FLUSH MOUNT
• Die Cast Aluminum
• Size options between 4.75”, 6.25”, 8.5”, and 10.5”
• Ultra-thin ½” height with less than ¼” trim
• Available in 3000k (Made-to-order Color
Temperatures available)
• Suitable for Closets according to NEC
Section 410.8 & 410.16
• Available in White (WT), Black (BK),
Polished Chrome (PC) and Satin Nickel (SN)
• Dimmable with Triac and ELV Dimmers
• Easy to install: fits in 3-0 and 4-0 Outlet Box
(pancake and mud ring acceptable)
• Pendant light accessory available
(sold separately)
• Suitable for Wet Location, for use on
ceilings outdoor and above showers
• ETL/cETL IP65
Job Name :
Job Type :
Quantity :
Comments :
PENDANT ACCESORY
(Sold Separately,
Fixture NOT included)
PRODUCT DESCRIPTION
Thin discs of evenly illuminated LED create the impression of recessed lighting. The die-cast aluminum housings
are available in White, Black, Satin Nickel, and Polished Chrome all with a thoughtfully recessed White
polycarbonate diffuser. High efficiency and good color rendering make this a perfect choice for your next
project. Use the optional pendant adapter to convert any size to a hanging fixture.
MEASUREMENTS
H
L
W
DIMENS ION
4.75”W x 0.75”H x 4.75”L
6.25”W x 0.75”H x 6.25”L
8.5”W x 0.75”H x 8.5”L
10.5”W x 0.75”H x 10.5”L
2.25”W x 10.75”H x 2.25”L, 120”OAH
CANOPY
4.5”D x 0.5”H
6”D x 0.5”H
8.25”D x 0.5”H
10.25”D x 0.5”H
5”W x 0.25”H x 5”L
WIRE
LENGHT
8”L
8”L
8”L
8”L
120”L
LAMPING
BULB TYPE
12.5W PCB LED (Integrated)
15W PCB LED (Integrated)
18W PCB LED (Integrated)
20W PCB LED (Integrated)
CRI
90+
90+
90+
90+
COL
TEMP.
3000K
3000K
3000K
3000K
LUMENS
920
1100
1280
1450
DELRATED
875
1050
1260
1400
DIMMABLE
Triac CL
Triac CL
Triac CL
Triac CL
INPUT
120V
120V
120V
120V
FINISHES OPTIONS:
Polished Chrome (PC)
Satin Nickel (SN)
White (WT)
Black (BK)
MATERIAL:
PC + Aluminum
Shade: Polycarbonate
GLASS:
White Acrylic (WT)
AVAILABLE SIZE:
4.75” | 6.25” | 8.5” | 10.5”
RATINGS:
cETLus
Wet Location
Dimmable
Title 24 JA8 Compliant
Energy Star
ADA
Always consult a qualified electrician before installing any lighting product
ADDITIONAL:
RATED LIFE: 35,000 hours
WARRANTY: 5 Years
