ZTE K3806 Z Users Manual

ZTE CORPORATION NO. 55, Hi-tech Road South, ShenZhen, P.R.China Postcode: 518057 Tel: (86) 755 26779999 URL: http://www.zte.com.cn E-mail: mobile@zte.com.cn

K3806-Z

USB Modem

Quick Guide

LEGAL INFORMATION

No part of this publication may be excerpted, reproduced, translated or utilized in any form or by any means, electronic or mechanical, including photocopying and microfilm, without the prior written permission of ZTE Corporation.

The manual is published by ZTE Corporation. We reserve the right to make modifications on print errors or update specifications without prior notice.

Version No. : R1.0

C h a p t e r 1

Quick Guide

Introduction

The ZTE USB modem is a multi-mode USB modem, working in HSPA+/HSUPA/HSDPA/ WCDMA/EDGE/GPRS/GSM networks. With USB interface connecting to a laptop or a desktop PC, it integrates the functionality of a modem and a mobile phone (SMS), and combines mobile communication with Internet perfectly. It supports data and SMS services through the mobile phone network, enabling you to communicate anytime and anywhere.

Specification

The following table shows the specification of your device.

Interface Type USB 2.0 HIGH SPEED

Systems supported Supports most types of laptop and desktop PC.

Operating systems supported

Functions SMS service, Data service, Applications management,

Network Standards HSPA+/HSUPA/HSDPA/WCDMA/EDGE/GPRS/GSM

Transmission speed (Max)

Temperature Storage: -40 ~ +80℃℃

Dimension 74mm*26mm*12mm

Weight About 26g

microSD capability Support up to 32GB microSD card

Windows XP(SP2 and later), Vista(32bit and 64 bits), Windows 7

MAC 10.4 later

support microSD card, etc.

HSUPA: 5.76Mbps UL HSDPA: 14.4Mbps DL

Operation:-10 ~ +55℃℃

Notes:

microSD

is a trademark of SD Card Association.

Getting to know your device

The following figure shows the appearance of the MF652. It is only for your reference. The actual product may be different.

Confidential and Proprietary Information of ZTE CORPORATION 1
