ASSEMBLY (cont.):

™

Congratulations on your purchase of Zoo Med’s REPTI

BREEZE™ IGUANARIUM. The following instructions will

assist you with the proper assembly of your new habitat. Please read the following instructions carefully prior to assembly. If you have any
questions regarding these instructions or the proper use of this item, please contact our customer service [e-mail] or
by calling [phone] (US and Canada only). Customers in other countries, please call [phone].

Your new REPTI BREEZE™ IGUANARIUM® includes the following components (see fig. 1):

QTY. ITEM

1 Back panel
1 Upper front panel with door
1 Top panel with door
2 Left and right side panels
1 Lower Front Panel
1 Bottom Tray with caster brackets
1 Basking Shelf
4 Caster wheels
8 Angle brackets
32 Screws and nuts for corner brackets
22 Panel assembly screws (Black)

TOOLS REQUIRED:

• Phillips screwdriver with #2 tip.

• Adjustable wrench.

fig. 1

Upper Front

with Door

Left

Side

Lower Front

Casters

INSTRUCTIONS

Top

with Door

Back

Bottom

Basking

Shelf

Right

Side

ASSEMBLY TIPS:

• Prior to assembly, check to make sure
that there are no missing pieces.

• Do not over-tighten the screws to avoid stripping the holes in the cage.

• For ease of assembly, assemble the panels in the order listed below. Be sure to match up the corresponding letters for each panel
during assembly.

ASSEMBLY:

1. Attach SIDE PANELS to BACK PANEL (see fig. 2): Stand the back panel on its bottom edge with side “A” up. Attach the left and right side

panels to the back panel using the black panel assembly screws. Be sure to match the letters B and C on the back panel to the corresponding
letters on the side panels. Note: The panel label stickers should face “out” as shown in the photos.

2. Attach LOWER FRONT PANEL to SIDE PANELS (see fig. 3): Place the lower front panel between the side panels as shown, matching the

letters E and D on the
lower front panel to the
corresponding letters
on the side panels. The
door latch brackets
should face out and
are located on the top
edge. Screw the
panels together using
the black panel
assembly screws.

3. Attach the UPPER

FRONT PANEL WITH
DOOR to SIDE
PANELS (see fig. 4):

Place the upper front panel with door between the two
side panels as shown. The letters E and D on the upper
front panel should match the corresponding letters on the
side panels. Secure the latches on the door to the door
latch brackets on the lower front panel.

4. Install the ANGLE BRACKETS in the upper and lower

corners (see fig. 5 and 6): Attach the angle brackets to

the upper and lower corners of the IGUANARIUM. First,
install brackets in the upper four corners. Then, flip the
cage over and install the remaining brackets in the
bottom four corners. Each bracket is secured with four
screws and four nuts. When finished, turn the cage back over to the upright position.

fig. 2

fig. 3

fig. 5

fig. 4

fig. 6

5. Install the BASKING SHELF

(see fig. 7 and 8): To install the

basking shelf, insert it into the cage at
an angle through the opening in the top.
Attach the two brackets along one edge
of the shelf to the cage at the desired
height. Make sure that the brackets are
securely clipped to the wire as shown.
Then, lower the opposite side of the
shelf and attach the remaining
two clips.

fig. 8

fig. 10

fig. 13

6. Attach the TOP

PANEL WITH
DOOR (see fig. 9):

Rest the top panel
on the cage,
aligning letters
A, F, G, and H.
Screw the top
panel to the cage
using the black
panel screws.
Secure the top
door using the
latch.

fig. 11

fig. 9

fig. 7

7. Attach

CASTERS
(see fig. 10):

Attach the
four casters to
the caster
brackets on
the bottom
tray by
inserting the
casters into
the holes of
the brackets.

fig. 12

8. Attach the cage assembly to the BOTTOM TRAY (see fig. 11, 12 and 13): Place the cage assembly on the bottom tray and

attach the spring clips onto the bottom tray as shown. Remove the panel identification stickers. Your REPTIBREEZE IGUANARIUM
is now assembled and ready to use!
