Page 1
Zoom Networking
Model 4160 Internet Gateway
The Model 4160 Internet Gateway provides shared Internet access, printer sharing, and local
area networking management for multiple PCs in a home or small business. Advanced security
features protect PCs connected to the network from hacker attacks. Installation, operation and
management are easy and accomplished using a simple graphic user interface (GUI).
General Features include:
• All local area network (LAN) users can share an Internet connection through an ADSL
modem, cable modem, ISDN terminal adapter, or analog modem using NAT (Network
Address Translation); LAN users share one valid external IP address, while retaining their
local IP address
• LAN connections are supported through two 10/100BaseT Ethernet ports. Additional PCs
can be connected to the Model 4160 by simply plugging in a network hub to one of the
Ethernet ports. WAN support is provided by a 10BaseT Ethernet port and an RS-232 serial
port
• Provides firewall protection to the LAN against external attacks. Firewall configuration is
password protected. Firewalls include: NAT, Port Redirect, Packet Filtering, and Stateful
Packet Inspection
• Can be both a DHCP server or a DHCP client
• Protocols supported include: TCP/IP, PPPoE, HTTP
• Virtual private networking support with PPTP and IP Sec pass-through
• Specified software applications can be supported through the firewall with factory
configuration, or by user configuration
• Printer sharing through a parallel interface
Management Features include:
• LAN Administrator can limit the Internet access of individual workstations or groups of
workstations
• Configuration and management can be done through a PC directly attached to the Gateway,
or remotely from authorized PCs on the LAN using any Web browser software. The interface
is Operating System independent and easy to use.
• Upgrades to the firmware can be done through the Web, through a Windows application, or
through FTP (File Transfer Protocol)
Ports supported include:
• WAN Ports: 10BaseT, serial DB-9
• LAN Ports: wired 10/100BaseT (auto-switched)
• Printer Sharing Port: DB-25
Page 2
Model 4160 Internet Gateway
Technical Specification
Port Characteristics:
One WAN Port, RJ-45 Interface (10Mbps, IEEE 802.3 10BaseT)
Two LAN Ports, RJ-45 Interface (10/100Mbps, IEEE 802.3/802.3u 10BaseT/100BaseTX)
One Printer Port, Female DB-25 Interface
One COM Port RS-232 port, male DB9 Interface
Features:
NAT Router - Ethernet Interface
IP Address Static or Dynamic (DHCP)
PPP over Ethernet
Maximum Users: 253
NAT Router - Asynchronous Interface
Dial-on-demand
Firewall:
- Network Address Translation (NAT); Port Redirect; Stateful Packet Inspection (SPI);
Access Control:
- By Group, Allow all, Block all, Allow or block by port;
International
Headquarters
Zoom Telephonics, Inc.
207 South Street
Boston, MA 02111
USA
Tel: 617 423-1072
Fax: 617 423-3923
European
Sales/Support
Zoom/Hayes
430 Frimley Business Park
Frimley, Camberley
Surrey, GU16 5SG UK
Tel: +44 (0) 1276 704400
Fax +44 (0) 1276 704500
email: [email protected]
Website: www.zoom.com
NASDAQ: ZOOM
Special Application Support:
- Battle.net, Dialpad, ICU II, MSN Gaming, PC-to-Phone, Quick Time 4 and User Defined.
Systems Certifications: ETSI-CE, FCC Part 15b&c, VCCI and UL
Power 11 Volts AC to 12 Volts DC
Dimensions 20 cm x 11.5 cm x 4 cm (7.8” x 4.5” x 1.6”)
Weight 1.39 Kg (3 lbs.)
Made in U.S.A.
