ASSEMBLY INSTRUCTIONS
Read this instruction carefully. See hardwre and Furniture part list for guidance.
Be sure all parts are complate, before you assemble. Place all wooden prevent from being scratched.
Follow the figure to start assembling.
CAUTIONS: 1. Do not FULLY- TIGHTEN the nut or bolt until all nut and bolt is ready assembled.
2. Do not OVER - TIGHTEN the nut or bolt avoid causing damages to the thread.
3. Keep all hardware parts out of reach of children.
NOTE: THE LIST AND QUANTITY SHOWN ARE FOR 1 UNIT ASSEMBLY.
STEP 01
A
B
STEP 02 STEP 03 STEP 04
3
5
1
2
PART LIST
ITEM DESCRIPTION QTY
A
B
C
D
E
4
CHAIR BACK 1 PC
SIDE PANEL
STRETCHER
FRONT FRAME
CUSHION SEAT
6
2 PCS
2 PCS
1 PC
1 PC
ITEM DESCRIPTION QTY
1
SPRING WASHER M6 4 PCS
2
FLAT WASHER M6 x 13mm
3
CSK SCREW M4 x 35mm
4
5
7
HARDWARE LIST
4 PCSJCBC BOLT M6 x 50mm
4 PCS
8 PCS
1 PCALLEN KEY M4
4 PCSPAN HEAD SCREW M4 x 12mm6
2 PCSL BRACKET7
C
5
1
E
2
3
D
4
FULLY SET-UP (CHAIR)
PAGE : 1 OF 1
