Page 1
Model 4402
Wireless-N Router
combines
4-port Ethernet Switch,
Wireless-N Access Point,
and More
•
Connects to an ADSL Modem or Cable Modem for shared Internet access
International
Headquarters
Zoom Telephonics, Inc.
207 South Street
Boston, MA 02111
USA
Tel: 617 423-1072
Fax: 617 423-3923
email: [email protected]
www.zoom.com
OTCBB: ZMTP
European
Sales/Support
Zoom Telephonics, Inc.
Central House
2 Kings Road
Fleet, Hants
GU51 3AD UK
Tel: +44 (0) 1252 625323
Fax +44 (0) 1252 617920
©2010 Zoom Telephonics, Inc.,
207 South Street, Boston, MA 02111 USA
Zoom is a registered trademark of Zoom
Telephonics, Inc. Windows 2000, Windows
Vista and Windows XP are registered
trademarks of Microsoft Corporation. Wi-Fi is
a registered trademark of the Wi-Fi Alliance.
All other registered trademarks and
trademarks used herein are the property of
their respective holders.
•
Router supports networks with up to 253 computers and other devices
•
High data speeds and extended wireless coverage
•
Provides advanced network security and easy setup
The Model 4402 wireless-N router is an excellent choice for almost any home or business. It supports high
data speeds, a wide wireless coverage area, and up to 253 users. The Model 4402 connects easily to a
broadband modem to provide shared Internet access to all the computers and other devices on its
network. It features all the popular forms of wireless security, Wi-Fi Protected Setup (WPS), and local or
remote configuration using a browser. And it’s supported by Zoom Telephonics, a US-based leader in
communication products since 1977.
• Typically connects to the Ethernet port of an ADSL Modem, Cable Modem, or other broadband modem to provide
shared Internet access
• Built-in wireless-N router supports 802.11 n, g, b, and mixed wireless networks
• Built-in 4-port Ethernet switch allows direct connection of computers, Ethernet switches, HomePlug® adapters, and
other network devices.
• Wireless data speeds up to 150 Mbps even without compression
• Wireless range is typically up to 1000 feet (304 meters) outdoors. Indoor range varies depending on walls and other
obstructions.
• Can be configured as a Wireless Repeater to extend the reach of your network
• High security with WPS, 64 and 128 bit WEP, WPA, WPA2, NAT, SPI, protection from Denial of Service (DOS) attacks,
MAC/ Port/IP filtering, and URL blocking
• Includes detachable external antenna to allow easy attachment of a special purpose antenna for the extraordinary
situations where this is required
• Easy Installation and Setup with Universal Plug and Play and built-in setup wizard
• Highly interoperable product works with ADSL modems, Cable modems, WiMAX modems, Windows® and Macintosh
computers, Wi-Fi® compatible phones including the iPhone® and Blackberry®, the iPod® Touch, Nintendo® DS,
PlayStation PSP, HomePlug® adapters, VoIP adapters, and more.
• 1 year warranty and support by Zoom Telephonics, a communication products leader since 1977
®
Page 2
Model 4402
Wireless-N
Router
Specifications
Standards • 802.11b/g/n (Wireless LAN)
Interface • Four 10/100 Mbps RJ45 Ethernet LAN ports
• One 10/100 Mbps RJ45 Ethernet WAN port
Product Configuration as a: •Broadband Router with integrated 4-port switch to support concurrent Internet access by
wired and wireless clients
or a
• Wireless access point for providing wireless access to a network
or a
• Repeater to extend the range of a wireless network
Security • 64/ 128 bit, WEP (Wired Equivalent Privacy) with Pass Phrase
• WPA (WiFi
Radio Technology • 802.11b: Direct Sequence Spread Spectrum (DSSS)
• 802.11g: Orthogonal Frequency Division Multiplexing (OFDM)
• 802.11g: Orthogonal Frequency Division Multiplexing with Multiple Input
and Multiple Output (MIMO)
Antennas • Adjustable omni-directional dipole antenna
Transmission Rates • 1 Mbps to 150 Mbps
Range Coverage • Indoor : Up to 100 Meters (328 Feet) depending on environment
• 150 Mbps @20MHz - 68dBm (Typical)
• 150 Mbps @40MHz - 65 dBm (Typical)
• Outdoors: Up to 400 Meters (1312 Feet) depending on environment
Receiver Sensitivity • 54 Mbps: Typical -70 dbm @ (Typical)
• 11 Mbps: Typical -88 dbm @ (Typical)
LED Status Indicators • Power
• Wide Area Network Link/Activity
• Wired LAN Activity: for each Ethernet port
• Wireless LAN Activity
Wireless LAN • IEEE 802.11b/g/n 2.4000 to 2.4835 GHz
Frequency Range • US (FCC) Channel 1 through 11
• Europe (ETSI) Channel 1 through 13
®
Protected Access) and WPA2 with Pass Phrase
Dimensions (L x W x H) • 136 x 87 x 24 mm (5.4 x 3.4 x .9 inches)
Weight • 152 grams / .32 LBS
Power Supply • Output: 12V DC, 1 Amp
Temperature • Operating 0˚ to 40˚ C (32˚ to 104˚ F)
Humidity • 5 -95% non-condensing
Transmit Power (typical) • 11b: 18± 1dBm
Compliance • FCC
System
Requirements
Configuration requires a computer with an
Internet browser and either Wifi or an
Ethernet port. Clients on the network must
support TCP/IP.
• Storage -0˚ to 70˚ C (-32˚ to 158˚ F)
• 11g: 15± 1dBm
• 11n: 18± 1dBm
• CE
• Restriction of Hazardous Substances (RoHS)
Package Contents
- Wireless-N Router
- Energy-saving switching power
cube, 100 to 240 VAC, 50/60 Hz
- Ethernet cable
- Quick Start Flyer
in English and Spanish
- CD with User Manual
in English and Spanish
4402 17310
