ZLINE RGB30 Installation manual

Gas RanGes

Installation Guide

and Users Manual

Never sacrifice power for performance with a ZLINE range. Enjoy the
luxury of cast iron grills, triple layer insulated glass paneling, and a
high-gloss black porcelain cooktop.

Utilizing items engineered and crafted in Italy, this range is on the top
tier of technology with its advanced features and aesthetic upgrades.

CONTENTS

Installation Guide

IMPORTANT SAFETY INSTRUCTIONS 1

WARRANTY AND SERVICE 3

PRODUCT DIMENSIONS 3

BEFORE INSTALLATION 4

INSTALLING THE LEGS 6

INSTALLING THE CHAINS 7

INSTALLATION REQUIREMENTS 8

POWER RATING & ELECTRICAL CONNECTION 10

WIRING SCHEMATICS 11

GAS CONNECTION 12

GAS CONVERSION PROCEDURE 16

INSTALLATION CHECKLIST 21

FINAL PREPARATION 22

CONTENTS

Users Manual

ROOM VENTILATION 24

COOKTOP COOKING 24

USING THE OVEN 27

MAINTAINING YOUR RANGE 30

CHANGING DOORS 32

TROUBLESHOOTING 33

Thank You

We want to thank you for choosing one of our beautiful, professional ranges. We

know that you have many brands to choose from and we are thrilled that you have

decided to place one of our products in your home. Our appliances are designed

according to the strictest safety and performance standards for the North American

market. We follow the most advanced manufacturing process. Each appliance

leaves the factory after thorough quality inspection and testing. Our distributors and

our service partners are ready to answer any questions you may have regarding

installation of your ZLINE product. This manual will help you learn to use the

product in the safest, most efficient manner, and care for it so that it may give you

the highest satisfaction for years to come. This manual also includes directions for

the professional installer that will install the product in your home. We recommend

professional installation by trained personnel.

Please keep this manual for future use.

The rating tag shows the model and serial number of your range. The tag is located

under the front edge of the range cooktop. The tag is visible when the oven door is

open.

Important Appliance Information

Dealer

Model

Date Installed

Installer

Appliance Tag Here

Important Safety Instructions

An air curtain or other overhead range/cooktop hood which

WARNING

The manufacturer will not be responsible for any damage to property or to persons

caused by incorrect installation, improper use of the appliance, or failure to heed the

warnings listed.

The manufacturer reserves the right to make changes to its products when considered

necessary and useful, without affecting the essential safety and operating

characteristics.

This appliance has been designed for non-professional, domestic use only.

Do not place any pot or pan on the open oven door. The door is made of glass and

can break under the weight.

Before beginning installation, please read these instructions completely and carefully.

Please observe all local, state and national codes and ordinances. Please ensure

the range is properly grounded. The installer should leave these instructions with the

consumer who should retain for local inspectors use and for future reference. The

plug should always be accessible. Installation must conform with local codes or in

the absence of codes, the National Fuel Gas Code NSIZ223. 1/NFPA54. Electrical

installation must be in accordance with the National electrical code ANSI/NPA70-

latest edition and/or local codes. In Massachusetts: Installation must be performed

by a “Massachusetts” licensed plumber or gasfitter. A “T” handle type manual

gas valve must be installed in the gas line connected to this appliance. In Canada:

Installation must be in accordance with the current CAN/CGA-fe 149.1 National

gas installation code or CAN/CGA-B 149.2, Propane installation code and/or

local codes. Electrical installation must be in accordance with the current CSA C22.1

Canadian electrical codes Part 1 and/or local codes.

The installation of appliance designed for manufactured (mobile) home installation

must conform with the Manufactured Home Construction and Safety Standard,Title

24CFR,Part 3280 [formerly the Federal Standard for Mobile Home Construction and

Safety,Title 24,HUD(Part280)] or with local codes where applicable.

Installation of any gas-fired equipment should be made by a licensed plumber. A

manual gas shut-off valve must be installed in the gas supply line ahead of the oven

in the gas flow for safety and ease of service.

operates by blowing downward airflow onto the range, shall not be

used/installed in conjunction with this gas range.

1

Important Safety Instructions

Please read and follow these important instructions for the safety of your home and

the people living in it.

If the information in this manual is not followed exactly, a fire or explo-

WARNING

Do not store or use gasoline or any other flammable substances in the vicinity of this

or any other appliance.

NEVER use this appliance as space heater to heat or warm the room. Doing so may

result in carbon monoxide poisoning and overheating of the oven.

NEVER cover any slots, holes, or passages in the oven bottom or cover an entire

rack with materials such as aluminum foil. Doing so blocks air flow through the oven

and may cause carbon monoxide poisoning. Aluminum foil linings may also trap

heat,causing a fire hazard.

sion may result causing property damage, personal injury, or death.

Never use this appliance as a space heater to heat or warm the

WARNING

room. Doing so may result in carbon monoxide poisoning and

overheating of the oven.

What To Do If You Smell Gas

DO NOT light any appliance.

DO NOT touch any electrical switch.

DO NOT use any phone in your building.

DO NOT use any aerosol cans or combustibles.

Immediately call your gas supplier from a neighbor’s phone, follow the gas supplier’s

instructions.

In the case you cannot reach the gas supplier, call the fire department.

Installation and service must be conducted by a qualified installer, service agency, or

the gas supplier.

2

Warranty and Service

Warranty and Service

All range products carry a one year parts warranty and includes service, if required.

Service on all products shall be carried out by industry professionals only. For

warranty service, please call customer service.

Replacement Parts

Only authorized replacement parts may be used in performing service on this

appliance.
Replacement parts are available from ZLINE. Call 1-614-777-5004.

Product Dimensions

Internal Dimensions

36” Model: 30.5”W x 18.5”D x 15”H
30” Model: 26.5” W x 18.5”D x 15”H

3

Before Installation

This appliance shall only be installed by an authorized professional.

The appliance shall be installed in accordance with the standards of the country

where it will be installed. The installation of this appliance must conform to local

codes and ordinances. In the absence of local codes installation must conform to

American National Standards, National fuel Gas code ANSI Z223.1-Latest edition/

NFPA 54 or B 149.1.

The appliance, when installed, must be electrically grounded in accordance with

local codes or, in the absence of local codes, with the National Electrical code,

ANSI/NFPA 70.

If local codes permit, a flexible metal appliance connections with the new AGA or

CGA certified design, max 5 feet (1.5m) long, 34˝m is recommended for connecting

this appliance to the gas supply line. DO NOT bend or damage the flexible

connector when moving the appliance.

This appliance must be used with the pressure regulator provided. The regulator must

be properly installed in order to be accessible when the appliance is installed in

its final location. The pressure regulator must be set for the type of gas to be used.

The pressure regulator has 34˝ female pipe thread. The appropriate fitting must be

determined based on the size of your gas supply line, the flexible metal connector

and the shut-off valve.

The appliance must be isolated from the gas supply piping system by closing its

individual manual shut-off valve during any pressure testing of the gas supply piping

system at test pressures equal to or less than 34 PSI(13,8w.cpr 3,5kPA).

All opening holes in the wall and floor, back and under the appliance shall be sealed
before installation of the appliance.

A manual valve shall be installed in an accessible location in the gas line external to

the appliance for the purpose of turning on and shutting off the gas to the appliance.

Do not use aerosol sprays in the vicinity of this appliance while it is hot.

WARNING

4

Before Installation

Room Ventilation

An exhaust fan may be used with the appliance; in each case it shall be installed

in conformity with the appropriate national and local standards. Exhaust hood

operation may affect other vented appliances; in each case it shall be installed in

conformity with the appropriate national and local standards.

Type of Gas

This appliance is shipped from the factory for use with natural gas. For use with

propane LP gas, please follow the conversion procedure described on pg. 18. A step

by step conversion procedure is also included with each set of LP gas nozzles.

Gas Pressure

The maximum inlet gas supply pressure incoming to the gas appliance pressure

regulator is 34PSI (13,8w. cpr 3,5kPA).

The minimum gas supply pressure for checking the regulator setting shall be at least

1˝ w.c (249 Pa) above the inlet specified manifold pressure to the appliance (This

operating pressure is 4˝ w.c. (1.00kPa) for Natural gas and 11˝ w.c. (2.75 kPa) for

LP gas.

Gas cooktop requires 1”- 6” side wall spacing above the counter height for

proper combustion. Please review specific model installation instructions for

required dimensions. 30 inches between the cooktop and bottom of the cabinet

above. 0.25 inches for sides below countertop height.

NOTE: Please consult your local building codes for variations with installation.

5

Installing the Legs

Installing the Legs

The ranges must be used with the legs properly installed. Height-adjustable legs are

shipped with the range in a foam container above the range.

1. Before installing the legs, position the appliance near its final location, as the legs

are not suitable for moving the appliance over long distances.

2. After unpacking the range, raise it enough to insert the legs in the appropriate

receptacles situated on the lower part of the appliance. Lower the range gently to

keep any undue strain from legs and mounting hardware.

3. Adjust leg height to the desired level by twisting the inside portion of the leg

assembly until the proper height is reached. Check with a level that the cooktop is

perfectly level.

Installing the square covers

DuraSnow® Stainless Steel ranges come with attachable square leg covers. To

install, loosen the round leg from the range to accommodate for the square leg. Align

the top of the square leg (with the slit) to the top of the round legs and slide in. Adjust

the square leg and the round leg until they are flushed with the ground.

6

Note: If the range is not level, the cooking will be uneven.

When adjusting the legs, ensure they are the same height.
