, slide the switch to the O position.
Setting Up Your Wi-Fi Hotspot
You can change your phone’s Wi-Fi network name (SSID), secure your portable Wi-Fi
hotspot, and set other options.
1. Press the Home Key > > Settings > Wi-Fi hotspot.
2. Tap an option to congure settings.
42 43
• Congure:
– Network name: Enter or edit a network SSID (name) that other devices see when
scanning for Wi-Fi networks.
–
Channel: Select a Wi-Fi channel for your Wi-Fi hotspot, or set as Auto.
– Security: Choose a security option: Open (not recommended) or WPA2 PSK
(other users can access your hotspot only if they enter the correct password).
When you select WPA2 PSK, tap the Password eld to edit the security password.
– Show password: If you have chosen WPA2 PSK security, check or uncheck to
show or hide the password.
– Broadcast network name (SSID): Check to broadcast or uncheck to hide your
network name (SSID). If the broadcast is disabled, other users need to know your
network SSID to nd the Wi-Fi hotspot.
• Manage users: Block or unblock users, set the maximum number of devices that
can connect to the hotspot simultaneously, and view a list of connected users.
• Sleep policy: Set hotspot sleep policy and notication.
Connecting to Virtual Private Networks
Virtual private networks (VPNs) allow you to connect to the resources inside a secured
local network. VPNs are commonly deployed by corporations, schools, and other
institutions to let people access local network resources when not on campus, or when
connected to a wireless network.
Depending on the type of VPN you are using, you may be required to enter your login
credentials or install security certicates before you can connect to your VPN. You can get
this information from your network administrator.
NOTE: You need to set a lock screen pattern, PIN, or password before you can use
credential storage (VPN).
Adding a VPN
1. Press the Home Key > > Settings > More > VPN.
Connecting to Networks and Devices
Phone Calls
2. Tap and enter the VPN name.
3. Enter the server address and other information provided by your network
administrator. Check Show advanced options to ll out additional details.
4. Tap SAVE.
The VPN is added to the list on the VPN screen.
Connecting to a VPN
1. Press the Home Key > > Settings > More > VPN.
2. Tap the VPN that you want to connect to.
3. When prompted, enter any requested credentials and then tap CONNECT.
Modifying a VPN
1. Press the Home Key > > Settings > More > VPN.
2. Tap beside the VPN that you want to modify.
3. Edit the VPN settings and then tap SAVE.
You can place calls from the Phone app, the Contacts app, or other apps or widgets that
display contact information. Wherever you see a phone number, you can usually tap it
to dial.
Placing and Ending Calls
Placing a Call by Dialing
1. Press the Home Key > > .
2. Enter the phone number with the on-screen keypad. Tap to delete incorrect digits.
NOTE: As you enter digits, your phone searches for contacts that match. If you see the
number you want to dial, tap it to place the call immediately without entering the rest
of the number.
3. Tap below the keypad to dial.
You can also tap the search box at the top of the Phone app screen and enter the phone
number or contact name you want to call. Tap the matching contact or Call [number] to
place the call.
NOTES:
• To make an international call, press and hold the 0 Key to enter the plus (+) symbol.
Next, enter the country code followed by the city/area code and then the phone
number.
• To redial the last call you made, press the Home Key > > > and tap again.
Ending a Call
During a call, tap on the screen.
Answering or Rejecting Calls
When you receive a phone call, the Incoming Call screen opens, displaying the Caller ID or
the information about the caller that you’ve entered in the Contacts app. You can answer
or reject the call, or reject it with a text message.
44 45
Phone Calls
Phone Calls
Answering a Call
When you receive a phone call, slide (Slide down to answer) down to
answer the call.
NOTE: To silence the ringer before answering the call, press the Volume Up/Down Key.
Rejecting a Call
When you receive a phone call, slide
the call.
You can also slide up to reject the call and send a preset text message to the caller.
NOTE: To edit the text response from within the Phone app, tap > Settings >
Quick responses.
(Slide up to decline) up to reject
Working With the Call History
The call history is a list of all the calls you’ve placed, received, or missed. It provides a
convenient way to redial a number, return a call, or add a number to your Contacts.
To open the call history, press the Home Key > > > Call History.
Placing a Call From the Call History
1. Open the call history.
2. Tap a number for more information about the call, or tap beside it to call back.
NOTE: You can tap MISSED, OUTGOING, or INCOMING to lter the records by call type.
Adding a Call History Number as a Contact
1. Open the call history.
2. Tap the circle in front of a number.
3. Tap on the contact information tab.
4. To add the number to an existing contact, tap a contact in the list. To add a new
contact, tap Create new contact.
46 47
Taking Other Actions on a Call History Entry
1. Open the call history.
2. Tap a number and then tap Call details to view more call information. While viewing
the call details, you can:
• Tap > Edit before call to edit the number in the dialer before calling it.
• Tap the circle in front of an entry to open the contact information tab from the
bottom of the screen. You can send a message, call back, edit the contact, add the
contact to favorites, or add the number to contacts.
• Tap to delete the entry.
NOTE: You can tap > Clear call history in the call history screen to delete all
history records.
Calling Your Contacts
1. Press the Home Key > . Your favorite contacts and frequently called contacts are
displayed in the tab.
2. Tap a contact to place the call, or tap the tab and then tap beside a contact to
make a call.
Checking Voicemail
If you have set the phone to divert certain calls to voicemail, callers can leave voicemail
messages when they cannot reach you. Here’s how to check the messages they left.
1. Press the Home Key > > .
2. Press and hold the 1 Key in the dialer. If prompted, enter your voicemail password.
3. Follow the voice prompts to listen to and manage your voicemail messages.
NOTE: See Phone Calls – Adjusting Your Call Settings – Setting Voicemail for how to set your
voicemail service. For detailed information, please contact your service provider.
Phone Calls
Phone Calls
Using Options During a Call
During a call, you will see a number of on-screen options. Tap an option to select it.
• Tap to switch to the keypad when you need to enter a code (for example, the PIN
for your voicemail or bank account) during the call.
• Tap to put the call on hold.
• Tap to turn the speaker on or o.
• Tap to mute or unmute the microphone.
• Tap
• Tap to go to contacts.
• Tap to merge the separate calls into a single conference call.
• Tap to put the caller you are speaking to on hold, and switch to the other call that
• Tap to end the current call.
WARNING! Because of higher volume levels, do not place the phone near your ear during
speakerphone use.
to make another call separately from the rst call, which is put on hold.
has been put on hold.
Managing Multi-party Calls
When the call waiting and three-way call features are available, you can switch between
two calls or set up a conference call.
NOTE: Options and interface will vary. The call waiting and three-way call features need
network support and may result in additional charges. Please contact your service
provider for more information.
Switching Between Current Calls
When you’re on a call, your phone screen informs you that another call is coming in and
displays the caller ID.
48
To respond to an incoming call while you’re on a call:
• Tap
call. This puts the rst caller on hold and answers the second call.
• Tap (End current and answer) to answer the second call and end the
rst one.
• Tap to reject the second call.
• Tap to reject the second call and select a preset text message to send to the caller.
(Answer) or (Hold current and answer) to answer the
To switch between two calls:
Tap .
Setting Up a Conference Call
With this feature, you can talk to two people at the same time.
1. Place the rst call.
2. Once you have established the connection, tap and dial the second number. This
puts the rst caller on hold.
3. When you’re connected to the second party, tap .
4. You can tap Manage conference call to end or separate a call; tap Back to
call to return to the main call screen.
If one of the people you called hangs up during your call, you and the remaining
caller stay connected. If you initiated the call and are the rst to hang up, all callers are
disconnected.
To end the conference call, tap .
Adjusting Your Call Settings
You can congure a number of settings for the Phone application.
NOTE: Some call options are displayed only when these features are available, and some
features require network support and may result in additional charges. Please contact
your service provider for more information.
49
Phone Calls
Phone Calls
Setting Contact Display Options
You can set the order of the contacts displayed in the tab of the Phone app.
1. Press the Home Key > > > Settings > Display options.
2. Tap Sort by or Name format to set the order of the contacts and the format of the
contact names.
Setting Sound and Vibration
Set the sound and vibration for incoming calls as well as dial pad sounds.
1. Press the Home Key > > > Settings > Sounds and vibration.
2. Tap the option you want to congure.
• Tap Phone ringtone to select the ringtone for incoming call notication.
• Check Also vibrate for calls to enable vibration for incoming call notication.
• Check Dialpad tones to play sounds when you tap the dial pad keys.
NOTE: You can set the vibration pattern for incoming call notications. Press the
Home Key > > > Settings > Call settings > Vibrate pattern and select one.
Editing Quick Response to Rejected Callers
1. Press the Home Key > > > Settings > Quick responses.
2. Tap a text message to edit it.
3. Tap OK to save the message.
Setting Voicemail
1. Press the Home Key > > > Settings > Call settings.
2. Tap Voicemail to congure voicemail settings.
• Tap Service to select the voicemail service provider. Your carrier is the default.
•
Tap Setup to view the voicemail number; if needed, tap Voicemail number to edit it.
• Tap Ringtone to select the notication ringtone for new voicemails.
• Check Vibrate to enable vibration for notications.
50 51
Using Fixed Dialing Numbers
Fixed Dialing Numbers (FDN) allows you to restrict outgoing calls to a limited set of
phone numbers.
1. Press the Home Key > > > Settings > Call settings.
2. Tap Fixed Dialing Numbers for the following options:
• Enable FDN: Input the PIN2 code to enable the FDN feature.
• Change PIN2: Change the PIN2 code for FDN access.
• FDN list: Manage the FDN list.
NOTE: The PIN2 code is provided by your carrier. Entering an incorrect PIN2 code
more times than allowed can lock your nano-SIM card. Contact the service provider
for assistance.
Setting TTY Mode
Your phone is a TTY compatible device. A TTY device can allow people who have hearing
or speech disabilities to communicate by telephone. Simply connect the TTY device to
the phone’s headset jack.
Select a TTY mode for your phone to work with a TTY device, or turn TTY o.
1. Press the Home Key > > > Settings > Call settings > TTY mode.
2. Select one of the following options. Consult your teletypewriter manufacturer’s
manual if necessary.
• TTY O: Users who can hear and talk can disable TTY support.
• TTY Full: Users who cannot talk or hear may use this mode to send and receive text
messages through TTY device.
• TTY HCO: Users who can hear, but cannot talk, may use this mode to listen to
conversation of the other party, and respond via text messages.
• TTY VCO: Users who can talk, but cannot hear, may use this mode to talk through
the phone and receive responses via text messages.
Phone Calls
Phone Calls
Setting Hearing Aids
Your phone supports HAC (Hearing Aid Compatibility) function. When you turn on the
hearing aid compatibility and use a hearing aid with a telecoil to answer the phone, it will
help you hear more clearly during the phone call.
1. Press the Home Key > > > Settings > Call settings.
2. Check Hearing aids to turn on hearing aid compatibility.
CAUTION: Do not turn on the Hearing aids option unless you use a hearing aid with a
telecoil. Using this setting without a hearing aid or with a hearing aid without a telecoil
may be harmful to your hearing.
Setting Display Duration
When this feature is enabled, the phone will display the call duration on the calling screen
when a call is ended. You can also check the call duration in the call history.
1. Press the Home Key > > > Settings > Call settings.
2. Check or uncheck Display duration.
Setting Speed Dials
You can press and hold the 1-9 Keys from the dialer to call the corresponding speed
dial number.
The number 1 Key is reserved to speed dial your voicemail.
To assign a speed dial key:
1. Press the Home Key > > > Settings > Call settings > Speed dial.
2. Tap a speed dial entry.
3. Enter a phone number or tap to select one from the contact list.
4. Tap OK.
Setting DTMF Tones
You can set the length of dual-tone multi-frequency (DTMF) signal tones.
1. Press the Home Key > > > Settings > Call settings > DTMF tones.
2. Tap Normal or Long.
Setting the Vibration When a Call is Answered
You can make the phone vibrate when a call is answered.
1. Press the Home Key > > > Settings > Call settings.
2. Check Vibrate when call is answered to enable this feature.
Forwarding Incoming Calls
The call forwarding feature allows you to forward your incoming calls to another
phone number.
1. Press the Home Key > > > Settings > Call settings > Call forwarding.
2. Tap an available option to enable it.
Barring Certain Calls
The call barring feature allows you to forbid certain types of calls from your phone.
1. Press the Home Key > > > Settings > Call settings > Call barring.
2. Set the restriction of specic types of calls from your phone.
Setting Voice Privacy
This option allows you to enable enhanced privacy mode.
1. Press the Home Key > > > Settings > Call settings > Additional settings.
2. Check Voice privacy to enable this feature.
5352
Phone Calls
Contacts
Setting Plus Code Dialing
Plus Code Dialing allows the phone to automatically dial the international access code for
your location when you press and hold the 0 Key in the dialpad.
To activate Plus Code Dialing:
1. Press the Home Key > > > Settings > Call settings > Additional settings > Plus
code dialing setting.
2. Check Setup Plus Code Replacement to enable this feature.
To change the international dialing code:
1. Press the Home Key > > > Settings > Call settings > Additional settings > Plus
code dialing setting.
2. Tap Replace Code of Plus Code.
3. Enter a new code and tap OK.
Setting Call Waiting
This option allows you to get notied of incoming calls during a call.
1. Press the Home Key > > > Settings > Call settings > Additional settings.
2. Check Call waiting to enable this feature.
Setting Caller ID
Choose whether your number is displayed when someone receives your outgoing call.
1. Press the Home Key > > > Settings > Call settings > Additional settings.
2. Tap Caller ID and select an option.
54
You can add contacts on your phone and synchronize them with the contacts in your
Google account or other accounts that support contact syncing.
To see your contacts, press the Home Key > > Contacts. From there, you can tap the
tabs to quickly switch to your contact groups or favorite contacts.
Checking Contact Details
1. Press the Home Key > > Contacts > CONTACTS.
2. Scroll through the list to view all your contacts.
3. Tap a contact to view its details.
NOTE: If you have a lot of contacts stored, you’ll see a slider on the right side of the
screen. To go directly to a letter, press and hold the slider and drag it to a letter.
Adding a New Contact
1. Press the Home Key > > Contacts > CONTACTS.
2. Tap to add a new contact.
NOTE: If you have no contacts added yet, tap CREATE A NEW CONTACT.
3. Enter the contact name, phone numbers, and email addresses. Tap More Fields to
enter other information. If you have multiple account types associated with your
phone, tap the contact account eld at the top and select a contact type. If a sync
account is selected, the contacts will be synced automatically with your account online.
4. Tap to save the contact.
Setting Up Your Own Prole
You can create your own name card in your phone.
1. Press the Home Key > > Contacts > CONTACTS.
2. Tap Set up my prole. If a prole has been set up, tap the listing below ME and tap .
3. Edit your prole information. Tap More Fields to add more information if desired.
4. Tap to save.
55
Contacts
Contacts
Importing, Exporting, and Sharing Contacts
You can import/export contacts from/to the phone storage or the microSDXC card. This is
especially useful when you need to transfer contacts between dierent devices. You can
also quickly share your contacts using Bluetooth, Email, Messaging, Google Drive, or Gmail.
Importing Contacts From the microSDXC Card or Phone Storage
1. Press the Home Key > > Contacts.
2. Tap
> Import/Export > Import from storage.
3. If prompted, choose to import one, multiple, or all vCard les, and then tap OK.
4. If necessary, choose the vCard le(s) you would like to import, and then tap OK.
Exporting Contacts to the microSDXC Card or Phone Storage
1. Press the Home Key > > Contacts.
2. Tap
> Import/Export > Export to storage.
3. The phone will prompt you with the name of the vCard le. Tap OK to create the le.
Sharing Contacts
1. Press the Home Key > > Contacts > CONTACTS.
2. Press and hold the contact you want to share.
3. Tap to select more contacts if needed, and then tap .
4. Choose how to share the contacts. The options available depend on the applications
and services installed.
NOTE: You can also share your contacts by choosing Share visible contacts in the
Import/Export contacts menu.
Working With Favorite Contacts
You can add the contacts you use frequently to FAVORITES so that you can nd
them quickly.
56 57
Adding a Contact to Favorites
1. Press the Home Key > > Contacts > CONTACTS.
2. Tap a contact and then tap at the top of the screen.
Removing a Contact From Favorites
1. Press the Home Key > > Contacts > FAVORITES.
2. Tap a favorite contact and then tap .
Working With Groups
Viewing Your Contact Groups
1. Press the Home Key > > Contacts > GROUPS.
2. Scroll through the list to view the preset groups and any groups you have created.
3. Tap a group to view its members.
NOTE: To send a message or an email to the group members, tap a group > >
Send Group message/Send Group email and tap to select group members to include.
Setting Up a New Group
1. Press the Home Key > > Contacts > GROUPS.
2. Tap to create a new group.
3. Tap Group’s name and enter a name.
4. Tap Add member and select the contacts you wish to be the group members.
5. Tap .
6. If necessary, tap the eld below RINGTONE and NOTIFICATION RINGTONE to set a
special ringtone for incoming calls and messages from the group members, and then
tap OK.
7. Tap to save the group.
Contacts
Contacts
Deleting a Group
1. Press the Home Key > > Contacts > GROUPS.
2. Tap a group and then tap > Delete Group.
3. Tap OK to disband the group. The contacts in the group will not be deleted.
Editing a Group
1. Press the Home Key > > Contacts > GROUPS.
2. Tap a group >
3. Tap the group name to edit it, or tap the eld below MEMBER, RINGTONE or
NOTIFICATION RINGTONE to add more members or change the ringtone.
4. Tap .
NOTE: To remove group members, tap a group and then tap > Multi-Select and select
the members you would like to remove. Tap > OK.
> Edit.
Searching for a Contact
1. Press the Home Key > > Contacts and then tap to search.
2. Input the contact name you want to search for. The contacts matched will be listed.
Editing Contacts
Editing Contact Details
1. Press the Home Key > > Contacts > CONTACTS.
2. Tap a contact and then tap .
3. Edit the contact and tap .
Setting a Ringtone for a Contact
Assign a special ringtone to a contact, so you know who is calling when you hear
the ringtone.
1. Press the Home Key > > Contacts > CONTACTS.
2. Tap a contact you want to set a ringtone for, and then tap
> Set ringtone.
3. Select a ringtone you like and tap OK.
Deleting Contacts
1. Press the Home Key > > Contacts > CONTACTS.
2. Press and hold the contact you want to remove.
3. Check more contacts if needed, and then tap .
4. Tap OK to conrm.
Joining Contacts
As your phone synchronizes with multiple online accounts, you may see duplicate entries
for the same contact. You can merge all the separate information of a contact into one
entry in the Contacts list.
1. Press the Home Key > > Contacts > CONTACTS.
2. Tap a contact to display the contact’s details.
3. Tap > > Join.
4. Tap the contact whose information you want to join with the rst entry.
NOTES:
• The information from the second contact is added to the rst, and the second
contact is no longer displayed in the contacts list.
• You can repeat these steps to join another contact to the main contact.
5. Tap to save the joined contact.
Separating Contact Information
If contact information from dierent sources was joined in error, you can separate the
information back into individual contacts on your phone.
1. Press the Home Key > > Contacts > CONTACTS.
2. Tap a contact you want to separate.
3. Tap > > Separate.
4. Tap OK to conrm.
5958
Accounts
Accounts
Adding or Removing Accounts
You can add multiple Google accounts and Microsoft Exchange ActiveSync® accounts.
You may also add other kinds of accounts, depending on the apps installed on your phone.
Adding an Account
1. Press the Home Key > > Settings > Accounts > Add account.
2. Tap the type of account you want to add.
3. Follow the on-screen steps to enter the information about the account. Most accounts
require a username and password, but the details may vary. You may also need to
obtain some information from IT support or your system administrator.
When the account is successfully added, it is displayed in the Accounts menu in Settings.
Removing an Account
Removing an account will delete it and all information associated with it, such as emails
and contacts, from your phone.
1. Press the Home Key > > Settings > Accounts.
2. Tap the account category and then tap the account you’d like to remove.
3. Tap > Remove account > REMOVE ACCOUNT.
Conguring Account Sync
Conguring Auto Sync Setting
1. Press the Home Key > > Settings > Accounts.
2. Tap and check or uncheck Auto-sync data to enable or disable automatic sync.
3. Tap OK.
• When automatic sync is turned on, changes you make to information on your phone
or on the web are automatically synced with each other.
• When automatic sync is turned o, you need to sync manually to collect emails,
updates, or other recent information.
Syncing Manually
1. Press the Home Key > > Settings > Accounts.
2. Tap the account category and then the account you want to sync.
3. Tap > Sync now.
Changing an Account’s Sync Settings
1. Press the Home Key > > Settings > Accounts.
2. Tap the account category and then the account. The Sync settings screen appears,
showing a list of information the account can sync.
3. When Auto-sync data is enabled, switch items on or o as you need. The enabled
types of information will be kept in sync automatically between the phone and the
web. When Auto-sync data is disabled, tap a listing to sync that type of information
between the phone and the web.
6160
Email
Email
Press the Home Key > . Use it to read and send emails from Microsoft Exchange
ActiveSync, Gmail, Hotmail, Yahoo!®, and more.
Setting Up the First Email Account
1. Press the Home Key > .
2. Select an email server, and then enter your email address and password.
3. Tap NEXT to let the phone retrieve the network parameters automatically.
NOTE: You can also enter these details manually by tapping MANUAL SETUP or if
automatic setup fails.
4. Follow the on-screen instructions to nish setup.
Your phone will show the inbox of the email account and start to download email
messages.
Checking Your Emails
Your phone can automatically check for new emails at the interval you set when setting
up the account.
You can also check new emails manually by swiping down on the message list. Tap LOAD
MORE at the bottom of the email list to download earlier messages.
Responding to an Email
You can reply to or forward a message that you receive. You can also delete messages and
manage them in other ways.
Replying to or Forwarding an Email
1. Open the email you want to reply to or forward from the Inbox.
2. Choose one of the following:
• To reply to the sender, tap .
• To reply to the sender and all recipients of the original message, tap .
• To forward the message, tap .
3. Edit your message and tap .
Marking an Email as Unread
You can return a read email to the unread state—for example, to remind yourself to read
it again later. You can also mark a batch of emails as unread.
• While reading a message, tap > Mark unread.
• While in a message list (for instance, the inbox), tap the sender image before the
message and then tap .
Deleting an Email
You can delete an email from its folder. You can also delete a batch of emails.
• While reading a message, tap > Delete.
• While in a message list (for instance, the inbox), tap the sender image before the
message and then tap .
NOTE: If you accidentally delete an email, tap UNDO to retrieve it.
Writing and Sending an Email
1. Open your email Inbox and tap .
NOTE: If you have more than one email account added on the phone, tap the sender
line to select the account you want to use for sending the message.
2. Enter a contact name or email address in the To eld. Separate each recipient with a
comma. You can also tap
NOTE: To send a carbon copy or blind carbon copy to other recipients, tap beside
the To eld to open the Cc/Bcc elds and enter the contact names or email addresses.
3. Enter the email subject and compose the email text.
4. Tap to add audio les, images, videos, and other types of les as attachments.
5. Tap at the top of the screen to send the message.
to select recipients from your contacts.
+
6362
Email
Email
Adding a Signature to Your Emails
You can set a few lines of plain text as a signature for every outgoing email message from
an account, such as your name and contact information.
1. Open the Email app.
2. Tap > Settings and select the account you want to add a signature to.
3. Tap Signature and enter the text.
4. Tap OK.
Adding and Editing Email Accounts
Adding an Email Account
After setting up your rst email account (see Email – Setting Up the First Email Account),
you can add more email accounts and manage them separately.
1. Open the Email app.
2. Tap > Settings > Add account.
3. Set up the account as you did with the rst one.
Editing an Email Account
You can change a number of settings for an account, including how often you check for
email, how you’re notied of new emails, and details about the servers the account uses
to send and receive emails.
1. Open the Email app.
2. Tap > Settings and tap the account whose settings you want to change.
3. Make the changes you want and tap or press the Back Key when you’re nished.
Removing an Email Account
1. Open the Email app.
2. Tap > Settings and tap the account you want to remove.
3. Tap Remove account > OK.
Changing General Email Settings
General settings apply to all email accounts you add.
1. Open the Email app.
2. Tap > Settings > General settings.
3. Make the changes you want and tap or press the Back Key when
you’re nished.
6564
Messaging
Messaging
You can use Messaging to exchange text messages (SMS) and multimedia messages (MMS).
Opening the Messaging Screen
Press the Home Key > .
The Messaging screen opens, where you can create a new message, search for messages,
or open an ongoing message thread.
• Tap to write a new text or multimedia message.
• Tap to search for a message using keywords.
• Tap an existing message thread to open the conversation.
Sending a Message
1. On the Messaging screen, tap .
2. Add recipients in one of the following ways:
• Tap the To eld and manually enter the recipient’s number or the contact name. If
the phone presents a few suggestions, tap the one you want to add.
• Select recipients from your contacts by tapping .
3. Tap the Type message eld and enter the content of your text message.
4. If you want to send a multimedia message, tap to attach a le or a slideshow
to the message.
5. Tap
NOTES:
• You can also include email addresses as recipients for multimedia messages.
• Do not add an attachment if you want to send a text message. Otherwise you may be
66
or > Send.
charged for a multimedia message.
Replying to a Message
Messages you receive are appended to existing threads of the same number. If the new
message comes from a new number, a new thread is created.
1. On the Messaging screen, tap the thread that has the message you want to reply to.
2. Type your reply in the text eld at the bottom. You can tap if you want to reply with
an MMS.
3. Tap
or > Send.
Forwarding a Message
1. On the Messaging screen, tap the thread that has the message you want to forward.
2. Tap the message you would like to forward.
3. Tap Forward in the menu that opens.
4. Enter a recipient for the message and edit the content if needed.
5. Tap
or > Send.
Deleting Messages or Threads
Deleting Messages in a Thread
1. On the Messaging screen, tap a thread.
2. Tap
> Multi-Select.
3. Tap the checkboxes beside the messages you want to delete.
4. Tap > OK.
Deleting Message Threads
1. On the Messaging screen, press and hold one thread you want to delete.
2. If there are more threads you want to delete, tap them one by one.
3. Tap > OK.
67
Messaging
Calendar
Copying a Message
You can copy text messages from the nano-SIM card to the phone storage.
1. On the Messaging screen, tap > Settings > Manage SIM card messages.
2. Press and hold a message and then tap Copy to phone memory.
Changing Message Settings
Tap
> Settings in the Messaging screen to change Message settings.
Calendar on the phone works with the web-based Google Calendar™ service for creating
and managing events, meetings, and appointments. It also works with the Microsoft
Exchange ActiveSync calendar once you sign into your Exchange account on the phone.
To open Calendar, press the Home Key > > Calendar.
Viewing Your Calendars and Events
Selecting Visible Calendars
1. Open the Calendar app.
2. Tap
> Calendars to display.
3. In the new screen, tap to check the calendars you want to see or uncheck the
calendars you’d like to hide.
Events from hidden calendars are not shown in the Calendar app.
Changing Calendar Views
You can view your calendars in dierent forms. The app oers four views: Month, Week,
Day, and Agenda.
To change calendar views, tap the current view at the top left and select the view you
prefer. You can also change to Day view from Month view by tapping twice on any day
block in the monthly calendar.
• In Month view, swipe vertically to see earlier months and later months.
•
In Week or Day view, swipe horizontally to see earlier weeks/days and later weeks/days.
• When you are viewing earlier or later days, weeks, or months, tap the calendar icon at
the top of the screen to quickly switch to today.
Viewing Event Details
In Agenda, Day, or Week view, tap an event to view its details.
In Month view, tap a day, then tap an event to view its details.
68 69
Calendar
Calendar
Creating an Event
1. In any Calendar view, tap to open an event details screen for a new event.
You can also tap a spot in Day or Week view twice to add an event to that time spot.
NOTE: If you have more than one calendar, you can choose the calendar to which to
add the event by tapping the current calendar above the Event name box.
2. Add details about the event. Tap MORE to access more options.
3. Tap DONE to save the new event.
NOTE: You can also create a new event by copying the details of an existing event. Just
open the event details screen and tap
tap DONE.
> Copy. Then edit the new event information and
• To add an email account, tap
• For General settings, choose options for Calendar view setting and Notications &
reminders. You can choose to show the week number, set the day of the week the
calendar starts on, and use home time zone when you are traveling. You can also
choose event reminder settings such as notication sound, vibrate, default reminder
time, and more.
> Settings > to add a corporate or Google account.
Searching an Event
Tap
> Search and then type the event in the Search eld, or tap to speak out the
event you want to search.
Editing, Deleting, or Sharing an Event
1. Find the event you want to edit, delete, or share.
2. Open its details screen (see Calendar – Viewing Your Calendars and Events – Viewing
Event Details).
3. Choose one of the following options:
• To edit the event, tap . Tap DONE to save your changes.
• To delete the event, tap > OK.
• To share the event, tap and choose how to share.
Changing Calendar Settings
To change Calendar settings, open a Calendar view (Day, Week, Month, or Agenda) and
then tap
You can change General settings, which apply to all accounts, or other settings that only
apply to specic accounts.
70 71
> Settings.
Browser
Browser
Use Browser to view web pages and search for information.
Opening the Browser
Press the Home Key > to launch the web browser. The Browser also opens when you
tap a web link—for example, in an email or a text message.
1. Open the Browser app.
2. Tap the address box at the top of the web page.
3. Enter the address (URL) of a web page, or enter terms you want to search for.
4. Tap a URL or search suggestion or tap at the top of the screen to open the web
page or search results.
NOTE: Tap next to the address box if you want to stop opening the page.
Setting the Home Page
Your home page opens when you open a new browser tab, and when you open Browser
after restarting your phone.
1. Open the Browser app.
2. Tap > Settings > Set homepage.
3. Enter the URL and tap OK to set it as the homepage.
Using Multiple Browser Windows
You can open several web pages at the same time (one page in each window) and switch
between them freely.
Opening a New Browser Window
Tap at the bottom of the screen, and then tap New window. A new browser window
opens and the home page is loaded.
72
Switching Between Browser Windows
1. Tap the icon at the bottom of the screen. The number in the icon indicates the
number of currently active browser windows.
2. Swipe vertically to scroll through the list of opened web pages.
3. Tap one you want to open.
NOTE: Swipe a web page horizontally or tap to close the browser window. Tap
Close all > OK to close all windows.
Downloading Files
1. Press and hold an image or a link to a le or to another web page.
2. In the menu that opens, tap Save image or Save link.
The downloaded les are saved to your phone. You can view or open them in the
Downloads app.
Changing Browser Settings
You can congure a number of settings to customize the way you browse the web,
including several that you can use to control your privacy.
To open the Browser settings screen, tap > Settings in the browser screen.
73
Camera
You can take photos and record videos. Photos and
videos are stored on the microSDXC card, if you have
installed one, or to the phone’s internal storage. You
can copy them to your computer or access them in the
Gallery app.
➊
➒➓
➑
Capturing a Photo
1. Press the Home Key > .
2. Aim the camera at the subject and make any
necessary adjustments. PHOTO (auto camera) mode
is used by default.
3. Tap the area on the screen where you want the
camera to focus, or let the camera autofocus on the
center of the image.
4. Lightly tap , press the Volume Key, or tap the
Fingerprint Sensor to take the picture.
Number Function
1 Change the camera settings.
2
Switch between video camera, photo camera, and dual-camera mode.
3
Exit the camera.
4
Select a color eect or other special eects.
5 Capture a photo.
6 View photos and videos you have taken.
Use special photo or video camera modes: Manual, Panorama, Multi
7
Exposure, Time-Lapse, Slow Motion, and Sports.
74 75
➋
➌
➎➍
➐
➏
8 Switch between the front and back cameras.
Set a time delay before the camera automatically takes a picture after you
9
tap the shutter icon.
10 Change the HDR setting (back camera only).
11 Change the ash setting (back camera only).
WARNING! Keep a safe distance when using the ash. Do not point the ash toward the
eyes of people or animals.
NOTES:
• You can pinch or spread your ngers on the screen to zoom in or out before taking
a picture.
• In PHOTO (auto camera) mode, when you tap the screen to focus, the exposure bar
appears beside the focus point. You can drag up or down to adjust the exposure.
• When you use the front camera, you can also tap or BEAUTIFY to use smile
detection or beauty face.
Using Dual-Camera Mode
In dual-camera mode, you can adjust aperture for a bokeh eect or take monocolor or
monochrome pictures.
1. Press the Home Key > > DUAL.
2. Tap an option:
• BOKEH: Take a photo with the subject in focus and the background blurred. Hold
the phone 1 to 6.5 feet from the subject, and adjust the slider to change the shutter
aperture.
• MONOCOLOR: Take a photo with only one color visible. Tap a color option, and then
use the RANGE slider to adjust the color selection to achieve the desired eect.
Camera
Camera
Camera
• MONOCHROME: Tap ORIGINAL for a grayscale photo, SKETCH to render the photo
in a drawn style, or VIGNETTE to capture a grayscale photo with a soft-edge eect.
3. Tap to take the picture.
Using Manual Camera Mode
You can use the Manual camera mode to adjust more camera options for your photo,
such as ISO, white balance, and exposure.
1. Press the Home Key > > > MANUAL.
2. Aim the camera at the subject. You can make the following adjustments.
• Drag the green circle to any area on the screen that you want to focus on.
• Drag the yellow square to any area on the screen where you want the camera
to meter exposure so as to adjust the photo brightness. Press and hold to lock
exposure.
• Tap to unfold more options, including shutter speed, ISO, overall exposure, white
balance, interval for time-lapse photos, and focus.
3. Tap to take the photo.
Using Other Camera Modes
Besides capturing photos in the traditional way, your Camera app oers other powerful
and interesting camera modes. Tap in the viewnder screen to nd them all.
• PANORAMA: Capture panorama photos.
• MULTI EXPOSURE: Capture multiple photos to create collages and special eects.
• TIME-LAPSE: Set the time interval between each frame when you record time-lapse
videos with the back camera.
• SLOW MOTION: Capture slow-motion video clips.
• SPORTS: Keep the focus on moving objects.
76 77
Recording a Video
1. Press the Home Key > > VIDEO.
2. Aim the camera at the subject and make any necessary adjustments. You can
tap any area on the screen that you want the camcorder to focus on before and
during recording.
3. Tap to start recording. You can tap / to pause or resume recording, or tap
to save the frame as a photo.
4. Tap to stop recording.
NOTES:
• You can pinch or spread your ngers on the screen to zoom in or out before and
during recording.
• When you tap the screen to focus during recording, the exposure bar appears beside
the focus point. You can drag up or down to adjust the exposure. Press and hold the
focus point to lock the focus.
•
To capture slow-motion or time-lapse video, tap > SLOW MOTION or TIME-LAPSE.
Tap to start recording and to stop. In Slow Motion mode, you can tap / to
pause or resume recording. In Time-Lapse mode, you can tap to save the frame as
a photo.
Customizing Camera and Video Settings
Before capturing a photo or video, you can tap
NOTE: Some camera and video options will change in dierent camera modes.
• Resolution: (front and rear camera) Set the image size for your photo.
• Video quality: (Video mode) Set the quality for your video.
• Point-and-shoot: (front camera) Tap the viewnder screen to take a photo.
• Mirror image: (front camera) Take a mirror photo.
to open the following options.
Camera
Gallery
• Sele indicator: (front camera) Capture natural expressions by looking at the sele
indicator on screen.
• Light Supplementary: (front camera) Flash the screen to provide more light when
taking a sele.
• Metering: (Manual mode) Adjust the metering setting.
• Composition: (Manual mode) Show or hide grid or golden spiral (used for balanced
photo composition).
• Gradienter: (Manual mode) Enable or disable the gradienter.
• Watermark: (rear camera) Apply a watermark to your photos.
• Shutter tone: Turn the shutter tone on or o.
• Geo-tag: Select whether to store the GPS location in your captured photos and videos.
• Histogram: (Manual mode) Turn the histogram on or o. The histogram shows the
brightness and darkness of the current view.
• Volume key: (front and rear camera) Assign the function of the Volume Key for the
Camera app: Take photo, Zoom, or Volume.
• Anti-banding: Set the anti-banding value to avoid stripes on the screen when you
take pictures of TV or computer screens.
• Save location: Change the storage location for captured photos and videos when a
microSDXC card is installed.
• Help: Enable the Help icon on the viewnder screen, or tap More to view help details.
• Restore defaults: Restore default camera and video settings.
78 79
Opening the Gallery
Press the Home Key > > Gallery to view albums of your pictures and videos.
Working With Albums
When you open the Gallery, all pictures and videos on your phone are displayed in a
number of albums. Swipe up and down to see them all.
Viewing Album Contents
Tap an album to view the pictures and videos it contains.
Sharing Albums, Pictures, or Videos
1. Press and hold an item in the Albums view to select an album, or after you open an
album, to select a picture or a video.
2. Tap more items that you want to share.
3. Tap and select how you want to share the items.
Deleting Albums, Pictures, or Videos
1. Press and hold an item in the Albums view to select an album, or after you open an
album, to select a picture or a video.
2. Tap more items that you want to delete.
3. Tap > OK.
Hiding Albums
1. Press and hold an album to select it.
2. Tap more albums that you want to hide.
3. Tap > OK.
NOTE: To show the hidden albums again, tap > Settings > Manage hidden albums.
Tap the albums you want to restore, and then tap Show.
Gallery
Gallery
Working With Pictures
Tap a picture in an album to view the picture in full screen. Double-tap the picture, or
pinch two ngers together or spread them apart to zoom out or in. Slide left or right to
view other pictures in the album.
Number Function
Tap to return to the album, where all
1
its contents are displayed in a grid.
2 Delete the picture.
3 Edit the picture.
4 Share the picture.
View more options, such as rotate,
5
rename, and print.
6 Add to favorites.
➊
➋
➏
➎
➍
➌
NOTES:
• Pinch a picture or video to make it smaller. You’ll then see a lmstrip-style view of all
your pictures and videos in a row. Swipe left or right to scan through them all.
• You can delete a picture or video by tapping > OK or by swiping it up in the
lmstrip view. If you accidentally delete one by swiping it up, tap UNDO to retrieve it.
• For a picture captured in the dual-camera BOKEH mode, you can tap , tap anywhere
on the picture to refocus, and then select the blur level. Tap to save it.
• Not all options may be available for certain albums or pictures.
80 81
Retouching Your Pictures
You can edit any photos you took and some other pictures in Gallery with Photo Editor.
The changed picture is saved in the same album as the original one, while the original is
never aected.
1. While viewing a picture in full screen, tap the screen and tap
NOTE: You can also choose to edit the picture with Photos.
2. Tap the icons along the bottom of the screen to edit the picture.
Apply lters, old photo eects, or blur eects.
Crop, rotate, or ip (mirror) the picture.
Adjust exposure, saturation, hue, sharpness, and other color options.
Select a color and draw on the picture, or add some text or mosaics to the
picture and adjust the eect.
Add a frame to the picture, or decorate people in the picture with mustaches,
eyeglasses, hats, and more.
3. Tap to keep the change or to cancel it.
4. Tap to save the new picture.
NOTE: Tap in the Photo Editor screen to see the edits you have made and undo or
redo them.
> Photo Editor.
Making a GIF or a Collage
You can put together a few pictures in the same album to make an animated GIF or a
collage of pictures.
1. Open the Gallery app and tap > GIF maker or Collage maker.
2. Tap an album.
Gallery
Music
3. Tap the pictures you want.
• To make a GIF, tap 2 to 50 pictures in the order (or reverse of the order) that you want
them to appear in the GIF.
• To make a collage, tap 2 to 9 pictures.
The pictures you tapped are displayed along the bottom of the screen. Tap to
remove the pictures you do not want.
4. Tap NEXT. The GIF or collage is displayed.
5. Tap the options along the bottom to adjust the nal picture.
• For GIF, you can adjust the speed, order, and size. Tap MORE to adjust each picture,
and then tap Manage Frame to add more pictures or change their order.
• For collage, tap TEMPLATE, FREE, or COLLAGE and then select a border, shading,
and style.
6. When you are satised with the nal picture, tap to save the GIF or tap to save
the collage.
Depending on your storage setting, the picture is saved to the zte_editor/Save folder in
your phone storage or your microSDXC card.
Playing Videos
1. Tap an album in Gallery, and then tap the thumbnail of a video.
2. Tap at the center and select a player to start playing.
3. Tap the video to view the playback controls.
In the Video Player, you can tap to play the video in a small oating window and
continue with other tasks on the phone.
82
Press the Home Key > > Music to play audio les stored on your phone. Music
supports a wide variety of audio formats, so it can play music you purchase from online
stores, music you copy from your CD collection, and more.
Viewing Your Music Library
Press the Home Key > > Music, and your music library is displayed. All your audio les
are cataloged according to the information stored in the les.
• Tap All Songs to view all music les on your phone.
• Tap Artists or Albums to browse music les on your phone organized by the artist or
album name.
• Tap Folders to nd music les through the folders they are stored in.
• Tap Favorites to browse music les you have marked as favorites.
• Tap Playlists to view all music playlists you have created.
NOTE: If an audio le is being played, its name and player controls are displayed at the
bottom of the screen. Tap the area to open the playback screen.
Setting a Song as the Default Ringtone
The song will be used as the ringtone for all incoming calls, except those from contacts
you have assigned special ringtones to (see Contacts – Editing Contacts – Setting a
Ringtone for a Contact).
1. Press the Home Key > > Music to see the music library.
2. Tap next to a song in any list.
3.
In the menu that opens, tap Set as ringtone.
4.
Tap Phone Ringtone or Notication Ringtone.
NOTE: If the song is being played and you’re on the playback screen, tap >
ringtone
and select Phone Ringtone or Notication Ringtone.
Set as
83
Music
Music
Playing Music
Tap a song in the music library to listen to it. Tap the playback bar at the bottom of the
screen to open the following playback screen.
➊
➓
➒
➋
➌
➍
➎
➑
➐
➏
Number Function
1 Return to the music library.
Album artwork (if available). Slide left/right to switch to the next/previous
2
song in the playlist.
3 Open the Dolby Audio app to adjust the sound eect.
4 Check the track information.
5 Turn shue on or o.
Playback control: Skip songs or pause and resume playback. Drag the
6
progress bar to jump to any part of the track.
Toggle repeat mode: no repeat, repeat the current track, or repeat the
7
current playlist.
8 Add the track to the Favorites playlist.
9 Tap to see the current playlist (queue).
10 Access additional options.
You can still control the music when you are not in the playback screen.
• In other apps, swipe down the Notication Panel. Tap the song title to restore the
playback screen, or you can pause/resume playback or skip songs.
• When the screen is locked, the song information, album cover, and playback controls
are displayed on the screen. Tap the song title to restore the playback screen, or you
can pause/resume playback or skip songs.
Managing Playlists
Create playlists to organize your music les into sets of songs, so that you can play the
songs you like in the order you prefer.
• Tap > Add to playlist next to a song to add it to a playlist or create a new playlist.
• Tap > Delete next to a playlist to delete the playlist.
• Tap > Rename next to a playlist to rename the playlist.
• Tap a playlist to view its content. To delete a song, press and hold the song. Tap
additional songs to select multiple songs for removal. Tap to remove the songs
from the playlist.
8584
Video Player
➐
Use the Video Player to manage your video library and to
watch videos.
Opening the Video Library
Press the Home Key > > Video Player to view your
video library. Swipe up or down to nd the video you
want. You can also tap to search for video les, or
tap > View by or Sort by to change the display
mode or sort the list.
➊
➋
Playing and Controlling Videos
Tap a video in the video library to play it. Tap the screen
to show the playback controls. You can control the
video and audio or carry out other operations.
Number Function
1 Return to the video library list.
2 Rotate the video.
3 Change the video ratio (t to screen).
Playback control: Skip videos or pause and resume playback. Drag the
4
slider to jump to any part of the video.
Play the video in a small window and continue with other tasks on
5
the phone.
6 Share, trim, or delete the video, or congure player settings.
7 Hide video playback controls and lock the touch screen.
8 Take a screenshot.
9 Open the Dolby Audio app to adjust the sound eect.
86 87
➌
➑➒
➏
NOTES:
• Slide horizontally on the video to rewind or fast forward.
• Slide vertically on the right or left part of the screen to adjust volume or brightness,
respectively.
• Tap or to skip to the previous or the next video.
Managing Video Files
Deleting Videos
1. In the video library, tap > Multi-Select, or press and hold a video.
2. Tap the videos you want to delete.
3. Tap > OK.
➎
➍
Sharing Videos
1. In the video library, tap > Multi-Select, or press and hold a video.
2. Tap the videos you want to share.
3. Tap and select how you want to share them.
Trimming a Video
1. Tap a video to start playing it.
2. Tap > Trim.
3. Drag the two tabs on the progress bar to select the portion you want to keep. You can
tap to preview the selected portion.
4. Tap . The trimmed video is saved as a new video le.
Video Player
Video Player
Sound Recorder
Renaming a Video
1. Tap next to the video you want to rename.
2. Tap Rename.
3. Type the new video name and tap OK.
Viewing Details of a Video
1. Tap next to a video for which you want to view details.
2. Tap Details.
3. Tap CLOSE to close the window.
Sound Recorder enables you to record voice memos and listen to them whenever
you like.
Recording a Voice Memo
1. Press the Home Key > > Sound Recorder.
2. Tap to turn on or o high-quality recording.
3. Tap to start recording. Tap to pause and to continue recording.
4. Tap to stop recording. The memo is automatically saved.
Playing a Voice Memo
Playing a Memo You Just Recorded
Tap at the bottom of the screen.
Playing Any Saved Memo
1. Tap at the top right of the screen to see all recordings.
2. Tap the title of a memo to play it.
NOTE: You can also tap at the right of the memo to delete, share, rename, tag, or trim
it, check its le information, or set it as your phone ringtone.
88 89
More Apps
More Apps
Calculator
Press the Home Key > > Calculator to use the phone’s convenient built-in calculator
for some basic as well as advanced mathematical equations.
NOTE: To see more calculator options, swipe left while holding the phone in portrait view
or turn the phone to landscape view.
Clock
Press the Home Key > > Clock. The Clock app allows you to check local time in places
around the world, set alarms, and use timers.
Setting a New Alarm
1. Open the Clock app and tap .
2. Tap a default alarm to congure it, or tap at the bottom of the screen to create a
new alarm.
3. Set up the alarm options, such as time, alarm days, snooze, and alarm ringtone.
4. Tap SAVE to save and exit.
NOTES:
• To enable or disable existing alarms directly, tap On or O on the right side
of each alarm.
• Tap to congure alarm settings, including ringtone volume, vibration, alarm
duration, volume crescendo, and alarm in silent mode.
Using World Time
1. Open the Clock app and tap .
2. World time lets you check local times for cities around the world. Tap to add a
new city.
Using Stopwatch and Countdown
1. Open the Clock app and tap or .
2. Stopwatch allows you to record lap times, while countdown allows you to set a time
and count down to zero.
Dolby Audio
Press the Home Key > > Dolby Audio to select or customize a Dolby prole. You can
also tap to turn o Dolby Audio.
Downloads
The Downloads app keeps a record of the les you have downloaded using apps such
as Browser or Email.
Press the Home Key > > Downloads.
• Tap a le to open it with the appropriate application.
• Press and hold a le to delete or share it.
File Manager
Quickly access all of your images, videos, audio clips, and other types of les on your
phone and on the memory card.
Press the Home Key > > File Manager. Tap CATEGORY to nd the le you need
by category, or tap LOCAL to browse folders and les on the phone storage or the
microSDXC card.
• Tap folders and les to access stored items.
• Tap to create a new folder in the current directory.
• Tap to search for a le or folder by name.
• Press and hold a folder or le for options: copy , move , share , delete , and
more options .
9190
More Apps
More Apps
• To copy or move an item:
1. Press and hold the folder or le.
2. Tap or .
3. Navigate to a new location within File Manager and tap PASTE.
Wi-Fi Utility
Wi-Fi Utility can manage your Wi-Fi settings to provide free and high-speed data by
automatically connecting your phone to reputable Wi-Fi hotspots.
Press the Home Key > > Wi-Fi Utility, and select a Wi-Fi settings option.
Google Apps
NOTE: Some Google services may not be available in your region.
• Chrome: Use the Chrome app to browse the Internet and get your bookmarks,
browsing history, and more synced with your Google account.
• Drive: Store les on Google servers for free after you sign in to your Google
account. You can access them on your computers, your phones, and other
devices, share them, or collaborate with others.
• Gmail: Send and receive emails via your Gmail account or other personal
email accounts.
• Google: Use Google search or get information when you need it with Google Now.
• Hangouts: Chat with Google+ friends or send text or multimedia messages.
• Maps: Find your place and nd your way in the world.
• Photos: Manage photos on the phone and on your Google account.
• Play Movies & TV: Purchase, download, and watch movies and TV shows.
• Play Music: Play music on the phone and on your Google account.
•
Play Store: Purchase and download apps, games, and more from the Google Play store.
• Voice Search: Search for information with your voice.
• YouTube: Watch video clips from YouTube.com, or upload your own and share with
the world.
9392
Settings
Settings
Press the Home Key > > Settings. Settings contains most of the tools for customizing
and conguring your device.
Wireless & Networks
Wi-Fi
Turn Wi-Fi on or o and congure your Wi-Fi connections (see Connecting to Networks and
Devices – Connecting to Wi-Fi).
Bluetooth
Turn Bluetooth on or o and congure your Bluetooth connections (see Connecting to
Networks and Devices – Connecting to Bluetooth Devices).
Mobile Networks
Control mobile data use and data roaming and adjust other network settings (see
Connecting to Networks and Devices – Connecting to Mobile Networks).
Wi-Fi Hotspot
Share your phone's mobile data connection with other devices via Wi-Fi (see Connecting
to Networks and Devices – Sharing Your Mobile Data Connection).
Data Usage
Tap the Mobile data or Set mobile data limit switches to turn on or o mobile data or
the mobile data limit.
You can check how much data has been used during the time cycle you set, set a
mobile data limit and warning, see what apps have been using mobile data, or restrict
background data for individual apps.
NOTE: The data usage is measured by your phone, and your carrier’s data usage
accounting may dier.
94 95
Tap > Network restrictions to select Wi-Fi networks that are mobile hotspots. Apps
may warn you before using these networks for large downloads to avoid high mobile
data bills.
Airplane Mode
In the Settings app, tap More > Airplane mode to turn airplane mode on or o. All the
phone's radios that transmit voice or data are turned o when airplane mode is on.
VPN
In the Settings app, tap More > VPN to set up and connect to virtual private networks
(see Connecting to Networks and Devices – Connecting to Virtual Private Networks).
Default SMS App
In the Settings app, tap More > Default SMS app to choose the preferred application for
sending and receiving messages.
Personal
Display
• Brightness level: Set the brightness of the display.
• Adaptive brightness: Automatically adjust screen brightness.
•
Wallpaper: Select a background image or animation for the home screen or lock screen.
• Sleep: Set the length of time of inactivity before the screen turns o automatically.
• Daydream: Manage the Daydream function. When Daydream is enabled, photos or
animations will be displayed as a screensaver.
• Font size: Set the font size of the text on the screen.
• Auto-rotate screen: Select whether the screen contents should rotate when the
phone is rotated.
• Pulse notication light: Flash the backlight on the Home Key to notify you of missed
calls, new messages, and other events.
Settings
Settings
• Navigation key light duration: Control the backlight of the Home Key, Back Key, and
Recent Apps Key. Choose one of the following options to set the backlight duration:
– Always o: Turn o their backlight.
– Always on: Keep their backlight on while the screen is turned on.
– 2 seconds / 5 seconds: Their backlight comes on for two or ve seconds each time
you touch the screen or keys while the screen is on.
– Auto: Let your phone turn their backlight on or o automatically.
Sound & Notication
Adjust dierent types of volume (see Personalizing – Adjusting Volumes), adjust Dolby
Audio settings, set Do not disturb options (see Personalizing – Using Do Not Disturb Mode),
set up ringtone and notication sound (see Personalizing – Changing the Ringtone and
Notication Sound), select system sounds (see Personalizing – Turning System Sounds On/
O), set notication mode (see Personalizing – Switching to Silent or Vibration Mode), enable/
disable silent power-on/o, control notication display, or check apps that have requested
notication or Do not disturb access.
Security
• Screen lock: Lock the screen with long press, pattern, PIN, or password (see
Personalizing – Protecting Your Phone With Screen Locks).
• Make pattern visible: Show the pattern as you draw it. This option is available when
unlock pattern is set.
• Automatically lock: Set the time needed for the lock protection to be activated after
the screen turns o. This option is available when unlock pattern, PIN, or password is set.
• Power button instantly locks: Lock protection is activated immediately when
you press the Power/Lock Key. This option is available when unlock pattern, PIN, or
password is set.
• Lock screen message: Set the text that you may display on the lock screen.
96 97
• Fingerprint: Set up to ve ngerprints and use them to unlock the phone. You can
also press the ngerprint sensor to take a photo, answer an incoming call, or open a
bound app when the screen is o or locked. See Personalizing – Using Your Fingerprint.
• Smart Lock: Keep the phone unlocked when connected to trusted devices, in trusted
places, when recognizing trusted faces or voices, or while being held or carried.
NOTE: You need to sign in to your Google account on the phone to use the Smart
Lock feature.
• Encrypt phone: Your phone is already encrypted.
• Set up SIM card lock: Lock the nano-SIM card and change the nano-SIM PIN.
– Lock SIM card: Activate or deactivate the PIN lock to require PIN before accessing
the nano-SIM card.
– Change SIM PIN: Change the PIN used to access the nano-SIM card.
NOTE: Put all your condential passwords in a safe place for future use. If you enter the
wrong SIM PIN more times than allowed, your nano-SIM card will be locked and you
cannot access the mobile phone network. Contact your operator for a PIN Unlock Key
(PUK) to restore the nano-SIM card.
• Make passwords visible: Display passwords as you enter them.
• Device administrators: View or deactivate apps you have authorized to be device
administrators.
• Unknown sources: Permit installation of apps from sources other than the Play Store.
• Storage type: Check the credential storage type.
• Trusted credentials: Display trusted CA certicates.
• Install from SD card: Install certicates from the internal storage or the microSDXC card.
• Clear credentials: Delete all certicates.
• Trust agents: View or deactivate trust agents.
• Screen pinning: Keep a screen of your choice in view so others cannot switch apps
and access personal information (see Personalizing – Protecting Your Phone With
Screen Pinning).
Settings Settings
• Apps with usage access: Turn on or o some apps’ access to your phone usage
information.
Navigation Key
You can swap the positions of the Back Key and the Recent Apps Key. Select an option
to make the switch.
Date & Time
Set date, time, time zone, and how time is displayed. You can also use network-provided
data (see Personalizing – Setting the Date and Time).
Language & Input
• Language: Select a language for your system.
• Spell checker: Activate Google Spell Checker to check for spelling errors when
entering text, and change its settings.
• Personal dictionary: Add new words to the phone’s dictionary or remove words from
the dictionary. The words you add are used for spelling check and word suggestion.
• Keyboard & input methods: Congure text input settings (see Knowing the Basics –
Changing Input Methods).
• Text-to-speech output
– Preferred engine: Select the speech synthesis engine you want to use, or change
its settings.
– Speech rate: Select how quickly you want the synthesizer to speak.
– Pitch: Adjust the tone of spoken text.
– Listen to an example: Play a brief sample of the speech synthesizer, using your
current settings.
– Default language status: Check the default language status.
• Pointer speed: Select how fast the pointer/mouse should scroll when you connect the
phone to a trackpad or mouse accessory.
Google
Manage settings for Google apps and services that are installed on your device.
Device
Location
Activate location services to determine your location. To use location-related applications,
such as nding your location on Google Maps, you must have location services turned on
on your phone.
1. Press the Home Key >
2. Slide the Location switch to the On position to turn on location access.
3. When location access is enabled, tap Mode to select the location sources you want to
use. To get your accurate location, choose High accuracy. To save battery power and
get approximate location, choose Battery saving. To use only GPS to pinpoint your
location, choose Device only.
NOTE: Tap Accelerated location and check Location consent to use Qualcomm® IZat™
hardware accelerated location to determine your location.
Storage
The Storage settings menu lets you check memory information for your microSDXC
card and phone storage.
You can choose the default location for new data, such as photos captured and voice
recorded. Tap Save location and select to store items in the phone storage or the
installed microSDXC card.
Under Device storage, tap Phone to get a detailed breakdown of space usage by type.
Tap a data type to see more information or delete the les you do not need.
For more information about using the internal storage and the microSDXC card, see
Connecting to Networks and Devices – Using the microSDXC Card as Portable Storage.
> Settings > Location.
9998
Settings Settings
When you connect a USB storage device (such as a USB ash drive) to your phone with an
OTG adapter cable, you can view its storage status, unmount it, or erase all data on it. See
Connecting to Networks and Devices – Using USB On-the-Go (OTG).
Battery
View remaining battery power and check which items have been using the battery.
Tap an app or service to adjust its settings in order to save battery life. For example, tap
Screen > Reduce the screen brightness and/or screen timeout to change screen
brightness and sleep setting.
Tap > Battery saver to manage battery saving mode. You can turn Battery saver on or
o, or set a battery level at which it turns on automatically.
Tap > Battery optimization. Battery optimization helps prolong battery standby time
when you’re not using the phone. To turn battery optimization o for specic apps, tap
Not optimized > All apps. Tap the app name, and then tap Don’t optimize > DONE.
Apps
Press the Home Key >
manage them.
Tap
> Show system/Hide system to show/hide system apps in the list.
Tap
> Reset app preferences to reset all preferences. (You will not lose app data, but
app preferences will be restored to default.)
Tap
to congure apps.
In the app list, tap an app to see its information. The following options may be available:
• DISABLE/ENABLE: Disable or enable the app.
• FORCE STOP: Stop the app.
• Storage: Check the amount of storage required and clear its data or cache.
• Data usage: Check data used by the app during a specied time cycle and change
background data restriction settings.
100
> Settings > Apps to see apps installed on your phone and
• Permissions: Check or change the app permissions.
• Notications: Manage the app notications in the Notication Panel and the
lock screen.
• Open by default: Check or change settings of the app links and clear defaults.
• Battery: Check the battery use details of the app since last full charge.
• Memory: Check how much memory has been used by the app.
NOTE: Not all options are available for all apps.
Memory
Monitor the average memory use and performance of your phone. You can also check
which apps use the most memory.
Connect to PC
Select the USB connection mode between your phone and PC (see Connecting to
Networks and Devices – Connecting to Your Computer via USB – Connecting Your Phone
to a Computer via USB).
Backup & Reset
• Back up my data: Back up app data, Wi-Fi passwords, and other settings to Google
servers after you sign in to your Google account.
• Backup account: Set the Google account that the data is backed up to.
• Automatic restore: Restore previously backed up settings and data when you reinstall
an app.
• Network settings reset: Reset all your network settings, including Wi-Fi, cellular data,
and Bluetooth.
• Factory data reset: Reset your phone to factory default settings. All your personal
data from the phone's internal storage will be erased. You can also erase the data on
the microSDXC card during the process.
101
Settings
Upgrading the Phone Software
Accounts
Manage your accounts and synchronization. Tap Add account to sign in to or create
accounts on your phone.
Tap an account type to see accounts of that type you have added and adjust their settings.
System
Accessibility
Congure the system accessibility options and accessibility plug-ins on your phone, such
as using Color inversion or Large text for users with sight problems.
Printing
Congure Google Cloud Print™ service or other printer plug-ins installed from the Google
Play Store or your printer manufacturer.
About phone
View phone status, legal information, and other information. Tap Software Update to
check for available software updates for your phone.
102
There are several ways to upgrade your phone software:
1. Use the online upgrade tool for mobile terminal products.
2. Use the one-press upgrade package oered by your mobile service provider.
3. Use your PC to download an upgrade package to your microSDXC card and install it to
your phone from the card.
NOTE: Visit the ZTE ocial handset service support website (http://www.ztedevice.
com/support) and click your country or region to learn more about the above upgrade
methods, as well as which phones and methods are supported.
103
Troubleshooting
Troubleshooting
If you encounter problems while using the phone, or if it performs abnormally, you
can refer to the chart below. If your particular problem cannot be resolved using the
information in the chart, contact the dealer where you purchased the phone.
Problem Possible Causes Possible Solution
The network signal is too weak
Poor reception
Echo or noise
Unable to
select certain
features
104
at your current location (for
example, in a basement or near
a tall building) because wireless
transmissions cannot eectively
reach it.
The network is busy at the
current time (for example,
during peak times, there may
be too much network trac to
handle additional calls).
You are too far away from a base
station for your service provider.
Poor network link quality on the
part of your service provider.
Poor local telephone line quality.
Your service provider does not
support these features, or you
have not applied for services
that provide these features.
Move to a location where the
network signal can be properly
received.
Avoid using the phone at such
times, or try again after waiting a
short time.
You can request a service area
map from your service provider.
End the call and dial again. You
may be switched to a betterquality network link or phone line.
End the call and dial again. You
may be switched to a betterquality network link or phone line.
Contact your service provider.
Problem Possible Causes Possible Solution
Battery not
charging
Shortened
standby time
The battery or battery charger is
damaged.
The phone’s temperature is
below 32°F (0°C) or higher than
113°F (45°C).
Poor contact between the
battery and charger.
The standby time is related to
your service provider system
conguration. The same phone
used with dierent service
providers’ systems will not
provide exactly the same length
of standby time.
The battery is depleted. In
high-temperature environments,
battery life will be shortened.
If you are not able to connect
to the network, the phone will
continue to send out signals as it
attempts to locate a base station.
Doing so consumes battery
power and will consequently
shorten standby time.
Contact the dealer.
Adjust the battery charging
environment to avoid extremes
of temperature.
Check all connectors to make
sure all connections have been
properly made.
If you are located in an area where
signaling is weak, temporarily
power o the phone.
Contact the dealer for a
new battery.
Change your location to one
where the network is accessible,
or temporarily turn o your
phone.
105
Troubleshooting Troubleshooting
Problem Possible Causes Possible Solution
Cannot turn
your phone on
nano-SIM
card error
Battery power has been
depleted.
The nano-SIM card has
malfunctioned or is damaged.
The nano-SIM card is inserted
improperly.
Debris is on the nano-SIM card
contacts.
Recharge the phone’s battery.
Take the nano-SIM card to your
service provider for testing.
Insert the nano-SIM card properly.
Use a soft, dry cloth to clean the
nano-SIM card contacts.
The nano-SIM card is invalid. Contact your service provider.
Unable to
connect to the
network
You are not within the network’s
service area.
Poor signal.
Check the service area with your
service provider.
Move to an open space, or if you
are inside a building, move closer
to a window.
You cannot
answer
incoming calls
You cannot
make outgoing
calls
106
You have activated the Call
barring feature.
You have activated the Call
barring feature.
You have activated the Fixed
Dialing Numbers feature.
Disable this feature. See Phone
Calls – Adjusting Your Call Settings
– Barring Certain Calls.
Disable this feature. See Phone
Calls – Adjusting Your Call Settings
– Barring Certain Calls.
Disable this feature. See Phone
Calls – Adjusting Your Call Settings
– Using Fixed Dialing Numbers.
Problem Possible Causes Possible Solution
Contact your service provider. If
PIN code
blocked
You have entered an incorrect
PIN code three consecutive
times.
the service provider provides the
nano-SIM card’s PUK code, use the
PUK code to unlock the
nano-SIM card.
Phone crashes,
reboots,
freezes, or
cannot be
powered on
Some third-party software is not
compatible with your phone.
Uninstall the software that may be
causing the problem.
Upgrade the phone software.
Reset the phone to factory status.
107
For Your Safety
General Safety
Don’t make or receive
handheld calls while driving.
Never text while driving.
Keep your phone at least
10 mm away from your ear or
body while making calls.
Small parts may cause
choking.
Your phone can produce a
loud sound.
Avoid contact with anything
magnetic.
Keep away from pacemakers
and other electronic medical
devices.
Power o when asked to in
hospitals and medical facilities.
Power o when told to in
aircrafts and airports.
Power o when near explosive
materials or liquids.
108
Don’t use at gas stations.
Your phone may produce a
bright or ashing light.
Don’t dispose of your phone
in re.
To prevent possible hearing
damage, do not listen at high
volume levels for long periods.
Avoid extreme temperatures.
Avoid contact with liquids.
Keep your phone dry.
Don’t take your phone apart.
Only use approved
accessories.
Don’t rely on your phone for
emergency communications.
For Your Safety
Radio Frequency (RF) Energy
This phone is designed and manufactured not to exceed the emission limits for exposure
to radio frequency (RF) energy set by the Federal Communications Commission of the
United States.
During SAR testing, this device was set to transmit at its highest certied power level in
all tested frequency bands, and placed in positions that simulate RF exposure in usage
against the head with no separation, and near the body with the separation of 0.4 inches
(10 mm). Although the SAR is determined at the highest certied power level, the actual
SAR level of the device while operating can be well below the maximum value. This is
because the phone is designed to operate at multiple power levels so as to use only the
power required to reach the network. In general, the closer you are to a wireless base
station antenna, the lower the power output.
The exposure standard for wireless devices employs a unit of measurement known as the
Specic Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6 W/kg.
This device complies with SAR for general population/uncontrolled exposure limits
in ANSI/IEEE C95.1-1992 and has been tested in accordance with the measurement
methods and procedures specied in IEEE1528.
The FCC has granted an Equipment Authorization for this model phone with all
reported SAR levels evaluated as in compliance with the FCC RF exposure guidelines.
SAR information on this model phone is on le with the FCC and can be found under
the Display Grant section of www.fcc.gov/oet/ea/fccid after searching on FCC ID:
SRQ-Z986DL.
For this device, the highest reported SAR value for usage against the head is 0.68 W/kg,
for usage near the body is 1.19 W/kg.
While there may be dierences between the SAR levels of various phones and at various
positions, they all meet the government requirements.
SAR compliance for body-worn operation is based on a separation distance of 0.4 inches
(10 mm) between the unit and the human body. Carry this device at least 0.4 inches
(10 mm) away from your body to ensure RF exposure level compliant or lower to the
109
For Your Safety
For Your Safety
reported level. To support body-worn operation, choose the belt clips or holsters, which
do not contain metallic components, to maintain a separation of 0.4 inches (10 mm)
between this device and your body.
RF exposure compliance with any body-worn accessory, which contains metal, was not
tested and certied, and use such body-worn accessory should be avoided.
FCC Regulations
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause
undesired operation.
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment o and on,
the user is encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
CAUTION: Changes or modications not expressly approved by the manufacturer could
void the user’s authority to operate the equipment.
110 111
Hearing Aid Compatibility (HAC) Regulations for Mobile Phones
In 2003, the FCC adopted rules to make digital wireless telephones compatible with
hearing aids and cochlear implants. Although analog wireless phones do not usually
cause interference with hearing aids or cochlear implants, digital wireless phones
sometimes do because of electromagnetic energy emitted by the phone’s antenna,
backlight, or other components. Your phone is compliant with FCC HAC regulations
(ANSI C63.19-2011).
While some wireless phones are used near some hearing devices (hearing aids and
cochlear implants), users may detect a buzzing, humming, or whining noise. Some
hearing devices are more immune than others to this interference noise, and phones
also vary in the amount of interference they generate. The wireless telephone industry
has developed ratings for some of their mobile phones to assist hearing device users in
nding phones that may be compatible with their hearing devices. Not all phones have
been rated. Phones that have been rated have a label on the box. These ratings are not
guaranteed. Results will vary, depending on the level of immunity of your hearing device
and the degree of your hearing loss. If your hearing device happens to be vulnerable to
interference, you may not be able to use a rated phone successfully. Trying out the phone
with your hearing device is the best way to evaluate it for your personal needs.
This phone has been tested and rated for use with hearing aids for some of the wireless
technologies that it uses. However, there may be some newer wireless technologies used
in this phone that have not been tested yet for use with hearing aids. It is important to
try the dierent features of this phone thoroughly and in dierent locations, using your
hearing aid or cochlear implant, to determine if you hear any interfering noise. Consult
your service provider or the manufacturer of this phone for information on hearing aid
compatibility. If you have questions about return or exchange policies, consult your
service provider or phone retailer.
M-Ratings: Phones rated M3 or M4 meet FCC requirements and are likely to generate
less interference with hearing devices than phones that are not labeled. M4 is the better/
higher of the two ratings.
For Your Safety
For Your Safety
T-Ratings: Phones rated T3 or T4 meet FCC requirements and are likely to be more
usable with a hearing device’s telecoil (“T Switch” or “Telephone Switch”) than unrated
phones. T4 is the better/higher of the two ratings. (Note that not all hearing devices
contain telecoils.)
Your Z986DL has been tested for hearing aid device compatibility and has an M4/T3 rating.
Hearing devices may also be measured for immunity to this type of interference. Your
hearing device manufacturer or hearing health professional may help you nd results for
your hearing device.
For additional information about the FCC’s actions with regard to hearing aid compatible
wireless devices and other steps the FCC has taken to ensure that individuals with
disabilities have access to telecommunications services, please go to www.fcc.gov/cgb/dro.
Distraction
Driving
Full attention must be given to driving at all times in order to reduce the risk of an
accident. Using a phone while driving (even with a hands free kit) can cause distraction
and lead to an accident. You must comply with local laws and regulations restricting the
use of wireless devices while driving.
Operating Machinery
Full attention must be given to operating machinery in order to reduce the risk of
an accident.
Product Handling
General Statement on Handling and Use
You alone are responsible for how you use your phone and any consequences of its use.
You must always turn o your phone wherever the use of a phone is prohibited.
Use of your phone is subject to safety measures designed to protect users and their
environment.
112 113
• Always treat your phone and its accessories with care and keep it in a clean and dustfree place.
• Keep the screen and camera lens clean. Unclean screen or camera lens may slow down
the phone’s reaction to your operations or lower image quality.
• Clean the device and its accessories with a soft material such as cleaning cloth for
eyeglass lenses. Do not use alcohol or other corrosive substances for cleaning or allow
them to get inside.
• Do not expose your phone or its accessories to open ames or lit tobacco products.
• Do not expose your phone or its accessories to liquid, moisture or high humidity.
• Do not drop, throw or try to bend your phone or its accessories.
• Do not use harsh chemicals, cleaning solvents, or aerosols to clean the device or its
accessories.
• Do not paint your phone or its accessories.
• Do not attempt to disassemble your phone or its accessories. Only authorized
personnel can do so.
• Do not expose or use your phone or its accessories in an environment with or that can
reach extreme temperatures, minimum 23°F (-5°C) and maximum 122°F (+50°C).
• Do not place your phone inside or near heating equipment or high-pressure
containers, such as water heaters, microwave ovens, or hot cooking utensils.
Otherwise, your phone may be damaged.
• Please check local regulations for disposal of electronic products.
• Do not carry your phone in your back pocket as it could break when you sit down.
Small Children
Do not leave your phone and its accessories within the reach of small children or allow
them to play with it. They could hurt themselves or others, or could accidentally damage
the phone. Your phone contains small parts with sharp edges that may cause an injury or
may become detached and create a choking hazard.
For Your Safety
For Your Safety
Demagnetization
To avoid the risk of demagnetization, do not allow electronic devices or magnetic media
to be close to your phone for a long time.
Electrostatic Discharge (ESD)
Do not touch the nano-SIM/SD card’s metal connectors.
Antenna
Do not touch the antenna unnecessarily.
Normal Use Position
When placing or receiving a phone call, hold your phone to your ear, with the bottom
towards your mouth.
Air Bags
Do not place a phone in the area over an air bag or in the air bag deployment area as
an airbag inates with great force and serious injury could result. Store the phone safely
before driving your vehicle.
Seizures/Blackouts
The phone can produce a bright or ashing light. A small percentage of people may
be susceptible to blackouts or seizures (even if they have never had one before) when
exposed to ashing lights or light patterns such as when playing games or watching
video. If you have experienced seizures or blackouts or have a family history of such
occurrences, please consult a physician. To reduce the risk of blackouts or seizures, you
can use your phone in a well-lit room and take frequent breaks.
Repetitive Strain Injuries
To minimize the risk of Repetitive Strain Injury (RSI) when texting or playing games with
your phone:
• Do not grip the phone too tightly.
• Press the buttons lightly.
• Use the special features that are designed to minimize the times of pressing buttons,
such as Message Templates and Predictive Text.
• Take many breaks to stretch and relax.
Emergency Calls
This phone, like any wireless phone, operates using radio signals, which cannot
guarantee connection in all conditions. Therefore, you must never rely solely on any
wireless phone for emergency communications.
Loud Noise
This phone is capable of producing loud noises, which may damage your hearing.
Turn down the volume before using headphones, Bluetooth stereo headsets or other
audio devices.
Phone Heating
Your phone may become warm during charging and during normal use.
Electrical Safety
Accessories
Use only approved accessories. Do not connect with incompatible products or
accessories. Take care not to touch or allow metal objects, such as coins or key rings, to
contact or short-circuit the charging jack terminals. Never puncture the surface of the
phone with sharp objects.
Connection to Vehicles
Seek professional advice when connecting a phone interface to the vehicle electrical
system.
115114
For Your Safety
For Your Safety
Faulty and Damaged Products
Do not attempt to disassemble the phone or its accessories. Only qualied personnel can
service or repair the phone or its accessories. If your phone (or its accessories) has been
submerged in water, punctured, or subjected to a severe fall, do not use it until you have
taken it to be checked at an authorized service center.
CTIA Requirements
• Do not disassemble or open, crush, bend or deform, puncture, or shred.
• Do not modify or remanufacture, attempt to insert foreign objects into the battery,
immerse or expose to water or other liquids, expose to re, explosion or other hazard.
• Only use the battery for the system for which it is specied.
• Only use the battery with a charging system that has been qualied with the system
per CTIA Certication Requirements for Battery System Compliance to IEEE 1725. Use
of an unqualied battery or charger may present a risk of re, explosion, leakage, or
other hazard.
• Do not short-circuit a battery or allow metallic conductive objects to contact battery
terminals.
• Replace the battery only with another battery that has been qualied with the system
per this standard, IEEEStd-1725. Use of an unqualied battery may present a risk of re,
explosion, leakage or other hazard.
• Promptly dispose of used batteries in accordance with local regulations.
• Battery usage by children should be supervised.
• Avoid dropping the phone or battery. If the phone or battery is dropped, especially on
a hard surface, and the user suspects damage, take it to a service center for inspection.
• Improper battery use may result in a re, explosion, or other hazard.
• The phone shall only be connected to CTIA certied adapters, products that bear the
USB-IF logo or products that have completed the USB-IF compliance program.
116
Radio Frequency Interference
General Statement on Interference
Care must be taken when using the phone in close proximity to personal medical
devices, such as pacemakers and hearing aids. Please consult your doctor and the device
manufacturers to determine if the operation of your phone may interfere with the
operation of your medical devices.
Pacemakers
Pacemaker manufacturers recommend that a minimum separation of 6 inches (15 cm)
be maintained between a mobile phone and a pacemaker to avoid potential interference
with the pacemaker. To achieve this, use the phone on the opposite ear to your
pacemaker and do not carry it in a breast pocket.
Hearing Aids
People with hearing aids or other cochlear implants may experience interfering noises
when using wireless devices or when one is nearby. The level of interference will depend
on the type of hearing device and the distance from the interference source. Increasing
the separation between them may reduce the interference. You may also consult your
hearing aid manufacturer to discuss alternatives.
Medical Equipment
Turn o your wireless device when requested to do so in hospitals, clinics or healthcare
facilities. These requests are designed to prevent possible interference with sensitive
medical equipment.
Aircraft
Turn o your wireless device whenever you are instructed to do so by airport or airline
sta. Consult the airline sta about the use of wireless devices onboard the aircraft. If
your device oers airplane mode, this must be enabled prior to boarding an aircraft.
117
For Your Safety
Specications
Interference in Vehicles
Please note that because of possible interference with electronic equipment, some
vehicle manufacturers forbid the use of mobile phones in their vehicles unless a handsfree kit with an external antenna is included in the installation.
Explosive Environments
Gas Stations and Explosive Atmospheres
In locations with potentially explosive atmospheres, obey all posted signs to turn o
wireless devices such as your phone or other radio equipment. Areas with potentially
explosive atmospheres include fueling areas, below decks on boats, fuel or chemical
transfer or storage facilities, areas where the air contains chemicals or particles, such as
grain, dust, or metal powders.
Blasting Caps and Areas
Power o your mobile phone or wireless device when in a blasting area or in areas posted
power o “two-way radios” or “electronic devices” to avoid interfering with blasting
operations.
WARNING: This product contains a chemical known to the State of California to cause
cancer, birth defects or other reproductive harm.
118 119
Handset specications are shown in the following table.
Operating system Android 6.0.1 (Marshmallow)
Handset standards LTE/GSM/UMTS/CDMA
Dimensions (H × W × D) 6.5" (H) x 3.3" (W) x 0.37" (D)
Weight 7.36 oz. (with battery)
Display 6" 1920 x 1080
Camera Front 5 MP; Back 13 MP mono + 13 MP RGB
Internal memory ROM: 16 GB, RAM: 2 GB
Removable memory card Supports microSDXC card up to 128 GB
Battery 3,990 mAh (nonremovable)
Continuous idle time Up to 14 days
Continuous talk time Up to 30 hours
WAP browser version WAP 2.0
Bluetooth BT 4.2
HAC M4/T3
NOTE: The phone’s talk time and idle time are based on ideal working environments.
The use of extended backlighting, browser, and network conditions can reduce battery
life and talk/idle time.
Notes
Notes
120 121
Notes
Notes
123122
Notes
124
Loading...
