ZTE Blade L6
User Manual
1
About This Manual
Thank you for choose this ZTE mobile device. In order to
keep your device in its best condition, please read this
manual and keep it for future reference.
Copyright
Copyright © 2015 ZTE CORPORATION
All rights reserved.
No part of this publication may be quoted, reproduced,
translated or used in any form or by any means, electronic or
mechanical, including photocopying and microfi lm, with out the
prior written permission of ZTE Corporation.
Notice
ZTE Corporation reserves the ri ght t o make mo dificati ons on print
errors or update specifications in this guide without prior notice.
This manual has been designed with the utmost care to ensure
the accuracy of its content. However, all statements, information
and recommendations contained therein do not constitute a
warranty of any kind, either expressed or implied. Please refer to
chapter For Your Safety to be sure to use your phone properly
and safely.
We offer self-service fo r our smart terminal device us ers. Please
visit the ZTE official website (at www.ztedevice.com) for more
information on self-service and supported product models.
Information on the website takes precedence.
2
Disclaimer
ZTE Corporation expressly disclaims any liability for faults and
damages caused by unauthorized modifications of the software.
Images and screenshots used in this manual may differ from the
actual product. Content in this manual may differ from the actual
product or software.
Trademarks
ZTE and the ZTE logos are trademarks of ZTE Corporation.
Google and Android are trademarks of Google, Inc.
The Bluetooth® trademark and logos are owned by the Bluetooth
SIG, Inc. and any use of such trademarks by ZTE Corporation is
under license.
microSDHC Logo is a trademark of SD-3C, LLC.
Other trademarks and trade names are the property of their
respective owners.
Version No.: R1.0
Edition Time : 2015.07.29
3
Contents
Getting Started ......................................................... 9
Getting to Know Your Phone ............................................... 9
Knowing the Keys .............................................................. 11
Installing the microSDHC™ Card (Not Included) ............... 13
Charging the Battery.......................................................... 14
Extending the Battery Life ................................................. 15
Powering On/Off ................................................................ 16
Setting Up for the First Time .............................................. 16
Locking/Unlocking the Screen and Keys ........................... 16
Using the Touch Screen .................................................... 17
Getting to Know the Home Screen .................................... 18
Personalizing .......................................................... 20
Changing the System Language ....................................... 20
Setting the Date and Time ................................................. 20
Changing Ringtone and Notification Sound ....................... 20
Adjusting Volume ............................................................... 21
Applying New Wallpapers .................................................. 21
Changing Screen Brightness ............................................. 21
Protecting Your Phone With Screen Locks ........................ 22
Protecting Your Phone With Encryption ............................. 23
Knowing the Basics ............................................... 25
Monitoring the Phone Status ............................................. 25
Managing Notifications ...................................................... 25
4
Managing Shortcuts and Widgets ...................................... 26
Rearranging the Favorites Tray ......................................... 27
Entering Text ...................................................................... 28
Connecting to Networks and Devices .................. 31
Connecting to Mobile Networks ......................................... 31
Connecting to Wi-Fi® ......................................................... 33
Connecting to Bluetooth® Devices ..................................... 36
Connecting to Your Computer via USB .............................. 39
Sharing Your Mobile Data Connection ............................... 41
Connecting to Virtual Private Networks.............................. 44
Phone Calls ............................................................ 46
Placing and Ending Calls ................................................... 46
Answering or Rejecting Calls ............................................. 47
Working With the Call Log ................................................. 47
Calling Your Contacts ......................................................... 48
Checking Voicemail ........................................................... 48
Using Options During a Call............................................... 49
Managing Multi-party Calls ................................................ 50
Adjusting Your Call Settings ............................................... 51
People ..................................................................... 55
Checking Contact Details ................................................... 55
Adding a New Contact ....................................................... 55
Setting Up Your Own Profile .............................................. 56
Importing, Exporting, and Sharing Contacts ...................... 56
5
Searching for a Contact ..................................................... 58
Editing Contacts ................................................................ 58
Messaging .............................................................. 59
Opening the Messaging Screen ........................................ 59
Sending a Message ........................................................... 59
Replying to a Message ...................................................... 60
Forwarding a Message ...................................................... 61
Copying a Message ........................................................... 61
Changing Message Settings .............................................. 61
Calendar ................................................................. 62
Viewing Your Calendars and Events .................................. 62
Creating an Event .............................................................. 64
Editing or Deleting an Event .............................................. 64
Changing Calendar Settings .............................................. 65
Browser .................................................................. 65
Opening the Browser ......................................................... 65
Downloading Files ............................................................. 66
Changing Browser Settings ............................................... 66
Camera .................................................................... 66
Taking Pictures with Your Camera ..................................... 67
Shooting Video with Your Camcorder ................................ 67
Gallery ..................................................................... 68
Opening Gallery ................................................................ 68
6
Working With Albums ......................................................... 68
Working With Pictures........................................................ 69
Music ................................................................................. 71
Copying Music Files to Your Phone ................................... 71
Viewing Your Music Library ................................................ 72
FM Radio ................................................................ 73
Scanning and Saving Channels ......................................... 73
Listening to FM Radio ........................................................ 73
Adding a Radio Station to Favorites ................................... 74
Recording a Voice Memo ................................................... 75
Save the voice recording after stop, or tap Discard
to delete the recording.More Apps ....................... 75
More Apps .............................................................. 76
Backup and Restore .......................................................... 76
Calculator .......................................................................... 76
Chrome™ .......................................................................... 76
Clock .................................................................................. 76
Downloads ......................................................................... 77
File Manager ...................................................................... 78
System Updates ................................................................ 78
Settings .................................................................. 79
Wireless and Networks ...................................................... 79
Device ................................................................................ 81
Personal ............................................................................ 82
7
Accounts ............................................................................ 85
System .............................................................................. 85
Upgrading the Phone Software ............................. 87
Troubleshooting ..................................................... 88
For Y our Safety....................................................... 93
General Safety .................................................................. 93
Distraction ......................................................................... 95
Product Handling ............................................................... 95
Electrical Safety ................................................................. 99
Radio Frequency Interference ......................................... 100
Explosive Environments .................................................. 102
8
Getting Started
Getting to Know Your Phone
Earpiece
Touch Screen
Indicator
Camera
Volume Key
Power Key
Home Key
Back Key
Menu Key
9
k
Camera
Speaker
Charging/ USB Jack
10
Headset Jac
Flash
Back Cover
Knowing the Keys
Key Function
Power Key
Home Key
Menu Key
Back Key
Volume Keys
NOTE:
Y ou can ex chan ge the positi on s of th e Back K ey and Menu Key.
Touch the Home Key > > Settings > Hard Key and select
one case.
Installing the SIM Card
Power off your phone before installing or removing the SIM
card.
WARNING!
1. To avoid damage to the phone, do not use any
non-standard nano-SIM card / micro-SIM card. You can get the
Hold to turn on or off Airplane mode, or to
power off.
Press to switch your phone to Sleep mode.
Press to wake up your phone.
Press to return to the Home Screen from any
application or screen.
Hold to see Google search .
Press to see recently used applications.
Press to go to the previous screen.
Press or hold to turn the volume up or down.
11
standard nano-SIM card / micro-SIM card from your service
provider.
1. Insert the tip of the tray eject tool into the hole on the SIM card
tray.
2. Pull out the SIM card tray and place the SIM cards on the tray,
as shown. Then carefully install the tray back.
NOTES:
12
Place your WCDMA or GS M micro-S IM card o n the Card Slot
1.
Place your GSM nano-SIM card on the Card Slot 2.
Note: The Card Slot 1 can only be placed the micro-SIM card,
while the Card Slot 2 can be placed the nano-SIM card and SD
card.
Installing the microSDHC™ Card (Not Included)
A microSDHC card can be installed or removed while the
phone is turned on. You need to unmount the microSDHC
card before removing it.
1. Insert the tip of the tray eject tool into the hole on the
microSDHC card tray.
2. Pull out the tray and place the card on the tray, as shown.
Then carefully install the tray back.
13
NOTE:
Some applications may require a microSDHC card to work
normally or may store certain data on it. Therefore, it is
recommended that you keep a microSDHC card installed
and not remove or replace it randomly.
Charging the Battery
Your phone’s battery should have enough power for the
phone to turn on, find a signal, and make a few calls. You
should fully charge the battery as soon as possible.
WARNING!
Use only ZTE-approved chargers and cables. The use of
unapproved accessories could damage your phone or cause
the battery to explode.
CAUTION:
Do not remove or change the built-in rechargeable battery in
your phone by yourself. The battery can only be changed by
ZTE or ZTE authorised service provider.
1. Connect the adapter to the charging jack. Ensure that the
adapter is inserted in the correct direction.
14
2. Connect the charger to a standard AC power outlet.
3. Disconnect the charger when the battery is fully charged.
NOTE:
If the battery is extremely low, you may be unable to power on
the phone even when it is being charged. In this case, try
again after charging the phone for at least 20 minutes.
Contact the customer service if you still cannot power on the
phone after prolonged charging
.
Extending the Battery Life
Active applications, screen brightness lev els, Blueto oth and Wi-Fi
usage and GPS functionality can drain your battery. You can
follow the helpful tips below to conserve your battery power:
Reduce the screen backlight time.
Lower the screen brightness.
15
Turn auto-sync, Wi-Fi, and Bluetooth off when not in use.
Disable the GPS function when not in use. Most applications
using this function will periodically query the GPS satellites
for your current location; each query drains your battery.
Powering On/Off
Press and hold the Power Key to turn on your phone.
To turn it off, press and hold the Power Key to open the
options menu. Touch Power off > OK .
Setting Up for the First Time
When you first power on your phone after you purchase it or
reset it to factory settings (see Settings – Personal – Backu p and
Reset), you need to do some settings before using it.
Flick the language field to select the language and touch .
Then follow the prompts to set up Wi-Fi, G oogle A cco unt, G oogle
location and other options.
Locking/Unlocking the Screen and
Keys
Your phone allows you to quickly lock the screen and keys (put
the phone into sleep mode) when not in use and to turn the
screen back on and unlock it when you need it.
16
To lock the screen and keys:
To quickly turn the screen off and lock the keys, press the Power
Key.
NOTE:
To save battery power, the phone automatically turns off the
screen after a certain period of time when you leave it idle. Y ou
will still be able to receive messages and calls while the phone
screen is off.
To unlock the screen and keys:
1. Press the Power Key to turn the screen on.
2. Touch and swipe up to unlock the screen.
NOTE:
If you have set an unlock pattern, PIN or password for your
phone (see the chapter Personalizing – Protecting Your Phone
With Screen Locks), you’ll need to draw the pattern or enter the
PIN/password to unlock your screen.
Using the Touch Screen
Your phone’s touch screen lets you control actions through a
variety of touch gestures.
Touch
When you want to type using the onscreen keyboard, select
onscreen items such as application and settings icons, or
press onscreen buttons, simply touch them with your finger.
17
Touch and Hold
To open the available options for an item (for example, a
message or link in a Web page), touch and hold the item.
Swipe or Slide
To swipe or slide means to quickly drag your finger vertically
or horizontally across the screen.
Drag
To drag, press and hold your finger with some pressure
before you start to move your finger. While dragging, do not
release your finger until you have reached the target position.
Pinch
In some apps (such as Maps, Browser, and Gallery), you can
zoom in and out by placing two fingers on the screen at once
and pinching them together (to zoom out) or spreadi ng them
apart (to zoom in).
Rotate the screen
For most screens, you can automatically change the screen
orientation from portrait to landscape by turning the phone
sideways.
Getting to Know the Home Screen
The home screen is the starting point for your phone’s
applications, functions, and menus. You can customize your
home screen by adding application icons, shortcuts, folders,
widgets, and more. Your home screen extends beyond the initial
18
screen. Swipe the screen left or right to display additional
screens.
Wallpaper
Favorite Tray
Shortcuts
Status &
Notifications
Google Search
Shortcut
Extended Home Screens
Your home screen extends beyond the initial screen, providing
more space to add icons, widgets, and m ore. Simply swipe left or
right on the screen to see the extended home screens.
19
Personalizing
Changing the System Language
1. Touch the Home Key > > Sett ings > Language &
input > Language.
2. Select the language you need.
Setting the Date and Time
1. Touch the Home Key > > Settings > Date & time.
2. Uncheck Automatic date & time and Automatic time zone
if you want to set the date, time and time zone by yourself.
3. Set the date, time, time zone, and date/time format.
Changing Ringtone and Notification
Sound
You can customize the default ringtone for incoming calls and th e
default notification sound quickly.
1. Touch the Home Key > > Settings >Sound &
notification>
2. Touch Phone ringtone or Default notification sound.
3. Scroll through the ringtone list and select the ringtone you
want to use.
.
20
4. Touch OK.
Adjusting Volume
1.Touch the Home Key > > Settings >Sound &
notification> .
2.Drag the sliders to adjust the volume for each type of audio.
NOTE:
You can adjust the media volume when a media application is in
use by pressing the Volume Up/Down Key. If no media
application is active, press the Volume Up/Down Key to adjust
ringtone volume (or the earpiece volume during a call).
Applying New Wallpapers
You can set the wallpaper for the Home Screen.
1. Press Home Key to return to the Home Screen.
2. Press and hold Home Screen and select WALLPAPERS.
3.Choose the image or animation you want to use as the
wallpaper. Some cropping may be needed for Gallery images.
4.Touch Set wallpaper.
Changing Screen Brightness
1.Touch the Home Key > > Settings > Display >
Brightness level.
2.click next to the Adaptive brightness to turn it on to make
21
the phone adjust the screen brightness automatically, or drag the
slider to adjust the brightness manually.
Protecting Your Phone With Screen
Locks
You can protect your phone by creating a screen lock. When it is
enabled, you need to touch and hold certai n icon, look at the fr ont
camera, draw a pattern or enter a numeric PIN or a password to
unlock the phone’s screen and keys.
1.Touch the Home Key > > Settings > Security.
2.Touch Screen lock.
3.Touch Pattern, PIN or Password.
If you touch Pattern, you’re guided to create a pattern you
must draw to unlock the screen. The first time you do this,
a short tutorial about creating an unlock pattern appears.
Then you’re prompted to draw and redraw your own
pattern.
If you touch PIN or Password, you’re prompted to set a
numeric PIN or a password you must enter to unlock your
screen.
NOTE:
Screen lock options are listed in the approximate order of the
strength of their security, starting with None, which provide no
security. A pattern provides minimal security, although it can be
more convenient than the stronger options.
22
Protecting Your Phone With Encryption
You can encrypt all the data on your phone: Google Accounts,
application data, music and other media, dow nloaded informatio n,
and so on. If you do, you must enter a numeric PIN or a
password each time you power on your phone.
WARNING!
Encryption is irreversible. The only way to revert to an
unencrypted phone is to perform a factory data reset which
erases all your data.
Encryption provides additional protection i n ca se y our phone is
stolen and may be required or recommended in some
organizations. Consult your sy stem admi nis trato r bef ore turni ng it
on. In many cases the PIN or password you set for encryption is
controlled by the system administrator.
Before turning on encryption, prepare as follows:
Set a lock screen PIN or password.
Charge the battery.
Keep the phone connected to the charger.
Schedule an hour or more for the encryption process. You
must not interrupt it or you will lose some or all of your data.
When you're ready to turn on encryption:
1.Touch the Home Key > > Settings > Security > Encrypt
phone.
2.Read the information about encryption carefully.
The Encrypt phone button is dimmed if your battery is not
23
charged or your phone is not plugged in.
If you change your mind about encrypting your phone, touch
the Back Key.
WARNING!
If you interrupt the encryption process, you will lose data.
3.Touch Encrypt phone.
4.Enter your lock screen PIN or password and touch Next.
5.Touch Encrypt phone again.
The encryption process starts and displays its progress.
Encryption can take an hour or more, during which time your
phone may restart several times.
When encryption is completed, you're prompted to enter your
PIN or password.
Subsequently you must enter your PIN or password each time
you power on your phone in order to decrypt it.
24
Knowing the Basics
Monitoring the Phone Status
The status bar at the top of the home screen provides phone and
service status icons on the right side. Below are some of the
icons you may see.
Flight mode Signal strength
Wi-Fi in use Alarm set
Wired headset
connected
Battery full Vibrate mode
Battery charging Bluetooth on
Managing Notifications
Notification Icons
The status bar at the top of the home screen provides notific ation
icons on the left. Below are some of the icons you may see.
New SMS
New MMS GPS on
Ringer off
microSDHC card removed
25
New email
New Gmail message
Missed call
New Wi-Fi network detected
Updates available
USB connected
Open/Close the Notification Panel
Notifications report the arrival of new mes sages , calend ar
events, and alarms, as well as ongoing e vents, such as when
you've configured your phone as a Wi-Fi hotspot. You can open
the notification panel to view the details of notifications.
To open the notification panel, swipe your finger down from
the top of the screen.
To close the notification panel, swipe your finger up from the
bottom of the screen or touch the Back Key.
Managing Shortcuts and Widgets
Add Shortcuts
1.Touch the Home Key > .
2.Touch and hold a shortcut and drag it to the Home Screen.
Add Widgets
1. Press Home Key to return to the Home Screen.
2. Press
and hold Home Screen and select WIDGETS.
26
3.Touch and hold a widget and drag it to the Home Screen.
Move Shortcuts or Widgets
1.Touch and hold a widget or shortcut on the Home Screen.
2.Drag it to the place you need.
Remove Shortcuts or Widgets
1.Touch and hold a widget or shortcut on the Home Screen.
2.Drag it to to remove it.
Adjust Widget Size
1.Touch and hold a widget on t he Home S cre en and then rele ase
it.
2.An outline appears around the widget. Drag the outline to
resize the widget.
NOTE:
Not all widgets can be resized.
Rearranging the Favorites Tray
The Home Screen includes a customizable favorites tray at
the bottom visible from all Home Screens. Y ou can drag apps,
shortcuts, folders, and other priority items in or out of the
favorites tray for instant access from any Home Screen.
27
To remove items from the favorites tray:
Touch and hold an item in the favorites tray and drag it out of the
tray.
To add items to the favorites tray:
Touch and hold an item on the Home Screen and drag it into the
favorites tray.
If the favorites tray is full, you need to first remove an item from
the tray.
Entering Text
You can enter text using the onscreen keyboard. Some apps
open it automatically. In others, you open it by touching where
you want to type. You can touch the Back Key to hide the
onscreen keyboard.
Change Input Methods
1.When you use the onscreen keyboard to enter text, the icon
appears on the notification bar.
2.Open the notification panel
3.Select an input method you need.
28
Android Keyboard
The Android Keyboard provides a layout similar to a desktop
computer keyboard. Turn the phone sideways and the keyboard
will change from portrait to landscape. The land scape keyboard
is not supported in all applications.
Touch the alphabetic keys to enter letters. Touch and hold
some specific keys to enter associated accented letters or
numbers. For example, to enter è, touch and hold and the
available accented letters and number 3 appear. Then slide
to choose è.
Touch to use uppercase. Double-tap to lock
uppercase. This key also changes to indicate the current
case you are using: for lowercase, for uppercase, and
when locked in uppercase.
29
Touch to delete the text before the cursor.
Touch to select numbers and symbols. You can then
touch to find more. Also, often used symbols are
displayed above the keyboard.
Touch to use Google’s networked voice input.
Google Voice Typing
Google Voice typing uses the Goog l e v oice rec ogniti o n serv ice to
convert speech to text. You must have a data connecti on on a
mobile or Wi-Fi network to use it.
1. Flick down the status bar when entering text and touch
Choose input method, and then select Google voice
typing.
Or touch to access the voice typing when you are using
the Android Keyboard.
2. When you see the microphone image, speak what you want
to type.
3. You can continue entering text to keep it or to delete it.
NOTE:
Say "comma," "period," "question mark," "exclama tion mark," or
"exclamation point" to enter punctuation.
Input Settings
Choose input settings by tapping > Settings > Language
& input from the Home Screen.
30
Loading...
