F18Standalone Reader Controller
Features:
2.4” TFT-LCD color screen
Standard Wiegand Input and Output interfaces are compatible with most all 3rd party 26-bit Wiegand readers and access control panels.
USB HOST port makes offline data backup/management fast & easy.
Relay contacts for alarm, electric lock, exit button, and wired door bell.
Reads fingerprint, Password and card
Specifications:
Fingerprint capacity |
3,000 |
Transaction capacity |
100,000 |
Hardware Platform |
ZEM720 |
CPU |
ZK 6001, 400Mhz |
Memory |
64M Flash, 32MSDRAM |
Fingerprint Sensor |
ZK optical sensor |
Display |
2.4” TFT LCD color screen |
LED Indicator |
Red, Green |
Communication |
Ethernet 10/100M , RS485, USB- |
|
HOST, |
Weigand signal |
Weigand Input and Weigand Output |
Identification speed |
≤2 sec |
FAR |
≤0.0001% |
FRR |
≤1% |
Operating Temperature |
0-45 |
Operating Humidity |
20%-80% |
Language |
English and Spanish |
Power Supply |
12V DC, 3A |
Access control interfaces |
Electric lock, alarm, exit button, wired |
|
door bell |
Dimensions |
3.15* 7.2* 1.65 inches |
|
80*183*42 mm (L*W*D) |
201 Circle Drive N, Suite 116 Piscataway, NJ 08854 Tel: 732-412-6007 Fax: 732-412-6008 www.zkaccess.com
Basic Contents:
F18 Fingerprint |
|
Metallic Mounting Plate |
Wall Mounting Screws and |
|
|
Holders |
|||
Reader |
|
|
||
|
|
|
|
|
Star-shape Screw for |
Star-shape Screw Driver |
Mini-USB Cable |
||
Mounting Plate |
|
|
||
|
|
|
|
|
Software CD |
|
Installation Guide |
Mounting Paper |
|
|
|
|
|
|
Optional Accessories |
|
|
|
|
|
|
|
|
|
FR1200 Fingerprint Slave |
K1 Exit Button |
12V3A Power Adaptor |
||
Reader |
|
|||
|
|
|||
|
|
|
|
|
Mifare
Integrated Module and Card
Front
201 Circle Drive N, Suite 116 Piscataway, NJ 08854 Tel: 732-412-6007 Fax: 732-412-6008 www.zkaccess.com
Side
Rear
201 Circle Drive N, Suite 116 Piscataway, NJ 08854 Tel: 732-412-6007 Fax: 732-412-6008 www.zkaccess.com
Installation Diagram
Product Dimensions (mm)
201 Circle Drive N, Suite 116 Piscataway, NJ 08854 Tel: 732-412-6007 Fax: 732-412-6008 www.zkaccess.com
201 Circle Drive N, Suite 116 Piscataway, NJ 08854 Tel: 732-412-6007 Fax: 732-412-6008 www.zkaccess.com
Cable Specifications
