Zotac ZBOX pico PI335 Technical data

PI335 PICO GEMINI LAKE

Windows 10 Home in S Mode

SKU: ZBOX-PI335-GK-W2D/W3D

ZOTAC ZBOX PICO doubles the viewing capacity with
more power in one of the smallest form factors. Prepare
for durable performance in a package small enough to
slide into your pocket, making it nimble for easy
placement. Designed for silent performance, we’ve
equipped an ever more powerful fanless cooling
solution to answer to the power upgrade while
maintaining no moving parts. With HDMI and
DisplayPort outputs available, greater display options
are available, or use both to double your desktop size.
Pre-installed with Windows, it’s ready to hit the ground
running out of the box.

MINI PC

FANLESS

OPERATION

802.11 AC
WIFI

HIGH SPEED

USB 3.0

MICRO SDXC

CARD READER

FEATURES

• Passive cooling

• 802.11ac WiFi & Bluetooth 5

• Microsoft DirectX 12 compatible

SPECIFICATIONS

• Intel UHD Graphics 600

• Intel N4100 (Gemini Lake)

(quad-core 1.1 GHz, up to 2.4 GHz)

DISPLAY OUTPUTS

• HDMI 2.0 (3840X2160 @60Hz)

• DisplayPort 1.2 (up to 4096X2160 @60Hz)

AUDIO OUTPUTS

• Digital 8 Channel Loss-less Bitstream (via HDMI)

• Headphone/Mic in combo

GIGABIT

LAN

ULTRA

HD

TECHNICAL SPECIFICATIONS

PASSIVE COOLED

HARD DRIVE & MEMORY

• 64GB eMMC onboard storage

• 4GB LPDDR4 onboard memory

REAR SIDE PORTS

• 1 x USB 3.0 Type-C

• 1 x Gigabit Ethernet

INSIDE THE BOX

• ZOTAC ZBOX PI335 pico Gemini Lake

• Universal Power Adapter with Multiple Plugs

• OS Recovery USB Flash Drive

• User Manual and Quick Install Guide

• VESA mounting bracket (w/ screws)

• CTIA / OMTP adapter

RIGHT SIDE PORTS

• Power Button

• Power LED

LEFT SIDE PORTS

• 2 x USB 3.0

• Power Connector

FRONT SIDE PORTS

• micro SDHC/SDXC slot

SOFTWARE COMPATIBILITY

• Microsoft Windows 10 Home in S Mode* 64-bit pre-installed

MINI PC DIMENSIONS

• Length: 115mm (4.53in)

• Width: 76mm (2.99in)

• Height: 20.7mm (0.81in)

BOX DIMENSIONS

• Length: 178mm (7.01in)

• Width: 175mm (6.89in)

• Height: 53mm (2.09in)

For more information please visit:

ZOTAC.COM

*Windows 10 Home N in S Mode for Regions of Europe. Extended warranty exclusions may apply based on country/region.
(Product Registration is required within 30 days of purchase on zotac.com)
