Declaration of Conformity
We, Manufacturer
ZIPPY TECHNOLOGY CORP.
10F,No.50,MIN CHYUAN RD.
SHIN-TIEN, TAIPEI HSIEN
TAIWAN, R.O.C.
declare that the product
(description of the apparatus, system, installation to which it refers)
SWITCHING POWER SUPPLY
R2G-6350P
is in conformity with
(reference to the specification under which conformity is declared)
i in accordance with 2004/108/EC-EMC Directive
▓
EN 55022 : 2006+A1/2007
Information technology equipment
-Radio disturbance characteristics
-Limits and methods of measurement
▓
EN 55024 : 1998+A1/2001+A2/2003
Information technology equipment
-Immunity characteristics
-Limits and methods of measurement
▓
EN 61000-4-2 : 2009 Criteria B
Electrostatic discharge
requirements "ESD"
▓
EN 61000-4-3 : 2006+A1/2008 Criteria A
Radiated, radio frequency
electromagnetic field
▓
EN 61000-4-4 : 2004 Criteria B
Electrical fast transient
requirements "EFT"
Manufacturer
▓
EN 61000-4-5 : 2006 Criteria B
Surge Immunity
requirements
▓
EN 61000-4-6 : 2007 Criteria A
Conducted Immunity
▓
EN 61000-4-8 : 1993+A1/2001 Criteria A
Power Frequency Magnetic
Field Immunity
▓
EN 61000-4-11 : 2004
Dip Criteria B
Interruptions Criteria C
Voltage Dip,interruptions
Immunity requirements
▓
EN 61000-3-2 : 2006
Harmonic current
requirements
▓
EN 61000-3-3 : 2008
Voltage fluctuations
and flicker
requirements
Test-Lab
Date : JUN,01,2010
Signature:
Name: ZIPPY
Date : JUN,01,2010
Signature:
Name: ZIPPY
MODEL : R2G-6350P REPORT NO. : 10060102
APPLICATION FOR CERTIFICATION
ON Behalf Of
ZIPPY TECHNOLOGY CORP.
SWITCHING POWER SUPPLY
Model# : R2G-6350P
FCCID:N/A
PREPARED FOR：
ZIPPY TECHNOLOGY CORP.
10F,No.50,MIN CHYUAN RD.
SHIN-TIEN, TAIPEI HSIEN
TAIWAN, R.O.C
REPORT BY
：
ZIPPY TECHNOLOGY CORP.
10F,No.50,MIN CHYUAN RD.
SHIN-TIEN, TAIPEI HSIEN
TAIWAN, R.O.C
TEL： (02)2918-8512
FAX：(02)2913-4969
2
MODEL : R2G-6350P REPORT NO. : 10060102
TABLE OF CONTENTS
Description
1. Test Report Certification
2. General Information
2.1 Production Description
2.2 Tested System Details
2.2.1 Resistor Load
2.3 Test Methodology
2.4 Test Facility
3. Electronic-Magnetic Interference Test
3.1. Conducted Power Line Test
3.1.1 Test Equipments
3.1.2 Block Diagram of Test Setup
3.1.3 Conducted Powerline Emission Limit
3.1.4 EUT Configuration on Measurement
3.1.5 EUT Exercise Software
……………………………………………………………..
…………………………………………………………………..
………………………………………………………………….……..
……………………………………………………………….………...
……………………………………………………………………………..
……………………………………………………………………………..
…………………………………………………………………………………….
……………………………………………………………..…..
………………………………………………………………………….
……………………………………………………………
………………………………………………….
……………………………………………………
…………………………………………………………….…….
………………………………….…..…...
Page
5
6
6
7
7
7
7
8
8
8
8
9
9
9
3.1.6 Conducted Emission Data
………………………………………………………….…….
3.2. Radiation Emission Test .........................................................……….............………… 11
3.2.1 Test Equipment ....................................................................……...............………... 11
3.2.2 Test Setup ...........................................................……................................………... 11
3.2.3 Radiated Emission Limited ....................................…….............................……….. 12
3.2.4 EUT Configuration ...................................................……..........................………... 13
3.2.5 Operating Condition of EUT .......................................…….......................………... 13
3.2.6 Radiated Emission Data .....................................................…….................……….. 13
3.2.7 Test Photo and Setup ..................................................…….................……………. 13
4. ESD Measurement
4.1 Test Equipments
4.2 Test Setup
4.2.1 Block Diagram of Connections between EUT and simulators
4.2.2 Test Setup of EUT
4.3 Severity Levels
4.4 EUT Operating Condition
………………………………………………………………………………….……
……………………………………………………………………..
………………………………………………………………………………..
……………………….
…………………………………………………………………….…..
…………………………………………………………………………………
……………………………………………………………………..
9
17
17
17
17
17
18
18
4.5 Test Procedure
4.6 Test Method
4.7 Test Result
………………………………………………………………………….………
…………………………………………………………………….……….……..
……………………………………………………………………………………..
3
18
18
19
MODEL : R2G-6350P REPORT NO. : 10060102
TABLE OF CONTENTS
Description
5. Radiated Susceptibility Measurement
5.1 Test Equipment
5.2 Block Diagram of Test Setup
5.3 Severity Levels
5.4 EUT Operating Condition
5.5 Test procedure
5.6 Test Method
5.7 Test Result
6.Electrical Fast Transient/Burst Measurement
6.1 Test Equipment
6.2 Block Diagram of Test Setup
6.3 Severity Levels
6.4 EUT Operating Condition
6.5 Test procedure
…………………………………………….
…………………………………………………………………………….…...
…………………………………………………………………
………………………………………………………………………….……..
……………………………………………………………………..
…………………………………………………………………….…….……..
……………………………………………………………………………….……
……………………………………………………………………………………..
…………………………………………………………………………….…
…………………………………………………………………
………………………………………………………………………………..
…………………………………………………………………….
……………………………………………………………………….………..
……………...…………………..
Page
20
20
20
21
21
21
21
22
23
23
23
23
24
24
6.6 Test Method
6.7 Test Result
7. Harmonic Current Requirements
8. Voltage Fluctuation and Filcker Test
9. Surge Immunity Test
10. Conducted Immunity Test
11. Voltage Dip,interruptions Immunity Test
12. Photographs
…………………………………………………………………………………….
……………………………………………………………………………………..
…………………………………………………
……………………………………………..
………………………………………………………………….
………………………………………………………….
……………………………………...
……………………………………………………………………………
13. EMI Reduction method during compliance Testing
Appendix A Circuit diagram, block diagram, User Manual
Appendix B Doc
…………………………
24
25
26
29
30
31
32
33
39
4
MODEL : R2G-6350P REPORT NO. : 10060102
1. Test Report Certification
Applicant
：
ZIPPY TECHNOLOGY CORP.
：
MEASUREMENT PROCEDURE USED :
EN 55024 RULES
EN 55022 RULES
THE DEVICE DESCRIBED ABOVE WAS TESTED BY ZIPPY SHIN JIUH CORP. TO
DETERMINE THE SEVERITY LEVELS THE DEVICE CAN ENDURE AND ITS
PERFORMANCE CRITERION.
THE MEASUREMENT RESULTS ARE CONTAINED IN THIS TEST REPORT AND
ZIPPY SHIN JIUH CORP. IS ASSUMED FULL RESPONSIBILITY FOR THE
ACCURACY AND COMPLETENESS OF THESE MEASUREMENT.
ALSO, THIS REPORT SHOWS THAT THE EUT TO BE TECHNICALLY COMPLIANT
WITH THE EN STANDARD.
Manufacturer
EUT Description
(A) FCC ID
(B) Model No.
(C) Serial No.
(D) Power Supply
ZIPPY TECHNOLOGY CORP.
：
Switching Power Supply
：
N/A
：
R2G-6350P
：
N/A
：
115Vac/60Hz,230Vac/50Hz
Test Dated
Test Engineer
Approve & Authorized Signer
：
：
：
JUN,01,2010
a
5
MODEL : R2G-6350P REPORT NO. : 10060102
2. General Information
2.1 Production Description
：
Description
Model Number
Applicant
Switching Power Supply
：
R2G-6350P
：
ZIPPY TECHNOLOGY CORP.
Address
FCC ID
Data Cable
PowerCord
10F,No.50,MIN CHYUAN RD. SHIN-TIEN,
：
TAIPEI HSIEN TAIWAN, R.O.C
：
N/A
：
N/A
：
Non-Shielded, detachable, 1.5m
6
MODEL : R2G-6350P REPORT NO. : 10060102
2.2 Tested System Details
The FCC IDs for all equipment, plus descriptions of all cables used in the tested system
(including inserted cards, which have grants) are:
2.2.1 Resistor Load
Model Number : ELECTRONIC LOAD
Serial Number : N/A
FCC ID : N/A
Manufacturer : ZIPPY
Power : 350W
2.3 Test Methodology
EMI Test:
Both conducted and radiated testing were performed according to the procedures in EN 55022
Radiated testing was performed at an antenna to EUT distance of 10 meters.
EMS Test:
Performed according to procedures in EN 61000 series regulations.
2.4 Test Facility
ZIPPY TECHNOLOGY CORP.
10F,No.50,MIN CHYUAN RD.
SHIN-TIEN, TAIPEI HSIEN
TAIWAN, R.O.C
7
MODEL : R2G-6350P REPORT NO. : 10060102
r
r
r
r
pply
d
(
)
r
3. Electronic-Magnetic Interference Test
3.1 Conducted Power Line Test
3.1.1 TEST Equipment's
The following test equipment's are used during the conducted power line tests:
Item Instrument Manufacture Type No: Last Calibration
1 TEST RECEIVER ROHDE & SCHWARZ ESHS10 Mar.,2010
2 LISN ROHDE & SCHWARZ ENV4200 Jan.,2010
3 COMPUTER Acer Power8000 N/A
4 PRINTER EPSON 5700L N/A
5 SHIELDED ROOM 4.0M*3.0M*3M N/A
3.1.2 Block Diagram of Test Setup
TO
Power Line
Transforme
Test Receive
Personal Compute
Printer/Plotte
L.I.S.N
Pulse Limite
EUT
Switch Power Su
Loa
Active
L.I.S.NTerminato
AC IN
8
MODEL : R2G-6350P REPORT NO. : 10060102
3.1.3 Conducted Powerline Emission Limit
Maximum RF Line Voltage dB(uV)
Frequency Class B
MHz QUASI-PEAK AVERAGE
0.15 - 0.50 66-56 66-56
0.50 - 5.0 56 56
5.0 - 30 60 60
Remarks : In the Above Table, the tighter limit applies at the band edges.
3.1.4 EUT Configuration on Measurement
The equipment's which is listed 3.2 are installed on Conducted Power Line Test to meet the
Commission requirement and operating in a manner which tends to maximize its emission
characteristics in a normal application.
3.1.5 EUT Exercise Software
The EUT exercise program used during conducted testing was designed to exercise the EUT in a
manner similar to a typical use. The exercise sequence is listed as below :
3.1.5.1 Setup the EUT and simulators as shown on 3.2.
3.1.5.2 Turn on the power of all equipment's.
3.1.6 Conducted Emission Data
The measurement range of conducted emission which is from 0.15 MHz to 30 MHz was
investigated. The initial step in collecting conducted data is a spectrum analyzer peak scan of the
measurement range for all the test modes. Then the worst modes were reported the following data
pages.
9
MODEL : R2G-6350P REPORT NO. : 10060102
Conducted Emission Data
DATE OF TEST
EUT
TEST MODE
Frequency Reading Level dBuV Limites
MHz Line 1 Line 2 DBuV
0.152 45.66 44.73 65.89
0.186 40.28 39.98 64.21
：
JUN,01,2010 TEMPERATURE
：
SWITCH POWER SUPPLY HUMIDITY
：
R2G-6350P
DISPLAY PATTERN ：N/A
：26℃
：65％
Remark：All readings are Quasi-Peak values.
10
ZIPPY EMC LAB
conduction test
EUT:
Manuf:
Op Cond:
Operator:
Test Spec:
Comment:
R2G-6350P SPS
ZIPPY TECH CO..LTD
FULL LOAD
EN 55022-- Class B
Load Condition(15 20 0.5 0.8 14 2)
L220V
Scan Settings
Start Stop Step IF BW Detector M-Time Atten Preamp OpRge
150kHz 500kHz 2kHz 10kHz QP+AV 1msec Auto OFF 60dB
500kHz 5MHz 20kHz 10kHz QP+AV 1msec Auto OFF 60dB
5MHz 30MHz 50kHz 10kHz QP+AV 1msec Auto OFF 60dB
Transducer No. Start Stop Name
Prescan Measurement: Detectors: X QP / + AV
dBµV
100
90
80
(3 Ranges)
Frequencies
1 9kHz 30MHz CEB
Meas Time:
Peaks:
Acc Margin:
see scan settings
8
25 dB
EN_QP_B EN_AV_B
Receiver Settings
70
60
50
40
30
20
10
0
30.00.15 1.0 10.0
MHz
PAGE 1
ZIPPY EMC LAB
conduction test
EUT:
Manuf:
Op Cond:
Operator:
Test Spec:
Comment:
R2G-6350P SPS
ZIPPY TECH CO..LTD
FULL LOAD
EN 55022-- Class B
Load Condition(15 20 0.5 0.8 14 2)
L220V
Scan Settings
Start Stop Step IF BW Detector M-Time Atten Preamp OpRge
150kHz 500kHz 2kHz 10kHz QP+AV 1msec Auto OFF 60dB
500kHz 5MHz 20kHz 10kHz QP+AV 1msec Auto OFF 60dB
5MHz 30MHz 50kHz 10kHz QP+AV 1msec Auto OFF 60dB
Transducer No. Start Stop Name
Prescan Measurement: Detectors: X QP / + AV
Peak Search Results
Frequency
MHz
0.152 45.66 65.89 20.23 N gnd
0.156 45.66 65.67 20.01 N gnd
0.166 42.99 65.16 22.17 N gnd
0.186 40.28 64.21 23.93 N gnd
0.234 37.63 62.31 24.68 N gnd
(3 Ranges)
Frequencies
1 9kHz 30MHz CEB
see scan settings
8
25 dB
QP Delta
dB
QP Level
dBµV
Meas Time:
Peaks:
Acc Margin:
QP Limit
dBµV
Phase
-
Receiver Settings
PE
-
Frequency
MHz
0.15 36.54 56.00 19.46 N gnd
0.156 37.94 55.67 17.73 N gnd
0.186 36.02 54.21 18.19 N gnd
0.234 35.71 52.31 16.60 N gnd
0.28 32.49 50.82 18.33 N gnd
0.298 31.57 50.30 18.73 N gnd
0.302 32.57 50.19 17.62 N gnd
0.326 30.07 49.55 19.48 N gnd
* limit exceeded
Indicated Phase/PE shows Configuration of max. Emission
AV Level
dBµV
AV Limit
dBµV
AV Delta
dB
PAGE 2
Phase
-
PE
-
ZIPPY EMC LAB
conduction test
EUT:
Manuf:
Op Cond:
Operator:
Test Spec:
Comment:
R2G-6350P SPS
ZIPPY TECH CO..LTD
FULL LOAD
EN 55022-- Class B
Load Condition(15 20 0.5 0.8 14 2)
N220V
Scan Settings
Start Stop Step IF BW Detector M-Time Atten Preamp OpRge
150kHz 500kHz 2kHz 10kHz QP+AV 1msec Auto OFF 60dB
500kHz 5MHz 20kHz 10kHz QP+AV 1msec Auto OFF 60dB
5MHz 30MHz 50kHz 10kHz QP+AV 1msec Auto OFF 60dB
Transducer No. Start Stop Name
Prescan Measurement: Detectors: X QP / + AV
dBµV
100
90
80
(3 Ranges)
Frequencies Receiver Settings
1 9kHz 30MHz CEB
Meas Time:
Peaks:
Acc Margin:
see scan settings
8
25 dB
EN_QP_B EN_AV_B
70
60
50
40
30
20
10
0
30.00.15 1.0 10.0
MHz
PAGE 1
ZIPPY EMC LAB
conduction test
EUT:
Manuf:
Op Cond:
Operator:
Test Spec:
Comment:
R2G-6350P SPS
ZIPPY TECH CO..LTD
FULL LOAD
EN 55022-- Class B
Load Condition(15 20 0.5 0.8 14 2)
N220V
Scan Settings
Start Stop Step IF BW Detector M-Time Atten Preamp OpRge
150kHz 500kHz 2kHz 10kHz QP+AV 1msec Auto OFF 60dB
500kHz 5MHz 20kHz 10kHz QP+AV 1msec Auto OFF 60dB
5MHz 30MHz 50kHz 10kHz QP+AV 1msec Auto OFF 60dB
Transducer No. Start Stop Name
Prescan Measurement: Detectors: X QP / + AV
Peak Search Results
Frequency
MHz
0.152 44.73 65.89 21.16 N gnd
0.16 45.36 65.46 20.10 N gnd
0.186 39.98 64.21 24.23 N gnd
20.2 35.19 60.00 24.81 N gnd
(3 Ranges)
Frequencies Receiver Settings
1 9kHz 30MHz CEB
QP Level
dBµV
Meas Time:
Peaks:
Acc Margin:
QP Limit
dBµV
see scan settings
8
25 dB
QP Delta
dB
Phase
-
PE
-
Frequency
MHz
0.15 38.25 56.00 17.75 N gnd
0.16 41.89 55.46 13.57 N gnd
0.186 35.05 54.21 19.16 N gnd
0.234 36.11 52.31 16.20 N gnd
0.282 31.96 50.76 18.80 N gnd
0.3 30.76 50.24 19.48 N gnd
0.322 30.26 49.66 19.40 N gnd
20.2 32.01 50.00 17.99 N gnd
* limit exceeded
Indicated Phase/PE shows Configuration of max. Emission
AV Level
dBµV
AV Limit
dBµV
AV Delta
dB
PAGE 2
Phase
-
PE
-
MODEL : R2G-6350P REPORT NO. : 10060102
3.2 Radiation Emission Test
3.2.1 Test Equipment
The following test equipment's are used during the radiated emission test :
Instrument Manufacture Type No: Last Calibration
Spectrum Analyzer H.P 8594A May.,2010
Test Receiver IFR System A-7550 Jun.,2010
Preamplifier H.P 8447D May.,2010
Biconical Ant. Emco 3110 Jun.,2010
Log-Periodic Ant. Emco 3146 Jun.,2010
Dipole Antenna Emco 3121C May.,2010
3.2.2 Test Setup
3.2.2.1 Block Diagram of Connection between EUT and simulators
Equipment under Test
Load
EUT: SWITCHING POWER SUPPLY
11
MODEL : R2G-6350P REPORT NO. : 10060102
3.2.2.2 Open Field Test Site - description
The open field test site (OFTS) is designed to provide an environment in which repeatable tests of
radiated emissions can be carried out.
It consists of a flat elliptical area as shown in the diagram below.
The equipment under test and the antenna are placed at the foci of the ellipse.
The antenna height should be remotely adjustable from 1m to 4m. Measuring instrumentation
should be outside the ellipse at the position shown or in a room under the ground plane.
The whole or part of the site may be enclosed in an RF transparent building.
For precompliance testing a 3m test site with a fixed height antenna (at 1.5-2m height) and no
metallic ground plane may be used. This may be a clear area on a car park or a grass area but should
be away from large metallic structures.
3.2.3 Radiated Emission Limit
Class B Limits
Frequency Distance Field Strength
MHz Meter DB(uV/M)
30-230 3 40
230-1000 3 47
Remarks :
1. The tighter limit shall apply at the edge between two frequency bands.
2. Distance refers to the distance in meters between the measuring instrumentantenna and the
closed point of any part of the device or system.
12
MODEL : R2G-6350P REPORT NO. : 10060102
3.2.4 EUT Configuration
The equipment's which is listed 4.2.1 are installed on Radiated Emission Test to meet the
Commission requirement and operating in a manner which tends to maximize its emission
characteristics in a normal application.
3.2.5 Operation Condition of EUT
Same as Conducted Power Line Test which is listed in 3.1.5 .
3.2.6 Radiated Emission Data
The measurement range of radiated emission which is from 30 MHz to 1000 MHz was investigated.
The initial step in collecting conducted data is a spectrum analyzer peak scan of the measurement
range for all the test modes. Then the worst modes were reported the following data pages.
3.2.7 Test Photo and Setup
※
During the radiated test, the power-supply has to test with chassis, which is not allowed to be
operated stand-alone. (For user, final assembly has to comply with corresponding EMC-and
safety-regulations.)
13
MODEL : R2G-6350P REPORT NO. : 10060102
Radiated Emission Data
DATE OF TEST
EUT
TEST MODE
Frequency
(MHz) dBuV/m dBuV/m
30-230 <30 47.0
230-1000 <35 47.0
：
JUN,01,2010 TEMPERATURE
：
SWITCH POWER SUPPLY HUMIDITY
：
R2G-6350P
DISPLAY PATTERN ：N/A
：26℃
：65％
Emission Level
Limits
Horizontal
Remark
14
MODEL : R2G-6350P REPORT NO. : 10060102
Radiated Emission Data
：
DATE OF TEST
EUT
TEST MODE
Frequency
(MHz) dBuV/m dBuV/m
30-230 <30 47.0
230-1000 <35 47.0
JUN,01,2010 TEMPERATURE
：
SWITCH POWER SUPPLY HUMIDITY
：
R2G-6350P
Emission Level
Vertical
：26℃
：65％
DISPLAY PATTERN ：N/A
Limits
Remark
15
MODEL : R2G-6350P REPORT NO. : 10060102
Horizontal Curve
Vertical Curve
16
MODEL : R2G-6350P REPORT NO. : 10060102
4. ESD Measurement
4.1 Test Equipment
The following test equipment's are used during the ESD test :
Instrument Manufacture Type No: Last Calibration
ESD Simulator system Keytek MZ-15/EC May.,2010
Electronic Load D-RAM Load-2000 N/A
4.2 Test Setup
4.2.1 Block Diagram of Connections between EUT and simulators
ESD
Simulator
system
4.2.2 Test Setup of EUT
EUT Load
17
MODEL : R2G-6350P REPORT NO. : 10060102
4.3 Severity Levels
TEST VOLTAGE CONTACT
TEST VOLTAGE AIR
LEVEL
DISCHARGE
DISCHARGE
1 2KV 2KV
2 4KV 4KV
3 6KV 6KV
4 8KV 8KV
X SPECIAL SPECIAL
4.4 EUT Operating Condition
1. Setup the EUT and Test Equipment as shown on 4.2
2. power on.
4.5 Test Procedure
Air Discharge:
This test was done above a non-conductive surfaces. The round discharge electrode about 30cm
away will approach as fast as possible to touch test points of the EUT.
Discharge happens before the contact. This procedure is repeated ten times on one selected location.
4.6 Test Method
According to IEC 61000-4-2
18
MODEL : R2G-6350P REPORT NO. : 10060102
4.7 Test Result
DATE OF TEST
EUT
TEST MODE
：
JUN,01,2010 TEMPERATURE
：
SWITCH POWER SUPPLY HUMIDITY
：
R2G-6350P
Item Amount of discharge Voltage Results
Contact discharge 500
Contact discharge 500
：26℃
：65％
DISPLAY PATTERN ：N/A
+2KV
-2KV
+4KV
-4KV
Pass
Pass
Pass
Pass
Air discharge 500
Air discharge 500
Air discharge 500
Air discharge 500
※
Input Voltage : AC 230Vac/50Hz
+2KV
-2KV
+4KV
-4KV
+6KV
-6KV
+8KV
-8KV
Pass
Pass
Pass
Pass
Pass
Pass
Pass
Pass
19
MODEL : R2G-6350P REPORT NO. : 10060102
5. Radiated Susceptibility Measurement
5.1 Test Equipment
The following test equipment's are used during the RS test :
Instrument Manufacture Type No: Last Calibration
Signal generator H.P 8657A Dec.,2009
Power amplifier A&R 100A100 Dec.,2009
Field strength meter A&R FM2000 Oct.,2009
Field strength sensor A&R EP2000 Oct.,2009
Power antenna A&R AT1080 Oct.,2009
5.2 Block Diagram of Test Setup
Antennas-layout
For the upper frequency range of 200 to 1000 MHz, antennas are the normal method of producing
the required field strength. This is also carried out in an anechoic chamber or a screened room. If a
screened room is used it must be damped . The anechoic chamber should be used for compliance
testing, the screened room may be used for precompliance testing. The fields in the screened room
will not be as uniform as those obtainable in an anechoic chamber and will also not be as repeatable.
The EUT is placed on a non-conductive table, 0.8 m above the reference ground plane, which in
many cases will be the floor of a screened room. According to the standards, the EUT should be
oriented so that its most sensitive side is facing the antenna. In practice it can be difficult to decide
beforehand which is the most sensitive side, and in most cases, a series of tests will be required with
the EUT in several orientations.
20
MODEL : R2G-6350P REPORT NO. : 10060102
5.3 Severity Levels
LEVEL FIELD STRENGTH V/M
1 1
2 3
3 10
X SPECIAL
5.4 EUT Operating Condition
Same as section 4.4.
5.5 Test Procedure
The EUT and load are placed on a table which is 0.8 meter above ground. The field sensor is
also placed on the same table to monitor field strength from transmitting antenna.
EUT is set 1 meter away from the transmitting antenna which is mounted on an antenna each
time.
The antenna is fixed 1 meter above ground. Both horizontal and vertical polarization of the
antenna are set on measurement. In order to judge the EUT performance, a CCD camera is
used to monitor EUT screen.
All the scanning conditions are as follows :
Condition of Test Remarks
1. Field Strength 3 V/M Level 2
2. Radiated Signal 80% Amplitude Modulated with a 1KHz Tone
3. Scanning Frequency 80 MHz-1 GHz
4. Sweep Time of Radiated 0.0015 Decade/s
5.6 Test Method
According to IEC 61000-4-3
21
MODEL : R2G-6350P REPORT NO. : 10060102
5.7 Test Result
DATE OF TEST
EUT
TEST MODE
Frequency Range
(MHz)
80-1000
80-1000
80-1000
80-1000
80-1000
：
JUN,01,2010 TEMPERATURE
：
SWITCH POWER SUPPLY HUMIDITY
：
R2G-6350P
Position
(Angle)
90∘
180∘
270∘
0∘
(Front) H 3 Pass
(Right) H 3 Pass
(Back) H 3 Pass
(Left) H 3 Pass
0∘
(Front) V 3 Pass
DISPLAY PATTERN ：N/A
Polarity
(HorV)
Field Strength
(V/M)
：26℃
：65％
Results
80-1000
80-1000
80-1000
Test Result：Criteria A
90∘
180∘
270∘
(Right) V 3 Pass
(Back) V 3 Pass
(Left) V 3 Pass
22
MODEL : R2G-6350P REPORT NO. : 10060102
6. Electrical Fast Transient / Burst Measurement
6.1 Test Equipment
The following test equipment's are used during the EFT tests :
Instrument Manufacturer Type No. Last Calibration
Fast Transient / Burst enerator Keytek EMCpro May.,2010
6.2 Block Diagram of Test Setup
6.3 Severity Levels
Level On power supply lines
1 0.5KV
2 1KV
3 2KV
4 4KV
X SPECIAL
Open Circuit Output Test Voltage +/- 10%
23
MODEL : R2G-6350P REPORT NO. : 10060102
6.4 EUT Operation Condition
Same as section 4.4.
6.5 Test Procedure
The EUT and its load are placed on a table which is 0.8 meter above a metal ground plane
measured 1m*1m min. And 0.65 mm thick min. And projected beyond the EUT by at least
0.1m on all sides.
The EUT is away from the walls of the test AC power line test is as follows:
For Ac power line test:
The EUT is connected to the power mains through a coupling device that directly couples the
EFT interference signal.
Each of the Line and Neutral conductor is impressed with burst noise for 1 min.
6.6 Test Method
According to IEC 61000-4-4.
24
MODEL : R2G-6350P REPORT NO. : 10060102
6.7 Test Result
：
DATE OF TEST
EUT
TEST MODE
JUN,01,2010 TEMPERATURE
：
SWITCH POWER SUPPLY HUMIDITY
：
R2G-6350P
Inject Line Voltage KV
L1 +/-1 60 Direct Pass
L2 +/-1 60 Direct Pass
PE +/-1 60 Direct Pass
L1-L2 +/-1 60 Direct Pass
DISPLAY PATTERN ：N/A
Inject time
(sec)
：26℃
：65％
Inject Method Result
L1-PE +/-1 60 Direct Pass
L2-PE +/-1 60 Direct Pass
L1,L2-PE +/-1 60 Direct Pass
※
Input Voltage : AC 230Vac/50Hz
25
MODEL : R2G-6350P REPORT NO. : 10060102
7. Harmonic Current Test
：
DATE OF TEST
EUT
TEST MODE
JUN,01,2010 TEMPERATURE
：
SWITCH POWER SUPPLY HUMIDITY
：
R2G-6350P
：26℃
：65％
DISPLAY PATTERN ：N/A
Reading Leve A Reading Leve A
Item
A Limites
1 2.055
3 0.338 1.605
5 0.056 0.897
7 0.036 0.472
Item
A Limites
9 0.024 0.236
11 0.014 0.165
13 0.006 0.140
15 0.009 0.121
17 0.008 0.107
19 0.009 0.096
21 0.007 0.087
23 0.007 0.079
25 0.005 0.073
27 0.004 0.067
29 0.003 0.063
31 0.001 0.059
33 0.001 0.055
35 0.002 0.052
37 0.002 0.049
39 0.003 0.047
26
MODEL : R2G-6350P REPORT NO. : 10060102
27
MODEL : R2G-6350P REPORT NO. : 10060102
28
MODEL : R2G-6350P REPORT NO. : 10060102
8. Voltage Fluctuation And Flicker Test
DATE OF TEST
EUT
TEST MODE
Item Reading Limit Result
Pst 0.000 1.00 Pass
P1t 0.000 0.65 Pass
Dc (%) 0.000 3.00 Pass
Dmax (%) 0.000 4.00 Pass
Dt (%) 0.000 0.20 Pass
：
JUN,01,2010 TEMPERATURE
：
SWITCH POWER SUPPLY HUMIDITY
：
R2G-6350P
DISPLAY PATTERN ：N/A
：26℃
：65％
29
MODEL : R2G-6350P REPORT NO. : 10060102
9. Surge Immunity Test
DATE OF TEST
EUT
TEST MODE
：
JUN,01,2010 TEMPERATURE
：
SWITCH POWER SUPPLY HUMIDITY
：
R2G-6350P
DISPLAY PATTERN ：N/A
：26℃
：65％
Wavefor Voltage Output:LC Phs Ref Phs Ang Tests Delay Result
12 Ohm -2000V MAINS:L1/PE L1 0 deg. 5 60 sec Pass
12 Ohm -2000V MAINS:L1/PE L1 90 deg. 5 60 sec Pass
12 Ohm -2000V MAINS:L1/PE L1 270 deg. 5 60 sec Pass
12 Ohm 2000V MAINS:L1/PE L1 0 deg. 5 60 sec Pass
12 Ohm 2000V MAINS:L1/PE L1 90 deg. 5 60 sec Pass
12 Ohm 2000V MAINS:L1/PE L1 270 deg. 5 60 sec Pass
12 Ohm -2000V MAINS:L2/PE L1 0 deg. 5 60 sec Pass
12 Ohm -2000V MAINS:L2/PE L1 90 deg. 5 60 sec Pass
12 Ohm -2000V MAINS:L2/PE L1 270 deg. 5 60 sec Pass
12 Ohm 2000V MAINS:L2/PE L1 0 deg. 5 60 sec Pass
12 Ohm 2000V MAINS:L2/PE L1 90 deg. 5 60 sec Pass
12 Ohm 2000V MAINS:L2/PE L1 270 deg. 5 60 sec Pass
2 Ohm -1000V MAINS:L1/L2 L1 0 deg. 5 60 sec Pass
2 Ohm -1000V MAINS:L1/L2 L1 90 deg. 5 60 sec Pass
2 Ohm -1000V MAINS:L1/L2 L1 270 deg. 5 60 sec Pass
2 Ohm 1000V MAINS:L1/L2 L1 0 deg. 5 60 sec Pass
2 Ohm 1000V MAINS:L1/L2 L1 90 deg. 5 60 sec Pass
2 Ohm 1000V MAINS:L1/L2 L1 270 deg. 5 60 sec Pass
30
MODEL : R2G-6350P REPORT NO. : 10060102
10. Conducted Immunity Test
：
DATE OF TEST
EUT
TEST MODE
Frequency Range
(MHz)
JUN,01,2010 TEMPERATURE
：
SWITCH POWER SUPPLY HUMIDITY
：
R2G-6350P
Polarity
(HorV)
0.15-80 H 3 Pass
INJECTION TYPE：DIRECT CDN Type M3
TEST CONDITION：Step:1% Dwell Time : 3sec
Test result：Criteria A
：26℃
：65％
DISPLAY PATTERN ：N/A
Field Strength
(V/M)
Results
31
MODEL : R2G-6350P REPORT NO. : 10060102
11. Voltage Dip, Interruptions Immiunity Test
DATE OF TEST
EUT
TEST MODE
Test
Voltage
Phase Duration Performance
Angle
180 deg.
270 deg.
AC 115V
180 deg.
：
JUN,01,2010 TEMPERATURE
：
SWITCH POWER SUPPLY HUMIDITY
：
R2G-6350P
DISPLAY PATTERN ：N/A
：26℃
：65％
Reduction
%
0 deg.
90 deg.
(Periods) Required Observation
0.5 B A
0.5 B A
>95%
0.5 B A
0.5 B A
0 deg.
90 deg.
25 C A
25 C A
30%
25 C A
Result
Pass
Pass
Pass
Pass
Pass
Pass
Pass
AC 230V
270 deg.
0 deg.
90 deg.
180 deg.
270 deg.
0 deg.
90 deg.
180 deg.
270 deg.
0 deg.
90 deg.
180 deg.
270 deg.
0 deg.
90 deg.
180 deg.
270 deg.
>95%
>95%
30%
>95%
25 C A
250 C C
250 C C
250 C C
250 C C
0.5 B A
0.5 B A
0.5 B A
0.5 B A
25 C A
25 C A
25 C A
25 C A
250 C C
250 C C
250 C C
250 C C
Pass
Pass
Pass
Pass
Pass
Pass
Pass
Pass
Pass
Pass
Pass
Pass
Pass
Pass
Pass
Pass
Pass
32
MODEL : R2G-6350P REPORT NO. : 10060102
12. Photographs
1.Front view of Power Supply
2.Back view of Power Supply
33
MODEL : R2G-6350P REPORT NO. : 10060102
3.Front view of Power Supply
4.Back view of Power Supply
34
MODEL : R2G-6350P REPORT NO. : 10060102
5.Component side of Mainboard
6.Solder side of Mainboard
35
MODEL : R2G-6350P REPORT NO. : 10060102
7.Component side of Mainboard
8.Solder side of Mainboard
36
MODEL : R2G-6350P REPORT NO. : 10060102
9. Inside view of Power Supply
10.Inside view of Power Supply
37
MODEL : R2G-6350P REPORT NO. : 10060102
11.Inside view of Power Supply
12.Test view
38
MODEL : R2G-6350P REPORT NO. : 10060102
13. EMI Reduction Method During Compliance Testing
1.No modification was made during test.
39
Loading...
