Automatic suction c leaner
High performance
cleaning from top to
bottom for all types
of swimming pools.
www.zodiac-poolcare.com
ZODIAC POOL CARE EUROPE
ZI Est - 34, rue Francine Fromont
69120 Vaulx-en-Velin - France
Tel. 33 (0)4 78 79 56 20
Fax 33 (0)4 78 79 56 29
zpce@zodiac.com
Réf.WL 05014. Ed. 11/07
- Zodiac Pool Care Europe - S.A.S.U. au capital de 400 000 € - 395 068 679 RCS Nanterre - J.P. Bajard
ZODIAC, MASTERING THE ELEMENTS.
Renowned worldwide for the quality and reliability of its products in the
aeronautical and marine sectors, Zodiac has now brought its expertise to
swimming pools, to bring you a full range of pools, automatic pool cleaners,
water treatment systems, heating systems and dehumidification units for
swimming pools.
Backed by Baracuda technology, expertise and experience, Zodiac brings you
the reassurance of top quality equipment in terms of both design and
performance.
A real guarantee of efficiency and peace of mind!
Super G+ uses a filtration system as a source of energy. Easy to install, it connects
to the skimmer or the suction point without any need for additional equipment. The
power from the pool’s pump enables it to move around automatically and at random,
to suck up debris, which is then stored in the pump basket and filter.
High performance cleaning from top to
bottom for all types of swimming pools.
• 12 hose sections
• A flow tester
• An automatic flow adjustment valve
• A leaf basket
HIGH SUCTION
POWER.
HOSE LENGTH: 12 x 1 m hose
sections
ROBOT DIMENSIONS
(L X D X H): 40,5x46x36 cm
ROBOT WEIGHT: 1 kg 600
F
ILTERING SURFACE
FILTRATION CAPACITY
CLEANING WIDTH: 40 cm
M
INIMUM FILTER PUMP POWER REQUIREMENT :
3/4 h.p
T
RAVELLINGSPEED: 5 m/min.
}
: ITS FUNCTIONING.
TECHNICAL CHARACTERISTICS:
LEAF BASKET
CLIMBS THE
POOL WALLS.
: FOR USE WITH WHAT TYPES OF POOL?
COMES WITH:
Pool filtration
system
The "Diaphragm", exclusive technology by Zodiac,
moves a step further for the very best cleaning results.
By inventing the Diaphragm, the motor component of hydraulic-suction pool
cleaners, Zodiac revolutionised the swimming pool industry.
This system is the result of exclusive expertise and know-how, and confers
unique features to automatic pool cleaners: high-speed mobility, exceptional
suction capacity for all types of debris, highly efficient even with low output
pumps used in smaller pools, and super-silent operation.
But this technological gem has more to offer… Today, Zodiac improves the
system and creates the
"Long-Life Diaphragm", offering enhanced reliability
thanks to the use of highly durable materials. Who else other than Zodiac, the
pioneer of this technology, could go to such lengths to ensure maximum
comfort for swimming pools?
Automatic suction c leaner
POOL In-ground pools.
SHAPE Rectangular, oval or custom shapes.
BOTTOM All types of pool floors
(
flat, gently sloping, diving area with
complex slopes or diamond-shaped diving area).
SURFACE All surfaces
(tiling, liner, Polyester skin, reinforced PVC or painted concrete).
HIGHLY
RESISTANT
TWO-TONE HOSES.
X 12
Filter Filter pump
Leaf basket Vaccum point
Deflector
Disk
equipped
with
ailerons
Hose
Pre-filter
EFFICIENCY
➤
Carefully studied balance designed
to ensure
perfect adherence to the
pool bottom and walls.
➤
Anti-obstacle thanks to a double
cut-out wheel and two hose
deflector wheels.
INDEPENDENT AND
AUTONOMOUS
➤
Automatic adaptationto the
filtration rate of your pool.
➤
The leaf basket delivered with
Super G+ catches the leaves before
they reach the pump basket.
MULTI-PURPOSE
➤
Cleaning of pool walls and bottom.
➤
Super G+ adapts to all types of
swimming pools.
MAXIMUM LIFE
➤
New generation Long Life
Diaphragm technology.
➤
High resistance hoses.
